The nozzle, as a critical jet component in dry powder fire extinguishing systems, significantly affects jet characteristics through its geometric configuration. To explore the influence of structural parameters on ultrafine dry powder gas-solid two-phase jet characteristics, a bidirectional coupled numerical model based on the SST k-ω turbulence model and the Discrete Phase Model is employed. This study examines how variations in the semi-expansion angle (α) and semi-contraction angle (β) of the nozzle affect compressible gas flow behavior and particle distribution trajectories through a combination of simulations and experiments. The results indicate that when α = 2°, the gas jet is in an under-expanded state, leading to increased particle dispersion due to the stripping effect of the surrounding high-speed airflow. Within the range of x = 0–180 mm, the dry powder exhibits a diffusion trend. When α = 4.5°, the gas jet core region is the longest, providing optimal particle acceleration. Under constant inlet pressure, reducing α enhances particle collimation. The reduction of α alters the gas jet state, with α = 2° showing better powder diffusion compared to α = 6°. However, an excessively small α is detrimental to increasing the range of dry powder. With consistent structural parameters, the diffusion and range of dry powder remain the same across different β values, and variations in β have a relatively minor impact on supersonic jet characteristics. These findings offer theoretical guidance for optimizing and improving nozzles in ultrafine dry powder fire extinguishing systems. Full article

Creating a high-quality aircraft engine is closely connected to the problem of obtaining the jet flow characteristics that appear while an aircraft’s engine is in operation. As natural experiments are costly, studying turbulent jets by numerical simulation appears practical and acute. Biconic nozzle supersonic jet flow is the research subject of this article. A compression and expansion train of waves called barrels were formed in the jet flow at preset conditions. The simulation was performed on an unstructured numerical grid. In order to enhance the calculation accuracy in the shock-wave domain, a hybrid gradient computation scheme and numerical grid static adaptation method were applied in the regions of gas-dynamic values’ significant differential. This approach resulted in a description of nozzle supersonic gas flow structure. It was shown that building local refinement when using a static adaptation numerical grid contributed to improving the accuracy of determining shock waves’ fronts. In addition, this approach facilitated the identification of the Mach disk in the flow when using an unstructured grid, allowing for calculation schemes not higher than a second-order of accuracy. Full article

An approach based on the OpenFOAM library has been developed to solve a high-speed, multicomponent mixture of a reacting, compressible flow. This work presents comprehensive validation of the newly developed solver, called compressibleCentralReactingFoam, with different supersonic flows, including shocks, expansion waves, and turbulence–combustion interaction. The comparisons of the simulation results with experimental and computational data confirm the fidelity of this solver for problems involving multicomponent high-speed reactive flows. The gas dynamics of turbulence–chemistry interaction are modeled using a partially stirred reactor formulation and provide promising results to better understand the complex physics involved in supersonic combustors. A time-scale analysis based on local Damköhler numbers reveals different regimes of turbulent combustion. In the core of the jet flow, the Damköhler number is relatively high, indicating that the reaction time scale is smaller than the turbulent mixing time scale. This means that the combustion is controlled by turbulent mixing. In the shear layer, where the heat release rate and the scalar dissipation rate have the highest value, the flame is stabilized due to finite rate chemistry with small Damköhler numbers and a limited fraction of fine structure. This solver allows three-dimensional gas dynamic simulation of high-speed multicomponent reactive flows relevant to practical combustion applications. Full article

