Search Results (59)

Search Parameters:
Keywords = steady-state equivalent circuit

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
27 pages, 7892 KB
Article
Model of a Switched Reluctance Generator Considering Iron Losses, Mutual Coupling and Remanent Magnetism
by Šime Grbin, Dinko Vukadinović and Mateo Bašić
Energies 2025, 18(10), 2656; https://doi.org/10.3390/en18102656 - 21 May 2025
Viewed by 560
Abstract
In this paper, an advanced model of a switched reluctance generator (SRG) with mutual coupling, iron losses, and remanent magnetism is presented. The proposed equivalent circuit for each SRG phase is represented by the winding resistance, phase inductance and electromotive forces (EMFs) induced [...] Read more.
In this paper, an advanced model of a switched reluctance generator (SRG) with mutual coupling, iron losses, and remanent magnetism is presented. The proposed equivalent circuit for each SRG phase is represented by the winding resistance, phase inductance and electromotive forces (EMFs) induced by mutual flux-linkage and remanent magnetism. In the advanced SRG model, the phase inductance and equivalent iron-loss resistance need not be known, as the components of the phase current flowing through them are determined directly from appropriate look-up tables, making the advanced SRG model simpler. Both the magnitude of the mutual flux-linkage and its time derivative are considered in the advanced model. The proposed model only requires knowledge of data that can be obtained using the DC excitation method and does not require knowledge of the SRG material properties. For the first time, the remanent magnetic flux of the SRG is modeled and the induced EMS caused by it is included in the advanced SRG model. Stray losses within the SRG are considered negligible. Connection to an asymmetric bridge converter is assumed. Magnetization angles of individual SRG phases are provided by the terminal voltage controller. The results obtained with the advanced SRG model are compared with experiments carried out in the steady-state of the 8/6 SRG with a rated power of 1.1 kW SRG over a wide range of load, terminal voltage, turn-on angle, and rotor speed in single-pulse mode suitable for high-speed applications. Full article
Show Figures

Figure 1

24 pages, 4684 KB
Article
Identification, Control, and Characterization of Peristaltic Pumps in Hemodialysis Machines
by Cristian H. Sánchez-Saquín, Jorge A. Soto-Cajiga, Juan M. Barrera-Fernández, Alejandro Gómez-Hernández and Noé A. Rodríguez-Olivares
Appl. Syst. Innov. 2025, 8(2), 44; https://doi.org/10.3390/asi8020044 - 31 Mar 2025
Cited by 2 | Viewed by 2008
Abstract
Peristaltic pumps represent a fundamental component of hemodialysis machines. They facilitate the transfer of fluids, particularly in the collection and treatment of blood. This study aims to improve pump precision and reliability by reducing steady-state error and optimizing flow consistency, measured in milliliters [...] Read more.
Peristaltic pumps represent a fundamental component of hemodialysis machines. They facilitate the transfer of fluids, particularly in the collection and treatment of blood. This study aims to improve pump precision and reliability by reducing steady-state error and optimizing flow consistency, measured in milliliters per minute. A detailed characterization established the relationship between revolutions per minute (RPM) and flow rate (mL/min), with redundant mass and volume measurements supporting accuracy. To model the system’s behavior, two non-linear functions and one linear function were compared, with the polynomial model proving the most accurate and revealing the pump’s inherently non-linear flow behavior. A proportional–integral (PI) controller was then applied, and optimized through step input and non-linear least squares fitting. A key aspect of this study is a comparative validation against a commercial hemodialysis machine, configured identically with the same blood circuit diameter, tubing brand, and filter, in order to ensure equivalency in conditions. Results showed a maximum flow rate error of 0.5296%, highlighting the integration of control and characterization methods that enhance system precision, dependability, and reproducibility—critical factors for ensuring the safety and effectiveness of hemodialysis treatments. Full article
Show Figures

