Search Results (17)

Search Parameters:
Keywords = radar entomology

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
22 pages, 9013 KiB
Article
Application of Instance Segmentation to Identifying Insect Concentrations in Data from an Entomological Radar
by Rui Wang, Jiahao Ren, Weidong Li, Teng Yu, Fan Zhang and Jiangtao Wang
Remote Sens. 2024, 16(17), 3330; https://doi.org/10.3390/rs16173330 - 8 Sep 2024
Cited by 2 | Viewed by 1634
Abstract
Entomological radar is one of the most effective tools for monitoring insect migration, capable of detecting migratory insects concentrated in layers and facilitating the analysis of insect migration behavior. However, traditional entomological radar, with its low resolution, can only provide a rough observation [...] Read more.
Entomological radar is one of the most effective tools for monitoring insect migration, capable of detecting migratory insects concentrated in layers and facilitating the analysis of insect migration behavior. However, traditional entomological radar, with its low resolution, can only provide a rough observation of layer concentrations. The advent of High-Resolution Phased Array Radar (HPAR) has transformed this situation. With its high range resolution and high data update rate, HPAR can generate detailed concentration spatiotemporal distribution heatmaps. This technology facilitates the detection of changes in insect concentrations across different time periods and altitudes, thereby enabling the observation of large-scale take-off, landing, and layering phenomena. However, the lack of effective techniques for extracting insect concentration data of different phenomena from these heatmaps significantly limits detailed analyses of insect migration patterns. This paper is the first to apply instance segmentation technology to the extraction of insect data, proposing a method for segmenting and extracting insect concentration data from spatiotemporal distribution heatmaps at different phenomena. To address the characteristics of concentrations in spatiotemporal distributions, we developed the Heatmap Feature Fusion Network (HFF-Net). In HFF-Net, we incorporate the Global Context (GC) module to enhance feature extraction of concentration distributions, utilize the Atrous Spatial Pyramid Pooling with Depthwise Separable Convolution (SASPP) module to extend the receptive field for understanding various spatiotemporal distributions of concentrations, and refine segmentation masks with the Deformable Convolution Mask Fusion (DCMF) module to enhance segmentation detail. Experimental results show that our proposed network can effectively segment concentrations of different phenomena from heatmaps, providing technical support for detailed and systematic studies of insect migration behavior. Full article
(This article belongs to the Topic Radar Signal and Data Processing with Applications)
Show Figures

Figure 1

22 pages, 10945 KiB
Article
Analysis of the Influence of Polarization Measurement Errors on the Parameter and Characteristics Measurement of the Fully Polarized Entomological Radar
by Muyang Li, Teng Yu, Rui Wang, Weidong Li, Fan Zhang and Chunfeng Wu
Remote Sens. 2024, 16(7), 1220; https://doi.org/10.3390/rs16071220 - 30 Mar 2024
Viewed by 1103
Abstract
Measuring the orientation, mass and body length of migratory insects through entomological radar is crucial for early warnings of migratory pests. The fully polarized entomological radar is an efficient device for observing migratory insects by calculating insect parameters through the scattering matrix obtained [...] Read more.
Measuring the orientation, mass and body length of migratory insects through entomological radar is crucial for early warnings of migratory pests. The fully polarized entomological radar is an efficient device for observing migratory insects by calculating insect parameters through the scattering matrix obtained from the target. However, the measured target scattering matrix will be affected by system polarization measurement errors, leading to errors in insect parameter calculation, while the related analysis is currently relatively limited. Therefore, the scattering matrix measurement process is modeled, followed by an analysis of the effects of different errors on orientation, mass and body length estimation. The influence of polarization measurement errors on insect scattering characteristics is also analyzed. The results present that for fixed polarization measurement errors, the measurement errors of insect orientation, mass and body length will vary with insect orientation in specific patterns, and the distribution of measured insect parameters will be drastically distorted compared to the true parameter distribution. In addition, polarization measurement errors could seriously disrupt the reciprocity and bilateral symmetry of the measured insect scattering matrix. These analyses and conclusions provide a good basis for eliminating the effects of polarization measurement errors and improving the accuracy of insect parameter measurement. Full article
(This article belongs to the Special Issue Aerial Remote Sensing System for Agriculture)
Show Figures

