Search Results (16)

Local overheating in cavities seriously threatens the safe operation of scramjet engines. To investigate the formation mechanism and control methods of local overheating, this paper conducts numerical simulations on the cooling process of cavity sudden expansion (S-E) structures. A three-dimensional numerical model coupled with pyrolysis reactions is established and validated through experiments. The effects of thermal pyrolysis reactions and cooling channel parameters on flow distribution are analyzed, and comparative studies with different channel parameters are performed. The results show that S-E structures are prone to uneven fuel flow distribution, leading to local over-temperature phenomena, and thermal pyrolysis reactions will aggravate this phenomenon to a certain extent. Increasing the aspect ratio of the channel can enhance the pressure drop at the inlet of the S-E structure and improve the uniformity of flow distribution. When the aspect ratio increases from one to eight, the mass flow distribution deviation ϕ_m decreases from 0.954 to 0.181. More uniform flow distribution under a larger aspect ratio avoids local over-temperature in the S-E structure, and reduces the coking risk caused by local excessive pyrolysis. This work reveals the fundamental characteristics of cooling heat transfer in the S-E structure of Scramjet engines and can provide recommendations for the design of cooling channels. Full article

The pylon has been identified as a highly promising method for enhancing mixing efficiency in scramjet combustors. This work systematically assessed the impact of spanwise, streamwise, and oblique multi-pylon combinations in a supersonic cold flow through numerical simulations, employing pylon-aided ethylene fuel injection under low dynamic pressure conditions. The Reynolds-averaged Navier–Stokes (RANS) equations with the SST k-ω turbulence model are applied during the simulation. Numerical results reveal that, in comparison to the streamwise combination, the spanwise combination exhibits superior flow field characteristics in terms of mixing efficiency, penetration depth, and total pressure loss. For a given injection condition, an optimal distance between pylons exists in the spanwise combination, with the angle between two pylons having minimal influence on mixing efficiency. The oblique multi-pylon combination yields poorer mixing enhancement efficiency and fuel penetration but incurs less total pressure loss in the near field when compared to the spanwise combination. Additionally, the oblique multi-pylon combination demonstrates enhanced mixing efficiency further downstream of the injector than the spanwise combination. This investigation into fuel injection schemes based on multi-pylon combinations offers valuable insights for the structural design of scramjet engines. Full article

This study focuses on the three-dimensional flow and combustion characteristics of a cavitied scramjet engine with multi-position injection. A single-equation large eddy simulation (LES) turbulence model is employed, with a detailed reaction mechanism for hydrogen combustion, as described by Jachimowski. The combustion characteristics of hydrogen in the scramjet combustion chamber are analyzed. Based on the combustion chamber model, the influence of different equivalence ratios, injection timing, injection positions, and injection pressures on the flame formation and propagation process are compared. The results indicate that within a certain range, an increase in the equivalence ratio enhances the combustion intensity and chamber pressure. In the case of multi-position injection, the order of injection from different nozzles has little effect on the final flame stabilization mode and pressure distribution. The opposite-side distribution of nozzles can effectively improve the fuel efficiency and the internal pressure. Furthermore, when the nozzles are closely placed in the opposite-side distribution, the combustion efficiency increases, although this leads to a higher total pressure loss. In scenarios where the fuel injection duration is short, an increase in the injection pressure at the upstream nozzles of the cavity results in a higher local equivalence ratio, as well as reduced fuel mixing and ignition time. Full article

Scramjet based on solid propellant has become a potential choice for the development of future hypersonic vehicles. In this paper, a boron-containing solid rocket scramjet based on the central strut injection was proposed, and the ground direct-connect experiment with the equivalence ratios of 0.43 to 2.4 under the flight condition of Mach 6, 25 km was carried out. The pressure and flow rate over time were measured in the experiment. The results show that the engine can realize stable supersonic mode or subsonic mode combustion by changing the gas flow rate. The engine can effectively increase the combustor pressure, reduce the unstable combustion time, and advance the strong combustion position by increasing the gas flow rate. The engine achieved high combustion efficiency when the equivalence ratio was about 1, with a maximum of 88.28%. A numerical simulation analysis was also carried out in this paper. Compared to the experimental results, the pressure error obtained by numerical simulation was less than 4%, and the typical position error was less than 3%, suggesting that the simulation model can be used to predict the behavior of scramjet. Full article

