This study investigates two novel prefabricated frame joints: prestressed steel sleeve-connected prefabricated reinforced concrete joints (PSFRC) and non-prestressed steel sleeve-connected prefabricated reinforced concrete joints (SSFRC). A total of three PSFRC specimens, four SSFRC specimens, and one cast-in-place joint were designed and fabricated. Seismic performance tests were conducted using different end-plate thicknesses, grout strengths, stiffener configurations, and prestressing tendon configurations. The experimental results showed that all specimens experienced beam end failures, and three failure modes occurred: (1) failure of the end plate of the beam sleeve, (2) failure of the variable cross-section of the prefabricated beam, and (3) failure of prefabricated beams at the connection with the steel sleeves. The load-bearing capacity and initial stiffness of the structure are increased by 35.41% and 32.64%, respectively, by increasing the thickness of the end plate. Specimens utilizing C80 grout exhibited a 39.05% higher load capacity than those with lower-grade materials. Adding stiffening ribs improved the initial stiffness substantially. Specimen XF2 had 219.08% higher initial stiffness than XF1, confirming the efficacy of stiffeners in enhancing joint rigidity. The configuration of the prestressed tendons significantly influenced the load-bearing capacity. Specimen YL2 with symmetrical double tendon bundles demonstrated a 27.27% higher ultimate load capacity than specimen YL1 with single centrally placed tendon bundles. An analytical model to calculate the moment–rotation relationship was established following the evaluation criteria specified in Eurocode 3. The results demonstrated a good agreement, providing empirical references for practical engineering applications. Full article

To address the challenges of slow construction and high self-weight in steel–concrete composite floors for rural light steel frame structures in China, a new prefabricated floor system was developed. This system features prefabricated slabs made from recycled concrete, connected via reinforced shear pocket joints. In seismic environments, assembly floor joints often become vulnerable points, making their shear resistance particularly crucial. This study investigated the shear performance of this new type of floor joint, examining the effects of various parameters such as joint configuration, stud diameter, recycled concrete strength, and grout strength. A refined finite element model was established for an in-depth parameter analysis. The research revealed stud–shear failure as the mode of floor joint failure under different design parameters. The detailed design of the new joint structure ensures safety in the floor joint area. Increasing stud diameter, recycled concrete strength, and grout strength all contributed to enhancing the joint’s shear capacity and stiffness, with stud diameter having the most significant impact. Higher recycled concrete strength improved shear capacity, although its influence decreased beyond a certain threshold. Optimal reserved hole diameter proved beneficial for enhancing joint shear performance, with a diameter of 40 mm showing superior performance. Full article

As one type of critical load-bearing element in precast concrete structures, grouted sleeve (GS) connections enable efficient force transmission between reinforcing bars while maintaining structural integrity. Despite their growing global adoption, significant variations exist in design philosophies, construction specifications, and performance requirements among regional standards. Through bibliometric analysis, the most active countries and regions in GS application and research worldwide were identified, and the relevant technical standards established by these countries and regions were systematically reviewed. By comparing standards from Asia, the Americas, Europe, and Oceania, the main differences in design philosophy, construction quality control, material specifications, and performance requirements among these standards were analyzed and identified. The results show that different standards have a conceptual difference at the materials and quality control level, with one approach focusing on stricter management of sleeve materials and more detailed on-site construction requirements, and another approach emphasizing testing-based methods and third-party verification. These standards can be divided into the following two categories for the design limits of GS tensile performance: one category takes multiples of the yield strength of the connected reinforcing bars as the limit, and the other category takes multiples of the tensile strength of the connected reinforcing bars as the limit. Regarding mechanical performance requirements, standards using the ultimate tensile strength of the connected reinforcing bars as the control parameter differ from those using multiples of yield strength in their performance requirements for connections of low-strength and high-strength reinforcing bars. The variation in yield-to-tensile strength ratios among steel grades across different countries is a key factor leading to these different requirements. When using the uniform steel bar material properties specified in the standard for quantification, as the bar strength increases from approximately 240 MPa to 600 MPa, the minimum required ratio of the limits for standards based on multiples of yield strength and multiples of tensile strength increases from 0.79 to 1.07. When applying GS connections to reinforcing bars of varying strength levels, using fixed strength multiplier requirements may result in uneconomical designs or create technical challenges in achieving the required strength. Full article

