Search Results (21)

Solution-processed OLEDs represent a low-cost, scalable alternative to vacuum-deposited devices, particularly for flexible and large-scale applications. However, selecting compatible materials for each layer remains a complex task, further complicated by inconsistent documentation, solvent interactions, and limited reproducibility across the literature. This work presents a literature review and critical analysis of materials, solvents, and fabrication methods involved in solution-processed OLEDs, with particular attention to layer formulation, solvent orthogonality, and processing constraints. A Monte Carlo-based optimization framework is introduced as a proof of concept, aiming to formalize stack selection and explore viable combinations based on empirical constraints. The critical analysis highlights recurring issues in the field and advocates for a more structured, reproducibility-oriented approach to OLED design. Full article

The fabrication of high-performance organic optoelectronic devices using solution-based techniques, in particular inkjet printing, is both a desirable and challenging goal. Organic light-emitting diodes (OLEDs) are multilayer devices that have demonstrated great potential in display applications, with ongoing efforts aimed at extending their use to the lighting sector. A key objective in this context is the reduction in production costs, for which printing techniques offer a promising pathway. The main obstacle to fully printed OLEDs lies in the difficulty of depositing new layers onto pre-existing ones while maintaining high film quality and avoiding damage to the underlying layers. In a bottom-emitting OLED, the electron transport layer (ETL) is the final organic layer to be deposited, making its printing particularly challenging, a process for which only a few successful examples have been reported. In this work, we report on the optimization of a 2,2′,2″-(1,3,5-Benzinetriyl)-tris(1-phenyl-1-H-benzimidazole) (TPBi)-based ink formulation for ETL printing on an emitting layer composed of 5,10-Bis(4-(3,6-di-tert-butyl-9H-carbazol-9-yl)-2,6-dimethylphenyl)-5,10-dihydroboranthrene (tBuCzDBA). A specific ratio of methanol to diethyl ether was identified as the most suitable for printing the ETL without compromising the integrity of the underlying layer. The printed ETL was successfully integrated into an OLED device, which exhibited a maximum current efficiency of 6.8 cd/A and a peak luminance of about 8700 cd/m². These results represent a significant step toward the development of a fully printed OLED architecture. Full article

In this study, fully aromatic polyether sulfones were developed, bearing blue, yellow, and orange–red π-conjugated semiconducting units. Carbazole-, anthracene-, and benzothiadiazole-based fluorophores are copolymerized with a diphenylsulfone moiety. A diphenylpyridine comonomer was additionally utilized, acting as both a solubilizing unit and a weak blue fluorescent group. Using this rationale, fluorescent polyarylethers with high molecular weights, up to 70 kDa, were developed, showing film formation ability and high thermal stability, while preserving excellent solubility in common organic, nonvolatile, and nonchlorinated solvents. Fine-tuning of the emission color was achieved through subtle changes of the comonomers’ type and ratio. Single-chromophore-bearing copolymers emitted in the blue or the yellow region of the visible spectrum, while the dual-chromophore-bearing terpolymers emitted throughout the visible spectrum, resulting in white light emission. Solutions of 20 wt% in polar aprotic solvents at ambient conditions allowed the deposition of fluorescent copolyethers and printing from non-chlorinated solvents. All polyethers were evaluated for their structural and optoelectronic properties, and selected copolymers were successfully used in the emitting layer (EML) of organic light-emitting diode (OLED) devices, using either rigid or flexible substrates. Remarkable color stability was displayed in all cases for up to 15 V of bias voltage. The Commission Internationale de L’Eclairage (CIE) of the fabricated devices is located in the blue (0.16, 0.16), yellow (0.44, 0.50), or white region of the visible spectrum (0.33, 0.38) with minimal changes according to the ratio of the comonomers. The versatile methodology toward semiconducting polyethersulfones for polymer light-emitting diodes (PLEDs) developed herein led to the scaled-up production of luminescent polymers of up to 25 g of high-molecular-weight single batches, demonstrating the effectiveness of this approach as a straightforward tool to facilitate the synthesis of flexible and printable EMLs for large-area PLED coverage. Full article