Figure 1

13 pages, 5237 KB
Article
A Control-Oriented Model for Polymer-Dispersed Liquid Crystal Films as an Actuator for Natural Light Control
by Alexander H. Pesch and Chiara Vetter
Actuators 2025, 14(4), 167; https://doi.org/10.3390/act14040167 - 28 Mar 2025
Cited by 1 | Viewed by 1331
Abstract
A polymer-dispersed liquid crystal (PDLC) film is a device that can transition from opaque to transparent when electrically charged. These films can be used as actuators to control light levels in response to changing natural light. However, the current state of the art [...] Read more.
A polymer-dispersed liquid crystal (PDLC) film is a device that can transition from opaque to transparent when electrically charged. These films can be used as actuators to control light levels in response to changing natural light. However, the current state of the art for controlling PDLC films is limited to on/off functionality, and few works in the current body of literature have explored continuous control. This study develops a novel nonlinear model for PDLCs in the context of the feedback control of light. This study also demonstrates the model’s utility by comparing experimental data of a PDLC in feedback with a proportional–integral (PI) controller for disturbance rejection and tracking of a desired light setpoint. This development is motivated by the need for a smart greenhouse that can provide programmable optimized light levels for plant growth. Specifically, a light sensor is composed of a circuit with photodiodes and calibrated for the photosynthetically active radiation range. The light sensor is placed under the film, separate from an exogenous light source, allowing for feedback control to be applied. A proportional–integral type control law is selected for stiffness and the ability to eliminate steady-state error, and it is implemented using a microcontroller. An equivalent analog control effort is applied to the PDLC via a PWM voltage signal and an H-bridge type driver. Details necessary for the driving of the PDLC are presented. Open-loop identification of the nonlinear quasi-static and dynamic step-response transients of the PDLC at different control levels are presented and modeled. Finally, closed-loop experimental and simulated results are presented for both light disturbance rejection and setpoint tracking. This shows that the proposed control framework allows for continuous control of light. Full article
(This article belongs to the Section Control Systems)
Show Figures

Figure 1

22 pages, 2696 KB
Article
Benchmarking a Single-Stage REFLUX Flotation Cell Against a Multi-Stage Industrial Copper Concentrator and Lab-Scale Mechanical Cell
by Siân Parkes, Peipei Wang and Kevin P. Galvin
Minerals 2025, 15(3), 266; https://doi.org/10.3390/min15030266 - 3 Mar 2025
Cited by 1 | Viewed by 1525
Abstract
A low-grade copper ore from an Australian mine was processed under continuous steady state conditions using the REFLUX Flotation Cell (RFC), and the performance was quantified with reference to a batch mechanical cell and the plant circuit, at the plant [...] Read more.
A low-grade copper ore from an Australian mine was processed under continuous steady state conditions using the REFLUX Flotation Cell (RFC), and the performance was quantified with reference to a batch mechanical cell and the plant circuit, at the plant feed concentration. In the RFC, the variation in the copper grade and the recovery were determined using feed fluxes ranging from 0.5 to 3.0 cm/s, with a strong positive bias flux to achieve cleaning. The RFC experiments showed an increasing product grade with increasing feed flux, increasing to 23% copper in a single stage. The result exceeded the grade of 14% produced by a laboratory-scale, two-stage mechanical cell and was comparable to the multi-stage plant circuit. The RFC recoveries increased with increasing feed flux, peaking at 81.7% for a feed flux of 2.0 cm/s before declining. Moreover, for equivalent copper recovery, the laboratory-scale RFC throughput performance was more than five times higher than for the rougher circuit of the industrial plant. It is noted the RFC product grade was nearly three times higher than for the rougher cells. For similar recoveries and product grades, the RFC throughput was about eight times higher than that observed for the rougher and cleaner circuits of the industrial plant. This work demonstrates the potential for the process footprint to be significantly minimised. Full article
(This article belongs to the Section Mineral Processing and Extractive Metallurgy)
Show Figures

