This paper presents a methodology for estimation of hydrodynamic loads acting on the bottom and at the walls of a stilling basin of a stepped chute with converging walls, based on the pressure measurements at the selected points of a scale model. This is the first study of hydrodynamic loads for this type of structure, and the first one of the loads on the stilling basin walls in general. For selected flow discharges, step heights and hydraulic jump submergence ratio, the hydrodynamic pressures were measured at a significant number of points, providing the spatio-temporal distribution of relevant hydrodynamic loads. The most influential effect proved to be a convergence angle of the chute walls. Based on these measurements, appropriate regression expressions were proposed for predicting hydrodynamic loads. These expressions show good agreement with measurements, offering a reliable tool for the structural design of stepped spillway stilling basins. Full article

Floating raft aquaculture has gradually become a mainstream aquaculture model in the waters of Changhai County, Dalian. To quantitatively describe the impact of floating raft aquaculture facilities on the hydrodynamic environment of nearby sea areas, in this study, we took a single floating raft aquaculture structure as the research object and built a numerical prediction model for water flows passing through the floating raft aquaculture structure using a six-degree-of-freedom VOF (volume of fluid) multiphase flow simulation method based on an overset moving mesh system. Then, we verified the numerical model by utilizing oblique hydraulic jumps and water flows passing through a submerged bar. As shown by the findings, the simulated values are in good agreement with the theoretical solutions and measured values, indicating that the model features high precision and great stability. The impact of the raft area on the hydrodynamic force was introduced into the source term of an equation for consideration. In order to further determine the hindering effect of the raft body on the water body, transport equations and the tracer method were used to simulate the impact of floating raft aquaculture facilities on the water exchange performance of nearby sea areas. This study shows that the VOF multiphase flow model can be easily and accurately applied to studies on floating raft aquaculture, which can greatly reduce the limitations of experiments that utilize pure hydraulic models, wherein the impacts of floating raft aquaculture facilities on hydrodynamic force are generally considered simply based on observations, water roughness or the secondary drag force coefficient, thereby effectively improving the scientific understanding of the physical mechanism involved in floating raft aquaculture. Full article

Downstream of the sluice gate or weir, wave-type flows inevitably occur in stilling basins with no tailwater. This paper aims to investigate the hydraulic performance of wave-type flows at a sill-controlled stilling basin through experimental research. The flow pattern, bottom pressure profiles along the stilling basin, and the air concentrations on the bottom and the sidewall were examined in five sill-controlled stilling basins by altering the sill position and the height. The results show that wave-type flow patterns contain submerged and non-submerged jumps, which are relevant to ambient pressure head and air entrainment. The bottom pressure profiles are related to larger pressure fluctuations at large unit discharges and two peak pressure values in the vicinity of the sill. The air concentrations on the bottom and the sidewall decrease with the increasing unit discharge. The flow zone in the vicinity of the sill should be focused upon concerning protection against cavitation damage because of the slight air entrainment and significant pressure fluctuations. These findings advance our understanding of wave-type flows, and their ambient pressure heads and air entrainment are useful for designing the sill-controlled stilling basin in hydraulic engineering. Full article

Low-head dams can be dangerous to recreational river users when a submerged hydraulic jump forms downstream, with recirculating surface flows that repeatedly carry trapped recreationists upstream into the high-velocity jet plunging over the dam crest. The flow endangers those who pass over the dam from upstream and can also entrap those who approach too closely from downstream. A national task force is using a range of methods to identify potentially dangerous structures, but definite determination requires field data and an analysis of the hydraulic conditions for each site’s range of likely flow rates. The spreadsheet tool described here determines the submergence created by site-specific tailwater levels and uses previous research results to estimate the associated magnitude of reverse flow velocities. The spreadsheet also determines the crucial tailwater level at which the jet passing over the dam stops plunging into the tailwater pool and instead flips to the surface, creating safer, downstream-directed velocities. The article describes application to specific sites and provides insight about the dangerous flow range of typical low-head dams. Full article