Supersonic jets of metal vapors with carrier gas are promising for producing nanostructured metal films at relatively low source temperatures and high deposition rates. However, the effects of the carrier gas on the jet composition and expansion dynamics, as well as on film properties, remain virtually unexplored. In this work, the free-jet expansion of a mixture of silver vapor with helium in a rarefied regime at an initial temperature of 1373 K is investigated through mass spectrometry and direct-simulation Monte Carlo methods. Introducing the carrier gas into the source is found to result in a transition from a collisionless to a collision-dominated expansion regime and dramatic changes in the Ag jet, which becomes denser, faster, and more forward-directed. The changes are shown to be favorable for the formation of small Ag clusters and film deposition. At a fairly high helium flow, silver Ag₂ dimers are observed in the jet, both in the experiment and the simulations, with a mole fraction reaching 0.1%. The terminal velocities of silver atoms and dimers are nearly identical, indicating that the clusters are likely formed due to the condensation of silver vapor in the expanding jet. A high potential of supersonic Ag-He jets for the deposition of nanostructured silver films is demonstrated. The deposited jet Ag₂ dimers appear to serve as nucleation centers and, thus, allow for controlling the size of the produced surface nanostructures. Full article

This paper discusses accuracy improvements to Reynolds-Averaged Navier–Stokes (RANS) modeling of supersonic flow by assessing a wide range of factors for physics capture. Numerical simulations reveal complex flow behavior resulting from shock and expansion waves and so, a supersonic jet emanating from rectangular nozzle is considered. PIV based experimental data for the jet is available from literature and is used for validation purposes. Effect of various boundary conditions and turbulence modeling approaches is assessed qualitatively and quantitatively. Of particular interest are the inlet conditions considering the turbulence intensity and the effect of upstream air supply duct, the effect of nozzle wall surface roughness on nozzle internal flow and downstream, wall y+ sensitivity for boundary layer resolution and laminar to turbulent transition modeling. In addition to mesh sensitivity, domain dependency is conducted to evaluate the appropriate domain size to capture the kinetic energy dissipation downstream of the nozzle. To further improve the flow characteristics, accounting for the anisotropy of Reynolds stresses is also one of the focuses. Therefore, non-linear eddy viscosity-based two-equation model and Reynolds stress transport model are also investigated. Additionally, the results of baseline linear (Boussinesq) RANS are compared. Corresponding comparisons with high-fidelity LES are presented. Jet self-similar behavior resulting from all simulation fidelities is assessed and it appears that turbulent flow in LES becomes self-similar, but not in RANS. Finally, various factors such as the nozzle geometry and numerical modeling choices influencing the anisotropy in jet turbulence are discussed. Full article

To effectively reduce shock wave loss at the trailing edge of a supersonic cascade under high back-pressure, a shock wave control method based on air jets is proposed. The air jet was arranged on the pressure side of the blade in the upstream of the trailing-edge shock. The flow control mechanism and effects of parameters were analyzed by computational methods. The results show that the air jet formed an oblique shock wave in the cascade passage which decelerated and pressurized the airflow. The resulting expansion wave downstream of the jet slot weakened the strength of the trailing-edge shock. This could effectively change the normal shock into oblique shock and thus weaken the shock loss. Optimal control effect was achieved when the mass flow rate ratio of the jet to the passage airflow remained 0.35–1.11% and the distance from the jet slot to the shock foot of the trailing-edge shock was about five times the thickness of the boundary layer. The proposed method can reduce the total pressure loss of a supersonic cascade, with the maximum improvement effect reaching 7.29% compared to the no-control state. Full article

Using the example of studying the supersonic underexpanded jet initial section, the issue of interpreting the experimental visualization data and Pitot pressure measurement data using the results of numerical calculations (2d RANS k-ω SST) is discussed. It is shown that the gradient S-shaped feature of the gas-dynamic structure near the nozzle exit, observed in the form of a barrel shock, is a characteristic that separates the expansion and compression regions, and downstream is transformed into a barrel shock. It has been established that the reason for the observed S-shaped curvature of this feature is the axisymmetric nature of the jet flow. Full article

