Search Results (65)

A scheme of load frequency control (LFC) is proposed based on the deep deterministic policy gradient (DDPG) and active disturbance rejection control (ADRC) for multi-region interconnected power systems considering the renewable energy sources (RESs) and energy storage (ES). The dynamic models of multi-region interconnected power systems are analyzed, which provides a basis for the subsequent RES access. Superconducting magnetic energy storage (SMES) and capacitor energy storage (CES) are adopted due to their rapid response capabilities and fast charge–discharge characteristics. To stabilize the frequency fluctuation, a first-order ADRC is designed, utilizing the anti-perturbation estimation capability of the first-order ADRC to achieve effective control. In addition, the system states are estimated using a linear expansion state observer. Based on the output of the observer, the appropriate feedback control law is selected. The DDPG-ADRC parameter optimization model is constructed to adaptively adjust the control parameters of ADRC based on the target frequency deviation and power deviation. The actor and critic networks are continuously updated according to the actual system response to ensure stable system operation. Finally, the experiment demonstrated that the proposed method outperforms traditional methods across all performance indicators, particularly excelling in reducing adjustment time (45.8% decrease) and overshoot (60% reduction). Full article

The rapid proliferation of renewable energy sources (RESs) has significantly reduced system inertia, thereby intensifying stability challenges in modern power grids. To address these issues, this study proposes a comprehensive approach to improve the grid stability concerning RESs and load disturbances. The methodology integrates controlled energy storage systems, including ultra-capacitors (UC), superconducting magnetic energy storage (SMES), and battery storage, alongside a robust frequency regulation management system (FRMS). Central to this strategy is the implementation of a novel controller which combines a constant with proportional–integral–derivative (PID) and modified fractional-order (MFO) control, forming 1+MFOPID controller. The controller parameters are optimized using a novel formulation of an improved objective function that incorporates both frequency and time domain characteristics to achieve superior performance. The efficacy of the proposed controller is validated by comparing its performance with conventional PID and fractional-order PID controllers. System stability is further analyzed using eigenvector analysis. Additionally, this study evaluates the performance of various energy storage systems and their individual contributions to frequency regulation, with a particular emphasis on the synergistic benefits of battery storage in conjunction with other storages. Finally, sensitivity analysis is conducted to assess the impact of parameter uncertainties in the system design, reinforcing the robustness of the proposed approach. Full article

An eco-friendly standalone microgrid is demonstrated in this article. It has an energy storage system (ESS), a superconducting magnetic energy storage system (SMES), and a wind power generator. Usually, microgrid control and energy management are challenging issues when designing microgrids. Hence, introducing fuzzy control concepts enhances the performance of the recommended microgrid. Wind and ESS energy are normally suitable for satisfying load demands under normal circumstances. However, the SMES supports the microgrid’s transient performance against load demand disturbances. The newly designed fuzzy proportion integral derivative (FPID) controller was used to measure the microgrid’s behavior subjected to fluctuations in wind power and load demand. Simulations via Matlab/Simulink were performed to assess the suggested system’s performance. The simulations’ outcomes established that the introduced microgrid continuously energizes the load demand with AC power during all interruptions with a regulated frequency and voltage. Furthermore, the microgrid operated excellently despite changing wind power and load. The results have been examined under identical conditions with and without SMES using the FPID controller and then compared to the proportional integral derivative (PID). Hence, the suggested microgrid has been examined under four situations: FPID controller with SMES, PID controller with SMES, FPID controller without SMES, and PID controller without SMES. It was found that the microgrid with the proposed FPID controller and SMES produced the best microgrid performance and responses of all the tested situations. The proposed control system provides an average improvement in overshoot, about 24.4%. Also, it is discovered that the suggested controller can precisely maintain the microgrid response stable under any disturbances, notwithstanding the modeling errors. Additionally, the TI C2000 Launchpad XL, TMS320F28379D microcontroller kit was used to create a Hardware-In-the-Loop (HIL) emulator in order to assess the suggested system and verify the simulation outcomes. Full article