Figure 1

13 pages, 9814 KiB
Communication
Shadow Effect for Small Insect Detection by W-Band Pulsed Radar
by Miguel Hernández Rosas, Guillermo Espinosa Flores-Verdad, Hayde Peregrina Barreto, Pablo Liedo and Leopoldo Altamirano Robles
Sensors 2023, 23(22), 9169; https://doi.org/10.3390/s23229169 - 14 Nov 2023
Cited by 2 | Viewed by 1946
Abstract
In radar entomology, one primary challenge is detecting small species (smaller than 5 cm) since these tiny insects reflect radiation that can be poorly observable and, therefore, difficult to interpret. After a literature search on radar entomology, this research found few works where [...] Read more.
In radar entomology, one primary challenge is detecting small species (smaller than 5 cm) since these tiny insects reflect radiation that can be poorly observable and, therefore, difficult to interpret. After a literature search on radar entomology, this research found few works where it has been possible to sense insects with dimensions smaller than 5 cm using radars. This paper describes different methodologies to detect Mediterranean fruit flies with 5–6 mm sizes using a pulsed W-band radar and presents the experimental results that validate the procedures. The article’s main contribution is the successful detection of Mediterranean fruit flies employing the shadow effect on the backscattered radar signal, achieving an 11% difference in received power when flies are present. So far, according to the information available and the literature search, this work is the first to detect small insects less than 1 cm long using a pulsed radar in W-Band. The results show that the proposed shadow effect is a viable alternative to the current sensors used in smart traps, as it allows not only detection but also counting the number of insects in the trap. Full article
(This article belongs to the Section Radar Sensors)
Show Figures

Figure 1

19 pages, 5880 KiB
Article
A Migratory Biomass Statistical Method Based on High-Resolution Fully Polarimetric Entomological Radar
by Teng Yu, Muyang Li, Weidong Li, Tianran Zhang, Rui Wang and Cheng Hu
Remote Sens. 2022, 14(21), 5426; https://doi.org/10.3390/rs14215426 - 28 Oct 2022
Viewed by 1908
Abstract
Entomological radar is a specially designed instrument that can measure the behavioral and biological characteristics of high-altitude migrating insects. Its application is of great significance for the monitoring, early warning, and control of agricultural pests. As an important component of the local migratory [...] Read more.
Entomological radar is a specially designed instrument that can measure the behavioral and biological characteristics of high-altitude migrating insects. Its application is of great significance for the monitoring, early warning, and control of agricultural pests. As an important component of the local migratory biomass, insects fly in the air during the day and night. The fully polarimetric entomological radar was carefully designed with all-day, all-weather, and multi-function measurement capabilities. The fully polarimetric entomological radar measures the mass of a single insect based on the radar cross-sectional (RCS) measurement and then calculates the biomass of migrating insects. Therefore, the measurement accuracy of the insect RCS is the key indicator affecting the accuracy of migratory biomass statistics. Due to the radar’s lack of in-beam angle measurement ability, the insect RCS is usually measured based on the assumption that the insect is on the beam center. Therefore, the measured RCS will be smaller than true value if the insect deviates from the beam center due to the gain curve of the antenna. This leads to measurement errors in regard to the insect mass and migratory biomass. In order to solve this problem, a biomass estimation method, reported in this paper, was designed under the assumption of a uniform distribution of migrating insects in the radar monitoring airspace. This method can estimate the individual RCS expectation of migrating insects through a statistical method without measuring the position of the insects in the beam and then obtain the migratory biomass. The effectiveness of the model and algorithm is verified by simulations and entomological radar field measurements. Full article
Show Figures

