Search Results (41)

Improvement of energy efficiency in technological processes at industrial enterprises is one of the key areas of energy saving. Reduction of energy costs required for the production of energy-intensive products can be achieved through the utilization of waste heat produced by high-temperature thermal furnace units. Generation of electric power based on the waste heat using power cycles with working fluids that are not conventional for large power engineering, may become a promising energy saving trend. In this paper, thermodynamic analysis and optimization of power cycles for the purposes of waste heat recovery are performed. The efficiency of combining several power cycles was also evaluated. It has been established that the combination of the Brayton recompression cycle on supercritical carbon dioxide with the organic Rankine cycle using R124 allows for greater electrical power than steam-power cycles with three pressure circuits under conditions where the gas temperature is in the range of 300–550 °C and the cooling temperature of is up to 80 °C. Additionally, when cooling gases with a high sulfur and moisture content to 150 °C, the combined cycle has greater electrical power at gas temperatures of 330 °C and above. At enterprises where the coolant has a high content of sulfur compounds or moisture and deep cooling of gases will lead to condensation, for example, at petrochemical and non-ferrous metallurgy enterprises, the use of combined cycles can ensure a utilization efficiency of up to 45%. Full article

Solar energy and biomass offer sustainable alternatives to meet the energy demand and reduce the environmental impact of fossil fuels. In this study, through mass and energy balances, a comparative analysis of energy, exergy, and environmental impact (LCA) was conducted on two renewable thermal sources: solar energy and coconut shell biomass, both coupled to a supercritical CO₂ Brayton cycle (sCO₂) with an organic Rankine cycle (ORC) for waste heat recovery. The sCO₂–ORC–biomass configuration showed higher exergy efficiency (41.1%) and lower exergy destruction (188.88 kW) compared to the sCO₂–ORC–solar system (23.76% and 422.63 kW). Thermal efficiency (50.6%) and net power output (131.73 kW) were similar for both sources. However, the solar system (204,055.57 kg CO₂-equi) had an 85.6% higher environmental impact than the biomass system (109,933.63 kg CO₂-equi). Additionally, the construction phase contributed ~95% of emissions in both systems, followed by decommissioning (~4.5%) and operation (~0.1%). Finally, systems built with aluminum generate a higher carbon footprint than those with copper, with differences of 2% and 3.2% in sCO₂–ORC–solar and sCO₂–ORC–biomass, respectively. This study and an economic analysis make these systems viable thermo-sustainable options for clean energy generation. Full article

This paper presents a comprehensive analysis of supercritical carbon dioxide (sCO₂)-enhanced geothermal systems (EGSs) in Poland, focusing on their energetic performance through process modeling and optimization. EGSs harness the potential of geothermal energy by utilizing supercritical carbon dioxide as the working fluid, offering promising avenues for sustainable power generation. This study investigates two distinct configurations of sCO₂-EGS: one dedicated to power generation via a binary system with an organic Rankine cycle and the other for combined power and heat production through a direct sCO₂ cycle. Through accurate process modeling and simulation, key parameters influencing system efficiency and performance are identified and optimized. The analysis integrates thermodynamic principles with geological and operational constraints specific to the Polish context. The results highlight the potential of sCO₂-EGSs to contribute to the country’s energy transition, offering insights into the optimal design and operation of such systems for maximizing both power and thermal output while ensuring economic viability and environmental sustainability. Full article

The opportunities related to the adoption of synthetic gaseous fuels derived from solid biomass are limited by the issues caused by the peculiarities of the syngas. The aim of this paper is to analyze several possible layouts of hybrid energy systems, in which the main thermal source is the organic fraction of municipal solid wastes. The case of a small community of about 1000 persons is analyzed in this paper. The examined layouts coupled an externally fired micro gas turbine with a waste heat recovery system based on both an Organic Rankine Cycle and supercritical CO₂ gas turbines. A thermodynamic analysis has been carried out through the use of the commercial software Thermoflex 31, considering the losses of each component and the non-ideal behavior of the fluids. The results of the numerical analysis highlight that the introduction of a waste heat recovery system leads to an increase of at least 16% in the available net power, while a cascade hybrid energy grid can lead to a power enhancement of about 29%, with a considerable increase also in the energetic and exergetic global efficiencies. Full article

