Utilizing titanium diboride (TiB₂) inoculation for grain-refining purposes is a widely established practice in aluminum casthouses and foundries. Since this inoculation is usually implemented jointly with or between routine melt treatment steps ahead of casting, it is important to know whether and how other melt treatment processes affect the fade of TiB₂ particles. For the present study, we investigated the influence of degassing process on the separation behavior of TiB₂ particles in aluminum melt. Multiple sampling methods were employed and the samples were analyzed via spectrometer analysis. The removal efficiency of TiB₂ during the gas-purging process of 5083 aluminum melt was confirmed to be significant over 10 min of treatment time. The rate at which the TiB₂ content decays was found to increase with the impeller rotary speed from 400 rounds per minute (rpm) to 700 rpm. The separation rate of TiB₂ particles was obtained to be 0.05–0.08 min⁻¹ by fitting the experimental data. Particle mapping results suggest that the TiB₂ particles were separated to a dross layer. The obtained experimental results were used to quantitatively evaluate the conventional deterministic flotation model. The deviation between the conventional model and the experimental data was explained through the entrainment–entrapment (EE) model. Suggestions were made for future analytical and experimental works which may validate the EE model. Full article

Foundry Degassing Units (FDU) are used for refining aluminum alloys. For an ideal refining process using an FDU unit, it is necessary to select several parameters, which are linked to each other. For a rotary impeller, we searched for several parameters, such as its optimal shape, speed in the liquid alloy, and distance from the bottom of the refining ladle, where the aforementioned parameters contribute to the overall wear and life of the rotor and, consequently, of the rotor shaft. The Computational Fluid Dynamics (CFD) method can be used to determine the above-mentioned parameters. This paper describes the particular steps of preparation of rotor geometry for the subsequent setting up of the basic numerical model. Full article

Rotary Ultrasonic Machining (RUM) stands as a crucial method for machining hard and brittle materials. However, for machining hard-to-machine metal, it continues to face many challenges due to the complex vibration of the milling tool. Flank milling is an efficient method for machining complex parts, such as blisks and impellers, which have been widely used in aerospace field. However, current research is more focused on rotary ultrasonic end milling. In this context, we will study the surface integrity of rotary ultrasonic flank milling 40Cr steel using a self-developed RUM system. We delve into exploring the impacts of tool vibration on surface morphology, residual stress, and micro-hardness of the workpiece under various process parameters. The experimental findings reveal that rotary ultrasonic flank milling, in contrast to traditional flank milling techniques, significantly diminishes the surface roughness by about 40%. The reasons for the reduction of surface roughness are analyzed from the point of view of the cutting force. The surface roughness appears to be notably linked to both the average cutting force and the frequency domain characteristics. In addition, the experimental results indicate that rotary ultrasonic flank milling demonstrates the capacity to elevate the micro-hardness of the machined surface. Full article

An in-depth analysis of the flow patterns and mixing dynamics in a twin-paddle blender with bi-disperse non-spherical particles was investigated using the discrete element method (DEM) and experiments. This study aimed to explore the mixing efficiency of a twin-paddle blender containing two different shapes of non-spherical particles. The study focussed on the demonstration of the applicability of the GPU-based DEM model. To achieve this, calibration tests were performed using a classical rotary drum to validate the accuracy of the DEM model. The next step was to examine the impact of various operating parameters on the mixing performance, such as impeller rotational speed. The relative standard deviation (RSD) was employed as a measure of mixing performance. Results revealed that the rotational speed of the impellers had a significant impact on the mixing performance. Full article

Concern for the environment and rational management of resources requires the development of recoverable methods of obtaining metallic materials. This also applies to the production of aluminium and its alloys. The quality requirements of the market drive aluminium producers to use effective refining methods, and one of the most commonly used is blowing an inert gas into liquid aluminium via a rotating impeller. The efficiency and cost of this treatment depends largely on the application of the correct ratios between the basic parameters of the process, which are the flow rate of the inert gas, the speed of the rotor and the duration of the process. Determining these ratios in production conditions is expensive and difficult. This article presents the results of research aimed at determining the optimal ratio of the inert gas flow rate to the rotary impeller speed, using physical modeling techniques for the rotor as used in industrial conditions. The tests were carried out for rotary impeller speeds from 150 to 550 rpm and gas flow rates of 12, 17 and 22 dm³/min. The research was carried out on a 1:1 scale physical model, and the results, in the form of visualization of the degree of gas-bubble dispersion, were assessed on the basis of the five typical dispersion patterns. The removal of oxygen from water was carried out analogously to the process of removing hydrogen from aluminium. The curves of the rate of oxygen removal from the model liquid were determined, showing the course of oxygen reduction during refining with the same inert gas flows and rotor speeds mentioned above. Full article

