Multi-view fringe projection profilometry systems that integrate a telecentric projector with multiple oblique-view cameras offer unique advantages for inspecting high dynamic-range surfaces featuring densely packed, intricate microstructures. Nevertheless, such systems encounter fundamental calibration challenges, namely, sign ambiguity in the rotation matrices and truncated extrinsic parameters inherent to telecentric projector models, as well as difficulties in multi-view point cloud registration. This paper introduces a novel calibration framework with three principal contributions. First, we resolve the sign ambiguity by calibrating the telecentric projector under a quasi pinhole model and directly transferring the extrinsic sign conventions, thereby obviating the need for costly precision displacement stages or elaborate virtual targets. Second, we fix the axial-gauge freedom by constraining the origin of the projector coordinate system to lie on the XY-plane of the camera coordinate system. Third, we establish precise relative poses between all cameras and a designated reference camera, enabling unified multi-view point cloud registration directly within the projector coordinate frame, which substantially reduces alignment errors and accelerates data processing. Experimental results demonstrate marked improvements in accuracy: reprojection root-mean-square errors of 0.084 pixels for the cameras and 0.106 pixels for the projector, corresponding to in-plane spatial resolutions of 0.21 µm and 0.26 µm, respectively. The proposed method offers a robust solution for micron-level inspection in semiconductor packaging and precision manufacturing. Full article

As the primary power transmission conduits, aircraft hydraulic pipelines are critical for actuating flight control surfaces and landing gear systems. Accurate in situ strain evaluation of these pipelines is essential, as installation-induced pre-loads directly compromise fatigue life and sealing performance, threatening overall system reliability. However, such evaluation is frequently hindered by the perspective distortions and limited depth of field inherent in conventional imaging systems. To overcome these metrological limitations, this study presents a novel virtual telecentric camera array system designed for high-precision, non-contact strain measurement. Unlike traditional pinhole models, the proposed system leverages a catadioptric setup with planar mirrors to create a virtual four-eye telecentric array from a single physical lens, ensuring constant magnification within the depth of field. A comprehensive simulation framework was established to rigorously compare the reprojection errors and scale accuracies between telecentric and pinhole projection models, quantitatively demonstrating the superior stability of the telecentric approach. Furthermore, a dedicated calibration strategy for non-overlapping telecentric fields of view was developed and validated. Experimental results from pipeline installation tests indicate a high concordance with strain gauge data, confirming that the proposed telecentric system effectively mitigates parallax errors and provides a robust solution for static and quasi-static micro-scale deformation monitoring in complex assembly environments. Full article

As one of the most important optical components of a laser scanning system, the f-theta lens group largely determines the working range and scanning accuracy of this system. In this paper, a numerical iterative design method of a double freeform surface telecentric f-theta lens is proposed. Then the scanning linearity and optical transmittance of the designed f-theta lens are simulated and analyzed. The results show that the f-theta lens designed by this method has a compact structure, large scanning area, extremely high optical transmittance over the entire field of view, and stable, controllable error of scanning linearity. Different from the optimization design method of the traditional f-theta lens group, the two freeform surfaces of this f-theta lens can be obtained directly and simultaneously by using this numerical iterative method, which consumes less computational resources and significantly reduces the design complexity. Full article

A double-sided telecentric zoom optical system can ensure the measurement and detection accuracy for different workpiece sizes and plays a crucial role in industrial detection. The conventional double-sided telecentric mechanical zoom system is faced with the problem of complex structure and difficult focusing. To address these issues, a liquid lens is applied to design a non-displacement double-sided telecentric zoom system in this paper. Here, the design method of the conventional double telecentric zoom system is analyzed first; then, the liquid lenses are substituted for the mechanical motion groups. Finally, a double-sided telecentric zoom system with a detection range of 25~60 mm and a magnification of −0.44×~−0.183× has been designed and optimized by Zemax software. The design results show that in the process of magnification, the root mean square radius of the diffuse spot in the system is smaller than the pixel size during the process of zooming. The modulation transfer function values at the Nyquist frequency of 80 lp/mm are all above 0.4, distortion is controlled within 0.2, and telecentricity is less than 0.5°, indicating that the system has excellent imaging quality, low distortion, and high telecentric and other characteristics, which meet system requirements. The design method proposed in this paper can provide an effective solution for the rapid conversion of displacement zoom systems to non-displacement zoom systems. Full article

