In tunnel blasting, an analytical solution for dynamic stress in the surrounding rock of adjacent tunnels is critical for dynamic response analysis, mechanical evaluations, and crack propagation control. Previous studies on stress field analytical solutions primarily modeled rock as a linear elastic material, focusing mainly on the P-wave effects from instantaneous detonation. Based on Heelan’s short cylindrical cavity model, this paper derives an analytical solution for blast-induced dynamic stresses in adjacent tunnel rock, incorporating both induced SV-waves and a rock mass damage factor through rigorous theoretical analysis. Numerical case studies and field measurements were used to analyze stress propagation during tunnel blasting, and theoretical results were compared with measured data. The key findings were as follows: Radial stress > axial stress > hoop stress. All three stresses decay with increasing distance and damage factor, following an inversely proportional relationship with distance. Radial stress decays faster than axial and hoop stresses. Stress also decays exponentially over time, with the peak occurring after the transverse wave arrival. The theoretical results show approximately 10% deviation from the existing empirical formulas, while field measurements closely match the theoretical model, showing consistent stress trends and an average error of 7.02% (radial), 7.56% (axial) and 7.05% (hoop), confirming the reliability of the proposed analytical solution. Full article

It is vital to stabilize pillar dams in underground reservoirs in coal mine goafs to protect groundwater resources and quarry safety, practice green mining, and protect the ecological environment. Considering the actual occurrence of coal pillar dams in underground reservoirs, acoustic emission (AE) mechanical tests were performed on dry, naturally absorbed, and soaked coal samples. According to the mechanical analysis, Quantitative analysis revealed that dry samples exhibited the highest mechanical parameters (peak strength: 12.3 ± 0.8 MPa; elastic modulus: 1.45 ± 0.12 GPa), followed by natural absorption (peak strength: 9.7 ± 0.6 MPa; elastic modulus: 1.02 ± 0.09 GPa), and soaked absorption showed the lowest values (peak strength: 7.2 ± 0.5 MPa; elastic modulus: 0.78 ± 0.07 GPa). The rate of mechanical deterioration increased by ~25% per 1% increase in moisture content. It was identified that the internal crack development presented a macrofracture surface initiating at the sample center and expanding radially outward, and gradually expanding to the edges by adopting AE seismic source localization and the K-means clustering algorithm. Soaked absorption was easier to produce shear cracks than natural absorption, and a higher water content increased the likelihood. The b-value of the AE damage evaluation index based on crack development was negatively correlated with the rock damage state, and the S-value was positively correlated, and both effectively characterized it. The research results can offer reference and guidance for the support design, monitoring, and warning of coal pillar dams in underground reservoirs. (The samples were tested under two moisture conditions: (1) ‘Soaked absorption’—samples fully saturated by immersion in water for 24 h, and (2) ‘Natural absorption’—samples equilibrated at 50% relative humidity and 25 °C for 7 days). Full article

This study investigates a novel anchor-based method for controlled rock fragmentation, designed as an alternative to conventional excavation or explosive techniques. The proposed solution utilizes a specially modified undercut anchor that induces localized failure within the rock mass through radial expansion rather than traditional pull-out forces. Finite Element Method simulations, performed in ABAQUS with an extended fracture mechanics approach, were used to model the initiation and propagation of failure zones in sandstone. The results revealed a two-phase cracking process starting beneath the anchor’s driving element and progressing toward the rock’s free surface, forming a breakout cone. This behavior significantly deviates from conventional prediction models, such as the 45° cone or Concrete Capacity Design methods (cone 35°). The simulations were supported by field tests, confirming both the feasibility and practical advantages of the proposed anchor system, especially in confined or safety-critical environments. The findings offer valuable insights for the development of compact and efficient rock fragmentation technologies suitable for mining, rescue operations, and civil engineering applications. Full article

Acoustic tomography is a non-destructive technique used in the internal assessment of standing trees. Various researchers have focused on developing analytical tools using this technique, demonstrating that they can detect internal biodeterioration in cross-sections with good accuracy. This study evaluates the use of two ultrasonic wave devices with different frequencies (USLab and Sylvatest Duo) and a stress wave device (Microsecond Timer) to generate acoustic tomography using ImageWood VC1 software. The tests were carried out on 12 cross-sections of urban trees in the city of Madrid of the species Robinia pseudoacacia L., Platanus × hybrida Brot., Ulmus pumila L., and Populus alba L. Velocity measurements were made, forming a diffraction mesh in both standing trees and logs after cutting them down. An inspection was carried out with a perforation resistance drill (IML RESI F-400S) in the radial direction in each section, which allowed for more precise identification of defects and differentiating between holes and cracks. The various defects were determined with greater accuracy in the tomographic images taken with the higher-frequency equipment (45 kHz), and the combination of ultrasonic tomography and the use of the inspection drill can provide a more accurate representation of the defects. Full article

