Search Results (33)

To enhance the standardization and construction efficiency of prefabricated steel structures and to promote the application of cold-formed steel tubes with the advantages of high standardization, superior mechanical properties, and fast processing speeds, two types of composite beam to concrete-filled cold-formed high-strength square steel tubular column joints with different connection forms were designed in this study: the external diaphragm joint (ED joint) and the through diaphragm joint (TD joint). These joints were subjected to cyclic loading tests to evaluate the influence of the connection designs on key seismic performance parameters, such as failure modes, load-bearing capacities, the degradation of strength and stiffness, ductility, and energy dissipation capabilities. The results show that both the ED and TD joints experienced butt weld fractures at the bolted-welded connections on the beam, effectively transferring the plastic hinges from the joint zone to the beam and demonstrating good seismic performance. The ED joint specimen JD1 and the TD joint specimen JD2 exhibited similar load-bearing capacity, stiffness, strength degradation, and energy dissipation capacity. However, the TD joint showed lower ductility compared to the ED joint due to premature weld fractures. A nonlinear finite element model (FEM) was developed using MSC.MARC 2012, and the numerical simulation showed that the FEM could effectively simulate the hysteresis performance of the composite beam to concrete-filled, cold-formed, high-strength, square, steel tubular column joints with external and through diaphragms. Full article

Utilizing crushed spontaneous combustion coal gangue as a coarse aggregate in concrete preparation effectively reduces reliance on natural resources and mitigates environmental pollution; however, the suboptimal workability of spontaneous combustion coal gangue coarse aggregate concrete (SCG-CAC) limits its engineering applications. To address this issue, this study places SCGCAC at the center of a CFDST (Concrete-Filled Double-Skin Steel Tubular) stub column. Through finite element modeling validated for reliability, this study examines the structural mechanical response to axial loading, along with the effects of various parameters. The analysis encompasses parameters such as the strength of the core SCGCAC (f_c,i), the strength of the sandwiched concrete (f_c,o), the yield strength of the outer steel tube (f_y,o), the yield strength of the inner steel tube (f_y,i), the width-to-thickness ratio (B/t_o), the diameter-to-thickness ratio of the inner tube (D/t_i), and the diameter-to-width ratio of the outer tube (D/B). Results show that this structural configuration significantly enhances the core SCGCAC ultimate bearing capacity, and increases in D/t_i, f_c,i, f_c,o, f_y,i, and B/t_o all lead to an increase in the peak load. Particularly, when D/t_i increases from 28.57 to 80, the peak load increases by 42.72%. However, changes in f_y,o and D/B have no significant effect on the peak load. Full article

This paper investigates the seismic performance of thin-walled stiffened steel square box columns, modeling bridge piers subjected to unidirectional cyclic lateral loading with a constant axial load, focusing on local, global, and local-global interactive buckling phenomena. Initially, the finite element model was validated against existing experimental results. The study further explored the degradation in strength and ductility of both thin-walled and compact columns under cyclic loading. Thin-walled, stiffened steel square box columns exhibited buckling near the base, forming a half-sine wave shape. The research also addresses discrepancies from different material models used to analyze steel tubular bridge piers. Analysis using a modified two-surface plasticity model (2SM) yielded results closer to experimental data than a multi-linear kinematic hardening model, particularly for compact sections. The 2SM, which accounts for cycling within the yield plateau and strain hardening regime, demonstrated enhanced accuracy over the multi-linear kinematic hardening model. Additionally, a parametric study was conducted to assess the impact of key design parameters—such as width-to-thickness ratio (R_f), column slenderness ratio (λ), and magnitude of axial load (P/P_y)—on the performance of thin-walled stiffened steel square box columns. Design equations were then developed to predict the strength and ductility of bridge piers. These equations closely matched experimental results, achieving an accuracy of 95% for ultimate strength and 97% for ductility. Full article

