Fault location in DC microgrids (DCMGs) is a critical challenge due to the system’s inherent complexities and the demand for high reliability in modern power systems. This study proposes an explainable artificial intelligence (XAI)-based quantum deep neural network (QDNN) framework to address fault localization challenges in DCMGs. First, voltage signals from the DCMG are collected and analyzed using high-order synchrosqueezing transform to detect traveling waves (TWs) and extract critical fault parameters such as time of arrival, magnitude, and polarity of the first and second TWs. These features are fed into the proposed QDNN model that integrates advanced learning techniques for accurate fault localization. The cumulative distance from the fault point to the bus connecting the DCMG to the power network is considered the output vector. The model uses a combination of deep learning and quantum computing techniques to extract features and improve accuracy. To ensure transparency, an XAI technique called Shapley additive explanations (SHAP) is applied, enabling system operators to identify critical fault features. The SHAP-based explainability framework plays a critical role in translating the model’s predictions into actionable insights, ensuring that the proposed solution is not only accurate but also practically implementable in real-world scenarios. The results demonstrate the QDNN framework’s superior accuracy in fault localization even in noisy environments and with high-resistance faults, independent of voltage levels and DCMG configurations, making it a robust solution for modern power systems. Full article

We consider novel discrete derivative nonlinear Schrödinger equations (ddNLSs). Taking the continuum derivative nonlinear Schrödinger equation (dNLS), we use for the discretisation of the derivative the forward, backward, and central difference schemes, respectively, and term the corresponding equations forward, backward, and central ddNLSs. We show that in contrast to the dNLS, which is completely integrable and supports soliton solutions, the forward and backward ddNLSs can be either dissipative or expansive. As a consequence, solutions of the forward and backward ddNLSs behave drastically differently compared to those of the (integrable) dNLS. For the dissipative forward ddNLS, all solutions decay asymptotically to zero, whereas for the expansive forward ddNLS all solutions grow exponentially in time, features that are not present in the dynamics of the (integrable) dNLS. In comparison, the central ddNLS is characterized by conservative dynamics. Remarkably, for the central ddNLS the total momentum is conserved, allowing the existence of solitary travelling wave (TW) solutions. In fact, we prove the existence of solitary TWs, facilitating Schauder’s fixed-point theorem. For the damped forward expansive ddNLS we demonstrate that there exists such a balance of dissipation so that solitary stationary modes exist. Full article

Fault location estimation in transmission lines is critical for power system reliability. Various methods have been developed for this purpose, among which transient frequency spectrum analysis (TFSA) stands out as a recent method based on travelling wave (TW) theory. TFSA determines the fault location by analyzing the frequency spectrum of transient currents and/or voltages at the instant of the fault, offering advantages such as independence from fault impedance and the ability to locate faults with one-side measurements. Despite its success in fault location, TFSA has several considerations that warrant detailed investigation. This study explores the effects of source inductance, series compensation, fault arc, and current transformer (CT) characteristics on transient frequencies. Additionally, the impact of noise on TFSA results is examined. The new proposed source inductance compensation method can reduce the error of 6.55% to 0.88%, where the same error can be reduced to 3.45% with the compensation method given in previous study. Strategies to enhance accuracy are discussed and compared to previous studies, including a proposed detection approach providing appropriate data size and precise wave propagation speed calculations. These findings contribute to a deeper understanding of TFSA’s limitations and inform practical improvements for fault location accuracy in power transmission systems. Full article

In this study, a traveling wave Mach-Zehnder intensity modulator (TW-MZM) was designed and optimized for six different electro-optical (EO) crystals: lithium niobate (LNB), potassium niobate (KNB), lithium titanate (LTO), beta barium borate (BBO), cadmium telluride (CdTe), and indium phosphide (InP). The performance of each EO crystal, including optical and radio frequency (RF) loss, applied voltage, and modulation bandwidth, was estimated and compared. The results suggest that, in theory, KNB, LTO, BBO, and CdTe have the potential to outperform LNB. However, it should be noted that the loss associated with KNB and LTO is comparable to that of LNB. The findings demonstrated that BBO and CdTe exhibit a modulation bandwidth exceeding 100 GHz and demonstrate the lowest loss among the considered crystals based on the assumed geometry. Full article

