Search Results (201)

As a core functional component of multi-degree-of-freedom precision motion mechanisms, spherical hinges are widely used in high-end equipment fields such as industrial robots, vehicle engineering, and intelligent manufacturing. Their dynamic performance directly determines the motion accuracy and the level of intelligent control of the equipment. The high-precision real-time measurement of two-degree-of-freedom (2-DOF) angles is a key prerequisite for achieving precise closed-loop control of spherical hinges. However, due to the strong coupling characteristics between the 2-DOF angle signals, it is difficult to directly and accurately measure the angular motion parameters of spherical hinges, which has become a core technical bottleneck restricting the improvement in their application efficiency. To address this challenge, this paper presents an improved study of the previously proposed spherical differential quadrature capacitance sensor for measuring the 2-DOF angle signals of spherical hinges. Firstly, the 2-DOF angle signal decoupling model is reconstructed and optimized. Secondly, a real-time decoupling circuit architecture for phase-shift detection with single-frequency signal excitation is innovatively proposed. This solution effectively addresses the incomplete decoupling of 2-DOF angle signals in previous studies, as well as the problems of considerable measurement noise, low resolution, and high calibration difficulty caused by random amplitude and phase errors in the excitation signals. Through the construction of an experimental platform for verification tests, the results show that the proposed scheme can significantly suppress the random errors caused by the parameter dispersion of the device, achieve an angle measurement resolution of 0.001°, and simultaneously considerably reduce the complexity of system calibration, laying a key technical foundation for the engineering application of spherical hinges in the fields of precision measurement and high-performance control. Full article

To evaluate cross-platform measurement consistency and diagnostic threshold requirements in shear wave elastography (SWE), this study presents a robotically controlled, phantom-based validation framework to quantify and interpret inter-vendor variability that limits clinical standardisation. A custom-fabricated polyvinyl chloride-graphite phantom containing eight spherical inclusions (15–25 mm diameter, 25–95 mm depth, 23.53–259.58 kPa stiffness), representing breast tissue mechanical properties, was evaluated using Samsung HS50 and Aixplorer ultrasound systems. Robotic automation standardised probe positioning and contact, eliminating operator-dependent variability and enabling direct, system-level comparison. Cross-platform reproducibility, accuracy against mechanically validated ground truth, and diagnostic threshold performance were assessed across 80 measurements. Both systems demonstrated excellent intra-machine reproducibility (coefficient of variation: Samsung 0.42%, Aixplorer 0.46%) with strong inter-machine correlation (r = 0.9951, p < 0.0001). However, systematic bias of 7.05 kPa and 95% limits of agreement spanning 38.7 kPa revealed substantial cross-platform measurement differences. All phantom inclusions (8/8) measured below their assigned ground truth stiffness on both systems, with systematic underestimation ranging from 0.33 kPa to 109.57 kPa, indicating parameter-dependent measurement distortion linked to inclusion size, depth, and stiffness. Dynamic range compression was observed (Samsung: 68.7%, Aixplorer: 59.1% of true phantom range), providing a mechanistic explanation for diagnostic threshold instability. This study contributes an interpretable validation methodology that links SWE measurement bias to physical lesion properties and imaging system characteristics, rather than relying on correlation alone. Despite strong reproducibility, the observed system-dependent bias demonstrates that SWE measurements are not directly transferable across ultrasound platforms, and system-specific collaboration is required to ensure reliable clinical interpretation. Full article

To address the precision and motion-smoothing challenges in path planning for spherical workpieces without Computer-Aided Design (CAD) models, this paper proposes a robust point-cloud-driven framework. Conventional Principal Component Analysis (PCA) alignment suffers from centroid shift errors due to asymmetric data loss from light-absorbing surface features. To solve this, a RANSAC-compensated hybrid PCA algorithm is developed to decouple position and orientation estimation, ensuring stable coordinate alignment despite incomplete data. Furthermore, to resolve the geometric collapse and kinematic jitter caused by traditional planar slicing in high-curvature polar regions, a spherical latitudinal equiangular conical slicing algorithm is introduced. By aligning the slicing planes with the sphere’s radial geometry, the method preserves topological accuracy while maintaining an optimal point density for smooth robotic execution. Experimental results on rubber ball groove processing demonstrate a repeat positioning accuracy of 0.09 mm and a feature coverage of 95.21%. This research provides a scientifically rigorous and computationally efficient solution for the automated processing of complex spherical surfaces. Full article