Free-form factor optoelectronics is becoming more important for various applications. Specifically, flexible and transparent optoelectronics offers the potential to be adopted in wearable devices in displays, solar cells, or biomedical applications. However, current transparent electrodes are limited in conductivity and flexibility. This study aims to address these challenges and explore potential solutions. For the next-generation transparent conductive electrode, Al-doped zinc oxide (AZO) and silver (AZO/Ag/AZO) deposited by in-line magnetron sputtering without thermal treatment was investigated, and this transparent electrode was used as a transparent organic light-emitting diode (OLED) anode to maximize the transparency characteristics. The experiment and simulation involved adjusting the thickness of Ag and AZO and OLED structure to enhance the transmittance and device performance. The AZO/Ag/AZO with Ag of 12 nm and AZO of 32 nm thickness achieved the results of the highest figure of merit (FOM) (Φ₅₅₀ = 4.65 mΩ⁻¹) and lowest roughness. The full structure of transparent OLED (TrOLED) with AZO/Ag/AZO anode and Mg:Ag cathode reached 64.84% transmittance at 550 nm, and 300 cd/m² at about 4 V. The results demonstrate the feasibility of adopting flexible substrates, such as PET, without the need for thermal treatment. This research provides valuable insights into the development of transparent and flexible electronic devices. Full article

The effects of the solvent used for the active layer materials of an OLED based on TADF emitters play a fundamental role in solution-deposited devices. This work focuses on the effects on the performance of different solvents employed to fabricate a very simple two-organic-layer OLED based on a green TADF emitter, under the concept of host: guest matrix. From the different results of the main figures of merit, it was possible to conclude that the OLED that used toluene as a solvent for the active layer reached a maximum EQE of 14%, almost the maximum already obtained for this emitter in more complex device structures. With the analysis of the charge-transport processes, it was possible to establish an explanatory model for the obtained results. Through impedance spectroscopy, additional characterization of the nature of charge-transport processes was carried out. With these results, it was possible to correlate the relaxation times, with the electrical properties of the active layer, and make inferences about the interaction between the electrical charges and the defect levels, opening new possibilities for further development in printed OLEDs. Full article

Two dinuclear copper(II) complexes with macrocyclic Schiff bases K1 and K2 were prepared by the template reaction of (R)-(+)-1,1′-binaphthalene-2,2′-diamine and 2-hydroxy-5-methyl-1,3-benzenedicarboxaldehyde K1, or 4-tert-butyl-2,6-diformylphenol K2 with copper(II) chloride dihydrate. The compounds were characterized by spectroscopic methods. X-ray crystal structure determination and DFT calculations confirmed their geometry in solution and in the solid phase. Moreover, intermolecular interactions in the crystal structure of K2 were analyzed using 3D Hirshfeld surfaces and the related 2D fingerprint plots. The magnetic study revealed very strong antiferromagnetic Cu^II-Cu^II exchange interactions, which were supported by magneto-structural correlation and DFT calculations conducted within a broken symmetry (BS) framework. Complexes K1 and K2 exhibited luminescent properties that may be of great importance in the search for new OLEDs. Both K1 and K2 complexes showed emissions in the range of 392–424 nm in solutions at various polarities. Thin materials of the studied compounds were deposited on Si(111) by the spin-coating method or by thermal vapor deposition and studied by scanning electron microscopy (SEM/EDS), atomic force microscopy (AFM), and fluorescence spectroscopy. The thermally deposited K1 and K2 materials showed high fluorescence intensity in the range of 318–531 nm for K1/Si and 326–472 nm for the K2/Si material, indicating that they could be used in optical devices. Full article

