A comprehensive investigation of hydrogen grabbing towards the formation of hetero-clusters of AlGaN–H, Si–AlGaN–H, Ge–AlGaN–H, Pd–AlGaN–H, and Pt–AlGaN–H was carried out using DFT computations at the CAM–B3LYP–D3/6-311+G (d,p) level of theory. The notable fragile signal intensity close to the parallel edge of the nanocluster sample might be owing to silicon or germanium binding-induced non-spherical distribution of Si–AlGaN or Ge–AlGaN hetero-clusters. Based on TDOS, the excessive growth technique of doping silicon, germanium, palladium, or platinum is a potential approach to designing high-efficiency hybrid semipolar gallium nitride devices in a long-wavelength zone. Therefore, it can be considered that palladium or platinum atoms in the functionalized Pd–AlGaN or Pt–AlGaN might have more impressive sensitivity for accepting the electrons in the process of hydrogen adsorption. The advantages of platinum or palladium over aluminum gallium nitride include its higher electron and hole mobility, allowing platinum or palladium doping devices to operate at higher frequencies than silicon or germanium doping devices. In fact, it can be observed that doped hetero-clusters of Pd–AlGaN or Pt–AlGaN might ameliorate the capability of AlGaN in transistor cells for energy storage. Full article

AlN epilayers were grown on magnetron-sputtered (MS) (11–22) AlN buffers on m-plane sapphire substrates at 1450 °C via hydride vapour phase epitaxy (HVPE). The MS buffers were annealed at high temperatures of 1400–1600 °C. All the samples were characterised using X-ray diffraction, atomic force microscopy, scanning electron microscope and Raman spectrometry. The crystal quality of epilayers regrown by HVPE was improved significantly compared to that of the MS counterpart. With an increasing annealing temperature, the crystal quality of both MS buffers and AlN epilayers measured along [11–23] and [1–100] improved first and then decreased, maybe due to the decomposition of MS buffers, while the corresponding anisotropy along the two directions decreased first and then increased. The optimum quality of the AlN epilayer was obtained at the annealing temperature of around 1500 °C. In addition, it was found that the anisotropy for the epilayers decreased significantly compared to that of annealed MS buffers when the annealing temperature was below 1500 °C. Full article

Nonpolar (11$\overline{2}$0) a-plane GaN films were grown on semipolar (1$\overline{1}$02) r-plane sapphire substrates using various buffer layers within a low-pressure metal organic chemical vapor deposition system. The structural properties of nonpolar a-plane GaN films were intensively investigated by X-ray diffraction and Raman spectra measurements. A set of buffer layers were adopted from a GaN layer to a composite layer containing a multiple AlN layers and a gradually varied-Al-content AlGaN layer, the full width at half maximum of the X-ray rocking curves measured along the [0001] and [10$\overline{1}$0] directions of a-plane GaN were reduced by 35% and 37%, respectively. It was also found that the basal-plane stacking faults (BSFs) density can be effectively reduced by the heterogeneous interface introduced together with the composite buffer layer. An order of magnitude reduction in BSFs density, as low as 2.95 × 10⁴ cm⁻¹, and a pit-free surface morphology were achieved for the a-plane GaN film grown with the composite buffer layer, which is promising for the development of nonpolar GaN-based devices in the future. Full article

Semipolar AlGaN multiple quantum wells (MQWs) have unique advantages in deep ultraviolet light emitters due to the weak Quantum-Confined Stark Effect. However, their applications are hampered by the poor crystalline quality of semipolar AlGaN thin films. Different treatments were developed to improve the crystal quality of semipolar AlGaN, including a multistep in situ thermal annealing technique proposed by our group. In this work, temperature-dependent and time-resolved photoluminescence characterizations were performed to reveal the carrier localization in the MQW region. The degree of carrier localization in semipolar AlGaN MQWs grown on top of the in situ-annealed AlN is similar to that of conventional ex situ face-to-face annealing, both of which are significantly stronger than that of the c-plane counterpart. Moreover, MQWs on in situ-annealed AlN show drastically reduced dislocation densities, demonstrating its great potential for the future development of high-efficiency optoelectronic devices. Full article

