Advanced High-Strength Steel (AHSS) exhibits stress-state-dependent competing shear–tensile fracture modes that limit the applicability of conventional ductile fracture criteria based solely on equivalent plastic strain accumulation, such as the Forming Limit Diagram (FLD) approach and the classical Gurson–Tvergaard–Needleman (GTN) model. This paper proposes an extended GTN damage model incorporating Hill’48 anisotropy and the Nahshon–Hutchinson shear mechanism, regulated by a stress-state-dependent weighting function. The experimental program comprised uniaxial tension tests for constitutive calibration, notched plate specimens with shear angles ranging from 0° to 90° (spanning pure shear to tensile–shear stress states), and tension-bending tests. The fracture initiation point was identified from the abrupt load drop on the experimental force–displacement curve and further located in the finite element simulation to extract the corresponding stress-state history. SEM fractography was employed to characterize the microscopic damage mechanisms, revealing a continuous transition from shear-dominated to void-dominated damage at a critical stress triaxiality of approximately 0.35. A weighting function dependent on both stress triaxiality and the normalized Lode angle was formulated to couple void evolution with shear band localization. Following calibration via finite element inverse fitting, the model, implemented as an ABAQUS VUMAT subroutine, successfully reproduced fracture strains and crack paths across stress states ranging from pure shear to high hydrostatic tension. Comparative simulations indicate that this approach yields improved prediction accuracy over the classical GTN model, particularly under mixed-mode conditions, thereby offering a practical numerical tool for analyzing AHSS formability. Full article

The cyclic material properties are crucial for accurate assessment of structural response; however, conventional numerical methods often fail to replicate the mechanical degradation caused by ultra-low cycle fatigue (ULCF) damage accumulation. This paper focuses on a novel constitutive model characterizing the continuous degradation in yield stress and stiffness under large-strain tension–compression cyclic loads. A series of 32 cyclic tests on circular notched specimens covering a range of stress triaxialities are first revisited to systematically identify the cyclic softening behavior. The corresponding limitations of the widely applied classical Chaboche theory are examined, and an enhanced elastoplastic constitutive framework is proposed accordingly. On this basis, the stress-weighted ductile fracture model (SWDFM), which is developed from micro-damage mechanics, is then employed as the internal damage criterion of the proposed constitutive model. Explicit functional relationships linking the evolved yield stress and Young’s modulus to the imposed damage index are established and calibrated against the test data. Based on these findings, a new cyclic ductile constitutive model is developed, which is programmed into the UMAT subroutine compatible with ABAQUS/Standard. Numerical validations against the experimental cyclic responses exhibit good agreement, as indicated by the considerably low average errors of 5% for both strength and stiffness, demonstrating its validity in terms of the hysteretic behavior simulation for metals subjected to progressive ULCF damage. Full article

Red-bed soft rock is widely distributed in the upper Yellow River. To investigate the strain-rate effect of saturated red-bed soft rock, a series of triaxial tests was conducted on argillaceous siltstone. Specifically, fifteen samples were tested by controlling confining pressures (5 MPa, 10 MPa, 15 MPa, 20 MPa, and 25 MPa) and strain rates (6.0%/min, 0.6%/min, and 0.06%/min) via triaxial tests, scanning electron microscopy (SEM), X-ray diffraction (XRD), Computed Tomography (CT), and 3D laser scanner. The results show that the peak strength of argillaceous siltstone increases with the rise in strain rate, being highly sensitive to the variation in strain rate under low confining pressure while relatively insensitive under high confining pressure. The tangent modulus of argillaceous siltstone is significantly affected by strain rate, and the influence of strain rate on tangent modulus weakens with the increase in confining pressure. Strain rate exerts an influence on the fracture mode and the shear zone roughness of soft rock. That is, with the increase in strain rate, the roughness increases, and the fracture mode transforms from pure shear fracture to tension–shear coupled fracture. With the increase in confining pressure, the number of shear cracks increases, and the shear surfaces tend to distribute approximately in parallel. The research results provide a scientific reference for the reservoir site selection of pumped storage power station in the upper Yellow River. Full article