Identifying low-head dams (LHDs) and creating an inventory is a priority, as fatalities continue to occur at these structures. Because obstruction inventories do not specifically identify LHDs and they are not assigned a hazard classification, there is no official inventory of LHDs; a multi-agency taskforce is creating one now by identifying LHDs using Google Earth Pro (GE Pro). The purpose of this paper is to assess whether a machine learning approach can accelerate the creation of the national inventory. We implemented a machine learning approach to use a high-resolution remote sensing data with a Convolutional Neural Network (CNN) architecture. The model achieved 76% accuracy in identifying LHDs (true positives) and 95% accuracy identifying Non-low-head-dams (true negatives) on the validation set. We deployed the trained model for the National Hydrologic Geospatial Fabric (Hydrofabric) flowlines in the Provo River watershed. The results showed a high number of false positives and low accuracy due to the mismatch between Hydrofabric flowlines and actual waterways. We recommend improving the accuracies of the Hydrofabric waterway tracing algorithms to increase the percentage of correctly classified LHDs. Full article

With the increasing availability of low head dam inventories for the United States, the next challenge is discovering how to determine what dams pose the greatest risk to public safety, preferably before a death occurs. Submerged hydraulic jumps create the dangerous current that drowns roughly 50 recreationists each year, and high tailwater is a key element in its formation. Using a simplified approach based on the Manning equation, flat downstream slopes can be a predictor of high tailwater. Stream slopes at low head dams in Colorado, Idaho, Indiana, Maryland, New Mexico, North Carolina, and Pennsylvania were collected from the NHDPlus HR, and dams with recorded fatalities were compared to stream slopes at low head dams with no recorded fatalities. Using the Mann–Whitney U test, there was not enough evidence to reject the null hypothesis that there is no statistically significant difference between the two populations. Until more fatality data are compiled and more low head dam locations are verified, individual testing of dams is recommended to establish each respective flow range that is likely to pose a risk to public safety. Full article

Sluice gates are common hydraulic structures for controlling and regulating flow in open channels. This study investigates five models’ performance in distinguishing conditions of flow regimes, estimating the discharge coefficient ($C_d$) and flow rate. Experiments were conducted for different gate openings, flow rates, upstream and downstream conditions. New equation forms and methods are proposed to determine $C_d$ for energy–momentum considering losses (EML) and HEC-RAS models. For distinguishing the flow regimes, results indicated a reasonable performance for energy–momentum (EM), EML, and Swamee’s models. For flow rate and discharge coefficient performance of EM, EML, and Henry’s models in free flow and for EM and EML in submerged flow were reasonable. The effects of physical scale on models were investigated. There were concerns about the generality and accuracy of Swamee’s model. Scaling effects were observed on loss factor k in EML. A new equation and method were proposed to calibrate k that improved the EML model’s accuracy. This study facilitates the application and analysis of the studied models for the design or calibration of sluice gates and where the flow in open channels needs to be controlled or measured using sluice gates such as irrigation channels or water delivery channels of small run-of-river hydropower plants. Full article

This study investigates the characteristics of free and submerged hydraulic jumps on the triangular bed roughness in various T/I ratios (i.e., height and distance of roughness) using CFD modeling techniques. The accuracy of numerical modeling outcomes was checked and compared using artificial intelligence methods, namely Support Vector Machines (SVM), Gene Expression Programming (GEP), and Random Forest (RF). The results of the FLOW-3D^® model and experimental data showed that the overall mean value of relative error is 4.1%, which confirms the numerical model’s ability to predict the characteristics of the free and submerged jumps. The SVM model with a minimum of Root Mean Square Error (RMSE) and a maximum of correlation coefficient (R²), compared with GEP and RF models in the training and testing phases for predicting the sequent depth ratio (y₂/y₁), submerged depth ratio (y₃/y₁), tailwater depth ratio (y₄/y₁), length ratio of jumps ($L_j/y_2^{*}$) and energy dissipation (ΔE/E₁), was recognized as the best model. Moreover, the best result for predicting the length ratio of free jumps $(L_{jf/}{y}_2^{*}$) in the optimal gamma is γ = 10 and the length ratio of submerged jumps $(L_{js/}{y}_2^{*}$) is γ = 0.60. Based on sensitivity analysis, the Froude number has the greatest effect on predicting the (y₃/y₁) compared with submergence factors (SF) and T/I. By omitting this parameter, the prediction accuracy is significantly reduced. Finally, the relationships with good correlation coefficients for the mentioned parameters in free and submerged jumps were presented based on numerical results. Full article

