Ensuring the safe operation of large hydro-generators is essential for energy supply and economic development. Stator-winding single-phase grounding faults are among the most common failures in such generators. Conventional protection methods—such as fundamental voltage protection, third-harmonic voltage saturation, and low-frequency injection—lack fault location capability and cannot assess the fault severity. This paper proposes a stepwise variable-frequency pulse injection method for fault diagnosis and location in large hydro-generator stator windings. A finite element model of a salient-pole hydro-generator is established to analyze magnetic flux density and electromotive force distributions under normal and fault conditions, from which fault characteristics are derived. Equivalent circuit models suitable for low- and high-frequency pulse injection are developed. A bidirectional pulse injection circuit and algorithm are designed to identify the fault phase via terminal current vector characteristics, diagnose the faulty branch based on leakage loop equivalent inductance, and locate the fault point using voltage–current signal slopes. Simulation results validate the effectiveness of the proposed diagnostic approach. Full article

Due to the “low damping” characteristics of the DC distribution system, the traditional passive scheme is not suitable for DC fault detection and positioning. Therefore, this paper proposes an active injection fault identification method suitable for DC feeder line under single-pole grounding faults. Based on the high controllability of converters, this method uses the oscillation circuit characteristics of the DC side single-pole grounding fault to superimpose the harmonics of fixed frequency into the converter modulated wave, and derives the selection principles of harmonic amplitude and frequency. After the fault, the positive and negative current signals are extracted from the feeder lines, and the zero-mode current components are extracted by the Karrenbauer transformation and band-pass filter, the current phases are compared to achieve the fault feeder line selection. According to simulation verification, the power quality of the actively injected harmonics is within the standard range under the condition of global injection, and the single-pole grounding faults in each feeder line can be identified. Full article

With the development of offshore wind power towards the deep and distant sea, the DC collection and DC transmission (all-DC) wind farm demonstrates distinct advantages, including the absence of the Ferranti effect and elimination of multi-level voltage conversion requirements. For the protection of the all-DC collection network in offshore wind farms, this paper first analyzes the zero-mode current relationship at line outlets of the collection network and wind turbine outlets during single-pole-to-ground (SPG) faults. Analysis reveals that (1) zero-mode current polarities are opposite between fault and non-fault lines, and (2) zero-mode current polarities are opposite between the upstream and downstream of the fault point. Based on these characteristics, a polarity comparison-based protection and fault localization scheme is proposed. The method implements waveform peak–valley detection through mathematical morphology algorithms, with detection results quantified by similarity algorithms to achieve fault section localization. An all-DC offshore wind farm simulation is built in PSCAD/EMTDC. A variety of simulations under different operating conditions are delivered, demonstrating the validity and effectiveness of the proposed protection and fault localization scheme. The method accurately distinguishes the SPG fault on lines and buses while remaining unaffected by fault resistance. Full article

Flexible DC grids are an important technological means for optimizing power supply structures and promoting energy transition. However, as a system with low inertia and weak damping, the flexible DC grid inherently faces challenges, such as rapid rising of fault currents, vulnerability to significant damage, difficulty in fault interruption, and with regard to the poor overcurrent-withstanding capabilities of power electronic devices. To address these issues, this paper proposes a method for calculating the single-pole ground fault current in a symmetrical monopolar DC grid, and further introduces a matrix exponential calculation method. This method enables quantitative analysis of the influence of various component parameters on the fault current, taking into account the dynamic characteristics of both the faulted and healthy poles in the DC system. The results demonstrate the high accuracy of this calculation method. The analysis reveals that the inductance of the faulted branch has the greatest impact on the fault current, while the inductances of the adjacent outgoing lines also have a certain influence. In contrast, the inductances of lines not adjacent to the faulted branch have minimal impacts on the fault current. Furthermore, the grounding electrode parameters of the converter station connected to the faulted branch exert the most significant influence on the fault current, with the grounding electrode parameters of neighboring converter stations also showing a notable effect. This indicates that the fault current is impacted by the topology of the nearby DC grid, but is not affected by the fault currents at remote converter stations. Full article

