In recent years, spaceborne Global Navigation Satellite System reflectometry (GNSS-R) technology has made significant progress in the fields of Earth observation and remote sensing, with a wide range of applications, important research value, and broad development prospects. However, despite existing research focusing on the application of spaceborne GNSS-R L1-level data, the potential value of raw intermediate-frequency (IF) signals has not been fully explored for special applications that require a high accuracy and spatiotemporal resolution. This article provides a comprehensive overview of the current status of the measurement of raw IF signals from spaceborne GNSS-R in multiple application fields. Firstly, the development of spaceborne GNSS-R microsatellites launch technology is introduced, including the ability of microsatellites to receive GNSS signals and receiver technique, as well as related frequency bands and technological advancements. Secondly, the key role of coherence detection in spaceborne GNSS-R is discussed. By analyzing the phase and amplitude information of the reflected signals, parameters such as scattering characteristics, roughness, and the shape of surface features are extracted. Then, the application of spaceborne GNSS-R in inland water monitoring is explored, including inland water detection and the measurement of the surface height of inland (or lake) water bodies. In addition, the widespread application of group delay sea surface height measurement and carrier-phase sea surface height measurement technology in the marine field are also discussed. Further research is conducted on the progress of spaceborne GNSS-R in the retrieval of ice height or ice sheet height, as well as tropospheric parameter monitoring and the study of atmospheric parameters. Finally, the existing research results are summarized, and suggestions for future prospects are put forward, including improving the accuracy of signal processing and reflection signal analysis, developing more advanced algorithms and technologies, and so on, to achieve more accurate and reliable Earth observation and remote sensing applications. These research results have important application potential in fields such as environmental monitoring, climate change research, and weather prediction, and are expected to provide new technological means for global geophysical parameter retrieval. Full article

In this paper, we discuss the results of hydroacoustic sounding in the frequency range of units of kHz, conducted during voyage No. 90 of the research vessel “Akademik Mstislav Keldysh”. The employment of a vertical antenna array and electronic phasing to the recorded data made it possible to determine both the reflection coefficient from the bottom at incidence close to normal, and the diffuse scattering coefficients at oblique angles for the surface and the bottom. Based on the processing of experimental data, and with the help of computer modeling, an analysis of the structure of hydroacoustic signals scattered by the bottom and free surface of water was carried out. An approach combining the Green’s function and the scattering function was used to model the reverberation signal. The models of formation of the Doppler spectrum of the scattered acoustic signal were refined, taking into account the influence of sound propagation conditions in the marine environment. The comparison of the results of experimental studies of bottom reverberation in the waters of the Barents and Kara Seas with numerical calculations of the ray structure of the acoustic field demonstrates good agreement. Full article

Statistical optimization methods serve as fundamental tools for studying sea-ice-related phenomena in the polar regions. To comprehensively analyze the spatial distributions of ice ridge keels, including the draft and spacing distributions, a statistical optimization model was developed with the aim of determining the optimal keel cutoff draft, which differentiates ice ridge keels from sea ice bottom roughness. By treating the keel cutoff draft as the identified variable and minimizing the relative errors between the theoretical and measured keel spatial distributions, the developed model aimed to seek the optimal keel cutoff draft and provide a precise method for this differentiation and to explore the impact of the ridging intensity, defined as the ratio of the mean ridge sail height to spacing, on the spatial distributions of the ice ridge keels. The utilized data were obtained from observations of sea ice bottom undulations in the Northwestern Weddell Sea during the winter of 2006; these observations were conducted using helicopter-borne electromagnetic induction (EM-bird). Through rigorous analysis, the optimal keel cutoff draft was determined to be 3.8 m, and this value was subsequently employed to effectively differentiate ridge keels from other roughness features on the sea ice bottom. Then, building upon our previous research that clustered measured profiles into three distinct regimes (Region 1, Region 2, and Region 3, respectively), a detailed statistical analysis was carried out to evaluate the influence of the ridging intensity on the spatial distributions of the ice ridge keels for all three regimes. Notably, the results closely matched the predictions of the statistical optimization model: Wadhams’80 function (a negative exponential function) exhibited an excellent fit with the measured distributions of the keel draft, and a lognormal function proved to effectively describe the keel spacing distributions in all three regimes. Furthermore, it was discovered that the relationship between the mean ridge keel draft and frequency (number of keels per kilometer) could be accurately modeled by a logarithmic function with a correlation coefficient of 0.698, despite considerable data scatter. This study yields several significant results with far-reaching implications. The determination of the optimal keel cutoff draft and the successful modeling of the relationship between the keel draft and frequency represent key achievements. These findings provide a solid theoretical foundation for analyzing the correlations between the morphologies of the sea ice surface and bottom. Such theoretical insights are crucial for improving remote sensing algorithms for ice thickness inversion from satellite elevation data, enhancing the accuracy of sea ice thickness estimations. Full article

