This study presents an algorithm for non-invasive blood pressure (BP) estimation in neonates using photoplethysmography (PPG), suitable for resource-constrained neonatal telecare platforms. Using the Windkessel model, the algorithm processes PPG signals from a MAX 30102 sensor, (Analog Devices (formerly Maxim Integrated), based in San Jose, CA, USA) filtering motion noise and extracting cardiac cycle time and systolic time (ST). These parameters inform a derived blood flow signal, the input for the Windkessel model. Calibration utilizes average parameters based on the newborn’s post-conceptional age, weight, and gestational age. Performance was validated against readings from a standard non-invasive BP cuff at SES Hospital Universitario de Caldas. Two parameter estimation methods were evaluated. The first yielded root mean square errors (RMSEs) of 24.14 mmHg for systolic and 19.13 mmHg for diastolic BP. The second method significantly improved accuracy, achieving RMSEs of 2.31 mmHg and 5.13 mmHg, respectively. The successful adaptation of the Windkessel model to single PPG signals allows for BP calculation alongside other physiological variables within the telecare program. A device analysis was conducted to determine the appropriate device based on computational capacity, availability of programming tools, and ease of integration within an Internet of Things environment. This study paves the way for future research that focuses on parameter variations due to cardiovascular changes in newborns during their first month of life. Full article

This study represents a first step toward improving the repeatability, reproducibility, and accuracy of a process designed to enhance dynamic water structuring. We aim is to investigate the optical reflectivity of a watery magnesium chloride solution treated with electromagnetic waves, we employ a novel methodology derived from human plethysmography (PPG) with three wavelengths spanning the visible and infrared spectra. We measured the reflectance of 17 flasks at 536 nm, 660 nm, and 940 nm before and after treatment, first using the succussion method (control) and second using a 50 Hz signal. The observed variability was acceptable, with repeatability errors below 0.15% and reproducibility errors below 3.5% across all wavelengths before and after treatment. Out of 51 samples dynamically structured using the succussion method, we obtained two false negatives, while one false negative was recorded out of 51 samples dynamically structured using the electromagnetic (EM) method. PPG appears to be a relevant sensor, as it correctly detected dynamically structured water in 99 out of 102 cases, using either the succussion or electromagnetic method. Our results show significant differences in reflectance (supposedly correlated with water’s structured status) at 536 nm between dynamically structured and dynamic non-structured samples (p < 0.001). Future improvements will include a validation protocol against gold-standard spectrophotometry with a larger sample size. Full article

Asymptomatic peripheral artery disease (PAD) poses a silent risk, potentially leading to severe conditions if undetected. Integrating new screening tools into routine general practitioner (GP) visits could enable early detection. This study investigates the feasibility of photoplethysmography (PPG) monitoring for assessing vascular health across different blood pressure (BP) conditions. Custom femoral artery phantoms representing healthy (0.82 MPa), intermediate (1.48 MPa), and atherosclerotic (2.06 MPa) vessels were tested under hypertensive, normotensive, and hypotensive conditions to evaluate PPG’s ability to distinguish between vascular states. Extracted features from the PPG signal, including amplitude, area under the curve (AUC), median upslope–downslope ratio, and median end datum difference, were analysed. Kruskal–Wallis tests revealed significant differences between healthy and unhealthy vessels across BP states, supporting PPG as a screening tool. The fiducial points from the second derivative of the photoplethysmography signal (SDPPG) were analysed. The ${\displaystyle \frac{b}{a}}$ ratio was most pronounced between healthy and unhealthy phantoms under hypertensive conditions (ranging from –2.13 to –2.06), suggesting a change in vascular wall distensibility. Under normotensive conditions, the difference in ${\displaystyle \frac{b}{a}}$ ratios between healthy and unhealthy phantoms was smaller (0.01), and no meaningful difference was observed under hypotensive conditions, suggesting the reduced sensitivity of this metric at lower perfusion pressures. Intermediate states were challenging to detect, particularly under hypotension, suggesting a need for further research. Nonetheless, this study highlights the promise of PPG monitoring in identifying vascular stiffness. Full article