Figure 1

22 pages, 2571 KB
Article
Numerical Analysis of Steady-State Multi-Field Coupling in Electro-Fused Magnesia Furnace
by Cunjian Weng, Zhen Wang, Xianping Luo and Hui Li
Materials 2025, 18(5), 1049; https://doi.org/10.3390/ma18051049 - 27 Feb 2025
Viewed by 891
Abstract
The internal conditions of the high-temperature molten pool in an electro-fused magnesia furnace (EFMF) are difficult to measure, and the temperature distribution–energy conservation relationship in the EFMF cannot be effectively evaluated. Assuming that the feeding speed is constant, the heat absorbed by the [...] Read more.
The internal conditions of the high-temperature molten pool in an electro-fused magnesia furnace (EFMF) are difficult to measure, and the temperature distribution–energy conservation relationship in the EFMF cannot be effectively evaluated. Assuming that the feeding speed is constant, the heat absorbed by the newly added raw materials is equal to the rated power minus the heating power required to maintain thermal balance. Therefore, the EFMF can be approximately described by a steady-state model. In order to analyze the state of the molten pool of EFMF at different smelting stages, this study first constructed a three-dimensional steady-state multi-physics field numerical simulation model. The calculations show that the equivalent resistance of the molten pool varies approximately between 1 mΩ and 0.4 mΩ. Furthermore, the equivalent reactance produced by the whole conductive circuit is almost of the same order as the resistance. The Reynolds number of the convection inside the molten pool exceeds 105, which means that the flow inside the molten pool is forced convection dominated by the Lorentz force. Moreover, the turbulence makes the temperature uniformity of the molten pool (the temperature gradient near the solid–liquid interface is approximately within 300 K/m) far greater than that of the unmelted raw materials with very low thermal conductivity (the average temperature gradient reaches over 1000 K/m); the respective proportions of arc power and Joule heating power can be predicted by the model. When the molten pool size is small, the proportion of Joule heating power is high, reaching about 20% of the rated power (3700 kVA); as the molten pool size increases, the convection effect is relatively weakened, and the proportion of Joule heating power also decreases accordingly, only 5% to 10%; the model prediction and experimental estimation results are in good agreement, which makes it feasible to conduct a quantitative analysis of the power distribution in different smelting stages. Full article
Show Figures

Figure 1

19 pages, 3971 KB
Article
An Extra-High Voltage Test System for Transmission Expansion Planning Studies Considering Single Contingency Conditions
by Bhuban Dhamala and Mona Ghassemi
Electronics 2024, 13(19), 3937; https://doi.org/10.3390/electronics13193937 - 5 Oct 2024
Cited by 7 | Viewed by 1625
Abstract
This paper presents an extra-high voltage synthetic test system that consists of 500 kV and 765 kV voltage levels, specifically designed for transmission expansion planning (TEP) studies. The test network includes long transmission lines whose series impedance and shunt admittance are calculated using [...] Read more.
This paper presents an extra-high voltage synthetic test system that consists of 500 kV and 765 kV voltage levels, specifically designed for transmission expansion planning (TEP) studies. The test network includes long transmission lines whose series impedance and shunt admittance are calculated using the equivalent π circuit model, accurately reflecting the distributed nature of the line parameters. The proposed test system offers technically feasible steady-state operation under normal and all single contingency conditions. By incorporating accurate modeling for long transmission lines and EHV voltage levels, the test system provides a realistic platform for validating models and theories prior to their application in actual power systems. It supports testing new algorithms, control strategies, and grid management techniques, aids in transmission expansion planning and investment decisions, and facilitates comprehensive grid evaluations. Moreover, a TEP study is conducted on this test system and various scenarios are evaluated and compared economically. Full article
(This article belongs to the Special Issue Monitoring and Analysis for Smart Grids)
Show Figures