This study centers on the development and characterization of an innovative electrochemical sensing probe composed of a sensing mesoporous functional sol–gel coating integrated onto a glassy carbon electrode (sol–gel/GCE) for the detection of NH₃ and/or NH₄⁺ in water. The main interest for integrating a functional sol–gel coating onto a GCE is to increase the selective and sensing properties of the GCE probe towards NH₃ and/or NH₄⁺ ions. The structure and surface morphology of the newly developed sol–gel/GCE probe were characterized employing scanning electron microscopy (SEM), atomic force microscopy (AFM), dynamic light scattering (DLS), and Fourier-transform infrared (FTIR), while the electrochemical sensing properties were evaluated by Berthelot’s reaction, cyclic voltammetry (CV), and adsorptive square wave–anodic striping voltammetry (Ads SW–ASV). It is shown that the newly developed sol–gel coating is homogeneously deposited on the GCE with a sub-micron and uniform thickness close to 630 nm and a surface roughness of 25 nm. The sensing testing of the sol–gel/GCE probe showed limits of detection and limits of quantitation of 1.7 and 5.56 nM of NH₄⁺, respectively, as well as a probe sensitivity of 5.74 × 10⁻¹ μA/μM cm⁻². The developed probe was fruitfully validated for the selective detection of NH₃/NH₄⁺ in fresh and sea water samples. Computed Student t_exp (0.45–1.25) and F_exp (1.69–1.78) (n = 5) tests were less than the theoretical t_tab (2.78) and F_tab (6.39) at 95% probability. Full article

This work presents a numerical study on atmospheric sound propagation over rough water surfaces with the aim of improving predictions of sound propagation over long distances. A method for generating pseudorandom sea profiles consistent with sea wave spectra is presented. The proposed method is suited for capturing the logarithmic nature of the energy distribution of the waves. Sea profiles representing fully developed seas for sea states 2, 3, 4, and 5 are generated from the Elfouhaily et al. (ECKV) sea wave spectra. Excess attenuation caused by refraction and surface roughness is predicted with a parabolic equation (PE) solver. A novel method for estimating equivalent effective impedance based on PE predictions at different sea states is presented. Parametric expressions using acoustic frequency and significant wave height are developed for effective surface impedances. In this work, sea surface roughness is on a scale comparable with the acoustic wavelength. Under this condition, the acoustic scattering is primarily incoherent. This work shows the limitations of using an equivalent surface impedance in such incoherent scattering cases. Full article

This paper proposes an Synthetic Aperture Radar (SAR) imaging and detection model of multiple targets at the maritime scene. The sea surface sample is generated according to the composite rough surface theory. The SAR imaging model is constructed based on a hybrid EM calculation approach with the fast ray tracing strategy and the modified facet Small Slope Approximation (SSA) solution. Numerical simulations calculate the EM scattering and the SAR imaging of the multiple cone targets above the sea surface, with the scattering mechanisms analyzed and discussed. The SAR imaging datasets are then set up by the SAR image simulations. A modified YOLOv7 neural network with the Spatial Pyramid Pooling Fast Connected Spatial Pyramid Convolution (SPPFCSPC) module, Convolutional Block Attention Module (CBAM), modified Feature Pyramid Network (FPN) structure and extra detection head is developed. In the training process on our constructed SAR datasets, the precision rate, recall rate, mAP@0.5 and mAP@0.5:0.95 are 97.46%, 90.08%, 92.91% and 91.98%, respectively, after 300 rounds of training. The detection results show that the modified YOLOv7 has a good performance in selecting the targets out of the complex sea surface and multipath interference background. Full article