Figure 1

22 pages, 6916 KiB
Article
High-Resolution and Low Blind Range Waveform for Migratory Insects’ Taking-Off and Landing Behavior Observation
by Rui Wang, Tianran Zhang, Kai Cui, Teng Yu, Qi Jiang, Rongjing Zhang, Jiayi Li and Cheng Hu
Remote Sens. 2022, 14(13), 3034; https://doi.org/10.3390/rs14133034 - 24 Jun 2022
Cited by 5 | Viewed by 1988
Abstract
The observation of taking-off and landing behaviors of migratory insects is important for pest early monitoring and forecasting. Entomological radar, which can measure the ascent or descent rates remotely, has been proved to be the most effective way to observe the above behaviors. [...] Read more.
The observation of taking-off and landing behaviors of migratory insects is important for pest early monitoring and forecasting. Entomological radar, which can measure the ascent or descent rates remotely, has been proved to be the most effective way to observe the above behaviors. For the current entomological radars, the highest range resolution of 7.5 m and smallest blind range of 150 m make it difficult to distinguish individual insects in a swarm and observe the migratory behaviors at low altitudes. In this paper, based on the outfield data acquired from a high-resolution radar of 0.2 m, the spatial spacing distribution of migratory insects is presented for the first time and waveform design requirements are analyzed, proving the necessity of a higher resolution. Secondly, for the high-resolution and low blind range observation of insects, the stepped frequency train of LFM pulses (also called frequency-jumped burst, FJB) waveform is discussed as the optimal choice. In order to resolve the high grating-lobe problem in the FJB waveform with the low blind range, the precise spectrum model and its approximation of the LFM subpulse are first derived in detail. Then, according to the obtained spectrum characteristics, the high-resolution and low blind range FJB waveform design methods based on spectrum fluctuation period and Fresnel integral windowing are proposed to reduce the grating-lobe number to more than 50% and suppress the highest grating lobe level by at least 4 dB. Finally, based on the high-resolution and low blind range VLR adopting the proposed waveform, several typical taking-off and landing behavior observation results are presented, which proves that, in their migratory pattern, insects usually take off around sunset. Full article
Show Figures

Graphical abstract

20 pages, 9357 KiB
Article
Insect Migration Flux Estimation Based on Statistical Hypothesis for Entomological Radar
by Teng Yu, Muyang Li, Weidong Li, Jiong Cai, Rui Wang and Cheng Hu
Remote Sens. 2022, 14(10), 2298; https://doi.org/10.3390/rs14102298 - 10 May 2022
Cited by 2 | Viewed by 2079
Abstract
Measuring migration flux with entomological radar is of great importance to assess the biomass of migratory insects and study the influence of insects on the ecosystem. However, the migration flux is measured with a large quantity of errors for the entomological radar without [...] Read more.
Measuring migration flux with entomological radar is of great importance to assess the biomass of migratory insects and study the influence of insects on the ecosystem. However, the migration flux is measured with a large quantity of errors for the entomological radar without the ability of in-beam angle measurement, because the insect RCS is measured with the assumption that the insect flies over the beam center. When the insect does not pass through the beam center, the measured RCS is less than the true value. To improve the estimation accuracy of migration flux, a new estimation method of migration flux based on statistical hypothesis is proposed for radars working in the fixed-beam vertical-looking mode. This method avoids the RCS measurement error caused by the offset of the insect trajectory to the radar beam center by assuming that the insect flight trajectory is evenly distributed in the beam and calculating the average value of flux. This method is extended to be used in fixed-beam arbitrary pointing mode and a new proposed scanning mode. The effectiveness of the proposed method is verified by simulations and migration insect data measured by a radar. Full article
Show Figures

