Search Results (177)

In aerospace manufacturing, validating heavy-duty automated production tooling and Ground Support Equipment (GSE) traditionally requires costly and time-consuming physical proof load testing. This study proposes a novel Virtual Certification framework that utilizes a high-fidelity Multiphysical Digital Twin driven by a Software-in-the-Loop (SiL) co-simulation architecture (integrating Siemens NX MCD, SIMIT, and TIA Portal) to retroactively diagnose mechanical failures and virtually validate design modifications prior to physical manufacturing. The dual-focus methodology is rigorously applied to a physical case study: an over-constrained (hyperstatic) 4-point aerospace lifting system designed for a 26.48 kN fuselage section that suffered a catastrophic mechanical stall during a 39.24 kN physical proof load verification. While conventional static dimensioning models erroneously predicted a nominal drive torque of only 4.56 Nm, the high-fidelity dynamic twin (incorporating a non-linear exponential Stribeck friction model) calculated the transient mechanical resistance causing the stall, capturing a peak load of 46.2 Nm at the motor shaft. The SiL co-simulation revealed that the rigid positional synchronization logic enforced by the PLC inadvertently amplified localized boundary friction, driving the actuators beyond their rated 6.4 Nm capacity. Based on this forensic diagnosis, a remedial powertrain featuring an 8.0 Nm stepper motor coupled with a 16:1 planetary gearbox was integrated and virtually certified. The framework confirmed that the upgraded architecture successfully attenuated the hyperstatic resistance, reflecting a peak load of only 3.0 Nm at the motor shaft and guaranteeing a stable Safety Factor of 2.66. By bridging the reality gap without iterative physical prototyping, this framework establishes a scalable, “First-Time-Right” validation paradigm for multi-point automated manufacturing mechanisms. Full article

High-precision X–Y positioning systems driven by stepper motors are widely used in industrial automation, manufacturing, and scientific instrumentation. However, fixed feedforward–feedback controllers may degrade when operating conditions vary, particularly as step frequency changes and the risk of synchronism loss increases. This work proposes an adaptive fuzzy feedforward–feedback controller for stepper-motor-driven X–Y positioning systems. The controller uses a Takagi–Sugeno (T–S) fuzzy inference system to adjust the proportional, derivative, and feedforward actions according to the tracking error, step frequency, and an auxiliary error-based adaptation variable. The control law is integrated with the inverse kinematics of the platform to generate synchronized step-domain commands, and a practical synchronism-preservation condition is established. Experimental validation on a NEMA 17-based X–Y platform showed accurate trajectory tracking, with a steady-state error of approximately $1.6\left[\mathsf{\mu }\mathrm{m}\right]$ for a trapezoidal profile. For a multi-segment trajectory, the RMSE was $0.0749\left[\mathrm{mm}\right]$ without load and $0.0760\left[\mathrm{mm}\right]$ under a $7.5\left[\mathrm{kg}\right]$ external load. Compared with a conventional PID controller, the proposed method reduced the RMSE from $0.1741\left[\mathrm{mm}\right]$ to $0.0749\left[\mathrm{mm}\right]$, while preserving motor synchronism. Full article

A compact encoder-based focusing mechanism is proposed to compensate for axial focal-plane displacement in a space optical camera. The mechanism converts the rotation of a stepper motor into linear motion of the CCD focal plane assembly through a worm gear pair, a gear pair, and a cylindrical cam pair, while an encoder provides position feedback for closed-loop control. A displacement-count transmission model was developed and verified through MTF simulation, positioning tests, autofocusing experiments, finite element analysis, and vibration tests. The mechanism achieved a single-step control resolution of 1.38 μm and an encoder-based displacement measurement accuracy of 0.486 μm. The positioning test showed a maximum absolute error of 7 μm within a ±2 mm travel range, satisfying the ±7.5 μm requirement. Optical simulation indicated that axial defocus broadened the PSF and reduced the MTF near the 50 lp/mm Nyquist frequency. Autofocusing experiments using a resolution target showed that the normalized stripe contrast recovered to its maximum near the best-focus position, supporting the practical image-quality recovery trend predicted by the MTF simulation. The measured first natural frequency was 174.64 Hz, and the random vibration amplification ratios were below 3 in all tested directions. The results demonstrate that the proposed mechanism can provide accurate and mechanically robust compensation of focal-plane displacement. Full article

