Search Results (114)

Search Parameters:
Keywords = rotor stall

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
18 pages, 2291 KiB
Article
Experimental Results in a Variable-Pitch Wells Rotor
by Fabio Licheri, Tiziano Ghisu, Francesco Cambuli, Pierpaolo Puddu and Mario Carta
Int. J. Turbomach. Propuls. Power 2025, 10(2), 10; https://doi.org/10.3390/ijtpp10020010 - 11 Jun 2025
Viewed by 367
Abstract
Systems based on the oscillating water column (OWC) principle are often equipped with Wells turbines as power take-offs (PTOs) to convert sea-wave energy. The self-rectifying nature of the Wells turbine represents a strength for such applications, while its limited operating range, due to [...] Read more.
Systems based on the oscillating water column (OWC) principle are often equipped with Wells turbines as power take-offs (PTOs) to convert sea-wave energy. The self-rectifying nature of the Wells turbine represents a strength for such applications, while its limited operating range, due to stall, is one of the most relevant limitations. A possible improvement lies in varying the blade stagger angle during operation as this can delay stall by reducing the incidence angle. Although the performance of variable-pitch Wells turbines has been studied in the past, their local aerodynamic performance has never been investigated before. This study addresses this important task by experimentally reconstructing the flow field along the blade height of a Wells turbine prototype, coupled to an OWC simulator, for three values of the stagger angle. The aerodynamic behavior of the Wells rotor is characterized at its inlet and outlet, showing how the interaction between adjacent blades changes due to the stagger angle. The rotor performance is evaluated and compared, providing useful information that is of general validity for similar rows of symmetric blade profiles when pitched at different stagger angles. Full article
Show Figures

Figure 1

38 pages, 14799 KiB
Article
Investigation of Tilt-Proprotor Loads Correlation Between Wind Tunnel Test Data and Comprehensive Modeling
by Yin Ruan, Weite Wang and Wei Zhang
Aerospace 2025, 12(6), 452; https://doi.org/10.3390/aerospace12060452 - 22 May 2025
Viewed by 299
Abstract
The loads of a model tilt-proprotor with a gimbaled hub were measured in the wind tunnel of CHRDI, operating at 90°, 80°, 70°, 60°, and 45° inclination angles to represent the rotor loads of helicopter and transient flight modes. The flap, lead-lag moments, [...] Read more.
The loads of a model tilt-proprotor with a gimbaled hub were measured in the wind tunnel of CHRDI, operating at 90°, 80°, 70°, 60°, and 45° inclination angles to represent the rotor loads of helicopter and transient flight modes. The flap, lead-lag moments, and pitch rod forces were measured. A comprehensive model was established with both linear inflow and free-wake non-linear inflow models. It is shown that there is a better correlation of alternating flap bending moments between test data and linear inflow model predicted values for the helicopter mode and a good correlation between measured data and free-wake predicted values for transition modes. The static moments are well captured by all inflow models at high thrust coefficients, while they fail to reflect the flap bending direction of the blade root at low thrust coefficients. Neither of the inflow models captured higher harmonics of the blade flap bending moments. The measured 2/rev harmonics of the lag bending moments lie between the linear inflow model and the free wake model predicted values. The current model with no dynamic stall model failed to capture the oscillating loads of the pitch rod. Full article
(This article belongs to the Special Issue Recent Advances in Flight Testing)
Show Figures

