Search Results (91)

Actuating monolithic photonic components (particularly slab waveguides) requires higher force due to their inherent stiffness. However, two primary constraints must be addressed: actuator footprint and fabrication limits. Increasing the number of fingers to provide the required force is not a viable solution due to space constraints, and we must also adhere to the process design kits of standard fabrications and respect their design limits. Therefore, it is crucial to increase the actuator force output without significantly enlarging the actuator footprint while maintaining the necessary travel range. In order to achieve this, we utilize arrays of electrostatic comb drives, with each repeating cell geometry optimized to produce the highest force per actuator footprint. Our optimization strategy focuses on finger geometry, the arrangement of fingers and arms design in the comb structure, including the number of fingers per arm and arm length, ensuring that each repeating cell delivers maximum force per unit area or force intensity. Co-optimizing a repeatable, footprint-optimized comb-array unit cell (arm length, arm width, finger pitch, finger count) and validating it against an asymmetric slab waveguide load, we reach a maximum pre-pull-in force intensity of about 342 N m⁻² at 70 V with about 6 µm travel, confirmed by analytical modeling, numerical simulation, and measurement. Despite fabrication challenges such as over-etching and variations in electrode dimensions, detailed SEM analyses and correction functions ensure that the theoretical models closely match the experimental data, confirming the robustness and accuracy of the design. These optimized actuators, capable of achieving substantial force output without sacrificing travel range or mechanical stability, are particularly effective for applications in optical beam steering for in-plane silicon-photonics and related optical microsystems applications. Full article

Curved prisms can serve as core components of dispersive spectroscopy and converge light paths, making them widely used in spectral imaging technology. Their positional stability, surface shape errors, and temperature stability in optical systems directly affect the performance of spectral imaging systems. On the basis of the analysis of design indicators and optimization of the support structure for curved prisms, a multipoint flexible adhesive support structure (MPPASS) of large rectangular curved prisms for space-based application is proposed. The novelty of the MPPASS lies in its ability to achieve micro-stress and high stability support for large-aperture rectangular optical elements through the bonding of peripheral small points and the introduction of flexible bonding rings. The design principles of the adhesive support structure were deeply studied, and on this basis, the engineering design, finite element analysis, adhesive testing, and mechanical testing of large curved prisms were completed. The designed curved prism assembly has a maximum deformation displacement of 0.0085 mm and a maximum tilt angle of 0.65” under gravity loading, a first-order frequency of 1003.5 Hz, and a maximum acceleration amplification factor of 3.12 in the X, Y, and Z directions. The root mean square (RMS) variation value of the mirror shape errors for the curved prism assembly was 5.26 nm under a uniform temperature load of 20 ± 1 °C, and the RMS value of the mirror shape errors was 0.019 λ after mechanical testing. The installation surface flatness of 0.02 mm did not significantly affect its mirror shape errors. The experimental results verified the rationality of the design, temperature stability, and mechanical stability of the MPPASS. Full article

Aerosols play a crucial role in air quality, climate regulation, and public health; their timely monitoring is hence fundamental. The aerosol optical depth (AOD) is the parameter used to investigate the spatial–temporal distribution of aerosols from space. Specifically, the AOD retrieved from the Multi-Angle Implementation of Atmospheric Correction (MAIAC) algorithm applied to a Moderate Resolution Imaging Spectroradiometer (MODIS) is suitable for aerosol investigation at a local scale by exploiting its high spatial resolution (1 km × 1 km). In this study, the MAIAC AOD retrieval over Rome (Italy) was validated for the first time, using ground-based data provided by an AERONET station operating in a semi-rural environment close to the city, over a time series from January 2001 to December 2022. Moreover, AOD trends were evaluated in a study area encompassing Rome and its surroundings, characterized by a transition zone between urban and rural environments. The results show a general underestimation of the MAIAC AOD; specifically, the validation process highlighted the less accurate performance of the algorithm under higher aerosol loading and with predominantly coarse mode aerosol. Interesting results were obtained concerning the influence of the geometrical configuration of satellite acquisition on the accuracy of the MAIAC product. In particular, the solar zenith angle, the relative azimuth and the scattering angle between the principal plane of the sun and satellite synergistically influence retrievals. Finally, the spatial distribution of the AOD shows a decreasing trend over the 2001–2022 period and a strong influence of the city of Rome over the whole study area. Full article