L-shaped concrete-filled steel tubular (CFST) columns, a kind of structural member appropriate for high-rise buildings, not only avoid the defect of conventional square columns protruding from the wall but also have the green and low-carbon properties of steel structures appropriate for fabricated construction. To learn more about their axial compression behavior, refined 3D finite element models were established using the general finite element software ABAQUS. The reliability of the models was subsequently verified based on failure tests and load–displacement relation tests on eight L-shaped specimens. The axial compression mechanism of L-shaped CFST columns was investigated using the verified finite element models. Further systematic parameter analysis was carried out to investigate the influence of parameters such as steel strength, concrete strength, length ratio of long limb to short limb, the angle between the two limbs, and combination methods on the axial compression behavior of L-shaped CFST columns. The results demonstrate that the angle between the two limbs has a significant impact on the stress distribution of concrete and steel pipes. The corner effect increases as the angle between the two limbs decreases. The combination of F-type specimens can better exert the constraint effect of steel pipes on concrete, while the triangular cavity of unequal-limb specimens and specimens with an included angle of 60° cannot effectively trigger the interaction between steel pipes and concrete. The initial stiffness of L-shaped CFST columns increases with an increase in concrete strength and a decrease in limb length ratio, which is not sensitive to changes in steel strength and the included angle. The peak bearing capacity of the specimens increases with increases in steel strength and concrete strength and a decrease in the limb length ratio. Compared to C-type and Z-type specimens, the initial stiffness of F-type specimens is slightly higher, and the peak bearing capacity is significantly increased. Full article

Artificial neural networks (ANN) have a great promise in predicting the load-bearing capacity of building structures. The purpose of this work was to develop ANN models to determine the ultimate load of eccentrically compressed concrete-filled steel tubular (CFST) columns of circular cross-sections, which operated on the widest possible range of input parameters. Short columns were considered for which the amount of deflection does not affect the bending moment. A feedforward network was selected as the neural network type. The input parameters of the neural networks were the outer diameter of the columns, the thickness of the pipe wall, the yield strength of steel, the compressive strength of concrete and the relative eccentricity. Artificial neural networks were trained on synthetic data generated based on a theoretical model of the limit equilibrium of CFST columns. Two ANN models were created. When training the first model, the ultimate loads were determined at a given eccentricity of the axial force without taking into account additional random eccentricity. When training the second model, additional random eccentricity was taken into account. The total volume of the training dataset was 179,025 samples. Such a large training dataset size has never been used before. The training dataset covers a wide range of changes in the characteristics of the pipe metal and concrete of the core, pipe diameters and wall thicknesses, as well as eccentricities of the axial force. The trained models are characterized by high mean square error (MSE) scores. The correlation coefficients between the predicted and target values are very close to 1. The ANN models were tested on experimental data for 81 eccentrically compressed samples presented in five different works and 265 centrally compressed samples presented in twenty-six papers. Full article

In the present work, a novel foam burner design is proposed and experimentally evaluated for operation with highly diluted syngas mixtures. The lab-scale burner consists of a purpose-built, square-shaped, high-temperature-grade stainless steel tubular reactor filled with square-sectioned siliconized silico carbide (SiSiC) foams. The assembly was installed in an electrical furnace. Spatially resolved temperature measurements were obtained along the reactor axis, while simultaneous measurements of CO, CO₂, H₂, O₂, and N₂ were taken at the burner exit and the water levels were recorded upstream and downstream of the reactor. The results clearly show that flames can be stabilized along the reactor for a range of foam characteristics and operating conditions. Hydrogen conversion efficiencies in excess of 98%, and overall thermal efficiencies close to 95% were achieved for the selected operating conditions. Overall, the denser 10 ppi foam demonstrated superior combustion characteristics in terms of stability, lower enthalpy rises, and a wider operating range at the expense of a very modest pressure drop penalty. Finally, scanning electron microscopy, coupled with energy dispersion spectroscopy (SEM/EDS) and Raman spectroscopy analyses, was used to determine the morphological and compositional characteristics of the pristine and aged foams. After more than 100 h of operation, no significant performance degradation was observed, even though the burner design was subjected to considerable thermal stress. Full article

Concrete-filled steel tubular (CFST) columns are one of the most effective reinforced concrete structures, and improving their calculation is a critical task. The purpose of this study was to develop a simplified method for calculating slender CFST columns, taking into account the effect of lateral compression. The idea of the method is to use the equation of a reinforced concrete column’s longitudinal bending, without taking into account the effect of lateral compression. To take into account the lateral effects, the cross-sectional stiffnesses are corrected based on the analysis of the stress–strain state in the cross-sectional plane using the finite element method. The developed method was implemented by the authors in the MATLAB environment. The approbation of the proposed method was carried out on experimental data for centrally compressed columns of a circular cross-section, as well as eccentrically compressed columns of a circular and square cross-section, presented in two papers. For the centrally compressed columns, we conducted a study on the influence of initial imperfections in the form of eccentricities and initial curvatures on the value of the ultimate load. For the eccentrically compressed columns of the circular and square cross-section, the area of their effective operation was determined. Full article