While many studies have been conducted regarding wind-driven Ka-band scattering on the ocean and sea surfaces, few have identified the impacts of Ka-band scattering on small inland water bodies, and fewer have identified the influence of wind on coherence over water. These previous studies have been limited in spatial scale, covering only large water bodies >25 km². The recently launched Surface Water and Ocean Topography (SWOT) mission is the first Ka-band InSAR satellite designed for mapping water surface elevations and open water areas for rivers as narrow as 100 m and lakes as small as 0.0625 km². Because measurements of these types are novel, there remains some uncertainty about expected backscatter amplitudes given wind-driven water surface roughness variability. A previous study using the airborne complement to SWOT, AirSWOT, found that low backscatter and low coherence values were indicative of higher errors in the water surface elevation products, recommending minimum thresholds for backscatter and coherence for filtering the data to increase the accuracy of averaged data for lakes and rivers. We determined that the global average wind speed over lakes is 4 m/s, and after comparing AirSWOT backscatter and coherence data with ERA-5 wind speeds, we found that the minimum required speed to retrieve high backscatter and coherence is 3 m/s. We examined 11,072 lakes across Canada and Alaska, with sizes ranging from 350 m² to 156 km², significantly smaller than what could be measured with previous Ka-band instruments in orbit. We found that small lakes (0.0625–0.25 km²) have significantly lower backscatter (3–5 dB) and 0.20–0.25 lower coherence than larger lakes (>1 km²). These results suggest that approximately 75% of SWOT observable lake areas around the globe will have consistently high-accuracy water surface elevations, though seasonal wind variability should remain an important consideration. Despite very small lakes presenting lower average backscatter and coherence, this study asserts that SWOT will be able to accurately resolve the water surface elevations and water surface extents for significantly smaller water bodies than have been previously recorded from satellite altimeters. This study additionally lays the foundation for future high-resolution inland water wind speed studies using SWOT data, when the data become available, as the relationships between wind speed and Ka-band backscatter reflect those of traditional scatterometers designed for oceanic studies. Full article

Electromagnetic (EM) scattering of sea surface may exhibit sea-spikespikes when there exist breaking waves. As sea-spikes are usually mistaken for targets, the investigation of EM scattering characteristics and high-range resolution profiles (HRRPs) of three-dimensional (3D) sea surfaces with a plunging breaker is meaningful for target detection and recognition. To describe the basic features of a plunging breaker, this paper developed a feasible and wind-related plunging breaker model. Here, profiles of a plunging breaker in its life cycle are modeled according to the wind speed and time factor, and the small-scale roughness is considered. Then, the sea surface and plunging breaker are combined to obtain the composite model. Additionally, a hybrid algorithm based on the Capillary Wave Modification Facet Scattering Model (CWMFSM) and ray tracing technique is developed to calculate the EM scattering of 3D sea surface with a plunging breaker. Simulation results show that the sea-spike phenomenon is more likely to occur for the upwind and large incident angles. The amplitude of the backscattering electric field from the plunging breaker is much stronger than that of the sea surface. Furthermore, the HRRPs of 3D sea surface with a plunging breaker and target are computed. Sharp peaks from the plunging breaker that exhibit obvious target-like features are observed. Full article