Blood pressure measurement is a key indicator of vascular health and a routine part of medical examinations. Given the ability of photoplethysmography (PPG) signals to provide insights into the microvascular bed and their compatibility with wearable devices, significant research has focused on using PPG signals for blood pressure estimation. This study aimed to identify specific clinical PPG features that vary with different blood pressure levels. Through a literature review of 297 publications, we selected 16 relevant studies and identified key time-dependent PPG features associated with blood pressure prediction. Our analysis highlighted the second derivative of PPG signals, particularly the $b/a$ and $d/a$ ratios, as the most frequently reported and significant predictors of systolic blood pressure. Additionally, features from the velocity and acceleration photoplethysmograms were also notable. In total, 29 features were analyzed, revealing novel temporal domain features that show promise for further research and application in blood pressure estimation. Full article

The paper describes a method developed for the indirect cuffless estimation of arterial blood pressure (ABP) from two/three-channel photoplethysmography (PPG) signals. It is important when the actual ABPs cannot be measured, e.g., during scanning inside a magnetic resonance imager. The proposed procedure uses heart pulse transmission parameters (HPTPs) extracted from the second derivative PPG signals. The linear regression method was used to calculate the relation between the determined HPTPs and the ABPs measured in parallel by a blood pressure monitor. The ABP values were estimated by the inverse conversion characteristic calculated from these linear relations. Three auxiliary investigations were performed first to find appropriate settings for PPG signal processing. We tested the accuracy of ABP estimation using two small corpora of multi-channel PPG records sensed during our previous experiments. We also analyzed the distribution of the determined HPTP values depending on the hand and gender for the mapping of a mutual relationship of HPTPs and measured ABPs. The final estimation errors were evaluated graphically (by correlation scatter plots and Bland–Altman plots) and numerically (by a correlation coefficient between the measured and estimated ABPs and by enumeration of the relative estimation error). The obtained results achieve acceptable mean values of −2.6/−3.5 mm Hg for systolic/diastolic ABPs. Full article

Considerable research has been devoted to developing machine-learning models for continuous Blood Pressure (BP) estimation. A challenging problem that arises in this domain is the selection of optimal features with interpretable models for medical professionals. The aim of this study was to investigate evidence-based physiologically motivating features based on a solid physiological background of BP determinants. A powerful and compact set of features encompassing six physiologically oriented features was extracted in addition to another set of features consisting of six commonly used features for comparison purposes. In this study, we proposed a BP predictive model using Long Short-Term Memory (LSTM) networks with multi-stage transfer learning approach. The proposed model topology consists of three cascaded stages. First, a BP classification stage. Second, a Mean Arterial Pressure (MAP) regression stage to further approximate a quantity proportional to Vascular Resistance (VR) using the extracted Cardiac Output (CO) from the PPG signal. Third, the main BP estimation stage. The final stage (final BP prediction) is able to exploit embedded correlations between BP and the proposed features along with derived outputs carrying hemodynamic characteristics through the sub-sequence stages. We also constructed traditional single-stage Artificial Neural Network (ANN) and LSTM-based models to appraise the performance gain of our proposed model. The models were tested and evaluated on 40 subjects from the MIMIC II database. The LSTM-based multi-stage model attained a MAE ± SD of 2.03 ± 3.12 for SBP and 1.18 ± 1.70 mmHg for DBP. The proposed set of features resulted in drastic error reduction, of up to 86.21%, compared to models trained on the commonly used features. The superior performance of the proposed multi-stage model provides confirmatory evidence that the selected transferable features among the stages coupled with the high-performing multi-stage topology enhance blood pressure estimation accuracy using PPG signals. This indicates the compelling nature and sufficiency of the proposed efficient features set. Full article