To solve the international problem of global–local radiation features simulation of multi-spectral space targets, this paper proposes a multi-spectral space target simulation modulation algorithm that can combine global–local spectral radiation features. An overall architecture of a series-parallel multi-source information fusion space target simulation system (MITS) is constructed, and a global–local multi-spectral radiation feature modulation link is built. A multi-spectral feature modulation algorithm consisting of three modules, including optical engine non-uniformity compensation, global spectral radiant energy modulation, and local radiant grayscale modulation, is designed, and an experimental platform is built to verify the correctness and advancement of the proposed algorithm. The results indicate that the non-uniformity is better than 3.78%, the global simulation error is better than −4.56%, and the local simulation error is better than 4.25%. It is one of the few multi-spectral target simulation modulation algorithms worldwide that can combine the global whole and local details. It supports the performance test and technology iteration of multi-spectral optical loads. It helps to supplement the theoretical system of multi-spectral space target simulation and enhance the ground-based semi-physical simulation link of optical loads. Full article

Having good replication of the soil moisture evolution is desirable to properly simulate the dust emissions and atmospheric dust load because soil moisture increases the cohesive forces of soil particles, modulating the wind erosion threshold above which emissions occur. To reduce errors, one can use soil moisture retrievals from space-borne microwave radiometers. Here, we explore the potential of inserting soil moisture retrievals from the Soil Moisture Active Passive (SMAP) satellite into the Weather Research and Forecasting model coupled with Chemistry (WRF-Chem) to improve dust simulations. We focus our analysis on the contiguous U.S. due to the presence of important dust sources and good observational networks. Our analysis extends over the first year of SMAP retrievals (1 April 2015–31 March 2016) to cover the annual soil moisture variability and go beyond extreme events, such as dust storms, in order to provide a statistically robust characterization of the potential added value of the soil moisture retrievals. We focus on the Goddard Chemistry Aerosol Radiation and Transport (GOCART) model from the Air Force Weather Agency (GOCART-AFWA) dust emission parameterization that represents soil moisture modulations of the wind erosion threshold with a parameterization developed by fitting observations. The dust emissions are overestimated by the GOCART-AFWA parameterization and result in an overestimation of the aerosol optical depth (AOD). Sensitivity experiments show that emissions reduced to 25% in the GOCART-AFWA simulations largely reduced the AOD bias over the Southwest and lead to better agreement with the standard WRF-Chem parameterization of dust emissions (GOCART) and with observations. Comparisons of GOCART-AFWA simulations with emissions reduced to 25% with and without SMAP soil moisture insertion show added value of the retrievals, albeit small, over the dust sources. These results highlight the importance of accurate dust emission parameterizations when evaluating the impact of remotely sensed soil moisture data on numerical weather prediction models. Full article

The space-division multiplexed (SDM) transmission technique based on uncoupled multi-core fibers (MCF) shows great implementation potential due to its huge transmission capacity and compatibility with existing transceivers. In this paper, we demonstrate a real-time single-span 106 km field trial over deployed 4-core MCF cable using commercial 800 Gb/s optical transport network (OTN) transceivers. The transceivers achieved a modulation rate of 130 Gbaud with the optoelectronic multiple-chip module (OE-MCM) packaging technique, which enabled the adoption of a highly noise-tolerant probability constellation shaping a 16-array quadrature amplitude modulation (PCS-16QAM) modulation format for 800 Gb/s OTN transceivers, and could realize unrepeated long-span transmission. The 4-core 800 Gb/s transmission systems achieved a real-time transmission capacity of 256 Tb/s with fully loaded 80-wavelength channels over the C+L band. The performance of different kinds of 800 G OTN transceivers with different modulation formats under this long-span unrepeated optical transmission system is also estimated and discussed. This field trial demonstrates the feasibility of applying uncoupled MCF with 800 Gb/s OTN transceivers in unrepeated long-span transmission scenarios and promotes its field implementation in next-generation high-speed optical interconnection systems. Full article

