The dimensional accuracy of the intaglio surface of complete dentures fabricated using liquid crystal display (LCD) three-dimensional (3D) printing might be influenced by the build angle and post-processing storage conditions. This study evaluated the effect of build angle and natural light exposure duration on the intaglio surface trueness of maxillary complete denture bases. Standardized denture base designs (2 mm uniform thickness) were fabricated using an LCD 3D printer (Lilivis Print; Huvitz, Seoul, Republic of Korea) at build angles of 0°, 45°, and 90° (n = 7 per group). All specimens were printed using the same photopolymer resin (Tera Harz Denture; Graphy, Seoul, Republic of Korea) and identical printing parameters, followed by ultrasonic cleaning and ultraviolet post-curing. Specimens were stored under controlled light-emitting diode lighting and exposed to natural light (400–800 lux) for 0, 14, or 30 days. The intaglio surfaces were scanned and superimposed on the original design data, following the International Organization for Standardization 12836. Quantitative assessment included root mean square deviation, mean deviation, and tolerance percentage. Statistical analyses were performed using one-way analysis of variance and paired t-tests (α = 0.05). Build angle and light exposure duration significantly affected surface trueness (p < 0.05). The 90° build angle group exhibited the highest accuracy and dimensional stability, while the 0° group showed the greatest deviations (p < 0.05). These findings underscore the importance of optimizing build orientation and storage conditions in denture 3D printing. Full article

We developed biomimetic full-thickness artificial skin using stromal vascular fraction (SVF) cells and autologous keratinocytes for the dermal and epidermal layers of skin, respectively. Full-thickness artificial skin scaffolds were fabricated using 4% porcine collagen and/or elastin in a low-temperature three-dimensional printer. Two types of scaffolds with collagen-to-elastin ratios of 100:0 and 100:4 were printed and compared. The scaffolds were analyzed for collagenase degradation, tensile strength, and structural features using scanning electron microscopy. By 24 h, the collagen-only scaffolds showed gradual degradation, and the collagen-elastin scaffolds retained the highest structural integrity but were not degraded. In the tensile strength tests, the collagen-only scaffolds exhibited a tensile strength of 2.2 N, while the collagen-elastin scaffolds showed a tensile strength of 4.2 N. Cell viability tests for keratinocytes displayed an initial viability of 89.32 ± 3.01% on day 1, which gradually increased to 97.22 ± 4.99% by day 7. Similarly, SVF cells exhibited a viability of 93.68 ± 1.82% on day 1, which slightly improved to 97.12 ± 1.64% on day 7. This study presents a novel strategy for full-thickness artificial skin development, combining SVF and keratinocytes with an optimized single collagen scaffold and a gradient pore-density structure. Full article

This study evaluated the effects of print orientation and thermal aging on the flexural strength (FS) and flexural modulus (FM) of novel permanent three-dimensional (3D)-printed polymethyl methacrylate (PMMA) resins reinforced with nano-zirconia and nano-silica. Bar-shaped specimens (25 × 2 × 2 mm) were fabricated using a digital light processing (DLP) 3D printer (Asiga Max UV, Asiga Inc., Australia) in two orientations (0° and 90°). Specimens underwent three-point bending tests at 24 h and after artificial thermal aging (10,000 and 30,000 cycles) to simulate one and three years of intraoral conditions. Scanning electron microscopy (SEM) was used to analyze fracture patterns. Print orientation did not significantly affect FS or FM (p > 0.05). However, artificial aging significantly reduced FS and FM after 10,000 cycles (p < 0.001), with further deterioration after 30,000 cycles. The micro hybrid resin composite exhibited higher FS than the 3D-printed materials throughout aging. SEM analysis revealed distinct fracture patterns, with 3D-printed resins displaying radial fractures and the micro hybrid composite exhibiting horizontal fractures. These findings indicate that aging plays a more critical role in the long-term mechanical performance of 3D-printed restorative resins than print orientation. This study provides original data on the effects of print orientation and prolonged thermal aging on the mechanical behavior of permanent three-dimensional (3D)-printed dental resins. Furthermore, the comparative evaluation of aging protocols simulating one and three years of intraoral service represents a novel contribution to the existing literature. Further studies are required to optimize the mechanical durability of 3D-printed dental restorations. Full article

