The use of linear array pushbroom images presents a new challenge in photogrammetric applications when it comes to transforming object coordinates to image coordinates. To address this issue, the Best Scanline Search/Determination (BSS/BSD) field focuses on obtaining the Exterior Orientation Parameters (EOPs) of each individual scanline. Current solutions are often impractical for real-time tasks due to their high time requirements and complexities. This is because they are based on the Collinearity Equation (CE) in an iterative procedure for each ground point. This study aims to develop a novel BSD framework that does not need repetitive usage of the CE with a lower computational complexity. The Linear Regression Model (LRM) forms the basis of the proposed BSD approach and uses Simulated Control Points (SCOPs) and Simulated Check Points (SCPs). The proposed method is comprised of two main steps: the training phase and the test phase. The SCOPs are used to calculate the unknown parameters of the LR model during the training phase. Then, the SCPs are used to evaluate the accuracy and execution time of the method through the test phase. The evaluation of the proposed method was conducted using ten various pushbroom images, 5 million SCPs, and a limited number of SCOPs. The Root Mean Square Error (RMSE) was found to be in the order of ten to the power of negative nine (pixel), indicating very high accuracy. Furthermore, the proposed approach is more robust than the previous well-known BSS/BSD methods when handling various pushbroom images, making it suitable for practical and real-time applications due to its high speed, which only requires 2–3 s of time. Full article

Working with pushbroom imagery in photogrammetry and remote sensing presents a fundamental challenge in object-to-image space transformation. For this transformation, accurate estimation of Exterior Orientation Parameters (EOPs) for each scanline is required. To tackle this challenge, Best Scanline Search or Determination (BSS/BSD) methods have been developed. However, the current BSS/BSD methods are not efficient for real-time applications due to their complex procedures and interpolations. This paper introduces a new non-iterative BSD method specifically designed for line-type pushbroom images. The method involves simulating a pair of sets of points, Simulated Control Points (SCOPs), and Simulated Check Points (SCPs), to train and test a Multilayer Perceptron (MLP) model. The model establishes a strong relationship between object and image spaces, enabling a direct transformation and determination of best scanlines. This proposed method does not rely on the Collinearity Equation (CE) or iterative search. After training, the MLP model is applied to the SCPs for accuracy assessment. The proposed method is tested on ten images with diverse landscapes captured by eight sensors, exploiting five million SCPs per image for statistical assessments. The Root Mean Square Error (RMSE) values range between 0.001 and 0.015 pixels across ten images, demonstrating the capability of achieving the desired sub-pixel accuracy within a few seconds. The proposed method is compared with conventional and state-of-the-art BSS/BSD methods, indicating its higher applicability regarding accuracy and computational efficiency. These results position the proposed BSD method as a practical solution for transforming object-to-image space, especially for real-time applications. Full article

This paper proposes a new string transformation technique called Move with Interleaving (MwI). Four possible ways of rearranging 2D raster images into 1D sequences of values are applied, including scan-line, left-right, strip-based, and Hilbert arrangements. Experiments on 32 benchmark greyscale raster images of various resolutions demonstrated that the proposed transformation reduces information entropy to a similar extent as the combination of the Burrows–Wheeler transform followed by the Move-To-Front or the Inversion Frequencies. The proposed transformation MwI yields the best result among all the considered transformations when the Hilbert arrangement is applied. Full article

This work presents an estimate of the slip activation potential of existing fractures in a remote northern community located on Canadian Shield rocks for geothermal purposes. To accomplish this objective, we analyzed outcrop analogues and recorded geometrical properties of fractures, namely the strike and dip. Then, we estimated the stress regime in the study area through an empirical approach and performed a probabilistic slip tendency analysis. This allowed us to determine the slip probability of the pre-existing fractures at the current state of stress, the orientation of fractures that are most likely to be activated and the fluid pressures needed for the slip activation of pre-existing fractures, which are key aspects for developing Enhanced Geothermal Systems. The results of this simple, yet effective, analysis suggest that at the current state of stress, the pre-existing natural fractures are relatively stable, and an injection pressure of about 12.5 MPa/km could be required to activate the most optimally oriented fractures to slip. An injection of water at this pressure gradient could open the optimally oriented pre-existing fractures and enhance the permeability of the reservoir for geothermal fluid extraction. The information described in this paper provides a significant contribution to the geothermal research underway in remote northern communities. Full article

