A torsion sensor with directional discrimination based on a single-mode–twisted multimode–single-mode (STMS) fiber structure is demonstrated. The STMS fiber structure is fabricated by fusion-splicing a segment of multimode fiber (MMF) between two single-mode fibers (SMFs), where the MMF is simultaneously heated and twisted to form paired helical-type structures. The experimental results indicate that the resonance wavelength shifts towards shorter wavelengths as the twist rate increases in the clockwise direction, while an opposite shift occurs in the counterclockwise direction. Within a twist rate range of −5.2 rad/m~5.2 rad/m, the wavelength and transmission sensitivities are determined to be −1.38 nm/rad·m⁻¹ and 3.12 dB/rad·m⁻¹, respectively. Furthermore, the proposed twist sensor exhibits minimal temperature crosstalk of 0.0072 (rad/m)/°C, making it highly desirable for mitigating temperature-induced cross-sensitivity in torsion measurement applications. Full article

The magnetoelastic effect is known as the dependence between the magnetic properties of the material and applied mechanical stress. The stress might not be applied directly but rather generated by the applied torque. This creates the possibility of developing a torque-sensing device based on the magnetoelastic effect. In this paper, the concept of an axially twisted toroidal magnetic core as a torque-sensing element is considered. Most known works in this field consider the utilization of an amorphous ribbon as the core material. However, Ni-Zn ferrites, exhibiting relatively high magnetostriction, also seem to be promising materials for magnetoelastic torque sensors. This paper introduces a theoretical description of the magnetoelastic effect under torque operation on the basis of total free energy analysis. The methodology of torque application to the toroidal core, utilized previously for coiled cores of amorphous ribbons, was successfully adapted for the bulk ferrite core. For the first time, the influence of torque on the magnetic properties of Ni-Zn ferrite was investigated in a wide range of magnetizing fields. The obtained magnetoelastic characteristics allowed the specification of the magnetoelastic torque sensitivity of the material and the determination of the optimal amplitude of the magnetizing field to maximize this parameter. High sensitivity, in comparison with previously studied amorphous alloys, and monotonic magnetoelastic characteristics indicate that the investigated Ni-Zn ferrite can be utilized in magnetoelastic torque sensors. As such, it can be used in torque-sensing applications required in mechanical engineering or civil engineering, like the evaluation of structural elements exposed to torsion. Full article

In this work, the modeling of a demonstrator of a morphing system aimed at altering the twist of a rotorcraft blade is presented. The device was conceived for two different representative environments: the wind tunnel plant of the University of Bristol and the whirl tower facility of the DLR, for tests in fixed and wing rotary configurations, respectively. The concept, conceived and matured within the European Project of SABRE, is based on shape memory alloys, SMA. This technology was selected for its intrinsic compactness and solidity, which better meet the requirements of a typical blade structure, being extremely flexible and subjected to relevant inertial loads. A dedicated structural layout was conceived to favor the working modality of the SMA torsional system; this architecture was tailored both to absorb the typical actions occurring onto a blade and to assure a certain level of pre-twist necessary for the SMA strain recovery. The activation of the SMA was performed through an electrothermal helicoidal coil wrapped around it. A dedicated network of sensors was integrated within the structure to measure the impact of the different actions on the blade system. This subsystem, functional to shape reconstruction operations, is capable of splitting the contribution of the loads to pure twist and flapping. At first, the requirements imposed by the two test facilities were elaborated together to the operational needs, arriving at the issue of the most relevant specifications. Secondly, the conceptual and advanced design were considered, demonstrating, first, the feasibility of the concept and, then, its compliance with the test environment. The work ends with two different layouts, conceived respectively for the tests in fixed and rotary wing configurations. For both of them, a performance estimate was addressed, and a discussion on the advantages and disadvantages was presented. Full article

