This work presents the characterization of a large-scale pilot plant for nitric acid production that employs atmospheric-pressure plasma in a closed-loop configuration. The primary objective here is to evaluate the scientific and practical feasibility of using high-power Cerawave™ plasma torch technology, manufactured by Radom Corporation, to enhance the rate of nitric acid production of plasma-assisted nitrogen fixation systems, while achieving specific energy consumption (SEC) comparable to that of smaller-scale setups reported in the literature. We provide a comprehensive overview of the components of the pilot plant, its operational strategy, and the analytical models underlying its processes. Preliminary system optimization results are discussed alongside the outcomes from a controlled batch run. After 30.9 h of operation at 50 kW plasma power, the system produced 198.9 L of nitric acid with a concentration of 28.6% by weight, corresponding to overall SEC of approximately 5.3 MJ/mol. This SEC could be improved to 3.7 MJ/mol using absorption columns with greater than 90% absorption efficiency. Additionally, around 60% of the plasma power was recovered as usable process heat via a heat exchanger. These results demonstrate that plasma-based nitrogen fixation is scientifically and technically viable at higher production scales while maintaining competitive specific energy consumption using microwave plasma. Full article

The impact of radomization on the radiation pattern of a millimeter-wave antenna for an ETA system utilizing synthetic aperture radar (SAR) is examined with special emphasis placed on the phase shift across both the beamwidth and the bandwidth, rather than the amplitude. Three different radomization approaches, including one based on metasurfaces, are evaluated for a radar antenna operating within the 24.05–24.25 GHz frequency range. Fabricated prototypes, both of the standalone antenna and the radomized version, are tested and compared in terms of electromagnetic image quality. The metasurface-based radome provides the best results among the radomization options analyzed. Full article

Scandinavian erratic boulders in central Poland represent a significant element of the region’s geodiversity, fulfilling important natural, scientific, and cultural functions. As objects of high perceptual value, they integrate into the landscape and provide a wide range of geosystem services. The main objectives of research conducted in two areas of the Małopolska Upland are to determine the concentration of these boulders and identify the geosystem benefits they offer, with particular emphasis on lichen species inhabiting their surfaces. Research has confirmed the currently limited use of geosystem services provided by the 25 erratic boulders studied. However, this may change with growing ecological awareness among local communities, enabling a deeper appreciation of inanimate nature. Erratic boulders have the potential to attract geotourists and thus support economic development (by improving the residents’ quality of life), but this potential requires broader promotion. Although the Central Register of Geosites of Poland is an appropriate platform for their registration, none of the analysed boulders have yet been included. The research findings are also partly directed at local government units to help them recognise the value of erratic boulders for sustainable development, in line with existing legal frameworks and development strategies. The detailed characterisation of 25 boulders may inspire broader initiatives and foster knowledge transfer to support regional development through geotourism. The ability to identify the ecosystem benefits provided by erratic boulders is essential for maintaining ecological balance and sustaining natural processes. However, there is growing evidence of the systematic disappearance of erratic boulders from the landscape, which disrupts geosystem balance and leads to further environmental degradation, negatively affecting human well-being. In light of the lack of effective nature protection measures in the study area, it is proposed that some of these boulders be designated as geological protected features. Such a conservation approach could help maintain ecological balance in the designated area. Full article

This paper presents a novel ultrathin frequency selective surface (FSS) bandpass filter with an extraordinary wideband tailored for operating within the S-C bands. The filter structure entails a double-layer FSS structure with mutually perpendicular unit cells etched on the top and bottom sides of a 0.003${\lambda }_L$ thick FR4 dielectric substrate, where ${\lambda }_L$ is the free space wavelength at the lowest operating frequency. Thus, both TE and TM polarizations can be covered, ensuring the polarization insensitivity of the structure. The two FSS layers are loaded with resistors to implement the harmonic suppression principle. The overall periodicity is extremely compact, measuring 0.16${\lambda }_L$× 0.16${\lambda }_L$. An equivalent circuit analysis was conducted to comprehensively evaluate the structure and provide design guidelines. Numerical simulations and experimental measurements demonstrated that the proposed filter achieved a −3 dB transmission band spanning from 2 to 6.76 GHz (fractional bandwidth equal to 108.7%) under normal incidence. Moreover, aside from excellent wideband performance, the filter showcased a flat bandpass and stable responses up to 40° of incidence angle. These remarkable capabilities position the proposed filter as a valuable asset in advancing the development of radomes and applications relevant to electromagnetic interference (EMI) shielding, promising significant contributions to the field. Full article