With the growing penetration of renewable energy sources, ensuring the stability and reliability of Medium-Voltage Direct Current (MVDC) systems has become more critical than ever. A single fault in MVDC systems can cause significant disturbances, necessitating rapid and precise diagnostics to prevent equipment damage and maintain continuous power supply. In this work, we present a Bidirectional Gated Recurrent Unit (Bi-GRU) model that both classifies and locates MVDC faults. By capturing the temporal behavior of voltage signals, the Bi-GRU framework surpasses traditional algorithms such as Convolutional Neural Networks (CNNs) and Bidirectional Long Short-Term Memory (Bi-LSTM) networks. Furthermore, the proposed approach addresses multiple fault scenarios including PTP (Pole-to-Pole), PPTG (Positive Pole-to-Ground), and NPTG (Negative Pole-to-Ground) while preserving real-time diagnostic capabilities. In extensive tests, our model achieves an overall accuracy of 95.54% and an average fault detection time below 1.3 ms, meeting real-world operational requirements. To assess robustness, sensor noise was artificially introduced to emulate realistic conditions. Despite these challenging inputs, our method consistently maintained high diagnostic accuracy, confirming its practicality and reliability. Consequently, the proposed scheme demonstrates a significant contribution toward improving the safety and dependability of MVDC systems, even under noisy conditions. Full article

Pole tower grounding bodies are part of the normal structure of the power system, providing relief from fault currents and equalizing overvoltage channels. They are important devices; however, in the harsh environment of the soil, they are prone to corrosion or even fracture, which in turn affects the normal utilization of the transmission line, so accurately assessing the condition of grounding bodies of the power grid is critical. To assess the operational status of a grounding body in a timely manner, this paper proposes a multi-parameter pulsed eddy current (PEC) time-domain characteristic signal corrosion classification method for the detection of the state of a pole tower grounding body. The method firstly theoretically analysed the influence of multi-parameter changes on the PEC response time-domain feature signal caused by grounding body corrosion and extracts the decay time constant (DTC), and the decay time constant stabilization value (DTCSV) and time to stabilization (TTS) were obtained based on the DTC time domain characteristics for describing the corrosion of the grounding body. Subsequently, DTCSV and TTS were used as inputs to a support vector machine (SVM) to classify the corrosion of the grounding body. A simulation model was constructed to investigate the effect of multiparameter time on the DTCSV and TTS of the tower grounding body based on the single-variable method, and the multiparameter time-domain characterization method used for corrosion assessment was validated. Four defects with different corrosion levels were classified using the optimized SVM model, with an accuracy rate of 95%. Finally, a PEC inspection system platform was built to conduct classification tests on steel bars with different degrees of corrosion, and the results show that the SVM classification model based on DTCSV and TTS has a better discriminatory ability for different corrosive grounders and can be used to classify corrosion in the grounders of poles towers to improve the stability of power transmission. Full article

Flexible DC power grids are widely recognized as an important component of building smart grids. Compared with traditional AC power grids, flexible DC power grids have strong technical advantages in islanding power supplies, distributed power supplies, regional power supplies, and AC system interconnection. In multi-terminal flexible DC power grids containing renewable energy sources such as solar and wind power, due to the instability and intermittency of renewable energy, it is usually necessary to add energy storage units to pre-regulate the power of the multi-terminal flexible DC power grid in islanded operation. Aiming at the important problem of large current impact and serious consequences when the flexible DC distribution network fails, a combined location method combining an improved impedance method (series current-limiting reactors at both ends of the line to obtain a more accurate current differential value) and a particle swarm optimization algorithm is proposed. Initially, by establishing the enhanced impedance model, the differential variables under the conditions of inter-electrode short-circuit and single-pole grounding fault can be obtained. Then tailor-made fitness functions are designed for these two models to optimize parameter identification. Subsequently, the iterative parameters of the particle swarm optimization algorithm are fine-tuned, giving it dynamic sociality and self-learning ability in the iterative process, which significantly improves the convergence speed and successfully avoids local optimization. Finally, various fault types in a six-terminal DC distribution network are simulated and analyzed by MATLAB, and the results show that this method has good accuracy and robustness. This research provides strong theoretical and methodological support for improving the safety and reliability of DC distribution systems. Full article

