Blade tip leakage vortex (TLV) is a critical phenomenon in hydraulic machinery, which can significantly affect the internal flow characteristics and deteriorate the hydraulic performance. In this paper, the blade tip leakage flow and TLV characteristics in a novel dishwasher pump were investigated. The correlation between the vorticity distribution in various directions and the leakage vortices was established within a rotating coordinate system. The results show that the TLV in a composite impeller can be categorized into initial and secondary leakage vortices. The initial leakage vortex originates from the evolution of two corner vortices that initially form at different locations within the blade tip clearance. This vortex induces pressure fluctuations at the impeller inlet; its shedding is identified as the primary contributor to localized energy loss within the flow passage. These findings provide insights into TLVs in complex pump geometries and provide solutions for future pump optimization strategies. Full article

Turbines are rotating machines that generate power by the expansion of a fluid; due to their characteristics, these turbomachines are widely applied in aerospace propulsion systems. Due to the clearance between the rotor blade tip and casing, there is a leakage flow from the blade pressure to the suction sides, which generates energy loss. There are different strategies that can be applied to avoid part of this loss; one of them is the application of so-called desensitization techniques. The application of these techniques on gas turbines has been widely evaluated; however, there is a lack of analyses of hydraulic turbines. This study is a continuation of earlier analyses conducted during the first stage of the hydraulic axial turbine used in the low-pressure oxidizer turbopump (LPOTP) of the space shuttle main engine (SSME). The previous work analyzed the application of squealer geometries at the rotor tip. In the present paper, winglet geometry techniques are investigated based on three-dimensional flowfield calculations. The commercial CFX v.19.2 and ICEM v.19.2 software were used, respectively, on the numerical simulations and computational mesh generation. Experimental results published by the National Aeronautics and Space Administration (NASA) and data from previous works were used on the computational model validation. The parametric analysis was conducted by varying the thickness and width of the winglet. The results obtained show that by increasing the winglet thickness, the stage efficiency is also increased. However, the geometric dimension of its width has minimal impact on this result. An average efficiency increase of 2.0% was observed across the entire turbine operational range. In the case of the squealer, for the design point, the maximum efficiency improvement was 1.62%, compared to the current improvement of 2.23% using the winglet desensitization technique. It was found that the proposed geometries application also changes the cavitation occurrence along the stage, which is a relevant result, since it can impact the turbine life cycle. Full article

To investigate the performance of high-speed miniaturized screw refrigeration compressors, this study designed rotors with identical theoretical displacement but varying rated speeds. A normalized analysis established quantitative evaluation criteria for geometric performance, while an exergy analysis model assessed leakage exergy losses. Thermodynamic modeling evaluated the impact of different clearances and rated speeds on performance. Computational fluid dynamics (CFD) simulations analyzed the gas forces and torque acting on the rotors. The rate of efficiency improvement with increasing speed follows a non-linear relationship, demonstrating diminishing returns at ultra-high speeds, where further speed elevation provides negligible efficiency gains. This study reveals that, while tip-housing leakage represents the largest volumetric leakage in screw compressors, interlobe leakage contributes the most significantly to power losses. When the rated speed increases from 3000 rpm to 15,000 rpm, interlobe leakage remains the dominant source of power loss, with its relative contribution showing a marked increase. For compressors with identical cylinder dimensions, reducing the number of lobes decreases the discharge pressure fluctuations and power consumption. Larger wrap angles increase the contact line length and discharge port area, reducing the volumetric efficiency while creating a trade-off between leakage and discharge losses, resulting in an optimal wrap angle that maximizes the adiabatic efficiency. Full article

We introduce the solver ARES: Axial-flow pump Radial Equilibrium through Streamlines. The code implements a meanline method, enforcing the conservation of flow momentum and continuity across a set of discrete streamlines in the axial-flow pump’s meridional channel. Real flow effects are modeled with empirical correlations, including off-design deviation and losses due to profile shape, secondary flows, tip leakage, and the end-wall boundary layer (EWBL). Inspired by aeronautical fan and compressor methods, this implementation is specifically tailored for the analysis of the Outboard Dynamic-inlet Waterjet (ODW), the latest aero-engine-derived innovation in marine engineering. To ensure the reliable application of ARES for the systematic designs of ODW pumps, the present investigation focuses on prediction accuracy. Global and local statistics are compared between numerical estimates and available measurements of three test cases: two single rotors and a rotor–stator waterjet configuration. At mass flow rates near the design point, hydraulic efficiency is predicted within $1\%$ discrepancy to tests. Differently, as the flow coefficient increases, the loss prediction accuracy degrades, incrementing the error for off-design estimates. Spanwise velocity and pressure distributions exhibit good alignment with experiments near midspan, especially at the rotor exit, while end-wall boundary layer complex dynamics are hardly recovered by the present implementation. Full article

