The diversity of commercial tree planting sites, with their distinct environmental conditions, directly influences tree growth and consequently impacts the wood properties in various ways. However, there is limited research evaluating the impact of these variations in nondestructive testing. Therefore, this study aimed to investigate whether edaphoclimatic variations affect parameters obtained through nondestructive tests conducted on standing trees. To this end, 30 specimens were selected from 3 Eucalyptus sp. clones, aged 1, 3, and 4 years, grown in 2 regions, totaling 540 trees. Tree development was monitored quarterly over 12 months. The tests included ultrasound propagation, drilling resistance, and penetration resistance, and the trees were measured for diameter at breast height (DBH) and height. Among the edaphoclimatic factors evaluated, only temperature and soil water storage differed statistically between the two study regions. The higher temperature and lower soil water storage in region 2 promoted tree growth, with these trees showing greater drilling resistance and higher longitudinal wave velocities. In addition, the influence of climatic factors was evidenced by the variation of wave propagation velocity throughout the year. Periods of lower water availability resulted in higher velocities, while periods of greater precipitation were associated with lower velocities. The research results showed that temperature and soil water storage had significant effects on tree growth (DBH and height), as well as ultrasound wave propagation velocity and drilling resistance. Full article

Eucalyptus-based glued laminated timber (glulam) was produced to determine the feasibility of a non-destructive method (drilling resistance) to predict the properties of structural elements and add value to lower-quality hardwood species. Glulam was manufactured with formaldehyde (Resorcinol), reference condition, and bio-based (Castor oil-based) adhesives in two assembly schemes, the core composed either of two continuous lamellae each 105 cm long, or of two formed by the juxtaposition of shorter boards (35 and 55 cm). The shear strength of the glue line (f_v0), modulus of elasticity (E_c90), and strength (f_c90) in compression perpendicular to the grain; delamination (DL); and main and extended glue line thicknesses were evaluated. The Resistograph equipment was used to perform the perforation perpendicular to the glue line (samples extracted from the glulam elements) to correlate the properties. The results of this research demonstrate that the scheme of the boards had little effect on the physical and mechanical properties evaluated (except the main glue line and delamination), and the drilling resistance (DR) presents a significant correlation with practically all properties evaluated (variations in density values and other properties are explained by variations in DR values), making it possible to estimate E_c90 and f_c90 with desired precision (R²_adj ≈ 80%). This highlights the feasibility of using this methodology in the quality control of glulam elements. It is concluded that regardless of the adhesive, elements comprising a 105 cm-length core and external lamellae (T1 and control) are indicated for external use, presenting low delamination. Short-length central lamellae adhesively glued with PUR (T2) are not recommended for external applications due to their susceptibility to delamination. However, T2 is indicated for internal environments due to its low production cost. This study also proved the efficiency of using models based on drilling resistance to estimate wood density and its resistance to compression perpendicular to the fiber. Full article

Intending to safeguard architectural heritage, the assessment of the health of timber structures is crucial, though challenging, due to the organic nature of wood and to the uncertainties of its preservation state. To this end, useful support is provided by the ICOMOS guidelines, which provide conservation strategies based on thorough diagnosis and safety evaluations. In this context, the study summarized in this paper focuses on the medieval Tower of Montorio, which suffered considerable damage due to the strong earthquake that occurred in those area in September 2003. Its subsequent process of rehabilitation and restoration involved a widespread experimental campaign and the substitution of some timber beams. This circumstance has offered a rare opportunity to study these ancient elements in detail, although they are limited in number. Six beams made of oak and removed from an intermediate floor of the tower were evaluated through a comprehensive approach that included both non-destructive tests (NDT) and destructive tests (DT). Particularly, they were subjected to visual inspections, ultrasonic, sclerometric, and resistographic methods, and destructive four-point bending tests. Overall, the study presented here provides a useful qualitative comparison between them. Results highlighted that relying only on NDT might lead to an overestimation of mechanical properties and that combining NDT with DT is crucial for a more accurate assessment. Therefore, the need to deepen the research on correlations between NDT and DT to obtain reliable values of mechanical properties while respecting the conservation aim was confirmed. Full article