The prefabricated concrete channel, constructed by integrating factory-based prefabrication with on-site assembly, offers enhanced quality, reduced construction time, and minimized environmental impact. To promote its application in water conservancy projects, an innovative concrete joint combining semi-grouting sleeves and shear-resistant steel plates was proposed. Its seismic performance was assessed through a 1:3 scale low-cycle reversed loading test, focusing on failure mode, hysteretic behavior, skeleton curves, stiffness degradation, ductility, and energy dissipation. Results show that the joint primarily exhibits bending–shear failure, with cracks initiating at the sidewall–base slab interface. Also, the sidewall and base slab are interconnected through semi-grouting sleeves, while the concrete bonding is achieved via grouting and surface chiseling at the joint interface. The results indicated that the innovative concrete joint connection exhibits satisfied seismic performance. The shear-resistant steel plate significantly improves shear strength and enhances water sealing. Compared with cast-in-place specimens, the prefabricated joint shows a 16.04% lower equivalent viscous damping coefficient during failure due to reinforcement slippage, while achieving 16.34% greater cumulative energy dissipation and 52.00% higher ductility. These findings provide theoretical and experimental support for the broader adoption of prefabricated channels in water conservancy engineering. Full article

To reduce the cast in place work of concrete and realize the industrial production of a bamboo–concrete composite (BCC), innovative connection systems composed of an assembled bamboo–lightweight concrete composite (ABLCC) structure featuring perforated steel plate connectors are presented for use in engineering structures. This study examined the shear performance of connection systems composed of an assembled BCC structure featuring perforated steel plate connectors based on the design and fabrication of three groups of shear connectors with nine different parameters using bamboo scrimber, lightweight concrete, perforated steel plates, and grout. Push-out tests were conducted on these shear connectors. A linear variable differential transformer (LVDT) and digital image correlation (DIC) were utilized for measurements. The test parameters comprised fabrication techniques (assembled and cast-in-place/CIP) and connector size (steel plate thickness). This study investigated mechanical performance indicators, including the failure mode, load–slip relationship, shear stiffness, and shear capacity of the shear connectors. The experimental results showed that the shear connector failure modes involved concrete spalling near the connectors and deformation of the perforated steel plates. The load–slip curves generally included three stages: high slope linear increase, low slope nonlinear increase, and rapid decrease. The shear capacity and stiffness of the assembled shear connectors were 0.84 times and 2.46 times those of the CIP connectors, respectively. The stiffness of the 4 mm steel plate connectors increased by 42% compared to the 2 mm steel plate connectors. Analysis showed that the shear capacity of the BBC primarily consisted of four aspects: the end bearing force of the steel plate, contact friction, and forces due to the influence of tenon columns and the reinforcing impact of through-rebars. This study proposes a simple and suitable formula for obtaining the shear capacity of perforated steel plate connectors in the BCC structure, with the analytical values being in good agreement with the test results. Full article

This paper presents experimental results on the influence of the spiral anchor system on the flexural behavior of concrete beams reinforced with glass fiber-reinforced plastic (GFRP) bars. The experimental program consisted of eight beams with the spiral anchor system and two control fiber-reinforced concrete beams without any spiral anchor system. All specimens were tested under bending load. Rough and smooth surface textures of GFRP bars were considered. The test parameters were the diameter of spiral anchor and the condition of the GFRP reinforcement bars as either bonded or unbonded to the surrounding grout. The experimental results indicate that beams reinforced with a rough GFRP bar with an anchor system under flexural load had higher ultimate flexural strength, first crack strength, and stiffness as compared to the beams without an end anchor system. The success of the anchor system is attributed to the confining effect of the steel spiral in anchoring the reinforcement ends. This confining effect enhances the anchorage capacity of the anchor system and subsequently improves the overall flexural performance of the reinforced concrete beams. Full article