Surface roughness is ubiquitous in hard rock discontinuities at different scales and plays a critical role in governing frictional behavior and rupture dynamics. In this study, triaxial shear tests were conducted on sawcut smooth fractures and tension-induced rough fractures to investigate frictional behavior, roughness evolution, and rupture dynamics with increasing shear cycles. The results demonstrate that rough fractures exhibit higher shear strength and more intense stick-slip behavior than smooth fractures, but show strength weakening and reduced stress drops with shear cycle. In contrast, smooth fractures display relatively stable strength and stress drops. These differences in frictional behavior are governed by roughness evolution. Although roughness decreases in both fracture types after shearing, rough fractures experience degradation nearly an order of magnitude greater than that of smooth fractures. The initial stick-slip event on rough fractures generates the largest stress drop and apparent breakdown work. In addition, analyses of stress drop and energy dissipation reveal that friction drops for different types of fracture are concentrated within the range of 0.01 to 0.3. These findings highlight the critical role of roughness evolution in fault stability and provide valuable insights for seismic hazard assessment in deep underground engineering. Full article

To reveal the damage–seepage coupling mechanism of delayed floor water inrush induced by small fault activation under mining-induced stress, a cubic cement mortar specimen containing a persistent small fault was prepared based on similarity theory. Systematic triaxial loading–seepage tests were conducted under different fault fracture zone particle gradations, fracture zone widths, and fault angles, with simultaneous monitoring of stress–strain behavior, acoustic emission (AE) characteristics, and seepage flow evolution. The results show that: ① The peak strength decreases with increasing fracture zone width, but increases with increasing Talbot gradation coefficient (a fractal grading method) and fault angle. The failure mode transitions from shear-dominated to tension–shear composite failure. The spatial localization of AE events corresponds well with macroscopic fracture surfaces, and the AE source amplitude is positively correlated with compressive strength. ② The seepage flow exhibits a nonlinear evolution pattern of “compaction stabilization—stepwise rise—plateau stabilization” during loading. In the early loading stage, compaction of the fracture zone causes a slight decrease in flow. Approaching peak strength, the initiation and propagation of through-going fractures create interconnected seepage channels, leading to a stepwise jump in flow. In the post-peak stage, accompanied by fine particle erosion and framework reconfiguration, the flow tends to stabilize. A larger fracture zone width, smaller gradation coefficient, and smaller fault angle result in a more significant post-peak seepage surge, with the maximum flow rate reaching 3.6 times that of the specimen with a 2 mm wide fracture zone. ③ Grey relational analysis indicates that the fault angle is the most sensitive factor affecting the risk of delayed water inrush (correlation degree 0.788), followed by particle gradation and fracture zone width. The study demonstrates that under monotonic loading conditions, the damage evolution and seepage response of small faults are jointly controlled by their geometric parameters and internal structure, with the fractal grading method effectively quantifying the role of particle gradation. The findings provide a theoretical basis for risk assessment of delayed water inrush from small faults in working faces above confined aquifers. Full article

Freeze–thaw cycles cause mechanical deterioration and instability of slope rock masses in open-pit coal mines located in the cold regions of Northwest China. In this study, the research object is fine-grained sandstone from the Yan’an Formation in the Tarangole mining area of the Ordos Basin. Here, indoor freeze–thaw cycling, uniaxial compression, and triaxial compression tests were conducted to systematically analyze the deformation behavior, strength evolution, and failure modes of the sandstone under varying numbers of freeze–thaw cycles, freezing temperatures, and confining pressures, thereby revealing its freeze–thaw damage mechanism. The results show that the number of freeze–thaw cycles is the dominant factor affecting the elastic modulus. Freezing temperatures (especially between −5 °C and −15 °C) and the number of freeze–thaw cycles (particularly the first 10 cycles) significantly reduce peak strength. In addition, confining pressure can significantly enhance the resistance to deformation (under 15 freeze–thaw cycles, the elastic modulus increases by 181.8% as confining pressure rises from 0 to 2 MPa). Within the low confining pressure range (0–1.5 MPa), peak strain decreases monotonically with increasing confining pressure and is independent of the number of freeze–thaw cycles. Finally, the increase in the number of freeze–thaw cycles and the decrease in temperature jointly promote crack development, and the failure mode shifts from pure shear to a shear-tension composite mode. The underlying cause lies in the evolution of interparticle cementation within the soil skeleton and in the associated pore–crack structure. In addition, based on fracture damage mechanics and the modified Weibull distribution, a damage evolution equation and a constitutive model for sandstone considering freeze–thaw cycles and temperature effects were established and validated. Therefore, the research findings can provide a theoretical basis for slope support, freeze–thaw disaster prevention and mitigation, and stability assessment in the Tarangole mining area and other cold regions. Full article