In this paper, a weighted arctangent function is used in conjunction with the spectral method to generate a land–sea junction composite rough surface under the spatially homogeneous and time-stationary hypotheses. The exponential correlation function and the Joint North Sea Wave Project (JONSWAP) spectrum, combined with an experiment-verified shoaling coefficient, are applied to model the land surfaces and the time-varying sea surfaces separately. The second-order small slope approximation (SSA-II) with tapered wave incidence is utilized for evaluating the electromagnetic scattering characteristics and Doppler characteristics of the generated composite rough surface. The influence of land–sea interface factors on radar cross-section (RCS) and Doppler shift of radar echoes is investigated in detail by comparing the RCS and Doppler spectra of the land–sea junction composite rough surfaces with those of finite-depth sea surfaces. It can be found that the Doppler spectra of the land–sea junction composite rough surface is narrower than that of the finite-depth sea surface under upwind directions and wider than that of the finite-depth sea surface under crosswind directions. Full article

The Lambertian property of objects is one of the basic hypotheses in remote sensing research. However, the spectral radiance of natural objects is always anisotropic. On the sea surface, a large amount of sea foam is generated at the water–air interface, induced by wind speed and breaking gravity waves. Additionally, the scattering characteristic at the water–air interface significantly influences the accuracy of ocean color remote sensing and its output. The bidirectionality of the water light field is one of the sources of errors in ocean color inversion. Therefore, the knowledge of the bidirectional reflectance distribution of water surfaces is of great significance in quantitative remote sensing or for the evaluation of measurement errors in surface optical parameters. To clarify the bidirectional reflectance distribution, we used the coupled ocean–atmosphere radiative transfer (COART) model to simulate the bidirectional radiance of water bodies and explored the anisotropy of radiance at the water–air interface. The results indicate that the downward and upward irradiance just below the water surface and the water-leaving radiance changed with the sun-viewing geometry. The downward and upward radiance just below the water surface decreased as the zenith angle of the incident light increased. This effect can be mitigated using a function of the viewing angle. Additionally, the viewing azimuth angle and rough sea surface had no significant effect on the downward and upward radiance. The water-leaving radiance had an obvious bidirectional reflectance characteristic. Additionally, a backward hotspot was found in the simulated results. Then, the transmission coefficient was calculated, and the bidirectional distribution characteristic was found for flat and rough sea surfaces. This study can be used as a reference to correct bidirectional errors and to guide the spectral measurements of water and its error control for rough sea surfaces. Full article

The electromagnetic (EM) scattering characteristics of the rough sea surface is very important for target surveying and detection in a sea environment. This work proposes a scaled sea surface designing method based on a rough thin-film medium. For the prototype sea surface, the permittivity is calculated with the seawater temperature, salinity, and EM wave frequency according to the Debye model. The scale film material is mixed with carbon black and epoxy, whose volume ratio is optimized with the genetic algorithm through the existing electromagnetic parameter library. This method can overcome the previous difficulties of adjusting the same permittivity of the prototype sea water. According to the EM scaled theory, the scaled geometric sample is numerically generated with the D-V spectrum for the given wind speed, and is fabricated using 3D printing to keep the similar seawater shape. Then, the sample is sprayed with a layer of film material for EM scattering measurement. The simulated and measured radar cross-section (RCS) results show good consistency for the prototype seawater and scaled materials, which indicates the proposed scaled method is a more efficient method to get the seawater scattering characteristics. Full article

In this study, we investigate sea state estimation from spaceborne GNSS-R. Due to the complex scattering of electromagnetic waves on the rough sea surface, the neural network approach is adopted to develop an algorithm to derive significant wave height (SWH) from CYGNSS data. Eighty-nine million pieces of CYGNSS data from September to November 2020 and the co-located ECMWF data are employed to train a three-hidden-layer neural network. Ten variables are considered as the input parameters of the neural network. Without the auxiliary of the wind speed, the SWH retrieved using the trained neural network exhibits a bias and an RMSE of −0.13 and 0.59 m with respect to ECMWF data. When considering wind speed as the input, the bias and RMSE were reduced to −0.09 and 0.49 m, respectively. When the incidence angle ranges from ${35}^{°}$ to ${65}^{°}$ and the SNR is above 7 dB, the retrieval performance is better than that obtained using other values. The measurements derived from the “Block III” satellite offer worse results than those derived from other satellites. When the distance is considered as an input parameter, the retrieval performances for the areas near the coast are significantly improved. A soft data filter is used to synchronously improve the precision and ensure the desired sample number. The RMSEs of the retrieved SWH are reduced to 0.45 m and 0.41 m from 0.59 m and 0.49 m, and only 16.0% and 14.9% of the samples are removed. The retrieved SWH also shows a clear agreement with the co-located buoy and Jason-3 altimeter data. Full article

