Pulse-width modulation (PWM) and pulse-density modulation (PDM) are widely used in applications where electrical energy is delivered in a pulsed manner. Typical examples include LED (light-emitting diode) control, DC motor control, switched-mode power supplies (SMPS), and electric heating control. However, the pulsed operation of power switches is often associated with significant electromagnetic interference (EMI). As an alternative, stochastic pulse-density modulation (SPDM), also referred to as stochastic signal density modulation (SSDM), can be considered. This technique distributes the energy of generated harmonics over a broader frequency spectrum, thereby reducing the amplitude of individual frequency components. As a result, unwanted frequencies become easier to filter out, mitigating EMI more effectively. Full article

The growing demand for high-power battery output in the ever-evolving electric vehicle and energy storage sectors necessitates the development of efficient thermal management systems. High-power lithium-ion batteries (LIBs), known for their outstanding performance, are widely used across various applications. However, effectively managing the thermal conditions of high-power battery packs remains a critical challenge that limits the operational efficiency and hinders broader market acceptance. The high charge and discharge rates in LIBs generate significant heat, and, as a result, inadequate heat dissipation adversely impacts battery performance, lifespan, and safety. This study utilized theoretical analysis, numerical simulations, and experimental methodologies to address these issues. Considering the anisotropic heat transfer characteristics of laminated pouch cells, this study developed a fluid–solid coupling simulation model tailored to the liquid-cooled structure of pouch battery modules, supported by an experimental test setup. A U-shaped “bathtub-type” cooling structure was designed for a 48 V/8 Ah high-power-density battery pack intended for start–stop power supply applications. This design aimed to resolve heat dissipation challenges, optimize the cooling efficiency, and ensure stable operation under varying conditions. During the performance assessments of the cooling structure conducted through simulations and experiments, extreme discharge conditions (320 A) and pulse charging/discharging cycles (80 A) at ambient temperatures of up to 45 °C were simulated. An analysis of the temperature distribution and its temporal evolution led to critical insights. The results showed that, under these severe conditions, the maximum temperature of the battery module remained below 60 °C, with temperature uniformity maintained within a 5 °C range and cell uniformity within 2 °C. Consequently, the battery pack meets the operational requirements for start–stop power supply applications and provides an effective solution for thermal management in high-power-density environments. Full article

Photoacoustic tomography (PAT), also known as optoacoustic tomography, has been emerging as a biomedical imaging modality that can provide cross-sectional or three-dimensional (3D) visualization of biological tissues such as blood vessels and lymphatic vessels in vivo at high resolution. The principle behind the visualization involves the light being absorbed by the tissues which results in the generation of ultrasound. Depending on the strength of ultrasound and its decay rate, it could be used to visualize the absorber location. In general, pulsed lasers such as the Q-switched Nd-YAG and OPO lasers that provide high-energy widths in the range of a few nanoseconds operating at low repetition rates are commonly used as a light source in photoacoustic imaging. However, such lasers are expensive and occupy ample space. Therefore, PAT systems that use LED as the source instead of lasers, which have the advantage of being obtainable at low cost and portable, are gaining attention. However, LED light sources have significantly low energy, and the photoacoustic signals generated have a low signal-to-noise ratio (SNR). Therefore, in LED-based systems, one way to strengthen the signal and improve the SNR is to significantly increase the repetition rate of LED pulses and use signal processing, which can be achieved using a high-power LED along M-sequence signal decoding. M-sequence signal decoding is effective, especially under high repetition rates, thus improving the SNR. However, power supplies for high-power LEDs have a circuit jitter, resulting in random temporal fluctuations in the emitted light. Such jitters, in turn, would affect the M-sequence-based signal decoding. Therefore, we propose a new decoding algorithm which compensates for LED jitter in the M-sequence signal processing. We show that the proposed new signal processing method can significantly improve the SNR of the photoacoustic signals. Full article

