With the development of morphing aircraft, understanding the fluid–structure interaction (FSI) mechanisms of multibody systems composed of rigid and flexible components has become increasingly important. The coupled motion and deformation of such systems in a flow field give rise to complex nonlinear FSI problems. Here, we propose a fluid–multibody–structure interaction framework that couples a finite volume Navier–Stokes solver, a multibody dynamics solver, and radial basis function interpolation for fluid–structure data transfer. The framework is validated using a benchmark case and subsequently applied to simulations of a two-segment flexible beam and a three-dimensional continuously variable-sweep wing. The results show that the presence of joints and structural flexibility substantially affects the FSI response: hinge location markedly alters the FSI characteristics of the multibody flexible-beam system, while increasing the sweep angle during continuous morphing reduces the aerodynamic force coefficients and structural flexibility induces persistent fluctuations in aerodynamic loads. A key contribution of the proposed framework is its ability to capture both active morphing motions and passive aeroelastic deformations simultaneously. Compared with approaches based on inviscid, incompressible aerodynamic models, the present high-fidelity flow solver can better resolve complex flow phenomena during morphing. This framework provides a useful numerical tool for investigating FSI mechanisms in morphing aircraft. Its current limitations include the computational cost of global radial basis function interpolation for large multibody systems and its applicability being restricted to low-Mach-number flows. Full article

Background/Objectives: This paper investigates the application of radial basis function (RBF) interpolation to adapt the Toyota Human Model for Safety (THUMS) version 6 finite element (FE) models to diverse anthropometric profiles using ANSUR II data. The research focuses on generating personalized human body models (HBMs) across 50th, 80th, and 98th percentiles for both sexes in standing and seated postures, evaluating mesh quality with quantitative metrics, and assessing posture-dependent transformations. Methods: The geometric accuracy for the standing configuration was quantified using DICE similarity coefficients and the 95th percentile Hausdorff distance (HD95). Results: While global whole-body DICE similarity averaged approximately 0.40 due to an inherent variability in distal limb positioning, regional analysis demonstrated strong volumetric overlap in the critical chest and torso regions with DICE values ranging from 0.80 to 0.88. Regional HD95 values were within 20–30 mm across most of the surface area. Surfaces distance analyses showed that more than 95% of the nodes were within $\pm 20$ mm of the target surfaces with the distribution centered near zero across all the percentiles. The mesh quality for both standing and seated morphs demonstrated low violation rates with the aspect ratio being 28% to 30%, while warpage, skewness and, Jacobian determinants were less than 15%. The seated morphs preserved anatomical alignment and posture despite mesh density differences between the postures. Conclusions: These findings indicate that the morphing process preserves anatomical fidelity while highlighting the need for further optimization to mitigate localized distortions in dynamic simulations. Full article

Designing high-speed aircraft for wide-speed-range operation remains a major aerodynamic challenge. This study investigates the unsteady aerodynamics of a continuously morphing airfoil from transonic to hypersonic regimes. A smooth morphing trajectory is constructed among transonic, supersonic, and hypersonic baseline shapes, and analyzed via high-fidelity unsteady Reynolds-averaged Navier–Stokes (URANS) simulations with a radial basis function (RBF) dynamic mesh. Two processes are examined: pure geometric morphing at fixed Mach numbers (Ma), and morphing coupled with flight acceleration. Key findings reveal two distinct adaptation features: (1) Transonic flow is highly sensitive to morphing (28.8% drop in lift-to-drag ratio), while supersonic flow is robust (<5% variation). (2) During coupled acceleration, the flow transitions smoothly—the shock evolves from a detached bow wave to an attached oblique structure, and the adaptive airfoil maintains a lift-to-drag ratio above 4 across Ma = 0.8–6. Additionally, wake vorticity transitions from organized shear layers to multi-scale clusters. These results elucidate the flow physics mechanism of continuous morphing and provide a framework for designing adaptive wide-speed-range aircraft. Full article