Tip leakage flow interacts with the mainstream, impacting the energy transmission process within the impeller of the fan and causing a significant flow loss. Understanding the flow characteristics within the impeller is a prerequisite and foundation for achieving efficient operation of the fan. Therefore, numerical simulations and experimental methods were employed to obtain the internal flow field of the mining counter-rotating axial flow fan, and the influence of flow rate on the tip leakage flow pattern was mastered. The spatial trajectory of the leakage vortex was quantified, and the distribution characteristics of the backflow were explored. The mechanism of energy loss caused by the leakage flow was revealed. The research findings indicate that when the flow rate exceeds 1.0 Q_BEP (Q_BEP is flow rate at the best efficiency point), the complex flow field near the blade tip is mainly caused by the tip leakage flow. However, the tip leakage flow and the leading edge overflow are the main factors causing disturbances in the flow field within the impeller at small flow rates. At large flow rates, the starting positions of the tip leakage vortex cores for both the front and rear impellers are located near the middle of the blade tip. As the flow rate decreases, the starting position of the vortex core gradually shifts toward the leading edge point, and the vortex structure evolves from an initial circular shape to an elliptical shape. The tip leakage flow and the leading edge overflow are the main cause of the backflow at the impeller inlet. The helical vortices caused by the tip leakage flow and the leading edge overflow, as well as the backflow in the impeller, are the key factors causing energy loss in the tip clearance flow field. Full article

A submersible sewage pump is designed for conveying solid–liquid two-phase media containing sewage, waste, and fiber components, through its small and compact design and its excellent anti-winding and anti-clogging capabilities. In this paper, the computational fluid dynamics–discrete element method (CFD-DEM) coupling model is used to study the influence of different conveying conditions and particle parameters on the wear of the flow components in a submersible sewage pump. At the same time, the energy balance equation is used to explore the influence mechanism of different tip clearance sizes on the internal flow pattern, wear, and energy conversion mechanism of the pump. This study demonstrates that increasing the particle volume fraction decreases the inlet particle velocity and intensifies wear in critical areas. When enlarging the tip clearance thickness from 0.4 mm to 1.0 mm, the leakage vortex formation at the inlet is enhanced, leading to increased wear rates in terms of the blade and volute. Consequently, the total energy loss and turbulent kinetic energy generation increased by 3.57% and 2.25%, respectively, while the local loss coefficient in regard to the impeller channel cross-section increased significantly. The findings in this study offer essential knowledge for enhancing the performance and ensuring the stable operation of pumps under solid–liquid two-phase flow conditions. Full article

The leakage flow has a significant impact on the aerodynamic losses and efficiency of the compressor. This paper investigates the loss mechanism in the tip region based on a high-load cantilevered stator cascade. Firstly, a high-fidelity flow field structure was obtained based on the Enhanced Delay Detached Eddy Simulation (EDDES) method. Subsequently, the Liutex method was employed to study the vortex structures in the tip region. The results indicate the presence of a tip leakage vortex (TLV), passage vortex (PV), and induced vortex (IV) in the tip region. At $i=4°,8°$, the induced vortex interacts with the PV and low-energy fluid, forming a “three-shape” mixed vortex. Finally, a qualitative and quantitative analysis of the loss sources in the tip flow field was conducted based on the entropy generation rate, and the impact of the incidence on the losses was explored. The loss sources in the tip flow field included endwall loss, blade profile loss, wake loss, and secondary flow loss. At $i=0°$, the loss primarily originated from the endwall and blade profile, accounting for $40\%$ and $39\%$, respectively. As the incidence increased, the absolute value of losses increased, and the proportion of loss caused by secondary flow significantly increased. At $i=8°$, the proportion of secondary flow loss reached 47%, indicating the most significant impact. Full article