Achieving reliable and real-time inverse kinematics (IK) for 6-degree-of-freedom (6-DoF) spherical-wrist manipulators remains a significant challenge. Analytical formulations often struggle with complex geometries and modeling errors, and standard numerical solvers (e.g., Levenberg–Marquardt) can stall near singularities or converge slowly. Purely data-driven approaches may require large networks and struggle with extrapolation. In this paper, we propose a low-latency, polynomial-based IK solution for spherical-wrist robots. The method leverages spherical coordinates and low-degree polynomial fits for the first three (positional) joints, coupled with a closed-form analytical solver for the final three (wrist) joints. An iterative partial-derivative refinement adjusts the polynomial-based angle estimates using spherical-coordinate errors, ensuring near-zero final error without requiring a full Jacobian matrix. The method systematically enumerates up to eight valid IK solutions per target pose. Our experiments against Levenberg–Marquardt, damped least-squares, and an fmincon baseline show an approximate 8.1× speedup over fmincon while retaining higher accuracy and multi-branch coverage. Future extensions include enhancing robustness through uncertainty propagation, adapting the approach to non-spherical wrists, and developing criteria-based automatic solution-branch selection. Full article

The development of upper-limb prostheses is often hindered by limited dexterity, a restricted workspace, and bulky designs, primarily due to performance limitations in proximal joints like the shoulder and elbow, which contribute to high user abandonment rates. To overcome these challenges, this paper presents a novel, bioinspired, and integrated prosthetic system as an advancement in bionic technology. The design incorporates a shoulder joint based on an asymmetric 3-RRR spherical parallel mechanism (SPM) with actuators embedded within the moving platform, and an elbow joint actuated by low-voltage Shape Memory Alloy (SMA) springs. The inverse kinematics of the shoulder mechanism was established, revealing the existence of up to eight configurations. We employed Multi-Objective Particle Swarm Optimization (MOPSO) to simultaneously maximize workspace coverage, enhance dexterity, and minimize joint torque. The optimized design achieves remarkable performance: (1) 85% coverage of the natural shoulder’s workspace; (2) a maximum von Mises stress of merely 3.4 MPa under a 40 N load, ensuring structural integrity; and (3) a sub-0.2 s response time for the SMA-driven elbow under low-voltage conditions (6 V) at a motion velocity of 6°/s. Both motion simulation and prototype testing validated smooth and anthropomorphic motion trajectories. This work provides a comprehensive framework for developing lightweight, high-performance prosthetic limbs, establishing a solid foundation for next-generation wearable robotics and bionic devices. Future research will focus on the integration of neural interfaces for intuitive control. Full article

Humans could sensitively perceive and identify objects through dense mechanoreceptors distributed on the skin of curved fingertips. Inspired by this biological structure, this study presents a general conformal integration method for flexible tactile sensors on curved fingertip surfaces. By adopting a spherical partition design and an inverse mode auxiliary layering process, it ensures the uniform distribution of stress at different curvatures. The sensor adopts a 3 × 3 tactile array configuration, replicating the 3D curved surface distribution of human mechanoreceptors. By analyzing multi-point outputs, the sensor reconstructs contact pressure gradients and infers the softness or stiffness of touched objects, thereby realizing both structural and functional bionics. These sensors exhibit excellent linearity within 0–100 kPa (sensitivity ≈ 36.86 kPa⁻¹), fast response (2 ms), and outstanding durability (signal decay of only 1.94% after 30,000 cycles). It is worth noting that this conformal tactile fingertip integration method not only exhibits uniform responses at each unit, but also has the preload-free advantage, and then performs well in pulse detection and hardness discrimination. This work provides a novel bioinspired pathway for conformal integration of tactile sensors, enabling artificial skins and robotic fingertips with human-like tactile perception. Full article