Figure 1

17 pages, 3926 KB
Article
Design and Optimization of Thermal Vacuum Sensor Test System Based on Thermoelectric Cooling
by Xiaohang Shan, Min Zhao and Gang Li
Appl. Sci. 2024, 14(14), 6144; https://doi.org/10.3390/app14146144 - 15 Jul 2024
Viewed by 1806
Abstract
The performance of critical components in a sensor testing system may be compromised in a thermal vacuum environment as a result of the impact of extreme temperatures. Moreover, the precision of the angle measurement may be influenced by the thermal deformation effect. This [...] Read more.
The performance of critical components in a sensor testing system may be compromised in a thermal vacuum environment as a result of the impact of extreme temperatures. Moreover, the precision of the angle measurement may be influenced by the thermal deformation effect. This paper presents a simulated analysis of the temperature regulation impact of the thermoelectric cooler (TEC) and outlines the design and optimization process of a sensor test chamber that can function within a consistent temperature range. The mathematical model of TEC is utilized to suggest a design choice, taking into account the aforementioned model, in a temperature-controlled environment with thermal vacuum circumstances. Moreover, the orthogonal test method is employed in combination with the FloEFD finite element analysis to validate the effectiveness of temperature control. In addition, the parameters of the radiation radiator are tuned and designed. Therefore, the temperature range difference inside the test system decreased by 20%. The thermoelectric temperature control system’s steady-state model is investigated using the PSpice simulation, based on the equivalent circuit theory. The discovered conclusions establish a theoretical foundation for improving the efficiency of temperature regulation. The design concepts presented in this work, particularly the optimization technique for radiation radiators in aerospace test equipment using thermoelectric cooling temperature control research and development, hold promise for practical implementation. Full article
(This article belongs to the Section Applied Thermal Engineering)
Show Figures

Figure 1

20 pages, 9150 KB
Article
Propagation Mechanism and Suppression Strategy of DC Faults in AC/DC Hybrid Microgrid
by Chun Xiao, Yulu Ren, Qiong Cao, Ruifen Cheng and Lei Wang
Processes 2024, 12(5), 1013; https://doi.org/10.3390/pr12051013 - 16 May 2024
Cited by 3 | Viewed by 1256
Abstract
Due to their efficient renewable energy consumption performance, AC/DC hybrid microgrids have become an important development form for future power grids. However, the fault response will be more complex due to the interconnected structure of AC/DC hybrid microgrids, which may have a serious [...] Read more.
Due to their efficient renewable energy consumption performance, AC/DC hybrid microgrids have become an important development form for future power grids. However, the fault response will be more complex due to the interconnected structure of AC/DC hybrid microgrids, which may have a serious influence on the safe operation of the system. Based on an AC/DC hybrid microgrid with an integrated bidirectional power converter, research on the interaction impact of faults was carried out with the purpose of enhancing the safe operation capability of the microgrid. The typical fault types of the DC sub-grid were selected to analyze the transient processes of fault circuits. Then, AC current expressions under the consideration of system interconnection structure were derived and, on this basis, we obtained the response results of non-fault subnets under the fault process, in order to reveal the mechanism of DC fault propagation. Subsequently, a current limitation control strategy based on virtual impedance control is proposed to address the rapid increase in the DC fault current. On the basis of constant DC voltage control in AC/DC hybrid microgrids, a virtual impedance control link was added. The proposed control strategy only needs to activate the control based on the change rate of the DC current, without additional fault detection systems. During normal operations, virtual impedance has a relatively small impact on the steady-state characteristics of the system. In the case of a fault, the virtual impedance resistance value is automatically adjusted to limit the change rate and amplitude of the fault current. Finally, a DC fault model of the AC/DC hybrid microgrid was built on the RTDS platform. The simulation and experimental results show that the control strategy proposed in this paper can reduce the instantaneous change rate of the fault state current from 19.1 kA/s to 2.73 kA/s, and the error between the calculated results of equivalent modeling and simulation results was within 5%. The obtained results verify the accuracy of the mathematical equivalent model and the effectiveness of the proposed current limitation control strategy. Full article
(This article belongs to the Section Energy Systems)
Show Figures