Residual particles embedded at the bond coat/substrate (BC/SUB) interface after grit blasting can affect the failure behavior of thermal barrier coatings (TBCs) under thermal cycling. This study employed a 2D finite element model combining the cohesive zone method (CZM) and extended finite element method (XFEM) to analyze the effect of interfacial grit particles. Specifically, the CZM was used to simulate crack propagation at the BC/thermally grown oxide (TGO) interface, while XFEM was applied to model the arbitrary crack propagation within the BC layer. Three models were analyzed: no grit inclusion, 20 μm grit particles, and 50 μm grit particles at the BC/SUB interface. This systematic variation allowed isolating the influence of particle size on the location of crack propagation onset, stress distribution, and crack growth behavior. The results showed that grit particles at the SUB/BC interface had negligible influence on the crack propagation location and rate at the BC/TGO interface, due to their spatial separation. However, their presence significantly altered the radial tensile stress distribution within the BC layer. Larger grit particles induced more intense stress concentrations and promoted earlier and more extensive vertical crack propagation within the BC. However, due to plastic deformation and stress redistribution in the BC, the crack propagation was progressively suppressed in the later stages of thermal cycling. Overall, grit particles primarily promoted vertical crack propagation within the BC layer. Optimizing grit blasting to control grit particle size is crucial for improving the durability of TBCs. Full article

The application of rebar reinforced ultra-high-performance concrete (R-UHPC) has been increasingly adopted in engineering structures due to its exceptional mechanical performance and durability characteristics. Nevertheless, when subjected to combined saline and stray current conditions, R-UHPC remains vulnerable to severe corrosion degradation. This investigation examined the corrosion performance and tensile behavior evolution of R-UHPC containing 2.0 vol% copper-coated steel fiber content and HRB400 steel rebar with a reinforcement ratio of 3.1%. The accelerated corrosion process was induced through an impressed current method, followed by direct tensile tests at varying exposure periods. The findings revealed that the embedding of rebar in UHPC led to the formation of fiber-to-rebar (F-R) conductive pathways, generating radial cracks besides laminar cracks. The bonding between rebar and UHPC degraded as corrosion progressed, leading to the loss of characteristic multiple-cracking behavior of R-UHPC in tension. Meanwhile, R-UHPC load-bearing capacity, transitioning from gradual to accelerated deterioration phases with prolonged corrosion, aligns with steel fibers temporally. During the initial 4 days of corrosion, the specimens displayed surface-level corrosion features with negligible steel fiber loss, showing less than 4.0% reduction in ultimate bearing capacity. At 8 days of corrosion, the steel fiber decreased by 22.6%, accompanied by an 18.3% reduction in bearing capacity. By 16 days of corrosion, the steel fiber loss reached 41.5%, with a corresponding bearing capacity reduction of 29.1%. During the corrosion process, corrosion cracks and load-bearing degradation in R-UHPC could be indicated by the ultrasonic damage factor. Full article

As a by-product of phosphate fertilizer production, phosphogypsum (PG) poses pressing environmental challenges that demand urgent resolution. To address the research gap in dynamic impact behavior of PG-modified concrete (PGC), this study developed truss-reinforced PGC slabs (PG volumetric fractions: 0% and 2%) and evaluated their impact resistance through drop-weight tests from a 3.75 m height. A systematic parametric investigation was conducted to quantify the effects of slab thickness (100–120 mm), steel plate reinforcement at the tension zone, PG content, and impact cycles. Experimental results revealed that increasing slab thickness to 120 mm reduced mid-span displacement by 13%, while incorporating steel plate reinforcement provided an additional 5.3% reduction. Notably, PG addition effectively suppressed crack propagation, transitioning failure modes from radial fracture patterns to localized mid-span damage. Finite element modeling ABAQUS (2022) validated experimental observations, demonstrating strong agreement. While optimized PG dosage (2%) exhibited limited influence on impact resistance, it enhanced PG utilization efficiency by 18%. Combined with increased slab thickness (displacement reduction: 13%), this study establishes a design framework balancing environmental sustainability and structural reliability for impact-resistant PGC applications. Within the framework of truss-reinforced concrete slabs with constant PG dosage, this study established a numerical model for geometric parameter modulation of impactors. Through systematic adjustment of the drop hammer’s contact width (a) and vertical geometric height (h), a dimensionless control parameter—aspect ratio c = h/a (0.2 ≤ c ≤ 1.8)—was proposed. Nonlinear dynamic analysis revealed that the peak impact load demonstrates an inverse proportional functional decay relationship with increasing c, yielding an empirical predictive model. These parametrized regularities provide theoretical foundations for contact interface optimization in impact-resistant structural design. Full article