This study presents an investigation on the use of submerged counterflow jets as a means for stabilizing the spatial hydraulic jump occurring in abruptly expanding channels. The characteristics of the flow downstream from the stilling basin and the main parameters influencing the effectiveness of the device in improving flow uniformity and reducing scouring potential are examined in laboratory tests, under several geometric configurations and hydraulic boundary conditions. The position within the stilling basin and the jet density (i.e., the number of orifices issuing the counterflow jets) were found to be important parameters influencing the performance of the device. Overall, the results indicate that this dissipation system has promising capabilities in forcing the transition from supercritical to subcritical flow, by significantly shortening the protection length needed to limit the phenomena of instability associated with spatial hydraulic jumps. Full article

The submerged hydraulic jump is a sudden change from the supercritical to subcritical flow, specified by strong turbulence, air entrainment and energy loss. Despite recent studies, hydraulic jump characteristics in smooth and rough beds, the turbulence, the mean velocity and the flow patterns in the cavity region of a submerged hydraulic jump in the rough beds, especially in the case of triangular macroroughnesses, are not completely understood. The objective of this paper was to numerically investigate via the FLOW-3D model the effects of triangular macroroughnesses on the characteristics of submerged jump, including the longitudinal profile of streamlines, flow patterns in the cavity region, horizontal velocity profiles, streamwise velocity distribution, thickness of the inner layer, bed shear stress coefficient, Turbulent Kinetic Energy (TKE) and energy loss, in different macroroughness arrangements and various inlet Froude numbers (1.7 < Fr₁ < 9.3). To verify the accuracy and reliability of the present numerical simulations, literature experimental data were considered. Full article

Interaction of recirculating and mean flow downstream of a submerged gate may form significant vortex structures, which may affect the stability of the gate. Although these flow structures that appear in submerged hydraulic jumps received considerable attention in the literature, relatively less work was devoted to the analysis and suppression of the vortex structures downstream of a submerged gate. In this work, internal flow structure and vortex dynamics around a submerged gate were investigated through laboratory tests and large-eddy simulation (LES) using computational fluid dynamics (CFD). It is shown that numerical results obtained for mean velocity field are in good agreement with the experimental measurements. A helical vortex pair connected with a horseshoe vortex system was identified within the roller region using high-resolution numerical simulations. Damping performance of different types of anti-vortex elements placed on the downstream face of the gate are evaluated based on numerical studies. It is shown that the horizontal porous baffle mounted at an elevation below the free surface reduced the vortex magnitudes in the roller region by 26.8%. With the implementation of the proposed vortex breaker, lift forces acting on the gate lip were reduced by 9.4% and drag forces acting on the downstream face of the gate were reduced by 8.6%. Finally, in this study, we assess the performance of the vortex breaker under different flow conditions. Full article

Steps effectively dissipate the energy of water along a path and reduce the size of the stilling basin but are rarely used in curved spillways. The shore spillway of a reservoir, which is restricted by topography, must be arranged in a curved shape. At high flow velocity and low water depth, some areas of the base plate of the curved spillway were not covered by the water. The water flow into the stilling basin did not form a submerged hydraulic jump. It was proposed that a step with bottom non-uniform heights be placed in the smooth base plate of the curved spillway to improve these undesirable hydraulic phenomena. A physical model experiment with a length scale of 1:40 verified the feasibility of the curved stepped spillway in engineering. Based on the k-ε model and volume-of-fluid (VOF) method, a three-dimensional numerical model was established, and the reliability of the numerical model was verified by measured data. The main flow region, velocity field, cavitation on a step, and the energy loss rate of steps were discussed. The comparison between a curved spillway with and without steps shows that the steps balance the partial centrifugal force in the curved section, making the water depth of the cross-section evenly distributed, and the base plate was no longer covered by water. The flow pattern on the steps was skimming flow, and the velocity of the flow into the stilling basin was greatly reduced. The elevation of the concave bank of the base plate was raised, resulting in the formation of transverse flow, which in turn constituted a three-dimensional energy dissipation pattern with the longitudinal flow. The energy loss was significantly higher than that of the smooth curved spillway. However, the triangular region near to the concave bank on the base plate experienced negative pressure, and an aeration device in front of the steps was needed. Full article