This paper introduces a constraint-aware optimization framework for designing spherical multi-camera rigs that achieve complete panorama coverage while adhering to physical and field-of-view limitations. The approach assesses coverage using solid-angle geometry and calculates the sampling density in pixels per steradian, providing a measurable, traceable basis for panoramic optical measurement. By viewing panoramic imaging as a directional measurement challenge, the framework aligns with principles of optical metrology and guarantees uniform, non-contact optical sensing around the sphere. The optimization process includes capsule-based collision constraints, soft coverage losses, and field-of-view intersection modeling to produce physically feasible rig configurations. Experiments show that the optimized rigs provide improved coverage uniformity and less redundancy, with validation through Blender-generated synthetic panoramas confirming the practical performance of the designed optical systems. The proposed approach allows for systematic, measurement-driven design of spherical camera rigs for use in immersive imaging, robotic perception, and structural inspection. Full article

To address the challenging requirements of citrus detection in complex orchard environments, this paper proposes ACDNet (Adaptive Citrus Detection Network), a novel deep learning framework specifically designed for automated citrus harvesting. The proposed method introduces three key innovations: (1) Citrus-Adaptive Feature Extraction (CAFE) module that combines fruit-aware partial convolution with illumination-adaptive attention mechanisms to enhance feature representation with improved efficiency; (2) Dynamic Multi-Scale Sampling (DMS) operator that adaptively focuses sampling points on fruit regions while suppressing background interference through content-aware offset generation; and (3) Fruit-Shape Aware IoU (FSA-IoU) loss function that incorporates citrus morphological priors and occlusion patterns to improve localization accuracy. Extensive experiments on our newly constructed CitrusSet dataset, which comprises 2887 images capturing diverse lighting conditions, occlusion levels, and fruit overlapping scenarios, demonstrate that ACDNet achieves superior performance with mAP@0.5 of 97.5%, precision of 92.1%, and recall of 92.8%, while maintaining real-time inference at 55.6 FPS. Compared to the baseline YOLOv8n model, ACDNet achieves improvements of 1.7%, 3.4%, and 3.6% in mAP@0.5, precision, and recall, respectively, while reducing model parameters by 11% (to 2.67 M) and computational cost by 20% (to 6.5 G FLOPs), making it highly suitable for deployment in resource-constrained robotic harvesting systems. However, the current study is primarily validated on citrus fruits, and future work will focus on extending ACDNet to other spherical fruits and exploring its generalization under extreme weather conditions. Full article

Precise and programmable magnetic field control is essential for the reliable actuation of magnetic miniature robots in biomedical applications. However, the workspace of existing systems often relies on empirical designs and lacks a clear framework to define an entire workspace with independently controllable magnetic field strength, as well as precisely specified volume, shape, and position. Here, we present a rational design framework that systematically elucidates the fundamental principles governing the generation of uniform and gradient magnetic fields using spherically distributed magnetic coil arrays (SDMCAs). We first identify the eight independent parameters that fully define the magnetic field. Using both analytical and numerical methods, we demonstrate that the control of the magnetic field strength and gradient can be decoupled. This concept is then extended to three dimensions through the development of a finite element analysis (FEA) model, which accurately simulates the spatial magnetic field distribution of complex coil geometries. The simulation results are validated experimentally, showing excellent agreement. Finally, we propose a step-by-step SDMCA design workflow that enables precise control over the magnetic field parameters within a target workspace. This framework provides a practical and scalable approach for the development of high-performance magnetic actuation systems for miniature robots. Full article

