Search Results (37)

In this study, an effective strengthening method was investigated to improve the seismic performance of masonry brick walls. The strengthening method comprised the use of shotcrete, which was applied in both glass fiber-reinforced and unreinforced forms for steel plates and tie rods. Thirteen wall specimens constructed with vertical perforated masonry block bricks were tested under diagonal compression in accordance with ASTM E519 (2010). Reinforcement plates with different thicknesses (1.5 mm, 2 mm, and 3 mm) were anchored using 6 mm diameter tie rods. A specially designed steel frame and an experimental loading program with controlled deformation increments were employed to simulate the effects of reinforced concrete beam frame system on walls under the effect of diagonal loads caused by seismic loads. In addition, numerical simulations were conducted using three-dimensional finite element models in Abaqus Explicit software to validate the experimental results. The findings demonstrated that increasing the number of tie rods enhanced the shear strength and overall behavior of the walls. Steel plates effectively absorbed tensile stresses and limited crack propagation, while the fiber reinforcement in the shotcrete further improved wall strength and ductility. Overall, the proposed strengthening techniques provided significant improvements in the seismic resistance and energy absorption capacity of masonry walls, offering practical and reliable solutions to enhance the safety and durability of existing masonry structures. Full article

The superb dynamic performance of steel-plate composite (SC) structures under unexpected impact loading depends on the good design of the connection between the SC wall and foundation. This study investigated the flexural behavior and dynamic responses of SC wall-to-foundation connections subjected to low-velocity impact. Impact tests were performed on three SC connection specimens to evaluate failure mode, impact force, deflection, and strain responses. The effects of concrete strength grade and impact energy were analyzed in detail. All specimens exhibited flexural failure, with three distinct stages observed during impact. The experimental results demonstrated that compared to the specimen with C30 concrete, the specimen with C50 concrete significantly reduced wall damage, decreased deflections, and enhanced deflection recovery ability. It can be concluded that increasing the concrete strength grade effectively improves the impact resistance of SC wall-to-foundation connections. In addition, peak impact force, global deflection response, residual strains, and interface crack length were highly sensitive to changes in impact energy, whereas deflection recovery exhibited lower sensitivity. Furthermore, a finite element model was developed and validated against experimental results. Parametric studies explored the influence of key parameters with expanded ranges on the impact responses of SC wall-to-foundation connections. Full article

This paper proposes a hybrid steel plate–bolt dry and wet jointing method, where the dry jointing part is a steel plate–bolt connector joint and the wet jointing part is a cast-in-place concrete. The novel precast concrete shear wall (PCW) combines the advantages of both dry and wet connections. A steel plate–bolt dry–wet hybrid connection shear wall model was developed using the finite element method, and a low circumferential reciprocating load was applied to the PCW. By analyzing the force and deformation characteristics of the wall, the results showed that the failure mode of novel PCWs was bending-shear failure. Compared to the concrete wall (CW), the yield load, peak load, and ductile displacement coefficient were 6.55%, 7.56%, and 21.49% higher, respectively, demonstrating excellent seismic performance. By extending the wall parameters, it was found that the increased strength of the novel PCW concrete slightly improved the load-bearing capacity, and the ductility coefficient was greatly reduced. As the axial compression ratio increased from 0.3 to 0.4, the wall ductility decreased by 22.85%. Increasing the reinforcement rate of edge-concealed columns resulted in a severe reduction in ultimate displacement and ductility. By extending the connector parameters, it was found that there was an increased number of steel joints, a severe reduction in ductility, enlarged distribution spacing, weld hole plugging and bolt yielding, reduced anchorage performance, and weakening of the steel plate section, which reduced the load-bearing capacity and initial stiffness of the wall, with little effect on ductility. Full article

Underground granaries naturally preserve grain quality by maintaining low temperatures and reduced oxygen levels, eliminating the need for artificial cooling and pest control. However, cast-in-place reinforced concrete construction faces challenges such as waterproofing and complex on-site processes, necessitating prefabricated steel plate-concrete composite structures with robust joints for enhanced structural integrity and streamlined construction. The study utilizes a full-scale prefabricated steel plate-concrete underground silo, instrumented with strain gauges on circumferential steel bars and internal steel plates to monitor stress variations during six distinct backfilling loading cases. Concurrently, finite element models were developed using ABAQUS 6.14 software for numerical simulations, which were validated against experimental data. Stability analyses, including buckling load assessments and parameter sensitivity studies, were conducted to evaluate the effects of joint quantity and bending stiffness on the structural performance of the composite walls. The results revealed that circumferential joints play a critical role in stress distribution within the composite walls, underscoring the necessity of optimized joint design. The numerical model accurately replicated experimental results, with deviations below 9%, confirming its reliability. Furthermore, an equivalent joint design method was established, demonstrating that a joint bending stiffness ratio above 1.1 ensures that prefabricated composite walls achieve critical buckling loads comparable to cast-in-place walls. These findings provide a robust framework for enhancing the structural performance and reliability of prefabricated underground silos. Full article