Fractures and voids are widely distributed in slope rock masses. These defects promote crack initiation and propagation, ultimately leading to rock mass failure. Investigating their damage evolution mechanisms and strength characteristics is of significant importance for slope hazard prevention. A numerical simulation study of Brazilian splitting tests on disk samples containing prefabricated holes and fractures was conducted using the Finite Element Method with Cohesive Zone Modeling (FEM-CZM) in ABAQUS by embedding zero-thickness cohesive elements within the finite element model. This 2021 study analyzed the effects of fracture angle and length on tensile strength and crack propagation characteristics. The results revealed that when the fracture angle is small, cracks initiate near the fracture and propagate and intersect radially as the load increases, ultimately leading to specimen failure, with the crack coalescence pattern exhibiting local closure. As the fracture angle increases, the initiation location of the crack shifts. With an increase in fracture length, the crack initiation position may transfer to other parts of the fracture or near the hole, and longer fractures may result in more complex coalescence patterns and local closure phenomena. During the tensile and stable failure stages, the load–displacement curves of samples with different fracture angles and lengths exhibit similar trends. However, the fracture angle has a notable impact on the curve during the shear failure stage, while the fracture length significantly affects the peak value of the curve. Furthermore, as displacement increases, the proportion of tensile failure undergoes a process of rapid decline, slow rise, and then rapid decline again before stabilizing, with the fracture angle having a significant influence on the proportion of tensile failure. Lastly, as the fracture angle and length increase, the number of damaged cohesive elements shows an upward trend. This study provides novel perspectives on the tensile behavior of fractured rock masses through the FEM-CZM approach, contributing to a fundamental understanding of the strength characteristics and crack initiation mechanism of rocks under tensile loading conditions. Full article

The experimental study of shale fracture development is very important. As a channel of permeability, a fracture has a great influence on the development of shale gas. This study presents the results of a fracture evaluation in the Silurian Longmaxi Shale using the laboratory triaxial compression experiments and CT reconstruction, considering both mechanical properties and fracture network multi-dimensional quantitative characterization. The results indicate that the plastic deformation stage of shale lasts longer under high confining pressure, whereas radial deformation is restricted. Confining pressure has a nice linear connection with both compressive strength and elastic modulus. The 2D fractal dimension of radial and vertical cracks is 1.09–1.28 when the confining pressure is between 5 and 25 MPa. The 3D fractal dimension of the fracture is 2.08–2.16. There is a linear negative correlation at high confining pressure (R² > 0.80) and a weak linear association between the 3D fractal dimension of the fracture and confining pressure at low confining pressure. The fracture angle calculated by the volume weight of multiple main cracks has a linear relationship with the confining pressure (R² > 0.89), and its value is 73.90°–52.76°. The fracture rupture rate and fracture complexity coefficient are linearly negatively correlated with confining pressure (R² > 0.82). The Euler number can well characterize the connectivity of shale fractures, and the two show a strong linear positive correlation (R² = 0.98). We suggest that the bedding plane gap compression, radial deformation limitation, and interlayer effect weakening are efficient mechanisms for the formation of shale fracture networks induced by confining pressure, and that confining pressure plays a significant role in limiting and weakening the development of shale fractures, based on the quantitative characterization results of fractures. Full article

