To address head-end three-phase current unbalance and terminal power-quality deterioration caused by uneven three-phase load allocation in a low-voltage transformer area (LVTA), this paper proposes a DC-link-voltage-control-based phase-wise unbalanced power compensation strategy for a head-to-tail flexible interconnection structure embedded in the LVTA. The proposed structure consists of two three-phase four-leg converters sharing a common DC bus and connected to the head end and tail end of the LVTA, respectively. Different from conventional phase-wise compensation methods in which the DC side mainly acts as a power-transfer channel, the proposed strategy uses the DC-link voltage control of the head-end converter as the core of compensation power generation. Specifically, the outer DC-link voltage loop generates the total active compensation power, which is then allocated among the three phases according to the measured phase-power unbalance of the LVTA, thereby yielding the phase-wise compensation current references. Combined with phase-wise quasi-proportional-resonant current control, the compensation currents of different phase legs can be regulated without explicit positive-, negative-, and zero-sequence decomposition. Meanwhile, the tail-end converter adopts PQ control to support terminal power regulation and improve the terminal voltage quality of the LVTA. To provide a theoretical basis for the proposed method, a switching-cycle averaged model of the three-phase four-leg converter is established, and the leg-level phase-wise control characteristics are analyzed under the assumptions of a stiff DC link and symmetrical converter parameters. A control-oriented equivalent LVTA model is developed in MATLAB/Simulink. The proposed strategy is validated under steady-state unbalanced, RL load, load-disturbance, and equivalent feeder-impedance conditions. In addition, a conventional positive-, negative-, and zero-sequence compensation method is introduced as a benchmark for quantitative comparison. The simulation results demonstrate that the proposed method can effectively suppress the head-end three-phase current unbalance, maintain the DC-link voltage around its reference value, and improve the terminal voltage quality of the LVTA. Compared with the conventional sequence-component-based compensation method, the proposed strategy achieves effective unbalance mitigation while avoiding explicit sequence extraction and reducing the complexity of the compensation-current generation process. This study provides a feasible control framework for three-phase unbalance mitigation in flexible low-voltage transformer areas. Full article

In flexible DC distribution systems, the three-phase four-leg (3P4L) converter demonstrates excellent performance in addressing three-phase load imbalance problems, but suffers from DC-side second harmonics and complex multi-parameter control coordination. In this paper, a flying capacitor zero-sequence leg-based 3P4L (FCZS-3P4L) converter is proposed, which introduces the three-level flying capacitor structure into the fourth zero-sequence leg, making it possible to suppress the DC-side second harmonics by using the flying capacitor for energy buffering. Meanwhile, a modulated model predictive control (MMPC) strategy for proposed FCZS-3P4L is presented. This strategy utilizes a dual-layer control strategy based on a phase-split power outer loop and a model predictive current inner loop to simultaneously achieve AC three-phase imbalance current compensation and the energy buffering of the flying capacitor, thereby eliminating the complex parameter coordination among multiple control loops in conventional control structures. A MATLAB-based simulation model and Star-Sim hardware-in-the-loop (HIL) semi-physical experimental platforms are built. The results show that the proposed FCZS-3P4L converter and corresponding MMPC control can effectively reduces three-phase current unbalance by 19.57%, and reduce the second harmonic amplitude by 57%, i.e., decreasing from 14.74 V to 6.31 V, simultaneously realizing DC-side second harmonic and AC-side three-phase unbalance suppression. Full article

To address the complexity of multi-parameter degradation identification in three-phase four-leg (3P4L) converters, this paper proposes a digital twin-based identification method for 3P4L converters, which can simultaneously identify multi-degradation parameters in a coordinated manner. Firstly, a discretized model encompassing the main circuit and control strategy of a 3P4L converter is constructed, which is based on the topology and component characteristics. Secondly, a fourth-order Runge–Kutta (RK4)-based digital twin model of the 3P4L converter is developed on the discretized physical model. Finally, a 3P4L full-simulation and hardware-in-loop (HIL)-based verification platform based on StarSim is built, in which the Levy flight–Whale Optimization Algorithm (LF-WOA) is employed to iteratively identify the multi degradation characteristic parameters of the digital twin model. The results demonstrate that the proposed digital twin model and parameter identification method can achieve the simultaneous identification of multiple parasitic parameters, such as on-state resistance, capacitance, and inductance, with an identification accuracy exceeding 90%. Full article