The extreme thermal environment during the underground coal gasification (UCG) process poses a severe threat to the stability of the gasification cavity and the integrity of the surrounding rock. This paper aims to reveal the thermo-mechanical response characteristics and damage evolution mechanism of sandstone under true triaxial unloading conditions following exposure to high temperatures. Sandstone specimens were thermally pre-treated at five temperature gradients (25 °C, 200 °C, 400 °C, 600 °C, and 800 °C) and subsequently subjected to true triaxial loading and unloading experiments. The effects of varying temperatures on the strength, deformation parameters, dilation angle evolution, and macroscopic failure modes of the sandstone were systematically analyzed. The results indicate a significant critical transition point in the mechanical behavior of the sandstone at 400 °C. Below this threshold, thermal-induced microcrack closure leads to an increase in peak strength (with the peak strength at 800 °C increasing by approximately 67% compared to room temperature). Conversely, above 400 °C, thermal damage to the mineral grains intensifies, causing the crack propagation pattern to transition from brittle shear to a complex tension-shear splitting mode, accompanied by severe dilatancy (with a generalized Poisson’s ratio exceeding 0.8). Based on these findings, this study proposes a stage-wise damage evolution model alongside a targeted zonal support strategy, recommending the application of high-prestressed support in high-temperature zones above 400 °C to suppress tensile failure. Ultimately, this research provides a crucial theoretical basis for evaluating the long-term stability of high-temperature underground engineering projects and ensuring operational safety. Full article

Maintaining the integrity of impermeable strata between mine workings and overlying aquifers is critical, because seepage pathways may cause mine flooding and surface subsidence. In the Upper Kama potash deposit, the impermeable sequence is a 50–140 m thick layered sequence of evaporites and clays overlying mined-out chambers. Under long-term loading, salt rocks tend to creep, soften, and localize damage, which can cause failure in the impermeable strata. In this paper, the Concrete damage-plasticity model, supplemented by the N2PC-MCT viscoplastic creep model, is applied to simulate the initiation and evolution of seepage pathways in the Upper Kama impermeable strata. Model parameters are obtained from published laboratory tests (uniaxial and triaxial compression and tension) and validated using observed ground-surface subsidence. A plane-strain finite-element model incorporates the stratified lithology, interface elements between layers, and sequential excavation. Long-term simulations up to 50 years investigate two operational scenarios: with and without backfilling. The calibrated model reproduces the main stages of surface subsidence and chamber closure. Without backfilling, simulations indicate that tensile damage localizes mainly in a stiff central salt layer of the impermeable strata, with most cracks appearing approximately between 33 and 37 years after the start of mining. With backfill, tensile crack propagation stops and damage remains stable. A hypothetical homogeneous impermeable strata case confirms that the observed central-layer cracking is associated with stiffness contrasts and composite bending in the stratified system. An approximate analytical multilayer beam solution, based on energy minimization, predicts bending stress concentration in stiff intermediate layers and is consistent with the numerical stress distribution. The combined numerical and analytical results provide insight into the mechanisms of long-term conductive fracture initiation in stratified impermeable strata and may serve as a basis for preliminary hazard indication and for planning mitigation measures, including backfilling and focused monitoring of stiff central layers. Because the study is based on a 2D plane-strain model, the quantitative estimates should be regarded as preliminary and require verification by 3D modelling and further field observations. Full article

