Current research on the vibration characteristics of fastener clips primarily employs modal experiments combined with finite element simulations; however, limited attention has been given to the dynamic vibration behavior of clips during actual train operations. This study investigates both the quasi-static and dynamic vibration characteristics using an integrated approach of finite element simulation and dynamic testing. Based on the Vossloh W300-1 fastener system, a three-dimensional model is established. Modal and frequency response analyses, together with field test validation, reveal two significant vibration modes within 0–1000 Hz: a first-order mode at 500 Hz and a second-order mode at 560 Hz. These modes are characterized by vertical overturning of the clip arm. Dynamic testing demonstrates that the dominant frequency of the arm acceleration is strongly correlated with the second-order natural frequency, confirming that wheel–rail excitation readily triggers second-order mode resonance. The study further shows that, at train speeds of 200–350 km/h, rail corrugation with wavelengths of 99.2–173.6 mm induces high-frequency excitation at 560 Hz, resulting in resonance fatigue of the clip. As a mitigation measure, regular rail grinding is recommended to eliminate corrugation at critical wavelengths. Additionally, optimizing the clip structure to avoid resonance frequency bands is proposed. These findings elucidate the coupling mechanism between the vibration characteristics of the clip and dynamic loads, providing theoretical support for the safety evaluation of high-speed rail fastener systems and the vibration-resistant design of clips. Full article

This paper presents a nonlinear vertical dynamic model of an electromagnetic suspension (EMS) system in maglev trains regulated by a dual nonlinear saturation controller (DNSC) under simultaneous resonance ($\Omega \cong {\omega }_s,{\omega }_s\cong 2{\omega }_c$). The governing nonlinear differential equations of the system are addressed analytically utilizing the multiple time-scale technique (MTST), concentrating on resonance situations obtained from first-order approximations. The suggested controller incorporates two nonlinear saturation functions in the feedback and feedforward paths to improve system stability, decrease vibration levels, and enhance passenger comfort amidst external disturbances and parameter changes. The dynamic bifurcations caused by DNSC parameters are examined through phase portraits and time history diagrams. The goal of control is to minimize vibration amplitude through the implementation of a dual nonlinear saturation control law based on displacement and velocity feedback signals. A comparative analysis is performed on different controllers such as integral resonance control (IRC), positive position feedback (PPF), nonlinear integrated PPF (NIPPF), proportional integral derivative (PID), and DNSC to determine the best approach for vibration reduction in maglev trains. DNSC serves as an effective control approach designed to minimize vibrations and enhance the stability of suspension systems in maglev trains. Stability evaluation under concurrent resonance is conducted utilizing the Routh–Hurwitz criterion. MATLAB 18.2 numerical simulations (fourth-order Runge–Kutta) are employed to analyze time-history responses, the effects of system parameters, and the performance of controllers. The evaluation of all the derived solutions was conducted to verify the findings. Additionally, quadratic velocity feedback leads to intricate bifurcation dynamics. In the time domain, higher displacement and quadratic velocity feedback may destabilize the system, leading to shifts between periodic and chaotic movements. These results emphasize the substantial impact of DNSC on the dynamic performance of electromagnetic suspension systems. Frequency response, bifurcation, and time-domain evaluations demonstrate that the DNSC successfully reduces nonlinear oscillations and chaotic dynamics in the EMS system while attaining enhanced transient performance and resilience. Full article

A compliant parallel multi-directional piezoelectric vibration energy harvester (C-MVEH) is proposed based on a 3-RRR compliant parallel mechanism. The energy harvester structure consists of three identical L-shaped beams, whose bending deformation can be equivalent to the rotations of the three joints. In order to achieve greater bending deformation for composite beams, motion flexibility optimization of the mechanism theory is applied to structure the synthesis of the C-MVEH. Meanwhile, to reduce the natural frequencies corresponding to the working modes, the length of the elastic beam is optimized with the maximum natural frequency among the first three modes. In order to verify the excellent performance of the C-MVEH, an electromechanical model, finite element simulations, and experimental studies are carried out. Analysis of the studies reveals that the C-MVEH has three resonance peaks of output voltage within a bandwidth of 7–13 Hz and can output a total voltage of at least 20 V under a small excitation of 0.2 g. The energy harvester can achieve multiple peak output voltages under small excitations in different directions and a wide frequency range. With its outstanding stability, the proposed C-MVEH demonstrates considerable application value in the supplying of power to microenergy electronic devices, such as smart sensors and microactuators. Full article