The single pole-to-ground (SPG) fault is one of critical failures which will have a serious impact on the stable operation of the multi-terminal DC distribution network based on the modular multilevel converter (MMC). It is very significant to analyze fault characteristics for detecting faults and protection design. This paper established the DC SPG fault model, which showed that in the presence of a reactor, the short-circuit current was reduced from 2.3 kA to 1 kA at 6 ms after the fault. Then, a novel SPG fault protection strategy was proposed, which detected the current derivative in connection transformer grounding branch. When the value increases past the threshold of current derivative, small resistance was switched on to increase fault current. Thus, the reliability of differential protection was enhanced. Compared with the traditional protection method, the proposed method does not need communication, and improved the speed of protection. Finally, the simulation model was established in PSCAD/EMTDC. The model included three converter stations: T1, T2 and T3. Among them, T1 outputs power, and T2 and T3 receive power. The results of RTDS showed that the DC circuit breaker operated within 3 ms, the three-port circuit breaker worked within 50 ms, which proves that the proposed strategy was effective. At this time, the system switched from the T1–T2–T3 three-terminal networking operation mode to the T1–T2 two-terminal hand-in-hand operation mode. Since the T3 terminal no longer received power, the transmission power of the T1 terminal decreased, and the received power of the T2 terminal remained unchanged. Full article

Most of the fault location methods in high voltage direct current (HVDC) transmission lines usemethods which require signals from both ends. It will be difficult to estimate fault location if the signal recorded is not correct due to communication problems.Hence a robust method is required which can locate fault with minimum error. In this work, faults are located using boosting ensembles in HVDC transmission lines based on single terminal direct current (DC) signals. The signals are processed to obtain input features that vary with the fault distance. These input features are obtained by taking maximum of half cycle current signals after fault and minimum of half cycle voltage signals after fault from the root mean square of DC signals. The input features are input to a boosting ensemble for estimating the location of fault. Boosting ensemble method attempts to correct the errors from the previous models and find outputs by combining all models. The boosting ensemble method has been also compared with the decision tree method and thebagging-based ensemble method. Fault locations are estimated using three methods and compared to obtain an optimal method. The boosting ensemble method has better performance than all the other methods in locating the faults. It also validated varying fault resistance, smoothing reactors, boundary faults, pole to ground faults and pole to pole faults. The advantage of the method is that no communication link is needed. Another advantage is that it allowsreach setting up to 99.9% and does not exhibitthe problem of over-fitting. Another advantage is that the percentage error in locating faults is within 1% and has a low realization cost. The proposed method can be implemented in HVDC transmission lines effectively as an alternative to overcome the drawbacks of traveling wave methods. Full article

The true bipolar modular multilevel converter-based multi-terminal direct current (MMC-MTDC) DC transmission line is prone to single-pole grounding fault, which may cause overload and overcurrent of the non-fault DC line with fault poles, resulting in system protection misoperation and system collapse. Therefore, the power transfer control strategy should be adopted to improve system stability. In addition, considering that the commutator stations of true bipolar MMC-MTDC system may have unipolar faults, it is necessary to adopt the control strategy of inter-pole power transfer or inter-station power transfer to improve the transmission capacity of the system under fault conditions. In this paper, a power transfer control strategy is proposed, which is widely applicable to MMC-MTDC system. In the case of line fault, the power transfer takes into account the line power margin and the power margin of converter station. The inter-pole power transfer is better than the inter-station power transfer under the converter station fault condition, and the inter-station power transfer takes into account the priority of the power margin of the converter station. At the same time, based on the Zhangbei four-terminal flexible direct current transmission project, the Zhangbei four-terminal flexible direct current transmission system is built by using PSCAD/EMTDC, and the flexibility and effectiveness of the proposed strategy are verified by simulation. Full article