Graphical abstract

19 pages, 29486 KiB
Article
Polarimetric Calibration Technique for a Fully Polarimetric Entomological Radar Based on Antenna Rotation
by Teng Yu, Muyang Li, Weidong Li, Huafeng Mao, Rui Wang, Cheng Hu and Teng Long
Remote Sens. 2022, 14(7), 1551; https://doi.org/10.3390/rs14071551 - 23 Mar 2022
Cited by 6 | Viewed by 2746
Abstract
For entomological radar, the polarization information of the target is usually used to estimate the biological parameters, such as orientation, body length, and mass, of the insect. Thus, the accuracy of polarization measurement directly affects the performance of the biological parameters’ estimation. The [...] Read more.
For entomological radar, the polarization information of the target is usually used to estimate the biological parameters, such as orientation, body length, and mass, of the insect. Thus, the accuracy of polarization measurement directly affects the performance of the biological parameters’ estimation. The polarization measurement error is mainly caused by the imbalance of amplitude and phase between two polarization channels and the crosstalk of the dual-polarization antenna. In order to obtain the correct polarization information of the target, the polarimetric calibration of the entomological radar is required. This paper proposes a new polarimetric calibration technique based on antenna rotation, which does not require the calibrator to have a specific polarization scattering matrix (PSM). Compared with the currently existing calibration techniques, no prior knowledge of the calibrator PSM is required (in fact, any fixed-point target can be used as a calibrator); thus, the errors introduced by the mechanical process can be avoided. Simulations and data measured by radar verify the effectiveness of the method. This method has the potential to be extended to other fully polarimetric radar systems in the future, such as fully polarimetric weather radar, fully polarimetric synthetic aperture radar (SAR), and so on. Full article
Show Figures

Figure 1

21 pages, 8249 KiB
Technical Note
Simulation of the Radar Cross Section of a Noctuid Moth
by Freya I. Addison, Thomas Dally, Elizabeth J. Duncan, James Rouse, William L. Evans, Christopher Hassall and Ryan R. Neely
Remote Sens. 2022, 14(6), 1494; https://doi.org/10.3390/rs14061494 - 20 Mar 2022
Cited by 5 | Viewed by 3775
Abstract
Electromagnetic modelling may be used as a tool for understanding the radar cross section (RCS) of volant animals. Here, we examine this emerging method in detail and delve deeper into the specifics of the modelling process for a single noctuid moth, with the [...] Read more.
Electromagnetic modelling may be used as a tool for understanding the radar cross section (RCS) of volant animals. Here, we examine this emerging method in detail and delve deeper into the specifics of the modelling process for a single noctuid moth, with the hope of illuminating the importance of different aspects of the process by varying the morphometric and compositional properties of the model. This was accomplished by creating a high-fidelity three-dimensional insect model by micro-CT scanning a gold-palladium-coated insect. Electromagnetic simulations of the insect model were conducted by applying different morphological and compositional configurations using the WiPL-D Pro 3D Electromagnetic Solver. The simulation results show that high-resolution modelling of insects has advantages compared to the simple ellipsoidal models used in previous studies. We find that the inclusion of wings and separating the composition of the body, wings, and legs and antennae have an impact on the resulting RCS of the specimen. Such modifications to the RCS are missed when a prolate spheroid model is used and should not be ignored in future studies. Finally, this methodology has been shown to be useful in exploring the changes in the RCS that result from variations in specimen size. As such, utilising this methodology further for more species will improve the ability to quantitatively interpret aeroecological observations of weather surveillance radars and special-purpose entomological radars. Full article
(This article belongs to the Section Ecological Remote Sensing)
Show Figures

