Twin Rotor Multi-Input Multi-Output (TRMS) platforms combine strong aerodynamic cross-coupling, gravitational loading on the vertical axis, friction-dominated horizontal dynamics, and systematic mismatch between idealised models and laboratory hardware. The platform provides only two optical encoders, so the angular rates and the rotor states are unavailable for feedback. This paper presents an observer-based output-feedback architecture that addresses both difficulties. A high-gain observer built on the fully coupled six-state model, including the gyroscopic terms that the control design cannot retain, reconstructs the four unmeasured states from the two encoder angles. The reconstructed states drive a Hybrid Backstepping–Super-Twisting (B-STA) controller in which a second-order continuous sliding mode is embedded at the final recursive step through a composite surface. Because backstepping requires strict-feedback structure, which the centralised coupled model does not possess, the controller is synthesised on a decentralised design model and the residual coupling is rejected as a matched perturbation of the sliding variable. Closed-loop behaviour is analysed as a three-stage cascade covering observer error, sliding variable, and tracking error, yielding practical stability under bounded residuals with an explicit input-to-state gain. The residual bounds are evaluated numerically from the actuator saturation limit and the identified coefficients rather than assumed, and the resulting figures are shown to predict the marked difference in sliding-variable behaviour observed between the two axes. A second architecture applies a windowed Grey Wolf Optimiser (B-GWO) to the backstepping gains, in which each candidate is applied to the plant for a fixed test window, scored on its own accumulated integral of time-weighted absolute error, and followed by a settle window at the incumbent best. We prove that this windowing is a requirement rather than a convenience: a fitness evaluated at a single sample is common to all candidates, cancels from the population ranking, and reduces the search to the minimiser of its own regularisation term. Both schemes are implemented on a physical TRMS through a Simulink Desktop Real-Time interface at a control period of $10\mathrm{ms}$. On a $100\mathrm{s}$ experimental run, B-STA attains a pitch tracking error of $0.0318\mathrm{rad}$ RMS, $7.94\%$ of the reference amplitude, and the lowest control energy on both axes among the strategies compared, reducing pitch control energy by $72.9\%$ relative to a first-order Backstepping–Sliding Mode baseline recorded on the same interface. Numerical disturbance rejection tests on the fully coupled model confirm the mechanism: under a matched actuator step the super-twisting integrator state migrates to a new steady level that cancels the disturbance, driving the residual pitch error to $2\times {10}^{-4}\mathrm{rad}$, whereas the same recursive law without the second-order injection retains a permanent offset of $0.28\mathrm{rad}$. Full article

Unmanned surface vehicle (USV) formations operating under GNSS denial require accurate relative localization using proprioceptive sensors and inter-vehicle ranging. This paper presents an anomaly-aware adaptive extended Kalman filter for four-USV formations using inertial measurements, compass, and ultra-wideband ranging, and systematically characterizes its operating envelope. Observability analysis establishes that S-curve maneuvering achieves structural rank 24, with only global translation unobservable, while straight-line motion leads to a rank deficiency of exactly seven dimensions All four gyroscope biases remain observable under both trajectories. The proposed filter integrates chi-square testing, cumulative sum (CUSUM) detection, and bias drift rate monitoring to trigger coordinated R adaptation and Q-boost mechanisms. Controlled experiments spanning outlier magnitudes and drift rates reveal three performance regimes, clean conditions with equivalent performance across all variants, moderate outliers $[3{\sigma }_d,10{\sigma }_d]$ where the proposed method achieves 4.8–13.4% improvement, and extreme outliers where all robust methods converge. Critically, pure bias drift experiments expose a structural limitation of single-hypothesis, residual domain robustification within the tested drift range—all variants exhibit equivalent performance across the tested drift rates, analytically attributable to Kalman gain partitioning that distributes innovations between position and bias subspaces. The characterized operating envelope establishes that robust mechanisms provide measurable benefits for transient anomalies but encounter hard boundaries under persistent drift conditions, with all variants converging to equivalent performance across the tested range, necessitating multi-hypothesis or constraint-based approaches. Full article