Accurate numerical simulation of Cr20Ni80 alloy processing relies on reliable constitutive and failure models. This study employs a comprehensive experimental–numerical approach to calibrate and validate the Johnson–Cook (J-C) parameters of Cr20Ni80 alloy under varying stress states and strain rates. Quasi-static tensile tests on smooth and notched specimens, alongside dynamic Split Hopkinson Tension Bar (SHTB) tests (1000–3000 s⁻¹), were conducted. Pulse-shaping technology was employed, and dynamic force balance was verified to ensure the physical validity of the high-strain-rate data. The constitutive parameters ($A=621.02 \mathrm{MPa}, B=543.20 \mathrm{MPa}, n=0.4564, C=0.0141$) were determined based on true stress–strain responses. Theoretical analysis confirms that the thermal softening effect caused by adiabatic heating can be neglected. Furthermore, the failure parameters ($D_1=-0.4300,{ D}_2=2.6405,{ D}_3=-0.7055$) were calibrated to capture the stress triaxiality effects ($R^2=0.978$). The parameter $D_4$ was iteratively calibrated using SHTB data from the 1000 s⁻¹ and 3000 s⁻¹ test conditions and validated using SHTB data from the 2000 s⁻¹ test condition. The engineering stress–strain curves obtained from simulations using the calibrated parameters showed good agreement with experimental results, confirming the reliability of the calibrated parameters. Full article

Silicone rubber is extensively used in engineering applications due to its toughness and impact resistance; however, traditional characterisation methods fail to capture its nonlinear deformation characterisation and triaxial mechanical behaviour. To address this, we derived a constitutive model within the framework of continuum mechanics that assumes a condition of near incompressibility and conducted uniaxial, planar, and equibiaxial tension tests to fit the model parameters. Through systematic analysis of triaxial mechanical responses under these three loading modes, we determined the material’s nonlinear large-deformation behaviour and sensitivity to the biaxiality ratio. Comparative analyses with classical hyperelastic models show that the proposed model achieves a good balance between the number of parameters and fitting accuracy. After the parameter-fitting process, we performed finite element simulations of the three loading modes. The simulation results show good agreement with experimental data in terms of deformation patterns and stress–strain curves. This study provides a novel theoretical tool for evaluating the mechanical properties and structural designs of soft materials. Full article

The mechanical response of the iron–hydrogen (Fe-H) system under triaxial tensile loading is systematically investigated using molecular dynamics simulations. The study focuses on how hydrogen concentration affects the stress state and void evolution and further explores its coupled effects with temperature. The results indicate that when the hydrogen concentration is less than or equal to 1%, hydrogen atoms impede dislocation motion, thereby retarding void growth by promoting dislocation entanglement and the formation of loop structures. Moreover, the evolution of void volume exhibits a typical three-stage characteristic: an initial slow growth phase, a rapid growth phase, and a decelerated growth phase after coalescence. In addition, the evolution of void surface area in the model essentially results from competition between two mechanisms: the decrease caused by void collapse and coalescence and the increase caused by void expansion. Cluster configuration analysis reveals that void formation around the clusters serves as a critical turning point for their structural stability, and the subsequent evolution of the voids leads to a substantial reduction in local structural stability. The analysis of the coupling effect between temperature and hydrogen concentration reveals that under high-temperature conditions, temperature plays a key role in determining the strength, while the strengthening effect of low hydrogen concentrations can be neglected. Additionally, at low temperatures, hydrogen concentration has a negligible effect on structure, but under elevated temperatures, increased hydrogen concentration markedly intensifies the degree of structural disorder. Full article

This study examines the mechanical response of medium-manganese TRIP steels under different stress states, focusing on deformation-induced austenite-to-martensite transformation and ageing phenomena. Two steels with distinctly different ferrite–austenite morphologies and retained austenite (RA) fractions were analysed: a globular microstructure with 18% RA and a lamellar microstructure with 14% RA, produced by single (SA) and double annealing (DA), respectively. Continuous and interrupted tests were performed under in-plane shear, uniaxial tension, and plane strain stress states. Strain fields were analysed using high-resolution digital image correlation, while RA fractions were quantified as a function of strain by ex situ X-ray diffraction. The results demonstrate a pronounced stress-state dependence. SA samples exhibit discontinuous yielding, with uniaxial tests showing clear Lüders band formation. Both steels exhibit dynamic strain ageing manifested by Portevin–Le Chatelier (PLC) serrations and associated strain bands, which are most pronounced under uniaxial tension, weaker in plane strain, and barely detectable in in-plane shear. Static strain ageing is also evidenced by a strengthened yield response upon unloading–reloading in all samples. The SA globular microstructure exhibits higher PLC band inclination angles than the lamellar DA microstructure, consistent with its more pronounced anisotropy. The propagation velocity in uniaxial tensile samples decreases with increasing strain following the work-hardening response. For both steels, the austenite-to-martensite transformation rate is highest in uniaxial tension, slightly reduced in plane strain, and strongly suppressed under in-plane shear. A Beese–Mohr/Johnson–Mehl–Avrami–Kolmogorov formulation incorporating stress triaxiality and Lode angle captures these trends for both steels. For the stress states considered, the DA condition exhibits a consistently higher transformation rate than the SA condition, accompanied by a higher work-hardening rate. These findings highlight the coupled role of stress state and microstructural morphology in governing localisation behaviour and strain-induced transformation in medium-manganese steels. Full article