To address the issue of low efficiency in recovering low-frequency vibration energy during vehicle operation, this paper proposes a piezoelectric energy capture harvester based on wheel vibration. The device employs a parallel configuration of dual cantilever beam piezoelectric transducers in its mechanical structure, with additional mass blocks to optimize its resonant characteristics in the low-frequency range. A synchronous switch energy harvesting circuit was designed. By actively synchronizing the switch with the peak output voltage of the piezoelectric element, it effectively circumvents the turn-on voltage threshold limitations of diodes in bridge rectifier circuits, thereby enhancing energy conversion efficiency. A dynamic model of this device was established, and multiphysics simulation analysis was conducted using COMSOL-Multiphysics to investigate the modal characteristics, stress distribution, and output performance of the energy harvester. This revealed the influence of the piezoelectric vibrator’s thickness ratio and the mass block’s weight on its power generation capabilities. Experimental results indicate that under 20 Hz, 12 V sinusoidal excitation, the system achieves an average output power of 3.019 mW with an average open-circuit voltage reaching 16.70 V. Under simulated road test conditions at 70 km/h, the output voltage remained stable at 6.86 V, validating its feasibility in real-world applications. This study presents an efficient and reliable solution for self-powering in-vehicle wireless sensors and low-power electronic devices through mechatronic co-design. Full article

This article explores whether jerk, the derivative of acceleration, should be limited in trajectory planning for position-controlled mechanical systems or in the controller. The excess jerk excites structural resonances and increases actuator wear, motivating the use of a limited jerk. However, we question the necessity of incorporating the jerk directly in trajectory planning by comparing third-order jerk-limited trajectories with second-order trajectories with reduced controller bandwidth that regulate torque gradients. We demonstrate by a typical practical application that reducing controller bandwidth can achieve comparable or superior jerk reduction without extending overall motion time for point-to-point trajectories. As a result, second-order parabolic trajectory profiles simplify on-line implementation. This investigation relies on a detailed sensitivity analysis of a one-dimensional model, incorporating crucial elements such as signal and sensor quantisation, sampling, and modes of structural resonances. The study shows that smooth trajectories reduce resonant vibrations and wear, but the jerk limitation may be addressed more effectively within the controller rather than within the trajectory generator. We conclude that although the limitation of the jerk in the trajectories is valuable, feedback controllers can reduce the jerk more effectively by bandwidth reduction, allowing simpler point-to-point trajectory designs without compromising performance. Full article

This study presents an optimal design methodology for a piezoelectric-based bladeless wind turbine (BWT) that efficiently converts wind-induced vibration of a cantilever-mounted cylinder into electrical energy. A lumped-parameter model integrating structural dynamics, fluid-structure interaction, and piezoelectric energy conversion is introduced and simplified to derive key dimensionless design parameters and optimal conditions for maximizing power output. The optimal design criteria are as follows: tuning the resonance between the structural natural frequency and vortex shedding frequency; setting the dimensionless load resistance R* to unity; and minimizing ω_nR_LC_eq to a value smaller than unity. Numerical simulations and wind tunnel experiments validate the model, showing good agreement with less than 7% error in power prediction under resonance conditions and successfully predicting the coupled behavior of fluid, structure, and piezoelectric components. The proposed optimal design methodology facilitates the development of compact and efficient piezoelectric-based bladeless wind energy harvesting systems suitable for urban and space-constrained environments. Full article