Given the fundamental importance of the power grid in both supply and demand, frequency stability is critical to the reliable and stable function of energy systems. When energy is stored in the system, it mitigates problems caused by various disturbances that interrupt the energy system’s operation. The energy storage system (ESS) stores excess energy and returns it to the system by reducing power oscillations and improving stability and dependability. Superconducting magnetic energy storage (SMES) is one strategy for storing energy in the power system. As a rotational storage system, its quick dynamic response is a significant advantage. This device can quickly release a substantial amount of energy. A gas power plant in one area, along with a steam and a hydropower plant in another, constitute a multi-resource energy system. This paper’s primary objective is to study and model how SMES affects the dynamic behavior of this energy system. The state-space representation of the power system’s dynamic behavior is given by first-order differential equations. This power system has a complexity of fifteen orders. The outcomes of the simulation using MATLAB software are presented in the time domain, and its correctness is shown by analyzing the power system’s modes. The results show that placing an SMES unit not only eliminates oscillations and frequency deviation but also reduces the induction time in the time responses of power in the connection line and frequency deviation. Different modes are considered for the energy system, and the effect of the power storage unit is shown by presenting the simulation results. Full article

The increasing deployment of decentralized power generation based on intermittent renewable resources to reach environmental targets creates new challenges for power systems stability. Several technologies and approaches have been proposed in recent years including the use of superconducting magnetic energy storage. This study focuses on the review of existing superconducting magnetic energy storage systems for power quality control purposes. Such systems can supply and absorb the rated power level within seconds, promoting fast power quality regulation. Systems for power quality services such as frequency regulation, power oscillation damping, power fluctuation suppression, and active power filtering are identified and described. First, the physical characterization of superconducting magnets concerning geometries, materials, associated inductances, and nominal magnetic energy storage capacities is conducted. Then, the functional description of several current conversion circuits and systems used as interfaces for superconducting magnets is performed. The existing methodologies and systems to perform the control of current converters for different power control services and applications are also identified and described. Finally, the results regarding the number of different systems identified for each power quality control service are presented, and their applicability is discussed based on the adopted control approach. Challenges concerning the development of new systems to improve the power quality on grids with high penetration of decentralized energy resources from intermittent renewables are also identified. Full article

This study addresses the load frequency control (LFC) within a multiarea power system characterized by diverse generation sources across three distinct power system areas. area 1 comprises thermal, geothermal, and electric vehicle (EV) generation with superconducting magnetic energy storage (SMES) support; area 2 encompasses thermal and EV generation; and area 3 includes hydro, gas, and EV generation. The objective is to minimize the area control error (ACE) under various scenarios, including parameter variations and random load changes, using different control strategies: proportional-integral-derivative (PID), two-degree-of-freedom PID (PID-2DF), fractional-order PID (FOPID), fractional-order integral (FOPID-FOI), and fractional-order integral and derivative (FOPID-FOID) controllers. The result analysis under various conditions (normal, random, and parameter variations) evidences the superior performance of the FOPID-FOID control scheme over the others in terms of time-domain specifications like oscillations and settling time. The FOPID-FOID control scheme provides advantages like adaptability/flexibility to system parameter changes and better response time for the current power system. This research is novel because it shows that the FOPID-FOID is an excellent control scheme that can integrate these diverse/renewable sources with modern systems. Full article

The lack of dense random-access memory is one of the main obstacles to the development of digital superconducting computers. It has been suggested that AVRAM cells, based on the storage of a single Abrikosov vortex—the smallest quantized object in superconductors—can enable drastic miniaturization to the nanometer scale. In this work, we present the numerical modeling of such cells using time-dependent Ginzburg–Landau equations. The cell represents a fluxonic quantum dot containing a small superconducting island, an asymmetric notch for the vortex entrance, a guiding track, and a vortex trap. We determine the optimal geometrical parameters for operation at zero magnetic field and the conditions for controllable vortex manipulation by short current pulses. We report ultrafast vortex motion with velocities more than an order of magnitude faster than those expected for macroscopic superconductors. This phenomenon is attributed to strong interactions with the edges of a mesoscopic island, combined with the nonlinear reduction of flux-flow viscosity due to the nonequilibrium effects in the track. Our results show that such cells can be scaled down to sizes comparable to the London penetration depth, ∼100 nm, and can enable ultrafast switching on the picosecond scale with ultralow energy per operation, ∼${10}^{-19}$ J. Full article