This study investigates the fatigue durability of Plexus MA300 methacrylic adhesive, which is employed in structural joints of metals, plastics, and composites. Cast adhesive specimens were subjected to cyclic tensile loads at a frequency of 5 Hz with a stress ratio R = 0.1. Six load levels were tested. Hysteresis loops were recorded during testing and analyzed in detail. Significant differences in fatigue fracture characteristics were observed depending on load level. Specimens subjected to high loads exhibited a characteristic radial structure with a distinct crack initiation point, whereas specimens tested at lower loads showed more uniform, matte fracture surfaces. Hysteresis loop analysis revealed phenomena typical for polymers: creep and damping causing energy dissipation. Various fatigue approaches were compared: stress-based, strain-based, energy-based, and stiffness-based. The highest coefficient of determination (R²) was obtained for the model based on strain energy density, indicating its superior utility in predicting the fatigue life of the tested adhesive. The obtained results contribute to the understanding of the fatigue behavior of methacrylic adhesives and provide practical data for structural joint design involving this material class. Full article

Wellbore instability is a major constraint in large-scale shale oil extraction. This study focuses on the shale–sandstone interbedded shale oil reservoirs in the Chang 7 area, delving into the evolutionary principles governing wellbore stability in horizontal drilling operations within these formations. A geological feature analysis of shale–sandstone reservoir characteristics coupled with rigorous mechanical experimentation was undertaken to investigate the micro-mechanisms underpinning wellbore instability. The Mohr–Coulomb failure criterion applicable to sandstone and the multi-weakness planes failure criterion of shale were integrated to analyze the stress distribution of surrounding rocks within horizontal wells, facilitating the computation of collapse pressure and fracture pressure. A finite element model of wellbore stability in shale–sandstone horizontal drilling was established, and then we conducted a comprehensive analysis of the impacts of varying elastic moduli, Poisson’s ratio, and in-situ stress on wellbore stability. The findings reveal that under varying confining pressures, the predominant failure mode observed in most sandstone samples is characterized by inclined shear failure, coupled with a reduced incidence of crack formation. The strength of shale escalates proportionally with increasing confining pressure, resulting in a reduced susceptibility to failure along its inherent weak planes. This transition is characterized by a gradual shift from the prevalent mode of longitudinal splitting towards inclined shear failure. As the elastic modulus of shale rises, the discrepancy between circumferential and radial stresses decreases. In contrast, with the increasing elastic modulus of sandstone, the gap between circumferential and radial stresses widens, potentially inducing potential instabilities in the wellbore. An increase in sandstone’s Poisson’s ratio corresponds to a proportional increase in the difference between circumferential and radial stresses. Under reverse fault stress regimes, wellbore collapse and instability are predisposed to occur. Calculations of collapse pressure and fracture pressure reveal that the safety density window is minimized at the interface between shale and sandstone, rendering it susceptible to wellbore instability. These research findings offer significant insights for the investigation of wellbore stability in interbedded shale–sandstone reservoirs contributing to the academic discourse in this field. Full article

In nature, many brittle materials contain natural defects such as microcracks or joints, for example, rocks. Under water-saturated conditions, the strength of defective materials undergoes varying degrees of attenuation, leading to material failure and even structural instability in engineering contexts. Moreover, the deformation and failure of defective brittle materials are essentially the result of the accumulation and dissipation of energy. Studying the energy evolution of defective brittle materials under load is more conducive to reflecting the intrinsic characteristics of strength changes and overall failure of brittle materials under external loading. Natural defective brittle rock materials were firstly water saturated and triaxial compression tests were performed to determine the mechanical properties of water-saturated materials. The energy evolution patterns of water-saturated materials under varying confining pressures were also obtained. Using the discrete element method, the macro- and micro-failure characteristics of water-saturated materials were investigated, revealing the mesoscopic mechanisms of deformation and failure evolution in these materials. The results indicate that confining pressure significantly enhances the peak compressive strength and elastic modulus of water-saturated defective materials. When the confining pressure increased from 0 MPa to 20 MPa, the peak strength and elastic modulus of the water-saturated materials increased by 126.8% and 91.9%, respectively. Confining pressure restricts the radial deformation of water-saturated materials and dominates the failure mode. As confining pressure increases, the failure mode transitions from tensile splitting (at 0 MPa confining pressure) to shear failure (at confining pressures ≥ 10 MPa), with the failure plane angle gradually decreasing as confining pressure rises. Confining pressure significantly alters the energy storage–release mechanism of water-saturated defective brittle materials. At peak load, the total energy, elastic energy, and dissipated energy increased by 347%, 321%, and 1028%, respectively. The ratio of elastic energy storage to peak strain ratio shows a positive correlation, and the elastic storage ratio of water-saturated defective brittle materials under confining pressure is always higher than that without confining pressure. When the strain ratio exceeds 0.94, a negative correlation between confining pressure and the rate of elastic storage ratio is observed. From the perspective of mesoscopic fracture evolution in water-saturated defective brittle materials, the crack propagation path shifts from the periphery to the center of the material, and the fracture angle decreases linearly from 89° to 58° as confining pressure increases. The dominant direction of crack development is concentrated within the 45–135° range. The findings elucidate the mechanisms by which water saturation and confining pressure influence the strength degradation of natural defective brittle materials from both mesoscopic and energy perspectives, providing theoretical support for the stability control of related engineering structures. Full article

