Search Results (161)

Confinement with a rectangular cross-section is commonly used to simulate the role of a swirl combustor, yet its effect on swirling flows remains poorly understood. This study investigates the influence of confinement on the isothermal flow field of a counter-rotating swirler. A particle image velocimetry (PIV) system was employed to measure the swirling flow field under varying confinement ratios at an air pressure drop equivalent to 3% of atmospheric pressure. The results reveal two distinct flow patterns, delineated by a critical confinement ratio of approximately 8.92. Detailed analyses of the velocity components, contour distributions, and Reynolds shear stresses were conducted. The two flow patterns are attributed to the wall attachment effect and swirling intensity, respectively. Furthermore, the results confirm that the swirling flow field is primarily governed by the confinement ratio. Full article

Reducing the anthropogenic impact on the environment is an increasingly urgent challenge, particularly in the energy and heat generation sectors. This study presents the results of an experimental investigation into the combustion characteristics of four nozzle types in a burner system. The experiments focused on emissions of NOx and CO under varying equivalence ratios. This study presents an experimental investigation of combustion with one swirl-stabilized nozzle and two multihole plates under varying equivalence ratios (φ). The swirl-stabilized configuration produced the highest NOx, reaching 54.4 ppm at φ = 0.9, which we attribute to higher flame temperatures and longer effective residence. In contrast, the multihole plates—122 holes of 1.0 mm and 36 holes of 4.0 mm in a 100 mm insert—exhibited lower NOx and lower temperatures owing to more effective fuel–air mixing. CO showed a strong dependence on both geometry and φ; the lowest levels occurred near φ ≈ 0.9, consistent with optimal combustion. The findings underscore the importance of nozzle geometry and air–fuel ratio in optimizing combustion efficiency and minimizing harmful emissions, providing valuable insights for the development of low-emission combustion systems in modern energy applications. Full article

In order to alleviate the energy crisis and respond to the “dual carbon strategy”, a new energy substance is needed to replace pulverized coal as the new blast furnace blowing fuel. Hydrochar is a clean and renewable carbon resource with high calorific value, good transportation and storage properties, and low ash content. Numerical simulation is used to study the combustion process of co-blown pulverized coal and hydrochar inside the cyclone zone. In this study, a three-dimensional physical model was constructed based on the actual dimensions of the direct-blowing pipe, tuyere, coal gun, and swirl zone of a large blast furnace in China. Numerical simulation methods were used to study the combustion process of coal powder and hydrothermal carbon co-injected into the swirl zone, and to investigate changes in the swirl zone of the tuyere under different conditions. The results show that increasing the proportion of hydrochar in the blended coal is conducive to improving the combustion rate of the blended coal, the temperature inside the gyratory zone increases significantly with the increase in the oxygen enrichment rate, and the high temperature zone is gradually enlarged. For every 1% increase in the oxygen enrichment rate, the maximum temperature of the centerline of the coal plume increases by 28 K, and the burnout rate increases by 1.12%; the increase in the blast temperature makes the combustion of pulverized coal slightly advance and promotes the increase in the internal temperature of the gyratory zone. The change of the blast temperature to 1559 K is more obvious, and the increase in the blast temperature after it is greater than 1559 K is not significant for the improvement of the burnout rate and the temperature of the gyratory area, and it will increase the cost; the lower the proportion of the small particle size is, the bigger the high temperature area of the gyratory area is, and the higher the temperature of the centerline of the coal strand is. If the content of the volatile matter remains unchanged, the increase in the ratio of the hydrochar has little influence on the temperature field of the gyratory area and the temperature of the centerline of the coal strand. The temperature difference is kept at 20 K. With the increase in the hydrochar ratio, the overall burnout rate of pulverized coal gradually increases. Therefore, hydrochar can replace bituminous coal as blast furnace blowing fuel to a certain extent, which can reduce costs and carbon emissions. Full article

Meso-scale combustors face persistent challenges in sustaining stable combustion and efficient heat transfer due to high surface-to-volume ratios and attendant heat losses. In contrast, larger outlet diameters exhibit weaker recirculation and more diffused temperature zones, resulting in reduced combustion efficiency and thermal confinement. The behavior of non-premixed flames in meso-scale combustor has been investigated through a comprehensive numerical study, utilizing computational fluid dynamics (CFD) under stoichiometric natural gas (methane)–air conditions; three outlet configurations (6 mm, 8 mm, and 10 mm) were analysed to evaluate their impact on temperature behaviour, vortex flow, swirl intensity, and central recirculation zone (CRZ) formation. Among the tested geometries, the 6 mm outlet produced the most robust central recirculation, intensifying reactant entrainment and mixing and yielding a sharply localised high-temperature core approaching 1880 K. The study highlights the critical role of geometric parameters in governing heat release distribution, with the 6 mm configuration achieving the highest exhaust temperature (920 K) and peak wall temperature (1020 K), making it particularly suitable for thermoelectric generator (TEG) integration. These findings underscore the interplay between combustor geometry, flow dynamics, and heat transfer mechanisms in meso-scale systems, providing valuable insights for optimizing portable power generation devices. Full article