Carbon dioxide (CO₂) has been recognized as one of the potential working fluids to operate power generation cycles, either in supercritical or transcritical configuration. However, a small concentration of some of the additives to CO₂ have shown promising improvements in the overall performance of the cycle. The current study is motivated by the newly proposed additive silicon tetrachloride (SiCl₄), and so we perform a detailed investigation of SiCl₄ along with a few well-known additives to CO₂-based binary mixtures as a working fluid in transcritical organic Rankine cycle setup with internal heat regeneration. The additives selected for the study are pentane, cyclopentane, cyclohexane, and silicon tetrachloride (SiCl₄). A comprehensive study on the energy and exergy performance of the cycle for warm regions is conducted at a turbine inlet temperature of 250 °C. The performance of the heat recovery unit is also assessed to highlight its importance in comparison to a simple configuration of the cycle. This study shows that the cycle operating with binary mixtures performs significantly better than with pure CO₂, which is mainly due to its better heat recovery in the heat recovery unit. The results show that the optimal molar concentration of the additives is in between 20% and 25%. Besides having better thermal stability, SiCl₄ shows an improvement in the cycle thermal efficiency by 6% points which is comparable to cyclopentane (7.3% points) and cyclohexane (7.8% points). The optimal cycle pressure ratio for SiCl₄ is also relatively lower than for other additives. The energy efficiency of the cycle with pure CO₂ is around 45% which is also increased to 58%, 63%, 64%, 60% with pentane, cyclopentane, cyclohexane, and SiCl₄, respectively. These results suggest that additives like SiCl₄ could make CO₂-based cycles more viable for power generation in warm regions. Full article

Worldwide, the growing demand for energy has been largely met through power cycles utilizing fossil fuels. Combined cycles, which integrate a gas turbine with a steam cycle, prove to be the best alternative due to their power generation capacity and high efficiencies. This efficiency is primarily attributed to the ability to harness exhaust gases to generate steam in the heat recovery boiler, allowing additional power generation through the steam turbine. Currently, there is a quest for the integration of low-temperature power cycles to maximize the utilization of residual thermal energy flows for power generation. Therefore, this work conducts an exergetic optimization of a power trigeneration system aimed at maximizing exergetic efficiency. This system includes a gas turbine and a steam cycle coupled with three different configurations of the Organic Rankine Cycle (ORC): a simple ORC, a supercritical ORC, and an ultracritical ORC. The ORC configurations are analyzed using eight organic working fluids, namely R1234yf, R290, R134a, R1234ze, R152a, R600a, R245fa, and R123. The results show that the maximum exergetic efficiency is achieved by using R152a in the ultracritical ORC configuration coupled with the combined cycle, achieving an exergetic efficiency of 55.79%. Furthermore, the maximum power generated is attained by the steam cycle with 85,600.63 kW and 3101.21 kW for the ultracritical ORC. Full article

Waste heat recovery from exhaust gas is one of the most convenient methods to save energy in internal combustion engine-driven vehicles. This paper aims to investigate a reduction in waste heat from the exhaust gas of an internal combustion engine of a serial Diesel–electric hybrid bus by recovering part of the heat and converting it into useful power with the help of a split-flow supercritical CO₂ (sCO₂) recompression Brayton cycle. It can recover 17.01 kW of the total 33.47 kW of waste heat contained in exhaust gas from a 151 kW internal combustion engine. The thermal efficiency of the cycle is 38.51%, and the net power of the cycle is 6.55 kW. The variation in the sCO₂ temperature at the shutdown of the internal combustion engine is analyzed, and a slow drop followed by a sudden and then a slow drop is observed. After 80 s from stopping the engine, the temperature drops by (23–33)% depending on the tube thickness of the recovery heat exchanger. The performances (net power, thermal efficiency, and waste heat recovery efficiency) of the split-flow sCO₂ recompression Brayton cycle are clearly superior to those of the steam Rankine cycle and the organic Rankine cycle (ORC) with cyclopentane as a working fluid. Full article

Small nuclear power plants are a promising direction of research for the development of carbon-free energy in isolated power systems and in remote regions with undeveloped infrastructure. Improving the efficiency of power units integrated with small modular reactors will improve the prospects for the commercialization of such projects. Power cycles based on supercritical carbon dioxide are an effective solution for nuclear power plants that use reactor facilities with an initial coolant temperature above 550 °C. However, the presence of low temperature rejected heat sources in closed Bryton cycles indicates a potential for energy saving. This paper presents a comprehensive thermodynamic analysis of the integration of an additional low-temperature organic Rankine cycle for heat recovery to supercritical carbon dioxide cycles. A scheme for sequential heat recovery from several sources in S-CO₂ cycles is proposed. It was found that the use of R134a improved the power of the low-temperature circuit. It was revealed that in the S-CO₂ Brayton cycle with a recuperator, the ORC add-on increased the net efficiency by an average of 2.98%, and in the recompression cycle by 1.7–2.2%. With sequential heat recovery in the recuperative cycle from the intercooling of the compressor and the main cooler, the increase in efficiency from the ORC superstructure will be 1.8%. Full article