Inspecting the inner walls of large pressure vessels requires accurate weld seam recognition, complete coverage, and precise path tracking, particularly in low-feature environments. This paper presents a fully autonomous mobile robotic system that integrates weld seam detection, localization, and tracking to support ultrasonic testing. An improved Differentiable Binarization Network (DBNet) combined with the Spatially Variant Transformer (SVTR) model enhances digital stamp recognition, while weld paths are reconstructed from three-dimensional position data acquired via binocular stereo vision. To ensure complete traversal and accurate tracking, a global–local hierarchical planning strategy is implemented: the A-star (A*) algorithm performs global path planning, the Rapidly Exploring Random Tree Connect (RRT-Connect) algorithm handles local path generation, and point cloud normal–based spherical interpolation produces smooth tracking trajectories for robotic arm motion control. Experimental validation demonstrates a 94.7% digital stamp recognition rate, 95.8% localization success, 1.65 mm average weld tracking error, 2.12° normal fitting error, 98.2% seam coverage, and a tracking speed of 96 mm/s. These results confirm the system’s capability to automate weld seam inspection and provide a reliable foundation for subsequent ultrasonic testing in pressure vessel applications. Full article

The dynamic performance of parallel robots directly determines the machining accuracy in large optical mirror processing (LOMP). However, limitations in traditional dynamic modeling methods hinder their application in real-time control, constraining further improvements in robotic precision. This paper aims to establish a high-precision and practical dynamic model that considers joint friction for parallel robots used in LOMP, and to design an efficient real-time friction compensation control strategy to effectively enhance trajectory tracking and repetitive positioning accuracy. The novelty of this work lies in proposing a dynamic modeling approach that integrates the static mechanics-based “Disassembly Method” with a “Coulomb + Viscous” friction model. First, static analysis of the mechanism is conducted using the “Disassembly Method” to accurately compute the joint constraint reactions in any pose, providing critical input for friction calculation. Subsequently, a complete dynamic model incorporating friction in joints such as Hooke joints, composite spherical hinges, and ball screws is developed based on the Newton–Euler formulation. This method overcomes the shortcomings of traditional approaches in solving joint reactions and managing model complexity. Numerical simulations demonstrate that, compared to conventional friction-neglected models, the proposed model reveals a maximum increase of approximately 350 N in driving chain joint reaction forces and significant peaks in driving forces at motion reversal instants (e.g., 0.28 s, 0.45 s), quantitatively proving that neglecting friction severely underestimates the actual system loads. Experimental validation shows that the feedforward PD friction compensator designed based on this model reduces the rotational tracking errors of the moving platform around the X- and Y-axis from 0.295° and 0.286° to 0.134° and 0.128°, respectively, achieving an error reduction of about 55% and effectively improving motion control accuracy. This study provides a reliable dynamic modeling foundation and an effective real-time control compensation solution to address force output errors and trajectory deviations caused by joint friction in high-precision LOMP. Full article

This study presents a comprehensive simulation-based comparative analysis of four parallel robotic mechanisms, each developed to assist patient recovery through adaptive movement control and feedback, particularly for upper and lower limb therapy. Kinematic and dynamic models were developed and implemented in Matlab-Simulink, integrating force control via conventional regulators and real-time interaction with simulated patient-applied forces. The structural differences between spherical, rotational, and universal joints in each kinematic chain variant were evaluated. To systematically determine the most suitable design, a detailed Analytic Hierarchy Process was applied considering performance, precision, stability, and actuator effort. The study emphasizes the advantages of parallel robots in rehabilitation due to their precision, rigidity, and compact design, highlighting the potential of parallel robotic systems in customized and adaptive physical therapy interventions. These insights contribute to the optimal design selection of clinical motor therapy robots. Full article