Precision machining technology has received significant attention from researchers and engineers. With the increasing complexity of product designs and continuous advancements in high-tech industries, the precision requirements for manufacturing are constantly escalating. For researchers who are new to precision machining, conducting experiments directly on commercial equipment is resource-intensive and does not accommodate diverse working scenarios. Therefore, designing a generalized precision machining experimental test platform is particularly important. This paper presents a practical plan to construct such a platform, integrating key components such as a gantry-type Cartesian coordinate robot, a 2D rotary table, a 2D precision slide stage, a galvanometer, and a telecentric lens. The platform serves as a test environment for verifying the feasibility of various precision machining control algorithms. It not only demonstrates the desired stability and scalability but also offers a user-friendly operational interface via the LabVIEW front panel. This facilitates simple and efficient experimental operations, providing an effective and reliable environment for testing precision machining control algorithms. Full article

Lidar has the advantages of high accuracy, high resolution, and is not affected by sunlight. It has been widely used in many fields, such as autonomous driving, remote sensing detection, and intelligent robots. However, the current lidar detection system belongs to weak signal detection and generally uses avalanche photoelectric detector units as detectors. Limited by the current technology, the photosensitive surface is small, the receiving field of view is limited, and it is easy to cause false alarms due to background light. This paper proposes a method based on a combination of image-side telecentric lenses, microlens arrays, and interference filters. The small-area element detector achieves the high-concentration reception of echo beams in a large field of view while overcoming the interference of ambient background light. The image-side telecentric lens realizes that the center lines of the echo beams at different angles are parallel to the central axis, and the focus points converge on the same focal plane. The microlens array collimates the converged light beams one by one into parallel light beams. Finally, a high-quality aspherical focusing lens is used to focus the light on the small-area element detector to achieve high-concentration light reception over a large field of view. The system achieves a receiving field of view greater than 40° for a photosensitive surface detector with a diameter of 75 μm and is resistant to background light interference. Full article

The numerical aperture (NA) of objective lens optical (inspection) systems has been increased to achieve higher resolution. However, the depth of focus decreases with an increase in the NA, and focusing becomes difficult. Therefore, the entire optical lens in currently developed optical inspection systems must be moved to focus within the depth of focus. To achieve a high resolution, many lenses are used in optical inspection systems, increasing the size and weight of the optical systems. To address this issue, a focus control group was placed on a tube lens that could adjust its focus based on the movement of the sample in front of the objective lens. Therefore, we developed a focus range increment to focus on the range of the optical inspection system. Using objective lenses with focal lengths of 30 and 60 mm and tube lenses with a focal length of 300 mm, optical systems for 10× and 5× inspection were constructed. In the designed optical systems, the weights of the objective lenses with focal lengths of 30 and 60 mm were calculated to be approximately 844 and 570 g, respectively. These values confirm that the weight of the moving group can be reduced. Full article

Based on the application requirements of high spectral resolutions, high spatial resolutions and wide swatches, a new-generation, high-performance, spaceborne, hyperspectral imaging spectrometer (NGHSI) with a spatial resolution of 15 m and a swatch of 90 km is proposed. The optical system of the NGHSI has a focal length of 1128 mm, an F-number of three, a field of view (FOV) of 7.32° and a slit length of 144 mm. A new off-axis, multi-mirror telescope structure with intermediate images is put forward, which solves the design problem that realizes secondary imaging and good telecentricity at the same time. And a new off-axis lens-compensation Offner configuration is adopted to address the challenge of the high-fidelity design of spectral imaging systems with long slit lengths. The relationship between X-Y polynomials and aberration coefficients is analyzed, and the X-Y polynomial freeform surfaces are used to correct the off-axis aberrations. The design results show that the image quality of the telescope system is close to the diffraction limit. The smile, known as the spectral distortion along the line, and keystone, which is the magnification difference for different wavelengths, of the spectral imaging system are less than 1/10 pixel size. The complete optical system of the NGHSI, including the telescope system and the spectral imaging system, has excellent imaging quality and the layout is compact and reasonable, which realizes the miniaturization design. Full article