The last decade (2013–2023) was the most prolific period of organic Rankine cycle (ORC) research in history in terms of both publications and citations. This article provides a detailed review of the broad and voluminous collection of recent internal combustion engine (ICE) waste heat recovery (WHR) studies, serving as a necessary follow-on to the author’s 2013 review. Research efforts have targeted diverse applications (e.g., vehicular, stationary, and building-based), and it spans the full gamut of engine sizes and fuels. Furthermore, cycle configurations extend far beyond basic ORC and regenerative ORC, particularly with supercritical, trilateral, and multi-loop ORCs. Significant attention has been garnered by fourth-generation refrigerants like HFOs (hydrofluoroolefins), HFEs (hydrofluoroethers), natural refrigerants, and zeotropic mixtures, as research has migrated away from the popular HFC-245fa (hydrofluorocarbon). Performance-wise, the period was marked by a growing recognition of the diminished performance of physical systems under dynamic source conditions, especially compared to steady-state simulations. Through advancements in system control, especially using improved model predictive controllers, dynamics-based losses have been significantly reduced. Regarding practically minded investigations, research efforts have ameliorated working fluid flammability risks, limited thermal degradation, and pursued cost savings. State-of-the-art system designs and operational targets have emerged through increasingly sophisticated optimization efforts, with some studies leveraging “big data” and artificial intelligence. Major programs like SuperTruck II have further established the ongoing challenges of simultaneously meeting cost, size, and performance goals; however, off-the-shelf organic Rankine cycle systems are available today for engine waste heat recovery, signaling initial market penetration. Continuing forward, next-generation engines can be designed specifically as topping cycles for an organic Rankine (bottoming) cycle, with both power sources integrated into advanced hybrid drivetrains. Full article

Organic Rankine cycles (ORCs) have been widely used to convert medium-low-temperature geothermal energy to electricity. Proper cycle layout is generally determined by considering both the thermo-physical properties of the working fluid and the geothermal brine temperature. This work investigates saturated, superheated and supercritical ORCs using R1234yf/R236ea for brine temperatures of 383.15 K, 403.15 K and 423.15 K. The evaporation and condensation pressures were optimized to maximize the net power outputs. The thermodynamic characteristics of the cycles at the optimal conditions were analyzed. The saturated ORCs produced slightly more net power than superheated cycles for the R1234yf mole fraction less than 0.2 due to lower exergy losses in the evaporator and condenser; however, the limited evaporation pressure by the turning point at the higher R1234yf mole fraction led to excessive exergy losses in the evaporator. Two R1234yf mole fractions maximized the net power and exergy efficiency in a superheated cycle, with the maximum net power output occurring at the R1234yf mole fraction of 0.8 for brine temperatures of 383.15 K and 403.15 K. The exergy losses for evaporation were reduced by 6–12.7% due to the use of an IHE, while those for condensation were reduced up to 42% in a superheated cycle for a brine temperature of 423.15 K, resulting in a 1–17.8% increase in the exergy efficiency. A supercritical cycle with an IHE using R1234yf/R236ea (0.85/0.15) generated the maximum net power output for a brine temperature of 423.15 K, 8.2–17.5% higher than a superheated cycle with an IHE. Full article

It has been demonstrated that energy systems driven by conventional energy sources like fossil fuels are one of the main causes of climate change. Organic Rankine cycles can help to reduce that impact, as they can be operated by using the industrial waste heat of renewable energies. The present study presents a comprehensive bibliographic review of organic Rankine cycles. The study not only actualizes previous reviews that mainly focused on basic cycles operating on subcritical or supercritical conditions, but also includes the analysis of novel cycles such as two-stage and hybrid cycles and the used fluids. Recuperative and regenerative cycles are more efficient than reheated and basic single-stage cycles. The use of two-stage cycles makes it possible to achieve higher thermal efficiencies and net power outputs of up to 20% and 44%, respectively, compared with those obtained with single-stage cycles. Theoretical studies show that hybrid systems, including Brayton and organic Rankine cycles, are the most efficient; however, they require very high temperatures to operate. Most organic Rankine cycle plants produce net power outputs from 1 kW up to several tens of kW, mainly using microturbines and plate heat exchangers. Full article