Due to its high axial bearing capacity and good ductility, the embedded steel plate composite shear wall structure has become one of the most widely used lateral force-resisting structural members in building construction. However, bending failure is prone to occur during strong earthquakes, and the single energy dissipation mechanism of the plastic hinge zone at the bottom leads to the concentration of local wall damage. To improve the embedded steel plate composite shear wall structure, the plastic hinge zone of the composite shear wall is replaced by fiber-reinforced concrete (FRC) and analyzed by ABAQUS finite element simulation analysis. Firstly, the structural model of the embedded steel plate composite shear wall structure with FRC in the plastic hinge zone is established and the accuracy of the model is verified. Secondly, the effects of steel ratio, longitudinal reinforcement ratio, and FRC strength on the bearing capacity of composite shear walls are analyzed by numerical simulation. Finally, a method for calculating the embedded steel plate composite shear wall structure with FRC in the plastic hinge zone is proposed. It is shown that the displacement and load curves and failure modes of the model are basically consistent with the experimental results, and the model has high accuracy. The axial compression ratio and FRC strength have a great influence on the bearing capacity of composite shear walls. The calculation formula of the normal section bending capacity of the embedded steel plate composite shear wall structure with FRC in the plastic hinge zone is proposed. The calculated values of the bending capacity are in good agreement with the simulated values, which can provide a reference for its engineering application. Full article

Nuclear power plants, where steel-plate concrete (SC) structures are commonly adopted, require large-scale components to withstand significant loads, such as those caused by sudden explosions. As a result, SC modular members used in nuclear power plants must have thicker walls filled with concrete compared to standard-sized ones. These large walls also require additional components, such as tie bars and H-shaped steel sections, to reinforce adhesion and resist shear stresses. This study focuses on tie bars placed adjacent to studs and evaluates their influence on the tensile strength of wall structures. To investigate this, we conducted experimental tests using full-scale specimens, including various combinations ranging from single stud to combined stud-tie configurations. Based on the results of these performance tests, we propose a design recommendation for estimating the tensile capacity of SC structures, considering the influence of tie bars. Full article

To enhance the seismic resilience of building structures and refine the stability and longevity of buildings, it is essential to implement strategies that not only reinforce their structural integrity but also ensure their enduring functionality. The seismic performance test of corrugated steel plate–concrete–filled steel tube shear walls with transverse ribs was studied. Three specimens of shear walls featuring transversely ribbed corrugated steel plates filled with concrete were fabricated, namely, a C–shaped shear wall with four square steel tube concrete columns (specimen C40), a C–shaped shear wall with vertical loading beams (specimen C40X), and a C–shaped shear wall with two steel tube concrete columns (specimen C40LX). Each specimen was equipped with transverse–rib corrugated steel plates with the same parameters. The seismic performances of the specimens were tested by applying loads to different specimens through the displacement–controlled loading system. The tests show that the hysteretic curves of test piece C40 and test piece C40X are not full compared with that of test piece C40LX; the cracking load, yield load, peak load, and ultimate load of both are significantly lower than those of test piece C40LX; and the energy consumption levels of test piece C40 and test piece C40X are relatively weak. The test piece C40LX obviously has a high ductility coefficient, and the stiffness decrease under load is relatively small. During the loading process, the strain change law of the vertical reinforcement in the bottom section of the wall also maintains a reasonable state. It can be seen that the C–shaped transverse–rib corrugated steel plate–concrete–filled steel tube shear wall with two concrete–filled steel tube columns has a higher seismic performance. Full article