This study evaluates the manufacturing accuracy of Merlon fracture models produced using two vat-photopolymerization-based three-dimensional (3D) printers: digital light processing (DLP) and liquid-crystal display (LCD). The Merlon fracture model is used to assess dimensional precision and machining accuracy. The root mean square (RMS) values, wall and bottom thicknesses, and field-emission scanning electron microscopy images are analyzed. The DLP-based printers exhibit lower RMS values and superior accuracy compared with LCD-based printing and subtractive milling. Polymer-based slurries for permanent dental applications exhibit better dimensional stability than those for temporary restorations. This study also highlights the significant impact of postprocessing and cleaning procedures on the final model accuracy. These findings suggest that optimizing the postprocessing parameters is crucial for enhancing the precision of 3D-printed dental restorations. The Merlon fracture model is a viable method for evaluating additive manufacturing accuracy, contributing to the improved clinical application of vat photopolymerization in dental prosthetics. Full article

Following the rising popularity of Unmanned Aerial Vehicles (UAVs) among large-scale users, in the form of domestic as well as professional drones, with applications in domains such as safety (e.g., surveillance drones), terrain mapping (using geo-scanning UAVs), videography drones, and high performance drones used in FPV (First Person View) drone competitions—as well as the rising wide accessibility of Fused Filament Fabrication (FFF)—especially considering the recent apparition and popularization of 3D printers capable of displaying exponential increases in performance metrics, the present work takes into consideration the practice of fabricating UAV propellers by means of FFF, focusing on the theoretical, as well as on the practical aspects of the roughness and quality observed at the level of the resulting surfaces. The paper proposes a set of propeller configurations obtained by combining popular propeller geometries, such as the Gemfan 51466-3 three-bladed propeller and the novel Toroidal propeller model, with a range of different fabrication materials, such as the Polyethylene Terephthalate Glycol (PETG) filament and the Polylactic Acid (PLA) filament. The main aim of the study is to reveal observations on the influence that the surface quality has on the performance metrics of a propeller. Based on the practical work, which aims to develop a comparative study between two drone propeller geometries manufactured by a nonconventional process, 3D printing, the practical applications in the study were carried out using low-cost equipment in order to evaluate the results obtained in a domestic setting. The study involves the identification of the noise values produced by the two geometries due to the roughness of the propeller surfaces. Full article

Herein, a recently developed UAV/Drone approach as a new vector for the collection of airborne particulate matter is reported. In this study, airborne particle emissions from plumes generated in a holiday fireworks display were collected. A platform fabricated using a 3D printer was mounted on the drone, which allowed for particulate capture using double-sided carbon tape attached to aluminum disks. The drone platform was used to trap airborne samples from two types of plumes: high-altitude sampling (HAS), which relates to professional fireworks, and low-altitude sampling (LAS), associated with personal fireworks. Collected samples were studied using a Scanning Electron Microscope alongside Electron Dispersal X-ray Spectroscopy (EDX) for elemental composition analysis. The overall findings regarding the physical morphology reveal several key observations. Firstly, particles from professional fireworks are significantly larger and more spheroidal than those from personal fireworks. Secondly, both types of fireworks show a consistent trend in which some of the larger particles have finer particulates deposited on their surfaces. Lastly, the plumes produced by both types contain spheres that are either solid, hollow or exhibit a core–shell structure. EDX analysis revealed the presence of various types of metals within the samples. EDX analysis shows that the samples collected from the HAS and LAS contain particulates with common elements. However, the samples from the plume of professional fireworks appear to have Ba, Mg, and Fe compared to the samples from personal fireworks. These elements are known to be used in powerful fireworks to create colored displays. A proposed mechanism for particulate growth in fireworks is proposed and discussed. Full article