Figure 1

16 pages, 4276 KiB
Technical Note
Insect-Equivalent Radar Cross-Section Model Based on Field Experimental Results of Body Length and Orientation Extraction
by Rui Wang, Xiao Kou, Kai Cui, Huafeng Mao, Shuaihang Wang, Zhuoran Sun, Weidong Li, Yunlong Li and Cheng Hu
Remote Sens. 2022, 14(3), 508; https://doi.org/10.3390/rs14030508 - 21 Jan 2022
Cited by 6 | Viewed by 2802
Abstract
Migratory insects constitute a valuable component of atmospheric and terrestrial biomass, and their migratory behavior provides abundant information for insect management and ecological effect assessment. Effective monitoring of migratory insects contributes to the evaluation and forecasting of catastrophic migration events, such as pest [...] Read more.
Migratory insects constitute a valuable component of atmospheric and terrestrial biomass, and their migratory behavior provides abundant information for insect management and ecological effect assessment. Effective monitoring of migratory insects contributes to the evaluation and forecasting of catastrophic migration events, such as pest outbreaks. With a large-scale monitoring technique using S-band weather radar, the insect density is estimated based on the linear relationship between radar reflectivity and the average radar cross-section (RCS) of the insects. However, the average RCS model neglects the morphological and observation parameters of the insects, which reduces the estimation accuracy. In this paper, we established an insect-equivalent RCS model based on the joint probability distribution of “body length–incident angle”. Then, we observed and extracted the morphological and observational parameters of the migratory insects by conducting a 69-day field experiment, using a Ku-band fully polarimetric entomological radar, in Dongying, Shandong Province, China. Finally, combined with the experimental results and the simulated scattering characteristics of individual insects with different body lengths, the typical insect-equivalent RCS model was established. The RCS of the model fluctuates between 0.233 mm2 and 0.514 mm2, with different incident angles. Our results lay a data foundation for the quantitative analysis of insects by weather radar. Full article
Show Figures

Graphical abstract

20 pages, 8033 KiB
Article
Design of Insect Target Tracking Algorithm in Clutter Based on the Multidimensional Feature Fusion Strategy
by Linlin Fang, Weiming Tian, Rui Wang, Chao Zhou and Cheng Hu
Remote Sens. 2021, 13(18), 3744; https://doi.org/10.3390/rs13183744 - 18 Sep 2021
Cited by 1 | Viewed by 2217
Abstract
Entomological radar is an effective means of monitoring insect migration, and can realize long-distance and large-scale rapid monitoring. The stable tracking of individual insect targets is the basic premise underlying the identification of insect species and the study of insect migration mechanisms. However, [...] Read more.
Entomological radar is an effective means of monitoring insect migration, and can realize long-distance and large-scale rapid monitoring. The stable tracking of individual insect targets is the basic premise underlying the identification of insect species and the study of insect migration mechanisms. However, the complex motion trajectory and large number of false measurements decrease the performance of insect target tracking. In this paper, an insect target tracking algorithm in clutter was designed based on the multidimensional feature fusion strategy (ITT-MFF). Firstly, multiple feature parameters of measurements were fused to calculate the membership of measurements and target, thereby improving the data association accuracy in the presence of clutter. Secondly, a distance-correction factor was introduced to the probabilistic data association (PDA) algorithm to accomplish multi-target data association with a low computational cost. Finally, simulation scenarios with different target numbers and clutter densities were constructed to verify the effectiveness of the proposed method. The tracking result comparisons of the experimental data acquired from a Ku-band entomological radar also indicate that the proposed method can effectively reduce computational cost while maintaining high tracking precision, and is suitable for engineering implementation. Full article
Show Figures

Graphical abstract

11 pages, 2051 KiB
Communication
Seasonal Trends in Movement Patterns of Birds and Insects Aloft Simultaneously Recorded by Radar
by Xu Shi, Baptiste Schmid, Philippe Tschanz, Gernot Segelbacher and Felix Liechti
Remote Sens. 2021, 13(9), 1839; https://doi.org/10.3390/rs13091839 - 9 May 2021
Cited by 19 | Viewed by 5143
Abstract
Airspace is a key but not well-understood habitat for many animal species. Enormous amounts of insects and birds use the airspace to forage, disperse, and migrate. Despite numerous studies on migration, the year-round flight activities of both birds and insects are still poorly [...] Read more.
Airspace is a key but not well-understood habitat for many animal species. Enormous amounts of insects and birds use the airspace to forage, disperse, and migrate. Despite numerous studies on migration, the year-round flight activities of both birds and insects are still poorly studied. We used a 2 year dataset from a vertical-looking radar in Central Europe and developed an iterative hypothesis-testing algorithm to investigate the general temporal pattern of migratory and local movements. We estimated at least 3 million bird and 20 million insect passages over a 1 km transect annually. Most surprisingly, peak non-directional bird movement intensities during summer were of the same magnitude as seasonal directional movement peaks. Birds showed clear peaks in seasonally directional movements during day and night, coinciding well with the main migration period documented in this region. Directional insect movements occurred throughout the year, paralleling non-directional movements. In spring and summer, insect movements were non-directional; in autumn, their movements concentrated toward the southwest, similar to birds. Notably, the nocturnal movements of insects did not appear until April, while directional movements mainly occurred in autumn. This simple monitoring reveals how little we still know about the movement of biomass through airspace. Full article
(This article belongs to the Section Ecological Remote Sensing)
Show Figures

