The increasing demand for sustainable and renewable energy solutions has made radio frequency energy harvesting (RFEH) a promising technique for powering low-power electronic devices. RFEH captures ambient RF signals from wireless communication systems, such as mobile networks, Wi-Fi, and broadcasting stations, and converts them into usable electrical energy. This approach offers a viable alternative for battery-dependent and hard-to-recharge applications, including streetlights, outdoor night/security lighting, wireless sensor networks, and biomedical body sensor networks. This article provides a comprehensive review of the RFEH techniques, including state-of-the-art rectenna designs, energy conversion efficiency improvements, and multi-band harvesting systems. We present a detailed analysis of recent advancements in RFEH circuits, impedance matching techniques, and integration with emerging technologies such as the Internet of Things (IoT), 5G, and wireless power transfer (WPT). Additionally, this review identifies existing challenges, including low conversion efficiency, unpredictable energy availability, and design limitations for small-scale and embedded systems. A critical assessment of current research gaps is provided, highlighting areas where further development is required to enhance performance and scalability. Finally, constructive recommendations for future opportunities in RFEH are discussed, focusing on advanced materials, AI-driven adaptive harvesting systems, hybrid energy-harvesting techniques, and novel antenna–rectifier architectures. The insights from this study will serve as a valuable resource for researchers and engineers working towards the realization of self-sustaining, battery-free electronic systems. Full article

The Internet of Things (IoT) is one of the pivotal technologies driving the digital transformation of industry, business, and personal life. Along with new opportunities, the exponential growth of IoT devices also brings environmental challenges, driven by the increasing accumulation of e-waste. This paper introduces a novel, compact, cubic-shaped rectenna with a 3D-printed composite substrate featuring five identical patches. The design aims to integrate RF energy harvesting technology with eco-friendly materials, enabling its application in powering next-generation sustainable IoT systems. Due to its symmetrical design, each patch antenna achieves a bandwidth of 130 MHz within the frequency range of 2.4 GHz to 2.57 GHz, with a maximum efficiency of 60.5% and an excellent isolation of below −25 dB between adjacent patch antennas. Furthermore, measurements of the rectifier circuit indicate a maximum conversion efficiency of 33%, which is comparable to that of other rectennas made on 3D-printed substrates. The proposed visually unobtrusive design not only enhances compactness but also allows the proposed rectenna to harvest RF energy from nearly all directions. Full article

The advancement of microwave wireless power transfer technology has positioned low-power rectennas as a research hotspot. This paper systematically reviews core technological progress in low-power rectennas, focusing on innovations in rectifier circuit topologies, nonlinear device models, antenna array optimization, and efficiency enhancement strategies. Current technical bottlenecks and future application directions are analyzed, providing theoretical references for space solar power stations, IoTs, and related fields. Full article

Globally, there are now more than 19 billion connected Internet of Things (IoT) devices, which are fostering innovation across various sectors, including industry, healthcare, education, energy, and agriculture. With the rapid expansion of IoT devices, there is an increasing demand for sustainable, self-powered, eco-friendly solutions for next-generation IoT devices. Harvesting and converting radio frequency (RF) energy through rectennas is being explored as a potential solution for next-generation self-powered wireless devices. This paper presents a methodology for designing, optimizing, and fabricating a flexible rectenna for RF energy harvesting in the 5G lower mid-band and ISM 2.45 GHz band. The antenna element has a tree form based on a fractal structure, which provides a small size for the rectenna. Furthermore, to reduce the rectenna’s environmental impact, we fabricated the rectenna on a substrate from biodegradable materials—natural rubber filled with rice husk ash. The rectifier circuit was also designed and fabricated on the flexible substrate, facilitating the seamless integration of the rectenna in next-generation low-power IoT devices. The numerical analysis of the parameters and characteristics of rectenna elements, based on the finite-difference time-domain method, demonstrates a high degree of agreement with the experimental results. Full article

Due to the rise of gigascale antenna arrays considered to implement long-range wireless power transfer (WPT), there is a need for a scalable high-efficiency adaptive dynamic beam focusing method. Several methods have been proposed, including methods requiring position information of the receiver, use of pilot signals or channel sounding, and feedback-based approaches. The latter has the potential to achieve maximum WPT efficiency due to use of feedback between the rectenna target and the transmitter array. In this paper, we present an overview of the different feedback-based long-range WPT methods that have been proposed. We also compare their performance in terms of convergence time, complexity of implementation, and steady-state efficiency through an electromagnetic simulation, whose results are incorporated into a time-domain simulation model. The results show that methods that measure channel state information (CSI) and the both-sides retrodirective system can achieve high efficiency with less convergence time but with added implementation complexity. Full article