To improve the estimation accuracy of wood density and study the linear correlation between drill feed resistance and wood density, a new micro drill instrument prototype that can simultaneously measure the rotation resistance and feed resistance of the drill needle was designed. The test tree species included hard and soft broad-leaved trees and coniferous trees, and the absolute dry density of each wood sample was measured. The drill resistance data were tested by our newly proposed prototype and a Resistograph 650-SC, and four linear models were established to define the relation between drill resistance and the absolute dry density of the wood. The results showed that (1) the statistical indicators of each model for our proposed prototype were better than the corresponding indicators of the Resistograph 650-SC for three of the four species tested; (2) the coefficient of determination of the linear regression model between the feed resistance of our proposed prototype and the absolute dry density of wood was 0.946; and (3) the statistical indicators of the model that included rotation resistance and feed resistance were better than those of the model that only including rotation resistance. Although the proposed prototype produced a competitive level of accuracy and explicitly demonstrated that including feed resistance improved wood density measurement accuracy, the prototype should be considered a first iteration as further hardware design changes and in-forest performance assessments across wider diverse set of test species are required before a conclusive evaluation can be rendered. Full article

Wood is very present in the structures of old buildings and real estate with historical value. Yet, as a biodegradable material, it is highly vulnerable to adverse environmental conditions, such as permanent high humidity and attacks by xylophages. Furthermore, being a natural material, wood has great potential for low-carbon building within a circular economy. To preserve historical wooden structures, periodic inspections, preferably non-destructive or minimally invasive, are needed. Inspection may involve visual or resistographic testing techniques. However, both of these methods are time consuming and inaccurate. In this work, the joint use of techniques is proposed, in order to make multi-feature decisions about the repair or replacement of elements. The acoustic emission technique is proposed to determine active xylophages, the elastic wave technique to determine the dynamic elastic modulus and the resistance class, and finite element numerical modelling to determine the state of deformation and structural capacity. An old beam floor from a historic building in the center of Granada, Spain, was used as a practical case. The results demonstrate the effectiveness of a multi-analysis, instead of a single analysis, in arriving at correct decision making. Full article

Predicting future stand conditions based on tree age is crucial for natural forest management. The objective of this study was to model and predict the future age distribution of Picea jezoensis, Abies sachalinensis, and broad-leaved trees by assessing the past and current survival trends of preserved stands located at the University of Tokyo Hokkaido Forests (UTHF), Furano, Japan. This study analyzed forest census data of four plots (927 trees) in a preserved permanent area over 30 years (1989–2019). Individual tree-ring data were identified using a resistograph to determine the current tree age of the targeted trees. The predicted age distributions nearly converged to the shape of the survival probability curve. Among the scenario predictions, the multimodal age class distribution of P. jezoensis was predominant among all prediction scenarios. In contrast, the exponential shape of A sachalinensis and the age distribution of broad-leaved trees in the 100% scenario gradually shifted to the multimodal shape at the 50% scenario prediction. The species composition of conifer and broad-leaved trees and their age distribution would reach stable states in the long run by reaching a climax state. Therefore, it is theoretically possible to maintain stands under the pre-climax stage by allowing high growth rates at the stand level. The suggested age class-prediction of living and dead trees can improve the natural forest management of UTHF. Full article

To determine the appropriate final use of wood from a particular tree species, it is first necessary to know its properties. Methods that use wood samples taken directly from the trunk of a growing or felled tree are very time-consuming and require a great deal of manual work. Non-destructive methods may be more effective and much faster, thanks to the use of advanced technologies. The resistance drilling can be used to determine the variation in wood density along the radius of the stem. The main aim of the present study was to determine the basic density of the wood on a cross-section of the trunk of oak trees and to investigate the correlation of the results with those obtained by drilling the same trees with the IML RESI-PD 400. The results of Spearman’s correlation test showed strong positive correlations between all examined properties. We observed a trend whereby the density of the wood and Resi amplitude increased in direct proportion to the width of the annual rings. The results of linear regression show a strong relationship between examined properties. This study provide evidence that the Resi is an appropriate tool for non-destructive determination of wood density. Full article