Stepper-motor-driven Selective Compliance Assembly Robot Arms are susceptible to motion control challenges under short-stroke and high-frequency start–stop conditions, including high sensitivity to pulse timing, difficulty in multi-joint coordination, and insufficient trajectory smoothness. To address these issues, this paper proposes an optimized motion control method for smooth execution of obstacle-avoidance trajectories, integrating path smoothing, asymmetric S-curve velocity planning, and pulse-frequency-based multi-axis synchronization. First, piecewise cubic Hermite interpolation, Gaussian smoothing, and end-effector-based equidistant resampling are applied to post-process Rapidly-exploring Random Tree-generated paths, thereby eliminating polyline turning points and improving uniformity of waypoint distribution. Second, an asymmetric S-curve velocity planning method with nonzero boundary velocity constraints is developed, and multi-axis synchronization is achieved based on the maximum segment duration principle. Finally, instantaneous reference velocities are converted into per-axis pulse frequency commands via proportional mapping, enabling real-time stepper motor drive control. Experimental results show that the proposed method reduces the obstacle-avoidance path length by 8.52% and significantly decreases the dispersion of trajectory step sizes. In single-segment dynamic simulations, the proposed method reduces the peak dynamic output force by 62%. In real robot experiments, the average motion time across three obstacle-avoidance tasks is reduced by approximately 55.21%, while end-effector trajectory continuity and inter-joint coordination are improved, suggesting the effectiveness and preliminary engineering feasibility of the proposed method under the tested conditions. Full article

Programmable gas flowmeters with remote reading and control are increasingly needed in the era of automation and AI. However, commercially available options remain expensive, hindering their adoption. We therefore developed a cost-effective programmable flowmeter as a compact device based on a low-cost glass rotameter. This system consists of a reading unit (webcam + rotameter), a control unit (development board + stepper motor-actuated valve) using an open-loop pre-calibrated step-to-flow matrix, and a terminal interface. The side-view imaging of the glass rotameter avoids occlusion of the rotor by the scale, enabling reliable rotor identification using well-established algorithms. The flow rate is derived by mapping the normalized rotor position to the scale instead of recognizing the scale markings or numerals. Two terminal configurations are offered: USB-connected (PC + MATLAB) and embedded (Raspberry Pi + Python). The USB-connected configuration uses direct serial communication between MATLAB and Arduino for stepper motor step control, ensuring fast response and good compatibility. The prototype retains manual control and direct eye reading. Experiments demonstrated strong programmability, fast response (0.2 s), high accuracy (mean error < 3%), and stable reading (fluctuation < 0.5%). This cost-effective yet programmable gas flowmeter is expected to benefit gas sensor development and accelerate automation in fluid-related fields. Full article

At present, although there are many SCARA manipulator solutions with vertical lifting functionality, they generally suffer from high maintenance costs and complex structures. Moreover, systematic performance evaluations based on international standards are lacking, leading to unclear critical performance boundaries such as accuracy and payload in practical applications. To address these issues, this paper designs and manufactures a low-cost SCARA manipulator for educational and research demonstrations as well as light-duty electronic parts assembly scenarios. A “leadscrew + stepper motor” scheme is adopted for vertical lifting, and an Arduino Mega 2560 development board serves as the core controller, significantly reducing system cost. A three-dimensional model is established using SolidWorks 2022, and kinematic simulations are carried out with MATLAB 2024a to preliminarily verify the feasibility of the mechanism. Subsequently, a physical prototype is built and experimental tests are conducted in accordance with the ISO 9283 standard. The experimental results show that the repeatability of the manipulator is controlled within the range of 0.05–0.3 mm, the path deviation caused by vibration lies between −0.52 mm and 0.3 mm, and the maximum payload capacity is 3.91 N. These experimental data can serve as a benchmark for the design and performance comparison of similar low-cost manipulators. Full article