A superradiant FEL in the THz (3 THz) region is currently operating at Ariel University. It is based on the novel ORGAD accelerator, which is a hybrid linear RF photo-cathode 6 MeV electron gun. The hybrid term stands for its unique standing wave (SW)—traveling wave (TW) structure. The undulator generates spontaneous superradiance, which corresponds to spontaneous emission when the electron bunch duration is shorter than the radiated frequency, resulting in a much higher photon yield. However, the efficiency of this scheme is still quite low. In order to achieve higher emission (by improved efficiency), we intend to implement a new and promising radiative interaction scheme: tapering-enhanced superradiance (TES). This particular undulator design employs a tapered (amplitude) undulator in the zero-slippage condition to obtain a significantly more powerful and efficient THz radiation source. At the current stage, the scheme is designed for emission at approximately $0.5$ THz. The design and start-to-end simulations demonstrate significant enhancement of superradiant energy and extraction efficiency using this method compared to a reference uniform case. Full article

The arc suppression device based on ground fault transfer (GFT) has been preliminarily applied in the medium voltage distribution network (MVDN). An accurate travelling wave (TW) fault location method is proposed to extend the use of the ground fault transfer device. D-PMU is used as a travelling wave detection tool to record the transient voltage travelling waves of fault grounding and bus active grounding during arc suppression. Then, the faulty section is identified through the time difference of travelling wave arrival at the upstream and downstream measurement points. On this basis, the fault location equations of the arrival time and distance of the upstream travelling wave are established, and an accurate fault location method based on the arrival time difference of the travelling wave is proposed. The simulation model is established by PSCAD/EMTDC, and the results show that the method has high location accuracy, and the absolute error is less than 30 m. It is not affected by the TW velocity, the fault conditions, or the distributed power sources. Full article

The Jimbo-Miwa equation (JME) that describes certain interesting (3+1)-dimensional waves in plasma physics is studied in this work. The Hirota bilinear equation is developed via the Cole-Hopf transform. Then, the symbolic computation, together with the ansatz function schemes, are utilized to seek exact solutions. Some new solutions, such as the multi-wave complexiton solution (MWCS), multi-wave solution (MWS) and periodic lump solution (PLS), are successfully constructed. Additionally, different types of travelling wave solutions (TWS), including the dark, bright-dark and singular periodic wave solutions, are disclosed by employing the sub-equation method. Finally, the physical characteristics and interaction behaviors of the extracted solutions are depicted graphically by assigning appropriate parameters. The obtained outcomes in this paper are more general and newer. Additionally, they reveal that the used methods are concise, direct, and can be employed to study other partial differential equations (PDEs) in physics. Full article

This work proposes and develops an implementation of a fault location method to provide a fast and resilient protection scheme for power distribution systems. The method analyzes the transient dynamics of traveling waves (TWs) to generate features using the discrete wavelet transform (DWT), which are then used to train several graph convolutional network (GCN) models. Faults are simulated in the IEEE 34-node system, which is divided into three protection zones (PZs). The goal is to identify the PZ in which the fault occurs. The GCN models create a distributed protection scheme, as all nodes are able to retrieve a prediction. Given that message-passing between nodes occurs both during training and in the execution of the model, the resiliency of such schemes to communication losses was analyzed and demonstrated. One of the models, which only uses voltage measurements, was implemented on a Texas Instruments F28379D development board. The execution times were monitored to assess the speed of the protection scheme. It is shown that the proposed method can be executed in approximately a millisecond, which is comparable to existing TW protection in the transmission system. For experimental purposes, a DWT-based detection method is employed. A design of a setup to playback TWs using two development boards is also addressed. Full article

This paper explores the most important factors that define the Traveling Wave (TW) propagation on distribution systems. The factors considered in this work are: the distance to the fault location, the fault type, and the crossing of system elements (such as regulators, capacitor banks, laterals, and extra loads within the protection zones). This work uses a realistic, yet simplified, distribution system composed of two protection zones, in which, several combinations of the previously mentioned factors are considered. The simulated fault measurements undergo a signal processing stage in which, first, they are decomposed into independent modes using the Karrenbauer transform. Second, a time–frequency representation is obtained using the Stationary Wavelet Transform (SWT), dividing the signal into several frequency bands. Finally, the Parseval’s Energy (PE) theorem is applied to calculate the signal energy in each frequency band. A qualitative analysis is performed based on the previously calculated energies to outline which are the factors that most affect the TW energy during propagation. The results show that distance, the presence of regulators, either in the propagation path or upstream, and the type of fault are the main factors that affect TW propagation across the system, and therefore they should be considered for TW-based protection schemes for distribution systems. Full article

This work provides an analytical approach to characterize and determine solutions to a porous medium system of equations with views in applications to invasive-invaded biological dynamics. Firstly, the existence and uniqueness of solutions are proved. Afterwards, profiles of solutions are obtained making use of the self-similar structure that permits showing the existence of a diffusive front. The solutions are then studied within the Travelling Waves (TW) domain showing the existence of potential and exponential profiles in the stable connection that converges to the stationary solutions in which the invasive species predominates. The TW profiles are shown to exist based on the geometry perturbation theory together with an analytical-topological argument in the phase plane. The finding of an exponential decaying rate (related with the advection and diffusion parameters) in the invaded species TW is not trivial in the nonlinear diffusion case and reflects the existence of a TW trajectory governed by the invaded species runaway (in the direction of the advection) and the diffusion (acting in a finite speed front or support). Full article