High-precision angular-rate measurements in extreme spin environments require systems capable of handling very high rotation rates, rapid startup, and reliable operation under vibration and shock. However, most commercially available gyro-based Inertial Measurement Units (IMUs) provide measurement ranges limited to approximately ±2000°/s, which may be insufficient for high-speed spinning platforms such as spin-stabilized satellites and drilling systems. This work presents the design, implementation, calibration, and validation of a complete Data Acquisition System (DAS) based on the ADXRS649 analog gyroscope, supporting angular rates up to ±20,000°/s. The system integrates a 12-bit ADC within a dsPIC33 microcontroller, high-speed nvSRAM for continuous logging, and firmware enabling sensor self-testing, memory checks, synchronized sampling, and onboard processing. Operating at a configurable sampling frequency of 50 Hz, the proposed system provides approximately 20 min of continuous data recording. Custom hardware, including multilayer PCB design, signal conditioning, power management, a rugged metallic enclosure, and polyurethane potting, enhances mechanical robustness for operation under vibration and shock. Laboratory calibration over the angular-rate range of ±980°/s quantified the gyroscope bias and scale factor, while experimental validation using a high-speed rotary machine demonstrated stable rolling measurements and reliable data integrity at angular rates exceeding 2000°/s. The results demonstrate that the proposed analog gyro-based DAS provides a robust and cost-effective solution for ultra-high-spin applications and future multi-sensor integration. Full article

Microelectromechanical systems (MEMS) gyroscopes are now standard rate sensors in inertial navigation, automotive electronics, industrial automation, and medical instrumentation because they are inexpensive, compact, and readily integrated. Their accuracy, however, degrades with temperature: damping and quadrature coupling change, and readout-electronics behavior shifts, producing temperature-dependent zero-rate-output drift, elevated random noise, and poorer long-term stability. Hardware- and structure-based temperature compensation address part of the problem but carry cost and generality penalties, which has moved recent work toward data-driven software-based temperature-drift compensation. This review focuses on the fusion algorithms that have come to dominate that literature, organized as a four-stage pipeline: signal decomposition, learning-based drift modeling, adaptive filtering, and signal reconstruction. We examine how optimizer-tuned variational mode decomposition and improved empirical-mode-decomposition variants separate temperature-related components from noise; how deep temporal networks and optimizer-coupled learners model the nonlinear, time-lagged drift; and how adaptive Kalman variants and time-frequency filtering reconstruct a stable output. We close by identifying four open problems that recur across the recent gyroscope-specific work—cross-device generalization, temperature hysteresis, embedded real-time deployment, and physics-informed lightweight modeling. Full article

Agile attitude control of nanosatellites is increasingly required for high-resolution imaging, yet actuators that provide agility on larger spacecraft do not scale down well: reaction wheels are torque-limited and slew slowly, while miniaturized control moment gyroscopes (CMGs) deliver high torque but their stored wheel momentum produces a gyroscopic coupling torque that degrades fine pointing—an inherent agility–precision trade-off on low-inertia 3U platforms. This paper presents a two-step variable-speed CMG (VSCMG) strategy that preemptively decelerates the wheel momentum once the attitude error falls below a threshold, attenuating the gyroscopic torque before fine pointing and thus decoupling slewing from precision pointing. It is validated on an experimentally grounded model: a fabricated 1U-class four-CMG pyramid ($90\times 90\times 105$ mm, 584 g), gimbal dynamics identified experimentally ($93.2\%$ fit) and regulated by an integral-type optimal servo, and bench-measured wheel dynamics. At 560 km under aerodynamic and gravity-gradient disturbances, the strategy completes a 90° slew in 25.3 s at a mean slew rate of $3.55°/\mathrm{s}$ with $0.42°$ accuracy—$4.5\times$ faster than a reaction-wheel system and $12\times$ more accurate than single-mode CMG operation—with a Lyapunov-based stability guarantee. The spacecraft-level closed-loop performance is established in closed-loop simulation, while the component-level ground experiments verify only that the assumed wheel-speed and gimbal-rate envelopes are achievable on the prototype; the present work is thus a simulation study supported by experimentally identified actuator models, not a system-level experimental demonstration. These results show that momentum-managed VSCMG control substantially relieves the agility–precision trade-off within a 1U envelope under the single-axis 90° slew studied here, extending CMG-class agility to small form-factor satellites previously confined to reaction wheels. Full article