The recent trend in analog design to replace typical analog circuits with digital implementations has led to the use of resistive feedback to pull a CMOS inverter into the switching threshold region to achieve gain, which is ideal for analog operations. Here, we report a three-transistor (3T) CMOS resistive-feedback inverter-based amplifier capable of achieving high gain paralleled with reduced noise, low power consumption, and enhanced stability. Unlike conventional resistive-feedback inverter-based amplifiers, the transistors are operated in the subthreshold region, which allows for a lower supply voltage and current, leading to lower power consumption. Subthreshold conduction also reduces typical amplifier noise sources. This design provides a novel approach to resistive feedback in the inverter amplifier, allowing for a large gain while occupying minimal layout area. The reported amplifier design facilitates unique capabilities, e.g., detection of ultra-low (fC) charges or sub-pA currents for newly emerging PHz electronic and optoelectronic devices driven by few-cycle laser pulses. As proof of concept, the specifications of the proposed amplifier are successfully measured and verified by multiple test chips designed and fabricated in TSMC’s 180 nm CMOS process. The fabricated amplifier operates at a 1.35 V power supply with a measured voltage gain of 53.61 dB (or 480 V/V), a bandwidth of 94 kHz, and an equivalent input voltage noise of 6.4 nV/$\sqrt{\mathrm{Hz}}$, consuming only 13.5 µW. Full article

Ambient temperature has a significant effect on the electrical and luminous parameters of light-emitting diodes (LEDs), which include forward and reverse current, forward voltage, and luminous flux. This paper gives insight into the influence of ambient temperature on the electrical and luminous parameters of LEDs powered by a rectangular pulsed voltage source versus those powered by a constant voltage source. The characteristics of LEDs in LED lighting devices were studied to determine their optimal operating conditions. To this end, rectangular pulse voltages with different pulse filling factors D were considered against the DC voltage source. Characteristics were obtained for the current stabilization mode and for the LED voltage stabilization mode. In both modes, the temperature dependence of the luminous flux, current, voltage, power consumption, and luminous efficiency of the LEDs was studied in the 20 °C to 60 °C range. The optimal LED operating conditions were determined, of which their luminous flux and luminous efficiency are least dependent on ambient temperature. When powered by a rectangular pulse voltage, the LED device drivers’ optimal pulse filling factor and operating frequency were determined. Full article

This article deals with problems related to electromagnetic compatibility, which is a very important issue due to the fact of ensuring the proper coexistence of devices and systems in a given electromagnetic environment. The devices manufactured today can, on the one hand, be a source of electromagnetic disturbance emissions and, on the other hand, be susceptible to disturbance signals from the environment. A large group of receivers in which electronic specialised circuits are used are LED lamps. The operation of an RGB LED lamp due to higher harmonic current emissions has been analysed in this paper. Lamp tests were carried out in several stages. In each of them, the values of the generated higher harmonics were analysed and related to the parameters of the current flowing through the lamp. It was shown how the parameters of the current pulse affect the generated harmonics when the value of the luminous flux was changed, its colour was changed, or the built-in function was turned on. It is also shown how, for example, changing the value of an electronic component in the lamp’s power supply changes the parameters of the current and thus the value of the generated higher harmonics. Full article

The fabrication of Sb₂Se₃ thin-film solar cells deposited by a pulsed hybrid reactive magnetron sputtering (PHRMS) was proposed and examined for different growth conditions. The influence of growth temperature and Se pulse period were studied in terms of morphology, crystal structure, and composition. The Sb₂Se₃ growth showed to be dependent on the growth temperature, with a larger crystal size for growth at 270 °C. By controlling the Se pulse period, the crystal structure and crystal size could be modified as a function of the supplied Se amount. The solar cell performance for Sb₂Se₃ absorbers deposited at various temperatures, Se pulse periods and thicknesses were assessed through current-voltage characteristics. A power conversion efficiency (PCE) of 3.7% was achieved for a Sb₂Se₃ solar cell with 900 nm thickness, Sb₂Se₃ deposited at 270 °C and Se pulses with 0.1 s duration and period of 0.5 s. Finally, annealing the complete solar cell at 100 °C led to a further improvement of the V_oc, leading to a PCE of 3.8%, slightly higher than the best reported Sb₂Se₃ solar cell prepared by sputtering without post-selenization. Full article

This article presents the method of implementation and the results of experimental investigations illustrating an influence of parameters of the signal controlling the current flowing through power LEDs on their junction temperature and on parameters characterizing the light emitted by them. The measurement system used and the tested power LEDs are described. The results of measurements of the junction temperature of the tested devices, the values of the average value of the power dissipated in the tested devices and the photometric and radiometric parameters of these devices obtained for different values of frequency and the duty cycle of the signal controlling the current flowing through the tested diodes are presented and discussed. It is shown that the operation of the considered semiconductor devices is more effective at low frequency values. The possibility of adjusting the optical parameters of the power LEDs in the considered range of frequency and the duty cycle adjustment is assessed. Additionally, the measured waveforms of the current supplying the tested LEDs is shown. The influence of the parasitic capacitances of the tested devices is discussed. On the basis of the obtained investigation results, some recommendations for the designers of lighting systems can be formulated. In order to obtain an almost linear dependence of the illuminance on the duty cycle, the values of frequency not exceeding 10 kHz should be used. Full article