Cell culture in two dimensions has been the main instrument in cellular and molecular biology. But there are limitations to two-dimensional culture when it comes to tissue engineering and in vivo reproduction. Tissue engineering technology enabled the creation of biomedical scaffolds, which are mostly utilized to biofabricate different artificial human organs. Tissue architecture that encourage cell proliferation can be produced using direct bioprinting technology. The development of bioinks for 3D bioprinting is consistently seen as a problem in the domains of biofabrication and tissue engineering. This study aimed to determine if Fibroblasts and Keratinocytes could grow on hydrogel scaffolds as efficiently as they can in the culture plates. Melanocytes were co-cultured, and the production of melanin was assessed in a two- and three-dimensional culture system. Scaffolds were fabricated using 8% alginate and 6% gelatin and 3D-printed using a cell link printer. FTIR was used to determine the precise composition of the gels. SEM analysis was performed for the cells present in gel and the topology of the cells. In addition, 8% alginate and 6% alginate gel scaffolds were analyzed for swelling and degradation over time in the cell growth medium and PBS. Furthermore, a gene expression study of cell cultures on scaffolds was performed through qPCR. A live/dead assay was performed to determine cell viability for cells grown on scaffolds for 7, 14, and 21 days. Most of the cells were shown to be viable, similar to the control cells grown on a plate. The findings from the SEM showed that cells were grown on the gel surface, remained viable even after 21 days, and displayed circular cells stacked three-dimensionally on the gel surface in the 3D scaffold. The MTT assay was performed to check the viability of cells cultured on a 3D-printed scaffold for 1, 5, and 15 days. We observed about 40% viable cells after 15 days, as shown by the MTT assay. Furthermore, a co-culture study with Melanocyte showed an increased production of melanin in a 3D culture as compared to a 2D culture. Our findings suggest that an alginate and gelatin polymer can be used as a cellular matrix for epithelial cell culture. Further, in vivo and ex vivo experiments are needed to validate the results for future applications in tissue engineering for wound healing and other tissue engineering domains. Full article

Purpose: Dry eye disease is highly prevalent, and the most common treatment, lubricating eye drops, only remains effective for a very short period of time. This project aims to 3D print a proof-of-concept, custom-fit, polyvinyl alcohol (PVA)-eluting contact lens (CL) for the treatment of dry eye disease. PVA is a commonly used viscosity enhancer in eye drops, with the capability of reducing symptoms of dry eye by stabilizing the tear film and reducing tear evaporation. The protective effects of PVA could be attributed to its water-retaining ability, which provides moisturization and prevents the loss of water. Method: In this work, a low-cost stereolithography-based 3D printer was retrofitted with a humidity and temperature control kit to 3D print a PVA-loaded custom-fit CL. To evaluate the print quality of the 3D-printed CL, circularity was used to evaluate the shape fidelity in 3D printing. The PVA release from these lenses was assessed, along with its role in acting as a viscosity enhancer. The effect of PVA was further analyzed by a dry eye disease (desiccation stress) cell model. Results: The shape fidelity evaluation of the 3D-printed CL displayed excellent circularity. The diameter, sagittal depth, and base curve of the 3D-printed lenses were measured to be 14.27 ± 0.06 mm, 3.77 ± 0.16 mm, and 6.4 ± 0.24 mm, respectively. The PVA release curves showed that approximately 1300 µg of PVA was released over the study duration of 24 h. Conclusions: Overall, this work demonstrates that a 3D-printed PVA-eluting CL is a promising candidate for the treatment of dry eye. Full article

Background: Implant surgical guides manufactured in-house using 3D printing technology are widely used in clinical practice to translate virtual planning to the operative field. Aim: The present in vitro study investigated the dimensional changes of 3D surgical guides printed in-house using Shining 3D surgical guide resin (SG01). Materials and methods: Five test bodies, varying in shape and dimensions, were designed using computer-aided design (CAD) software and manufactured using three different Light Crystal Display (LCD) 3D printers (AccuFab-L4D, Elegoo Mars Pro 3, and Zortrax Inspire). Specific printing and post-processing parameters for the SG01 resin were set to produce 25 test bodies (5 of each shape) from each of the three printers, resulting in a total of 75 samples. The dimensional changes were evaluated using a digital calliper at four different time points: immediately after printing (T0), one month after storage (T1), immediately after sterilization (T2), and one month after sterilization (T3). Results: All the test bodies showed deviations from the overall CAD reference value of 12.25 mm after printing and post-processing (T0) and following steam sterilization (T2). Similar trends were observed for the effect of storage times at T1 and T3. The AccuFab prints demonstrated a better dimensional stability than the Elegoo and Zortrax samples. Conclusions: The LCD 3D printers, sterilization, and storage times influenced the dimensional stability of the test bodies made with SGO1 resin. Full article