Graphical abstract

23 pages, 1619 KiB
Review
A Review of Insect Monitoring Approaches with Special Reference to Radar Techniques
by Alexey Noskov, Joerg Bendix and Nicolas Friess
Sensors 2021, 21(4), 1474; https://doi.org/10.3390/s21041474 - 20 Feb 2021
Cited by 44 | Viewed by 17831
Abstract
Drastic declines in insect populations are a vital concern worldwide. Despite widespread insect monitoring, the significant gaps in the literature must be addressed. Future monitoring techniques must be systematic and global. Advanced technologies and computer solutions are needed. We provide here a review [...] Read more.
Drastic declines in insect populations are a vital concern worldwide. Despite widespread insect monitoring, the significant gaps in the literature must be addressed. Future monitoring techniques must be systematic and global. Advanced technologies and computer solutions are needed. We provide here a review of relevant works to show the high potential for solving the aforementioned problems. Major historical and modern methods of insect monitoring are considered. All major radar solutions are carefully reviewed. Insect monitoring with radar is a well established technique, but it is still a fast-growing topic. The paper provides an updated classification of insect radar sets. Three main groups of insect radar solutions are distinguished: scanning, vertical-looking, and harmonic. Pulsed radar sets are utilized for all three groups, while frequency-modulated continuous-wave (FMCW) systems are applied only for vertical-looking and harmonic insect radar solutions. This work proves the high potential of radar entomology based on the growing research interest, along with the emerging novel setups, compact devices, and data processing approaches. The review exposes promising insect monitoring solutions using compact radar instruments. The proposed compact and resource-effective setups can be very beneficial for systematic insect monitoring. Full article
(This article belongs to the Section Remote Sensors)
Show Figures

Figure 1

22 pages, 6742 KiB
Article
Fast Implementation of Insect Multi-Target Detection Based on Multimodal Optimization
by Rui Wang, Yiming Zhang, Weiming Tian, Jiong Cai, Cheng Hu and Tianran Zhang
Remote Sens. 2021, 13(4), 594; https://doi.org/10.3390/rs13040594 - 7 Feb 2021
Cited by 6 | Viewed by 2414
Abstract
Entomological radars are important for scientific research of insect migration and early warning of migratory pests. However, insects are hard to detect because of their tiny size and highly maneuvering trajectory. Generalized Radon–Fourier transform (GRFT) has been proposed for effective weak maneuvering target [...] Read more.
Entomological radars are important for scientific research of insect migration and early warning of migratory pests. However, insects are hard to detect because of their tiny size and highly maneuvering trajectory. Generalized Radon–Fourier transform (GRFT) has been proposed for effective weak maneuvering target detection by long-time coherent detection via jointly motion parameter search, but the heavy computational burden makes it impractical in real signal processing. Particle swarm optimization (PSO) has been used to achieve GRFT detection by fast heuristic parameter search, but it suffers from obvious detection probability loss and is only suitable for single target detection. In this paper, we convert the realization of GRFT into a multimodal optimization problem for insect multi-target detection. A novel niching method without radius parameter is proposed to detect unevenly distributed insect targets. Species reset and boundary constraint strategy are used to improve the detection performance. Simulation analyses of detection performance and computational cost are given to prove the effectiveness of the proposed method. Furthermore, real observation data acquired from a Ku-band entomological radar is used to test this method. The results show that it has better performance on detected target amount and track continuity in insect multi-target detection. Full article
(This article belongs to the Section Engineering Remote Sensing)
Show Figures