The aim of this work is to characterize Traveling Waves (TW) solutions for a coupled system with KPP-Fisher nonlinearity and weak advection. The heterogeneous diffusion introduces certain instabilities in the TW heteroclinic connections that are explored. In addition, a weak advection reflects the existence of a critical combined TW speed for which solutions are purely monotone. This study follows purely analytical techniques together with numerical exercises used to validate or extent the contents of the analytical principles. The main concepts treated are related to positivity conditions, TW propagation speed and homotopy representations to characterize the TW asymptotic behaviour. Full article

The aim of this work was to provide a formulation of a non-linear diffusion model with forced convection in the form of a reaction–absorption system. The model was studied with analytical and numerical approaches in the frame of the parabolic operators theory. In addition, the solutions are applied to a gas interaction phenomenon with the intention of producing an inerted ullage in an Airbus A320 aircraft centre fuel tank. We made use of the travelling wave (TW) solutions approach to study the existence of solutions, stability and the precise evolution of profiles. The application exercise sought to answer a key question for aerospace sciences which can be formulated as the time required to ensure an aircraft fuel tank is safe (inerted) to prevent explosion due to the presence of oxygen in the tank ullage. Full article

The use of wave-based locomotion mechanisms is already well established in the field of robotics, using either standing waves (SW) or traveling waves (TW). The motivation of this work was to compare both the SW- and the TW-based motion of a 20-mm long sub-gram glass plate, with attached 3D printed legs, and piezoelectric patches for the actuation. The fabrication of the robot did not require sophisticated techniques and the speed of motion was measured under different loading conditions. In the case of the TW mechanism, the influence of using different pairs of modes to generate the TW on the locomotion speed has been studied, as well as the effect of the coupling of the TW motion and the first flexural vibration mode of the legs. This analysis resulted in a maximum unloaded speed of 6 bodylengths/s (BL/s) at 65 V peak-to-peak (Vpp). The SW approach also examined different modes of vibration and a speed of locomotion as high as 14 BL/s was achieved, requiring, unlike the TW case, a highly precise location of the legs on the glass supporting platform and a precise tuning of the excitation frequency. Full article

Traveling wave (TW)-based fault-location methods have been used to determine single-phase-to-ground fault distance in power-distribution networks. The previous approaches detected the arrival time of the initial traveling wave via single ended or multi-terminal measurements. Regarding the multi-branch effect, this paper utilized the reflected waves to obtain multiple arriving times through single ended measurement. Potential fault sections were estimated by searching for the possible traveling wave propagation paths in accordance with the structure of the distribution network. This approach used the entire propagation of a traveling wave measured at a single end without any prerequisite of synchronization, which is a must in multi-terminal measurements. The uniqueness of the fault section was guaranteed by several independent single-ended measurements. Traveling waves obtained in a real 10 kV distribution network were used to determine the fault section, and the results demonstrate the significant effectiveness of the proposed method. Full article

This paper reports the design, fabrication and performance of MEMS-based piezoelectric bidirectional conveyors featuring 3D printed legs, driven by linear travelling waves (TW). The structures consisted of an aluminium–nitride (AlN) piezoelectric film on top of millimetre-sized rectangular thin silicon bridges and two electrode patches. The position and size of the patches were analytically optimised for TW generation in three frequency ranges: 19, 112 and 420 kHz, by the proper combination of two contiguous flexural modes. After fabrication, the generated TW were characterized by means of Laser–Doppler vibrometry to obtain the relevant tables of merit, such as the standing wave ratio and the average amplitude. The experimental results agreed with the simulation, showing the generation of a TW with an amplitude as high as 6 nm/V and a standing wave ratio as low as 1.46 for a device working at 19.3 kHz. The applicability of the fabricated linear actuator device as a conveyor was investigated. Its kinetic performance was studied with sliders of different mass, being able to carry a 35 mg silicon slider, 18 times its weight, with 6 V of continuous sinusoidal excitation and a speed of 0.65 mm/s. A lighter slider, weighting only 3 mg, reached a mean speed of 1.7 mm/s at 6 V. In addition, by applying a burst sinusoidal excitation comprising 10 cycles, the TW generated in the bridge surface was able to move a 23 mg slider in discrete steps of 70 nm, in both directions, which is a promising result for a TW piezoelectric actuator of this size. Full article