Figure 1

20 pages, 7536 KB
Article
Fault-Tolerant Multiport Converter for Hybrid Distribution Systems: Configuration, Control Principles and Fault Analysis
by Simone Negri, Giovanni Ubezio and Roberto Sebastiano Faranda
Appl. Sci. 2024, 14(10), 4024; https://doi.org/10.3390/app14104024 - 9 May 2024
Cited by 3 | Viewed by 1672
Abstract
Multiport converters (MCs) are widely adopted in many applications, from renewable energy sources and storage integration to automotive applications and distribution systems. They are used in order to interface different energy sources, storage devices and loads with one single, simple converter topology in [...] Read more.
Multiport converters (MCs) are widely adopted in many applications, from renewable energy sources and storage integration to automotive applications and distribution systems. They are used in order to interface different energy sources, storage devices and loads with one single, simple converter topology in contrast to the traditional approach, which can require different solutions made by two-port converters. MCs allow for a reduction in the number of components and cascaded conversion stages with respect to an equivalent system of two-port converters, resulting in reduced complexity, dimensions and costs, as well as in improved reliability and enhanced efficiency. Nevertheless, some aspects related to the design of MCs are still worth further discussion when MCs are applied to hybrid AC/DC distribution systems. First, most converters are developed for one specific application and are not modular in structure. Furthermore, many of the proposed solutions are not equally suitable for AC and DC applications and they can introduce significant issues in hybrid distribution systems, with earthing management being particularly critical. Even though most available solutions offer satisfying steady-state and dynamic performances, fault behavior is often not considered and the possibility of maintaining controllability during faults is overlooked. Building on these three aspects, in this paper, a new MC for hybrid distribution systems is presented. An innovative circuit topology integrating three-phase AC ports and three-wire DC ports and characterized by a unique connection between the AC neutral wire and the DC midpoint neutral wire is presented. Its control principles and properties during external faults are highlighted, and extensive numerical simulations support the presented discussion. Full article
Show Figures

Figure 1

15 pages, 4310 KB
Article
Study of Resistance Extraction Methods for Proton Exchange Membrane Fuel Cells Based on Static Resistance Correction
by Yuzheng Mao, Yongping Hou, Rongxin Gu, Dong Hao and Qirui Yang
World Electr. Veh. J. 2024, 15(5), 179; https://doi.org/10.3390/wevj15050179 - 24 Apr 2024
Viewed by 2183
Abstract
Accurate extraction of polarization resistance is crucial in the application of proton exchange membrane fuel cells. It is generally assumed that the steady-state resistance obtained from the polarization curve model is equivalent to the AC impedance obtained from the electrochemical impedance spectroscopy (EIS) [...] Read more.
Accurate extraction of polarization resistance is crucial in the application of proton exchange membrane fuel cells. It is generally assumed that the steady-state resistance obtained from the polarization curve model is equivalent to the AC impedance obtained from the electrochemical impedance spectroscopy (EIS) when the frequency approaches zero. However, due to the low-frequency stability and nonlinearity issues of the EIS method, this dynamic process leads to an additional rise in polarization resistance compared to the steady-state method. In this paper, a semi-empirical model and equivalent circuit models are developed to extract the steady-state and dynamic polarization resistances, respectively, while a static internal resistance correction method is proposed to represent the systematic error between the two. With the correction, the root mean square error of the steady-state resistance relative to the dynamic polarization resistance decreases from 26.12% to 7.42%, indicating that the weighted sum of the static internal resistance and the steady-state resistance can better correspond to the dynamic polarization resistance. The correction method can also simplify the EIS procedure by directly generating an estimate of the dynamic polarization resistance in the full current interval. Full article
Show Figures