This paper presents a summary of and introduction to research on high-altitude and subatmospheric combustion concerning turbine and scramjet engines. The investigation includes theoretical analysis, experimental studies, and numerical simulations. The analysis encompasses the flow field structure, fuel atomization, and combustion performance. Subsequently, recent research on the combustion performance of liquid fuels, solid fuels, and gaseous fuels under high-altitude and low-pressure plateau environments is reviewed. This includes an evaluation of flame height, flame temperature, combustion rate, fire spread rate, and heat radiation flux. Additionally, combustion performance prediction models for high-altitude environments based on experimental and theoretical analysis have been introduced. Lastly, issues in subatmospheric combustion in the aerospace and plateau fire fields are presented based on the current research. Full article

With the in-depth research on hypersonic aerodynamics and hypersonic propulsion technology, humans are growing closer to space travel. Recent studies have shown that the pre-cooled air-turborocket (ATR) or turboexpander engines are some of the potential propulsion methods for reusable space vehicles and single stage-to-orbit (SSTO) missions because they have a high specific impulse at low Mach numbers, which can overcome the problem of the “thrust gap” in turbine-based combined-cycle (TBCC) engines. The ATR engine needs an additional oxidizing agent and the turboexpander engine usually uses hydrogen as fuel, which has low energy density and poor safety. To address this problem, this paper proposed a high-energy-density (HED) hydrocarbon-fueled turboexpander engine, and its feasibility has been proven through a simplified thermodynamic model. Through detailed thermodynamic analysis based on the energy and pressure balance, this paper analyzed the performance characteristics of the engine to evaluate its capacity to work in a wide speed range at low Mach numbers. The results show that the endothermic hydrocarbon-fueled turboexpander engine has good specific impulse in Mach 0∼4 at an equivalence ratio of 0.7∼1.3, and the turboexpander engine can be combined with the dual-mode scramjet and become an efficient acceleration method for SSTO missions and the reusable spacecraft. Full article

At an extremely high Mach number, the regenerative cooling of traditional kerosene cannot meet the requirement of the heat sink caused by aerodynamic heating and internal combustion in a scramjet propulsion system. As a supplement of traditional regenerative cooling, supercritical CO₂ is regarded as an effective coolant in severe heating environments due to its excellent properties of heat and mass transportation. In this paper, the heat transfer and flow structure characteristics of regenerative cooling in a rectangular channel using supercritical CO₂ are analyzed numerically using a validated model. The effect of heat flux magnitude, nonuniform heat flux, acceleration and buoyancy and flow pattern are considered to reveal the regenerative cooling mechanism of supercritical CO₂ in the engine condition of a scramjet. The results indicate that the heat transfer deterioration phenomenon becomes obvious in the cooling channel loaded with relatively high heat flux. Compared with the cooling channels loaded with increased heat flux distribution, the maximum temperature increased for the channel loaded with decreased heat flux distributions. When larger acceleration is applied, a relatively lower wall temperature distribution and higher heat transfer coefficients are obtained. The wall temperature distribution becomes more uniform and the high-temperature region is weakened when the coolants in adjacent channels are arranged as a reversed flow pattern. Overall, the paper provides some references for the utilization of supercritical CO₂ in regenerative cooling at an extremely high Mach number in a scramjet. Full article

The feasibility of regenerative cooling technology in scramjet engines has been verified, while the heat transfer behavior involved in the process needs further study. This paper expounds on the necessity of coupled heat-transfer analysis and summarizes its research progress. The results show that the effect of pyrolysis on heat transfer in the cooling channel depends on the heat flux and coking rate, and the coupling relationship between combustion and heat transfer is closely related to the fuel flow rate. Therefore, we confirm that regulating the cooling channel layout according to the real heat-flux distribution, suppressing coking, and accurately controlling the fuel flow rate can contribute to accomplishing the optimal collaborative design of cooling performance and combustion performance. Finally, a conjugate thermal analysis model can be used to evaluate the performance of various thermal protection systems. Full article