Lower-limb amputation remains a significant clinical and socio-economic challenge, while the high cost of microprocessor-controlled prostheses (MPKs) limits their widespread accessibility. This paper presents the design and preliminary laboratory-scale evaluation of a low-cost microprocessor-controlled ankle prosthesis intended as a feasibility-oriented alternative platform for future active prosthetic system development. Building upon the previously developed V1 mechanical architecture, an updated CAD model was created in the SolidWorks 2024 environment, and the kinematic configuration was refined using a ball-screw transmission (SFU1204-300) driven by a NEMA 17 stepper motor. The electronic control system integrates an ESP32 microcontroller, an MPU9250 inertial measurement unit (IMU), a limit switch for initial-position detection, and a WiFi-based REST API interface for communication and control. Laboratory no-load experiments demonstrated controlled positional behavior, repeatable angular response, and successful operation of the homing procedure within a motion range of 0–4200 motor steps. The prototype actively generated dorsiflexion–plantar flexion motion in the sagittal plane, while a passive inversion–eversion mechanism was incorporated and intended to improve structural adaptability. IMU-based measurements enabled preliminary monitoring of angular displacement and positional behavior during the experiments. The presented prototype represents an initial engineering feasibility study of a low-cost active ankle actuation architecture and provides a foundation for future investigations involving load-bearing experiments, biomechanical gait analysis, and closed-loop control implementation. Full article

Hybrid stepper (HB) motors are widely used in precision actuation systems such as cryogenic refrigerator robotic arms. Under cryogenic working conditions, the core loss characteristics of magnetic materials change significantly, while conventional core loss models calibrated at room temperature can hardly provide reliable prediction accuracy. In this work, the electromagnetic properties of 35SW1900 non-oriented silicon steel were measured from 25 °C − 100 °C using a BROCKHAUS Epstein frame system. Variations in permeability, core loss and coercivity with magnetic flux density, temperature and frequency were obtained. An improved core loss model was developed by introducing a flux-dependent exponent and dual temperature correction coefficients for hysteresis and eddy current losses. Experiments place the prediction error of the proposed model within 4% under cryogenic conditions. Compared with the classical Bertotti model, the proposed model effectively reduces high-frequency deviation caused by the temperature-dependent material properties and skin effect. The core loss of silicon steel increases by 15–30% at −100 °C compared with room temperature, which is mainly attributed to the decrease in resistivity and the strengthening of domain wall pinning. This paper provides an accurate loss prediction method and design references for HB motors applied in ultralow temperature working conditions. Full article

Vibrations in stepper motors remain a critical issue, reducing positioning accuracy and overall system performance. This study investigates vibration levels in stepper motors operated in an open-loop using classical control strategies across a range of rotational speeds. The obtained results have led to the identification of vibration levels during different control configurations. The research conclusions can improve positioning stability and reduce vibration without requiring hardware modifications. Full article

To monitor online the operational condition and quality of a desktop fused deposition modeling (FDM) printer, the dynamics of vibro-acoustics must be accurately understood. In this paper, an electromechanical coupling (EMT) framework is established to relate the dynamics of stepper actuation, the transmission chain, and machine motion, deriving a steady-state frequency–velocity mapping for steady or near steady printing segments. The mapping is evaluated by numerical calculation to obtain a theoretical drive frequency for different toolpath directions and commanded printing velocities. Validation is performed on the experiment platform I. Drive-side vibration is measured by an accelerometer mounted on the x-axis beam near the motor end. An acoustic channel is recorded as an auxiliary qualitative cross-check rather than for quantitative error evaluation. For steady printing segments, the dominant frequency in drive-side vibration is compared with the theoretical drive frequency. In the tested steady segments and toolpath directions, the relative error remained below 3%. In a further case study, the G-code is modified to introduce two constant printing velocity segments (40 mm/s and 80 mm/s) within the same continuous record, enabling a direct comparison of dominant frequencies between two steady segments. The results show that, under open-loop stepper drive and within the steady/near steady scope adopted here, a drive-related dominant frequency can be observed stably in the x-axis beam vibration response and matches the theoretical drive frequency. When the commanded constant printing velocity is doubled, the dominant frequency in drive-side vibration in the corresponding steady segment changes by approximately a proportional factor. This study provides a verifiable drive referenced frequency–velocity mapping for steady segments under the tested configuration and a traceable frequency reference for steady segment comparisons within the same print record in subsequent case studies. Full article