This study developed and implemented a driving power supply for light-emitting diode (LED) array streetlamps. The power stage was a quasi-resonant (QR)-flyback converter, its input power was the alternating-current power, and the LED array streetlamp was driven by the direct-current output power. The developed QR-flyback converter was operated in discontinuous conduction mode, and the pulse-width modulation (PWM) control chip was used to switch and conduct at the resonant valley of the drain-source voltage on the metal-oxide-semiconductor field-effect transistor (MOSFET) switch to reduce the switching loss. Moreover, the PWM control chip had a disable function, which was connected with a bright and extinguishable control circuit, and the high/low voltage level signal output by the Arduino development board can be used to control the output power of the QR-flyback converter, achieving bright and extinguishable controls for the LED array streetlamp. Full article

Nowadays, lifestyle change is one of the problems of the new world economic order, and the procedures of feeding, purchasing, preparation, and the storage of food products, are forcing authorities to establish more rigorous methods concerning the control of food quality and safety. Owing quality in the agro-food sector is a complex and global issue, due to the distance between production and final consumption, as well as the new demands of society on food. Contributing to the bacteria minimization during their path in the supply chain, the objective of this research is the use of an UV-C LED artificial lighting system with emission in continuous light (CL) and two of pulsed light (Mode 1 and Mode 2) for fresh products’ disinfection. A mathematical model is introduced as a reference to establish the equivalence dose of continuous and pulsed UV-C LED irradiation. The doses applied were 5, 15, and 25 mJ cm⁻². The configured parameters per each technique were the irradiance, time also the frequency (500 Hz), and duty cycle (30, 50, and 80%) for Mode 1 and Mode 2. The germicidal effect (GE), energy consumption, and effective germicidal effect (EGE), were evaluated for the different techniques. According to the results, the technique Mode 1 was the best in the GE with 1.06 ± 0.01 and 1.08 ± 0.01 Log reduction by 25 mJ cm⁻² at 30 and 80% duty cycle, correspondingly. The CL and Mode 1 showed an outstanding performance with the EGE. Finally, Mode 1 reduced 11% in energy and the GE is comparable with CL. The pulsed light technique Mode 1 constitutes a powerful method against the microorganism’s destruction and a strategy for saving energy during the treatment. The UV-C LEDs proved to be an excellent alternative in the disinfection of fresh products with pulsed light emission in the real process. Full article

This paper presents a low-noise analog front end (AFE) with interstage systematically ambient interference cancellation for a pulse oximeter, which is suitable for clinical oxygen saturation (${\mathrm{S}}_{\mathrm{P}}{\mathrm{O}}_2$) detection with a low perfusion index. The fully differential implementation is adopted to have a better rejection performance of common mode interference and noise. Firstly, the proposed interstage systematically ambient interference cancellation is placed in the two gain stages to decrease low frequency noise in the bandwidth of interest (0.1–20 Hz), so that the larger signal-to-noise ratio (SNR) can be achieved to increase the detection accuracy of this system. Secondly, due to the additional gain stage compared with traditional implementation, the current-reuse OTA is employed to have better noise and power efficiency. Thirdly, the auto zero technique is utilized in the LED Driver to decrease the offset voltage and acquire a larger dynamic range (DR) in the low frequency bandwidth of interest. This PPG AFE chip is designed and fabricated in a 180 nm standard CMOS process. The receiver (RX) of this AFE consumes 220 $\mathsf{\mu }\mathrm{W}$ from a 1.8 V supply, and the power consumption of the transmitter (TX) is 60 $\mathsf{\mu }\mathrm{W}$ from a 3 V supply. The measurement results show that the input-referred noise current of 2.3 pA/sqrt(Hz) is achieved in RX and 110 dB peak DR is obtained in TX. Full article