The performances of a dual-combustion ramjet (DCR) and a scramjet were compared via computational fluid dynamics numerical simulation to provide theoretical guidance for engine selection for a hypersonic vehicle. Kerosene, C₁₂H₂₃, with an equivalence ratio of 0.8, was employed as the fuel, and the reactive flow was modeled using six-species and four-step chemistry. The results show that the DCR has a central combustion mode, which has a smaller temperature gradient and more uniform heat release, resulting in higher combustion efficiency, compared to the near-wall combustion mode of the scramjet. The total pressure recovery coefficient of scramjet is 0.9% lower than that of DCR under the Ma6 condition, but 5.6% higher than that of DCR under the Ma7 condition. The combustion efficiency of DCR is 35.6% and 25.4% higher than that of the scramjet under Ma6 and Ma7 conditions, respectively. The decrease in the combustion efficiency of the DCR is caused by the increase in the dissociation rate of CO₂ into CO with the increase in temperature. The performance of DCR is better than that of scramjet under both conditions. However, the performance advantage of DCR decreases as the Mach number increases. Specifically, under the conditions of Ma6 and Ma7, the specific impulse or specific thrust of DCR was 2.67 times and 1.51 times that of scramjet, respectively. Full article

Large Eddy Simulation (LES) has rapidly developed into a powerful computational methodology for fluid dynamic studies, between Reynolds-Averaged Navier–Stokes (RANS) and Direct Numerical Simulation (DNS) in both accuracy and cost. High-speed combustion applications, such as ramjets, scramjets, dual-mode ramjets, and rotating detonation engines, are promising propulsion systems, but also challenging to analyze and develop. In this paper, the building blocks needed to perform LES of high-speed combustion are reviewed. Modelling of the unresolved, subgrid terms in the filtered LES equations is highlighted. The main families of combustion models are presented, focusing on finite-rate chemistry models. The density-based finite volume method and the reaction mechanisms commonly employed in LES of high-speed H₂-air combustion are briefly reviewed. Three high-speed combustor applications are presented: an experiment of supersonic flame stabilization behind a bluff body, a direct connect facility experiment as a transition case from ramjet to scramjet operation mode, and the STRATOFLY MR3 Small-Scale Flight Experiment. Several combinations of turbulence and combustion models are compared. Comparisons with experiments are also provided when available. Overall, the results show good agreement with experimental data (e.g., shock train, mixing, wall heat flux, transition from ramjet to scramjet operation mode). Full article

The rapidly changing and wide dynamic range of combustion temperature in scramjet engines presents a major challenge to existing test techniques. Tunable diode laser absorption spectroscopy (TDLAS) based temperature measurement has the advantages of high sensitivity, fast response, and compact structure. In this invited paper, a temperature measurement method based on the TDLAS technique with a single diode laser was demonstrated. A continuous-wave (CW), distributed feedback (DFB) diode laser with an emission wavelength near 1.4 μm was used for temperature measurement, which could cover two water vapor (H₂O) absorption lines located at 7153.749 cm⁻¹ and 7154.354 cm⁻¹ simultaneously. The output wavelength of the diode laser was calibrated according to the two absorption peaks in the time domain. Using this strategy, the TDLAS system has the advantageous of immunization to laser wavelength shift, simple system structure, reduced cost, and increased system robustness. The line intensity of the two target absorption lines under room temperature was about one-thousandth of that under high temperature, which avoided the measuring error caused by H₂O in the environment. The system was tested on a McKenna flat flame burner and a scramjet model engine, respectively. It was found that, compared to the results measured by CARS technique and theoretical calculation, this TDLAS system had less than 4% temperature error when the McKenna flat flame burner was used. When a scramjet model engine was adopted, the measured results showed that such TDLAS system had an excellent dynamic range and fast response. The TDLAS system reported here could be used in real engine in the future. Full article