Figure 1

19 pages, 2550 KiB
Article
Analytical Modeling of Shrouded Rotors in Hover with Experimental and Computational Validation
by Abdallah Dayhoum, Alejandro Ramirez-Serrano and Robert J. Martinuzzi
Actuators 2025, 14(3), 138; https://doi.org/10.3390/act14030138 - 11 Mar 2025
Cited by 1 | Viewed by 870
Abstract
Rotors have been utilized for aircraft propulsion since the dawn of aviation, but their performance can degrade significantly if not properly designed. This study focuses on developing an accurate design tool and model validation for shrouded rotors. An experimental test rig was designed [...] Read more.
Rotors have been utilized for aircraft propulsion since the dawn of aviation, but their performance can degrade significantly if not properly designed. This study focuses on developing an accurate design tool and model validation for shrouded rotors. An experimental test rig was designed and manufactured to measure the rotor thrust and total thrust separately as well as the rotor torque. A key aspect was to account for the impact of a test rig on experimental results using computational simulations for the shrouded rotor configuration with and without the test rig. The findings indicate that the effects of the test rig were minimal and could be neglected, ensuring the validity of the experimental data compared to the analytical model. The analytical model employs a hybrid approach combining blade element momentum theory (BEMT) and the sphere-cap model which are used in conjunction with the shrouded rotor inflow ratio, as well as post-stall and tip gap clearance models. BEMT is used to calculate rotor performance, while the sphere-cap model addresses the aerodynamic influence of the shroud. The results demonstrate that the analytical model predicts shrouded rotor performance with considerable accuracy, addressing both the rotor dynamics and the shroud’s contribution to performance. Full article
(This article belongs to the Special Issue Aerospace Mechanisms and Actuation—Second Edition)
Show Figures

Figure 1

16 pages, 10239 KiB
Article
Flow Analysis of a 300 MW F-Class Heavy-Duty Gas Turbine 1.5 Stage Compressor
by Kunhang Li, Bo Song, Suyu Jiang, Jiao Wang, Xiaojun Fan and Jingyin Li
Aerospace 2025, 12(1), 25; https://doi.org/10.3390/aerospace12010025 - 31 Dec 2024
Cited by 1 | Viewed by 976
Abstract
The axial compressor is crucial for heavy-duty gas turbines, with its aerodynamic performance directly affecting efficiency. The current trend in the development of these compressors is to increase the stage load and efficiency, thereby achieving a higher pressure ratio with fewer stages. The [...] Read more.
The axial compressor is crucial for heavy-duty gas turbines, with its aerodynamic performance directly affecting efficiency. The current trend in the development of these compressors is to increase the stage load and efficiency, thereby achieving a higher pressure ratio with fewer stages. The aerodynamic characteristics of a 1.5-stage axial compressor from a 300 MW F-class heavy gas turbine at three different rotation speeds (100%, 90%, and 80%) were studied. Specifically, the distribution of the inlet Mach number, shock wave structures, isentropic Mach number of blade surface, and blade surface separation flow characteristics under three typical working conditions, at the near stall (NS) point, maximum efficiency (ME) point, and near choke point (NC), were discussed. The results indicate that at 80% rotational speed, 70~100% spanwise of the compressor rotor blade is operated under the transonic zone. Meanwhile, at 100% rotational speed, almost all the spanwise of the compressor rotor blade is operated under the transonic zone. Furthermore, compared to the detached shock wave observed under the NS condition, the normal passage shock wave observed under the NC condition exhibits more significant changes in shock intensity and shock pattern. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

22 pages, 29982 KiB
Article
Numerical Study on the Effects of Boundary Layer Suction on Flow in the Sectorial Transonic Cascade Under Imitated Near-Stall Condition
by Ruixing Liang, Huawei Lu, Zhitao Tian, Hong Wang and Shuang Guo
Appl. Sci. 2025, 15(1), 76; https://doi.org/10.3390/app15010076 - 26 Dec 2024
Cited by 1 | Viewed by 1105
Abstract
In the experimental study of a compressor’s cascade under the near-stall condition, the test bench has the disadvantages of high risk and high maintenance cost. This paper explores a method of using the inlet guide vane to imitate near-stall conditions instead of the [...] Read more.
In the experimental study of a compressor’s cascade under the near-stall condition, the test bench has the disadvantages of high risk and high maintenance cost. This paper explores a method of using the inlet guide vane to imitate near-stall conditions instead of the rotor. The suction groove is set in the sectorial cascade so as to explore the aerodynamic performance of the fluid and the change in the flow field structure. Three different schemes are proposed along the suction surface, and the results indicate that the EW2 scheme, which is located behind the separation starting point and near the vortex core of the separation vortex, has the best performance. The suction groove weakens the downwash caused by the boundary layer on the upper endwall, reducing the radial dimension of the corner and suppressing separation. Suction on the upper endwall also increases the pressure difference in the radial direction of the flow passage, resulting in a slight increase in the suction-side horseshoe vortex (HSV) at the hub. An overall loss reduction of 9.4% is achieved when the suction coefficient is 46%, and the corner separation is most effectively suppressed while ensuring that the HSV at the hub only slightly increases. Full article
(This article belongs to the Special Issue Application of Fluid Mechanics and Aerodynamics in Aerospace)
Show Figures