Figure 1

19 pages, 4333 KB
Article
Characteristics and Parameters of a Three-Phase, Three-Wire Balanced Circuit with Non-Linear Load
by Miroslaw Wcislik, Robert Kazala and Pawel Strzabala
Energies 2024, 17(8), 1867; https://doi.org/10.3390/en17081867 - 13 Apr 2024
Viewed by 1673
Abstract
The existing non-linear load in a three-phase circuit limits the possibilities of using the symmetrical components method to analyse it. This paper presents a method for analysing such a circuit when only the zero and positive components are present. Nonlinear loading in a [...] Read more.
The existing non-linear load in a three-phase circuit limits the possibilities of using the symmetrical components method to analyse it. This paper presents a method for analysing such a circuit when only the zero and positive components are present. Nonlinear loading in a circuit limits the applicability of the symmetrical components method in the analysis of a three-phase circuit. When there is only a zero component and a positive component, it is possible to carry out the analysis as presented in this article. The analysed circuit is balanced. An equal nonlinear load with a voltage described by a signum function of the current is considered in three phases. This load, through equal series RL elements, is supplied from a symmetrical three-phase voltage source. For a steady state with unbroken current flows, the equations of the circuit are solved symbolically. In the broader scope of the equation, solutions obtained using MATLAB-Simulink R2021b were used. The matching of the symbolic and simulation solutions was obtained. The current and voltage harmonic content coefficients of the receiver, the equivalent resistance and inductance of the nonlinear load, and the distribution of active and reactive power in the circuit were determined. The reactive power analysis shows that the considered load nonlinearity when generating higher harmonics, increases the reactive power of the circuit and the inductance of the circuit, which is seen from the terminals of the power source. Full article
(This article belongs to the Special Issue Power Electronics and Battery Management Systems)
Show Figures

Figure 1

12 pages, 2990 KB
Article
Temperature Field Calculation and Thermal Circuit Equivalent Analysis of 110 kV Core Cable Joint
by Zhiqiang Zhang, Xiaolong Deng, Lili Liang, Xuezong Wang, Yu Chen and Jiangjun Ruan
Processes 2024, 12(3), 463; https://doi.org/10.3390/pr12030463 - 24 Feb 2024
Cited by 2 | Viewed by 1871
Abstract
In order to indirectly calculate the core temperature of a cable joint, an equivalent transient thermal circuit model of single-core cable joint by considering axial heat dissipation is proposed. Firstly, the temperature field of the middle joint of a 110 kV single-core cable [...] Read more.
In order to indirectly calculate the core temperature of a cable joint, an equivalent transient thermal circuit model of single-core cable joint by considering axial heat dissipation is proposed. Firstly, the temperature field of the middle joint of a 110 kV single-core cable is calculated by finite element method. Based on the heat dissipation path of the core, an improved equivalent thermal circuit model is proposed. The axial heat dissipation of the cable joint core is simplified to a thermal resistance and the temperature rise of the cable body core, the temperature calculation of the cable joint transient process is realized. Compared with the results of finite element simulation, the steady-state temperature errors of the thermal circuit model are within 1 °C, while the maximum temperature errors of the transient process shall not exceed 3 °C, which proves the validity of the model. This method can provide reference for temperature inversion and the dynamic current-carrying capacity prediction of cable joints. Full article
Show Figures

Figure 1

18 pages, 2804 KB
Article
Efficiency Improvement of Permanent Magnet Synchronous Motors Using Model Predictive Control Considering Core Loss
by Lian Hou, Youguang Guo, Xin Ba, Gang Lei and Jianguo Zhu
Energies 2024, 17(4), 773; https://doi.org/10.3390/en17040773 - 6 Feb 2024
Cited by 11 | Viewed by 3415
Abstract
The highway cycle is an important consideration in the EV’s new European driving cycles (NEDCs) range, as the steady-state efficiency improvement in such conditions can be greatly beneficial. In the model predictive control (MPC) of the permanent magnet synchronous motors (PMSMs), the predicted [...] Read more.
The highway cycle is an important consideration in the EV’s new European driving cycles (NEDCs) range, as the steady-state efficiency improvement in such conditions can be greatly beneficial. In the model predictive control (MPC) of the permanent magnet synchronous motors (PMSMs), the predicted next-step feedback reference generated by the equivalent circuit model (ECM) will contribute directly to the voltage vector selection, therefore influencing the performance of the motor control. In the current MPC scheme, when the conventional ECM is applied, it only considers copper loss, and the core loss is usually disregarded. In some circumstances, such as the highway cycle of EVs, the motors are at high speed, the torque is low, and the core loss can be significant in the losses, thus affecting the accuracy of control and the efficiency of the system; hence, the introduction of core loss ECM into the MPC would be beneficial. This paper aims to investigate the steady-state efficiency improvement of a novel ECM of PMSM considering core loss ECM, and the comparison will be based on model predictive direct torque control (MPDTC) using the core loss ECM, which will be compared to MPDTC with the conventional ECM of the PMSM. The results demonstrate the proposed ECM’s efficiency improvement in various conditions, the limitations of the model and the simulation are discussed, and future work is proposed. Full article
(This article belongs to the Special Issue Energy Management and Optimization for New Power Systems)
Show Figures