In satellite-denied environments such as urban canyons, tunnels, and underground parking facilities, achieving high-precision autonomous positioning for vehicles remains a critical challenge. Although high-precision inertial measurement units (IMUs) can provide accurate dead reckoning, their deployment is limited by cost, size, and power consumption, making low-cost, microelectromechanical systems IMUs (MIMUs) an attractive alternative solution. However, the single MIMU suffers from substantial measurement noise and bias instability, leading to rapid error divergence that cannot sustain long-term autonomous navigation. To address the above issues, this paper proposes an autonomous positioning system based on a wheel-mounted MIMU array (Wheel-AINS). The system adopts a differential layout in which multiple low-cost MIMU chips are installed at the center of each of the left and right rear wheels, forming redundant sensor arrays. By differentially fusing symmetrically mounted chips, common-mode noise and zero bias are effectively canceled while the wheel rotation provides natural rotational modulation. The fused gyroscope outputs and known wheel radius are then used to estimate the vehicle forward speed, replacing traditional odometers. The estimated wheel speed and vehicle kinematic constraints are then integrated within a Kalman filter framework to suppress the error divergence of the inertial navigation system. A dedicated embedded hardware prototype with multi-chip synchronous acquisition and wireless transmission was developed. Three groups of urban road tests with total distances of 0.85 km, 2.14 km, and 2.49 km were conducted. The results indicate that the average position drift rate of the Wheel-AINS is 0.50%, and the average heading RMSE is 12.2°. The closure error of the 2.49 km trajectory is 10.43 m, reduced by approximately 80% compared with a single MIMU. The ablation experiment reveals that the MIMU array fusion module is the primary source of accuracy improvement, reducing the position RMSE from 155.0 m to 10.1 m, while the dual-wheel distance constraint further optimizes the position RMSE to 8.2 m, but increases the heading RMSE from 13.3° to 13.6°. This demonstrates that the proposed method can substantially improve autonomous positioning accuracy while maintaining a notably low system cost, providing a viable technical pathway for long-endurance vehicle navigation in satellite-denied environments. Full article

To improve operational safety in confined spaces, this study proposes an intelligent safety monitoring framework that utilizes multimodal data from wearable devices. The framework comprises two core components: a human activity recognition (HAR) module and a bio-inspired adaptive multimodal decision fusion (BA-MDF) module. The HAR module processes accelerometer and gyroscope data through an enhanced FFT–LSTM architecture that integrates time- and frequency-domain features for real-time activity classification. The BA-MDF module, inspired by biological multisensory integration mechanisms—particularly the inverse effectiveness principle observed in the superior colliculus—evaluates contextual risk by adaptively fusing HAR outputs, heart rate variability, and geospatial constraints without additional computational overhead. Experimental testing demonstrated 92.4% overall HAR accuracy and 94.3% identification accuracy for emergency scenarios under a simulated sensor degradation environment. These results validate the framework’s effectiveness in mitigating risks from anomalous events in visually constrained environments. Full article

This work presents a high-performance piezoelectric MEMS yaw gyroscope fabricated on a single-crystal silicon platform, which achieves a quality factor of 75 k—the highest reported to date among silicon-based piezoelectric gyroscopes. The device employs a wide annular resonator that operates at 132 kHz in the in-plane wineglass mode. To maximize transduction efficiency, we develop an analytical model that relates output charge to the area-integrated in-plane stress under modal deformation, and we use this model to guide parametric optimization of the annular width. The resulting geometry simultaneously enhances the mechanical quality factor and the piezoelectric coupling. A back-etching fabrication process is used to eliminate front-side release holes, thereby preserving structural continuity and suppressing thermoelastic damping. In open-loop rate mode operation with a native frequency split of 28 Hz, the gyroscope demonstrates an angle random walk of 0.34°/√h and a bias instability of 8.19°/h. These performance metrics are comparable to those of state-of-the-art lead zirconate titanate (PZT)-based annular gyroscopes, while the use of lead-free aluminum nitride as the transduction material ensures compliance with RoHS environmental regulations. Full article