This paper put forward a hybrid energy harvester for collecting RF and solar energy in quad-band (GSM-900/1800, ISM-2400 and WiMAX-3500). By introducing diverse parasitic structures, good impedance matching with unidirectional radiation is achieved in the multi-band. Below the solar antenna, a low-power rectifier circuit is employed to achieve broadband rectification. Under the input power of 0 dBm, and maximum RF-DC conversion efficiency of 56.94% is realized. Accordingly, the hybrid energy harvester collects RF and solar energy individually or simultaneously, and then converts it into DC for power supply. With a light intensity of 1500 lux, the solar cell obtains 1.732 mW, and the rectenna can harvest additional 0.37–0.405 mW power. The proposed RF–Solar energy harvester has the advantages of multi-frequency operation, high gain, and high energy harvesting conversion efficiency. Full article

As the energy crisis is leading to energy shortages and constant increases in prices, green energy and renewable energy sources are trending as a viable solution to this problem. One of the most rapidly expanding green energy methods is RF (RadioFrequency) energy harvesting, as RF energy and its corresponding technologies are constantly progressing, due to the introduction of 5G and high-speed telecommunications. The usual system for RF energy harvesting is called a rectenna, and one of its main components is an antenna, responsible for collecting ambient RF energy. In this paper, the optimization process of an ultra-wideband antenna for RF energy harvesting applications was studied, with the main goal of broadening the antenna’s operational bandwidth to include 5G New Radio. For this purpose, the Bezier Search Differential Evolution Algorithm (BeSD) was used along with a novel CST-Matlab API, to manipulate the degrees of freedom of the antenna, while searching for the optimal result, which would satisfy all the necessary dependencies to make it capable of harvesting RF energy in the target frequency band. The BeSD algorithm was first tested with benchmark functions and compared to other widely used algorithms, which it successfully outperformed, and hence, it was selected as the optimizer for this research. All in all, the optimization process was successful by producing an ultra-wideband optimal antenna operating from 1.4 GHz to 3.9 GHz, which includes all vastly used telecommunication technologies, like GSM (1.8 GHz), UMTS (2.1 GHz), Wi-Fi (2.4 GHz), LTE (2.6 GHz), and 5G NR (3.5 GHz). Its ultra-wideband properties and the rest of the characteristics that make this design suitable for RF energy harvesting are proven by its $S_{11}$ response graph, its impedance response graph, its efficiency on the targeted technologies, and its omnidirectionality across its band of operation. Full article

This article presents a novel, compact, and flexible dual-band magnetoelectric dipole rectenna designed for radio frequency (RF) energy harvesting. The rectenna consists of a unique antenna structure, combining electric and magnetic dipoles to create unidirectional radiation patterns, minimizing interference from the human body. The rectifier is integrated with the antenna through conjugate matching, eliminating the need for additional matching circuits, reducing circuit losses, minimizing design complexity, and improving conversion efficiency. The proposed rectenna utilizes a flexible graphene film as the radiating element, which offers excellent conductivity and corrosion resistance, enabling conformal operation in diverse scenarios. Simulation and experimental results show that the rectenna operates effectively at 3.5 GHz and 4.9 GHz, achieving peak conversion efficiencies of 53.43% and 43.95%, respectively, at an input power of 4 dBm. The simulated and measured results achieved good agreement. The rectenna maintains stable performance under various bending conditions, demonstrating its suitability for flexible, wearable RF energy-harvesting systems. Full article

This work presents a numerical analysis of a 2.45 GHz full-wave bridge rectifier for RF (radio frequency) energy harvesting under low-power input conditions, and a guideline for developing a figure of merit (FOM) for RF energy harvester rectennas by relying on data science techniques, laying the foundation for a universally accepted FOM. The performance of the full-wave bridge rectifier, using two types of Schottky diodes, HSMS2850 and SMS7630, was evaluated at −5 and −15 dBm, with the diodes achieving maximum power conversion efficiencies (PCEs) of 57% and 33%, respectively, and reflection coefficient S11 values below −30 dB. A printed circuit board was designed to prepare for future laboratory measurements offering insights into real-world performance. Additionally, a double-voltage rectifier was simulated, achieving PCE values of 41% and 66% at similar input power levels; furthermore, various CMOS-based rectifier topologies reached PCE values of 69% at −5 dBm and 43.6% at −26 dBm. Full article

In this work, an omnidirectional RF energy harvester with wideband coverage (1.5–2.7 GHz), all-polarization, and high-efficiency DC combining is proposed. The harvester integrates six microstrip rectenna elements with varying directions and polarizations. The harvester strategically combines six microstrip rectenna elements with different orientations and polarizations to enhance the stability of omnidirectional energy harvesting. The rectifier employs impedance compression matching techniques, incorporating open-circuited and short-circuited transmission lines to achieve a compact, broadband rectification. Experimental results show that the rectifier maintains an RF-to-DC conversion efficiency exceeding 50% within a bandwidth of 1.5 GHz to 2.7 GHz at an input power of 0 dBm, achieving a maximum efficiency of 62%. The maximum DC-combining efficiency of the rectifier array reaches 92%. These findings indicate that the harvester performs effectively with RF energy of all polarizations from various directions. Full article