As the world’s demand for sustainable and reliable energy source intensifies, the need for efficient energy storage systems has become increasingly critical to ensuring a reliable energy supply, especially given the intermittent nature of renewable sources. There exist several energy storage methods, and this paper reviews and addresses their growing requirements. In this paper, the energy storage options are subdivided according to their primary discipline, including electrical, mechanical, thermal, and chemical. Different possible options for energy storage under each discipline have been assessed and analyzed, and based on these options, a handsome discussion has been made analyzing these technologies in the hybrid mode for efficient and reliable operation, their advantages, and their limitations. Moreover, combinations of each storage element, hybrid energy storage systems (HESSs), are systems that combine the characteristics of different storage elements for fulfilling the gap between energy supply and demand. HESSs for different storage systems such as pumped hydro storage (PHS), battery bank (BB), compressed air energy storage (CAES), flywheel energy storage system (FESS), supercapacitor, superconducting magnetic coil, and hydrogen storage are reviewed to view the possibilities for hybrid storage that may help to make more stable energy systems in the future. This review of combinations of different storage elements is made based on the previous literature. Moreover, it is assessed that sodium-sulfur batteries, lithium-ion batteries, and advanced batteries are the most helpful element in HESSs, as they can be hybridized with different storage elements to fulfill electricity needs. The results also show that HESSs outperformed other storage systems and, hence, hybridizing the characteristics of different storage elements can be employed for optimizing the performance of energy storage systems. Full article

The decline in fossil fuels on the earth has become a primary global concern which has urged mankind to explore other viable alternatives. The exorbitant use of fuels by an ever-increasing global population demands a huge production of energy from renewable sources. Renewable energy sources like the sun, wind, and tides have been established as promising substitutes for fossil fuels. However, the availability of these renewable energy sources is dependent on weather and climatic conditions. Thus, this goal can only be achieved if the rate of energy production from renewable sources is enhanced under favorable weather conditions and can be stored using high energy storing devices for future utilization. The energy from renewable sources is principally stored in hydropower plants, superconducting magnetic energy storage systems, and batteries. Full article

Thin films of the superconductor YBa₂Cu₃O_7−δ (YBCO) were modified by low-energy light-ion irradiation employing collimated or focused He⁺ beams, and the long-term stability of irradiation-induced defects was investigated. For films irradiated with collimated beams, the resistance was measured in situ during and after irradiation and analyzed using a phenomenological model. The formation and stability of irradiation-induced defects are highly influenced by temperature. Thermal annealing experiments conducted in an Ar atmosphere at various temperatures demonstrated a decrease in resistivity and allowed us to determine diffusion coefficients and the activation energy $\Delta E=(0.31\pm 0.03)$ eV for diffusive oxygen rearrangement within the YBCO unit cell basal plane. Additionally, thin YBCO films, nanostructured by focused He⁺-beam irradiation into vortex pinning arrays, displayed significant commensurability effects in magnetic fields. Despite the strong modulation of defect densities in these pinning arrays, oxygen diffusion during room-temperature annealing over almost six years did not compromise the signatures of vortex matching, which remained precisely at their magnetic fields predicted by the pattern geometry. Moreover, the critical current increased substantially within the entire magnetic field range after long-term storage in dry air. These findings underscore the potential of ion irradiation in tailoring the superconducting properties of thin YBCO films. Full article

Presently, there exists a multitude of applications reliant on superconducting magnetic energy storage (SMES), categorized into two groups. The first pertains to power quality enhancement, while the second focuses on improving power system stability. Nonetheless, the integration of these dual functionalities into a singular apparatus poses a persistent challenge. Considering this, this paper proposes a multi-functional device based on SMES, encompassing both power quality enhancement and power system stability improvement capabilities. It incorporates power quality enhancement features such as current harmonic filtering, active power smoothing, reactive power compensation, and critical load protection, while also furnishing virtual inertia to bolster grid frequency. Simulation results validate the effectiveness of the proposed methodologies. Full article