Designed to mitigate the significant low-frequency vibration and noise inherent in conventional marine centrifugal pump systems, the magnetic levitation pump constitutes a novel form of centrifugal pump employing active magnetic bearing technology. While this fully levitated design effectively enhances vibration and noise performance, it results in the complete immersion of the rotor within a confined fluid domain, which contains narrow fluid clearances. This poses significant challenges for the accurate computation of rotor wet modes, which is crucial for the structural design of the rotor system to avoid the resonance induced by flow. Despite exerting a substantially greater influence on rotor wet modal characteristics than unconfined domains, the analysis of rotors under confined fluid conditions has received comparatively little research attention. This study focuses on two types of magnetic levitation pump rotors. From the perspective of analytical modeling, an improved analytical method for wet modal computation based on added mass correction is proposed. The validation of this method included examining two distinct computational approaches for the added mass, the thickening treatment for axially elongated disk components, and the methodology for implementing disk equivalent density. Based on this foundation, wet modal analysis was performed on both rotors utilizing the proposed analytical method, alongside acoustic fluid–structure interaction simulations. The results indicate that for the first bending mode, the errors between the analytical and experimental values are 1.2% and 4.1%, respectively, while the discrepancies between the simulated and experimental values are 0.1% and 3.2%. Finally, regularity analysis was conducted on the wet modal characteristics of the rotor under confined water, considering various fluid clearances. The results reveal that the first three bending modes generally exhibit an increasing trend with the enlargement of the fluid clearance, with a triple-size annulus serving as a transition point. However, increasing the annulus size does not always elevate the modal frequencies above their initial values. This study contributes to understanding the influence mechanisms of confined water on the wet modal properties of magnetic levitation pump rotors. Furthermore, the proposed analytical method improved computational efficiency for the early design stages of water-immersed rotors, alongside a model of greater accuracy essential for magnetic bearing control. Full article

The dynamic characterization of historical buildings located in a complex geological and seismological context is essential to assess seismic vulnerability and to guide conservation strategies. This study presents a non-invasive, ambient vibration-based, investigation of the Norman Castle of Aci Castello (Sicily, Italy), applying Horizontal to Vertical Spectral Ratio (HVSR), Horizontal to Horizontal Spectral Ratio (HHSR), and Random Decrement Method (RDM) to evaluate the structure’s dynamic behavior and potential Soil–Structure Interaction (SSI) effects. The fundamental site frequency, estimated within a broad plateau in the range 2.05–2.70 Hz, does not overlap with the structural frequencies of the castle, which range approximately from 6.30 Hz to 9.00 Hz in the N–S structural direction and from 3.50 Hz to 8.50 Hz in the E–W direction, indicating absence of global SSI resonance. However, the structure exhibits a complex multimodal response, with direction-dependent behavior evident both in spectral peaks and in damping ratios, ranging from 2.10–7.73% along N–S and 0.90–5.84% along E–W. These behaviors can be interpreted as possibly linked to structural complexity and the interaction with the fractured volcanic substrate, characterized by shallow cavities, as well as to the material degradation of the masonry. In particular, the localized presence of subsurface voids may induce a perturbation of the low-frequency ambient vibration wavefield (e.g., microseisms), producing a localized increase in spectral amplitude observed at Level I. The analysis indicates the absence of global SSI resonance due to the lack of overlap between site and structural fundamental frequencies, while significant local SSI effects, mainly related to cavity-induced wavefield perturbation, are observed and may represent a potential vulnerability factor. These findings highlight the relevance of vibration-based diagnostics for heritage vulnerability assessment and conservation strategies. Full article

Piezoelectric vibration energy harvesters (PVEHs) have demonstrated their potential for sustainable energy generation from diverse ambient vibrations for low-power devices and systems. However, great challenges remain concerning harvesting more energy from low-frequency input sources and broadband random excitations. In this paper, a novel PVEH featuring a lead zirconate titanate (PZT) hollowed trapezoidal cantilever beam is proposed, simulated, optimized and fabricated to effectively broaden its output bandwidth at low frequency ranges. Under 1 g acceleration, the traditional solid PVEH showed a resonant frequency of 47.80 Hz and a maximum output power density of 14.22 mW/cm³, while the proposed PVEH showed two resonant frequencies of 21.30 Hz and 50.40 Hz. Compared to the traditional solid PVEH, the first-order resonant frequency was reduced by 55.44% and the corresponding maximum output power density was 3.3 times higher in the proposed PVEH. Furthermore, a parallel synchronized switch harvesting inductor quadruple voltage rectifier (P-SSHI-QVR) circuit is designed to extract energy from the proposed PVEH. For the proposed PVEH incorporating the P-SSHI-QVR circuit, the maximum stored voltage was 20.49 V at a first-order resonant frequency of 21.30 Hz and 5.68 V at a second-order resonant frequency of 50.40 Hz, with corresponding maximum stored powers of 36.89 μW and 2.97 μW, respectively. This study verified the feasibility of the optimized design through simulation and experimental comparison. Full article