The output of MEMS gyroscopes is highly vulnerable to ambient temperature variations, which induce temperature drift errors and degrade navigation precision. Consequently, temperature compensation for MEMS gyroscope outputs is of critical importance. To address this issue, this study proposes a novel temperature compensation model for the dual-mass vibration MEMS gyroscope (DMVMG), which integrates the TTAO-VMD, 1D-CNN-Bi-GRU-Attention, and SHAKF algorithms. The implementation process of the proposed model is as follows: firstly, the structural configuration and fundamental operating principle of the DMVMG are elaborated. Secondly, the temperature error compensation model is constructed based on the fusion of the TTAO-VMD, 1D-CNN-Bi-GRU-Attention, and SHAKF algorithms. Thirdly, the raw output signal of the DMVMG is preprocessed using the TTAO-VMD algorithm, which decomposes the signal into four distinct components, namely high-frequency noise, white noise, mixed noise, and temperature-induced noise. Subsequently, the high-frequency and white noise components are eliminated, while the mixed noise component is filtered via the SHAKF algorithm. On this basis, the 1D-CNN-Bi-GRU-Attention algorithm is adopted to establish the temperature error compensation model, with the temperature, temperature change rate, time, and temperature-induced noise as input variables. Finally, the optimized signal components are reconstructed to yield the temperature-compensated output of the DMVMG. The experimental results based on the Allan variance method demonstrate that the angle random walk (N) is reduced from 18.56 $°/\sqrt{h}$ to 0.17 $°/\sqrt{h}$, and the bias instability (B) is decreased from 32.76 °/h to 0.82 °/h, verifying the effectiveness of the proposed method. Full article

Correcting an illegal bowling action in cricket through technical intervention involves modifying a movement pattern. This study evaluated the success of an intervention aimed at correcting the suspect actions of two off-spin bowlers and assessed whether it influenced other movement patterns and performance parameters that were not directly targeted by the intervention (the “side-effects” of the intervention). For this purpose, a smart cricket ball equipped with three high-speed gyroscopes was used. This technology not only detects illegal bowling actions but also measures five physical and five skill performance parameters, along with ratios within and across these two parameter groups. Additionally, it tracks the position of the centre of pressure, where torque is applied to the ball, and identifies the type of delivery based on the direction of the angular velocity vector in the global coordinate system. The significant reduction of 15–27% in the integral of the precession signal before the torque spike provided the required evidence for the success of the intervention. Among the performance parameters not targeted by the intervention, skill parameters improved by 7–53% after the intervention relative to before the intervention, while physical performance parameters (spin rate, torque, angular acceleration) decreased (≈10%) significantly after the intervention. The position and vector of the centre of pressure shifted significantly distally and closer to the palm in both bowlers (33.3° and 47.5° in participants A and B, respectively) after the intervention. Although the basic average type of delivery (sidespin plus half swerve, and top-spin plus half swerve) did not change, the yaw angle of the angular velocity vector in the global coordinate system moved significantly counterclockwise by 18–20°. This study demonstrated that while the intervention successfully corrected illegal bowling actions, the smart cricket ball also revealed changes in other performance measures, which aligns with the understanding that the bowling action operates as an integrated, dynamic system. Full article

A vast number of boreholes in underground mining operations are often plagued by deviation issues, which severely impact both production efficiency and safety. The accurate and rapid acquisition of borehole trajectories is fundamental for subsequent deviation control and correction. However, existing inclinometers are limited by their operational efficiency and estimation accuracy, making them inadequate for large-scale measurement demands. To address this, this paper proposes a novel method for the rapid and accurate reconstruction of underground mine borehole trajectories using a robotic system. We employ a custom-designed robot equipped with an Inertial Measurement Unit (IMU) and a displacement sensor, which travels stably while collecting real-time attitude and depth information. Algorithmically, a complementary filter is used to fuse data from the gyroscope with that from the accelerometer and magnetometer, overcoming both integration drift and environmental disturbances. A cubic spline interpolation algorithm is then utilized to time-register the low-sampling-rate displacement data with the high-frequency attitude data, creating a time-synchronized sequence of ‘attitude–displacement increment’ pairs. Finally, the 3D borehole trajectory is accurately reconstructed by mapping the attitude quaternions to direction vectors and recursively accumulating the displacement increments. Comparative experiments demonstrate that the proposed method significantly improves efficiency. On a complex trajectory, the maximum and mean errors were reduced to 0.38 m and 0.18 m, respectively. This level of accuracy is far superior to that of the conventional static point-by-point measurement mode and effectively suppresses the accumulation of dynamic errors. This work provides a new solution for routine borehole trajectory surveying in mining operations. Full article