The paper describes the development, testing, and verification of practical usability of the indirect cuffless method for estimation of arterial blood pressure (ABP) values from the photo-plethysmography (PPG) signal sensed by the optical PPG sensor. The proposed procedure uses time domain features (systolic/diastolic pulse time ratios and partial areas around the pulses) extracted from the second derivative of the PPG signal. The linear regression method is next used to calculate the relation between the determined PPG wave features and the blood pressure values measured in parallel using a blood pressure monitor. ABP values are finally estimated by the inverse conversion characteristic calculated from these linear relations. Summary estimation errors obtained from first-step experiments achieve acceptable values of about 8/3% for systolic/diastolic ABPs. However, further improvements are necessary before usage of the proposed procedure. Full article

Pulse waves (PWs) are mechanical waves that propagate from the ventricles through the whole vascular system as brisk enlargements of the blood vessels’ lumens, caused by sudden increases in local blood pressure. Photoplethysmography (PPG) is one of the most widespread techniques employed for PW sensing due to its ability to measure blood oxygen saturation. Other sensors and techniques have been proposed to record PWs, and include applanation tonometers, piezoelectric sensors, force sensors of different kinds, and accelerometers. The performances of these sensors have been analyzed individually, and their results have been found not to be in good agreement (e.g., in terms of PW morphology and the physiological parameters extracted). Such a comparison has led to a deeper comprehension of their strengths and weaknesses, and ultimately, to the consideration that a multimodal approach accomplished via sensor fusion would lead to a more robust, reliable, and potentially more informative methodology for PW monitoring. However, apart from various multichannel and multi-site systems proposed in the literature, no true multimodal sensors for PW recording have been proposed yet that acquire PW signals simultaneously from the same measurement site. In this study, a true multimodal PW sensor is presented, which was obtained by integrating a piezoelectric forcecardiography (FCG) sensor and a PPG sensor, thus enabling simultaneous mechanical–optical measurements of PWs from the same site on the body. The novel sensor performance was assessed by measuring the finger PWs of five healthy subjects at rest. The preliminary results of this study showed, for the first time, that a delay exists between the PWs recorded simultaneously by the PPG and FCG sensors. Despite such a delay, the pulse waveforms acquired by the PPG and FCG sensors, along with their first and second derivatives, had very high normalized cross-correlation indices in excess of 0.98. Six well-established morphological parameters of the PWs were compared via linear regression, correlation, and Bland–Altman analyses, which showed that some of these parameters were not in good agreement for all subjects. The preliminary results of this proof-of-concept study must be confirmed in a much larger cohort of subjects. Further investigation is also necessary to shed light on the physical origin of the observed delay between optical and mechanical PW signals. This research paves the way for the development of true multimodal, wearable, integrated sensors and for potential sensor fusion approaches to improve the performance of PW monitoring at various body sites. Full article

High blood pressure is one of the most important precursors for Cardiovascular Diseases (CVDs), the most common cause of death in 2020, as reported by the World Health Organization (WHO). Moreover, many patients affected by neurodegenerative diseases (e.g., Parkinson’s Disease) exhibit impaired autonomic control, with inversion of the normal circadian arterial pressure cycle, and consequent augmented cardiovascular and fall risk. For all these reasons, a continuous pressure monitoring of these patients could represent a significant prognostic factor, and help adjusting their therapy. However, the existing cuff-based methods cannot provide continuous blood pressure readings. Our work is inspired by the newest approaches based on the photoplethysmographic (PPG) signal only, which has been used to continuously estimate systolic blood pressure (SP), using artificial neural networks (ANN), in order to create more compact and wearable devices. Our first database was derived from the PhysioNet resource; we extracted PPG and arterial blood pressure (ABP) signals, collected at a sampling frequency of 125 Hz, in a hospital environment. It consists of 249,672 PPG periods and the relative SP values. The second database was collected at STMicroelectronics s.r.l., in Agrate Brianza, using the MORFEA3 wearable device and a digital cuff-based sphygmomanometer, as reference. The pre-processing phase, in order to remove noise and motion artifacts and to segment the signal into periods, was carried out on Matlab R2019b. The noise removal was one of the challenging parts of the study because of the inaccuracy of the PPG signal during everyday-life activity, and this is the reason why the MORFEA3 dataset was acquired in a controlled environment in a static position. Different solutions were implemented to choose the input features that best represent the period morphology. The first database was used to train the multilayer feed-forward neural network with a back-propagation model, whereas the second one was used to test it. The results obtained in this project are promising and match the Association for the Advancement of Medical Instruments (AAMI) and the British Hypertension Society (BHS) standards. They show a Mean Absolute Error of 3.85 mmHg with a Standard Deviation of 4.29 mmHg, under the AAMI standard, and reach the grade A under the BHS standard. Full article