Figure 1

33 pages, 22386 KB
Article
Finite Element Analysis of Different Transverse Flux Linear Induction Motor Models to Improve the Performance of the Main Magnetic Circuit
by Juan Antonio Domínguez, Natividad Duro and Elena Gaudioso
Machines 2024, 12(2), 89; https://doi.org/10.3390/machines12020089 - 24 Jan 2024
Cited by 1 | Viewed by 1921
Abstract
This paper delves into the knowledge of transverse flux linear induction motors using three-dimensional finite element simulation tools. Original linear induction motors have a useful magnetic flux perpendicular to the movement. We propose some geometric changes to improve the main magnetic circuit of [...] Read more.
This paper delves into the knowledge of transverse flux linear induction motors using three-dimensional finite element simulation tools. Original linear induction motors have a useful magnetic flux perpendicular to the movement. We propose some geometric changes to improve the main magnetic circuit of the machine and to ensure simultaneous operation between longitudinal and transverse magnetic fluxes. To obtain the main parameters of the equivalent electrical circuit in a steady state, we propose two steps. Firstly, replicate the classic indirect tests used in rotating machines. This represents a significant advantage since it allows several models to be experimentally tested to obtain the values of electrical parameters. Secondly, use the data from these tests to solve a particular system of equations using numerical methods. The solution provides the electrical elements necessary to generate the equivalent circuit proposed by the authors. A quantitative analysis of the main electrical parameters is also carried out, confirming the advantages of the changes introduced. With them, a significant improvement in thrust force is obtained, especially in stationary conditions and low speeds. Finally, we study, in detail, a set of specific phenomena of linear machines using two parameters: the secondary equivalent air gap and the secondary equivalent conductivity. Full article
Show Figures

Figure 1

15 pages, 3237 KB
Article
Research on Dynamic and Thermal Effects Based on the Calculation of the Short-Circuit Current in Low-Voltage DC Distribution Systems for Civil Buildings
by Qiang Wei, Gaojun Ni, Jianhua Feng and Hao Ma
Appl. Sci. 2023, 13(20), 11543; https://doi.org/10.3390/app132011543 - 21 Oct 2023
Viewed by 2177
Abstract
The verification of short-circuit effects is very important for ensuring the safety of equipment and power systems. Compared with that in alternating current (AC) systems, research on this issue in direct current (DC) systems is scarce, and it is urgently necessary to develop [...] Read more.
The verification of short-circuit effects is very important for ensuring the safety of equipment and power systems. Compared with that in alternating current (AC) systems, research on this issue in direct current (DC) systems is scarce, and it is urgently necessary to develop an accurate verification method for applications in DC systems. This research establishes an equivalent model of a pole–pole cable short-circuit according to the characteristics of low-voltage DC distribution systems in civil buildings. Through theoretical analysis and numerical simulation, the development process of a short circuit is summarized, and the methods of verifying dynamic and thermal effects based on the time-domain characteristics of the short-circuit current are specified. By calculating the peak value and Joule integral of the short-circuit current, in comparison with those in the IEC 61660 (1997) standard, this research points out that the method in the IEC 61660 (1997) standard is insufficient. Finally, the short-circuit peak current is greatly affected by the DC-link capacitance, the steady-state current is directly related to the filter inductance of the AC-link; and the verification of the thermal effect requires the calculation of the Joule integral in the transient and steady state. Full article
(This article belongs to the Special Issue Electric Power Applications II)
Show Figures

Figure 1