Graphical abstract

33 pages, 22828 KiB
Article
Comparison of Two Fourier-Based Methods for Simulating Inlet Distortion Unsteady Flows in Transonic Compressors
by Lei Wu, Pengcheng Du and Fangfei Ning
Aerospace 2024, 11(12), 1050; https://doi.org/10.3390/aerospace11121050 - 22 Dec 2024
Cited by 1 | Viewed by 917
Abstract
The aerodynamic performance of transonic compressors, particularly the stall margin, is significantly influenced by inlet distortion. While time-marching methods accurately simulate such unsteady flows, they can be time-consuming. To enhance the computational efficiency, two Fourier-based methods are proposed in this paper: the time-accurate [...] Read more.
The aerodynamic performance of transonic compressors, particularly the stall margin, is significantly influenced by inlet distortion. While time-marching methods accurately simulate such unsteady flows, they can be time-consuming. To enhance the computational efficiency, two Fourier-based methods are proposed in this paper: the time-accurate method with interface filtering and the time–space collocation (TSC) method. The time-accurate method with interface filtering ignores the rotor–stator interaction effects, enabling a larger time step and faster convergence. In contrast, the TSC method accounts for harmonics of conservative variables and transforms the unsteady simulation into multiple steady-state calculations, thereby reducing computational costs. The two Fourier-based methods are validated using NASA Stage 67 and a two-stage transonic fan. Near the peak efficiency point, the results from both methods closely match that of URANS simulation and experimental data. The time-accurate method with interface filtering demonstrates a speed enhancement of 4 to 5 times as a result of a reduction in the iteration steps. In contrast, the TSC method exhibits a speed improvement of at least 20 times in two specific cases, attributable to the significantly smaller mesh size and iteration steps employed in the TSC method compared to the URANS method. Near the stall point, more harmonics for inlet distortion are necessary in TSC simulation to accurately capture flow separation. In the two-stage transonic fan simulations, the strong rotor–stator interaction effects lead to deviations from the URANS simulation; nevertheless, the Fourier-based simulations accurately reflect the trend of the stall margin under total pressure distortion. Overall, the Fourier-based methods show promising potential for engineering applications in estimating the performance degradation of compressors subjected to inlet distortion. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

31 pages, 12132 KiB
Article
Intelligent Control of an Experimental Small-Scale Wind Turbine
by Monica Borunda, Raul Garduno, Javier de la Cruz Soto and Rafael Alfonso Figueroa Díaz
Energies 2024, 17(22), 5656; https://doi.org/10.3390/en17225656 - 12 Nov 2024
Cited by 1 | Viewed by 1056
Abstract
Nowadays, wind turbines are one of the most popular devices for producing clean and renewable electric energy. The rotor blades catch the wind’s kinetic energy to produce rotational energy from the turbine and electric energy from the generator. In small-scale wind turbines, there [...] Read more.
Nowadays, wind turbines are one of the most popular devices for producing clean and renewable electric energy. The rotor blades catch the wind’s kinetic energy to produce rotational energy from the turbine and electric energy from the generator. In small-scale wind turbines, there are several methods to operate the blades to obtain the desired speed of rotation and power outputs. These methods include passive stall, active stall, and pitch control. Pitch control sets the angular position of the blades to face the wind to achieve a predefined relationship between turbine speed or power and wind velocity. Typically, conventional Proportional Integral (PI) controllers are used to set the angular position of the rotor blades or pitch angle. Nevertheless, the quality of speed or power regulation may vary substantially. This study introduces a rotor speed controller for a pitch-controlled small-scale wind turbine prototype based on fuzzy logic concepts. The basics of fuzzy systems required to implement this kind of controller are presented in detail to counteract the lack of such material in the technical literature. The knowledge base of the fuzzy speed controller is composed of Takagi–Sugeno–Kang (TSK) fuzzy inference rules that implement a dedicated PI controller for any desired interval of wind velocities. Each wind velocity interval is defined with a fuzzy set. Simulation experiments show that the TSK fuzzy PI speed controller can outperform the conventional PI controller in the speed and accuracy of response, stability, and robustness over the whole range of operation of the wind turbine prototype. Full article
(This article belongs to the Section A3: Wind, Wave and Tidal Energy)
Show Figures