Steel-reinforced grout (SRG) composites are a newly developed retrofitting technique, which is considered an alternative to other fiber-reinforced composites to increase the load-carrying capacity of existing structures. This work presents an experimental campaign aimed at investigating the response of reinforced concrete (RC) beams strengthened with SRG externally applied to the tension side of the member to improve flexural capacity. The number of fiber sheet layers and fiber sheet density have been varied to evaluate the effectiveness of the retrofitting system. For some beams, different solutions of anchors at the ends of the beams have been considered to delay the premature debonding of the SRG. Moreover, single-lap direct shear tests have been carried out on concrete prisms strengthened with the same SRG composite to evaluate the bond behavior of the system. Failure modes, load responses, and corresponding flexural capacity (beam tests) and debonding loads (shear tests) are reported. The moment–curvature curves derived from cross-sectional analysis are compared with the corresponding experimental curves. The strain when the loss of composite action occurs is obtained from the curvature measured experimentally and compared with the values from formulas for the strain available in the literature and the strain at debonding in single-lap shear tests. Full article

Traditional monolithic precast and precast prestressed concrete joints often face challenges such as complex steel reinforcement details and low construction efficiency. Grouting sleeve connections may also suffer from quality issues. To address these problems, a new precast prestressed concrete frame beam-column exterior joint using ultra-high-performance concrete (UHPC) for connection (PPCFEJ-UHPC) is proposed. This innovative joint lessens the amount of stirrups in the core area, decreases the anchorage length of beam longitudinal reinforcement, and enables efficient lap splicing of column longitudinal reinforcement, thereby enhancing construction convenience. Cyclic loading tests were conducted on three new exterior joint specimens (PE1, PE2, PE3) and one cast-in-place joint specimen (RE1) to evaluate their seismic performance. The study concentrated on failure modes, energy dissipation capacity, displacement ductility, strength and stiffness degradation, shear stress, and deformation’s influence on the longitudinal reinforcement anchoring length and axial compression ratio. The results indicate that the new joint exhibits beam flexural failure with minimal damage to the core area, unlike the cast-in-place joint, which suffers severe core area damage. The novel joint exhibits at least 21.7% and 6.1% improvement in cumulative energy consumption and ductility coefficient, respectively, while matching the cast-in-place joint’s bearing capacity. These characteristics are further improved by 5.5% and 10.7% when the axial compression ratio is increased. The new joints’ seismic performance indices all satisfy the ACI 374.1-05 requirements. Additionally, UHPC significantly improves the anchoring performance of steel bars in the core area, allowing the anchorage length of beam longitudinal bars to be reduced from 16 times of the diameter of reinforcement to 12 times. Full article

This study researches the bending and shear performance of the fragile cross-section of square hollow steel-reinforced concrete columns using experiments, numerical analysis, and theoretical investigation. First, three tests of square hollow steel-reinforced concrete column (HSrCC) specimens considering different sectional sizes and grouting conditions were conducted. The bearing capacity and load transfer mechanisms under bending and shear loading were experimentally compared. Second, a numerical model was established based on the experimental results, and then parametric studies were performed on the bearing capacity and deformation of the structure. Last, a peak load calculation formula was derived in this study considering thickness and strength for a 400 × 400 square HSrCC. Based on the experimental results, the failure process of the specimen can be divided into four steps. Grouting increases stiffness at the front part of the specimen but induces significant damage at the rear compared to the no-grouting case, with the maximum strain increasing by 25%. Increasing the cross-sectional area of the concrete short column effectively improves the overall performance, with the maximum tensile strain of the concrete short column being reduced by approximately 1.2 times. Under the given sectional dimensions, parametric analysis suggests that the optimal square hollow steel thickness and steel strength range from 14 mm to 16 mm and from Q355 to Q420, respectively. The proposed peak load calculation formula demonstrates a discrepancy of less than 5.06% when compared with the numerical model results. These findings provide valuable references for the design of square hollow steel-reinforced concrete columns. Full article