To address the issue of insufficient transverse connectivity in prestressed concrete box girder (PCB) bridges, this study investigates two transverse strengthening methods—installing diaphragms and utilizing concrete-filled steel tube trusses (CFSTTs). A finite element model was developed for a typical 30 m PCB bridge and was validated by on-site load test results for reliability. Based on the deflection and load distribution of PCB bridges before and after reinforcement, as well as the maximum stress and strain of the diaphragms and the CFSTTs, comparative analyses were conducted on diaphragms of different thicknesses and materials, as well as on CFSTTs of various strength grades. The results show that the addition of a transverse partition and CFSTTs can effectively improve the load distribution of the PCB bridge and reduce the maximum deflection of the girder, especially when using the CFSTT reinforcement method. The unique structural design improves the reinforcement effect of the material in the post-elastic stage. When using CFSTTs, increasing the steel tube wall strength significantly reduces the maximum deflection of the main girder. For example, using steel tubes with yield strengths of 235 MPa and 420 MPa filled with concrete of 50 MPa compressive strength reduced the maximum deflections by 15.32% and 24.55%, respectively, and improved the load distribution coefficients by up to 7.31% and 11.57%. Additionally, steel diaphragms demonstrated better reinforcement effects compared with concrete diaphragms. The load transverse distribution coefficients for the CFSTT-reinforced PCB bridge were calculated using the hinge plate (beam) and the rigid plate (beam) methods, showing minimal differences between the two approaches. The findings of this study provide valuable insights into the design of diaphragm and CFSTT reinforcement in PCB bridges, aiding in the selection of optimal reinforcement strategies. Full article

Against the backdrop of China’s continuous promotion of green and low-carbon transformation and the development of construction industrialization, high-strength composite structural systems have significant development prospects. However, their research and application in the field of construction are insufficient. In response to this issue, the study proposes a new high-performance structural system, namely the composite frame–high-strength steel plate wall core tube resilient structural system, which includes a core tube composed of double steel plate concrete composite shear walls and replaceable energy dissipation coupling beams, as well as composite frames. The highest strength grades of the steel plate and concrete used in the composite walls of the core tube are Q550 and C100, respectively. Using a 200 m building as an example, this study designs and establishes models for this high-performance structure and a conventional reinforced concrete frame–core tube structure. Subsequently, the dynamic elastoplastic time history analysis and seismic resilience assessment of structures are conducted under design basis earthquakes (DBEs), maximum considered earthquakes (MCEs), and extremely rare earthquakes (EREs). Research has shown that, compared to conventional structures, the thickness of shear walls of new high-performance structures can be effectively reduced, which helps decrease the self-weight of the structure and improve the available space in buildings. Additionally, high-performance structures exhibit a better performance in controlling the story drift ratio, lower plastic damage and overall stiffness degradation of the structure, and better seismic performance. The seismic resilience of the high-performance structure has been significantly enhanced, especially in terms of minimizing casualties, thereby better ensuring the safety of people’s lives and property. Full article

Steel Plate Shear Walls (SPSW) provide significant lateral load capacity and can be utilized in the seismic retrofit and upgrade of existing reinforced concrete (r/c) buildings. In this study, the application of SPSW to retrofit a r/c building designed according to older seismic provisions is presented. Three different options to model SPSW are utilized, i.e., by equivalent braces, by finite elements, and by membrane elements, seeking not only to appropriately simulate the actual behavior of the SPSW but also to achieve the desired seismic behavior of the retrofitted building. Specific seismic response indices, including plastic hinge formations, are derived by non-linear time-history analyses in order to assess the seismic behavior of the retrofitted r/c building. Inspection of the results provided by non-linear analyses in conjunction with the different modeling options of the SPSW leads to the conclusion that the model with the membrane elements exhibits the best performance, implying that for the seismic retrofit and upgrade of existing r/c buildings, the use of membrane elements to model the SPSW is recommended. Full article

In the Middle East, wall-like reinforced concrete (RC) columns are a common choice in multistory buildings. Sometimes, these columns need axial retrofitting for increased load capacity. In practice, unstrengthened columns bear their load, and if retrofitting is necessary, the load is released before the upgrade—unlike in past research studies that overlooked this real-world scenario. This study aimed to investigate the response of preloaded wall-like RC columns after being retrofitted using different configurations. In the experimental campaign, two half-scale columns were cast and axially loaded to 80% of their capacity, and the load was then totally released. After that, these specimens were strengthened with two different schemes, and hence, they were concentrically loaded until failure. In both schemes, the section shape was not modified. The first scheme comprised wrapping carbon FRP (fiber-reinforced polymer) sheets together with near-surface mounted (NSM) steel rebars. However, the second technique was composed of wrapping glass FRP (GFRP) sheets together with NSM steel rebars and bolted steel plates. The second scheme was found to be superior to the first one due to the extra confinement provided by the bolted steel plates. This scheme improved the peak load, stiffness, and dissipated energy by 115%, 75%, and 524%, respectively. Other than the testing campaign, nonlinear numerical modeling was undertaken to examine the behavior of tested specimens. The models were utilized to conduct a parametric study, exploring the influence of the percentage of preloading and the amount of load release on the response of columns strengthened with the second scheme. Full article

