Shock buffet is one of the critical issues affecting the aerodynamic performance, flight quality, and flight safety of large aircraft. To overcome the limitations of traditional experimental measurement methods, such as insufficient capability in capturing flow features and high cost, an integrated experimental system tailored for extreme cryogenic and high-Reynolds-number conditions is developed based on the conventional tuft technique. This system comprises “preparation of low-flow-disturbance fluorescent mini-tufts, high-efficiency large-area tuft taping, automatic generation of digital streamline, and flow topology analysis”. Furthermore, a technique for assessing the transonic shock buffet onset using dynamic flow visualization with fluorescent mini-tufts is proposed. This paper takes a typical supercritical airfoil as the research object. First, through high-precision numerical simulations, it reveals that low-energy, unstable boundary-layer separation is the core driving force for the development and maintenance of shock buffet, and that flow separation characteristics serve as an important basis for determining the shock buffet onset. Subsequently, experimental validation is conducted in a 0.3 m high-Reynolds-number transonic wind tunnel. Using a dual-excitation-band composite light source, simultaneous measurements of pressure-sensitive paint (PSP) and fluorescent mini-tuft patterns are realized. The experimental results show that under extreme conditions, characterized by a wide total temperature range of 110 K to 280 K and strong scouring at Mach numbers from 0.6 to 0.9, the fluorescent mini-tufts (approximately 0.05 mm in diameter) exhibit excellent flow-following capability without any detachment. The digitized flow patterns of the fluorescent mini-tufts, obtained via computer image recognition algorithms, clearly reveal the location and area of boundary-layer separation. The trends show good agreement with the cryogenic PSP results, providing an important reference for determining the shock buffet onset. Full article

Machine learning has demonstrated significant potential as a valuable tool for aerodynamic design. However, collecting an abundant training set is usually computationally expensive and time-consuming. To address this data scarcity, meta-learning and transfer learning offer viable strategies. Meta-learning enables models to learn efficiently from limited data by leveraging experience across related tasks, while transfer learning reduces data requirements by reusing knowledge from pre-trained models. In addition, integrating physics knowledge into the models provides a complementary path to enhance the reliability and generalizability under data-scarce conditions. This paper studies meta-learning and transfer learning strategies to realize the prediction of supercritical airfoil pressure distribution under multiple free stream conditions with a small-scale dataset. All the models are tested both in the source domain and the target domain. Then, a systematic comparative analysis of different models across different target domain training sample scales is studied. Results show that meta-learning and transfer learning both improve target-domain performance compared to the baseline model. Yet, meta-learning still achieves limited accuracy in the target domain, and data-driven transfer learning exhibits poor generalization. Compared with data-driven models, the Mach number weighted transfer learning model provides more generalized results and higher accuracy. Full article

Mesh-agnostic models have advantages in processing flow field data with various topologies and densities, and they can easily incorporate partial differential equations. Beyond physics-informed neural networks, mesh-agnostic models have been studied for data-driven predictions of simple flows. In this study, a data-driven mesh-agnostic model is proposed to predict the transonic flow field of various supercritical airfoils. The model consists of two subnetworks, i.e., ShapeNet and HyperNet. ShapeNet is an implicit neural representation used to predict spatial bases of the flow field. HyperNet is a simple neural network that determines the weights of these bases. The input of ShapeNet is extended to ensure accurate prediction for different airfoil geometries. To reduce overfitting while capturing shock waves and boundary layers, a multi-resolution ShapeNet combining two activation functions is proposed. Additionally, a physics-guided loss function is proposed to enhance accuracy. The proposed model is trained and tested on various supercritical airfoils under different free-stream conditions. Results show that the model can effectively utilize airfoil samples with different grid sizes and distributions, and it can accurately predict the shock wave and boundary layer velocity profile. The proposed mesh-agnostic model can be used as a decoder in any conventional models, contributing to their application in complex and three-dimensional geometries. Full article

This study investigates the effect of Reynolds number on unsteady buffet characteristics of the OAT15A supercritical airfoil under transonic conditions (Ma = 0.73, AOA = 3.5°) using DDES based on the SST k-ω turbulence model coupled with the γ-Reθ transition model. Results show that, compared with fully turbulent conditions, the free-transition cases exhibit a more downstream shock position and higher lift. Under fully turbulent conditions, higher Reynolds numbers drive the shock downstream and enhance its stability. Under free-transition conditions, the shock moves downstream at low Reynolds numbers but shifts upstream at high Reynolds numbers due to changes in the transition location. During the unsteady buffet cycle at low Reynolds numbers, the lift increases as the shock moves downstream and the separation region shrinks. The lift reaches its maximum when the separation is minimal, corresponding to a quiet flow state with weak acoustic emission. As the lift decreases, a large separation region forms behind the shock, forcing the shock upstream and reducing the lift to its minimum. At high Reynolds numbers, the buffet cycle changes: the shock becomes more stable; trailing-edge vortex shedding intensifies; lift oscillation amplitude decreases; and buffet frequency increases. Full article