FRP (fiber-reinforced polymer)–concrete–steel double-skin square tubular (FCSST) columns are composed of an outside FRP tube, an inside steel tube and the concrete filled between them. Under the continuous constraint of the outside and inside tube, the strain, strength and ductility of concrete are improved significantly compared with those of traditionally reinforced concrete without lateral restraint. Additionally, the outside and inside tube not only function as the permanent formwork in casting but improve the bending and shear resistance of composite columns. Meanwhile, the hollow core also reduces the weight of the structure. Through the compressive testing of 19 FCSST columns subjected to eccentric load, this study focuses on the influence of eccentricity and layers of axial FRP cloth (away from the loading point) on the evolution of axial strain along the cross-section, axial bearing capacity, axial load–lateral deflection curve and other eccentric properties. The results can provide basis and reference for the design and construction of FCSST columns and are of great theoretical significance and practical value for the application of composite columns in the engineering of structures in a corrosive environment and other harsh conditions. Full article

PBL stiffeners, made of thin-walled steel plates with circular openings and welded to the steel tube of a square concrete-filled steel tubular (CFST) column, can improve the combined effect effectively by co-carrying axial compressive forces and confining the concrete core. A numerical simulation study based on the previous test was conducted to study the ultimate strength of the CFST stub column with PBL stiffeners. Finite element models of CFST with different stiffeners were made and verified by the test results of typical failure modes and load–strain curves of specimens. The parameter study was conducted, including PBL stiffener detailing (i.e., material strength, stiffener thickness, opening diameter, and opening spacing). Finally, based on the study and analysis results, an ultimate bearing capacity prediction formula was proposed, which can reasonably predict the bearing capacity of a square CFST column with longitudinal or diagonal stiffeners, while the methods in ACI, BS5400, EC4, AIJ, and DBJ were more conservative. Full article

Two new types of connection between concrete-filled U-shaped steel (CFUS) beams and concrete-filled square steel tube (CFSST) columns were presented in this study, including rebar-sleeve with internal diaphragm connection and rebar-through with internal diaphragm connection. Based on the experiments of the rebar-plate with internal diaphragm connections between CFUS beams and CFSST columns under cyclic loading, the nonlinear finite element models of the tested specimens were developed and validated by comparing them with the experimental results. The numerical results were in agreement with the experimental results in terms of failure modes, stress distribution, and load-displacement skeleton curves. Based on the FEA results, the mechanical behavior of the two new types of connection were comprehensively discussed and compared. Furthermore, this parametric study was conducted for the rebar-sleeve with internal diaphragm connection to investigate the effect of specific parameters on the capacity of the connection. The parameters included: The thickness of U-shaped steel, the ratio of longitudinal reinforcement in the concrete slab, the strength of concrete in the beam, the strength of the U-shaped steel, and the thickness of the internal diaphragm. The results indicate that the thickness of the U-shaped steel (t_b), the ratio of the longitudinal reinforcement in concrete slab (ρ), and the strength of the U-shaped steel have significant effects on the loading capacity of the connection—the loading capacity increases by about 20% when t_b increases from 6 mm to 8 mm, increases by about 45% when ρ increases from 1.5% to 4.8% under negative P, and increases by about 20% when the steel yield strength (f_y) increases from 235 Mpa to 420 Mpa. Full article

This research collected and summarized a total of 455 experimental tests of axially loaded square and rectangular concrete-filled steel tubular (CFST) stub columns. The recently published papers were used to evaluate the current design equations from four international standards, namely the American Concrete Institute (ACI) code, British Standard (BS5400), Chinese standard (BDJ13-51), and Eurocode 4 (EC4). It was found that the results obtained from the codes have appreciable differences and could be improved, especially for the specimens fabricated using high-resistance materials. Therefore, new empirical equations were proposed based on the four standard formulas and the wide range of previously available experimental data to provide more accurate estimations. The proposed equations could predict an average sectional capacity of only 0.1% lower than the experimental results, with better data scattering than the existing equation’s results. Full article