This manuscript proposes a novel approach for determining phase and neutral-current-ripple RMS in grid-connected four-leg inverters with the neutral inductor. The harmonic pollution is determined for any arbitrary pulse width modulation (PWM) technique and a generic value of the neutral inductor. Thanks to the proposed approach, it is possible to describe the neutral inductor in a parametric way with respect to phase inductors and obtain a wide range of results, ranging from a direct neutral connection (no neutral inductor) to a conventional three-phase inverter (no fourth wire) for any value of modulation index and common mode injection. The results permit one to compare different design choices in multiple scenarios effectively. The findings were validated by numerical simulations and experimental tests employing the most popular PWM techniques, such as space vector PWM (SVPWM) and discontinuous PWM (DPWM). Full article

In the field of power electronics-based electrical power conversion, the Dual Active Bridge (DAB) topology has become very popular in recent years due to its characteristics (e.g., bidirectional operation and galvanic isolation), which are particularly suitable to applications such as interface to renewable energy sources, battery storage systems and in smart grids. Although this converter type has been extensively investigated, its analysis and control still pose many challenges, due to the multiple control variables that affect the complex behavior of the converter. This paper presents a theoretical model of the single-phase DAB converter. The proposed model is very general, i.e., it can consider any modulation technique and operating condition. In particular, the converter is seen as composed by four legs, each capable of generating voltage on the inductor, and by the two output legs, which can steer the resulting inductor current to the load. Three variables are considered as the control inputs, i.e., the phase-shifts with respect to one leg. This approach results in a very simple yet accurate closed-form algorithm for obtaining the inductor current waveform. Moreover, a novel analytical model is proposed for calculating the average output current, based on the phase-shift values, independently of the output voltage. It is also shown that average output current can be varied cycle-by-cycle, with no further dynamics. In fact, average output current is not affected by the initial value of inductor current or by DC offset (which may arise during transients). The proposed models can be exploited at several stages of development of a DAB: during the design stage, for fast iteration, when selecting its operating points and when designing the control. In fact, based on the analytical results, a novel control loop is proposed, which adopts a “fictitious” (i.e., open-loop) inner current regulation loop, which can be applied to any modulation scheme (e.g., Single Phase-Shift, Triple Phase-Shift, etc.). The main advantage of this control scheme is that the simple dynamics of the output voltage versus the average output current can be decoupled from the complicated relationship between the phase-shifts and the output current. Moreover, a Finite Control Set (FCS) method is proposed, which selects the optimal operating points for each operating condition and control request, ensuring full Zero-Voltage Switching (ZVS) in all cases. The analytical results obtained and control methods proposed are verified through simulations and extensive experimental tests. Full article

This paper presents a thorough prediction of DC-link voltage switching ripples in the three-phase four-leg inverters operating in balanced and unbalanced working conditions. The unbalanced modes examined here employ the highest degree of AC current imbalance while still preserving three-phase operation. This behavior can be found in many grid-connected or standalone grid-forming three-phase converters that supply “heavy” single-phase loads, comprising a recent trend in smart-grid, smart electric vehicle (EV)-charging applications. In this sense, for instance, the smart EV chargers might be employed in conditions when different power is drawn/injected from/to the grid, providing power conditioning services to the latter. The analysis of three-phase four-leg inverters is then extended to single-phase operations typical of home-charging or vehicle-to-home (V2H) applications. Their performances in terms of DC-link voltage switching ripple are demonstrated. Two of the most common carrier-based PWM modulation techniques are employed to drive the three-phase inverter—namely, sinusoidal PWM and centered PWM (carrier-based analogy of the space vector modulation). The derived mathematical expressions of peak-to-peak and RMS values of DC-link voltage switching ripple for balanced and unbalanced conditions are handy for designing the associated DC-link capacitor and estimating the overall efficiency of the converter. Extensive numerical simulations and experimental tests have been performed to validate the presented analytical developments. Full article

This paper presents a comprehensive study of peak-to-peak and root-mean-square (RMS) values of AC current ripples with balanced and unbalanced fundamental currents in a generic case of three-phase four-leg converters with uncoupled AC interface inductors present in all three phases and in neutral. The AC current ripple characteristics were determined for both phase and neutral currents, considering the sinusoidal pulse-width modulation (SPWM) method. The derived expressions are simple, effective, and ready for accurate AC current ripple calculations in three- or four-leg converters. This is particularly handy in the converter design process, since there is no need for heavy numerical simulations to determine an optimal set of design parameters, such as switching frequency and line inductances, based on the grid code or load restrictions in terms of AC current ripple. Particular attention has been paid to the performance comparison between the conventional three-phase three-leg converter and its four-leg counterpart, with distinct line inductance values in the neutral wire. In addition to that, a design example was performed to demonstrate the power of the derived equations. Numerical simulations and extensive experimental tests were thoroughly verified the analytical developments. Full article