In this work, the growth mechanism of aluminum nitride (AlN) epitaxial films by hydride vapor phase epitaxy (HVPE) on silicon carbide (SiC) epitaxial layers grown on silicon (110) substrates is investigated. The peculiarity of this study is that the SiC layers used for the growth of AlN films are synthesized by the method of coordinated substitution of atoms. In this growth method, a part of the silicon atoms in the silicon substrate is replaced with carbon atoms. As a result of atom substitution, the initially smooth Si(110) surface transforms into a SiC surface covered with octahedron-shaped structures having the SiC(111) and SiC($11\overline{1}$) facets. The SiC(111)/($11\overline{1}$) facets forming the angle of 35.3° with the original Si(110) surface act as “substrates” for further growth of semipolar AlN. The structure and morphology of AlN films are investigated by X-ray diffraction (XRD), scanning electron microscopy (SEM), reflection high-energy electron diffraction (RHEED) and Raman spectroscopy. It is found that the AlN layers are formed by merged hexagonal microcrystals growing in two directions, and the following relation is approximately satisfied for both crystal orientations: AlN($10\overline{1}3$)||Si(110). The full-width at half-maximum (FWHM) of the X-ray rocking curve for the AlN($10\overline{1}3$) diffraction peak averaged over the sample area is about 20 arcmin. A theoretical model explaining the presence of two orientations of AlN films on hybrid SiC/Si(110) substrates is proposed, and a method for controlling their orientation is presented. Full article

In this work, the epitaxial semipolar (11–22) AlN was prepared on nonpolar m-sapphire substrate by combining sputtering and high-temperature annealing. According to our systematic measurements and analysis from XRD, Raman spectra, and AFM, the evolution of crystalline structure and morphology was investigated upon increasing AlN thickness and annealing duration. The annealing operation intensively resets the lattice and improves the crystalline quality. By varying the film thickness, the contribution from the AlN-sapphire interface on crystalline quality and lattice parameters during the annealing process was investigated, and its contribution was found to be not so obvious when the thickness increased from 300 nm to 1000 nm. When the annealing was performed under durations from 1 to 5 h, the crystalline quality was found unchanged; meanwhile, the evolution of morphology was pronounced, and it means the crystalline reorganization happens prior to morphology reset. Finally, the annealing treatment enabled a zig-zag morphology on the AlN template along the sapphire [0001] direction in the plane, which potentially affects the subsequent device epitaxy process. Therefore, our results act as important experience for the semipolar nitride semiconductor laser device preparation, particularly for the epitaxy of microcavity structure through providing the crystalline evolution. Full article

High-quality AlN film is a key factor affecting the performance of deep-ultraviolet optoelectronic devices. In this work, high-temperature annealing technology in a nitrogen atmosphere was used to improve the quality of AlN films with different polarities grown by magnetron sputtering. After annealing at 1400–1650 °C, the crystal quality of the AlN films was improved. However, there was a gap between the quality of non-polar and polar films. In addition, compared with the semi-polar film, the quality of the non-polar film was more easily improved by annealing. The anisotropy of both the semi-polar and non-polar films decreased with increasing annealing temperature. The results of Raman spectroscopy, scanning electron microscopy and X-ray photoelectron spectroscopy revealed that the annihilation of impurities and grain boundaries during the annealing process were responsible for the improvement of crystal quality and the differences between the films with different polarities. Full article

We have investigated the effect of high-temperature nitridation and buffer layer on the semi-polar aluminum nitride (AlN) films grown on sapphire by hydride vapor phase epitaxy (HVPE). It is found the high-temperature nitridation and buffer layer at 1300 °C are favorable for the formation of single (10–13) AlN film. Furthermore, the compressive stress of the (10–13) single-oriented AlN film is smaller than polycrystalline samples which have the low-temperature nitridation layer and buffer layer. On the one hand, the improvement of (10–13) AlN crystalline quality is possibly due to the high-temperature nitridation that promotes the coalescence of crystal grains. On the other hand, as the temperature of nitridation and buffer layer increases, the contents of N-Al-O and Al-O bonds in the AlN film are significantly reduced, resulting in an increase in the proportion of Al-N bonds. Full article

Since the first demonstration of (Al, In, Ga)N-based blue vertical-cavity surface-emitting lasers (VCSELs) in 2008, the maximum output power (P_max) and threshold current density (J_th) has been improved significantly after a decade of technology advancements. This article reviewed the key challenges for the realization of VCSELs with III-nitride materials, such as inherent polarization effects, difficulties in distributed Bragg’s reflectors (DBR) fabrication for a resonant cavity, and the anti-guiding effect due to the deposited dielectrics current aperture. The significant tensile strain between AlN and GaN hampered the intuitive cavity design with two epitaxial DBRs from arsenide-based VCSELs. Therefore, many alternative cavity structures and processing technologies were developed; for example, lattice-matched AlInN/GaN DBR, nano-porous DBR, or double dielectric DBRs via various overgrowth or film transfer processing strategies. The anti-guiding effect was overcome by integrating a fully planar or slightly convex DBR as one of the reflectors. Special designs to limit the emission polarization in a circular aperture were also summarized. Growing VCSELs on low-symmetry non-polar and semipolar planes discriminates the optical gain along different crystal orientations. A deliberately designed high-contrast grating could differentiate the reflectivity between the transverse-electric field and transverse-magnetic field, which restricts the lasing mode to be the one with the higher reflectivity. In the future, the III-nitride based VCSEL shall keep advancing in total power, applicable spectral region, and ultra-low threshold pumping density with the novel device structure design and processing technologies. Full article