For successful scramjet engine operations, it is important to understand the mechanism of the inlet unstart phenomenon. Among various unstarted flow patterns in hypersonic inlets, the mechanism of low-amplitude oscillatory unstarted flow is still unclear. Therefore, in the present study, the flow characteristics of non-oscillatory unstarted flow in a scramjet inlet-isolator model are studied by using numerical analysis with the RANS-based OpenFOAM solver. In the numerical results, the amplitude of pressure oscillation and the average pressure near the model outlet are in good agreement with experimental results. In the detailed analysis of the results, it is found that the incoming flow within the boundary layers repeatedly changes direction due to the flow blockage at the end of the model. In these direction-changing processes, recirculation zones near the walls irregularly influence the choked flow zones at the rear part of the model. These irregular behaviors result in non-oscillatory unstarted flow. Additionally, the main differences between the high-amplitude oscillatory unstarted flow and non-oscillatory unstarted flow are addressed. Full article

In this work, the dynamic combustion characteristics in a scramjet engine were investigated using three diagnostic data analysis methods: DMD (Dynamic Mode Decomposition), STFT (Short-Time Fourier Transform), and CEMA (Chemical Explosive Mode Analysis). The data for the analyses were obtained through a 2D numerical experiment using a DDES (Delayed Detached Eddy Simulation) turbulence model, the UCSD (University of California at San Diego) hydrogen/oxygen chemical reaction mechanism, and high-resolution schemes. The STFT was able to detect that oscillations above 50 kHz identified as dominant in FFT results were not the dominant frequencies in a channel-type combustor. In the analysis using DMD, it was confirmed that the critical point that induced a complete change of mixing characteristics existed between an injection pressure of 0.75 MPa and 1.0 MPa. A combined diagnostic analysis that included a CEMA was performed to investigate the dynamic combustion characteristics. The differences in the reaction steps forming the flame structure under each combustor condition were identified, and, through this, it was confirmed that the pressure distribution upstream of the combustor dominated the dynamic combustion characteristics of this scramjet engine. From these processes, it was confirmed that the combined analysis method used in this paper is an effective approach to diagnose the combustion characteristics of a supersonic combustor. Full article

This numerical study was conducted to investigate the flow properties in a model scramjet configuration of the experiment in the T4 shock tunnel. In most numerical simulations of flows in shock tunnels, the inflow conditions in the test section are determined by assuming the thermal equilibrium of the gas. To define the inflow conditions in the test section, the numerical simulation of the nozzle flow with the given nozzle reservoir conditions from the experiment is conducted by a thermochemical nonequilibrium computational fluid dynamics (CFD) solver. Both two-dimensional (2D) and three-dimensional (3D) numerical simulations of the flow in a model scramjet were conducted without fuel injection. Simulations were performed for two types of inflow conditions: one for thermochemical nonequilibrium states obtained from the present nozzle simulation and the other for the data available using the thermal equilibrium and chemical nonequilibrium assumptions. The four results demonstrate the significance of the modelling approach for choosing between 2D or 3D, and thermal equilibrium or nonequilibrium. Full article

In order to obtain a deeper understanding of the regenerative cooling process of scramjet engines, in this paper, a numerical investigation on the supercritical convective heat transfer of n-decane in horizontal circular tubes was conducted, based on a complete set of conservation equations and the Renormalization group (RNG) k–ε turbulence model with enhanced wall treatment. The present study mainly focuses on the heat transfer deterioration (HTD) phenomenon, including the mechanism and critical conditions for the onset of HTD. Moreover, the applicability of some conventional heat transfer empirical correlations was analyzed and compared, thus providing guidance for the Nusselt number predictions in the cooling channels. Results indicate that under the compositive conditions of low pressure and high heat flux, two types of HTD phenomena could occur when the wall and bulk fluid temperatures are near the pseudo-critical temperature, owing to the abnormal distributions of near-wall turbulent kinetic energy and radial velocity, respectively. Increasing the pressure would effectively alleviate and eliminate the HTD. A comparison of numerical results with those obtained with different empirical expressions shows that the Bae-Kim expression provides the best agreement, especially when HTD occurs. Furthermore, a new correction for critical heat flux of HTD has been successfully developed. Full article