This study reveals the governing mechanism of mass flow distribution within a multi-inlet, multi-outlet corotating disc cavity, providing critical insights for designing advanced gas turbine secondary air systems. An experimentally verified numerical investigation is conducted across a range of rotational Reynolds numbers $R{e}_{\varphi }=5\times {10}^6~2\times {10}^7$ and axial Reynolds numbers $R{e}_z=2\times {10}^5~5\times {10}^5$, corresponding to Rossby numbers $Ro$ from 0.01 to 0.10. Results highlight that $Ro$ governs the internal flow and outlet mass flow distribution through two distinct regimes. In the rotation-dominated regime at low $Ro$, the radial outlet mass flow ratio $MR$ decreases sharply, and a stable, dual-zone vortical structure forms. As $Ro$ increases, growing inflow inertia disrupts this structure, causing vortices to merge, which enhances swirl uniformity and slows the rate of $MR$ decrease. This transition dictates outlet performance: the radial outlet discharge steadily improves with $Ro$, while the axial outlet performance increases abruptly around $Ro=0.02$ before saturating. Full article

The operation range of the adaptive cycle engine (ACE) compression system is constrained by both the compression components and the bypass ducts, resulting in intricate matching mechanisms. Conventional analysis methods struggle to adequately evaluate the feasible operating range or the coupled constraints between components. This study employs an integrated hybrid-dimensional approach, combining zero-dimensional bypass analysis with one-dimensional/quasi-two-dimensional component analysis, to systematically investigate the matching effects of a triple-bypass compression system. The influence of key matching parameters, including the compression component operating points, high-pressure (HP) and low-pressure (LP) shaft speeds, and the core-driven fan stage (CDFS) variable inlet guide vane (VIGV) angles, is investigated. Results indicate that compression component matching primarily influences adjacent downstream bypass ratios, while HP/LP shaft speeds and the CDFS VIGV angle predominantly regulate the first and second bypass ratios. The feasible operating envelope is determined by the superimposed effects of these control parameters. To maximize the total bypass ratio, optimal operation requires increasing the front fan stall margin, elevating LP shaft speed, reducing HP shaft speed, and implementing partial CDFS VIGV closure to enhance pre-swirl. These findings provide critical guidance for control logic refinement and design optimization in advanced variable-cycle compression systems. Full article

Predicting the blow-off (BO) is critical for characterising the operability limits of gas turbine engines. In this study, the applicability of a low-order extinction prediction modelling, which is based on a stochastic variant of the Imperfectly Stirred Reactor (ISR) approach, to predict the lean blow-off (LBO) curve and the extinction conditions in a hydrogen Rich-Quench-Lean (RQL)-like swirl combustor is investigated. The model predicts the blow-off scalar dissipation rate (SDR), which is then extrapolated using Reynolds-Averaged Navier–Stokes (RANS) cold-flow simulations and simple scaling laws, to determine the critical blow-off conditions. It has been found that the sISR modelling framework can predict the BO flow split ratio at different global equivalence ratios, showing a reasonable agreement with the experimental data. This further validates sISR as an efficient low-order modelling flame extinction tool, which can significantly contribute to the development of robust hydrogen RQL combustors by enabling the rapid exploration of combustor operability during the preliminary design phases. Full article

This study investigates the effects of diffusion modeling and swirl intensity on flow fields and NO emissions in CH₄/NH₃ non-premixed swirling flames using large eddy simulations (LESs). Simulations are performed for a 50/50 ammonia–methane blend at three global equivalence ratios of 0.77, 0.54, and 0.46 and two swirl numbers of 8 and 12, comparing the unity Lewis number (ULN) and mixture-averaged diffusion (MAD) models against the experimental data includes OH-PLIF and ON-PLIF reported in a prior study by the KAUST group. Both models produce similar flow fields, but the MAD model alters the flame structure and species distributions due to differential diffusion (DD) and limitations in its Flamelet library. Notably, the MAD library lacks unstable flame branch solutions, leading to extensive interpolation between extinction and stable branches. This results in overpredicted progress variable source terms and reactive scalars, both within and beyond the flame zone. The ULN model better reproduces experimental OH profiles and localizes NO formation near the flame front, whereas the MAD model predicts broader NO distributions due to nitrogen species diffusion. Higher swirl intensities shorten the flame and shift NO production upstream. While a low equivalence ratio provides enough air for good mixing, lower ammonia and higher NO contents in exhaust gases, respectively. Full article