Long-span steel box girder suspension bridges are prone to vortex-induced vibrations (VIVs) due to their light weight, flexible characteristics, and low structural damping. Traditional temporary aerodynamic measures, although effective in vibration suppression, involve prolonged construction periods and high costs, leading to traffic disruptions and considerable socio-economic losses. To address these limitations, this study implemented rapid vibration suppression by prescribing designated lanes and traveling speeds for vehicles with varying aerodynamic configurations, dynamically arranged on the bridge deck for efficient vibration control. Through CFD numerical simulations, the influence of vehicle placement on vibration suppression efficiency was systematically investigated. The results indicated that the strategic arrangement of vehicles could reduce the root-mean-square (RMS) amplitude of VIV of the main girder by more than 75%, with suppression efficiency significantly correlated with the spatial distribution of the vehicles. Moreover, the suppression mechanism was analyzed, revealing that resonance occurs when the vortex-shedding frequency matches the natural frequency of the main girder in the absence of suppression measures. Vehicle deployment alters the vortex-shedding frequency from the bridge surface, shifting it away from the structural natural frequency, while simultaneously weakening the periodic energy input from vortex shedding, thus effectively mitigating the vibration response. Full article

This paper presents a comparative analysis of the influence of Fused Deposition Modeling (FDM) parameters—specifically material type, infill geometry, and density—on the vibro-acoustic characteristics of loudspeaker enclosures. The enclosures were designed as exponential horns to intensify resonance phenomena for precise evaluation. Twelve unique configurations were fabricated using three materials with distinct damping properties (PLA, ABS, wood-composite) and three internal geometries (linear, honeycomb, Gyroid). Key vibro-acoustic properties were assessed via digital signal processing of recorded audio signals, including relative frequency response and time-frequency (spectrogram) analysis, and correlated with a predictive Finite Element Analysis (FEA) model of mechanical vibrations. The study unequivocally demonstrates that a material with a high internal damping coefficient is a critical factor. The wood-composite enabled a reduction in the main resonance amplitude by approximately 4 dB compared to PLA with the same geometry, corresponding to a predicted 86% reduction in mechanical vibration. Furthermore, the results show that a synergy between a high-damping material and an advanced, energy-dissipating infill (Gyroid) is crucial for achieving high acoustic fidelity. The wood-composite with 10% Gyroid infill was identified as the optimal design, offering the most effective resonance damping and the most neutral tonal characteristic. This work provides a valuable contribution to the field by establishing a clear link between FDM parameters and acoustic outcomes, delivering practical guidelines for performance optimization in personalized audio systems. Full article

This paper presents a physics-informed, tacholess pipeline for smartphone-grade Noise, Vibration, and Harshness (NVH) diagnosis in electric vehicle powertrains. A configurable generator synthesizes labeled signals with order components (1×/2×/3×), AM/FM modulation, sub-harmonics, impact-driven ring-down near resonance, and realistic white/pink/ambient noise at phone bandwidths. A ridge-guided harmonic comb recenters orders without a tachometer and splits tonal from residual content. Interpretable features—order-invariant ratios ($E_{2\times }/E_{1\times }$, ${\mathrm{S}\mathrm{B}}_1$/$E_{1\times }$, $E_{0.5\times }/E_{1\times }$) and residual descriptors (band-power, kurtosis, cepstrum/WPT)—feed light-compute models. A reproducible benchmark stresses SNR (−5…+10 dB), RPM profiles (ramp/steps/cycles), and simulated domain shift; parameter-to-feature analyses (with Sobol sensitivity and a delta-method identifiability proxy) quantify measurability under phone constraints. Across a five-fold CV, tacholess order tracking increases tonal SNR by ≥+6 dB and yields macro-F1 ≈ 0.86 with Random Forest, while ordinal severity achieves QWK ≈ 0.81 (ECE ≈ 0.06) and regression attains MAE ≈ 0.12 (R² ≈ 0.78). All code, datasets, figures, and tables regenerate from fixed seeds with one-command builds; a data card and a sim-to-real guide are included. The result is an open, low-compute standard that couples reproducibility with physics-aligned interpretability, providing a practical baseline for EV NVH diagnostics with smartphones and a common ground for future field validation. Full article