Some alternative refrigerants with excellent environmental performance often have different flammable limits. When refrigerant leaks, the external space may have a certain explosion risk if the refrigerant is not diffused timely. To understand the leakage and diffusion characteristics of the refrigerant, an improved gas leakage model was proposed in this paper, and the accuracy verification of the improved model was developed. Based on the above works, taking R290 as the research object, the variation law of the field strength between the leaked gas and external space and the influence of different initial leakage pressures on the field strength characteristics were analyzed. The simulation results showed that when the initial leakage pressure was 2 MPa, the R290 gas entered the external space as a supersonic jet, the gas underwent continuous expansion and compression processes in the near-field area and a Mach disk was formed within the flow area. During this process, parameters, such as the temperature, pressure, velocity and density of the leaked R290 gas, changed dramatically, and then the gas gradually returned to room temperature and normal pressure through interaction with the external space. The flammable area formed by the leaked R290 was mainly concentrated in the local flow area below the leak hole, and the existence of the Mach disk caused the R290 high concentration area to increase. With the increase in the initial leakage pressure, the distance from the Mach disk to the leak hole and the circumferential diameter of the Mach disk increased, and the flammable area increased slightly in the horizontal direction, whereas the flammable area increased significantly in the vertical direction. Full article

Weakly-bound intermolecular clusters constitute reductionist physical models for non-covalent interactions. Here we report the observation of the monomer, the dimer and the monohydrate of 2-adamantanol, a secondary alcohol with a bulky ten-carbon aliphatic skeleton. The molecular species were generated in a supersonic jet expansion and characterized using broadband chirped-pulse microwave spectroscopy in the 2–8 GHz frequency region. Two different gauche-gauche O-H···O hydrogen-bonded isomers were observed for the dimer of 2-adamantanol, while a single isomer was observed for the monomer and the monohydrate. The experimental rotational parameters were compared with molecular orbital calculations using density functional theory (B3LYP-D3(BJ), B2PLYP-D3(BJ), CAM-B3LYP-D3(BJ), ωB97XD), additionally providing energetic and electron density characterization. The shallow potential energy surface makes the dimer an interesting case study to benchmark dispersion-corrected computational methods and conformational search procedures. Full article

Prereactive complexes in noncovalent organocatalysis are sensitive to the relative chirality of the binding partners and to hydrogen bond isomerism. Both effects are present when a transiently chiral alcohol docks on a chiral $\mathsf{\alpha }$-hydroxy ester, turning such 1:1 complexes into elementary, non-reactive model systems for chirality induction in the gas phase. With the help of linear infrared and Raman spectroscopy in supersonic jet expansions, conformational preferences are investigated for benzyl alcohol in combination with methyl lactate, also exploring p-chlorination of the alcohol and the achiral homolog methyl glycolate to identify potential London dispersion and chirality effects on the energy sequence. Three of the four combinations prefer barrierless complexation via the hydroxy group of the ester (association). In contrast, the lightest complex predominantly shows insertion into the intramolecular hydrogen bond, such as the analogous lactate and glycolate complexes of methanol. The experimental findings are rationalized with computations, and a uniform helicality induction in the alcohol by the lactate is predicted, independent of insertion into or association with the internal lactate hydrogen bond. p-chlorination of benzyl alcohol has a stabilizing effect on association because the insertion motif prevents a close contact between the chlorine and the hydroxy ester. After simple anharmonicity and substitution corrections, the B3LYP-D3 approach offers a fairly systematic description of the known spectroscopic data on alcohol complexes with $\mathsf{\alpha }$-hydroxy esters. Full article

Rotational microwave jet spectroscopy studies of the monoterpenol $\alpha$-fenchol have so far failed to identify its second most stable torsional conformer, despite computational predictions that it is only very slightly higher in energy than the global minimum. Vibrational FTIR and Raman jet spectroscopy investigations reveal unusually complex OH and OD stretching spectra compared to other alcohols. Via modeling of the torsional states, observed spectral splittings are explained by delocalization of the hydroxy hydrogen atom through quantum tunneling between the two non-equivalent but accidentally near-degenerate conformers separated by a low and narrow barrier. The energy differences between the torsional states are determined to be only 16(1) and 7(1) cm${}^{-1}hc$ for the protiated and deuterated alcohol, respectively, which further shrink to 9(1) and 3(1) cm${}^{-1}hc$ upon OH or OD stretch excitation. Comparisons are made with the more strongly asymmetric monoterpenols borneol and isopinocampheol as well as with the symmetric, rapidly tunneling propargyl alcohol. In addition, the third—in contrast localized—torsional conformer and the most stable dimer are assigned for $\alpha$-fenchol, as well as the two most stable dimers for propargyl alcohol. Full article