Scientifically sound methods are essential to estimate the survival of trees, as they can substantially support sustainable management of natural forest resources. Tree mortality assessments have mainly been based on forest inventories and are mostly limited to planted forests; few studies have conducted age-based survival analyses in natural forests. We performed survival analyses of individual tree populations in natural forest stands to evaluate differences in the survival of two coniferous species (Abies sachalinensis (F. Schmidt) Mast. and Picea jezoensis var. microsperma) and all broad-leaved species. We used tree rings and census data from four preserved permanent plots in pan-mixed and sub-boreal natural forests obtained over 30 years (1989–2019). All living trees (diameter at breast height ≥ 5 cm in 1989) were targeted to identify tree ages using a Resistograph. Periodical tree age data, for a 10-year age class, were obtained during three consecutive observation periods. Mortality and recruitment changes were recorded to analyze multi-temporal age distributions and mean lifetimes. Non-parametric survival analyses revealed a multi-modal age distribution and exponential shapes. There were no significant differences among survival probabilities of species in different periods, except for broad-leaved species, which had longer mean lifetimes in each period than coniferous species. The estimated practical mean lifetime and diameter at breast height values of each coniferous and broad-leaved tree can be applied as an early identification system for trees likely to die to facilitate the Stand-based Silvicultural Management System of the University of Tokyo Hokkaido Forest. However, the survival probabilities estimated in this study should be used carefully in long-term forest dynamic predictions because the analysis did not include the effects of catastrophic disturbances, which might significantly influence forests. The mortality patterns and survival probabilities reported in this study are valuable for understanding the stand dynamics of natural forests associated with the mortality of individual tree populations. Full article

In China, preserving historic trees and ancient timber structures has attracted more attention from researchers and institutions. Nondestructive testing (NDT) technology has gained momentum in the application and research in recent years. This paper presents some examples of the application of NDT techniques in the protection of historic trees and ancient timber structures in China. A total of nine NDT techniques were applied, including five techniques of visual inspection, sounding, Resistograph, stress wave transmission velocity, stress wave tomography for both historic trees and ancient timber structures, two techniques of the pulling-test and ground-penetrating radar (GPR) for historic trees alone, and two techniques of acoustic emission (AE) and digital imaging for ancient timber structures. Based on field testing, there is a very good detecting effect for visual inspection and Resistograph, but sounding works unsatisfactorily. The stress wave transmission velocity is found to be excellent in screening for the internal defects of historic tree trunks, but performs badly in screening for the internal defects within the wood members of ancient timber structures. AE is less successful but digital imaging performs well in long-term monitoring and damage warning of wood structures. The stress wave tomography successfully obtains images of internal defects inside tree trunks. The anchorage of some historic trees cannot be quantitatively evaluated with the pulling test if the tree is too large. GPR’s resolution and accuracy are very low, which limit its application. Theoretical research on NDT and promotion of NDT technology are still an essential part of the work in the future. Full article

Buildings on piles have been constructed in Ljubljana since the Bronze Age. The piles were made of different types of wood. In the present study, piles that were erected about 125 years ago were investigated. Investors tend to renovate a building; therefore, the piles were analysed to assess the structural condition of the building. The building showed no signs of damage. To gain access to the piles, a 2 m thick layer of soil was removed. On-site, the following analyses were carried out: drilling resistance with a resistograph and a screw withdrawal test. Part of the piles was isolated and light microscopy, scanning electron microscopy, infrared spectroscopy, dynamic vapour sorption, density analysis, and chemical analysis were performed. Microscopic analysis revealed that the piles were made from the wood of Scots pine (Pinus sylvestris). The results indicate that the wood was severely degraded, mainly by soft-rot fungi and bacteria, resulting in a significant deterioration of its mechanical properties. Full article