Non-invasive measurement of physiological parameters and indicators, specifically among the elderly, is of utmost importance for personal health monitoring. In this study, we focused on photoplethysmography (PPG), and developed a regression model that calculates variables from the second (SDPPG) and third (TDPPG) derivatives of the PPG pulse that can observe the inflection point of the pulse wave measured by a wearable PPG device. The PPG pulse at the earlobe was measured for 3 min in 84 elderly Korean women (age: 71.19 ± 6.97 years old). Based on the PPG-based cardiovascular function, we derived additional variables from TDPPG, in addition to the aging variable to predict the age. The Aging Index (AI) from SDPPG and Sum of TDPPG variables were calculated in the second and third differential forms of PPG. The variables that significantly correlated with age were c/a, Tac, AI of SDPPG, sum of TDPPG, and correlation coefficient ‘r’ of the model. In multiple linear regression analysis, the r value of the model was 0.308, and that using deep learning on the model was 0.839. Moreover, the possibility of improving the accuracy of the model using supervised deep learning techniques, rather than the addition of datasets, was confirmed. Full article

Exploiting photoplethysmography signals (PPG) for non-invasive blood pressure (BP) measurement is interesting for various reasons. First, PPG can easily be measured using fingerclip sensors. Second, camera based approaches allow to derive remote PPG (rPPG) signals similar to PPG and therefore provide the opportunity for non-invasive measurements of BP. Various methods relying on machine learning techniques have recently been published. Performances are often reported as the mean average error (MAE) on the data which is problematic. This work aims to analyze the PPG- and rPPG based BP prediction error with respect to the underlying data distribution. First, we train established neural network (NN) architectures and derive an appropriate parameterization of input segments drawn from continuous PPG signals. Second, we use this parameterization to train NNs with a larger PPG dataset and carry out a systematic evaluation of the predicted blood pressure. The analysis revealed a strong systematic increase of the prediction error towards less frequent BP values across NN architectures. Moreover, we tested different train/test set split configurations which underpin the importance of a careful subject-aware dataset assignment to prevent overly optimistic results. Third, we use transfer learning to train the NNs for rPPG based BP prediction. The resulting performances are similar to the PPG-only case. Finally, we apply different personalization techniques and retrain our NNs with subject-specific data for both the PPG-only and rPPG case. Whilst the particular technique is less important, personalization reduces the prediction errors significantly. Full article

Since photoplethysmography (PPG) sensors are usually placed on open skin areas, temperature interference can be an issue. Currently, green light is the most widely used in the reflectance PPG for its relatively low artifact susceptibility. However, it has been known that hemoglobin absorption peaks at the blue part of the spectrum. Despite this fact, blue light has received little attention in the PPG field. Blue wavelengths are commonly used in phototherapy. Combining blue light-based treatments with simultaneous blue PPG acquisition could be potentially used in patients monitoring and studying the biological effects of light. Previous studies examining the PPG in blue light compared to other wavelengths employed photodetectors with inherently lower sensitivity to blue, thereby biasing the results. The present study assessed the accuracy of heartbeat intervals (HBIs) estimation from blue and green PPG signals, acquired under baseline and cold temperature conditions. Our PPG system is based on TCS3472 Color Sensor with equal sensitivity to both parts of the light spectrum to ensure unbiased comparison. The accuracy of the HBIs estimates, calculated with five characteristic points (PPG systolic peak, maximum of the first PPG derivative, maximum of the second PPG derivative, minimum of the second PPG derivative, and intersecting tangents) on both PPG signal types, was evaluated based on the electrocardiographic values. The statistical analyses demonstrated that in all cases, the HBIs estimation accuracy of blue PPG was nearly equivalent to the G PPG irrespective of the characteristic point and measurement condition. Therefore, blue PPG can be used for cardiovascular parameter acquisition. This paper is an extension of work originally presented at the 42nd Annual International Conference of the IEEE Engineering in Medicine and Biology Society. Full article