Aiming at the high efficiency of composite electromagnetic scattering analysis and radar target detection and recognition utilizing high-range resolution profile (HRRP) characteristics and high-resolution synthetic aperture radar (SAR) images, a near-field modified iterative physical optics and facet-based two-scale model for analysis of composite electromagnetic scattering from multiple targets above rough surface have been presented. In this method, the coupling scattering of multiple targets is calculated by near-field iterative physical optics and the far-field scattering is calculated by the physical optics method. For the evaluation of the scattering of an electrically large sea surface, a slope cutoff probability distribution function is introduced in the two-scale model. Moreover, a fast imaging method is introduced based on the proposed hybrid electromagnetic scattering method. The numerical results show the effectiveness of the proposed method, which can generate backscattering data accurately and obtain high-resolution SAR images. It is concluded that the proposed method has the advantages of accurate computation and good recognition performance. Full article

Underwater acoustic echosounding for surface roughness parameters retrieval is studied in a frequency band that is relatively new for such purposes. During the described 2-weeks sea experiment, 1–3 kHz tonal pulses were emitted from an oceanographic platform, located on the northern Black Sea shelf. Doppler spectra of the resulting reverberation were studied. The frequency band of the acoustic system, selected for this study, is chosen due to the fact that the sound propagation range is large enough for remote sensing in a coastal zone, and the resolution cell size does not limit the research. Backscattering of acoustical signals was received for distances around two nautical miles. However, it turned to be quite difficult to interpret the obtained data since backscattering spectrum shape was influenced by a series of effects, resulting in a complicated link to wind waves and currents’ parameters. Significant wave height and dominant wave frequency were estimated as the result of such signals processed with the use of machine learning tools. A decision-tree-based mathematical regression model was trained to solve the inverse problem. Wind waves prediction is in a good agreement with direct measurements, made on the platform, and machine learning results allow physical interpretation. Full article

It is well known that numerical models are powerful methods for wave simulation of typhoons, where the sea surface drag coefficient is sensitive to strong winds. With the development of remote sensing techniques, typhoon data (i.e., wind and waves) have been captured by optical and microwave satellites such as the Chinese-French Oceanography SATellite (CFOSAT). In particular, wind and wave spectra data can be simultaneously measured by the Surface Wave Investigation and Monitoring (SWIM) onboard CFOSAT. In this study, existing parameterizations for the drag coefficient are implemented for typhoon wave simulations using the WAVEWATCH-III (WW3) model. In particular, a parameterization of the drag coefficient derived from sea surface roughness is adopted by considering the terms for wave steepness and wave age from the measurements from SWIM products of CFOSAT from 20 typhoons during 2019–2020 at winds up to 30 m/s. The simulated significant wave height (H_s) from the WW3 model was validated against the observations from several moored buoys active during three typhoons, i.e., Typhoon Fung-wong (2014), Chan-hom (2015), and Lekima (2019). The analysis results indicated that the proposed parameterization of the drag coefficient significantly improved the accuracy of typhoon wave estimation (a 0.49 m root mean square error (RMSE) of H_s and a 0.35 scatter index (SI)), greater than the 0.55 RMSE of H_s and >0.4 SI using other existing parameterizations. In this sense, the adopted parameterization for the drag coefficient is recommended for typhoon wave simulations using the WW3 model, especially for sea states with H_s < 7 m. Moreover, the accuracy of simulated waves was not reduced with growing winds and sea states using the proposed parameterization. However, the applicability of the proposed parameterization in hurricanes necessitates further investigation at high winds (>30 m/s). Full article