The paper presents the results of tests carried out during the refining of the AlSi9Cu3(Fe) alloy in industrial conditions at the FDU stand. In the tests, three different rotors made of classical graphite, fine-grained graphite and classical graphite with SiC spraying were tested for the degree of wear. A series of tests was conducted for five cases—0% to 100% of consumption every 25%—corresponding to the cycles of the refining process. The number of cycles corresponding to 100% wear of each rotor was determined as 1112. The results of the rotor wear profile for all types of graphite after the assumed cycles are presented. Comparison of CAD models of new rotors and 3D scans of rotors in the final stage of operation revealed material losses during operational tests. The study assessed the efficiency of the rotor in terms of its service life as well as work efficiency. It was estimated on the basis of the calculated values of the Dichte Index (DI) and the density of the samples solidified in the vacuum. The structure of samples before and after refining at various stages of rotor wear is also presented, and the results are discussed. Full article

In this study, we have investigated the mixing kinetics and flow patterns of non-spherical particles in a horizontal double paddle blender using both experiments and the discrete element method (DEM). The experimental data were obtained using image analysis from a rotary drum containing cubical and cylindrical particles. Then, the experimental data were used in order to calibrate the DEM model. Using the calibrated DEM model, the effects of operating parameters such as vessel fill level, particle loading arrangement, and impeller rotational speed on the mixing performance were examined. The diffusivity coefficient was calculated to assess the mixing performance. Full article

Obtaining high-quality aluminum is associated with the use of an effective method of refining, which is argon-purging, in which gas bubbles are introduced into the liquid metal by means of rotary impellers. Various rotary impellers are used in the industry; however, if a newly designed impeller is constructed, it should be tested prior to industrial use. For this purpose, physical modeling is used, which enables the investigation of the phenomena occurring during refining and the selection of optimal processing parameters without costly research carried out in the industry. The newly designed rotary impeller was tested on the physical model of a URO-200 batch reactor. The flow rate of refining gas was: 10, 15 and 20 dm³·min⁻¹, whereas rotary impeller speed was 300, 400 and 500 rpm. The research consists of a visualization test showing the schemes of the gas bubbles’ dispersion level in the liquid metal and experiments for removing oxygen from water, which is an analogue of removing hydrogen from aluminum. Full article

Impellers are referred to as a core component of turbomachinery. The use of impellers in various applications is considered an integral part of the industry. So, increased performance and the optimization of impellers have been the center of attention of a lot of studies. In this regard, studies have been focused on the improvement of the efficiency of rotary machines through aerodynamic optimization, using high-performance materials and suitable manufacturing processes. As such, the use of polymers and polymer composites due to their lower weight when compared to metals has been the focus of studies. On the other hand, methods of the manufacturing process for polymer and polymer composite impellers such as conventional impeller manufacturing, injection molding and additive manufacturing can offer higher economic efficiency than similar metal parts. In this study, polymeric and polymer composites impellers are discussed and conclusions are drawn according to the manufacturing methods. Studies have shown promising results for the replacement of polymers and polymer composites instead of metals with respect to a suitable temperature range. In general, polymers showed a good ability to fabricate the impellers, however in more difficult working conditions considering the need for a substance with higher physical and mechanical properties necessitates the use of composite polymers. However, in some applications, the use of these materials needs further research and development. Full article

The present study addresses the incorporation of fine particles into liquids via the creation of a large-scale swirling vortex on the liquid free surface using a rotary impeller positioned along the axis of a cylindrical vessel. Four types of particles are used in the experiments to investigate the incorporation efficiency of the particles into a water bath under different impeller rotation speeds. Additionally, the vortex characteristics are investigated numerically. The results reveal that two factors, namely the particle wettability and turbulent oscillations at the bottom part of vortex surface, play dominant roles in determining the particle incorporation behavior. Hydrophobic particles are incapable of being incorporated into the water bath under any of the conditions examined in the present study. Partly wettable particles are entrained into the water bath, with the efficiency increasing with the impeller rotation speed and particle size. This is because an increase in the impeller rotation speed causes vortex deformation, whereby its bottom part approaches the impeller blades where the turbulent surface oscillations reach maximum amplitudes. Another possible mechanism of particle incorporation is the effect of capillary increases of liquid into the spaces between particles, which accumulate on the bottom surface of the vortex. Full article

The presented paper deals with the use of physical modelling to study the degassing process of aluminium melts in the refining ladle by blowing inert gas through a rotating impeller. For the purposes of physical modelling, a plexiglass model in a scale of 1:1 is used for the operating ladle. Part of the physical model is a hollow shaft used for gas supply that is equipped with an impeller and two baffles. The degassing process of aluminium melt by blowing of inert gas is simulated at physical modelling by a decrease of dissolved oxygen in the model liquid (water). This paper is aimed at the evaluation of laboratory experiments that were obtained by the method of physical modelling. Attention is focused on the assessment of relevant parameters for the degassing process—rotary impeller speeds, volume flow rate of inert gas, the distance of the impeller from the bottom of the refining ladle, and impeller variant. The preliminary results of physical modelling show that the optimal results of the refining process are achieved by using the F2A 190 impeller. Full article