Aerodynamics is a key factor in time-trial cycling. Over the years, various aspects have been investigated, including positioning, clothing, bicycle design, and helmet shape. The present study focuses on the development of a methodology for the aerodynamic optimization of a time-trial helmet through the implementation of a reduced-order model, alongside advanced simulation techniques, such as computational fluid dynamics, radial basis functions, mesh morphing, and response surface methodology. The implementation of a reduced-order model enhances the understanding of aerodynamic interactions compared to traditional optimization workflows reported in sports-related research, facilitating the identification of an optimal helmet shape during the design phase. The study offers practical insights for refining helmet design. Starting with a baseline teardrop profile, several morphing configurations are systematically tested, resulting in a 10% reduction in the drag force acting on the helmet. The reduced-order model also facilitates the analysis of turbulent flow patterns on the cyclist’s body, providing a detailed understanding of aerodynamic interactions. By leveraging reduced-order models and advanced simulation techniques, this study contributes to ongoing efforts to reduce the aerodynamic resistance of time-trial helmets, ultimately supporting the goal of improved athlete performance. Full article

In the realm of cardiac health research, accurate fluid dynamics simulations are vital for comprehending the heart function and diagnosing conditions. Central to these simulations is the precision of ventricular wall meshes used to model heart geometry. However, segmenting the wetted surface, particularly in the right ventricle (RV) with its significantly thinner parietal thickness compared to the left ventricle, presents challenges. This study focuses on qualitatively evaluating an automated reconstruction model for the RV’s outer wall using Radial Basis function (RBF) morphing. Two procedural criteria were compared, a random selection of control points and a curvature-based approach, which differ in terms of the identification of the control points of the RBF function. From these considerations, it emerges that a controlled use of the RBF function on the basis of the curvatures guarantees the greater controllability of the shape evolutions of the parietal structure of the RV, but it is more sensitive to any anomalies in the distribution of the vertices, as can be seen from the number of outliers, and its controllability is a function of the percentage of points chosen, exerting a greater impact on the required computational capacity. The definition of a strategic criterion for the selection of control points could represent a crucial aspect in the definition of an automatic reconstruction procedure of anatomical elements, which guarantees a morphological variability in line with the need to expand the pathological sample to be used for statistical formulations in the clinical field. Full article

The treatment for asthma and chronic obstructive pulmonary disease relies on forced inhalation of drug particles. Their distribution is essential for maximizing the outcomes. Patient-specific computational fluid dynamics (CFD) simulations can be used to optimize these therapies. In this regard, this study focuses on creating a parametric model of the human respiratory tract from which synthetic anatomies for particle deposition analysis through CFD simulation could be derived. A baseline geometry up to the fourth generation of bronchioles was extracted from a CT dataset. Radial basis function (RBF) mesh morphing acting on a dedicated tree structure was used to modify this baseline mesh, extracting 1000 synthetic anatomies. A total of 26 geometrical parameters affecting branch lengths, angles, and diameters were controlled. Morphed models underwent CFD simulations to analyze airflow and particle dynamics. Mesh morphing was crucial in generating high-quality computational grids, with 96% of the synthetic database being immediately suitable for accurate CFD simulations. Variations in wall shear stress, particle accretion rate, and turbulent kinetic energy across different anatomies highlighted the impact of the anatomical shape on drug delivery and deposition. The study successfully demonstrates the potential of tree-structure-based RBF mesh morphing in generating parametric airways for drug delivery studies. Full article

The forecasted growth in dynamic global air fleet size in the coming decades, together with the need to introduce disruptive technologies supporting net-zero emission air transport, demands more efficient design and optimization workflows. This research focuses on developing an aerodynamic optimization framework suited for multi-objective studies of small aircraft engine air-intake ducts in multiple flight conditions. In addition to the refinement of the duct’s performance criteria, the work aims to improve the economic efficiency of the process. The optimization scheme combines the advantages of Kriging-based Efficient Global Optimization (EGO) with the Radial Basis Functions (RBF)-based mesh morphing technique and the Chebyshev-type Achievement Scalarizing Function (ASF) for handling multiple objectives and design points. The proposed framework is applied to an aerodynamic optimization study of an I-31T aircraft turboprop engine intake system. The workflow successfully reduces the air-duct pressure losses and mitigates the flow distortion at the engine compressor’s front face in three considered flight phases. The results prove the framework’s potential for solving complex multi-point air-intake duct problems and the capacity of the ASF-based formulation to guide optimization toward the designer’s preferred objective targets. Full article

