Rotatory electric motors provide low efficiency in the case of linear motion. The reason for this is the mechanical conversion system required to convert rotary torque to linear thrust force. In this paper, two novel linear machines i.e., a Dual-Mover Segmented Secondary Hybrid Excited Linear Flux Switching Machine (DMSSHELFSM) and Dual-Stator Segmented Secondary Hybrid Excited Linear Flux Switching Machine (DSSSHELFSM), were investigated and compared for a ropeless vertical elevator system. The novelties of these designs include both series and parallel magnetic circuits, a complementary AC coil structure, and their unequal primary tooth width. Results reveal that the DSSSHELFSM exhibits better performance with higher and more sinusoidal flux linkage, higher thrust force, and a robust mechanical structure. Secondly, the selected linear motor was optimized using a deterministic optimization approach. An average thrust force of 10kN and a thrust force ripple ratio of less than 10% were considered as performance constraints during the optimization process. Finally, full-scale no-load experimental results were obtained, and they validated the research. Full article

In order to simplify the stator winding structure of traditional variable reluctance (VR) resolvers and enhance their performance under high-speed operating conditions, this paper proposes a design for a variable reluctance self-coupling resolver based on ultrahigh-frequency (UHF) square wave excitation. The proposed solution optimizes the traditional winding structure by eliminating the separate excitation winding and integrating both excitation and detection functions into the two-phase sine and cosine windings. By optimizing the arrangement of the sine and cosine windings, a single-layer equal-turn winding design is successfully implemented, significantly simplifying the winding layout and reducing copper usage. In terms of excitation signal, this paper innovatively replaces the traditional sinusoidal excitation with UHF square wave excitation. Compared to sinusoidal excitation, square wave excitation not only generates higher electromotive force (EMF) peaks but also simplifies engineering implementation, reducing the complexity of system hardware. To validate the feasibility and advantages of the proposed structure, a complete experimental testing platform was built, and comparative experiments were conducted under various rotational speeds. The experimental results show that the proposed self-coupling resolver can achieve high-precision rotor position detection across the entire speed range, significantly improving the detection accuracy and dynamic response of traditional methods under high-speed conditions. Ultimately, the design demonstrates strong engineering application potential and provides a new solution for high-precision, high-dynamic response rotor position detection. Full article

To establish the complex functional relationship between the stator bar end structure and the maximum electric field strength, and to optimize the anti-corona structure, an optimization model for the stator bar end based on the Seahorse Optimization algorithm—Radial Basis Function (SHO-RBF) neural network is proposed in this paper. The RBF neural network is employed to establish the complex relationship between the maximum electric field strength at the stator bar end and the anti-corona structure parameters. The SHO is introduced to find the optimal anti-corona structure at the stator bar end structure. A simulation model of the stator bar end is developed, and 30 sets of simulation data are collected for training and optimization purposes. The relationship between the stator bar end structure and the maximum electric field strength is established, and an optimized scheme comprising six groups of anti-corona structures is developed. The feasibility of the proposed design is validated through simulation calculations. Compared to manually adjusting parameters individually within the simulation model, this approach offers a significant advantage in terms of computational efficiency and speed. Full article

Double stator cylindrical linear oscillating generators (DSCLOGs) have been widely used in renewable energy power generation systems due to their higher power density, higher reliability, and low-noise characteristics. However, the detent force of a DSCLOG is an inevitable problem, which causes oscillations in the generator and leads to system instability. Conventionally, auxiliary teeth and skewed pole methods are employed to mitigate detent force, but these approaches often increase the overall machine size and the complexity of the manufacturing process. To solve this issue, an improved DSCLOG with curved teeth (CT-DSCLOG) is proposed to minimize the detent force. First, the structural characteristics and working principle of CT-DSCLOG are introduced. Then, to achieve a rapid and accurate analysis of the magnetic field in the irregular air gap, a 2D magnetic equivalent circuit (MEC) model is established by introducing Schwarz–Christoffel (S-C) mapping. And key structural parameters are identified through variance sensitivity analysis. Subsequently, a multi-objective optimization of the linear generator is performed using the Taguchi method combined with 3D finite element analysis (3D-FEA) to obtain the optimal structural parameters of CT-DSCLOG. Finally, the proposed structure is validated through prototype experiments. The results are provided to validate the effectiveness of the proposed structure. Full article