Figure 1

36 pages, 21118 KiB
Article
Flow Separation Control and Aeroacoustic Effects of a Leading-Edge Slat over a Wind Turbine Blade
by Sami Bouterra, Riyadh Belamadi, Abdelouaheb Djemili and Adrian Ilinca
Energies 2024, 17(22), 5597; https://doi.org/10.3390/en17225597 - 9 Nov 2024
Viewed by 1685
Abstract
To enable wind energy to surpass fossil fuels, the power-to-cost ratio of wind turbines must be competitive. Increasing installation capacities and wind turbine sizes indicates a strong trend toward clean energy. However, larger rotor diameters, reaching up to 170 m, introduce stability and [...] Read more.
To enable wind energy to surpass fossil fuels, the power-to-cost ratio of wind turbines must be competitive. Increasing installation capacities and wind turbine sizes indicates a strong trend toward clean energy. However, larger rotor diameters, reaching up to 170 m, introduce stability and aeroelasticity concerns and aerodynamic phenomena that cause noise disturbances. These issues hinder performance enhancement and social acceptance of wind turbines. A critical aerodynamic challenge is flow separation on the blade’s suction side, leading to a loss of lift and increased drag, ultimately stalling the blade and reducing turbine performance. Various active and passive flow control techniques have been studied to address these issues, with passive techniques offering the advantage of no external energy requirement. High-lift devices, such as leading-edge slats, are promising in improving aerodynamic performance by controlling flow separation. This study explores the geometric parameters of slats and their effects on wind turbine blades’ aerodynamic and acoustic performance. Using an adequate turbulence model at Re = 106 for angles of attack from 14° to 24°, 77 slat configurations were evaluated. Symmetric slats showed superior performance at high angles of attack, while slat chord length was inversely proportional to aerodynamic improvement. A hybrid method was employed to predict noise, revealing slat-induced modifications in eddy topology and increased low- and high-frequency noise. This study’s main contribution is correlating slat-induced aerodynamic improvements with their acoustic effects. The directivity reveals a 10–15 dB reduction induced by the slat at 1 kHz, while the slat induces higher noise at higher frequencies. Full article
Show Figures

Figure 1

24 pages, 10038 KiB
Article
The Influence of Bleed Position on the Stability Expansion Effect of Self-Circulating Casing Treatment
by Haoguang Zhang, Jinhang Xiao, Xinyi Zhong, Yiming Feng and Wuli Chu
Aerospace 2024, 11(10), 852; https://doi.org/10.3390/aerospace11100852 - 16 Oct 2024
Cited by 2 | Viewed by 1090
Abstract
The self-circulating casing treatment can effectively expand the stable working range of the compressor, with little impact on its efficiency. With a single-stage transonic axial flow compressor NASA (National Aeronautics and Space Administration) Stage 35 as the research object, a multi-channel unsteady numerical [...] Read more.
The self-circulating casing treatment can effectively expand the stable working range of the compressor, with little impact on its efficiency. With a single-stage transonic axial flow compressor NASA (National Aeronautics and Space Administration) Stage 35 as the research object, a multi-channel unsteady numerical calculation method was used here to design three types of self-circulating casing treatment structures: 20% Ca (axial chord length of the rotor blade tip), 60% Ca, and 178% Ca (at this time, the bleed position is at the stator channel casing) from the leading edge of the blade tip. The effects of these three bleed positions on the self-circulating stability expansion effect and compressor performance were studied separately. The calculation results indicate that the further the bleed position is from the leading edge of the blade tip, the weaker the expansion ability of the self-circulating casing treatment, and the greater the negative impact on the peak efficiency and design point efficiency of the compressor. This is because the air inlet of the self-circulating casing with an air intake position of 20% Ca is located directly above the core area of the rotor blade top blockage, which can more effectively extract low-energy fluid from the blockage area. Compared to the other two bleed positions, it has the greatest inhibitory effect on the leakage vortex in the rotor blade tip gap and has the strongest ability to improve the blockage at the rotor blade tip. Therefore, 20% Ca from the leading edge of the blade tip has the strongest stability expansion ability, achieving a stall margin improvement of 11.28%. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