Similar to biological muscles in nature, artificial muscles have unique advantages for driving bionic robots. However, there is still a large gap between the performance of existing artificial muscles and biological muscles. Twisted polymer actuators (TPAs) convert rotary motion from torsional to linear motion. TPAs are known for their high energy efficiency and large linear strain and stress outputs. A simple, lightweight, low-cost, self-sensing robot powered using a TPA and cooled using a thermoelectric cooler (TEC) was proposed in this study. Because TPA burns easily at high temperatures, traditional soft robots driven by TPAs have low movement frequencies. In this study, a temperature sensor and TEC were combined to develop a closed-loop temperature control system to ensure that the internal temperature of the robot was 5 °C to cool the TPAs quickly. The robot could move at a frequency of 1 Hz. Moreover, a self-sensing soft robot was proposed based on the TPA contraction length and resistance. When the motion frequency was 0.01 Hz, the TPA had good self-sensing ability and the root-mean-square error of the angle of the soft robot was less than 3.89% of the measurement amplitude. This study not only proposed a new cooling method for improving the motion frequency of soft robots but also verified the autokinetic performance of the TPAs. Full article

A fiber-optic torsion sensor based on a helical two-core fiber (HTCF) is proposed and experimentally demonstrated for simultaneously measuring torsion angle and torsion direction. The sensor consists of a segment of HTCF and two single-mode fibers (SMFs) forming a Mach–Zehnder interferometer (MZI). The helical structure is implemented by pre-twisting a 1 cm long two-core fiber (TCF). The performance of the sensor with pre-twisted angles of 180°, 360°, and 540° is experimentally analyzed. The results show that the sensor can realize the angular measurement and effectively distinguish the torsion direction. It is worth noting that the sensor has maximum sensitivity when the pre-twist angle is 180 degrees. The obtained wavelength sensitivities of torsion and temperature are 0.242 nm/(rad/m) and 32 pm/°C, respectively. The sensor has the advantages of easy fabrication, low cost, compact structure, and high sensitivity, which is expected to yield potential applications in fields where both torsion angle and direction measurements are required. Full article

The traditional optical fiber-based twist sensing has the disadvantage of low sensitivity and difficulty of distinguishing the twist direction. Moreover, chiral isomerism may lead to sensing errors. In this paper, a six-hole helical microstructured optical fiber (HMSF) with a thin-gold-film-coat based on the surface plasmon resonance (SPR) effect was designed. The twist sensing characteristics of this fiber were further analyzed. Numerical calculation and analysis show that the combination of helical effect and SPR effect can design an HMSF-based sensor that is very sensitive to distortion. In the torsion range of ±300°, the distortion sensitivity can reach 2470.7 pm/(rad/m), and the linear correlation coefficient is 0.99996. Based on the special sensing mechanism, it has a good linear coefficient over a large range. Additionally, the direction of the twist can be easily discerned. The HMSF in this work not only has high sensitivity, high linearity, high fault tolerance rate, and a wide range of measurement, but is also easy to manufacture. Therefore, it is promising in the field of twist sensing and has a good application prospect. Full article

This paper describes an evaluation of the structural properties of the next-generation active twist blade using X-ray computed tomography (CT) combined with digital image processing. This non-destructive testing technique avoids the costly demolition of the blade structure. The CT scan covers the whole blade region, including the root, transition, and tip regions, as well as the airfoil blade regions, in which there are spanwise variations in the interior structural layout due to the existence of heavy instrumentation. The three-dimensional digital image data are processed at selected radial stations, and finite element beam cross-section analyses are conducted to evaluate the structural properties of the blade at the macroscopic level. The fidelity of the digital blade model is first assessed by correlating the estimated blade mass with the measured data. A separate mechanical measurement is then carried out to determine the representative elastic properties of the blade and to verify the predicted results. The agreement is found to be good to excellent for the mass, elastic axis, flap bending, and torsional rigidity. The discrepancies are less than 2.0% for the mass and elastic axis locations, and about 8.1% for the blade stiffness properties, as compared with the measured data. Finally, a sensitivity analysis is conducted to clarify the impact of modeling the sensor and actuator cables, nose weight, and manufacturing imperfections on the structural properties of the blade. Full article