Intelligent control methodologies and artificial intelligence (AI) are essential components for the efficient management of energy storage modern systems, specifically those utilizing superconducting magnetic energy storage (SMES). Through the implementation of AI algorithms, SMES units are able to optimize their operations in real time, thereby maximizing energy efficiency. To have a more advanced understanding of this issue, DynamoMan is presented in this paper. For use with SMES systems, DynamoMan, an Artificial Neural Network (ANN)-tuned Fractional Order PID Brain Emotional Learning-Based Intelligent Controller (ANN-FOPID-BELBIC), has been developed. ANN tuning is employed to optimize the key settings of the reward/penalty generator of a BELBIC, which are important for its overall efficacy. Following this, DynamoMan is integrated into the SMES control system and compared to scenarios in which a BELBIC, PID, PI, and P are utilized. The findings indicate that DynamoMan performs considerably better than other models, demonstrating robust and control attributes alongside a considerably reduced period of settling time, especially when incorporated with the power grid. Full article

The increasing penetration of renewable energy sources (RESs) in transmission and distribution systems presents several challenges for grid operators. In particular, the unpredictable behavior of RESs can disrupt the balance between energy production and load demand, potentially affecting the stability of the entire system. Grid-connected energy storage systems (ESSs) offer a possible solution to manage the uncertainty associated with RESs. In fact, ESSs exchange power with the grid through the adoption of suitable energy management strategies, which are typically implemented by power electronics-based grid interfaces. Unlike other current source converter (CSC) solutions described in the literature, which only interface with a single energy storage device, this paper introduces a novel topology for a three-phase delta-type current source converter (D-CSC), which is capable of integrating three independent ESSs using the same number of semiconductors as traditional CSC solutions. Thus, it considerably enhances the flexibility of a power conversion system (PCS) without increasing the number of converter components. In addition, an innovative energy management control strategy is also introduced. This strategy enables the D-CSC to compensate for energy imbalances arising between the three ESSs, which might be caused by several factors, such as different aging characteristics, converter component tolerances, operating conditions, and temperature drifts. Hence, the D-CSC-based interface is capable of proper grid operation even if the three ESSs have different characteristics, thus opening the possibility of employing this converter to integrate both first and second-life devices. First, the topology of the proposed D-CSC is introduced, followed by a detailed mathematical description of its control strategy. The proper grid operation of the D-CSC was tested under different scenarios, considering the grid integration of three independent superconducting magnetic energy storage systems in a marine vessel. The proposed D-CSC is compared to traditional CSC solutions, highlighting the superior performances of the novel converter topology in terms of efficiency, total harmonic distortion of the output currents, and overall cost reduction for the PCS. Full article

Energy storage systems are essential in modern energy infrastructure, addressing efficiency, power quality, and reliability challenges in DC/AC power systems. Recognized for their indispensable role in ensuring grid stability and seamless integration with renewable energy sources. These storage systems prove crucial for aircraft, shipboard systems, and electric vehicles, addressing peak load demands economically while enhancing overall system reliability and efficiency. Recent advancements and research have focused on high-power storage technologies, including supercapacitors, superconducting magnetic energy storage, and flywheels, characterized by high-power density and rapid response, ideally suited for applications requiring rapid charging and discharging. Hybrid energy storage systems and multiple energy storage devices represent enhanced flexibility and resilience, making them increasingly attractive for diverse applications, including critical loads. This paper provides a comprehensive overview of recent technological advancements in high-power storage devices, including lithium-ion batteries, recognized for their high energy density. In addition, a summary of hybrid energy storage system applications in microgrids and scenarios involving critical and pulse loads is provided. The research further discusses power, energy, cost, life, and performance technologies. Full article

With the global trend of carbon reduction, high-speed maglevs are going to use a large percentage of the electricity generated from renewable energy. However, the fluctuating characteristics of renewable energy can cause voltage disturbance in the traction power system, but high-speed maglevs have high requirements for power quality. This paper presents a novel scheme of a high-speed maglev power system using superconducting magnetic energy storage (SMES) and distributed renewable energy. It aims to solve the voltage sag caused by renewable energy and achieve smooth power interaction between the traction power system and maglevs. The working principle of the SMES power compensation system for topology and the control strategy were analyzed. A maglev train traction power supply model was established, and the results show that SMES effectively alleviated voltage sag, responded rapidly to the power demand during maglev acceleration and braking, and maintained voltage stability. In our case study of a 10 MW high-speed maglev traction power system, the SMES system could output/absorb power to compensate for sudden changes within 10 ms, stabilizing the DC bus voltage with fluctuations of less than 0.8%. Overall, the novel SMES power compensation system is expected to become a promising solution for high-speed maglevs to overcome the power quality issues from renewable energy. Full article