Perception and sensing of the surrounding environment are crucial for ensuring the safety of autonomous driving systems. A key issue is securing sensor reliability from sensors mounted on the vehicle and obtaining accurate raw data. Surface contamination in front of a sensor typically occurs due to adverse weather conditions or particulate matter on the road, which can degrade system reliability depending on sensor placement and surrounding bodywork geometry. Moreover, the moisture content of dust contaminants can cause surface adherence, making it more likely to persist on a vertical sensor surface compared to moisture only. In this work, a 76–81 GHz radar sensor, a 72–82 GHz automotive radome tester, a 60–90 GHz vector network analyzer system, and a 76–81 GHz radar target simulator setup were used in combination with a representative polypropylene plate that was purposefully contaminated with a varying range of water and ISO standard dust combinations; this was used to determine any signal attenuation and subsequent impact on target detection. The results show that the water content in dust contaminants significantly affects radar signal transmission and object detection performance, with higher water content levels causing increased signal attenuation, impacting detection capability across all tested scenarios. Full article

Radome stealth technology is a key research area in aircraft stealth design. Traditional aircraft stealth methods primarily focus on optimizing the shape to scatter radar waves and using absorbing materials to absorb radar waves. However, when these methods are applied to radomes, they can negatively impact antenna performance. By combining Frequency-Selective Surface (FSS) technology with radome design, it is possible to ensure good transmission performance for the antenna within its operating frequency range while simultaneously reducing the radar cross-section outside the operating frequency range, achieving an integrated design for both transmission and stealth. This paper outlines the technical approaches for radome stealth, reviews the research status of scattering stealth radomes and absorbing stealth radomes based on FSS both domestically and internationally, and provides an outlook on the future development of FSS radomes from the perspectives of omnidirectional broadband, conformal design, and intelligent control. Full article

Radar sensors are critical for obstacle detection and navigation, especially for automated driving. Using the use-case “printing of heating coils on the inside of the front housing (primary radome)” needed for de-icing in winter, it is demonstrated that additive manufacturing (AM) can provide economic and functional benefits for manufacturing of the sensors. AM will allow significant cost reduction by eliminating parts and simplifying the manufacturing process. Different AM technologies for the coils were investigated, first, by applying the conductive traces by fused deposition modeling (FDM), and, second, by printing copper particle-free inks and pastes. The metal layers were electrically and mechanically characterized using a profilometer to measure the trace dimension and a four-point probe to measure the resistance. It was revealed that low-cost conductive filaments with low resistivity and current carrying capacity are commercially still not available. The best option sourced was a copper–polyester-based filament with 6000 µΩcm after printing. Therefore, low-cost particle-free copper inks and commercial copper flake paste were selected to print the heating coil. The Cu particle-free inks were amine-based Cu (II) formate complexes, where the Cu exists in an ionic form. Using contactless printing processes such as ink-jet printing or pneumatic dispensing, the traces could be deposited onto the low-melting temperature (225 °C) polymeric radome structure. After printing, the material needed to be sintered to form the conductive copper traces. To avoid damaging the polymer radome during sintering, two different processes were investigated: low-temperature (<150 °C) sintering in an oven for 30 min or fast laser sintering. The sintered Cu layers achieved the following specific electric resistivities when slowly sintered in the oven: paste 4 µΩcm and ink 8.8 µΩcm. Using laser sintering, the ink achieved 3.2 µΩcm because the locally high temperature provides better sintering. Also, the adhesion was significantly increased to (5 B). Therefore, laser sintering is the preferred technology. In addition, it allows fast processing directly after printing. Commercial equipment is available where printing and laser sintering is integrated. The potential of low-cost copper material and the integration in additive manufacturing of electronic systems using radar sensors as an example are demonstrated in this paper. Full article