In recent years, the use of highly flexible wings in aerial vehicles (e.g., aircraft or drones) has been attracting increasing interest, as they are lightweight, which can improve fuel-efficiency and distinct flight performances. Continuous wing monitoring can provide valuable information to prevent fatal failures and optimize aircraft control. In this paper, we demonstrate the capabilities of a distributed optical fiber sensor based on time-expanded phase-sensitive optical time-domain reflectometry (TE-ΦOTDR) technology for structural health monitoring of highly flexible wings, including static (i.e., bend and torsion), and dynamic (e.g., vibration) structural deformation. This distributed sensing technology provides a remarkable spatial resolution of 2 cm, with detection and processing bandwidths well under the MHz, arising as a novel, highly efficient monitoring methodology for this kind of structure. Conventional optical fibers were embedded in two highly flexible specimens that represented an aircraft wing, and different bending and twisting movements were detected and quantified with high sensitivity and minimal intrusiveness. Full article

In this paper, we demonstrate a fiber Bragg grating (FBG) with a wide range and a comb with continuous cladding mode resonances inscribed in non-photosensitive single mode fibers using a femtosecond laser and a phase mask. The FBG is inscribed in the core and cladding, exciting a series of cladding modes in transmission. The birefringence induced by this FBG structure offers significant polarization-dependence for cladding modes, thus allowing the vector fiber twist to be perceived. By measuring the peak-to-peak differential intensity of orthogonally polarized cladding mode resonances, the proposed sensor presents totally opposite intensity response in the anticlockwise direction for the torsion angle ranging from −45° to 45°. The cladding mode comb approximately covers wavelengths over the O-, E-, S-, and C-bands in transmission. The cutoff cladding mode of air can be observed in the spectrum. Thus, the sensible refractive index range is estimated to be from 1.00 to 1.44. Temperature responsivity of the grating is also characterized. The proposed device potentially provides new solutions to the various challenges of physical vector and bio-chemical parameters sensing. Full article

A novel micromachined z-axis torsional accelerometer based on the tunneling magnetoresistive effect is presented in this paper. The plane main structure bonded with permanent magnetic film is driven to twist under the action of inertial acceleration, which results in the opposite variation of the magnetic field intensity. The variation of the magnetic field is measured by two differential tunneling magnetoresistive sensors arranged on the top substrate respectively. Electrostatic feedback electrodes plated on the bottom substrate are used to revert the plane main structure to an equilibrium state and realize the closed-loop detection of acceleration. A modal simulation of the micromachined z-axis tunneling magnetoresistive accelerometer was implemented to verify the theoretical formula and the structural optimization. Simultaneously, the characteristics of the magnetic field were analyzed to optimize the layout of the tunneling magnetoresistance accelerometer by finite element simulation. The plane main structure, fabricated with the process of standard deep dry silicon on glass (DDSOG), had dimensions of 8000 μm (length) × 8000 μm (width) × 120μm (height). A prototype of the micromachined z-axis tunneling magnetoresistive accelerometer was produced by micro-assembly of the plane main structure with the tunneling magnetoresistive sensors. The experiment results demonstrate that the prototype has a maximal sensitivity of 1.7 mV/g and an acceleration resolution of 128 μg/Hz^0.5 along the z-axis sensitive direction. Full article

A highly sensitive torsion sensor can be constructed by combining a twisted photonic crystal fiber with a liquid-filled waveguide in its air-hole cladding. The torsion sensitivity of this type of sensor is determined directly by the phase-matching conditions between the fiber core mode and the liquid waveguide mode, which can be improved by tuning the helicity (denoted by the initial twist rate, α₀) of the twisted photonic crystal fiber. The enhancement mechanism of α₀ on the sensitivity of the proposed torsion sensor is investigated theoretically, followed by experimental verifications, and a torsion sensitivity as high as 446 nm∙mm∙rad⁻¹ can be obtained by tailoring these parameters. Experimental results show that the torsion sensitivity increases with α₀ decreasing from 3.142 to 3.925 rad/mm, which are in consistence with that of the numerical predictions. The demonstrated torsion sensor is expected to contribute to the development of highly sensitive torsion-related photonic crystal fiber devices. Full article