15 pages, 4422 KiB
Article
Aerodynamic Analysis of Blade Stall Flutter Prediction for Transonic Compressor Using Energy Method
by Ali Arshad and Akshay Murali
Aerospace 2024, 11(10), 815; https://doi.org/10.3390/aerospace11100815 - 6 Oct 2024
Viewed by 1577
Abstract
In this study, stall flutter onset prediction in a transonic compressor is carried out using the (uncoupled) energy method with Fourier transform. As the study is conducted computationally using computational fluid dynamics (CFD)-based simulations, the energy method was employed due to its higher [...] Read more.
In this study, stall flutter onset prediction in a transonic compressor is carried out using the (uncoupled) energy method with Fourier transform. As the study is conducted computationally using computational fluid dynamics (CFD)-based simulations, the energy method was employed due to its higher computational efficiency by implementing the one-way FSI (Fluid Structure Interaction) model. The energy method is relatively uncommon for determining the aerodynamic damping and flutter prediction, specifically in blade stall conditions for the 3D blade passages. The NASA Rotor 67 was chosen for the validation of the study due to the availability of a wide range of experimental data. A flutter prediction analysis was performed computationally using CFD for the two-blade passages of the rotor in the peak efficiency and stall regions. Prior to this, the modal analysis on the prestressed blade was conducted, considering the centrifugal effects. The modal analysis provided accurate blade frequency and amplitude, which were the inputs of the flutter analysis. The first three modes of blade resonance were studied with a range of nodal diameters within near-peak efficiency and stall regions. The energy method implemented in this study for the flutter analysis was successfully able to predict the aerodynamic damping coefficients of the first three modes for a range of nodal diameters from the periodic-unsteady solution of the defined blade oscillation within the regions of interest (peak efficiency and stall point). The results of the study confirm the rotor blade’s stability within the near-peak region and, most importantly, the prediction of the flutter onset in the stall region. The study concluded that the computationally inexpensive and time-efficient energy method is capable of predicting the stall flutter onset. In the future, further validations of the energy method and investigations related to flow mechanism of stall flutter onset are planned. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

15 pages, 10063 KiB
Article
Characteristics of Differential Entropy Generation in a Transonic Rotor and Its Applications to Casing Treatment Designs
by Jingyuan Ma, Yongsheng Wang and Feng Lin
Machines 2024, 12(10), 673; https://doi.org/10.3390/machines12100673 - 26 Sep 2024
Viewed by 827
Abstract
Casing treatments improve compressor stability but often at the expense of compressor efficiency. In this study, the differential entropy generation rate (DEGR) was applied to both efficiency evaluation and stall margin estimation. Rotor 67 was used as the compressor in this study and [...] Read more.
Casing treatments improve compressor stability but often at the expense of compressor efficiency. In this study, the differential entropy generation rate (DEGR) was applied to both efficiency evaluation and stall margin estimation. Rotor 67 was used as the compressor in this study and the simulation results were analyzed to correlate the distribution of the DEGR with the flow structures in the rotor at three rotating speeds. The characteristics of the DEGR at each speed were analyzed, exhibiting the characteristics of the flow structures at peak efficiency (PE) and near stall (NS) flow conditions. Loss analysis was conducted on the peak efficiency operating condition, particularly at 100% rotating speed. The critical state of the DEGR was investigated to identify stall occurrences on the near-stall condition. It was thus concluded that the DEGR can be a unified measure of both efficiency and stall margin. This theoretical exploration was subsequently applied to the design of casing treatments with two objectives: enhancing peak efficiency at 100% rotating speed and improving stability margins at all speeds. Two casing treatments were designed, with two circumferential grooves positioned axially at different locations. Their mechanisms for reducing the high DEGR area in the peak efficiency condition of 100% speed and suppressing an increase in DEGR during approaching stall were investigated, respectively. The results indicated that the presence of a groove near the leading edge of the blade tip can effectively suppress stall at all speeds. In order to achieve peak efficiency at high speeds, the extent of casing treatment coverage above the shock wave plays a crucial role in minimizing losses. Full article
(This article belongs to the Section Machine Design and Theory)
Show Figures