Hyperspectral sensors mounted on unmanned aerial vehicles (UAV) offer the prospect of high-resolution multi-temporal spectral analysis for a range of remote-sensing applications. However, although accurate onboard navigation sensors track the moment-to-moment pose of the UAV in flight, geometric distortions are introduced into the scanned data sets. Consequently, considerable time-consuming (user/manual) post-processing rectification effort is generally required to retrieve geometrically accurate mosaics of the hyperspectral data cubes. Moreover, due to the line-scan nature of many hyperspectral sensors and their intrinsic inability to exploit structure from motion (SfM), only 2D mosaics are generally created. To address this, we propose a fast, automated and computationally robust georectification and mosaicking technique that generates 3D hyperspectral point clouds. The technique first morphologically and geometrically examines (and, if possible, repairs) poorly constructed individual hyperspectral cubes before aligning these cubes into swaths. The luminance of each individual cube is estimated and normalised, prior to being integrated into a swath of images. The hyperspectral swaths are co-registered to a targeted element of a luminance-normalised orthomosaic obtained using a standard red–green–blue (RGB) camera and SfM. To avoid computationally intensive image processing operations such as 2D convolutions, key elements of the orthomosaic are identified using pixel masks, pixel index manipulation and nearest neighbour searches. Maximally stable extremal regions (MSER) and speeded-up robust feature (SURF) extraction are then combined with maximum likelihood sample consensus (MLESAC) feature matching to generate the best geometric transformation model for each swath. This geometrically transforms and merges individual pushbroom scanlines into a single spatially continuous hyperspectral mosaic; and this georectified 2D hyperspectral mosaic is then converted into a 3D hyperspectral point cloud by aligning the hyperspectral mosaic with the RGB point cloud used to create the orthomosaic obtained using SfM. A high spatial accuracy is demonstrated. Hyperspectral mosaics with a 5 cm spatial resolution were mosaicked with root mean square positional accuracies of 0.42 m. The technique was tested on five scenes comprising two types of landscape. The entire process, which is coded in MATLAB, takes around twenty minutes to process data sets covering around 30 Ha at a 5 cm resolution on a laptop with 32 GB RAM and an Intel^® Core i7-8850H CPU running at 2.60 GHz. Full article

SLAM (Simultaneous Localization and Mapping) based on lidar is an important method for UGV (Unmanned Ground Vehicle) localization in real time under GNSS (Global Navigation Satellite System)-denied situations. However, dynamic objects in real-world scenarios affect odometry in SLAM and reduce localization accuracy. We propose a novel lidar SLAM algorithm based on LOAM (Lidar Odometry and Mapping), which is popular in this field. First, we applied elevation maps to label the ground point cloud. Then we extracted convex hulls in point clouds based on scanlines as materials for dynamic object clustering. We replaced these dynamic objects with background point cloud to avoid accuracy reduction. Finally, we extracted feature points from ground points and non-ground points, respectively, and matched these feature points frame-to-frame to estimate ground robot motion. We evaluated the proposed algorithm in dynamic industrial park roads, and it kept UGV maximum relative position error less than 3% and average relative position error less than 2%. Full article

Within speech processing, articulatory-to-acoustic mapping (AAM) methods can apply ultrasound tongue imaging (UTI) as an input. (Micro)convex transducers are mostly used, which provide a wedge-shape visual image. However, this process is optimized for the visual inspection of the human eye, and the signal is often post-processed by the equipment. With newer ultrasound equipment, now it is possible to gain access to the raw scanline data (i.e., ultrasound echo return) without any internal post-processing. In this study, we compared the raw scanline representation with the wedge-shaped processed UTI as the input for the residual network applied for AAM, and we also investigated the optimal size of the input image. We found no significant differences between the performance attained using the raw data and the wedge-shaped image extrapolated from it. We found the optimal pixel size to be 64 × 43 in the case of the raw scanline input, and 64 × 64 when transformed to a wedge. Therefore, it is not necessary to use the full original 64 × 842 pixels raw scanline, but a smaller image is enough. This allows for the building of smaller networks, and will be beneficial for the development of session and speaker-independent methods for practical applications. AAM systems have the target application of a “silent speech interface”, which could be helpful for the communication of the speaking-impaired, in military applications, or in extremely noisy conditions. Full article