This paper presents an advanced adaptive single-pole auto-reclosing (ASPAR) scheme based on harmonic characteristics of the secondary arc voltage. For analysis of the harmonics, short-time Fourier transform (STFT), which is a universal signal processing tool for transforming a signal from the time domain to the frequency domain, is utilized. STFT is applied to extract the abnormal harmonic signature from the voltage waveform of a faulted phase when a transient or permanent fault occurs on a power transmission line. The proposed scheme uses the total harmonic distortion (THD) factor to determine the fault type based on the variation and distortion characteristics of the harmonics. Harmonic components in the order of odd/even are also utilized to detect the secondary arc extinction time and guide the reclosing operation. Based on these factors, two coordinated algorithms are proposed to reduce the unnecessary dead time in conventional auto-reclosing methods and enable an optimal reclosing operation in the event of a single-pole to ground fault. The proposed ASPAR scheme is implemented using the electromagnetic transient program (EMTP), and various simulations are conducted for actual 345 and 765 kV Korean study systems. Full article

The design of every power supply system must guarantee the safety for human life even in the event of a fault. Due to the system change in the electrical power supply, the fault current contains more and more unknown shares of current harmonics. Especially in medium voltage grids, which are operated with resonant grounding, these are determining for the level of the single-pole ground fault current for determination of permissible touch voltages and compliance with the normative requirements of the European standard EN 50522 must therefore be re-evaluated. In its first part, this concept paper presents the frequency dependent principles of earth loops formed by the grounding system. The focus here is on cabled grids and the influence of connected structures of the low voltage grid. The second part deals with the superposition of these loop currents and the resulting earth currents in case of a line to ground fault. The authors address explicitly the frequency dependence of the current distribution and describe the expected behaviour for current harmonics. The proposed approaches result from processing the state of knowledge, research work and the evaluation of several measurements. The aim is to develop an understanding of the influence of the components connected to a grounding system and to derive generally applicable principles. Therefore, the authors present the results of recent measurements in the last part of the handed paper and point out the possibilities and limits of modeling. It is shown that a dedicated treatment of harmonic currents in the case of a single-pole fault is possible with the methods described. This allows these to be neglected in the estimation of touch voltages under specified circumstances, saving costs for the assessment of grounding systems. Full article

The probability of a single pole-to-ground fault in high voltage direct current (HVDC) transmission lines is relatively high. For the modular multilevel converter HVDC (MMC-HVDC) systems, when a single pole-to-ground fault occurs, the fault current is small, and it is difficult to identify the fault quickly. Through a detailed analysis of the characteristics of the single pole-to-ground fault of the MMC-HVDC transmission line, it is found that the single pole-to-ground fault has obvious capacitance-related characteristics, and the transient process after the single pole-to-ground fault is the discharge process of the distributed capacitance of the line. However, other faults do not have such obvious capacitance-related characteristics. Based on such feature, this paper proposes a novel capacitive fuzzy identification method to identify the single pole-to-ground fault. This algorithm can effectively identify both the fault of single pole-to-ground and the fault pole, which can contribute to the large database of the future smart grid. Full article

Protection based on transient information is the primary protection of high voltage direct current (HVDC) transmission systems. As a major part of protection function, accurate identification of transient surges is quite crucial to ensure the performance and accuracy of protection algorithms. Recognition of transient surges in an HVDC system faces two challenges: signal distortion and small number of samples. Entropy, which is stable in representing frequency distribution features, and support vector machine (SVM), which is good at dealing with samples with limited numbers, are adopted and combined in this paper to solve the transient recognition problems. Three commonly detected transient surges—single-pole-to-ground fault (GF), lightning fault (LF), and lightning disturbance (LD)—are simulated in various scenarios and recognized with the proposed method. The proposed method is proved to be effective in both feature extraction and type classification and shows great potential in protection applications. Full article
