In hydraulic structures such as water control projects, spillway tunnels, and overflow dams that are subjected to high-velocity flow erosion, Concrete is required to exhibit high resistance to abrasion and cracking. While low water-to-binder ratio concrete can meet strength requirements, its inherent high shrinkage propensity often leads to cracking, seriously compromising long-term safety and durability under severe operating conditions. To address this engineering challenge, this study focuses on optimizing concrete performance through the synergistic combination of slag (GGBS) and silica fume (SF). This study systematically investigated the effects of incorporating GGBS (20–24%) and SF (6–10%) in a low water-to-binder ratio system with a fixed 70% cement content on key concrete properties. The evaluation was conducted through comprehensive tests including compressive strength, drying shrinkage, autogenous shrinkage, and hydration heat analysis. The results demonstrate that the blended system successfully achieves a synergistic improvement in both “high strength” and “low cracking risk.” Specifically, the incorporation of silica fume significantly enhances the compressive strength at all ages, providing a solid mechanical foundation for resisting high-velocity flow erosion. More importantly, compared to the pure cement system, the blended system not only delays the onset but also reduces the rate of early-age shrinkage, and lowers its ultimate autogenous shrinkage value. This characteristic is crucial for controlling the combined effects of thermal and shrinkage stresses from the source and preventing early-age cracking. Simultaneously, hydration heat analysis reveals that the blended system retards the heat release process, which helps mitigate the risk of thermal cracking. This study elucidates the regulatory mechanism of the GGBS-SF combination and provides a critical mix design basis and theoretical support for producing high-strength, high-abrasion-resistant, and low-shrinkage concrete in high-velocity flow environments, offering direct practical implications for engineering applications. Full article

Accurate prediction of air demand in free-surface flows through high-head spillway tunnels with multiple vents represents a critical design challenge. Existing empirical formulas for estimating air demand, derived from studies of single vents using experimental and prototype data, are not directly applicable to multi-vent configurations. This study investigates the combined effects of key parameters on ventilation requirements: (1) flow characteristics (velocity range of 6–12 m/s and depth varying between 0.06 and 0.1 m); (2) vent geometry (total vent area from 28 to 140 cm² and spatial distribution). Through an experimental analysis, an empirical formula is derived to correlate wall roughness with interfacial shear stress, enabling an improved method for estimating air demand in spillway tunnels with multiple air vents. The resulting predictive model achieves ±25% agreement with two prototype case studies and model tests. These experimentally validated relationships provide quantitative guidelines for optimizing ventilation system designs. Full article

Engineering dam projects benefit society, including hydropower, water supply, agriculture, and flood control. During the planning stage, it is crucial to calculate extreme hydrographs associated with different return periods for spillways and diversion structures (such as tunnels, conduits, temporary diversions, multiple-stage diversions, and cofferdams). In many countries, spillways have return periods ranging from 1000 to 10,000 years, while diversion structures are designed with shorter return periods. This study introduces a hydrological method based on data from large rivers which can be used to compute extreme hydrographs for different return periods in engineering dam projects. The proposed model relies solely on frequency analysis data of peak flow, base flow, and water volume for various return periods, along with recorded maximum hydrographs, to compute design hydrographs associated with different return periods. The proposed method is applied to the El Quimbo Hydropower Plant in Colombia, which has a drainage area of 6832 km². The results demonstrate that this method effectively captures peak flows and evaluates hydrograph volumes and base flows associated with different return periods, as a Root Mean Square Error of 11.9% of the maximum volume for various return periods was achieved during the validation stage of the proposed model. A comprehensive comparison with the rainfall–runoff method is also provided to evaluate the relative magnitudes of the various variables analysed, ensuring a thorough and reliable assessment of the proposed method. Full article

Whilst numerical modelling is commonly used for simulation to check the design of water conveyance, sluicing and spillway structure design, the numerical modelling has rarely been compared with the physical model tests. The objective of this research presented in this paper was to examine the validity and suitability of the numerical computational fluid dynamics (CFD) modeling method within an ANSYS Fluent/CFD R 18.2 software and compare its results with a fully instrumented and well-run physical model test at the 1:45 scale, carried out for Patrind Hydropower Project located in Pakistan. The physical model test was conducted for confirmation and optimization of a natural de-sanding basin, and diversion of suspended sediment-rich flood waters using a bypass tunnel. The numerical simulation was able to reproduce physical model test results and data gathered over a 7-year project operation to an acceptable level of accuracy. A detailed explanation of the approach used in numerical modelling together with analysis of simulation diagrams of ANSYS Fluent/CFD is also presented. The research shows that a 3D numerical model with accurate boundary conditions and mesh size can replace the need for physical model tests. Full article