Aluminum nitride (AlN) films were grown on the m-plane sapphire by high-temperature hydride vapor phase epitaxy (HVPE). The effect of high-temperature nitridation on the quality of AlN film was studied. The high-temperature nitridation is favorable for the formation of semi-polar single (10$\overline{1}$3) orientation AlN film, the quality of which shows strong dependence on the nitridation temperature. The full width at half maximum of X-ray diffraction for (10$\overline{1}$3) AlN film was only 0.343° at the optimum nitridation temperature of 1300 °C. It is found that the nano-holes were formed on the surface of substrates by the decomposition of sapphire in the process of high-temperature nitridation, which is closely related to the quality improvement of AlN. At the critical nitridation temperature of 1300 °C, the average size of the nano-holes is about 70 nm, which is in favor of promoting the rapid coalescence of AlN micro-grains in the early stages. However, the size of nano-holes will be enlarged with the further increase of nitridation temperature, which begins to play a negative role in the coalescence of AlN grains. As a result, the grain size will be increased and extended to the epilayer, leading to the deterioration of the AlN film. Full article

In this paper, we present the results of a computational analysis of continuous-wave (CW) room-temperature (RT) semipolar InGaN/GaN edge-emitting lasers (EELs) operating in the green spectral region. In our calculations, we focused on the most promising materials and design solutions for the cladding layers, in terms of enhancing optical mode confinement. The structural modifications included optimization of top gold metalization, partial replacement of p-type GaN cladding layers with ITO and introducing low refractive index lattice-matched AlInN or plasmonic GaN regions. Based on our numerical findings, we show that by employing new material modifications to green EELs operating at around 540 nm it is possible to decrease their CW RT threshold current densities from over 11 kA/cm² to less than 7 kA/cm². Full article

The polarization fields and electro-optical response of PIN-diodes based on nearly lattice-matched InGaN/GaN and InAlN/GaN double heterostructure quantum wells grown on (0001) sapphire substrates by metalorganic vapor phase epitaxy were experimentally quantified. Dependent on the indium content and the applied voltage, an intense near ultra-violet emission was observed from GaN (with fundamental energy gap E_g = 3.4 eV) in the electroluminescence (EL) spectra of the InGaN/GaN and InAlN/GaN PIN-diodes. In addition, in the electroreflectance (ER) spectra of the GaN barrier structure of InAlN/GaN diodes, the three valence-split bands, Γ₉, Γ₇₊, and Γ₇₋, could selectively be excited by varying the applied AC voltage, which opens new possibilities for the fine adjustment of UV emission components in deep well/shallow barrier DHS. The internal polarization field E_pol = 5.4 ± 1.6 MV/cm extracted from the ER spectra of the In_0.21Al_0.79N/GaN DHS is in excellent agreement with the literature value of capacitance-voltage measurements (CVM) E_pol = 5.1 ± 0.8 MV/cm. The strength and direction of the polarization field E_pol = −2.3 ± 0.3 MV/cm of the (0001) In_0.055Ga_0.945N/GaN DHS determined, under flat-barrier conditions, from the Franz-Keldysh oscillations (FKOs) of the electro-optically modulated field are also in agreement with the CVM results E_pol = −1.2 ± 0.4 MV/cm. The (absolute) field strength is accordingly significantly higher than the E_pol strength quantified in published literature by FKOs on a semipolar $\left(11\overline{2}2\right)$ oriented In_0.12Ga_0.88N quantum well. Full article

Through comparing ZnO directly grown on the substrates of a-plane, c-plane, and (11-22) plane GaN and Al_xGa_1−xN (0.06 ≤ x ≤ 1), the roles of different factors that may influence growth have been studied. Seeded by surface pits, ZnO nanowire (NW) preferentially grew along the polarized direction on top of the nonpolar GaN (laterally aligned), polar GaN and AlGaN (vertically aligned), and semipolar GaN (obliquely upward aligned). Nanosheets were easily formed when the polarized surface of the AlGaN film was not intact. The kinetic effect of polarization must be considered to explain the high aspect ratio of NWs along the polarized direction. It was found that dislocation affected NW growth through the surface pits, which provided excellent nucleation sites. If the surface pits on GaN could be controlled to distribute uniformly, self-organized ZnO NW array could be controllably and directly grown on GaN. Moreover, surface pits could also seed for nanosheet growth in AlN, since Al(OH)₄⁻ would presumably bind to the Zn²⁺ terminated surface and suppress the kinetic effects of polarization. Full article