The accurate prediction of tip leakage flow is the premise for flow mechanism analysis and compressor performance optimization. The detached eddy simulation (DES) method, which compromises cost and accuracy, has excellent potential for a high Reynolds flow, like a compressor.However, in the case of tip leakage flow, especially when there are multiple wall boundary layers and strong shear between the mainstream and leakage flow, the DES method exhibits accuracy deficiencies. This paper explores the resolution of the critical detailed structures using the DES method and its correlation with the accuracy of time-averaged aerodynamic parameter predictions. Based on this, we propose the necessary conditions for the DES method to accurately predict the leakage flow from the perspective of the detailed structure of the flow field. A simplified model is proposed to emphasize the characteristics of tip leakage flow with “multiple walls + narrow tip gap”, and the high-fidelity flow field of the WALE LES method is used as a benchmark. With the main fluctuation structures obtained by the SPOD method, it is concluded that the DES method is unable to resolve the Kelvin–Helmholtz instability at the initial position of the leakage, which leads to the generation of the secondary leakage vortex upstream of the leakage and the breakdown of the induced vortex, two critical flow structures, being incorrectly estimated. This can lead to misestimationsof the force direction on the tip leakage vortex and the main fluctuation on the flow field. As a result, the tip leakage vortex trajectory evolves toward the middle of the passage along the tangential direction and away from the upper wall downstream of the leakage compared with the LES results. Predictions of losses in the upstream and midstream regions are underestimated, whereas they are overestimated downstream of the leakage and outside the passage.Therefore, the accurate resolution of these two critical detailed structures is an essential prerequisite for the precise prediction of tip leakage flow using DES series methods. Full article

Gas–liquid multiphase pumps are critical transportation devices in the petroleum and chemical engineering industries, and improving their conveyance efficiency is crucial. This study investigates the influence of blade tip clearance variations on the flow characteristics within a multiphase pump. Numerical simulations were conducted using Eulerian two-phase and SST k-ω turbulence models with four distinct tip clearance sizes (0 mm, 0.3 mm, 0.6 mm, and 0.9 mm). The performance curve, tip leakage flow (TLF), and internal gas distribution were subjected to analysis. The results indicate that the TLF is linearly related to the clearance size and traverses multiple flow passages, resulting in energy losses and a reduced pump head coefficient. Larger tip clearances (0.6 mm and 0.9 mm) exhibited a more uniform flow pattern, contrasting the irregularities seen with a 0.3 mm clearance. Compared to no tip clearance (0 mm), gas holdup within the impeller passages decreased by 18.39%, 39.62%, and 58.53% for clearances of 0.3 mm, 0.6 mm, and 0.9 mm, respectively, leading to decreased overall system efficiency. This study highlights the connection between tip clearance size and flow dynamics in multiphase pumps, offering insights for optimal tip clearance selection during multiphase pump design. Full article

The motivation to design a more efficient and compact aircraft engine leads to a continuous increase in overall pressure ratio and decrease in the stage number in compressors. Compared to the traditional multi-stage compressor, a single-stage ultra-high-pressure-ratio centrifugal compressor with a pressure ratio higher than 10.0 can significantly improve the engine’s power-to-weight ratio and fuel economy with a reduced structure complexity. Thus, it has great potential to be adopted in the compression system of advanced aero engines, such as turboshaft engines, in the future. However, the highly narrow Stable Flow Range (SFR) of ultra-high-pressure-ratio centrifugal compressors is a severe restriction for engineering applications. This research focuses on the aerodynamic performance of a ultra-high-pressure-ratio centrifugal compressor, and three-dimensional simulation is employed to investigate the effect of Self-Recirculating Casing Treatment (SRCT) on the performance and stability of the centrifugal compressor. Firstly, the parametric model of SRCT is established to investigate the effect of geometry parameters (rear slot distance and rear slot width) on the aerodynamic performance of the centrifugal compressor. It is concluded that SRCT improves the compressor’s SFR but deteriorates its efficiency. Also, a non-linear and non-monotone relationship exists between the SFR and rear slot distance or width. Then, the flow mechanism behind the effect of SRCT is explored in detail. By introducing the SRCT, an additional flow path is provided across the blade along the circumferential direction, and the behavior of the shock wave and tip leakage flow is significantly changed, resulting in the obviously different loading distribution along the streamwise direction. As a result, the mixing and flow separation loss are enhanced in the impeller flow passage to deteriorate the efficiency. On the other hand, the blockage effect caused by the mixing of slot recirculation and mainstream flow near the impeller inlet increases the axial velocity and reduces the incidence angle below the 90% spanwise section, which is considered to effectively stabilize the impeller flow field and enhance the stability. Full article