Accurate yaw alignment is critical for maximizing power capture in horizontal-axis wind turbines, as even moderate yaw misalignment leads to significant aerodynamic losses, increased actuator usage, and accelerated mechanical wear. This research paper proposes a hybrid smart yaw control system for small-scale wind turbines that combines real-time measurements with short-term wind direction prediction to improve alignment accuracy, operational reliability, and energy efficiency under realistic operating conditions. The system integrates four wind direction information sources, such as physical wind vane sensing, live online weather data, forecast data, and a data-driven prediction module within a structured priority framework (VANE → LIVE → FORECAST → AI), to ensure continuous yaw control during sensor or communication unavailability. The prediction module is based on a long short-term memory (LSTM) neural network trained in MATLAB using live data from an online platform, with sine–cosine encoding employed to address the circular nature of directional data. The yaw controller incorporates a ±15° deadband, dwell-time logic, shortest-path rotation, and cable-safe constraints to reduce unnecessary actuation while maintaining effective alignment. The proposed system is validated through MATLAB/Simulink simulations and real-time microcontroller-based experiments using a stepper motor-driven nacelle. Compared with conventional vane-based yaw control, the hybrid AI-assisted approach reduces the average yaw error by approximately 35–45%, maintains a yaw error within ±15° for more than 90% of the operating time, increases average electrical power output by 3–5%, and reduces yaw motor energy consumption by 10–15%, while decreasing corrective yaw actuation events by 30–40%. These results demonstrate that integrating an LSTM-based wind direction predictor with multi-source wind data provides a robust, low-cost, and practically deployable yaw control solution that enhances energy capture and mechanical durability in small-scale wind turbines. Full article

Apple picking is an inherently labor-intensive, time-consuming, and costly task, and robotic harvesting represents a potential alternative to address this challenge. This study presents the development and field evaluation of an integrated robotic system for apple harvesting, which combines machine vision, a dual four-degree-of-freedom (DoF) manipulator, and a mobile platform. The harvesting mechanism employed a streamlined 4-DoF manipulator driven by closed-loop stepper motors, incorporating a differential gear mechanism to execute yaw and pitch motions. Trajectory planning utilized linear interpolation with a harmonic acceleration/deceleration profile to ensure smooth end-effector movement. Fruit detection and localization within the canopy were performed by a stereo vision system running a lightweight deep neural network, achieving a mean hand-eye calibration accuracy of 4.7 ± 2.7 mm. Three negative-pressure driven soft end-effector designs—a suction soft end-effector (SSE), a grasping soft end-effector (GSE), and a suction-grasping soft end-effector (SGSE)—were assessed for their harvesting performance. Field trials conducted in a commercial spindle orchard demonstrated that the GSE achieved the highest performance, with a harvesting success rate of 80.80% among reachable fruits, a full-process success rate (from detection to collection) of 61.59%, an overall fruit damage rate of 10.89%, and an average single-fruit cycle time of 5.27 s. In contrast, the SSE and SGSE showed lower success rates (49.21% and 64.71%, respectively). This work provides a practical robotic harvesting solution. It validates the feasibility of a zoned, multi-manipulator harvesting strategy and delivers comparative data to guide the development of more efficient and robust harvesting robots. Full article