Reservoirs are a crucial part of the human water supply system. The effectiveness and service life of a reservoir is decided mainly by its storage capacity, and as such, preventing reservoir capacity loss is of high interest worldwide. Due to climate change in recent years, precipitation types have changed, and heavy rainfall events have become more severe and frequent. Rainfall causes soil erosion in slope lands and transports large amounts of sediment downstream, forming deposition. This causes reservoir storage capacity to fall rapidly and decreases reservoir service life. The Sediment–Sluice Tunnel can reduce rapid deposition in reservoirs and is, thus, widely employed. By simulating sediment transportation in reservoirs, deposition reduction after building the Sediment–Sluice Tunnel can be evaluated. This study used the Physiographic Soil Erosion–Deposition (PSED) model to simulate the flow discharge and suspended sediment discharge flowing into the Zengwen reservoir then used the depth-averaged two-dimensional bed evolution model to simulate the sediment transportation and deposition in a hydrological process. Simulation results showed that the Sediment–Sluice Tunnel effectively reduced deposition and transported sediment closer to the spillway and Sediment–Sluice Tunnel gate. The deposition distribution with the Sediment–Sluice Tunnel built is more beneficial to the deployment of other dredging works. Full article

As the hydropower development strategies of China continue to be implemented, a host of large hydropower projects have been completed or are being constructed in southwest China. During construction of the Jinchuan hydropower station, this study examined the stability of the surrounding rock during the excavation and unloading of hydraulic tunnels under demanding geological conditions. Microseismic (MS) monitoring technology was employed to monitor the deformation and failure of the surrounding rock online and in real time, based on engineering geological data and site surveys. To analyze the stability of the surrounding rock in the spillway tunnel and to study the temporal and spatial evolution characteristics of MS events, source parameter analysis and numerical modeling were performed. The 3D finite-difference numerical modeling software FLAC3D was used to simulate the mechanical response of the surrounding rock during the excavation and unloading of the spillway tunnel and the diversion tunnel. The numerical modeling results were compared with the monitoring results and site surveys to determine the failure mechanisms of the surrounding rock during the construction and unloading of the hydraulic tunnels. The research results can serve as a guide for studying the stability of the surrounding rock in similar hydraulic tunnels. Full article

Numerous large hydropower projects have been built, are being built, or are planned to be developed in southwest China as a result of the increasing demand for clean energy in China’s social and economic development. Based on engineering geological data, site surveys, and the temporal and spatial distribution characteristics of microseismic (MS) events, an MS monitoring system was developed in this study to analyze the stability of the surrounding rock of the spillway tunnel of the Jinchuan hydropower station as well as the fracture and damage mechanism in the concentration zone. The results of the study indicated that the distribution of MS events was correlated with the construction process and geological conditions, that the concentration of MS events and their great moment magnitude could be regarded as signs of future damage to the surrounding rock, and that the surrounding rock of the spillway tunnel primarily exhibited non-shear failure, such as tensile failure, with only a small area exhibiting shear failure. The results can be used as a construction reference and as a forewarning of surrounding rock deformation. Full article

Spillway tunnels are key features in the regulation of the water surface of a reservoir and in ensuring the safety of life and properties of people downstream in a high dam project. This research aimed to provide a better understanding of the ventilation mechanism. The air–water two-phase flow was simulated under the Euler–Euler framework. A hybrid drag model, which was verified by the prototype data of Jinping-I spillway tunnel, was proposed to improve the prediction of air demand and air entrainment. The air demand prediction error was less than 18.9%, while the air entrainment prediction error was less than 28.35%. On the basis of the new drag model, the air entrainment behind aerators, air velocity distribution in the air ducts, and the residual space of the tunnel were systematically analyzed. Two flow patterns of the ventilation system were finally summarized. Full article

The objective of this research is to introduce a novel framework to quantify the risk of the reservoir system outside the design envelope, taking into account the risks related to flood-protection and hydro-energy generation under unfavourable reservoir element conditions (system element failures) and hazardous situations within the environment (flood event). To analyze water system behavior in adverse conditions, a system analysis approach is used, which is founded upon the system dynamics model with a causal loop. The capability of the system in performing the intended functionality can be quantified using the traditional static measures like reliability, resilience and vulnerability, or dynamic resilience. In this paper, a novel method for the assessment of a multi-parameter dynamic resilience is introduced. The multi-parameter dynamic resilience envelops the hydropower and flood-protection resilience, as two opposing demands in the reservoir operation regime. A case study of a Pirot reservoir, in the Republic of Serbia, is used. To estimate the multi -parameter dynamic resilience of the Pirot reservoir system, a hydrological model, and a system dynamic simulation model with an inner control loop, is developed. The inner control loop provides the relation between the hydropower generation and flood-protection. The hydrological model is calibrated and generated climate inputs are used to simulate the long-term flow sequences. The most severe flood event period is extracted to be used as the input for the system dynamics simulations. The system performance for five different scenarios with various multi failure events (e.g., generator failure, segment gate failure on the spillway, leakage from reservoir and water supply tunnel failure due to earthquake) are presented using the novel concept of the explicit modeling of the component failures through element functionality indicators. Based on the outputs from the system dynamics model, system performance is determined and, later, hydropower and flood protection resilience. Then, multi-parameter dynamic resilience of the Pirot reservoir system is estimated and compared with the traditional static measures (reliability). Discrepancy between the drop between multi-parameter resilience (from 0.851 to 0.935) and reliability (from 0.993 to 1) shows that static measure underestimates the risk to the water system. Thus, the results from this research show that multi-parameter dynamic resilience, as an indicator, can provide additional insight compared to the traditional static measures, leading to identification of the vulnerable elements of a complex reservoir system. Additionally, it is shown that the proposed explicit modeling of system components failure can be used to reflect the drop of the overall system functionality. Full article