This paper presents experimental investigations on aerodynamic performance of a ducted coaxial-rotor system to evaluate its potential application as a small unmanned aerial vehicle (SUAV). Aimed at determining the influence of design parameters (rotor spacing, tip clearance and rotor position within the duct) on hover performance, a variety of systematic measurements for several correlative configurations (single/coaxial rotor with or without a duct) in terms of thrust and torque, as well as power, were conducted in an attempt to identify a better aerodynamic configuration. The experimental results for the coaxial-rotor system indicated that varying rotor spacing affected the thrust-sharing proportion between the two rotors, but this had no significant effect on the propulsive efficiency. The optimal H/R ratio was identified as being 0.40, due to a larger thrust and stronger stability in the case of identical rotation speeds. As for the ducted single-rotor configuration, the tip clearance played a dominant role in improving its thrust performance, especially for smaller gaps ($\delta \le 0.015\mathrm{R}$), while the rotor position made subordinate contributions. The maximum performance was obtained with the rotor located at the P₅ position (0.31C_d from the duct lip), which resulted in an enhancement of approximately 20% in power loading over the isolated single rotor. When the coaxial rotors were surrounded within the duct, the system thrust for a given power degraded with the increasing rotor spacing, which was mainly attributed to the upper rotor suffering from heavier leakage losses. And hence, the ducted coaxial-rotor system with S₁ spacing had the best propulsion efficiency and hover performance with a figure of merit of 0.61. Full article

The unstable flow of a shaft tubular pump device (STPD) leads to energy loss, thereby reducing its efficiency. The aim of this study is to investigate the distribution pattern of energy loss in STPDs. This paper reveals that the two components with the highest proportion of energy loss are the impeller and the outlet passage. Furthermore, turbulent entropy production is the primary cause of energy loss. Due to the wall effect, the energy loss in the impeller mainly occurs near the hub and shroud. Additionally, the presence of a tip leakage vortex near the shroud further contributes to the energy loss in the region near the shroud. This results in the energy loss proportion exceeding 40% in the region with a volume fraction of 14% near the shroud. In the outlet passage, the energy loss mainly occurs in the front region, with a volume fraction of 30%, and the energy loss in this part accounts for more than 65%. Finally, this study reveals the locations of the vortex in the STPD under different flow-rate conditions, and when the distribution of energy loss is visualized, it is found that the energy loss occurs high in the vortex regions. Full article

The oblique flow compressor is one of the important components in the compressed air energy storage (CAES) system. The structural shape of the radial inlet chamber (RIC) directly affects the compressor performance, and a reasonable RIC design should achieve the smallest total pressure loss and outlet distortion as much as possible to meet the structural design. To study the influence of splitter blades, 4 RICs equipped with different numbers of splitter blades are designed, and the performance of 4 RICs and the overall performance of the compressor is calculated. The results show that with the increase in the number of splitter blades, the stall margin increases from 6.3% to 13.94%. At the design point, the isentropic efficiency is highest for the RIC with 17 splitter blades, and the pressure ratio is highest for the RIC with 11 splitter blades. Compared with the direct axial intake mode, the uniformity of the relative leakage distribution and the attack angle distribution of the impeller leading edge under 4 radial intake modes are poor. However, with an increase in the number of splitter blades, the uniformity of the relative tip leakage and the attack angle distribution gradually increase. The flow loss of RIC will increase simultaneously, though the uniformity of the outlet aerodynamic parameters distribution improves, and the influence on the downstream component performance gradually weakens. There is an optimal number of splitter blades in RIC, which balances the total pressure loss and distortion coefficient. Full article

An axial compressor has high efficiency under design conditions, but its stable working range is narrow. Adjusting the rotational speed can effectively expand the stable working range. In this paper, a five-stage axial compressor for a specific compressed air energy storage (CAES) system is taken as the research object, and different rotational speed (DRS) characteristics are studied with NUMECA software. Firstly, the influence of DRS on overall aerodynamic performance is explored, and the working flow range of the compressor is increased from 11.5% to 54.0%. Secondly, the effect of DRS on inlet parameters of the first stage rotor is analyzed, and the reasonable distribution of inlet parameters is obtained. Thirdly, the changing law of the internal flow is investigated at DRS. The corner separation is gradually enhanced when the rotational speed increases, and the leakage flow velocity at the rotor tip gradually improves. Finally, the loss distribution of tip clearance is researched. The result shows that the loss distribution increases significantly in both circumferential and spanwise directions when the speed increases. This work aims to provide a reference for the stable and efficient operation of axial compressors in CAES systems under the wide working range. Full article

A low specific speed centrifugal compressor with leading/trailing edge combined sweep blades is proposed. The performance and internal flow field characteristics are analyzed in detail by numerical simulations, and a bench test is carried out. It is shown that by using the combined leading/trailing edge swept blade, the stage pressure ratio of the centrifugal compressor is improved under all operating conditions, and the maximum increase can reach 6.5%. The efficiency can be markedly improved at high flow rates. Additionally, the leading edge tip leakage is reduced with the combined swept blade, the flow separation on the blade surface is inhibited, and the flow loss of low-energy flow masses downstream of the flow passage is improved. Meanwhile, the combined swept blade can increase the work area of the blade and enhance the work capacity at the blade tip position. Full article