An approach to increase the efficiency of europium-based OLEDs was proposed through the formation of a mixed-ligand complex. The design of a series of europium complexes, together with an optimization of the solution deposition, including the host selection, as well as the variation of the solvent and deposition parameters, resulted in a noticeable increase in OLED luminance. As a result, the maximum luminance of the Eu-based OLED reached up to 700 cd/m², which is one of the highest values for an Eu-based solution-processed OLED. Finally, its stability was investigated. Full article

The improvement of optical and optoelectronic properties of the individual poly [2-methoxy-5- (2-ethylhexyloxy)-1,4-phenylenevinylene] (MEH-PPV), poly[2-methoxy-5-(3,7-dimethyl-octyloxy)-1,4-phenylenevinylene]–End capped with Dimethyl phenyl (OC1C10–PPV–DMP), and poly (9,9′-di- n -octylfluorenyl-2,7-diyl) (F8) was revealed by blending them in ternary hybrid with optimal ratio (F8/2 wt.% MEH-PPV/2 wt.% OC1C10–PPV–DMP). All individual and optimal ternary solutions were prepared via the solution-blending method followed by depositing them onto glass and ITO substrates using spin-coating technique. The semi-crystalline phase of the ternary hybrid and the strong mixing between the conjugated polymers were evidenced by observing the X-ray diffraction patterns that related to F8 into the hybrid diffractogram. The optical and optoelectronic properties of all prepared thin films were investigated in terms of absorption and emission spectra, Commission International d′Eclairage (CIE) coordinates, and current–voltage (I-V) characterizations. Emission peaks at the entire range of visible spectrum can be revealed from the ternary hybrid of the three individual conjugated polymers, producing white emission as evidenced from the emission spectrum and CIE coordinates of the hybrid. Among all fabricated organic light-emitting diodes (OLEDs) devices, the ternary hybrid-based-OLED revealed the best performance in terms of current and turn-on voltage. Full article

As the demand for flexible organic light-emitting diodes (OLEDs) grows beyond that for rigid OLEDs, various elements of OLEDs, such as thin-film transistors, electrodes, thin-film encapsulations (TFEs), and touch screen panels, have been developed to overcome OLEDs’ physical and chemical limitations through material and structural design. In particular, TFEs, which protect OLEDs from the external environment, including reactive gases, heat, sunlight, dust, and particles, have technical difficulties to be solved. This review covers various encapsulation technologies that have been developed with the advent of atomic layer deposition (ALD) technology for highly reliable OLEDs, in which solutions to existing technical difficulties in flexible encapsulations are proposed. However, as the conventional encapsulation technologies did not show technological differentiation because researchers have focused only on improving their barrier performance by increasing their thickness and the number of pairs, OLEDs are inevitably vulnerable to environmental degradation induced by ultraviolet (UV) light, heat, and barrier film corrosion. Therefore, research on multi-functional encapsulation technology customized for display applications has been conducted. Many research groups have created functional TFEs by applying nanolaminates, optical Bragg mirrors, and interfacial engineering between layers. As transparent, wearable, and stretchable OLEDs will be actively commercialized beyond flexible OLEDs in the future, customized encapsulation considering the characteristics of the display will be a key technology that guarantees the reliability of the display and accelerates the realization of advanced displays. Full article