Due to the unique structural characteristics of loess, the strength of loess is significantly influenced by the water content. Therefore, different support parameters should be used for loess tunnels constructed in different water content strata. This paper takes the Fengshouling Tunnel as a case study, studying the reasonable primary support parameters under different water contents using the surrounding rock strength test, on-site monitoring, and numerical simulation software analysis. The research findings indicate that the strength of the surrounding rock is functionally related to its water content, with the cohesive force c exhibiting an exponential relationship and the angle of internal friction φ showing a linear relationship, and that the cohesive force c is more affected by changes in water content than the internal friction angle φ. The crown settlement of the loess tunnel exceeds the horizontal convergence, and the deformation behavior can be categorized into three distinct stages: rapid growth, continuous growth, and slow growth. Concurrently, the primary support structure mainly bears compressive stress. On the basis of considering structural safety and engineering economy, for tunnels with a general water content (10~17%), it is recommended to use I18 steel ribs spaced 60 cm apart and C25 shotcrete with a 24 cm thickness; for high water content (17~25%), it is recommended to use I20a steel ribs, also spaced 60 cm apart, complemented by C25 shotcrete increased to a 26 cm thickness; for situations with an extremely high water content (≥25%), it is recommended to reinforce the surrounding rock with curtain grouting and use steel ribs with the same 60 cm spacing, along with C25 shotcrete maintained at a 26 cm thickness. This paper proposes reasonable support parameters for loess tunnels applicable to different water contents. These results can provide guidance and specific reference for loess tunnels under different water content strata. Full article

Due to the impact of disordered mining activities in previous years, numerous abandoned roadways exist in the second mining district of the 13# coal seam in Chejiazhuang Coal Mine. The stability of the new roadway roof was analyzed under various distributions of abandoned roadways above. It was determined that the ultimate stable thickness of the coal layer between the new and abandoned roadways is 4.0 m. When the thickness between the two is less than 4.0 m, the roof becomes unstable after excavation, posing a risk of collapse. Advanced grouting reinforcement is required to enhance roof stability before installing U-shaped steel arches. Mechanical experiments were conducted on the polymer grouting consolidation of fractured coal, showing a significant increase in residual strength compared to intact coal. Furthermore, the uniaxial compressive strength of the polymer grouting consolidation partially recovered. On average, the consolidation coefficient and recovery coefficient were 5.28 and 85.51%, respectively. Grouting increased the ductility of the fractured surrounding rock, enhancing its resistance to deformation and plasticity. A polymer grouting consolidation technology for supporting fractured surrounding rock under the unstable roof of abandoned roadways is proposed, along with the design of corresponding support schemes and parameters. Monitoring the results of mine pressure indicated that the surrounding rock remained stable after roadway excavation, validating the effectiveness of the support schemes and parameters. Full article

In practical engineering, due to quality inspections of connections between prefabricated components and construction errors, reserved reinforcing bars in the transition layer may be partially insufficient or even completely absent. This defect significantly impacts the structural performance of sleeve connections, particularly under tensile or shear forces. This paper proposes a novel reinforcement method to address the connection issues caused by the absence of reserved reinforcing bars in the transition layer and verifies its feasibility through systematic experiments. To this end, this paper proposed a novel reinforcement method of grouting sleeve connection considering the absence of reserved bars in the transition layer, and 45 specimens with different reinforcement parameters were fabricated and tested under tension. Before verifying the reliability of the novel reinforcement method, nine specimens were fabricated and tested to verify the weldability of grouting sleeves and reinforcing bars. According to the test results, the fully grouted sleeves, including Grade 45 steel and Q345, showed good weldability with the HRB400 steel bars, while the ductile iron grouted sleeve showed poor weldability. When the single-sided welding length was greater than or equal to six times the diameter of the post-retrofitted connecting steel bar (D₂), the primary failure mode observed in specimens utilizing the novel reinforcement method was the fracture of the prefabricated steel bar. The novel reinforcement method could be used to repair the defect of the grouting sleeve connection considering the absence of reserved reinforcing bars in the transition layer. When the single-sided welding length was 4D₂, with a relative protective layer thickness of 2D₂, and using C60 grade reinforcement material, this combination of conditions represented the critical condition to avoid weld failure between the grouting sleeve and the post-retrofitted connecting steel bars. In practical reinforcement projects, it is suggested that the single-sided welding length should be 5D₂, the relative protective layer thickness should be 3D₂, and the reinforcement material strength should be C60. Full article