The variable camber morphing wing has the potential to achieve improved flight performance across different flight conditions by changing its geometry according to changing flight conditions. Evaluating the subtle aerodynamic benefits of variable camber technology necessitates wind tunnel testing under flight Reynolds number conditions. In high Reynolds number wind tunnels, the cryogenic environment readily damages model surface profiles through desublimation and frost, compromising test data accuracy. Consequently, cryogenic wind tunnels must enforce rigorous water vapor control standards. To address potential water vapor effects during cryogenic wind tunnel testing, high-resolution optical measurement techniques were employed to quantify the spatiotemporal evolution of desublimation frost thickness on a typical supercritical airfoil surface. Combined with numerical simulations, the mechanisms governing the frost layer’s influence on aerodynamic characteristics and flow field structures were systematically investigated. The results reveal that the influence of water vapor desublimation on the aerodynamic characteristics under diverse cryogenic working conditions has a commonality, and the difference in aerodynamic parameters shows an increasing tendency as the frost time increases; water vapor desublimation has an obvious influence on the flow structure of the airfoil and its pressure distribution on the surface, which increases flow instability and leads to the backward shift of the shock wave position; larger frost thickness gradients along the flow direction cause more drastic changes in pressure distribution and flow structure; and a larger rate of water vapor desublimation results from a lower temperature and a higher concentration of water vapor in the test environment, which causes frosting to have a more severe impact on the airfoil’s aerodynamic characteristics and flow structure. The findings establish a technical basis for cryogenic wind tunnel moisture control standards and provide a solid foundation for the refined assessment of aerodynamic benefits of the camber morphing wing. Full article

To investigate the aerodynamic characteristics and multi-objective optimization of the variable camber airfoils, the influence of leading- and trailing-edge deflections on aerodynamic performance is conducted. A novel prediction model is presented using the Kriging surrogate model, with leading and trailing edge deflection angles as inputs and lift coefficients and drag coefficients as outputs. The Non-dominated Sorting Genetic Algorithm II (NSGA II) multi-objective optimization technique is applied to ascertain the ideal deflection parameters. The results show that upward deflection of the leading edge raises the lift, whereas downward deflection increases the value of the critical angle of attack. The deflection of the trailing edge increases the value of the critical angle of attack, while the downward deflection can enhance the lift coefficient. Appropriate upward deflections of both leading and trailing edges can delay the critical Mach number, while downward deflections of both the leading and trailing edges can enhance the value of the critical Mach number. The discrepancies between the Kriging model prediction and the CFD simulation are less than 2%. Compared to the basic airfoil, the aerodynamic performance of the optimized airfoil has been improved, with the lift coefficient increasing by 7.55% and 7.37% and the lift-to-drag ratio rising by 6.97% and 10.27% at two Mach numbers, respectively. The efficiency and reliability of this method have been verified. Full article

The missions of modern aircraft require multiple abilities, such as highly efficient taking-off and landing, fast arrival, and long-endurance hovering. It is difficult to achieve all technical objectives using traditional aircraft design technology. The active flow control technology using the concept of a co-flow jet (CFJ) is a flow control method without a mass source that does not require air from the engine. It has strong flow control ability in low-speed flow, can greatly improve the stall angle of the aircraft, and can obtain large lift enhancement. At transonic conditions, it can lead to a larger lift–drag ratio with a small expense. CFJ technology has great application potential for aircraft due to its flexible control strategy and remarkable control effect. In this paper, the concept of a combination of CFJ and variable camber technology is proposed which realizes the change of airfoil camber to meet different task requirements with the movable droop head. By using the built-in ducted fan, air is blown and sucked in the jet channel so as to realize CFJ flow control. In a state of high-speed flight, complete geometric restoration is achieved by closing the channel and retracting the droop head. In this paper, the design and aerodynamic analysis of a CFJ device with variable camber based on a supercritical airfoil with small camber and a small leading-edge radius are carried out using the computational fluid dynamics (CFD) method. Comparative studies are conducted for different schemes on the taking off and landing performances, and discussions are had on core technical parameters such as power consumption. The results indicate that by utilizing the CFJ technology with more than 10 degrees of droop device, the maximum lift coefficient of a supercritical airfoil with a small camber and leading-edge radius, which is suitable for transonic flight, can be increased to a value larger than 4.0. Full article