Microwave wireless power transmission (MWPT) applications have attracted worldwide interest and attention in recent years. Rectennas are a crucial component of a MWPT system. The rectenna’s power capacity and output DC power have great significance with regard to the MWPT system’s performance. In this article, a compact 4 × 4 S-band rectangular patch rectenna array for MWPT is proposed and experimentally verified. Firstly, an S-band rectifier with better consistency and lower cost than a traditional output design using parallel capacitors as a filter is achieved. Then, a rectenna array based on the proposed rectifier and a novel design idea is proposed. The rectenna can achieve an output DC power of 117.6 mW/cm³ and an efficiency of 47.6%. Finally, a MWPT verification experiment is conducted. A 12-inch LCD screen powered by the rectenna with a rated power of 12 W successfully works without any other power supply. This article provides a new design of a rectenna for MWPT, and the proposed rectenna array demonstrates its good engineering significance and application prospects. Full article

In this paper, a novel topology and method for designing a multi-band rectenna is proposed to improve its RF-DC efficiency. The rectifier achieves simultaneous rectification using both series and parallel configurations by connecting two branches to the respective terminals of the diode, directing the energy input from two ports to the anode and cathode of the diode. Six desired operating frequency bands are evenly distributed across these two branches, each of which is connected to antennas corresponding to their specific operating frequencies, serving as the receiving end of the system. To optimize the design process, a low-pass filter is incorporated into the rectifier design. This filter works in conjunction with a matching network that includes filtering capabilities to isolate the two ports of the rectifier. The addition of the filter ensures that each structure within the rectifier can be designed independently without adversely affecting the performance of the already completed structures. Based on the proposed design methodology, a dual-port rectenna operating at six frequency bands—1.85 GHz, 2.25 GHz, 2.6 GHz, 3.52 GHz, 5.01 GHz, and 5.89 GHz—was designed, covering the 4G, 5G, and Wi-Fi/WLAN frequency bands. The measured results indicate that high-power conversion efficiency was achieved at an input power of −10 dBm: 43.01% @ 1.85 GHz, 41.00% @ 2.25 GHz, 41.33% @ 2.6 GHz, 35.88% @ 3.52 GHz, 22.36% @ 5.01 GHz, and 19.27% @ 5.89 GHz. When the input power is −20 dBm, the conversion efficiency of the rectenna can be improved from 5.2% for single-tone input to 27.7% for six-tone input, representing a 22.5 percentage point improvement. The proposed rectenna demonstrates significant potential for applications in powering low-power sensors and other devices within the Internet of Everything context. Full article

In this work, a novel quad-band rectifier circuit is introduced for RF energy harvesting and Internet of Things (IoT) applications. The proposed rectifier operates in the Wi-Fi frequency band and can supply low-power sensors and systems used in IoT services. The circuit operates at $2.4$, $3.5$, 5, and $5.8$ GHz. The proposed RF-to-DC rectifier is designed based on Delon theory and Greinacher topology on an RT/Duroid 5880 substrate. The results show that our proposed circuit can harvest RF energy from the environment, providing maximum power conversion efficiency (PCE) greater than 81% when the output load is $0.511$ kΩ and the input power is 12 dBm. In this work, we provide a comprehensive design framework for an affordable RF-to-DC rectifier. Our circuit performs better than similar designs in the literature. This rectifier could be integrated into an IoT node to harvest RF energy, thereby proving a green energy source. The IoT node can operate at various frequencies. Full article

In this paper, we investigate various graphene monolayer nanomesh structures (diodes) formed only by nanoholes, with a diameter of just 20 nm and etched from the graphene layer in different shapes (such as rhombus, bow tie, rectangle, trapezoid, and triangle), and their electrical properties targeting electromagnetic energy harvesting applications. In this respect, the main parameters characterizing any nonlinear device for energy harvesting are extracted from tens of measurements performed on a single chip containing the fabricated diodes. The best nano-perforated graphene structure is the triangle nanomesh structure, which exhibits remarkable performance in terms of its characteristic parameters, e.g., a 420 Ω differential resistance for optimal impedance matching to an antenna, a high responsivity greater than 10³ V/W, and a low noise equivalent power of 847 pW/√Hz at 0 V. Full article

This work presents the results of the characterization of two 1 × 5 mm² miniaturized rectennas developed for medical applications. They have been designed for relatively high voltage and high-power applications, given the size of the rectennas. Both rectennas were tested in open-air conditions and surrounded by pork fat and muscle tissues, whose properties are similar to those of the human body. The resonant frequencies of the rectennas were found, and the incident electric field on the rectennas tests was increased. The first chip showed a maximum output voltage of 5.29 V and a maximum output power of 0.056 mW, at 1.446 GHz, under an incident field on the rectenna of 340 V/m, and the second chip, 4.62 V and 4.27 mW, at 1.175 GHz, under 535 V/m. The second rectenna can provide an output power greater than 5 mW. The rectennas presented in this article are beyond the state of the art, as they can deliver about three times more power and voltage than those of similar dimensions reported in the literature. Based on the test results, the efficiency of the rectennas was analyzed at different locations of the human body, considering different thicknesses of tissues with high and low water content. Finally, potential applications are described in which the rectennas could power implantable medical devices or microsurgery tools, for example, pulmonary artery pressure monitors. Full article