This paper presents the design, construction, and calibration of a modular low-cost 3D printer based on open-source technologies, developed as part of an academic research project. The printer utilises fused filament fabrication (FFF) and is built using locally available materials and components, including a T-slot aluminium frame, NEMA 23 stepper motors, and an Arduino Mega 2560 with RAMPS 1.4 control board. The system integrates Marlin firmware and CURA slicing software, enabling autonomous operation via an LCD panel and encoder interface. A detailed methodology is provided for mechanical assembly, electronic integration, firmware configuration, and calibration procedures. Special attention is given to the challenges encountered during the initial testing phase, including filament feeding issues, thermal inconsistencies, and mechanical misalignments. Solutions such as replacing inadequate components (e.g., fibreglass bushings with PTFE), adjusting spring tension, and refining firmware parameters are discussed. The results demonstrate successful printing of complex geometries after iterative calibration, validating the printer’s performance and replicability. This work contributes to the democratisation of additive manufacturing by offering a replicable, open-source solution for educational and prototyping purposes. The findings are relevant to machine design, automation, and robotics communities seeking practical insights into low-cost fabrication systems. Full article

Standing equine computed tomography (CT) acquisitions are susceptible to residual postural sway, which can introduce view-inconsistent motion and degrade image quality. External optical tracking based on ChArUco fiducials is a promising, low-cost strategy to enable projection-wise motion compensation, yet quantitative guidance on how camera–marker geometry affects pose-estimation performance remains limited. This CT-motivated benchtop study characterizes how the relative camera–ChArUco configuration influences both the accuracy (bias with respect to ground truth) and the precision (repeatability) of pose estimates obtained from RGB images using OpenCV ChArUco detection and reprojection-error minimization to estimate the rigid camera-to-board transformation. Controlled experiments systematically varied acquisition protocol (continuous repeated estimates at fixed pose versus cyclic repositioning), viewing angle over a wide angular range at two working distances, and camera-to-board distance over multiple depth settings. Ground truth for angular configurations was defined by a stepper-motor rotation stage, while distance ground truth was obtained by ruler measurements. Performance was summarized via mean absolute error and standard deviation across repeated measurements, complemented by variance-based statistical testing with multiple-comparison correction. Cyclic repositioning did not yield evidence of increased variability relative to continuous acquisitions, supporting view-by-view sampling. Viewing angle induced a consistent accuracy–precision trade-off for rotations: frontal views minimized mean error but exhibited higher variability, whereas oblique views reduced jitter at the expense of increased bias. Increasing working distance reduced repeatability, most prominently for depth-related components. Overall, these findings provide pre-clinical guidance for selecting camera/marker placement (moderately oblique viewpoints, limited working distance, sufficient image footprint) before in-scanner and in-vivo validation for standing equine CT motion compensation. Full article

This paper presents a disc-type stepper motor based on PCB technology. Aiming to provide a solution for the difficulty of torque enhancement in multi-pole PCB stepper motors under the limited wiring space of the PCB stator, a novel spiral winding configuration is proposed. Without increasing the number of PCB stator layers or the overall dimensions, an axially offset layout is employed to enlarge the coil flux-linkage area, thereby increasing the electromagnetic torque. Theoretical analysis and finite element simulation results show that the proposed winding achieves approximately 30% higher torque than conventional spiral windings. Meanwhile, to address the current fluctuation problem caused by the low-inductance characteristic resulting from the coreless PCB stator, the influence of current ripple on the microstepping drive of the stepper motor is analyzed. A series-inductor approach is adopted to suppress current fluctuation, and the optimal inductor value is selected through theoretical calculation and simulation, which effectively reduces the current ripple and significantly improves the microstepping performance. Finally, a prototype is fabricated and tested experimentally. The results indicate that the motor output torque reaches 46.4 mN·m, and the step-angle error under 16-microstep drive is within 0.25°, providing a feasible solution for the design and control of PCB stepper motors in compact spaces. Full article