Herein, we report the synthesis and characterization of two Pt(II) coordination compounds, the new platinum(II)[N,N′-bis(salicylidene)-3,4-diaminobenzophenone)] ([Pt(sal-3,4-ben)]) and the already well-known platinum(II)[N,N′-bis(salicylidene)-o-phenylenediamine] ([Pt(salophen)]), along with their application as guests in a poly [9,9-dioctylfluorenyl-2,7-diyl] (PFO) conjugated polymer in all-solution processed single-layer white organic light-emitting diodes. Completely different performances were achieved: 2.2% and 15.3% of external quantum efficiencies; 2.8 cd A⁻¹ and 12.1 cd A⁻¹ of current efficiencies; and 3103 cd m⁻² and 6224 cd m⁻² of luminance for the [Pt(salophen)] and [Pt(sal-3,4-ben)] complexes, respectively. The Commission Internationale de l’Eclairage (CIE 1931) chromaticity color coordinates are (0.33, 0.33) for both 0.1% mol/mol Pt(II):PFO composites at between approximately 3.2 and 8 V. The optoelectronic properties of doped and neat PFO films have been investigated, using steady-state and time-resolved photoluminescence. Theoretical calculations at the level of relativistic density functional theory explained these results, based on the presence of the Pt(II) central ion’s phosphorescence emission, considering spin-orbit coupling relationships. The overall results are explained, taking into account the active layer morphological properties, along with the device’s electric balance and the emitter’s efficiencies, according to deep-trap space-charge models. Considering the very simple structure of the device and the ease of synthesis of such compounds, the developed framework can offer a good trade-off for solution-deposited white organic light-emitting diodes (WOLEDs), with further applications in the field of lighting and signage. Full article

One of the goals of adding adjuvants to agricultural spray solutions is to enhance the droplet size characteristics of this spray. Droplet size, in turn, has an influence in the deposited spray quality, in addition to the drift and losses of spray to off-target places. The aim of this research was to evaluate the effect of adding adjuvants to two types of water from different sources on the droplet size characteristics. Two types of adjuvants were employed in the tests: the active substance content of the first adjuvant was a 50% aqueous solution of sodium salt of alkylbenzenesulfonic acid—10% (HY), whereas the second was from rapeseed oil (natural origin)—85% (OL). Both adjuvants were tested in two concentrations: the first was with the concentration recommended by the manufacturer (100%), whereas the second concentration was 50% of the recommended dose. Two types of water from different sources were used in the tests: the first was from a village in the eastern part of Poland (WS), whereas the second was tap water from the city of Lublin, Poland (WUP). D_v0.1, D_v0.5, or volume median diameter (VMD), D_v0.9, Sauter mean diameter (SMD), relative span (RS), and the droplet size distribution were measured and calculated as characteristics of the droplet size. Results showed that the source of water affected the influence of adding adjuvant to the spray solution. Water from the WS source with adjuvant resulted in a numerical decrease in the D_v0.5 values in the percentage of droplet size range below 150 µm, whereas water from the WUP source resulted in an increase in these values (except when adding the HY adjuvant at 50% concentration). Adjuvant concentration significantly (p < 0.05) influenced the features of D_v0.9, SMD, and RS. Adding the OL adjuvant type numerically decreased the percentage of droplet size below 150 µm, and the D_v0.5 values, but only when the WS water source was used. Full article

Pentacene is a well-known conjugated organic molecule with high mobility and a sensitive photo response. It is widely used in electronic devices, such as in organic thin-film transistors (OTFTs), organic light-emitting diodes (OLEDs), photodetectors, and smart sensors. With the development of flexible and wearable electronics, the deposition of good-quality pentacene films in large-scale organic electronics at the industrial level has drawn more research attention. Several methods are used to deposit pentacene thin films. The thermal evaporation technique is the most frequently used method for depositing thin films, as it has low contamination rates and a well-controlled deposition rate. Solution-processable methods such as spin coating, dip coating, and inkjet printing have also been widely studied because they enable large-scale deposition and low-cost fabrication of devices. This review summarizes the deposition principles and control parameters of each deposition method for pentacene and its derivatives. Each method is discussed in terms of experimentation and theory. Based on film quality and device performance, the review also provides a comparison of each method to provide recommendations for specific device applications. Full article