We propose a novel hybrid FPP-DIC technique to measure an object’s shape and deformation in 3D simultaneously by using a single 3CCD color camera, which captures the blue fringe patterns and red fluorescent speckles within the same image. Firstly, red fluorescent speckles were painted on the surface of the specimen. Subsequently, 12 computer-generated blue fringe patterns with a black background were projected onto the surface of the specimen using a DLP projector. Finally, both the reference and deformed images with three different frequencies and four shifted phases were captured using a 3CCD camera. This technique employed a three-chip configuration in which red–green–blue chips were discretely integrated in the 3CCD color camera sensor, rendering independent capture of RGB information possible. Measurement of out-of-plane displacement was carried out through the implementation of Fringe Projection Profilometry (FPP), whereas the in-plane displacement was evaluated using a 2D Digital Image Correlation (DIC) method by leveraging a telecentric-lens-based optical system. In comparison to the traditional FPP-DIC hybrid methodology, the present approach showed a lower incidence of crosstalk between the fringe patterns and speckle patterns while also offering a corrective for the coupling of the in-plane displacement and out-of-plane displacement. Experimental results for the in-plane cantilever beam and out-of-plane disk comparisons with the traditional 3D-DIC method indicated that the maximum discrepancy obtained between FPP-DIC and 3D-DIC was 0.7 μm and 0.034 mm with different magnifications, respectively, validating the effectiveness and precision of the novel proposed FPP-DIC method. Full article

Besides precise levels, precise leveling staffs are a crucial part of the measuring equipment when carrying out geodetic (geometric) leveling measurements. The leveling staffs define the scale of the height reference system, so it is important to calibrate them periodically and when necessary. This paper shortly describes the development of the new method of calibrating leveling staffs in the Laboratory for Measurements and Measuring Technique of the Faculty of Geodesy, University of Zagreb. The existing horizontal comparator was upgraded by installing a servo-motorized positioning drive with a mounted CCD camera and telecentric lens that is used to record graduations of the leveling staffs. The software was developed to support the management of the comparator system, as well as for the analysis and processing of images and measurement data and, most importantly, giving the result in the form of a calibration report. The main subject of this paper is a detailed assessment of the measurement uncertainty of determining the position of the edges of the graduation lines and determining the scale of precise centimeter and coded leveling staffs. The estimates were confirmed by experimental measurements. Full article

Imaging using millimeter waves (MMW) and terahertz (THz) waves can help inspect hazardous materials hidden beneath clothing in a non-contact and non-invasive manner. A 3D terahertz imaging system for security gate applications in the 275–305 GHz range was developed and experimentally demonstrated to detect concealed objects carried by pedestrians. This system performs 3D measurements by combining depth detection using frequency-modulated continuous wave (FM-CW) radar, vertical scanning of the detection spot using a 1D high-speed mechanical beam scanner, and horizontal movement of the irradiated area and detection spot as the pedestrian walks. The high-speed beam scanner comprises an F-Theta telecentric lens and a polygon mirror. It has a vertical line scan rate of 142 lines/s and spatial resolution of ~10 mm, consistent with the design value, and a depth resolution of ~7 mm, which is 40% larger than the theoretical value estimated from the FM-CW radar principle. The depth-dependent lateral distortion in 3D images, known as telecentricity, measured using the body scanner imaging system, was also evaluated. Consequently, images with the same magnification were obtained at a range of more than 500 mm of focus depth. Finally, the detection of concealed objects carried by pedestrians was demonstrated, showing that the system can work for a pedestrian walking at speeds from 4 km/h to 7 km/h. Full article