Serious deficiencies in ground characterization, analysis and design at engineering works can occur when working with bimrocks (block-in-matrix rocks) and bimsoils (block-in-matrix soils). Since the 1990s, serious technical problems at engineering works performed in bimrocks/bimsoils spurred practical research, which revealed that the behavior of these geomaterials is directly related to the volumetric block proportions (VBPs). However, the way that VBPs can be confidently and correctly estimated remains an ongoing critical issue that still frustrates designers, contractors and owners. Stereological techniques can be applied to overcome this challenge by inferring 3D block contents from in situ 1D and 2D measurements, but the estimates have often been demonstrated to be erroneous. This paper presents findings from a computer-aided reinvestigation, revalidation and extension of Medley’s work of 1997 and subsequent researchers to provide approachable yet statistically robust methods to limit the uncertainty associated with estimates of 3D VBPs generated from 1D boring/scanline measurements. To this aim, a specialized Matlab code was created and virtual drilling programs were performed through 3D computer-generated bimrock models. Supported by extensive statistical-based investigations, a design chart is provided that updates and extends Medley’s 1999 chart relating uncertainty in estimates of VBP as a function of total boring/scanline lengths. Full article

Fengyun-3E, which is equipped with MicroWave Humidity Sounder 2 (MWHS-2) for detecting both temperature and humidity, is China’s latest polar orbiting meteorological satellite and China’s first satellite in early-morning orbit. The observation bias and observation error characteristics of MWHS-2 are evaluated by using ERA-5 as the background field. The results show that the biases range from −4 to 2 K, and the observation errors are within 1.5 K except for the window channels. A further analysis of the dependence on the scanning angles indicates that observation errors for the window channels and the 118-GHz channels increase with decreasing scanning angles. Observation errors of the window channels and water vapor channels are also latitudinally dependent, and the maximum errors in the high latitudes reach 2.0 K, while those in the tropical regions are approximately 0.8 K. In addition, the observed brightness temperature of FY-3E MWHS-2 is accompanied by striping noises along the track and high-frequency oscillation noises along the scanlines. The noise mitigation results show that both noises are approximately 0.2 K. Full article

Quantitative statistical discontinuity analysis of fractured rock masses is commonly applied in the fields of engineering geology, rock mechanics, slope stability, and hydrogeology. This study presents a workflow for the semiautomatic determination of basic discontinuity parameters, such as spacing, frequency, trace length, and termination, from scanline surveys written for the open-source software Octave. The aim is to provide theoretical background information and scripts for a quick introduction to all interested parties from academia and consulting, in order to promote the use of widely known and accepted statistical evaluation methods. Data from a study site in granodioritic rock are analyzed in the context of the proposed workflow. These test data and all scripts (m-files) used in the study are provided in order to minimize initial training time. The scripts provided herein are kept short and simple, but can be used as a basis for advanced automation of the workflow and presentation of the results. Full article

Underwater gliders (UGs) are widely applied to regional exploration to find potential targets. However, the complex marine environment and special movement patterns make it difficult to plan their coverage path. In this paper, a novel multi-underwater gliders coverage path planning algorithm based on ant colony optimization (MGCPP-ACO) is proposed. First, according to the detection radius of the sonar and the motion process of the UGs, we establish a detection coverage model. Then, considering the motion constraints of the UGs and optimization objectives, we redesign the feasible region, transition probability, pheromone update rule and heuristic function of the ACO algorithm. Finally, we carry out three groups of experiments. The simulation results show that the MGCPP-ACO can cover almost the entire sea area and adapt to different initial positions and heading angles. In addition, compared with the traditional scan-line (SCAN) algorithm, the MGCPP-ACO has a higher coverage efficiency and lower coverage cost. Full article

Ge₂Sb₂Te₅ (GST225) looks to be a promising material for rewritable memory devices due to its relatively easy processing and high optical and electrophysical contrast for the crystalline and amorphous phases. In the present work, we combined the possibilities of crystallization and anisotropic structures fabrication using femtosecond laser treatment at the 1250 nm wavelength of 200 nm thin amorphous GST225 films on silicon oxide/silicon substrates. A raster treatment mode and photoexcited surface plasmon polariton generation allowed us to produce mutually orthogonal periodic structures, such as scanline tracks (the period is 120 ± 10 μm) and laser-induced gratings (the period is 1100 ± 50 nm), respectively. Alternating crystalline and amorphous phases at the irradiated surfaces were revealed according to Raman spectroscopy and optical microscopy studies for both types of structures. Such periodic modulation leads to artificial optical and electrophysical anisotropy. Reflectance spectra in the near infrared range differ for various polarizations of probing light, and this mainly results from the presence of laser-induced periodic surface structures. On the other hand, the scanline tracks cause strong conductivity anisotropy for dc measurements in the temperature range of 200–400 K. The obtained results are promising for designing new GST225-based memory devices in which anisotropy may promote increasing the information recording density. Full article