The hyperloop transportation system is a promising ultra-high-speed mobility solution operating in a reduced-pressure environment, where pod performance is governed by the coupled behaviour of structural integrity, aerodynamics, and electromagnetic propulsion. This paper presents the design, numerical analysis, and performance evaluation of a lightweight hyperloop pod equipped with a linear induction motor (LIM)-based propulsion and electromagnetic stabilisation system. The pod chassis was fabricated using Carbon Fibre-Reinforced Polymer (CFRP) and Aluminium 6061-T6, achieving a significant weight reduction while maintaining structural safety. Finite Element Analysis reveals a maximum von Mises stress of 82 MPa, which is well below the material yield strength, and a maximum deformation of 0.64 mm under worst-case loading conditions. Modal analysis indicates the first natural frequency at 47.6 Hz, ensuring sufficient separation from operational excitation frequencies. Computational Fluid Dynamics analysis conducted inside a rectangular tube shows a drag coefficient reduction of approximately 18% compared to a baseline blunt design, with stable velocity distribution and no flow choking at operating speeds. The optimised nose geometry enables rapid acceleration, achieving 25 km/h within 1.1 s in prototype testing. The LIM analysis demonstrates a peak thrust of 1.85 kN at an optimal slip range of 6–8%, with operating currents between 35 and 55A and power consumption of 18–25 kW. Thermal analysis confirms a maximum stator temperature of 78 °C, remaining within safe operating limits. The integrated numerical and experimental results confirm the feasibility, efficiency, and stability of the proposed hyperloop pod design. Full article

We investigated stator–rotor structure optimization for a commercial electric scooter motor through geometric modeling and comparative analysis of various magnet configurations and arrangements. We improved magnetic circuit distribution to enhance output performance, efficiency, and overall motor characteristics. Sensitivity analysis was conducted to identify the dominant design parameters. Magnetic bridges were then incorporated on both outer sides of the rotor magnets to increase magnetic flux density and reduce leakage flux. The Taguchi method was applied to determine the optimal parameter set. Comparative simulations between the optimized and baseline commercial motor revealed that, at a rated current of 87 A and rated voltage of 96 V, the optimized design achieved an efficiency improvement from 89.14 to 90.28% (+1.28%), a torque increase from 22.84 to 23.29 N·m (+0.45 N·m), and a power output enhancement from 7104.78 to 8053.44 W (+948.65 W). The results confirm that the proposed rotor design yields superior performance across efficiency, torque, and power output compared with the commercial reference motor. Full article

As the electrification of the automotive industry accelerates, the importance of small-scale motors used in applications such as HVAC systems and water pumps is growing. To design small motors that exhibit high efficiency and high output within limited spaces, applying axial flux motors (AFMs) instead of conventional radial flux motors (RFMs) can maximize the power density within the same volume, offering advantages in both weight reduction and miniaturization. This study proposes an optimized end-turn layout design to mitigate back-EMF imbalance in AFMs utilizing PCB stators. Optimization results demonstrated that the structure employing a non-adjacent end-turn layout with equalized average end-turn heights (BCAACB type) exhibited the best performance in terms of average resistance and phase resistance variance, effectively mitigating back-EMF imbalance. The validity of the optimized end-turn structure was verified through finite element analysis (FEA). The analysis confirmed that the motor’s back-EMF balance was improved, and the magnitude of phase resistance was reduced. This reduction led to lower copper loss, thereby increasing overall efficiency. Furthermore, the variance in resistance for each phase was minimized, resulting in enhanced electrical balance. The results of this study are expected to contribute to enhancing the applicability of PCB stators in small motor design. Full article

This paper presents a novel integrated gear drive unit (IGDU), which integrates a high torque density flux-focusing magnetic gear with a V-shaped interior permanent magnet (IPM) motor into a compact structure. The proposed configuration enables direct torque amplification and efficient low-speed, high-torque operation, addressing the inherent torque limitations of conventional electric motors. Critical design parameters, including pole-pair selection, modulation ring dimensions, and stator slot openings, are optimized to enhance torque performance and minimize cogging torque. Finite element analysis (FEA) verifies a maximum torque output of 43.7 Nm. A prototype of the proposed IGDU was fabricated, and experimental validation confirms the effectiveness of the design, with a good match between the measured back-EMF and the simulated one. The results highlight the potential of the proposed machine for compact, high-performance applications such as electric vehicles and industrial drives. Full article