This study explores the use of a passive control technique to mitigate aeroelastic effects on a wing operating near the ground. An aeroelastic model, based on a typical airfoil section, equipped with a nonlinear tuned vibration absorber (NLTVA), is established to study the interactions between the airfoil’s dynamics, aerodynamics, and the nonlinear energy dissipation mechanisms. Geometric nonlinearity is incorporated into the airfoil’s dynamics to account for possible large wing deflection and rotation. The flow is modeled based on the nonlinear unsteady discrete vortex method with the ground effect simulated using the mirror image method. Stability analyses are conducted to study the influence of NLTVA parameters on flutter mitigation and the bifurcation behavior of the airfoil near the ground. The numerical results demonstrate that the NLTVA effectively delays the onset of flutter and promotes a supercritical bifurcation in the presence of ground effect. Optimally tuning the NLTVA’s linear parameters significantly increases flutter speed, while selecting the optimal nonlinear parameter is key to preventing subcritical behavior near the ground and reducing the amplitude of post-flutter limit cycle oscillations. Overall, this study highlights the potential of the NLTVA in enhancing the aeroelastic stability of flying vehicles with highly flexible wings, especially under the influence of ground effects during takeoff and landing. Full article

The uncertainty of the turbulence/transition model is a problem with relatively high attention in the CFD area. Wall distance is an important physical parameter in turbulence/transition modeling, and its accuracy has a large effect on numerical simulation results. As most CFD solvers use the solving strategy to calculate the nearest distance to the wall based on mesh topology, this makes wall distance one important source of the uncertainty of the simulation results. To investigate the role of wall distance in turbulence/transition simulations, we have conducted simulations for various aerodynamic shapes, such as the plate with zero pressure gradient (ZPG), RAE2822 supercritical airfoil and ONERA M6 transonic wing. Further, the prediction abilities on turbulence/transition and shock wave phenomena of several physical models, including SA, SST and Wilcox-k-ω turbulence models as well as the γ-Re_θt-SST transition model, are analyzed with different degrees of mesh orthogonality. The results imply that the numerical solution of wall distance in the boundary layer has a relatively large error when the mesh orthogonality is bad, having a large effect on the accuracy of the turbulence/transition model. In detail, the Wilcox-k-ω turbulence model is unaffected by mesh orthogonality; under the condition of mesh non-orthogonality, the SA model leads to a substantially larger friction drag and change in the location of shock wave; the SST model also leads to a larger friction drag under the condition of mesh non-orthogonality, whose effect is much less than that for SA model; and the γ-Re_θt-SST model leads to a substantial upstream shift of transition location. Full article

The zonal detached-eddy simulation (ZDES) method divides the flow field into different computational modes, offering flexibility in the simulation of complex flows. The transonic shock buffet on the upper surface of the OAT15A supercritical airfoil is numerically simulated by ZDES based on the k-ω SST model. The results show that the error in the low-frequency characteristics of the transonic shock buffet predicted by ZDES compared to experiments is within 3%. Its predictions of pressure fluctuations and averaged velocity agree better with the experimental data. Overall, ZDES is effective in predicting the periodic oscillations of shock waves along the streamwise direction, flow separation induced by shock wave motion, and the small-scale vortex structures in the wake region. Full article

The coupling between a transonic buffeting flow and a supercritical airfoil with harmonic heave motion was studied. A parametric space of the heave frequency and amplitude was investigated using a verified fluid–structural interaction framework. The spatial-temporal flow pattern around the transonic airfoil was studied using dynamic mode decomposition (DMD) to unveil the physical coupling mechanism. The results show three types of flow responses under the heave motion: (I) A buffet frequency response with a $\lambda$-shape shock wave structure and recirculation zone at the shock foot. The aerodynamic performance was alike the scenario in the flow past the stationary airfoil. (II) A transitional response with a weakened shock and enhanced boundary layer. The aerodynamic performance deteriorated sharply at $f=f_{\mathrm{buffet}}$ and recovered after the frequency was past the buffet frequency. The flow pattern was characterized by a double-shock structure that interacted with the enhanced boundary layer. (III) A heave frequency response with the dominant heave motion. The variance in the aerodynamic loading increased significantly at $f>f_{\mathrm{buffet}}$ and there were higher heave amplitudes in this stage. The driving motion of the airfoil transferred the energy of the buffet mode to the boundary layer with a more even energy balance according to the energy contribution analysis of the DMD modes. Full article