A research study aimed at the extending the means of estimating ISRM (International Society for Rock Mechanics) geomechanical parameters through non-contact methodologies, in the frame of the remote survey of rock masses, is herein presented. It was conducted by coupling UAV-based photogrammetry and Infrared Thermography. Starting from georeferenced UAV surveys and the definition of rock masses’ RGB point clouds, different approaches for the extraction of discontinuity spatial data were herein compared according to the ISRM subjective and objective discontinuity sampling criteria. These were applied to a survey a window and along a scanline, both defined on the dense point clouds, to simulate a field rock mass survey, although carried out on remotely acquired data. Spatial discontinuity data were integrated via the analysis of dense point clouds built from IRT images, which represents a relatively new practice in remote sensing, and the processing of thermograms. Such procedures allowed the qualitative evaluation of the main geomechanical parameters of tested rock masses, such as aperture, persistence and weathering. Moreover, the novel parameters of Thermal-spacing (T-spacing) and Thermal-RQD (T-RQD) are herein introduced in a tentative attempt at extending the application field of IRT to remote rock mass surveys for practical purposes. The achieved results were validated by field campaign, demonstrating that a remote survey of rock masses can be conducted according to the ISRM procedures even on models built by integrating RGB and IRT photogrammetry. In fact, these two technologies are positively complementary and, besides being feasible, are characterized by a relatively quick and non-contact execution. Thanks to the positive and satisfactory results achieved herein, this research contributes to the implementation of the scientific and technical casuistry on the remote survey of rock masses, which is a technical field offering a wide range of applications. Full article

Scanlines constitute a robust method to better understand in 3D the fracture network variability in naturally fractured geothermal reservoirs. This study aims to characterize the spacing variability and the distribution of fracture patterns in a fracture granitic reservoir, and the impact of the major faults on fracture distribution and fluid circulation. The analogue target named the Noble Hills (NH) range is located in Death Valley (DV, USA). It is considered as an analogue of the geothermal reservoir presently exploited in the Upper Rhine Graben (Soultz-sous-Forêts, eastern of France). The methodology undertaken is based on the analyze of 10 scanlines located in the central part of the NH from fieldwork and virtual (photogrammetric models) data. Our main results reveal: (1) NE/SW, E/W, and NW/SE fracture sets are the most recorded orientations along the virtual scanlines; (2) spacing distribution within NH shows that the clustering depends on fracture orientation; and (3) a strong clustering of the fracture system was highlighted in the highly deformed zones and close to the Southern Death Valley fault zone (SDVFZ) and thrust faults. Furthermore, the fracture patterns were controlled by the structural heritage. Two major components should be considered in reservoir modeling: the deformation gradient and the proximity to the regional major faults. Full article

Quantitative characterization of discontinuities is fundamental to define the mechanical behavior of discontinuous rock masses. Several techniques for the semi-automatic and automatic extraction of discontinuities and their properties from raw or processed point clouds have been introduced in the literature to overcome the limits of conventional field surveys and improve data accuracy. However, most of these techniques do not allow characterizing flat or subvertical outcrops because planar surfaces are difficult to detect within point clouds in these circumstances, with the drawback of undersampling the data and providing inappropriate results. In this case, 2D analysis on the fracture traces are more appropriate. Nevertheless, to our knowledge, few methods to perform quantitative analyses on discontinuities from orthorectified photos are publicly available and do not provide a complete characterization. We implemented scanline and window sampling methods in a digital environment to characterize rock masses affected by discontinuities perpendicular to the bedding from trace maps, thus exploiting the potentiality of remote sensing techniques for subvertical and low-relief outcrops. The routine, named QDC-2D (Quantitative Discontinuity Characterization, 2D) was compiled in MATLAB by testing a synthetic dataset and a real case study, from which a high-resolution orthophoto was obtained by means of Structure from Motion technique. Starting from a trace map, the routine semi-automatically classifies the discontinuity sets and calculates their mean spacing, frequency, trace length, and persistence. The fracture network is characterized by means of trace length, intensity, and density estimators. The block volume and shape are also estimated by adding information on the third dimension. The results of the 2D analysis agree with the input used to produce the synthetic dataset and with the data collected in the field by means of conventional geostructural and geomechanical techniques, ensuring the procedure’s reliability. The outcomes of the analysis were implemented in a Discrete Fracture Network model to evaluate their applicability for geomechanical modeling. Full article