In this paper, a comprehensive passive torsion measurement is performed firstly in a 40-cm-long polarization maintaining fiber-based Sagnac interferometer (PMF-SI), and the non-linear torsion response is found and investigated. Then, a fiber laser torsion sensor (FLTS) with a dual-ring-cavity structure is proposed and experimentally demonstrated, in which the PMF-SI is utilized as the optical filter as well as the sensing unit. In particular, the highly sensitive linear range is adjusted through fine phase modulation, and owing to the flat-top feature of fringes, an ~83.6% sensitivity difference is effectively compressed by the generated lasing. The experimental results show that, without any pre-twisting, the ultra-wide linear response from –175 to 175 rad/m is gained, and the torsion sensitivities are 2.46 and 1.55 nm/rad with high linearity (>0.99) in the clockwise and anti-clockwise directions, respectively. Additionally, a high extinction ratio (>42 dB) and small line-width (~0.14 nm) are obtained in the proposed FLTS, and the corresponding detection limit reaches 0.015 rad/m. Full article

The Matteucci effect (ME) is one of the lesser-known magnetomechanical effects and is most prominent in bistable amorphous wires. It has some experimental applications—Matteucci effect-based magnetic field sensors are very easy to produce and have inherently linear, hybrid analog/digital output signal. The effect is still poorly understood, however, and although it relies on torsion of the wire to manifest, there is no available model, or much experimental data, which would quantitatively connect the ME with the sample twist. In this paper, experimental characteristics of ME signal parameters dependence on torsion in Co-based amorphous bistable wire are presented. The results hint at possible applications, such as rotation or critical current sensors, as well as the necessity of torsion control in the development of ME magnetic field sensors. Full article

Photonic crystal fiber sensors have potential application in environmental monitoring, industry, biomedicine, food preservation, and many more. These sensors work based on advanced and flexible phototonic crystal fiber (PCF) structures, controlled light propagation for the measurement of amplitude, phase, polarization and wavelength of spectrum, and PCF-incorporated interferometry techniques. In this article various PCF-based physical sensors are summarized with the advancement of time based on reported works. Some physical PCF sensors are discussed based on solid core as well as hollow core structures, dual core fibers, liquid infiltrated structures, metal coated fibers, grating incorporated fibers. With the advancement of sensing technology the possibilities of temperature, pressure, strain, twist, curvature, electromagnetic field, and refractive index sensing are discussed. Also, limitations as well as possible solutions and future hopes are outlined. Full article

In this paper, the torsional stress effect on Giant Magneto-Impedance (GMI) was studied in Co-rich amorphous wires. The study, which was conducted in the context of the development of a current clamp based on GMI, considered torsion as a parameter of the influence of this sensor. Both diagonal, Z₁₁, and off-diagonal, Z₂₁, components of the impedance tensor were investigated. The samples were Co-rich wires with a 100 µ diameter. The wires were twisted positive and negative angles with respect to a reference position. For each component of the impedance, the intrinsic sensitivity and offset were measured as a function of the rotation angle. The results showed that the sensitivity of the diagonal component at a given working point slightly increased for angles between −90° to +90°, whereas the sensitivity was almost constant for the off-diagonal component at zero-field. The intrinsic offset in the diagonal configuration was almost unchanged for the rotation angles considered, whereas this offset increased in the off-diagonal configuration. Furthermore, the GMI ratio of Z₁₁ was also measured as a function of the rotation angle for comparison purposes with known data. The maximum of this ratio was obtained for a rotation angle of about 50°. Full article