Driven by stringent emission regulations, advanced combustion modes utilizing turbulent jet ignition technology are pivotal for enhancing the performance of marine low-speed natural gas dual-fuel engines. This review focuses on three novel combustion modes, yielding key conclusions: (1) Compared to the conventional DJCDC mode, the TJCDC mode exhibits a significantly higher swirl ratio and turbulence kinetic energy in the main chamber during initial combustion. This promotes natural gas jet development and combustion acceleration, leading to shorter ignition delay, reduced combustion duration, and a combustion center (CA50) positioned closer to the Top Dead Center (TDC), alongside higher peak cylinder pressure and a faster early heat release rate. Energetically, while TJCDC incurs higher heat transfer losses, it benefits from lower exhaust energy and irreversible exergy loss, indicating greater potential for useful work extraction, albeit with slightly higher indicated specific NOx emissions. (2) In the high-compression ratio TJCPC mode, the Liquid Pressurized Natural Gas (LPNG) injection parameters critically impact performance. Delaying the start of injection (SOI) or extending the injection duration degrades premixing uniformity and increases unburned methane (CH₄) slip, with the duration effects showing a load dependency. Optimizing both the injection timing and duration is, therefore, essential for emission control. (3) Increasing the excess air ratio delays the combustion phasing in TJCPC (longer ignition delay, extended combustion duration, and retarded CA50). However, this shift positions the heat release more optimally relative to the TDC, resulting in significantly improved indicated thermal efficiency. This work provides a theoretical foundation for optimizing high-efficiency, low-emission combustion strategies in marine dual-fuel engines. Full article

This study investigates the application of deep learning (DL) techniques for predicting temperature fields in the SM1 swirl-stabilized turbulent non-premixed flame. Two distinct DL approaches were developed using a comprehensive CFD database generated via the steady laminar flamelet model coupled with the SST k-ω turbulence model. The first approach employs a fully connected dense neural network to directly map scalar input parameters—fuel velocity, swirl ratio, and equivalence ratio—to high-resolution temperature contour images. In addition, a comparison was made with different deep learning networks, namely Res-Net, EfficientNetB0, and Inception Net V3, to better understand the performance of the model. In the first approach, the results of the Inception V3 model and the developed Dense Model were found to be better than Res-Net and Efficient Net. At the same time, file sizes and usability were examined. The second framework employs a U-Net-based convolutional neural network enhanced by an RGB Fusion preprocessing technique, which integrates multiple scalar fields from non-reacting (cold flow) conditions into composite images, significantly improving spatial feature extraction. The training and validation processes for both models were conducted using 80% of the CFD data for training and 20% for testing, which helped assess their ability to generalize new input conditions. In the secondary approach, similar to the first approach, studies were conducted with different deep learning models, namely Res-Net, Efficient Net, and Inception Net, to evaluate model performance. The U-Net model, which is well developed, stands out with its low error and small file size. The dense network is appropriate for direct parametric analyses, while the image-based U-Net model provides a rapid and scalable option to utilize the cold flow CFD images. This framework can be further refined in future research to estimate more flow factors and tested against experimental measurements for enhanced applicability. Full article

Ammonia combustion has garnered increasing attention due to its potential as a carbon-free fuel. Globally swirling flow in a rectangular furnace generates flameless conditions by high flue gas recirculation. The reverse air injection (RAI) technique enabled stable swirling flameless combustion of pure ammonia without auxiliary methods. Experiments with pure ammonia combustion in a swirling flameless furnace demonstrated an operable equivalence ratio (ER) range of 0.3–1.05, extending conventional flammability limits of pure ammonia as a fuel. NO emissions were reduced by 40% compared to conventional combustion, with peak concentrations of 1245 ppm at ER = 0.71 and near-zero emissions at ER = 1.05. Notably, flameless combustion exhibited lower temperature sensitivity in NO formation; however, the ER has a serious effect. Developing a simplified reaction model for ammonia combustion is crucial for computational fluid dynamics (CFD) research. A reduced kinetic mechanism comprising 36 reactions and 16 chemical species was introduced, specifically designed for efficient and precise modeling of pure ammonia flameless combustion. Combustion simulation using the eddy dissipation concept (EDC) approach confirmed the mechanism’s predictive capability, maintaining acceptable accuracy across the operating conditions. Full article