Organic Rankine cycles (ORC) are quite popular, but the overall efficiencies of these plants are rather very low. Numerous studies have been conducted in many scientific centers and research centers to improve the efficiency of such cycles. The research concerns both the modification of the cycle and the increase in the parameters of the medium at the inlet to the turbine. However, the efficiency of even these modified cycles rarely exceeds 20%. The plant modifications and the optimization of the working medium parameters, as a rule, lead to cycles with the high pressure and high temperature of live vapor and with a regenerator (heat exchanger) for the heating, vaporization and superheating of the medium. A new modified cycle with supercritical parameters of the working medium and with a new type of turbine has been described and calculated in the paper. For the first time, the isothermal turbine is proposed for supercritical organic cycles, though this solution is known as the Ericsson cycle for gas turbines. The innovative cycle and the usual ORC plants are characterized by almost identical block diagrams, while in the proposed cycle, the work of the turbine is obtained as a result of isothermal expansion and not in an adiabatic process. The analysis has been performed for 11 different working media and two cycles. The calculations have shown that power plants with isothermal expansion achieve better efficiency than cycles with adiabatic turbines. For example, the rise in efficiency changes from 8 percentage points for R245fa up to 10 percentage points for acetone. The calculations have proved that it is possible to obtain efficiency exceeding 50% for organic power plants. This is an outstanding result compared with modern steam and gas turbine units. Full article

This study aimed to investigate the potential of supercritical carbon dioxide (sCO2), organic Rankine cycle (ORC), and thermoelectric generator (TEG) systems for application in automotive exhaust waste heat recovery (WHR) applications. More specifically, this paper focuses on heavy-duty diesel engines applications such as marine, trucks, and locomotives. The results of the simulations show that sCO2 systems are capable of recovering the highest amount of power from exhaust gases, followed by ORC systems. The sCO2 system recovered 19.5 kW at the point of maximum brake power and 10.1 kW at the point of maximum torque. Similarly, the ORC system recovered 14.7 kW at the point of maximum brake power and 7.9 kW at the point of maximum torque. Furthermore, at a point of low power and torque, the sCO2 system recovered 4.2 kW of power and the ORC system recovered 3.3 kW. The TEG system produced significantly less power (533 W at maximum brake power, 126 W at maximum torque, and 7 W at low power and torque) at all three points of interest due to the low system efficiency in comparison to sCO2 and ORC systems. From the results, it can be concluded that sCO2 and ORC systems have the biggest potential impact in exhaust WHR applications provided the availability of heat and that their level of complexity does not become prohibitive. Full article

The rising number of applications of the organic Rankine cycle (ORC) or supercritical CO₂ (sCO₂) power systems have shaped a new branch of fluid mechanics called non-ideal compressible fluid dynamics (NICFD). This field of fluid mechanics is concerned with flows of vapors or gases, which are characterized by substantial deviations from the perfect gas model. In extreme cases, even non-classical gas dynamic phenomena could occur. Although these non-ideal compressible flows are the subject of sophisticated numerical simulation studies today, there is also a growing need for experimental data for validating purposes. In the last couple of years, new experimental test rigs designed for investigating non-ideal compressible fluid dynamics have been developed and commissioned. Classical practical measurement techniques are currently being re-developed and applied to non-ideal compressible flows. Despite its substantial relevance, information about these measurement techniques and their differences from conventional methods in the open literature is scarce. The present review article is an attempt to reduce that gap. After briefly discussing the thermodynamics and fluid dynamics of non-ideal compressible flows, the currently available test rigs and their utilized measurement techniques are reviewed. This review discusses schlieren optical investigations, pneumatic and laser-optical methods, and hot-wire anemometry for non-ideal compressible flows. Full article

Enhanced geothermal systems distinguish themselves among other technologies that utilize renewable energy sources by their possibility of the partial sequestration of carbon dioxide (CO₂). Thus, CO₂ in its supercritical form in such units may be considered as better working fluid for heat transfer than conventionally used water. The main goal of the study was to perform the techno-economic analysis of different configurations of supercritical carbon dioxide-enhanced geothermal systems (sCO₂-EGSs). The energy performance as well as economic evaluation including heat and power generation, capital and operational expenditures, and levelized cost of electricity and heat were investigated based on the results of mathematical modeling and process simulations. The results indicated that sCO₂ mass flow rates and injection temperature have a significant impact on energetic results and also cost estimation. In relation to financial assessment, the highest levelized cost of electricity was obtained for the indirect sCO₂ cycle (219.5 EUR/MWh) mainly due to the lower electricity production (in comparison with systems using Organic Rankine Cycle) and high investment costs. Both energy and economic assessments in this study provide a systematic approach to compare the sCO₂-EGS variants. Full article