Inertial Measurement Units (IMUs), which embed several sensors (accelerometers, gyroscopes, magnetometers) are employed by musicians and performers to control sound, music, or lighting on stage. In particular, wireless IMU systems in the performing arts require particular attention due to strict requirements regarding streaming sample rate, latency, power consumption, and programmability. This article presents a review of systems developed in this context at IRCAM as well as in other laboratories and companies, highlighting specificities in terms of sensing, communication, performance, digital processing, and usage. Although basic IMUs are now widely integrated into IoT systems and smartphones, the availability of complete commercial wireless systems that meet the constraints of the performing arts remains limited. For this reason, a review of systems used in performing Arts provides exemplary use cases that may also be relevant to other applications. Full article

Inertial navigation systems (INSs) exhibit distinctive characteristics, such as long-duration operation, full autonomy, and exceptional covertness compared to other navigation systems. However, errors are accumulated over time due to operational principles and the limitations of sensors. To address this problem, this study theoretically explores a numerically simulated integrated inertial navigation system consisting of a single-axis cold atom interferometer gyroscope (CAIG) and a conventional inertial measurement unit (IMU). The system leverages the low bias and drift of the CAIG and the high sampling rate of the conventional IMU to obtain more accurate navigation information. Furthermore, an adaptive gradient ascent (AGA) method is proposed to estimate the variance of the measurement noise online for the Kalman filter. It was found that errors of latitude, longitude, and positioning are reduced by 43.9%, 32.6%, and 32.3% compared with the conventional IMU over 24 h. On this basis, errors from inertial sensor drift could be further reduced by the online Kalman filter. Full article

This study proposes a novel heart rate estimation method that detects subtle cardiac-induced vibrations propagated through the cardiovascular system based on the ballistocardiography (BCG) principle, using a six-axis heart rate sensing device that integrates a three-axis accelerometer and a three-axis gyroscope. To validate the effectiveness of the proposed method, a comparative analysis was conducted against heart rate measurements obtained from photoplethysmography (PPG) sensors, which are widely used in conventional heart rate monitoring. Experiments were conducted on 20 adult participants, and frequency domain analysis was performed using different time windows of 30 s, 20 s, 8 s, and 4 s. The results showed that the 4 s window provided the highest accuracy in heart rate estimation, demonstrating that the proposed method can effectively capture fine cardiac-induced vibrations. This approach offers a significant advantage by utilizing inertial sensors commonly embedded in wearable devices for heart rate monitoring without the need for additional optical sensors. Compared to optical-based systems, the proposed method is more power-efficient and less affected by environmental factors such as ambient lighting conditions. The findings suggest that heart rate estimation using the six-axis heart rate sensing device presents a reliable, continuous, and non-invasive alternative for cardiovascular monitoring. Full article

Hemispherical resonator gyroscopes (HRGs) are critical components in high-precision inertial navigation systems, typically used in fields such as navigation, weaponry, and deep space exploration. Film thickness uniformity affects device performance through its impact on the resonator’s Q value. Due to the irregular structure of the resonator, there has been limited research on the uniformity of film thickness on the inner wall of the resonator. This study addresses the challenge of thickness non-uniformity in metallization coatings, particularly in the meridional direction of the resonator. By integrating COMSOL-based finite element simulations with reinforcement learning-driven optimization through the Proximal Policy Optimization (PPO) algorithm, a new paradigm for coating process optimization is established. Furthermore, a correction mask is designed to address the issue of low coating rate. Finally, a Zygo white-light interferometer is used to measure film thickness uniformity. The results show that the optimized coating process achieves a film thickness uniformity of 11.0% in the meridional direction across the resonator. This study provides useful information and guidelines for the design and optimization of the coating process for hemispherical resonators, and the presented optimization method constitutes a process flow framework that can also be used for precision coating engineering in semiconductor components and optical elements. Full article