The design-related behaviour of structural dynamics for electric-assisted bicycle (e-bike) drive units significantly influences the mechanical system—e.g., vibrations and durability, stresses and loads, or functionality and comfort. Identifying the underlying mechanical principles opens up optimisation possibilities, such as improved e-bike design and user experience. Despite its potential to enhance the system, the structural dynamics of the drive unit have received little research attention to date. To improve the current situation, this paper uses a flexible multibody modelling approach, enabling new insights through virtual trials and analyses that are not feasible solely from measurements. The incorporation of the drive unit’s system-level topology regarding mass, moment of inertia, stiffness, and damping enables the analysis of critical system states. Experiments accompany the analysis and validate the model by demonstrating a load-dependent shift of the first torsional mode around 35 Hz to 60 Hz, capturing comparable resonance frequency ranges up to 6 kHz, and yielding qualitatively consistent peak positions in both steady-state and ramp-up analyses (mean deviations of 0.03% and 0.06%, respectively). Theoretical considerations of the multibody system highlight the effects, and the stated modelling restrictions make the method’s limitations transparent. The key findings are that the drive unit’s structural dynamic behaviour exhibits solely one structural mode until 0.5 kHz, and further 27 modes up to 10 kHz, solely originating due to the multibody arrangement of the drivetrain. These modes are also load-dependent and lead to resonances during operation. In summary, the approach enables engineers, for the first time, to significantly improve the structural dynamics of the e-bike drive unit using a full-scale system model. Full article

To broaden the operating bandwidth of the vibration energy harvester at low frequencies, this paper presents a cantilever beam piezoelectric energy harvester (PEH) based on the sloshing of a liquid-filled container. The harvester is designed to recover energy from the multi-order sloshing modes of the liquid in the container. A mathematical model of the coupled system comprising the liquid within the container and the PEH was established. Based on the fluid–structure interaction (FSI) theory, the coupling mechanism between the liquid natural sloshing frequency and the immersed natural frequency of the beam was revealed. Experimental validation shows that the resonance characteristics of the PEH are mainly dominated by the liquid antisymmetric sloshing mode. Through comparative experiments, the effect of liquid-filled container and cantilever beam parameters on the PEH’s peak output voltage and operating bandwidth was systematically analysed. The performance of the PEH was significantly improved when the first-order natural frequency of the partially immersed beam approached the liquid natural sloshing frequency, with the bandwidth coefficient increasing by nearly fourfold under this condition. This research provides new ideas for the design and optimisation of piezoelectric energy harvesters in liquid sloshing environments. Full article

A dual-resonant ultrasonic motor is designed with an independent dual-oscillator configuration. The performance of this motor depends on both the structural parameters of the dual oscillators and the vibration mode combinations (i.e., vibration mode matching) between the stator and rotor. However, due to the relatively complex theoretical model of the dual-oscillator ultrasonic motor, two key performance indicators—maximum output torque and maximum speed—exhibit a mutually exclusive relationship. This poses significant challenges to the accurate characterization and optimization of the motor’s performance. To address this issue, this study first adopts a back propagation (BP) neural network fitting approach to establish the complex functional relationship between the optimization parameters and performance objectives, thereby achieving a scientific fitting of the motor’s theoretical model. Subsequently, the Non-dominated Sorting Genetic Algorithm II (NSGA-II)—well-suited for handling mutually exclusive multi-objective optimization problems—is employed to optimize the motor’s performance. Finally, based on the obtained Pareto optimal solution set, the oscillator’s structural parameters that meet the performance requirements are determined. Full article