Figure 1

25 pages, 12203 KiB
Article
Influence Mechanism of Ambient Air Parameters on the Rotational Stall of an Axial Fan
by Hui Ma, Guangtong Tang, Chaoyang Wang, Tianlong Wang, Xin Li, Yonghui Jia, Yulong Qiu, Wei Yuan and Lei Zhang
Processes 2024, 12(8), 1781; https://doi.org/10.3390/pr12081781 - 22 Aug 2024
Viewed by 1365
Abstract
This study investigates a dual-stage axial-flow fan within a specific power plant context. Numerical simulations encompassing both steady-state and stall conditions were conducted utilizing the Reynolds-averaged Navier–Stokes (RANS) equations coupled with the Realizable kε turbulence model. The findings reveal that, under [...] Read more.
This study investigates a dual-stage axial-flow fan within a specific power plant context. Numerical simulations encompassing both steady-state and stall conditions were conducted utilizing the Reynolds-averaged Navier–Stokes (RANS) equations coupled with the Realizable kε turbulence model. The findings reveal that, under normal operating conditions, there exists a positive correlation between the mass flow rate and outlet pressure with gas density while displaying a negative correlation with dynamic viscosity. Regardless of the changes in air density, the volumetric flow rate at the maximum outlet pressure of the fan remains essentially the same. When a stall occurs, the volumetric flow rate rapidly decreases to a specific value and then decreases slowly. The analysis of the three-dimensional flow field within the first-stage rotor was performed before and after the rotational stall occurrence. Notably, stall inception predominantly manifests at the blade tip. As the flow rate diminishes, the leakage area at the blade tip within a passage expands, directing the trajectory of the leakage vortex toward the leading edge of the blade. Upon reaching a critical flow rate, the backflow induced by the blade tip leakage vortex obstructs the entire passage at the blade tip, progressively evolving into a stall cell, thereby affecting flow within both passages concurrently. Full article
(This article belongs to the Special Issue Challenges and Advances of Process Control Systems)
Show Figures

Figure 1

16 pages, 9070 KiB
Article
A Study on the Effect of Turbulence Intensity on Dual Vertical-Axis Wind Turbine Aerodynamic Performance
by Yanan Yang, Yang Cao, Zhong Qian, Jian Wang, Yixian Zhu, Xia Chen, Wendong Zhang, Yujie Wang, Guoqing Wu and Shaohua Chen
Energies 2024, 17(16), 4124; https://doi.org/10.3390/en17164124 - 19 Aug 2024
Cited by 4 | Viewed by 1938
Abstract
Examining dual vertical-axis wind turbines (VAWTs) across various turbulence scenarios is crucial for advancing the efficiency of urban energy generation and promoting sustainable development. This study introduces a novel approach by employing two-dimensional numerical analysis through computational fluid dynamics (CFD) software to investigate [...] Read more.
Examining dual vertical-axis wind turbines (VAWTs) across various turbulence scenarios is crucial for advancing the efficiency of urban energy generation and promoting sustainable development. This study introduces a novel approach by employing two-dimensional numerical analysis through computational fluid dynamics (CFD) software to investigate the performance of VAWTs under varying turbulence intensity conditions, a topic that has been relatively unexplored in existing research. The analysis focuses on the self-starting capabilities and the effective utilization of wind energy, which are key factors in urban wind turbine deployment. The results reveal that while the impact of increased turbulence intensity on the self-starting performance of VAWTs is modest, there is a significant improvement in wind energy utilization within a specific turbulence range, leading to an average power increase of 1.41%. This phenomenon is attributed to the more complex flow field induced by heightened turbulence intensity, which delays the onset of dynamic stall through non-uniform aerodynamic excitation of the blade boundary layer. Additionally, the inherent interaction among VAWTs contributes to enhanced turbine output power. However, this study also highlights the trade-off between increased power and the potential for significant fatigue issues in the turbine rotor. These findings provide new insights into the optimal deployment of VAWTs in urban environments, offering practical recommendations for maximizing energy efficiency while mitigating fatigue-related risks. Full article
(This article belongs to the Section A3: Wind, Wave and Tidal Energy)
Show Figures