In this paper, a new measurement principle for decoupling mechanical and thermal signals in an OFDR measurement with integrated optical fibres is investigated. Previous methods for decoupling require additional measuring equipment or knowledge about the substrate properties. This new method is based solely on simultaneous measurements of two fibres with different temperature sensitivities resulting from different core doping processes. By exposing both fibres to the same thermal and mechanical load, the signal could be differentiated through the signal variations caused by the thermo-optical effect. The two fibres used in the tests have a sufficient response difference in the cryogenic temperature range. Therefore, the method is suitable for various applications, such as high-temperature superconductors as well as cryogenic and space applications. Full article

In cold atom physics, the complexity of traditional magneto-optical trap system limits the use of their associated instruments for field applications in atomic physics, such as gravity mapping, space navigation and deep space exploration. This study introduces a novel compact MOT design that addresses these issues by simplifying the structure and reducing the size. The height of the unit is 0.7 m, the volume is $6.3\times {10}^{-2}$${\mathrm{m}}^3$ and the mass is 11.32 kg. The new design utilizes a single laser to generate the two different frequencies needed for laser cooling by internally splitting the beam, shifting the frequency and then combining them, effectively controlling both the cooling and repumping beams. The compact vacuum chamber optical path, in conjunction with the magnetic field, facilitates the capture of ⁸⁷Rb atoms in an ultra-high vacuum environment. Experimental results demonstrate an atom loading rate of up to $1.79\times {10}^7$⁸⁷Rb atoms per second, confirming the system’s effectiveness in capturing and cooling ⁸⁷Rb atoms. This design provides a flexible and portable solution, offering valuable insights for the advancement of compact MOT and its applications in cold atom physics. Full article

Presently, on-orbit calibration methods have several problems, such as low calibration accuracy and broken traceability links, so an urgent need exists to unify traceable and high-precision on-orbit radiometric calibration loads as benchmarks for cross-transfer radiometric calibration. Considering the deficiencies of current on-orbit calibration, this paper proposes adjusting the size of the variable diaphragm at the entrance pupil and the integration time to attain large dynamic attenuation, converting the radiometric calibration into absolute geometric calibration of the attenuation device, and realizing a self-calibrating real entrance pupil imaging spectrometer (SCREPIS) that can be directly used to view the Earth and the Sun and quickly obtain apparent reflectance data. An initial structural design method based on the distance between individual mirrors is proposed according to the instrument design requirements. The design of a real entry pupil image-side telecentricity off-axis three-reflector front optical system with a 7° field of view along the slit direction, a 3.7 systematic F-number, and a 93 mm focal length is finally realized, and the system image plane energy is verified to change proportionally to the variable diaphragm area. Finally, the front system and rear Offner optical system are jointly simulated and optically designed. The system provides instrumental support for cross-calibration and theoretical support and a technical basis for planning space-based radiation references. Full article

A compact and miniaturized laser collimation system was proposed to measure the four-degrees-of-freedom of an optical payload in high-altitude space. Compared with other systems, this system has a simple structure and low cost, high measurement accuracy, and a large measurement range. The optical structure of the system was designed, the measurement principle of the four-degree-of-freedom was described in detail, the interference between the distance measurement and the angle measurement in the optical path was analyzed, and the installation error was analyzed. The error was minimized under different temperature conditions to improve the robustness of the system. An engineering prototype was built based on the system design scheme and an experiment was conducted to measure a target with a measured distance of 500 mm. The current indicators reached the requirements for the ground testing of optical payloads. The application of the system can be used to measure six degrees of freedom simultaneously by installing two systems in different coordinate systems. The system can also be used in industry; for example, by measuring the machine tool error in real time and compensating for it, the system can improve the positioning and motion accuracy. It can also be used for feedback control of the robot’s motion by measuring and controlling it. Full article

The development of eye pathology is a serious concern for astronauts who spend time in deep space. Microgravity is a major component of the spaceflight environment which could have adverse effects on ocular health. The use of centrifugation to exert forces that partially or fully mimic Earth-level gravity in space is a possible countermeasure to mitigate the effects of microgravity on the eye. Therefore, we subjected mice on the International Space Station (ISS) to microgravity (0 G) or artificial gravity by centrifugation at 0.33 G, 0.67 G, and 1 G, and then performed RNA sequencing (RNA-seq) on optic nerve and retinal tissue after returning them to Earth alive. We find that the microgravity environment induces transcriptomic changes in the optic nerve and retina consistent with an increased oxidative stress load, inflammation, apoptosis, and lipid metabolic stress. We also find that adding artificial gravity on board the ISS attenuates the transcriptomic response to microgravity in a dose-dependent manner. Such attenuation may effectively protect from and mitigate spaceflight-induced detrimental effects on ocular tissue. Full article