According to the WTO, there were 1.13 billion hypertension patients worldwide in 2015. The WTO encouraged people to check the blood pressure regularly because a large amount of patients do not have any symptoms. However, traditional cuff measurement results are not enough to represent the patient′s blood pressure status over a period of time. Therefore, there is an urgent need for portable, easy to operate, continuous measurement, and low-cost blood pressure measuring devices. In this paper, we adopted the convolutional neural network (CNN), based on the Hilbert–Huang Transform (HHT) method, to predict blood pressure (BP) risk level using photoplethysmography (PPG). Considering that the PPG′s first and second derivative signals are related to atherosclerosis and vascular elasticity, we created a dataset called PPG+; the images of PPG+ carry information on PPG and its derivatives. We built three classification experiments by collecting 582 data records (the length of each record is 10 s) from the Medical Information Mart for Intensive Care (MIMIC) database: NT (normotension) vs. HT (hypertension), NT vs. PHT (prehypertension), and (NT + PHT) vs. HT; the F1 scores of the PPG + experiments using AlexNet were 98.90%, 85.80%, and 93.54%, respectively. We found that, first, the dataset established by the HHT method performed well in the BP grade prediction experiment. Second, because the Hilbert spectra of the PPG are simple and periodic, AlexNet, which has only 8 layers, got better results. More layers instead increased the cost and difficulty of training. Full article

Diabetes is a chronic illness that affects millions of people worldwide and requires regular monitoring of a patient’s blood glucose level. Currently, blood glucose is monitored by a minimally invasive process where a small droplet of blood is extracted and passed to a glucometer—however, this process is uncomfortable for the patient. In this paper, a smartphone video-based noninvasive technique is proposed for the quantitative estimation of glucose levels in the blood. The videos are collected steadily from the tip of the subject’s finger using smartphone cameras and subsequently converted into a Photoplethysmography (PPG) signal. A Gaussian filter is applied on top of the Asymmetric Least Square (ALS) method to remove high-frequency noise, optical noise, and motion interference from the raw PPG signal. These preprocessed signals are then used for extracting signal features such as systolic and diastolic peaks, the time differences between consecutive peaks (DelT), first derivative, and second derivative peaks. Finally, the features are fed into Principal Component Regression (PCR), Partial Least Square Regression (PLS), Support Vector Regression (SVR) and Random Forest Regression (RFR) models for the prediction of glucose level. Out of the four statistical learning techniques used, the PLS model, when applied to an unbiased dataset, has the lowest standard error of prediction (SEP) at 17.02 mg/dL. Full article

Animal welfare remains a very important issue in the livestock sector, but monitoring animal welfare in an objective and continuous way remains a serious challenge. Monitoring animal welfare, based upon physiological measurements instead of the audio–visual scoring of behaviour, would be a step forward. One of the obvious physiological signals related to welfare and stress is heart rate. The objective of this research was to measure heart rate (beat per minutes) in pigs with technology that soon will be affordable. Affordable heart rate monitoring is done today at large scale on humans using the Photo Plethysmography (PPG) technology. We used PPG sensors on a pig′s body to test whether it allows the retrieval of a reliable heart rate signal. A continuous wavelet transform (CWT)-based algorithm is developed to decouple the cardiac pulse waves from the pig. Three different wavelets, namely second, fourth and sixth order Derivative of Gaussian (DOG), are tested. We show the results of the developed PPG-based algorithm, against electrocardiograms (ECG) as a reference measure for heart rate, and this for an anaesthetised versus a non-anaesthetised animal. We tested three different anatomical body positions (ear, leg and tail) and give results for each body position of the sensor. In summary, it can be concluded that the agreement between the PPG-based heart rate technique and the reference sensor is between 91% and 95%. In this paper, we showed the potential of using the PPG-based technology to assess the pig′s heart rate. Full article