Ammonia (NH₃) and hydrogen (H₂) are considered promising fuels for the power sector’s decarbonization. Their combustion is capable of producing energy with zero direct CO₂ emissions, and ammonia can act as a stable energy H₂ carrier. This study numerically investigates the design and implementation of staged combustion of a mixture of NH₃/H₂ by means of CFD simulations. The investigation employed the single-phase flow RANS governing equations and the eddy dissipation concept (EDC) combustion model, with the incorporation of a detailed kinetic mechanism. The combustion chamber operates under the RQL (rich–quench–lean) combustion regime. The first stage operates under rich conditions, firing mixtures of ammonia in air, enriched by hydrogen (H₂) to enhance combustion properties in a swirl and bluff-body stabilized burner. The secondary stage injects additional air and hydrogen to mitigate unburnt ammonia and NO_x emissions. Simulations of the first stage were performed for a thermal input ranging from 4 kW to 8 kW and flames with an equivalence ratio of 1.2. In the second stage, additional hydrogen is injected with a thermal input of either 1 kW or 2 KW, and air is added to adjust the global equivalence ratio to 0.6. Full article

This article reports the effect of twisted tapes with continuous V-ribs on the thermal performance index characteristics of a heat exchanger tube. Numerical and experimental studies were conducted to investigate the influence of V-rib attack angles (β = 15°, 30°, and 45°) in forward and backward arrangements. This investigation employed 0.9 mm thick, continuous V-rib twisted tapes (CVRTs) made from aluminum sheets formed with a twist ratio of y/w = 4.0. The experimental results indicated that a continuous V-rib twisted tape (CVRT) was more effective in heat transfer improvement than a typical twisted tape (TT). This was due to swirl and longitudinal vortex flows that helped increase flow mixing and reduce boundary layer thickness. Decreased V-rib attack angles (β) led to greater heat transfer enhancement, pressure drop, and thermal performance index values due to the greater turbulent mixing of fluid. The numerical result revealed that a continuous V-rib twisted tape created strong longitudinal vortex flow, especially with higher attack angles. The Turbulent Kinetic Energy (TKE) and core fluid temperature increased with the insertion of CVRTs. Local Nusselt numbers also remained relatively high for heat exchanger tubes with CVRTs. The experimental study illustrated that a tube with a CVRT installed augmented heat transfer. In the experimentally studied cases, a backward arrangement had more heat transfer, a greater friction factor, and a better thermal performance index. Compared to a plain tube, a tube with CVRT installed, having β = 15°, 30°, and 45°, showed 76.8, 71.6, and 66.2% improved heat transfer, respectively. CVRTs with these three β-values, respectively, exhibited higher thermal performance than a TT. Among the investigated CVRTs, the backward-arranged tape with β = 15° offered the maximum thermal performance index, 1.13 at Re = 6000. The results are congruent with the simulation outcomes, hence supporting the CFD analysis. Full article

This article reviews the physical and chemical mechanisms associated with unsteady swirl-stabilized partially or fully lean premixed combustion. The processes of flame stabilization, mode conversion, swirl number oscillation, equivalence ratio oscillation, and vortex rollup are described. The key challenges associated with flow-flame dynamics for several sources of perturbations are presented and discussed. The Rayleigh criterion is discussed. This article summarizes the scientific knowledge gained on swirling flames dynamics in terms of modeling, theoretical analysis, and transient measurements with advanced diagnostics. The following are specifically documented: (i) the effect of the swirler on swirling flames; (ii) the analytical results, computational modeling, and experimental measurements of swirling flame dynamics; (iii) the influence of flow features on flame response of swirling flames for combustion instabilities studies; and (iv) the identification and description of the combustion dynamics mechanisms responsible for swirl-stabilized combustion instabilities. Relevant elements from the literature in this context for hydrogen fuel are included. Full article

The last decades have offered new challenges to researchers worldwide through the problems our planet is facing both in the environmental protection field and the need to replace fossil fuels with new environmentally friendly alternatives. Bioenergy, as a form of renewable energy, is an acceptable option from all points of view, and biofuels, due to their biological origin, have the ability to satisfy the new needs of humanity. As they release non-polluting combustion products into the atmosphere, biofuels have already been adopted as additives in traditional liquid fuels, intended mainly for the internal combustion engines of automobiles. The current work proposes an extension of the biofuel application in combustion processes specific to industrial furnaces. This technical concern has not been found in the literature, except for the achievements of the research team involved in this work, who performed the previous investigations. A 51.5 kW burner was designed to operate with glycerin originating from the triglycerides of plants and animals, mixed with ethanol, an alcohol produced by the chemical industry recently used as an additive in gasoline for automobile engines. Industrial oxygen was chosen as the oxidizing agent necessary for the liquid mixture combustion, allowing us to obtain much higher flame temperatures compared with the usual combustion processes using air. Mixing glycerin with ethanol in an 8.8 ratio allowed for growing flame stability, also accentuated by creating swirl currents in the flame through the speed regime of fluids at the exit from the burner body. Results were excellent in both the flame stability and low level of polluting emissions. Full article