In order to understand the pressure fluctuation characteristics of a semi-open cutting pump, the three-dimensional unsteady flow fields were calculated. External and internal flow characteristics of four schemes with different relative angles between the rotary cutter and the impeller were studied. The pressure fluctuations in the lower plate, the upper plate, the clearance between the rotary cutter and the fixed cutter, the first section in volute and nearby parts of the tongue were all analyzed, which are all the places that pressure distributions are greatly affected by the static and dynamic interaction, and at the same time, the force on the impeller was also analyzed. The results show that the fluctuations at different positions change periodically; the main frequency is blade frequency. The amplitude of pressure fluctuation decreases from near the rotating part to far away, from near the tongue to far from the tongue. Due to the influence of both impeller and rotary cutter, the pressure fluctuation on the lower plate is the largest. The pressure fluctuation is affected by flow rate, the larger the flow rate, the greater the pressure fluctuation. The radial and axial forces of the impeller change periodically with time, and the number of wave peaks and wave valleys is the same as the number of blades. Full article

A continuous-flow output mode of a rotary blood pump reduces the fluctuation range of arterial blood pressure and easily causes complications. For a centrifugal rotary blood pump, sinusoidal and pulsatile speed patterns are designed using the impeller speed modulation. This study aimed to analyze the hemodynamic characteristics and hemolysis of different speed patterns of a blood pump in patients with heart failure using computational fluid dynamics (CFD) and the lumped parameter model (LPM). The results showed that the impeller with three speed patterns (including the constant speed pattern) met the normal blood demand of the human body. The pulsating flow generated by the impeller speed modulation effectively increased the maximum pulse pressure (PP) to 12.7 mm Hg, but the hemolysis index (HI) in the sinusoidal and pulsatile speed patterns was higher than that in the constant speed pattern, which was about 2.1 × 10⁻⁵. The flow path of the pulsating flow field in the spiral groove of the hydrodynamic suspension bearing was uniform, but the alternating high shear stress (0~157 Pa) was caused by the impeller speed modulation, causing blood damage. Therefore, the rational modulation of the impeller speed and the structural optimization of a blood pump are important for improving hydrodynamic characteristics and hemolysis. Full article

The refining process is one of the essential stages of aluminum production. Its main aim is to remove hydrogen, that causes porosity and weakens the mechanical and physical properties of casting aluminum. The process is mainly conducted by purging inert gas through the liquid metal, using rotary impellers. The geometry of the impellers and the processing parameters, such as flow rate of gas and rotary impeller speed, influence the gas dispersion level, and therefore the efficiency of the process. Improving the process, and optimization of parameters, can be done by physical modelling. In this paper, the research was carried out with the use of a water model of batch reactor, testing three different rotary impellers. Varied methods were used: visualization, which can help to evaluate the level of dispersion of gas bubbles in liquid metal; determination of residence time distribution (RTD) curves, which was obtained by measuring the conductivity of NaCl tracer in the fluid; and indirect studies, completed by measuring the content of dissolved oxygen in water to simulate hydrogen desorption. The research was carried out for different processing parameters, such as flow rate of refining gas (5–25 L·min⁻¹) and rotary impeller speed (3.33–8.33 s⁻¹). The obtained results were presented graphically and discussed in detail. Full article

Conventional magnet manufacturing is a significant bottleneck in the development processes of products that use magnets, because every design adaption requires production steps with long lead times. Additive manufacturing of magnetic components delivers the opportunity to shift to agile and test-driven development in early prototyping stages, as well as new possibilities for complex designs. In an effort to simplify integration of magnetic components, the current work presents a method to directly print polymer-bonded hard magnets of arbitrary shape into thermoplastic parts by fused deposition modeling. This method was applied to an early prototype design of a rotary blood pump with magnetic bearing and magnetic drive coupling. Thermoplastics were compounded with 56 vol.% isotropic NdFeB powder to manufacture printable filament. With a powder loading of 56 vol.%, remanences of 350 mT and adequate mechanical flexibility for robust processability were achieved. This compound allowed us to print a prototype of a turbodynamic pump with integrated magnets in the impeller and housing in one piece on a low-cost, end-user 3D printer. Then, the magnetic components in the printed pump were fully magnetized in a pulsed Bitter coil. The pump impeller is driven by magnetic coupling to non-printed permanent magnets rotated by a brushless DC motor, resulting in a flow rate of 3 L/min at 1000 rpm. For the first time, an application of combined multi-material and magnet printing by fused deposition modeling was shown. The presented process significantly simplifies the prototyping of products that use magnets, such as rotary blood pumps, and opens the door for more complex and innovative designs. It will also help postpone the shift to conventional manufacturing methods to later phases of the development process. Full article