We report a methodological approach for simulating luminary output radiation, which is achieved by mixing light-emitting diodes (LEDs) in order to match any plant absorption spectrum. Various recorded narrow-band LED spectra of different colors were first characterized and then fitted with a multi-Gaussian model. An optimizing procedure computed the optimal weighting of the relevant parameters so as to minimize the discrepancy between the combined spectrum and the reference target curve. The particle swarm optimization (PSO) method was applied because it is the most suitable technique for mono-objective situations. Within the useful spectral interval, the worst relative standard deviation between the optimized curve and recorded LED spectral power distribution (SPD) was 3.4%. When combining different LED types, the simulated light output showed that we could limit ourselves to selecting only five colored sources. This work will help us to design an optimized 200 W laboratory luminaire with a pulse-width switched-mode power supply. Full article

Inorganic perovskites have emerged as a promising candidate for light-emitting devices due to their high stability and tunable band gap. However, the power consumption and brightness have always been an issue for perovskite light-emitting diodes (PeLEDs). Here, we improved the luminescence intensity and decreased the current density of the PeLEDs based on CsPbI₃ quantum dots (QDs) and p-type Si substrate through an alternating current (AC) driving mode. For the different driving voltage modes (under a sine pulsed bias or square pulsed bias), a frequency-dependent electroluminescent (EL) behavior was observed. The devices under a square pulsed bias present a stronger EL intensity under the same voltage due to less thermal degradation at the interface. The red PeLEDs under a square pulsed bias driving demonstrate that the EL intensity drop-off phenomenon was further improved, and the integrated EL intensity shows the almost linear increase with the increasing driving voltage above 8.5 V. Additionally, compared to the direct current (DC) driving mode, the red PeLEDs under the AC condition exhibit higher operating stability, which is mainly due to the reducing accumulated charges in the devices. Our work provides an effective approach for obtaining strong brightness, low power consumption, and high stability light-emitting devices, which will exert a profound influence on coupling LEDs with household power supplies directly. Full article

Recently, low-frequency oscillation (LFO) has occurred many times in high-speed railways and has led to traction blockades. Some of the literature has found that the stability of the vehicle-grid coupling system could be improved by optimizing the control strategy of the traction line-side converter (LSC) to some extent. In this paper, a model-based predictive current control (MBPCC) approach based on continuous control set in the dq reference frame for the traction LSC for electric multiple units (EMUs) is proposed. First, the mathematical predictive model of one traction LSC is deduced by discretizing the state equation on the alternating current (AC) side. Then, the optimal control variables are calculated by solving the performance function, which involves the difference between the predicted and reference value of the current, as well as the variations of the control voltage. Finally, combined with bipolar sinusoidal pulse width modulation (SPWM), the whole control algorithm based on MBPCC is formed. The simulation models of EMUs’ dual traction LSCs are built in MATLAB/SIMULINK to verify the superior dynamic and static performance, by comparing them with traditional transient direct current control (TDCC). A whole dSPACE semi-physical platform is established to demonstrate the feasibility and effectiveness of MBPCC in real applications. In addition, the simulations of multi-EMUs accessed in the vehicle-grid coupling system are carried out to verify the suppressing effect on LFO. Finally, to find the impact of external parameters (the equivalent leakage inductance of vehicle transformer, the distance to the power supply, and load resistance) on MBPCC’s performance, the sensitivity analysis of these parameters is performed. Results indicate that these three parameters have a tiny impact on the proposed method but a significant influence on the performance of TDCC. Both oscillation pattern and oscillation peak under TDCC can be easily influenced when these parameters change. Full article

Traditional light-emitting diode (LED) drivers with pulse-width modulation (PWM)-type converters suffer the problem of hard switching, leading to low circuit efficiency and low reliability. LED drivers supplied by alternating current (AC) line source generally require using an additional power-factor correction (PFC) stage to satisfy the regulations on power factor (PF) and total current harmonic distortion (THDi). It results in more circuit losses, especially when the active switch of the PFC stage operates at hard switching. This paper presents an alternating current-to-direct current (AC/DC) converter for driving high-brightness LEDs with the features of soft switching and high PF. The proposed single-stage circuit is formed by integrating a buck–boost converter and a buck converter. By elaborately rearranging the wirings between the circuit components of both converters, the power MOSFETs can be switched on at zero voltage. The operating modes at steady-state are analyzed and the mathematical equations for deriving circuit parameters are conducted. Finally, a prototype circuit for driving 60-W LEDs was built and measured. Based on the experimental results, the feasibility and satisfactory performance of the proposed LED driver are proved. Full article