With regard to the high anti-scouring and abrasion-resistant performance requirements and great temperature control difficulties of lining concrete for large-sized spillway tunnels, in this study, a performance test was conducted on anti-scouring and abrasion-resistant concrete. The finite element method was used to analyze the temperature change rules of sidewall C₉₀50 (design strength of concrete is 50 MPa at 90 days) lining concrete for the spillway tunnel. Further, a new cooling measure was proposed for adopting “early-throughput, high-flow and short-duration”. As indicated by the results of this study, fly ash could reduce water consumption and micro-cracks via its “morphological effect”. Silica fume could improve the early strength of cement concrete and make up for the strength loss caused by fly ash. Polyvinyl alcohol (PVA) fiber could enhance concrete durability. The doping of these three additives reinforced the strength and abrasion resistance of concrete. The results showed that the temperature of the lining concrete presented a change trend of “rapid increase first, followed by a slow decrease”. The peak temperature was reached roughly 2 days after casting. In addition, properly increasing throughput flow or decreasing throughput temperature in the early stage of casting could significantly reduce the highest temperature and maximum temperature difference of concrete. Based on the results from the numerical simulation of temperature control effect, it was proposed to adopt “early-throughput, high-flow, and short-duration” for temperature control and cracking prevention. Specifically, within 2 days after casting, cooling water at roughly 12 °C was guided in at a flow of approximately 3.5 m³/h. Within 3–7 days after casting, river water at around 17 °C was guided in at a flow rate of approximately 1.8 m³/h. After 7 days, the cooling effect can be well achieved by only using the surface flowing water for curing. According to the field monitoring data, the changes in measured temperature were basically consistent with those from numerical simulations, and detection on the temperature of the sidewall lining concrete showed that a qualification rate of >91% was satisfactorily obtained by using the proposed approach. Full article

It is of great significance to study the ventilation characteristics of air supply systems in spillway tunnels, especially for high dams. In this paper, a brief theoretical approach to evaluate the ventilation characteristics of a multi-intake-well air supply system was established, which was mainly derived from the Bernoulli equation and continuity equation. With this approach, an analysis of the ventilation characteristics of the Jinping-I project spillway tunnel was carried out. A comparison of the theoretical results and prototype data suggested the theoretical approach to be valid and practical. The value of the drag coefficient at the air-water interface should be calibrated before evaluation because the drag coefficient is crucial for the accuracy of theoretical results. In addition, the influences of certain structural factors of the spillway tunnel and air intake well on the ventilation characteristics of multi-intake-well air supply systems are investigated. Full article

A new type of vortex drop shaft without ventilation holes is proposed to resolve the problems associated with insufficient aeration, negative pressure (Unless otherwise specified, the pressure in this text is gauge pressure and time-averaged pressure) on the shaft wall and cavitation erosion. The height of the intake tunnel is adjusted to facilitate aeration and convert the water in the intake tunnel to a non-pressurized flow. The hydraulic characteristics, including the velocity (Unless otherwise specified, the velocity in this text is time-averaged velocity), pressure and aeration concentration, are investigated through model experiment and numerical simulation. The results revealed that the RNG k-ε turbulence model can effectively simulate the flow characteristics of the vortex drop shaft. By changing the inflow conditions, water flowed into the vertical shaft through the intake tunnel with a large amount of air to form a stable mixing cavity. Frictional shearing along the vertical shaft wall and the collisions of rotating water molecules caused the turbulence of the flow to increase; the aeration concentration was sufficient, and the energy dissipation effect was excellent. The cavitation number indicated that the possibility of cavitation erosion was small. The results of this study provide a reference for the analysis of similar spillways. Full article

Artificial air entrainment has been widely used to avoid cavitation damage in spillways where high-velocity flow occurs, and its performance is very important for spillway safety. In order to evaluate the performance of the aeration system in the spillway tunnel of the Jinping-I Dam, which is the highest arched dam in the world to date, systematic prototype observation was conducted. Ventilation characteristics of the air supply system and aeration-related characteristics of the aeration devices were examined at the prototype scale. The results showed that air flows smoothly in the air intake well and the real effect of air entrainment of the aeration device was desirable. In contrast with results from laboratory tests with a physical model at a scale of 1/30 following the gravity similarity, it was found that air demand in the prototype is much greater, clearly indicating the scale effect. By summing up and analyzing the air demand ratio of the prototype to the model in some projects, the scale effect was found to be ignorable when the model scale was greater than 1/10. In addition, based on a series of prototype data on air demand, a brief evaluation of present calculation methods for air demand was conducted and a new form of calculation method for air demand related to unit width flow rate was established. The present prototype results can be used as a reference for similar engineering design, and to validate and verify numerical simulations as well as model tests. Full article