With the rapid growth in space-imaging demands, the scheduling problem of multiple agile optical satellites has become a crucial problem in the field of on-orbit satellite applications. Because of the considerable solution space and complicated constraints, the existing methods suffer from a huge computation burden and a low solution quality. This paper establishes a mathematical model of this problem, which aims to maximize the observation profit rate and realize the load balance, and proposes a multi-pointer network to solve this problem, which adopts multiple attention layers as the pointers to construct observation action sequences for multiple satellites. In the proposed network, a local feature-enhancement strategy, a remaining time-based decoding sorting strategy, and a feasibility-based task selection strategy are developed to improve the solution quality. Finally, extensive experiments verify that the proposed network outperforms the comparison algorithms in terms of solution quality, computation efficiency, and generalization ability and that the proposed three strategies significantly improve the solving ability of the proposed network. Full article

We propose a new free-space optical (FSO) communication system for moving platform tracking, which can achieve high precision aiming and tracking. Our prototype system consists of three parts. As a coarse sighting structure, the electro-optical pod module is used for target searching and coarse sighting in the initial stage. As a precise aiming structure, the precise targeting loads module located inside the electro-optical pod module uses miniaturized tubular folding optical path technology for high-precision alignment and tracking. The bottom module of the system is used for communication. In the tracking process, the control unit uses spot offset collected by CCD to perform decoupling calculation and then compensates the offset by swinging tracking and aiming structure. We did track experiments on a mobile platform. The experiment successfully tracked a moving target at 100 m distance, and the tracking error was less than 1 mrad. The proposed system can provide stable communication links between the mobile platforms. Full article

Edible films based on biopolymers are used to protect food from adverse environmental factors. However, their ample use may be hindered by some challenges to their mechanical and antimicrobial properties. Despite this, in most cases, increasing their mechanical properties and antibacterial activity remains a relevant challenge. To solve this problem, a possible option is to fill the biopolymer matrix of films with a functional filler that combines high reinforcing and antibacterial properties. In this work, biocomposite films based on a mixture of chitosan and cassava starch were filled with a hybrid filler in the form of bentonite clay particles loaded with ginger essential oil (GEO) in their structure with varied concentrations. For this purpose, GEO components were intercalated into bentonite clay interlayer space using a mechanical capture approach without using surface-active and toxic agents. The structure and loading efficiency of the essential oil in the obtained hybrid filler were analyzed by lyophilization and laser analysis of dispersions, ATR-FTIR spectroscopy, thermogravimetry, and X-ray diffraction analysis. The filled biocomposite films were analyzed using ATR-FTIR spectroscopy, optical and scanning electron spectroscopy, energy dispersive spectroscopy, mechanical analysis under tension, and the disk diffusion method for antibacterial activity. The results demonstrated that the tensile strength, Young’s modulus, elongation at the break, and the antibacterial effect of the films increased by 40%, 19%, 44%, and 23%, respectively, compared to unfilled film when the filler concentration was 0.5–1 wt.%. Full article

Near-space high-altitude balloon-based platforms have a series of advantages and provide superior conditions for optical observation. In order to ensure the stability of the optical axis of the optical detection load and stable tracking of the target, a near-space high-altitude balloon-based high-precision pointing and tracking system was designed, which can compensate for changes in the pitch angle and azimuth angle of the platform during flight. The system includes a primary platform stable pointing system and a secondary precise tracking system. In the finished flight experiment, the primary platform pointing system and secondary precise tracking system on the balloon-based observation platform worked normally, providing a guarantee for the coronagraph’s stable tracking and detection of the sun. The primary platform pointing system can realize ±1° pointing accuracy, and the simulated accuracy of the secondary precise tracking system is 4″, which guaranteed that the coronagraph obtained more than 20,000 images. In subsequent works, we will upgrade and optimize the whole system and conduct our next flight experiment in the future. Full article