In forests, tree mortality is strongly determined by complex interactions between multiple biotic and abiotic factors, and the analysis of tree mortality is widely implemented in forest management. However, age-based tree mortality remains poorly evaluated quantitatively at the stand scale for unevenly aged forests. The objective of this study was to predict the age distributions of living and dead trees based on survival analyses. We used a combination of tree-ring and census data from the two preserved permanent plots in the University of Tokyo Hokkaido Forest in pan-mixed and sub-boreal natural forests, Hokkaido, northern Japan, to derive site-specific survival models. All the living trees (diameter at breast height, ≥5 cm in 2009) were targeted to identify the tree ages using a RESISTOGRAPH, a semi-nondestructive device. Periodical tree age data with a 10-year age class were used during the observation periods of 2009–2019, and all the changes (i.e., death and new ingrowth) during the periods were recorded. We determined the time stabilities of the survival functions between periods in advance. The results show that the parametric survival analysis with the Weibull distribution successfully yielded the mortality rate, mortality probability, and survival probability in each plot. Finally, we predicted the future age class distributions of living and dead trees of each plot based on the survival analysis results and discussed their management implications. We recommend that the estimated mean lifetimes facilitate making decisions on the selection of harvesting trees in uneven forest management based on selective cutting. Full article

Given an overall aim of improving Scots pine structural wood quality by selective tree breeding, we investigated the potential of non-destructive acoustic sensing tools to accurately predict wood stiffness (modulus of elasticity, MOE) and strength (modulus of rupture, MOR) of sawn boards. Non-destructive measurements of wood density (DEN), acoustic velocity (VEL) and MOE were carried out at different stages of wood processing chain (standing trees, felled logs and sawn boards), whilst destructively measured stiffness and strength served as benchmark traits. All acoustic based MOE and VEL estimates proved to be good proxies (r_A > 0.65) for sawn-board stiffness while MOE_TREE, VEL_HIT and resistograph wood density (DEN_RES) measured on standing trees and MOE_LOG and VEL_FAK measured on felled logs well reflected board strength. Individual-tree narrow-sense heritability ( $h_i^2$ ) for VEL, MOE and MOR were weak (0.05–0.26) but were substantially stronger for wood density (0.34–0.40). Moreover, additive genetic coefficients of variation for MOE and MOR were in the range from 5.4% to 9.1%, offering potential targets for exploitation by selective breeding. Consequently, selective breeding based on MOE_TREE, DEN_RES or stem straightness (STR) could improve several structural wood traits simultaneously. Full article

To maximize utilization of our forest resources, detailed knowledge of wood property variation and the impacts this has on end-product performance is required at multiple scales (within and among trees, regionally). As many wood properties are difficult and time-consuming to measure our knowledge regarding their variation is often inadequate as is our understanding of their responses to genetic and silvicultural manipulation. The emergence of many non-destructive evaluation (NDE) methodologies offers the potential to greatly enhance our understanding of the forest resource; however, it is critical to recognize that any technique has its limitations and it is important to select the appropriate technique for a given application. In this review, we will discuss the following technologies for assessing wood properties both in the field: acoustics, Pilodyn, Resistograph and Rigidimeter and the lab: computer tomography (CT) scanning, DiscBot, near infrared (NIR) spectroscopy, radial sample acoustics and SilviScan. We will discuss these techniques, explore their utilization, and list applications that best suit each methodology. As an end goal, NDE technologies will help researchers worldwide characterize wood properties, develop accurate models for prediction, and utilize field equipment that can validate the predictions. The continued advancement of NDE technologies will also allow researchers to better understand the impact on wood properties on product performance. Full article