Front wings are a key element in the aerodynamic performance of Formula 1 race cars. Thus, their optimisation makes an important contribution to the performance of cars in races. However, their design is constrained by regulation, which makes it more difficult to find good designs. The present work develops a hybrid shape optimisation approach to obtain an optimal five-element airfoil front wing under the FIA regulations and 17 design parameters. A first baseline design is obtained by parametric optimisation, on which the adjoint method is applied for shape optimisation via Mesh Morphing with Radial Basis Functions. The optimal front wing candidate obtained outperforms the parametric baseline up to a 25% at certain local positions. This shows that the proposed and tested hybrid approach can be a very efficient alternative. Although a direct 3D optimisation approach could be developed, the computational costs would be dramatically increased (possibly unaffordable for such a complex five-element front wing realistic shape with 17 design parameters and regulatory constraints). Thus, the present approach is of strong interest if the computational budget is low and/or a fast new front wing design is desired, which is a frequent scenario in Formula 1 race car design. Full article

Numerical optimization procedures are one of the most powerful approaches with which to support design processes. Their implementation, nevertheless, involves several conceptual and practical complexities. One of the key points relates to the geometric parameterization technique to be adopted and its coupling with the numerical solver. This paper describes the setup of a procedure in which the shape parameterization, based on mesh morphing, is integrated into the analysis tool, accessing the grid nodes directly within the solver environment. Such a coupling offers several advantages in terms of robustness and computational time. Furthermore, the ability to morph the mesh “on the fly” during the computation, without heavy Input/Output operations, extends the solver’s capability to evaluate multidisciplinary phenomena. The procedure was preliminary tested on a simple typical shape optimization problem and then applied to a complex setup of an industrial case: the identification of the shape of a Volvo side-view mirror that minimizes the accumulation of water on the lens of a camera mounted beneath. Full article

Fluid structure interaction (FSI) is a complex phenomenon that in several applications cannot be neglected. Given its complexity and multi-disciplinarity the solution of FSI problems is difficult and time consuming, requiring not only the solution of the structural and fluid domains, but also the use of expensive numerical methods to couple the two physics and to properly update the numerical grid. Advanced mesh morphing can be used to embed into the fluid grid the vector fields resulting from structural calculations. The main advantage is that such embedding and the related computational costs occur only at initialization of the computation. A proper combination of embedded vector fields can be used to tackle steady and transient FSI problems by structural modes superposition, for the case of linear structures, or to impose a full non-linear displacement time history. Radial basis functions interpolation, a powerful and precise meshless tool, is used in this work to combine the vector fields and propagate their effect to the full fluid domain of interest. A review of industrial high fidelity FSI problems tackled by means of the proposed method and RBF is given for steady, transient, and non-linear transient FSI problems. Full article

Flow separation and dynamic stall occurring at a high angle of attack will lead to difficulty in control and maneuverability for morphing aircraft. This study proposes a novel active flow control technology using a synthetic jet actuator for the roll motion of morphing aircraft. With the help of the computational fluid dynamics method and vortex lattice method, the roll control model of morphing aircraft undergoing large shape change at a high angle of attack is established. In this model, both the array of the actuator with an optimized cavity shape and morphing span, which are subject to the input saturation constraint, are used to mimic the conventional control surface. Integrated flight control based on the sliding mode control method is designed to ensure the desired closed-loop asymptotic stability, wherein the radial basis function neural network is employed to provide the compensation induced by the input saturation constraint. To demonstrate the effectiveness of the control scheme, various control strategies for different combinations of input are proposed to maintain the roll motion. The numerical results show that the designed control law could track the target signal well, which suggests that the virtual control surface is an effective tool for maintaining the high flight performance of morphing aircraft. Full article