The galvanometer scanning system plays a crucial role in modern laser material processing. With the development of this industry, the requirements for galvanometer scanners are getting higher and higher, especially to overcome the inherent disadvantages that still exist, such as image distortion, marking speed and accuracy in state-of-the-art scanning systems. In this paper, a single-axis optical scanner using two galvanometers in combination with one f-theta telecentric lens and a 343 nm femtosecond pulse laser source is proposed as a new approach for enhancing the precision of laser micromachining technology. The additional second galvanometer is used to manipulate the output laser beam of the first galvanometer to the path with less lens aberration to enhance the telecentricity correction and the effective scanning area. This is based on the international standard regulation ISO (the International Organization for Standardization) 11145:2018 requirements in optics and photonics, in which an important criterion is for the roundness of the focused beam spot to be greater than 87% to determine the effective working length of the proposed scanning system compared to the conventional scanning system. It is demonstrated by optical simulations and real optical experiments that the effective working length can be increased by 3.6 mm, corresponding to 8.1% of the effective scanning field, to achieve a laser material processing system with ISO standard. The damped least squares (DLS) algorithm in optical design software ZEMAX is used to optimize the deflected angle of the two galvanometers to obtain the optimal incident position of the f-theta lens. Full article

We propose a method for accurately calibrating a telecentric structured light system consisting of a camera attached to a bilateral telecentric lens and a pin-hole projector. The proposed method can be split into two parts: axial calibration and transverse calibration. The first part is used for building the relationship between phase and depth by means of a planar plate with ring markers on its surface at several different positions in the measuring volume. The second part is used for establishing the relationship between transverse coordinates and pixel positions with the depth offered by a translation stage and the extracted ring centers. Compared with existing methods that require projector calibration, the proposed method can avoid a propagation of the correspondence error between the camera imaging plane and projector imaging plane, thus increasing calibration accuracy. The calibrated telecentric structured light system is further used for three-dimensional (3D) reconstructions of a planar, a ruled surface, and complex surfaces. Experimental results demonstrate that the proposed system calibration method can be used for accurate 3D measurement. Full article

The use of airborne-mapping technology plays a key role in the acquisition of large-scale basic geographic data information, especially in various important civil/military-mapping missions. However, most airborne-mapping cameras are limited by parameters, such as the flight altitude, working-environment temperature, and so on. To solve this problem, in this paper, we designed a panchromatic wide-spectrum optical system with a focusing function. Based on the catadioptric optical structure, the optical system approached a telecentric optical structure. Sharp images at different object distances could be acquired by micro-moving the focusing lens. At the same time, an optical passive compensation method was adopted to realize an athermalization design in the range of −40–60 °C. According to the design parameters of the optical system, we analyzed the influence of system focusing on mapping accuracy during the focusing process of the airborne-mapping camera. In the laboratory, the camera calibration and imaging experiments were performed at different focusing positions. The results show that the experimental data are consistent with the analysis results. Due to the limited experiment conditions, only a single flight experiment was performed. The results show that the airborne-mapping camera can achieve 1:5000 scale-imaging accuracy. Flight experiments for different flight altitudes are being planned, and the relevant experimental data will be released in the future. In conclusion, the airborne-mapping camera is expected to be applied in various high-precision scale-mapping fields. Full article

We propose a distortion-corrected integral imaging (II) 3D display system based on lens array holographic optical element (LAHOE). The LAHOE is used as a projection screen. The projection beam of the LAHOE is parallel light. Hence, the projection system consists of a spatial light modulator, a reverse projection lens, a relay optical element, and a telecentric lens. The acquired 3D data and the reconstructed 3D image of II are symmetrically related to each other. Therefore, there is lens distortion in the projection system. To avoid affecting the viewing experience of the viewers, the elemental image array (EIA) is projected obliquely on the LAHOE, causing the lateral distortion of the EIA. There is a position deviation in the projection system, so the projected EIA has geometric deformation. Due to the distortion of the EIA, it is difficult to precisely align the projected EIA and LAHOE, which results in serious flip of the reconstructed 3D images. The distortion of the EIA affects the asymmetry of the 3D image reconstruction. Lens distortion can be solved by the distortion compensation method. Lateral and the geometric deformation can be solved by the perspective transformations in computer graphics. After correction, the undistorted EIA is projected, and the projected EIA on the LAHOE has little distortion. In the process of 3D image reconstruction, the causes of asymmetry affecting 3D image reconstruction are analyzed, and the issues that generate these asymmetric factors are addressed. Experimental results indicate that a better 3D display effect is achieved. Full article