Coupled steel plate and reinforced concrete (SPRC) composite shear walls have been widely constructed in the core tube of super tall buildings in seismic regions. However, relevant research progress is far behind the practical application of this coupled composite wall system. Particularly, the current seismic design method does not consider the coupling mechanism and lacks efficiency in the computation of seismic base shear. In this research, the energy balance-based plastic design (EBPD) method is developed and used to design twelve prototype structures considering different structural heights and coupling ratios (CR). With the ABAQUS-based numerical techniques verified by relevant experimental results, all the prototype cases were studied by pushover analysis and nonlinear dynamic analysis to examine the effectiveness of the EBPD method in ensuring satisfactory seismic performance of coupled SPRC composite walls. The results indicate that the coupled SPRC composite walls designed by the EBPD method can satisfy the code requirements on lateral deformation under moderate and rare earthquakes. The analytical average story shear and bending moment distribution patterns have acceptable agreement with the relevant design assumptions. Favorable CR ranges are suggested for the coupled SPRC composite walls with different story numbers to achieve good earthquake-induced deformation characteristics. Full article

To study the seismic performance of self-centering circular-section rocking steel bridge piers whose functions can be restored after an earthquake, a high-precision finite element (FE) analysis model of such a bridge piers was established. The hysteresis behavior of concrete-infilled and hollow rocking steel bridge piers was compared. In response to the characteristics of the local deformation of the wall plates and elliptical deformation of the bottom surface, two reinforcement methods for the pier bottom, namely thickening the wall plate and adding longitudinal stiffeners in the plastic zone of the pier bottom, were proposed. The pseudo static analysis of bridge piers was carried out considering the effects of overall design parameters and reinforcement parameters of the pier bottom. The results indicate that the FE model used in this paper can obtain accurate horizontal load-displacement curves of rocking steel bridge piers. The hysteresis curves of the rocking steel bridge piers and infilled concrete rocking steel bridge piers is close, and directly using hollow steel bridge piers can improve the economic efficiency of the design. Compared to adding longitudinal stiffeners, the reinforcement form of thickened wall plates at the pier bottom has a better effect in improving the seismic performance of bridge piers. The reinforcement of the pier bottom has little effect on the energy dissipation capacity of the bridge pier, but it helps to reduce residual displacement and improve lateral stiffness. Full article

Although the anchorage location of longitudinal reinforcing bars is a significant design element for flexural behavior, the conventional anchorage method of using longitudinal reinforcing bars has limited applications in new types of structures, such as composite structures. Therefore, this study examined the effect of the anchorage location of longitudinal reinforcing bars on the flexural behavior of slabs at the junctions of developed composite basement walls (SCBW) under monotonic loads at the top free end of the slab. The test results showed that the slab with longitudinal reinforcing bars anchored to the cast-in-place pile (CIP) in the composite basement wall exhibited ductile behavior accompanied by the yielding of the longitudinal reinforcing bars, a relatively wide area of vertical cracks propagating along the slab length, and a plastic plateau flow in the load–deflection relationships. In particular, the slab with longitudinal reinforcing bars anchored to the basement wall experienced severe crack concentration localized at the junction of the composite basement walls and concrete spalling in the basement walls, which resulted in no yielding of the longitudinal reinforcing bars and no cracks in the slab. Consequently, in a slab, it is recommended that longitudinal reinforcing bars be anchored into the CIP by penetrating the steel plate. Full article

Reinforced concrete (RC) wall-like columns are commonly employed in structures in Saudi Arabia. These columns are preferred by architects owing to their minimum projection in the usable space. However, they often need strengthening due to several reasons, such as the addition of more stories and increasing the live load as a result of changing the usage of the building. This research aimed to obtain the best scheme for the axial strengthening of RC wall-like columns. The challenge in this research is to develop strengthening schemes for RC wall-like columns, which are favored by architects. Accordingly, these schemes were designed so that the dimensions of the column cross-section are not increased. In this regard, six wall-like columns were experimentally examined in the event of axial compression with zero eccentricity. Two specimens were not retrofitted to be used as control columns, whereas four specimens were retrofitted with four schemes. The first scheme incorporated traditional glass fiber-reinforced polymer (GFRP) wrapping, while the second one utilized GFRP wrapping combined with steel plates. The last two schemes involved the addition of near-surface mounted (NSM) steel bars combined with GFRP wrapping and steel plates. The strengthened specimens were compared with regard to axial stiffness, maximum load, and dissipated energy. Besides column testing, two analytical approaches were suggested for computing the axial capacity of tested columns. Moreover, finite element (FE) analysis was performed for evaluating the axial load versus displacement response of tested columns. As an outcome of the study, the best strengthening scheme was proposed to be used by practicing engineers for axial upgrading of wall-like columns. Full article