Graphical abstract

18 pages, 2044 KiB
Article
Insect Target Classes Discerned from Entomological Radar Data
by Zhenhua Hao, V. Alistair Drake, John R. Taylor and Eric Warrant
Remote Sens. 2020, 12(4), 673; https://doi.org/10.3390/rs12040673 - 18 Feb 2020
Cited by 17 | Viewed by 4014
Abstract
Entomological radars employing the ‘ZLC’ (zenith-pointing linear-polarized narrow-angle conical scan) configuration detect individual insects flying overhead and can retrieve information about a target’s trajectory (its direction and speed), the insect’s body alignment and four parameters that characterize the target itself: its radar cross [...] Read more.
Entomological radars employing the ‘ZLC’ (zenith-pointing linear-polarized narrow-angle conical scan) configuration detect individual insects flying overhead and can retrieve information about a target’s trajectory (its direction and speed), the insect’s body alignment and four parameters that characterize the target itself: its radar cross section, two shape parameters and its wingbeat frequency. Criteria have previously been developed to distinguish Australian Plague Locusts Chortoicetes terminifera, large moths, medium moths and small insects using the target-character parameters. Combinations of target characters that occur frequently, known as target ‘classes’, have also been identified previously both through qualitative analyses and more objectively with a 4D peak-finding algorithm applied to a dataset spanning a single flight season. In this study, fourteen years of radar observations from Bourke, NSW (30.0392°S, 145.952°E, 107 m above MSL) have been used to test this approach and potentially improve its utility. We found that the previous criteria for assigning targets to classes require some modification, that classes identified in the previous studies were frequently present in other years and that two additional classes could be recognized. Additionally, by incorporating air-temperature information from a meteorological model, we have shown that different classes fly in different temperature ranges. By drawing on knowledge concerning migrant species found in the regional areas around the radar site, together with morphological measurements and radar cross-section data for proxy species, we have made tentative identifications of the insect taxa likely to be contributing to each class. Full article
(This article belongs to the Special Issue Radar Aeroecology)
Show Figures

Graphical abstract

19 pages, 2354 KiB
Article
Radar Measurements of Morphological Parameters and Species Identification Analysis of Migratory Insects
by Cheng Hu, Shaoyang Kong, Rui Wang and Fan Zhang
Remote Sens. 2019, 11(17), 1977; https://doi.org/10.3390/rs11171977 - 22 Aug 2019
Cited by 12 | Viewed by 4119
Abstract
Migratory insect identification has been concerning entomology and pest managers for a long time. Their nocturnal behavior, as well as very small radar cross-section (RCS), makes individual detection challenging for any radar network. Typical entomological radars work at the X-band (9.4 GHz) with [...] Read more.
Migratory insect identification has been concerning entomology and pest managers for a long time. Their nocturnal behavior, as well as very small radar cross-section (RCS), makes individual detection challenging for any radar network. Typical entomological radars work at the X-band (9.4 GHz) with a vertical pencil beam. The measured RCS can be used to estimate insect mass and wingbeat frequency, and then migratory insects can be categorized into broad taxon classes using the estimated parameters. However, current entomological radars cannot achieve species identification with any higher precision or confidence. The limited frequency range of current insect radars have precluded the acquisition of more information useful for the identification of individual insects. In this paper, we report an improved measurement method of insect mass and body length using a radar with many more measurement frequencies than current entomological radars. The insect mass and body length can be extracted from the multi-frequency RCSs with uncertainties of 16.31% and 10.74%, respectively. The estimation of the thorax width and aspect ratio can also be achieved with uncertainties of 13.37% and 7.99%, respectively. Furthermore, by analyzing the statistical data of 5532 insects representing 23 species in East China, we found that the correct identification probabilities exceed 0.5 for all of the 23 species and are higher than 0.8 for 15 of the 23 species under the achievable measurement precision of the proposed technique. These findings provide promising improvements of individual parameter measurement for entomological radars and imply a possibility of species identification with higher precision. Full article
(This article belongs to the Special Issue Radar Aeroecology)
Show Figures

Graphical abstract