High-speed miniature rotary actuators are critical components in compact, high-performance systems. However, conventional electromagnetic micromotors face a prominent trade-off between miniaturization and output performance, which restricts their applicability in highly integrated devices. To address this challenge, a novel high-speed rotary piezoelectric ultrasonic motor is proposed. The proposed motor consists of a titanium alloy metal body with offset driving teeth, piezoelectric ceramic plates, two conical rotors, a compression spring, an output shaft, and a fastening sleeve. Four PZT-8 plates are bonded to the periphery of the metal body and excited to generate in-plane bending vibration modes; these vibrations are then transformed into unidirectional rotary motion through the periodic contraction and expansion of the offset driving teeth and frictional contact with the rotors. The operating principle and structural parameters of the proposed motor were analyzed and optimized using finite element analysis (FEA), including modal, harmonic response, and transient analyses. A prototype was fabricated to evaluate its mechanical properties. The stator has a compact size of 12 mm × 12 mm × 4 mm and a mass of 2.3 g. Experimental results demonstrate that under an excitation voltage of 350 V_p-p at the resonant frequency of 28.6 kHz, the motor achieves a maximum rotational speed of 4720 rpm and a maximum stall torque of 0.36 mN·m. With its simple structure, compact size, lightweight design, and excellent output performance, the proposed ultrasonic motor provides a solution for compact high-speed rotary actuation. Full article

Shaftless Pump-jet Thrusters (SPTs), which integrate the propulsion motor directly with impellers, provide a compact design and high propulsion efficiency. Despite this, their performance is significantly hampered by eddy current losses in conductive stator sleeves. This study introduces Titanium Matrix Composites (TMC) as superior alternatives to conventional titanium alloys (Ti-6Al-4V, Ti64), leveraging their tailorable anisotropic electromagnetic properties to effectively suppress eddy current losses. Through simulations and experimental validation, the electromagnetic performance of an SPT equipped with a TMC stator sleeve is systematically investigated. Electromagnetic simulations predict a dramatic reduction in eddy current loss of 53.5–79.8% and an improvement in motor efficiency of 5.8–8.5% across the 1500–2900 rpm operational range compared to the Ti64 baseline. Experimental measurements on prototype motors confirm the performance advantage, demonstrating a 3.5–5.7% reduction in input power under equivalent output conditions across the same speed range. After accounting for manufacturing tolerances and control strategies, the refined model demonstrated a markedly improved agreement with the experimental results. This research conclusively establishes TMCs as a high-performance containment sleeve material, which is promising not only for SPTs but also for a broad range of canned motor applications, where an optimal balance between electromagnetic and structural performance is critical. Full article

One of the most critical challenges in gas turbine design is preventing the ingestion of hot mainstream gases into the disk space between the stator and rotor disks. Rim seals and superposed sealant flows are commonly used to mitigate the risk of component overheating. However, leakage paths inevitably form between the mating interfaces of adjacent components due to the complex architecture of the engine. Therefore, the interaction between the different flows present within the disk space complicates the accurate determination of the optimal sealing flow quantity. For this reason, this study experimentally investigates fluid dynamics inside a stator–rotor cavity, with a particular focus on leakage flows. In particular, this work examines the impact of multiple parameters, including injection radius position, number of leakage holes, and injection angle, on the sealing effectiveness values measured on the stator side of the cavity through CO₂ gas sampling measurements. By comparing the effectiveness values with the swirl measurements derived from static and total pressure readings, the development of flow structures and the impact of leakage injection on sealing performance were finally evaluated. The results indicate that leakage injection has a minimal effect on the sealing effectiveness above the injection point, but significantly improves the performance at a lower radius. Moreover, it was observed that for a given mass flow rate, using a lower number of holes results in worse sealing performance due to a higher jet momentum, which causes the leakage flow to penetrate through the cavity toward the rotor side. In the end, employing two distinct injection angles—both aligned with the rotor’s direction of rotation—showed no substantial impact on sealing effectiveness. Full article