Three-phase four-leg voltage-source converters have been considered for some recent projects in smart grids and in the automotive industry, projects such as on-board electric vehicles (EVs) chargers, thanks to their built-in ability to handle unbalanced AC currents through the 4th wire (neutral). Although conventional carrier-based modulations (CBMs) and space vector modulations (SVMs) have been commonly applied and extensively studied for three-phase four-leg voltage-source converters, very little has been reported concerning their pollution impact on AC grid in terms of switching ripple currents. This paper introduces a thorough analytical derivation of peak-to-peak and RMS values of the AC current ripple under balanced and unbalanced working conditions, in the case of three-phase four-leg converters with uncoupled AC-link inductors. The proposed mathematical approach covers both phase and neutral currents. All analytical findings have been applied to two industry recognized CBM methods, namely sinusoidal pulse-width modulation (PWM) and centered PWM (equivalent to SVM). The derived equations are effective, simple, and ready-to-use for accurate AC current ripple calculations. At the same time, the proposed equations and diagrams can be successfully adopted to design the conversion system basing on the grid codes in terms of current ripple (or total harmonic distortion (THD)/total demand distortion (TDD)) restrictions, enabling the sizing of AC-link inductors and the determination of the proper switching frequency for the given operating conditions. The analytical developments have been thoroughly verified by numerical simulations in MATLAB/Simulink and by extensive experimental tests. Full article

The rectifier module is the key part of a permanent magnet synchronous generator integrated DC output system (PMSG-IDOS) with low-voltage and high-current. The high-speed switching device of the rectifier module is the main source of electromagnetic interference (EMI). In this paper, the matrix extraction method is proposed to establish an accurate conducted interference model, and a 3D crimped SiC MOSFET model is established via Ansoft Q3D simulation software. The matrix of the parasitic parameters between poles of the MOSFET is simulated to extract the accurate parasitic parameters. Furthermore, a high-precision conducted interference simulation model of the pulse width modulation (PWM) rectifier system is established. Then, the space vector pulse width modulation (SVPWM) jump-backward control strategy based on the three-phase four-leg structure is proposed to suppress the common-mode interference, and the comparison with other two methods is carried out based on this model. Finally, the experimental platform of a 5 V/1000 A synchronous generator with rectifier is constructed, and conducted interference is tested in accordance with the simulated results. It demonstrates the accuracy of the model with parasitic parameters based on the matrix extraction method. This paper provides a more simple and effective reference method for the prediction study of conducted interference in power converter systems. After comparing the simulation results with the experimental results, it is proven that the SVPWM jump-backward control strategy based on the three-phase four-leg structure can ensure the output balance of the bridge leg and allow the common-mode (CM) interference to reach the ideal state. Full article

A high-frequency link (HFL) three-phase four-leg matrix converter (MC) can output three-phase balanced voltage for unbalanced load conditions. It is an inverter with great development potential. This paper presents a hybrid pulse width modulation (HPWM) strategy for a four-wire matrix converter based on the fourth bridge leg compensation method. Firstly, the rear-stage topology of a high-frequency link three-phase four-leg matrix converter is decoupled into two sets of ordinary three-phase four-wire inverters. Then the compensation strategy is applied to separate the fourth bridge leg from the coupling of the ordinary inverter and realize its independent control. Under the theory of compensation, the fourth bridge leg plays a role in compensating the deviation of the neutral point potential when the load is unbalanced, the fourth bridge leg does not need to work when the load is balanced. Finally, the fourth bridge leg modulation wave obtained by the compensation method is combined with the front three bridge leg modulation waves to perform the coupling control using the hybrid pulse width modulation strategy. It has changed the problem that the previous hybrid pulse width modulation strategy cannot be directly applied to the four-wire matrix converter. This strategy is simple to control, without adding any auxiliary commutation detection circuitry, can effectively solve the inherent commutation problem in the bidirectional switch tube of the four-wire matrix converter. It simplifies the complexity of the system, reduced control cost, and high switching loss caused by high switching frequency. The fast adjustment function of compensation strategy makes the dynamic response performance of system under load fluctuation state more prominent, the harmonic distortion rate is smaller. The perfect combination of two strategies allows the high-frequency link three-phase four-leg matrix converter with any form of load to give full play to its structural advantages. The related work verifies the feasibility and effectiveness of the modulation method and control logic. Full article

This paper introduces a novel multi-converter-based unified power quality conditioner (MCB-UPQC). Three optimization methods are proposed based on the traditional UPQC: (1) The shunt converter is substituted with multi-modular parallel converters. Hence, the reactive power and harmonic currents can be increased greatly, which are suitable for low-voltage high-current distribution systems. (2) The series converters consist of three H-bridge inverters, and each of the H-bridge inverters is controlled separately. The control strategy is easier to achieve and can improve the control performance of voltage regulation under unbalanced voltage sag or swell. (3) A three-phase four-leg (3P4L) converter is connected to the common DC bus of the proposed UPQC to connect the renewable energy and energy storage system. The detailed mathematical models of shunt and series converters are analyzed, respectively. A multi-proportional resonant (PR) controller is presented in the voltage regulation and reactive power compensation control algorithms. The simulation results verify the feasibility of the control algorithms. Finally, the experimental platform is established, and the experimental results are presented to verify the validity and superiority of the proposed topology and algorithms. Full article