Figure 1

27 pages, 13198 KiB
Article
An Evaluation of Passive Wall Treatment with Circumferential Grooves at the Casing of the First and Second Blade Rotor Rows of a High-Performance Multi-Stage Axial Compressor
by Ruben Bruno Diaz, Jesuino Takachi Tomita, Cleverson Bringhenti, Franco Jefferds dos Santos Silva and Diogo Ferraz Cavalca
Aerospace 2024, 11(8), 662; https://doi.org/10.3390/aerospace11080662 - 12 Aug 2024
Cited by 2 | Viewed by 1077
Abstract
The internal losses in the tip clearance region strongly influence the compressor performance and its operational range. Previous research proved that passive wall treatments with circumferential grooves in axial compressors effectively increase the compressor stall margin. The vortex generated inside the circumferential grooves [...] Read more.
The internal losses in the tip clearance region strongly influence the compressor performance and its operational range. Previous research proved that passive wall treatments with circumferential grooves in axial compressors effectively increase the compressor stall margin. The vortex generated inside the circumferential grooves creates a resistance to the flow that leaks into the tip clearance region of the compressor. However, most works found in the literature on circumferential grooves in axial compressors deal only with high-performance single-stage axial compressors. Therefore, there is a need to investigate and analyze the behavior of circumferential grooves in a multi-stage environment. In the present work, a passive wall treatment with circumferential grooves was implemented in a multi-stage axial compressor. Different configurations of circumferential grooves were created at the casing of the first and second rotor rows used in a four-stage axial flow compressor. Numerical simulations were performed to evaluate the influence of the circumferential grooves on the performance of a multi-stage axial compressor. The results obtained after the simulations for the different circumferential groove configurations were compared with the results obtained for the compressor without casing treatment (smooth wall) for different rotational speeds. Furthermore, the complete compressor map characteristics were simulated for the different casing treatment configurations, and the results were compared with the compressor characteristics of the smooth wall case. The passive wall treatment with circumferential grooves produced changes in the multi-stage axial compressor flow field, especially in the tip clearance region, improving the compressor stability mainly for part load speeds. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

23 pages, 8991 KiB
Article
Investigations on Trimming Strategy and Unsteady Aerodynamic Characteristics of Tiltrotor in Conversion Procedure
by Guoqing Zhao, Zhuangzhuang Cui, Qijun Zhao, Xi Chen and Peng Li
Aerospace 2024, 11(8), 632; https://doi.org/10.3390/aerospace11080632 - 1 Aug 2024
Cited by 1 | Viewed by 1745
Abstract
Numerical simulations were conducted to analyze the unsteady aerodynamic characteristics of a tiltrotor aircraft with different conversion strategies. Firstly, the CFD method was established by taking the interaction between the rotor and wing into account, as well as the body-fitted grid of the [...] Read more.
Numerical simulations were conducted to analyze the unsteady aerodynamic characteristics of a tiltrotor aircraft with different conversion strategies. Firstly, the CFD method was established by taking the interaction between the rotor and wing into account, as well as the body-fitted grid of the tiltrotor. Then, the trimming approach of the rotor and wing was developed to ensure longitudinal balance of the aircraft, and the method for determining the conversion corridor of the tiltrotor aircraft was proposed by considering the limitations imposed by wing stall and the required power of the rotor. Finally, the aerodynamic characteristics of the rotor and wing during the continuous conversion process were investigated, considering various tilting angular velocities and horizontal accelerations of the tiltrotor. The numerical results indicated that a smaller acceleration can enhance the efficiency of the tiltrotor. However, this would increase the complexity of trimming the fuselage attitude angle. It was also found that excessive acceleration could exceed the required power limit of the tiltrotor, rendering the conversion strategy infeasible. Full article
Show Figures

Figure 1