The emergence of Industry 5.0 brings a paradigm shift towards collaborative environments where humans and intelligent robots work side-by-side, enabling personalized, flexible, and resilient manufacturing. However, integrating humans and robots introduces new operational and safety risks that require proactive and adaptive control strategies. This study proposes an intelligent multi-criteria decision-making framework for smart risk assessment and the selection of optimal adaptive control strategies in human–robot collaborative manufacturing settings. The proposed framework integrates advanced risk analytics, real-time data processing, and expert knowledge to evaluate alternative control strategies, such as real-time wearable sensor integration, vision-based dynamic safety zones, AI-driven behavior prediction models, haptic feedback, and self-learning adaptive robot algorithms. A cross-disciplinary panel of ten experts structures six main and eighteen sub-criteria spanning safety, adaptability, ergonomics, reliability, performance, and cost, with response time and implementation/maintenance costs modeled as cost types. Safety receives the most significant weight; the most influential sub-criteria are collision avoidance efficiency, return on investment (ROI), and emergency response capability. The framework preserves linguistic semantics from elicitation to aggregation and provides a transparent, uncertainty-aware tool for selecting and phasing adaptive control strategies in Industry 5.0 collaborative cells. Full article

This paper provides advances in the study of principal $\mathrm{SO}\left(3\right)$-bundles over smooth projective real curves, with applications to robot manipulation orientation. The work introduces a novel specific classification of these bundles, establishing a bijection between isomorphism classes and specific direct sums of cyclic groups. The explicit computation of the cohomology ring $H^{*}(P,\mathbb{Z})$ for a principal $\mathrm{SO}\left(3\right)$-bundle P over a real curve X, revealing its complete structure and torsion subgroups, is a major contribution of the paper. This paper further demonstrates that the equivariant cohomology $H_{\mathrm{SO}\left(3\right)}^{*}(P,\mathbb{Z})$ is isomorphic to $H^{*}(X,\mathbb{Z})\otimes H^{*}(B\mathrm{SO}\left(3\right),\mathbb{Z})$, with implications for connections and curvature. These results are then applied to robotics, showing that for manipulators with revolute joints, a principal $\mathrm{SO}\left(3\right)$-bundle encoding end-effector orientation whose second Stiefel–Whitney class characterizes the obstruction to continuous orientation control exists. For robots with spherical wrists, the configuration space factors as a product, allowing for the decomposition of connections with control implications. Finally, a mechanical connection is constructed that minimizes kinetic energy, with its curvature identifying configurations where small perturbations cause large orientation changes. Full article

With the iterative evolution of SLAM (Simultaneous Localization and Mapping) technology in the robotics domain, the SLAM paradigm based on three-dimensional Gaussian distribution models has emerged as the current state-of-the-art technical approach. This research proposes a novel MSGS-SLAM system (Monocular Semantic Gaussian Splatting SLAM), which innovatively integrates monocular vision with three-dimensional Gaussian distribution models within a semantic SLAM framework. Our approach exploits the inherent spherical symmetries of isotropic Gaussian distributions, enabling symmetric optimization processes that maintain computational efficiency while preserving geometric consistency. Current mainstream three-dimensional Gaussian semantic SLAM systems typically rely on depth sensors for map reconstruction and semantic segmentation, which not only significantly increases hardware costs but also limits the deployment potential of systems in diverse scenarios. To overcome this limitation, this research introduces a depth estimation proxy framework based on Metric3D-V2, which effectively addresses the inherent deficiency of monocular vision systems in depth information acquisition. Additionally, our method leverages architectural symmetries in indoor environments to enhance semantic understanding through symmetric feature matching. Through this approach, the system achieves robust and efficient semantic feature integration and optimization without relying on dedicated depth sensors, thereby substantially reducing the dependency of three-dimensional Gaussian semantic SLAM systems on depth sensors and expanding their application scope. Furthermore, this research proposes a keyframe selection algorithm based on semantic guidance and proxy depth collaborative mechanisms, which effectively suppresses pose drift errors accumulated during long-term system operation, thereby achieving robust global loop closure correction. Through systematic evaluation on multiple standard datasets, MSGS-SLAM achieves comparable technical performance to existing three-dimensional Gaussian model-based semantic SLAM systems across multiple key performance metrics including ATE RMSE, PSNR, and mIoU. Full article