A compact and low-cost meta-radomized wearable grid array antenna (MTR-GAA) for radar sensing application at 24 GHz is presented. It is based on eco-friendly aluminum-cladded Polypropylene (PP) substrate. The overall MTR-GAA size is 40 × 40 × 1.74 mm³. Prototypes are fabricated and tested, achieving consistent agreement between simulation and measurements and meeting typical requirements for the envisioned Electronic Travel Aid (ETA) radar sensing applications to aid visually impaired people. A comparison with state-of-the-art 24 GHz wearable radar antennas is also provided to endorse the advantages of the proposed metadome-antenna ensemble for the target application. Full article

In this article, a small-aperture, low-profile, and omnidirectional conformal antenna is proposed which can be utilized on space-limited equipment platforms such as airplanes, ships, and vehicles. The antenna consists of an open metal cavity, a discone antenna, a parasitic structure, and a radome. The small aperture and low-profile design of the metal cavity result in a rapid narrowing of the bandwidth of the discone antenna. Therefore, we introduce a parasitic structure that not only enlarges the impedance bandwidth by adding a resonant point, but can also be used to adjust the unroundness of the horizontal pattern. Meanwhile, the conformal design of the antenna with four surfaces of different curvatures is presented. The simulation and testing results demonstrate that the antenna can achieve a VSWR of less than 2 within a bandwidth of 1.95–2.62 GHz (29.3%), with a minimum aperture of 0.43 omnidirectional radiation pattern, with a gain exceeding −2.2 dBi in the azimuthal plane. This antenna offers the advantages of a small aperture, low profile, and conformal capability. Furthermore, the resonances of high and low frequencies can be adjusted through two different structures, enhancing the flexibility of antenna design. Full article

This study proposes a frequency-selective absorber (FSA) with dual passbands and wide-angle oblique incidence. The design consists of a circuit analog (CA) sheet and a dual-bandpass frequency selective surface (FSS) sheet, both embedded in dielectric slabs separated by a foam spacer. The CA sheet unit cell is based on a tripole loaded with multiple shorted transmission lines and lumped resistors. In this way, the performance of the CA sheet is equivalent to a resistive sheet in a low-frequency band and a transparent sheet in two high-frequency bands. By comprehensively designing the CA sheet and the dual-bandpass FSS sheet, we created an FSA structure that exhibits microwave absorption in the band from 2.6 GHz to 9.2 GHz with a reflectivity lower than −10 dB. It also possesses transmission in the 12.2–15.1 GHz and 30.6–31.5 GHz bands, with a transmittance greater than −3 dB in both. In addition, the FSA structure provides a stable transmission response of up to 60° of oblique incidence and absorption performance of up to 45° of oblique incidence in TE and TM polarization. A 400 × 400 mm flat FSA sample was fabricated, was measured, and is discussed. The experimental results are consistent with the simulation results, proving that the proposed FSA design holds great potential for applications in dual-frequency low-scattering radomes with high curvature and multi-directional electromagnetic interference suppression. Full article

This study presents a compact and stable gain spacecraft antenna that operates in all Global Navigation Satellite System (GNSS) bands from 1.164 GHz to 1.610 GHz. The proposed antenna structure based on the single-feed crossed bowtie antenna concept consists of four triangular patches excited with a 90° phase difference in between to generate right-hand circular polarization (RHCP), without needing complex feed networks. The radiator part of the antenna is covered by a radome and is also supported by a cylindrical dielectric cavity frame (DCF) to weaken the diffracted waves propagating along the ground plane while increasing vibration resistance. The fabricated antenna provides a return loss better than 10 dB with lower than 3 dB axial ratio and a stable gain around 7.2 ± 0.3 dBic over the entire GNSS bands, as well as a more compact and lightweight structural performance. It is also verified that the structural integrity and functional performance of the fabricated antenna remain consistent despite exposure to an equivalent vibration level in the launch process. The presented all-band spacecraft GNSS antenna is an innovative implementation with space industry insight for multi-band space applications that have application-specific limitations and provides consistent performance, as well as operational safety with the antenna design simplicity. Full article