The objective of this study was to specify, parameterize, and evaluate an acoustic-based inferential framework for estimating commercially-relevant wood attributes within standing jack pine (Pinus banksiana Lamb) trees. The analytical framework consisted of a suite of models for predicting the dynamic modulus of elasticity (m_e), microfibril angle (m_a), oven-dried wood density (w_d), tracheid wall thickness (w_t), radial and tangential tracheid diameters (d_r and d_t, respectively), fibre coarseness (c_o), and specific surface area (s_a), from dilatational stress wave velocity (v_d). Data acquisition consisted of (1) in-forest collection of acoustic velocity measurements on 61 sample trees situated within 10 variable-sized plots that were established in four mature jack pine stands situated in boreal Canada followed by the removal of breast-height cross-sectional disk samples, and (2) given (1), in-laboratory extraction of radial-based transverse xylem samples from the 61 disks and subsequent attribute determination via Silviscan-3. Statistically, attribute-specific acoustic prediction models were specified, parameterized, and, subsequently, evaluated on their goodness-of-fit, lack-of-fit, and predictive ability. The results indicated that significant (p ≤ 0.05) and unbiased relationships could be established for all attributes but d_t. The models explained 71%, 66%, 61%, 42%, 30%, 19%, and 13% of the variation in m_e, w_t, s_a, c_o, w_d, m_a, and d_r, respectively. Simulated model performance when deploying an acoustic-based wood density estimate indicated that the expected magnitude of the error arising from predicting d_t, c_o, s_a, w_t, m_e, and m_a prediction would be in the order of ±8%, ±12%, ±12%, ±13%, ±20%, and ±39% of their true values, respectively. Assessment of the utility of predicting the prerequisite w_d estimate using micro-drill resistance measures revealed that the amplitude-based w_d estimate was inconsequentially more precise than that obtained from v_d (≈ <2%). A discourse regarding the potential utility and limitations of the acoustic-based computational suite for forecasting jack pine end-product potential was also articulated. Full article

Wood stiffness is an important wood mechanical property that predetermines the suitability of sawn timber for construction purposes. Negative genetic correlations between wood stiffness and growth traits have, however, been reported for many conifer species including Scots pine. It is, therefore, important that breeding programs consider wood stiffness and growth traits simultaneously. The study aims to (1) evaluate different approaches of calculating the dynamic modulus of elasticity (MOE, non-destructively assessed stiffness) using data from X-ray analysis (SilviScan) as a benchmark, (2) estimate genetic parameters, and (3) apply index selection. In total, we non-destructively measured 622 standing trees from 175 full-sib families for acoustic velocity (VEL) using Hitman and for wood density (DEN) using Resistograph and Pilodyn. We combined VEL with different wood densities, raw (DEN_RES) and adjusted (DEN_RES.TB) Resistograph density, Pilodyn density measured with (DEN_PIL) and without bark (DEN_PIL.B), constant of 1000 kg·m⁻³ (DEN_CONST), and SilviScan density (DEN_SILV), to calculate MOEs and compare them with the benchmark SilviScan MOE (MOE_SILV). We also derived Smith–Hazel indices for simultaneous improvement of stem diameter (DBH) and wood stiffness. The highest additive genetic and phenotypic correlations of the benchmark MOE_SILV with the alternative MOE measures (tested) were attained by MOE_DENSILV (0.95 and 0.75, respectively) and were closely followed by MOE_DENRES.TB (0.91 and 0.70, respectively) and MOE_DENCONST and VEL (0.91 and 0.65, respectively for both). Correlations with MOE_DENPIL, MOE_DENPIL.B, and MOE_DENRES were lower. Narrow-sense heritabilities were moderate, ranging from 0.39 (MOE_SILV) to 0.46 (MOE_DENSILV). All indices revealed an opportunity for joint improvement of DBH and MOE. Conclusions: MOE_DENRES.TB appears to be the most efficient approach for indirect selection for wood stiffness in Scots pine, although VEL alone and MOE_DENCONST have provided very good results too. An index combining DBH and MOE_DENRES.TB seems to offer the best compromise for simultaneous improvement of growth, fiber, and wood quality traits. Full article