Conventional rock mechanical testing approaches encounter significant limitations when applied to deeply buried fractured formations, constrained by formidable sampling difficulties, prohibitive costs, and intricate specimen preparation demands. This investigation pioneers an innovative nanoindentation-based multiscale methodology (XRD–ED–SEM integration) that revolutionizes the mechanical characterization of dolostone through drill cuttings analysis, effectively bypassing conventional coring requirements. Our integrated approach combines precision surface polishing with advanced indenter calibration protocols, enabling the continuous stiffness method to achieve unprecedented measurement accuracy in determining micromechanical properties—notably an elastic modulus of 119.47 GPa and hardness of 5.88 GPa—while simultaneously resolving complex indentation size effect mechanisms. The methodology reveals three critical advancements: remarkable 92.7% dolomite homogeneity establishes statistically significant elastic modulus–hardness correlations (R² > 0.89), while residual imprint analysis uncovers a unique brittle–plastic interaction mechanism through predominant rhomboid plasticity (84% occurrence) accompanied by microscale radial cracking (2.1–4.8 μm). Particularly noteworthy is the identification of load-dependent property variations, where surface hardening effects and defect interactions cause 28.7% parameter dispersion below 50 mN loads, progressively stabilizing to <8% variance at higher loading regimes. By developing a micro–macro bridging model that correlates nanoindentation results with triaxial test data within a 12% deviation, this work establishes a groundbreaking protocol for carbonate reservoir evaluation using minimal drill cutting material. The demonstrated methodology not only provides crucial insights for optimizing hydraulic fracture designs and wellbore stability assessments, but it also fundamentally transforms microstructural analysis paradigms in geomechanics through its successful application of nanoindentation technology to complex geological systems. Full article

When two axisymmetric stress waves of the same strength propagate radially at the same velocity, the stress wave wavefronts collide and interact along a specific locus, which is the perpendicular bisector between the two sources. The maximum principal stress occurs along this perpendicular bisector, and the tensile stresses result in crack bridging between the two source points. This symmetric wave propagation behavior allows us to use the Voronoi tessellation diagram and its symmetric dual graph, the Delaunay triangulation, to gain first-order insight into complex wave propagation phenomena for an arbitrary distribution of wave propagation sources. The inherent symmetry of these simultaneous wave propagation mechanics allows us to rapidly visualize and predict the stress wave propagation and interactions, and the resultant crack bridging patterns that arise from random blast sources. The current work is focused on rock blast fracture mechanics, but the visualization scheme can be implemented for any application where waves propagate axisymmetrically and interact. Full article

Electronic devices play an extremely important role in the aerospace field. Aluminum nitride (AlN) is a promising ceramic material for high-reliability electronic packaging structures that are subjected to impact loads during service. Quasi-static and dynamic flexural tests were conducted to determine the rate-dependent flexural strengths of AlN ceramics. The impact response of the AlN substrates was investigated using experimental tests and a smeared fixed-crack numerical model. The critical velocity of the impactor and the failure mode of the ceramic plate can be accurately predicted using the Drucker–Prager criterion with the scaled fracture-strength parameter. The radial cracks on the ceramic plate upon impact were well reproduced via the proposed novel numerical technique, showing better accuracy compared to the widely used Johnson–Holmquist II (JH-2) model. The effect of impactor nose shape and deflection angles were further investigated to better illustrate the low-velocity impact response of AlN ceramic substrates. Based on the dynamic flexural-strength testing results, this study achieves the prediction of low-speed impact response for AlN ceramic structures, thereby providing technical support for the impact reliability analysis of aerospace ceramic-packaging devices. Full article