Organic light emitting diode (OLED) is a new, promising technology in the field of lighting and display applications due to the advantages offered by its organic electroactive derivatives over inorganic materials. OLEDs have prompted a great deal of investigations within academia as well as in industry because of their potential applications. The electroactive layers of OLEDs can be fabricated from low molecular weight derivatives by vapor deposition or from polymers by spin coating from their solution. Among the low-molar-mass compounds under investigation in this field, carbazole-based materials have been studied at length for their useful chemical and electronic characteristics. The carbazole is an electron-rich heterocyclic compound, whose structure can be easily modified by rather simple reactions in order to obtain 2,7(3,6)-diaryl(arylamino)-substituted carbazoles. The substituted derivatives are widely used for the formation of OLEDs due to their good charge carrier injection and transfer characteristics, electroluminescence, thermally activated delayed fluorescence, improved thermal and morphological stability as well as their thin film forming characteristics. On the other hand, relatively high triplet energies of some substituted carbazole-based compounds make them useful components as host materials even for wide bandgap triplet emitters. The present review focuses on 2,7(3,6)-diaryl(arylamino)-substituted carbazoles, which were described in the last decade and were applied as charge-transporting layers, fluorescent and phosphorescent emitters as well as host materials for OLED devices. Full article

Recently, inkjet printing technology has attracted much attention due to the advantages of drop-on-demand deposition, low-cost and large-area production for organic light-emitting diode (OLED) displays. However, there are still some problems in industrial production and practical application, such as the complexity of ink modulation, high-quality films with homogeneous morphology, and the re-dissolution phenomenon at interfaces. In this work, a printable poly(3,4-ethylenedioxythiophene): poly(styrenesulfonate) (PEDOT:PSS) ink is developed and obtains an adjustable viscosity. Finally, a patterned PEDOT:PSS electrode is fabricated by inkjet printing, and achieves a high conductivity of 1213 S/cm, a transparency of 86.8% and a uniform morphology without coffee-ring effect. Furthermore, the vacuum-evaporated and solution-processed OLEDs are fabricated based on this electrode and demonstrate a current efficiency of 61 cd/A, which is comparable to that of the indium tin oxide counterpart. This work confirms the feasibility of inkjet printing technology to prepare patterned electrodes and expects that it can be used to fabricate highly efficient optoelectronic devices. Full article

In this research, electrodeposition procedure was utilized for the synthesis of a new composite polymer: N-methylpyrrole–Triton–X100/N, N,N-diethylaniline (NMPY-TRX100/NNDEA) used as a coating on carbon steel type OL 37 electrode for corrosion protection. The surfactant Triton–X100, a dopant ion utilized throughout the process of electropolymerization, had a significant impact on the corrosion protection of this composite by impeding the penetration of corrosive ions. PNMPY-TRX100/PNNDEA coatings were successfully realized on the OL37 substrate by a galvanostatic method of synthesis using the solutions 0.1 M NNDEA, 0.1 M MPY, 0.03 M TRX-100, and 0.3 M H₂C₂O₄, at varied current densities (3 mA/cm², 5 mA/cm² and 8 mA/cm²) in different molar ratios (1:1, 1:5, 3:2 and 5:1). The deposition was performed for 20 and 30 min. The polymeric composite coatings were characterized electrochemically, spectroscopically, and morphologically by cyclic voltammetry, Fourier transform infrared spectroscopy, and scanning electron microscopy methods. Corrosion protection performance of PNMPY-TRX100/PNNDEA-coated OL 37 was examined through potentiostatic and potentiodynamic polarization, open circuit potential measurements, and electrochemical impedance spectroscopy procedures in 0.5 M H₂SO₄ media. The corrosion rate of PNPMPY-TRX100/PNNDEA-coated OL 37 was denoted to be around nine times less than that of an uncoated electrode. The corrosion protection yield of the coating was more than 90%. The best effectiveness was realized for PNMPY-TRX-100/PNNDEA by electrodeposition at 5 mA/cm² current density applied in molar ratios of 5:1 and 3:2, and at 8 mA/cm² current densities applied in molar ratio 5:1. The outcomes of the corrosion experiments revealed that PNMPY-TRX-100/PNNDEA coatings provide a good anticorrosion protection of OL 37 in corrosive solutions. Full article