We present waveguide cavity measurements used to evaluate several thin materials for use in radomes. In addition to the data on the materials, we show how these measurements can be performed with common laboratory equipment and simple calculations. We sought an approach that allowed candidate materials to be readily evaluated to deal with formerly selected materials becoming unavailable or cost-prohibitive. We used lengths of standard waveguide (WR650 and WR137 here) with readily manufactured irises and a vector network analyzer (Keysight N5225B here). To select the iris size and determine the limits of the simplifications in the equations used, we employed a full-wave 3D electromagnetic simulator (CST Microwave Studio). The equations required to calculate the dielectric properties of samples and their contribution to the equivalent system noise temperature from unloaded and loaded resonant frequencies and Q factors are shown. While these formulations can be found elsewhere, we did not find these assembled as conveniently in other studies in the literature. We also show that orienting the sample down the length of the cavity allows for higher-order modes to be fully utilized. We did not find this straightforward adaptation of the common cross-guide orientation in other works. Overall, the results allowed us to recommend three fabrics for use at the frequencies tested (1.7 and 5.6 GHz). The complete process is outlined to assist others in performing these measurements themselves. Full article

The 2020 Environmental Noise in Europe report shows that a vast majority of European countries have legal definitions of quiet areas and criteria for their designation. As much as 60% of them have designated at least one quiet area in their territory and have taken measures to protect the acoustic climate in these areas. In Poland, although the instrument was introduced in the national environmental legislation, guidelines for delimitation have not been defined yet in the form of a binding legal act. The objective of this article is to propose the method for identifying quiet areas through spatial analysis and present it on the example of two cities—Radom and Lublin. These cities represent different approaches to the designation of quiet areas. This work is a continuation of the survey conducted and published by the authors in 2023. At the outset, the legislation and literature on the subject were analysed. Based on that, the conditions that potential quiet areas must meet were determined. Spatial analyses were then conducted for the quiet areas proposed earlier in the survey and in the environmental noise programme to see if the criteria selected by the authors were actually met in these areas: acoustic, functional, related to land cover, size, as well as temporal, spatial and transport accessibility, and location, including distances from areas with the highest noise emissions and adequate population density. Quiet areas are forest areas, public green areas, and surface water areas with recreational functions. The criteria for the elimination of the selected quiet areas were mainly location related (distance from main roads and population density). The accessibility of the quiet areas is also important. A method devised by the authors enables the delimitation of quiet areas in cities. Furthermore, this method is primarily based on publicly available data, which makes it applicable to other cities as well. Full article

The digital model of airborne frequency selective surface radomes (AFSSRs) is the basis of design, simulation analysis, manufacturing, and other related research on AFSSRs. This paper proposes a rapid modeling method for AFSSRs based on dynamic customizable primitives. Firstly, a layered digital model construction scheme for AFSSRs is presented based on the typical radome wall structure. Then, according to the characteristics of various surface configurations and the complex wireframe information of AFSSRs, the dynamic primitives are raised to express the boundary and contour information of all kinds of radomes. Focusing on the undevelopable characteristics of the aerodynamic shape surface of the AFSSR, the arrangement solution and mapping method for frequency-selective elements on undevelopable surfaces are proposed. Furthermore, the implementation logic of this method for the creation of each layer model and the assembly of the whole machine model is introduced. Finally, a rapid modeling system (RMS) is established based on this method, enabling the automated creation of digital models of AFSSRs. Utilizing this system resulted in modeling time savings ranging from 20% to 97.5% compared to traditional methods, which verifies the feasibility and effectiveness of this method. Full article

Antenna design and optimization must ensure robust electrical performance, making its analysis a crucial step in all antenna design processes. Traditionally, this analysis involves setting up various cases after establishing the calculation model, comparing the performance of each case, and summarizing the impact of relevant factors to guide design and optimization. However, this method is time-consuming and inefficient. This paper proposes a sensitivity-based approach for analyzing antenna electrical performance, using a radome-covered array antenna as an example. First, we derive the formulas for calculating the antenna’s electrical performance and its sensitivity to the current amplitude, array element position, and radome thickness. We then design comparative experiments to analyze the antenna’s performance using the sensitivity-based method and the traditional case enumeration method. Comparing the conclusions of both methods, we find that they yield the same results regarding antenna performance. The proposed sensitivity-based method offers a quantitative evaluation of various influencing factors and provides a more scientific and systematic approach to analyzing antenna electrical performance. Full article