Joints in frame structures often fail before beams and columns in an earthquake and are a key part of reinforcement. In this study, to enhance the seismic performance of concrete frame structures, a steel-jacketed grouting composite reinforcement method is proposed by combining reinforcement technology, steel cladding technology, and eco-efficient materials from grouting technology. This method effectively utilizes the advantages of various materials, avoids major demolition and construction, and reduces waste and resource consumption. In order to verify the feasibility and effectiveness of the reinforcement method, one of the original joint specimens with a scale of 1:3 and one of the reinforced joint specimens were designed and tested. The experiments involved reversed cyclic testing of beam–column to measure its seismic behavior. The seismic performance indexes such as failure characteristics, hysteretic properties, and the energy dissipation capacity of the specimens were analyzed, and the corresponding finite element model was established. The influence of key parameters such as reinforcement range, steel plate thickness, and grout strength on its seismic performance was explored. The research shows that the method can effectively improve the seismic performance of the joints, and seismic performance indexes such as bearing capacity, ductility, and energy consumption of the specimens are significantly improved. The test results of the established finite element model are in good agreement. The variable parameter analysis of the finite element shows that the thickness of the steel plate has little influence on its bearing capacity. With the increase in the reinforcement range of the clad steel and the strength of the grouting material, the bearing capacity of the specimen increases. The research results can provide a reference for the reinforcement of frame structure joints. Full article

Aiming to solve the problems that a wind turbine foundation with a foundation pipe may suffer from grouting, where the concrete around the interface collapses and the interface disintegrates under a long-term wind load, a kind of wind turbine foundation with a constrained structural shear connector is proposed. In this article, the scaling model tests and a finite element simulation of a traditional stud foundation pipe, perforated steel shear connector foundation pipe, and three groups of constrained structural shear connector foundation pipes with different anchored depths are presented. The force transmission mechanism and damage mechanism of constrained structural shear connector wind turbine foundations are revealed, and the shear resistance of a constrained structural shear connector is analyzed. The influences of buried depth and other parameters on the mechanical properties of the shear connector are also investigated. The results show that the constrained structural shear connector has the advantages of stronger interfacial stiffness and significant force transfer and diffusion, and can more effectively connect the foundation pipe and concrete foundation to work together. It can give full play to the material advantages of concrete and reinforcements, and effectively improve the embedded stiffness and durability of concrete foundations. It can solve the problem of cracks in concrete caused by local pressure. At the same time, it is suggested that the diameter of the surrounding concrete should be in the range of 3 to 4 D, and the embedment depth of the stud should not be less than 0.4 D to give full play to the performance of the constrained structural shear connector. Full article

Basement anti-flotation design is crucial in modern urban construction. An increase in groundwater buoyancy can cause basement structures to uplift, leading to structural instability or even damage. To ensure the stability and safety of underground structures under various hydrogeological conditions, anti-flotation design must comprehensively consider factors such as construction, design, supervision, structure, and hydrology. During construction, improper dewatering measures or unreasonable construction progress may lead to an abnormal rise in groundwater levels, increasing the risk of anti-flotation. Design considerations must include sufficient safety margins, supervision must fully recognize the impact of groundwater, and the structural dead load must be adequate. Anti-flotation stability verification includes both overall and local anti-flotation, involving the calculation of groundwater buoyancy, structural self-weight, and overburden, and selecting appropriate anti-flotation stability safety factors. The assessment and selection of the anti-flotation design water level are also critical. Common anti-flotation measures include adding counterweights, tension-resistant piles, compression and tension-resistant piles, and hydro-pressure reduction methods, while reinforcement and repair methods include epoxy resin grouting and steel plating reinforcement. Through systematic analysis and comprehensive research, scientific basis and technical support are provided for anti-flotation design, enhancing design efficiency and reliability and ensuring the safety and stability of underground spaces. Future research will develop more accurate calculation methods, improve design standards, and explore new anti-flotation technologies and materials. Full article