This paper suggests an enhanced control scheme for a four-leg battery energy storage systems (BESS) under unbalanced and nonlinear load conditions operating in the isolated microgrid. Simplicity, tiny steady-state error, fast transient response, and low total harmonic distortion (THD) are the main advantages of the method. Firstly, a new decoupled per-phase model for the three-phase four-leg inverter is presented. It can eliminate the effect of power stage coupling on control design; thus, the three-phase four-leg power inverter can be viewed as three single input single output (SISO) control systems. Then, using an improved orthogonal signal generation method, the per-phase model of the four-leg inverter in the stationary and synchronous frame is derived. As the second step, a per-phase multi-loop control scheme for the four-leg inverter under unbalanced load conditions is suggested. The proposed control strategy has the ability to provide balanced output voltages under unbalanced load conditions by avoiding the need to deal with the symmetrical components. Finally, a multi-resonant harmonic compensator is used to actively prevent low-order harmonic currents to distort the output voltages of the three-phase four-leg grid-forming power converter. Simulations results are also presented to verify the performance of the suggested control strategy. Full article

This paper proposes a model predictive direct power control scheme for nonredundant fault tolerant grid-connected bidirectional voltage source converter (BVSC) with balanced dc-link split capacitor voltage and high reliability. Based on the operation analysis of fault-tolerant BVSC with phase leg faults, a power predictive model of three-phase four-switch fault-tolerant topology in αβ coordinates is established, and the space voltage vectors with unbalanced dc-link split capacitor voltage are analyzed. According to the power predictive model and cost function, the optimal space voltage vector is selected to achieve a flexible, smooth transition between inverter and rectifier mode with direct power control. Pulse width modulation and phase locked loop are not required in the proposed method. The constraint of dc-link voltage constraint is designed for the cost function to achieve a central point of dc-link voltage offset suppression, which can reduce the risk of electrolytic capacitor failure for over-voltage operation. With the proposed control method, the converter can work continuously in both inverter mode and rectifier mode, even if phase leg faults occur. The simulation and experimental results show good steady-state and dynamic performance of the proposed control scheme to enhance the reliability of bidirectional power conversion. Full article

This paper describes the design and implementation of three-level power converters for wind-driven permanent-magnet synchronous generators with unbalanced loads. To increase voltage stress and reduce current harmonics in the electrical power generated by a wind generator, a three-phase, three-level rectifier is used. Because a synchronous rotating frame is used on the AC-input side, the use of a neutral-point-clamped controller is proposed to increase the power factor to unity and reduce current harmonics. Furthermore, a novel six-leg inverter is proposed for transferring energy from the DC voltage to a three-phase, four-wire AC source with a constant voltage and a constant frequency. The power converters also contain output transformers and filters for power buffering and filtering, respectively. All three output phase voltages are fed back to control the inverter output during load variations. A digital signal processor is used as the core control device for implementing a 1.5 kV, 75 kW drive system. Experimental data show that the power factor is successfully increased to unity and the total current harmonic distortion is 3.2% on the AC-input side. The entire system can attain an efficiency of 91%, and the voltage error between the upper and lower capacitors is approximately zero. Experimental results that confirm the high performance of the proposed system are presented. Full article

Compared with the three-phase, two-split-capacitor active power filter (3P2C-APF), the three-phase, four-leg active power filter (3P4L-APF) has been widely used in three-phase, four-wire grid utility for power quality control due to its numerous advantages, such as higher current output capability, particularly in phase N, lower current and easier voltage control on the DC-side. However, designing the grid-connecting interface, which is between the voltage source converter (VSC) and grid utility, is rather difficult due to the higher requirement for current ripple filtering in phase N, cross-coupling in four phases and lack of relevant design methodology and specification. In this paper, a four-branch LCL-type (4B-LCL) grid-connecting interface is proposed for 3P4L-APF, which features better current ripple filtering performance without decreasing the current output capability in all phases. First, this paper describes the mathematical models of 4B-LCL in the fully-complex-vector form from the zero and non-zero sequence perspective, resulting in two independent and uniform equivalent circuits without cross coupling terms. Then, the 4B-LCL parameter design method based on the most comprehensive performance index is proposed, including three main stages as the specification: performance index requirement determination, fulfillment of that requirement, and verification. Finally, the validity and effectiveness of the proposed design are proven by the simulated and experimental results of a 3P4L-APF with 4B-LCL. Full article