In this study, the fracture behavior of zirconium was investigated by a hybrid experimental and numerical simulation method. Uniaxial tensile tests were conducted on samples of various geometries, thereby covering a wide range of stress states at fracture characterized by stress triaxiality between 0.05 and 0.96 and Lode angle parameter between 0.01 and 0.95. Stress state-related parameters of each geometry were collected and used to calibrate the parameters of the modified Bai-Wierzbicki (MBW) model. With the calibrated MBW model, the fracture of zirconium can be predicted. Additionally, the fracture surfaces of the pure shear and pure tension samples were analyzed using a scanning electron microscope (SEM), revealing that shear mode dominates the failure at a low stress triaxiality range from 0 to 1/3, while ductile fracture dominates the failure at a middle stress triaxiality range from 1/3 to 1. The deep understanding of the fracture behaviors and mechanisms of zirconium under various stress states in this study contributes to the safety assessment of cladding tubes used in nuclear power plants. Full article

The stress–strain–strength behavior of hydraulic asphalt concrete is critical to the safety of the high asphalt concrete core. To study the effect of bitumen grade on the stress–strain–strength behavior of hydraulic asphalt concrete, uniaxial compression tests, direct tension tests, bending tests, and triaxial compression tests were conducted. The variation patterns of mechanical performance indicators and stress–strain curves of hydraulic asphalt concrete with bitumen grades A70, A90, and A110 were analyzed. The elastic modulus expression of asphalt concrete based on nonlinear failure criteria were proposed. Considering potential issues associated with asphalt concrete core, the selection of bitumen grades was discussed. The results indicate that increasing the bitumen grade enhances the tensile, compressive, bending, and shear deformation properties of hydraulic asphalt concrete, and makes it exhibit more pronounced ductile behavior. However, the strength and modulus decrease. The use of higher-grade bitumen reduces the dilatancy of hydraulic asphalt concrete. As the bitumen grade increases, the nonlinear property of the shear strength of hydraulic asphalt concrete becomes more significant. An elastic modulus expression based on nonlinear failure criterion accurately describes the deviatoric stress–axial strain relationship for hydraulic asphalt concrete of different bitumen grades. When the strength of hydraulic asphalt concrete meets these requirements, it is advisable to select higher-grade bitumen to enhance the safety of the core. Full article

The mesh size significantly affects the accuracy and computational efficiency of finite-element analysis (FEA) simulations. This study investigates mesh regularization to mitigate mesh dependency, align numerical results with experimental data, and optimize the computational time for carbon/epoxy composites. Mesh regularization was implemented using the ^∗MAT_ADD_GENERALIZED_DAMAGE (MAGD) model in LS-DYNA, which incorporates a scaling factor based on the ply orientation and stress triaxiality to adjust the material failure criterion. To address the limitations of trial-and-error methods for determining scaling factors, four analytical models were developed to predict these factors as functions of element size. These predictions were validated against experimentally derived scaling factors for unidirectional carbon/epoxy composites across three ply orientations (0°, 45°, and 90°) and three stress triaxiality conditions (tension, compression, and shear) using mesh sizes ranging from 0.5 mm to 1.5 mm. The scaling factor effectively reduced the mesh dependency in the tested configurations. A clear relationship between ply orientation and mesh regularization was established; however, no definitive correlation was observed with stress triaxiality. Among the theoretical approaches, the stress degradation model yielded the most consistent predictions, although discrepancies with the experimental results indicate the need for further refinement. This study proposes integrating scaling factors into a material model as a practical approach to mesh regularization for orthotropic materials and evaluates existing theoretical models for predicting these factors. Full article