The homodimers of transiently chiral molecules offer physical insight into the process of molecular recognition, the preference for homo or heterochiral aggregation and the nature of the non-covalent interactions stabilizing the adducts. We report the observation of the benzyl mercaptan dimer in the isolation conditions of a supersonic jet expansion, using broadband (chirped-pulse) microwave spectroscopy. A single homochiral isomer was observed for the dimer, stabilized by a cooperative sequence of S-H···S and S-H···π hydrogen bonds. The structural data, stabilization energies and energy decomposition describe these non-covalent interactions as weak and dispersion-controlled. A comparison is also provided with the benzyl alcohol dimer. Full article

A new porous system in power plants allowing the management of the crisis of heat exchange at boiling water in porous structures has been investigated. This study refers to the thermal power plants of electrical power stations and devices for cutting natural and artificial mineral media. Combustion chambers and supersonic nozzles were cooled by different porous structures. The optimum cell sizes of the porous structures were determined and data on the heat transfer capacity for the (critical) heat flow were obtained. A thermal device in the form of a rocket-type burner with a detonation jet showed high efficiency for capillary-porous and flow-through cooling systems. The economic effect per burner is not less than 200–300 dollars, and the coolant consumption is reduced by dozens of times, which is environmentally important. A comparative evaluation of the investigated structures and coatings has advantages over other cooling systems. The integration of mesh structures with capillary-porous coatings of natural mineral media produces a synergistic effect of combining them into a technology of their manufacturing, the expansion of critical loads removal and control of the limit state of the coatings. Full article

Phenol is added to acetophenone (methyl phenyl ketone) and to six of its halogenated derivatives in a supersonic jet expansion to determine the hydrogen bonding preference of the cold and isolated 1:1 complexes by linear infrared spectroscopy. Halogenation is found to have a pronounced effect on the docking site in this intermolecular ketone balance experiment. The spectra unambiguously decide between competing variants of phenyl group stacking due to their differences in hydrogen bond strength. Structures where the phenyl group interaction strongly distorts the hydrogen bond are more difficult to quantify in the experiment. For unsubstituted acetophenone, phenol clearly prefers the methyl side despite a predicted sub-kJ/mol advantage that is nearly independent of zero-point vibrational energy, turning this complex into a challenging benchmark system for electronic structure methods, which include long range dispersion interactions in some way. Full article

In high-speed fluid dynamics, base pressure controls find many engineering applications, such as in the automobile and defense industries. Several studies have been reported on flow control with sudden expansion duct. Passive control was found to be more beneficial in the last four decades and is used in devices such as cavities, ribs, aerospikes, etc., but these need additional control mechanics and objects to control the flow. Therefore, in the last two decades, the active control method has been used via a microjet controller at the base region of the suddenly expanded duct of the convergent–divergent (CD) nozzle to control the flow, which was found to be a cost-efficient and energy-saving method. Hence, in this paper, a systemic literature review is conducted to investigate the research gap by reviewing the exhaustive work on the active control of high-speed aerodynamic flows from the nozzle as the major focus. Additionally, a basic idea about the nozzle and its configuration is discussed, and the passive control method for the control of flow, jet and noise are represented in order to investigate the existing contributions in supersonic speed applications. A critical review of the last two decades considering the challenges and limitations in this field is expressed. As a contribution, some major and minor gaps are introduced, and we plot the research trends in this field. As a result, this review can serve as guidance and an opportunity for scholars who want to use an active control approach via microjets for supersonic flow problems. Full article