To solve slot temperature accumulation in high thrust density permanent magnet linear synchronous motors (PMLSMs), this paper proposes an additive manufacturing (AM)-based variable cross-section winding design for coating-cooled tapered PMLSMs. Integrating the magnetic circuit features of tapered PMLSMs and AM windings’ technical merits, the motor’s operating mechanism and electromagnetic distribution are analyzed. With the coating cooling structure as the thermal management foundation, simulation reveals the motor’s temperature distribution under water cooling, defining core slot thermal management requirements. A novel cross-section winding design is then presented: first, a lumped-parameter thermal network model quantifies the coupling between the winding cross-sectional area and slot heat source distribution; second, a greedy algorithm optimizes the winding cross-section globally to reduce the slot hot-spot temperature and suppress temperature rise. Validated by a fabricated tapered PMLSM stator prototype and static temperature-rise experiments, the results confirm that winding cross-section reconstruction optimizes heat distribution effectively, offering a new approach for temperature rise suppression in high thrust density PMLSMs. Full article

Structural optimization focusing on the root fillet radius and the crown and band thicknesses was implemented to prevent rotor–stator interaction-induced resonance, with the objective of enhancing the frequency safety margin for the 4-nodal-diameter mode shape. An ultra-high-head pump–turbine runner is analyzed using an acoustic fluid–structure coupling method to investigate modal characteristics and identify effective design improvements. The results show that increasing the root fillet radius from 0 to 50 mm raises the frequency safety margin from 3.7% to 8.5%, thereby significantly reducing the resonance risk. Likewise, increasing the thickness of the crown, the band, or both leads to higher frequency safety margins, with simultaneous thickening of both components delivering the most improvement. Frequency safety margins continue to rise as the degree of thickening increases. When a runner’s natural frequency is only slightly higher than the corresponding excitation frequency, design measures such as enlarging the root fillet radius and jointly thickening the crown and band effectively expand the frequency safety margin. These findings can provide designers with both qualitative and quantitative references when modifying these structural parameters to mitigate resonance risk. Full article

This paper presents a kind of dual-channel coupled radial magnetic field resolver (DCCRMFR). The exciting winding and signal winding of this resolver adopt the structure of orthogonal phase. The number of turns and distribution of the four phase signal winding have been designed. The rotor has a double-wave magnetic conductive material structure. The variable reluctance mechanism between the stator and the rotor is derived by analytical method, and the feasibility of changing the coupling area for variable reluctance is obtained. The inductance of DCCRMFR was theoretically derived through the winding function method and combined with the finite element simulation method to obtain the inductance variation law and verify the correctness of the resolver design. Then simulation analysis was conducted on the output signal of DCCRMFR to extract the total harmonic distortion (THD) of the envelope of the electromotive force (EMF) output from the signal winding. Taking THD as the optimization objective, the optimized DCCRMFR simulation model is obtained by analyzing the air-gap length between the stator and the rotor and the thickness ratio of rotor. Finally, experimental measurements were conducted on a prototype model of a two pole pairs DCCRMFR, and the measurement results were compared and analyzed with simulation results to verify the correctness of the structural design and optimization of this DCCRMFR. Full article

As a highly integrated and compact power unit, the motor-pump finds critical applications in emerging electric vehicle (EV) domains such as electro-hydraulic braking and steering systems, where its vibration and noise performance directly impacts cabin comfort. A key factor limiting its NVH (Noise, Vibration, and Harshness) performance is the electromagnetic vibration and noise induced by the cogging torque of the built-in brushless DC motor (BLDCM). Traditional suppression methods that rely on stator auxiliary slots exhibit certain limitations. To address this issue, this paper proposes a collaborative optimization method integrating multi-parameter scanning and response surface methodology (RSM) for the design of auxiliary slots on the motor-pump’s stator teeth. The approach begins with a multi-parameter scanning phase to identify a promising region for global optimization. Subsequently, an accurate RSM-based prediction model is established to enable refined parameter tuning. Results demonstrate that the optimized stator structure achieves a 91.2% reduction in cogging torque amplitude for the motor-pump. Furthermore, this structure effectively suppresses radial electromagnetic force, leading to a 5.1% decrease in the overall sound pressure level. This work provides a valuable theoretical foundation and a systematic design methodology for cogging torque mitigation and low-noise design in motor-pumps. Full article