Transonic buffet flow is a classical complex and unstable flow that has a negative effect on aircraft fly safety. Therefore, it is crucial to study the unsteady characteristics of buffet flow. The numerical analysis method is very useful in achieving the aforementioned goal. In this paper, focused on the typical supercritical airfoil OAT15A in fixed and pitching conditions, unsteady Reynolds averaged Navier–Stokes (URANS) closed with the sst-kω turbulence mode, coupled with the structure dynamical equation, is utilized to investigate the transonic buffet flow. Firstly, from the perspective of coherent flow structure, flow velocity divergence snapshots constructed from unsteady flow solutions are used to analyze the feature of transonic buffets in the two cases mentioned. Then, DMD modes are extracted by the dynamic mode decomposition technique from the velocity snapshots and adopted to analyze the flow modes of the two distinct flow fields. The numerical simulation results show that, in the fixed case, the regular motion feature of the buffet is present, the shock oscillation is closely related to the vortex structure, and the durations of rearward and forward movements of the shock are both equal to half of the buffet period. In the pitching case, the duration of the rearward motion of the primary shock is approximately five eighths of one buffet period, and the secondary shock appears with the primary one moving downstream, and they interact with each other. The region of the shock movement is larger than that of the fixed case, and there is chaotic flow rather than periodic flow in its wake. Structural elastic oscillation changes the characteristics of the aerodynamic response, which is solely affected by the frequency of the pitching oscillation. Full article

The limit cycle oscillation (LCO) in the transonic buffet on the fixed supercritical airfoil OAT15A under Ma = 0.73, AoA = 3.5° and $Re\approx 3\times {10}^6$, is successfully simulated by means of the Reynolds Stress Model. Further, the buffet lock-in phenomena under prescribed pitch conditions near the buffet onset are also studied by evaluating the modified energy exchange based on the pitching component of the moment coefficients as well as the normalized relative phase map between the pitching component of the moment coefficients and the airfoil’s angular velocity. The zero energy transfer branches in the modified energy map fail to indicate the lock-in boundaries, while the normalized phase map generally outlines the lock-in boundaries for small pitch amplitudes near the buffet onset, which suggests that the lock-in occurs where the moment is in phase with the angular velocity at small pitch amplitudes near the buffet onset. For pitch amplitudes larger than $0.4°$, the lock-in onset deviates from the phase shift, possibly due to the fact the instantaneous angle of attack can be lower than the buffet onset where the buffet phenomena may vanish. Full article

Variable camber wing technology stands out as the most promising morphing technology currently available in green aviation. Despite the ongoing advancements in smart materials and compliant structures, they still fall short in terms of driving force, power, and speed, rendering mechanical structures based on kinematics the preferred choice for large long-range civilian aircraft. In line with this principle, this paper introduces a linkage-based variable camber trailing edge design approach. Covering coordinated design, internal skeleton design, flexible skin design, and drive structure design, the method leverages a two-dimensional supercritical airfoil to craft a seamless, continuous two-dimensional wing full-size variable camber trailing edge structure, boasting a 2.7 m span and 4.3 m chord. Given the significant changes in aerodynamic load direction, ground tests under cruise load utilize a tracking-loading system based on tape and lever. Results indicate that the designed single-degree-of-freedom Watt I mechanism and Stephenson III drive mechanism adeptly accommodate the slender trailing edge of the supercritical airfoil. Under a maximum cruise vertical aerodynamic load of 17,072 N, the structure meets strength requirements when deflected to 5°. The research in this paper can provide some insights into the engineering design of variable camber wings. Full article

To provide sufficient lift during takeoff and landing, large aircraft are equipped with complicated high-lift devices. The use of simple flaps coupled with active flow control (AFC) can achieve lift improvement while reducing mechanical structure and weight. The present study focuses on verifying the feasibility and effectiveness of simple flaps combined with sweeping jet flow control. An experimental study on the AFC of flaps, using sweeping jets, was carried out using a NASA SC(2)-0410 supercritical airfoil wind-tunnel model at Re = 2.0 × 10⁵ (with velocity V = 10 m/s). In the experiment, the wing angle of attack (α) ranged from 3 to 18°, and the flap deflection angle (δ) ranged from 0 to 30°; the aerodynamic characteristics and surface pressure characteristics of the wing at typical working conditions were analyzed. Using sweeping jets to control the flow on the flaps, the momentum coefficients (for three actuator groups) of the jet are 0.8%, 3.6%, and 8.2%, respectively, and the maximum lift coefficient was increased by approximately 33%. The influence of the sweeping jet flow rate on the aerodynamic performance of the airfoil is analyzed. There are two main reasons for the lift coefficient increase caused by sweeping jet flow: an extra suction peak near the flap and a suction peak increase near the leading edge area caused by induced flow. Full article