This paper presents a numerical study on the nonlinear behaviors of UHPC-filled square steel tubular (UHPCFST) columns under complex actions. A novel fiber model was developed considering the local buckling effects of steel tubes. The reliability and robustness of the model were validated by a large amount of experimental data in the reported literature. Then, the current design codes were evaluated and discussed on the basis of the collected experimental data, and a practical calculation method was finally proposed to predict the bending moment capacities of UHPCFST beam–columns. The results indicate that the proposed fiber model can accurately predict the nonlinear behaviors of UHPCFST beam–columns, including axial compression, eccentric compression, pure bending, and hysteretic behaviors. Compared with current design codes, the practical calculation method presents high precision and can accurately predict the bending moment capacities of UHPCFST beam–columns. Full article

Special T-shaped composite columns with concrete-filled square steel tubulars have good restraint on internal concrete, are convenient to process, have a high bearing capacity and good mechanical properties, and can increase the aesthetics of the building and the utilization rate of indoor space. Theoretical analysis, experimental study, and numerical simulation of the eccentric compression performance of the special-shaped column are carried out. Taking the specimen length, eccentric distance, and eccentric direction as test parameters, nine specimens with different slenderness ratios were designed to carry out eccentric compression tests. The eccentric compression performance was numerically simulated and analyzed by the general finite element software ABAQUS. The results show that the short column mainly suffers section strength failure, while the middle and long columns mainly suffer bending instability failure without torsional deformation. The degree of influence of the test parameters decreases in turn according to the eccentric distance, eccentric direction, and length of the specimen; there is no weld cracking phenomenon, and the square steel pipes can work together. The finite element calculation results are in good agreement with the experimental and theoretical values. Full article

This paper reports experimental and theoretical result derived from research on steel structural elements’ fire-protection with intumescent paint. The experimental results were obtained by means of an original testing bench, briefly described below and some basic cases, i.e., horizontally and vertically disposed, massive and square-tubular cross-sectioned, reduced-scale straight bars heated at one end. By means of the thermocouples mounted along the bars, the temperature distribution laws were monitored, depending on the heated end’s nominal temperature. The paper describes an original approach to the temperature distribution evaluation by means of some new parameters, based on the temperature distribution laws experimentally obtained with reduced-scale models. We involved the least-square method (LSM) and the curve-fitting one in order to obtain a more accurate temperature distribution law compared to the experimentally obtained ones. We also introduced some new parameters in order to define the amount of heat loss in a more accurate way. Based on the results obtained, the authors suggest that this approach to the temperature distribution law can be efficiently applied in further thermal analyses, for both 2D and 3D structures. The paper also includes a thorough analysis of “m” variation along the square-tubular-cross-section, reduced-scale straight bars, and similar new approaches are proposed by the authors. The sub-goals of this investigation were (1) to obtain useful correlations between the magnitudes of the massivity $\zeta =P/A$ and the parameter “m” along the bar, and (2) to analyze, on reduced-scale models, the heat distribution laws on unprotected and intumescent-paint-protected 2D and 3D steel structures. Full article

To enhance the local buckling resistance of thin-walled steel pipes and enhance their fire and corrosion resistance, a new spirally stiffened thin-walled square concrete-filled steel tubular laminated composite member with transverse ribs is proposed. Through the four forms of combined members for eccentric pressure testing, it was found that: ordinary thin-walled steel pipe concrete drum buckling is more severe; with spiral ribs, the buckling is limited between the stiffening ribs; and the deformation is significantly reduced. By addressing the problem of cooperative work between the inner and outer structural layers of new components, it was found that, after setting constraints such as steel bars, the integrity of the two can be ensured, and the stress performance is significantly improved; compared to ordinary steel pipe concrete, the load-carrying capacity is 17.9% higher, and the deformation capacity is roughly equivalent. Spiral ribs as a new form of spatial restraint, in addition to increasing the local bending stiffness, manifest an overall restraint role in limiting lateral deformation of the steel pipe, whereas the role of vertical stiffness is insignificant. Based on test evidence, the influences of the width to thickness ratio of spiral ribs and pitch were determined, and reasonable structural measures for the members were given. Through the N–M relationship curve, the limit of damage in compression and tension under eccentricity was obtained at an eccentricity of about 0.9. Finally, a method for calculating the eccentric compressive ultimate load capacity of this new composite member was proposed. Full article