Based on additive manufacturing via photopolymerization, this study combines polymer-dispersed liquid crystal (PDLC) technology with 3D printing technology to produce tunable micro-optical components with switchable diffraction or focusing characteristics. The diffraction grating and Fresnel zone plate are the research targets. Their structures are designed and simulated to achieve expected optical functions. A liquid crystal display (LCD) 3D printer is used to produce structures on transparent conductive substrates. The printed structures are filled with PDLCs and covered with transparent conductive substrates to achieve tunable functions. The proposed configurations are implemented and verified. The experimental results show that the diffraction efficiency of the 0th order increases from 15% to 50% for the diffraction grating and the focusing spot intensity decreases from 74% to 12% after the application of an electric field. These results demonstrate the feasibility of the proposed tunable optical component configurations. Full article

Background/Objectives: Mandibular gingival squamous cell carcinoma (SCC) is the second most common oral cancer after tongue cancer. As these carcinomas often invade the mandible early, accurately defining the resection extent is important. This report highlights the use of preoperative virtual surgery data, computer-aided design and manufacturing (CAD/CAM) technology, surgical guidance, and extended reality (XR) support in achieving highly accurate marginal mandibulectomy without recurrence or metastasis. Methods: CT imaging data obtained a month before surgery were imported into Materialize Mimics and Materialize Magics (Materialize, Leuven, Belgium, Ver22.0) CAD/CAM software and used to design an osteotomy guide. An STL file was generated, and the guide was fabricated using a 3D printer (Objet 260 Connex; Stratasys Ltd., Eden Prairie, MN, USA) prior to the operation. An XR application, installed on a HoloLens (Microsoft, WA, USA) head-mounted display, projected a hologram onto the surgical field. Results: The rapid intraoperative diagnostic tests were negative, and histopathology confirmed SCC without vascular or perineural invasion. No complications, including occlusal or feeding problems and sensory abnormalities, were observed. Postoperative imaging 3 years later showed no recurrence. Conclusions: Combining CAD/CAM and XR techniques for mandibulectomy may improve surgical accuracy and safety in oral and maxillofacial surgeries, whereas in-house 3D printing aids in managing tumor progression. Full article

Background: Grapefruit seed skin particles (GSSPs) have antifungal properties due to the presence of flavonoids. Therefore, it has the potential to display antifungal characteristics when added to acrylic resin, but it could affect the mechanical properties of the resin. This study investigated the effects of adding GSSPs on the mechanical characteristics of 3D-printed denture base resins. Purpose: The aim of the present study was to determine the effects of the addition of GSSPs to 3D-printed acrylic at different concentrations on the degree of conversion (DC), surface hardness, flexural strength, and tensile strength. Methods: In this study, 90 samples were printed with acrylic resin via a Digital Light Processing (DLP) printer. Thirty square samples were used for the surface hardness test. Thirty rectangular samples were used for the flexural strength test, and thirty dumbbell-shaped samples were used for the tensile strength test. These materials were prepared by adding different concentrations of GSSPs (0.0 wt.%, 5.0 wt.%, and 7.0 wt.%), which were determined by a pilot study to be the most effective in 3D denture base resins. The Durometer Shore Hardness Scale (DSHS) was used to measure the surface hardness, and a universal testing machine was employed to gauge the flexural strength and tensile strength. Field emission scanning electron microscopy (FE-SEM) was employed for particle size analysis and fracture behavior determination. Results: Compared with those of the control group, the degree of conversion (DC), surface hardness, flexural strength, and tensile strength of the treated groups significantly improved after the addition of 5.0 wt.% and 7.0 wt.% GSSPs. The FE‒SEM images revealed a decrease in porosity as the concentration of GSSPs increased with a brittle fracture behavior. Conclusions: The addition of GSSPs to 3D-printed acrylic is recommended because of their significant positive impacts on the mechanical properties of 3D-printed denture base resin. Full article

Triply periodic minimal surface lattice structures are three-dimensional arrays of complex cells that can only be efficiently manufactured by 3D printing. The mechanical properties of these lattice structures depend on lattice parameters such as cell sizes along the X, Y, and Z axes, and wall thickness. Designing such lattice structures for soft polymers permits the manufacturing of polymer foams with controllable mechanical stiffnesses. The objective of this work is to design and 3D print polymeric foams made of lattice structures and evaluate the effect of lattice parameters on the resulting stiffness. Lattice parameters define the lattice geometry and stiffness. Ten specimens with different lattice parameters were designed and 3D printed using a low-cost desktop liquid crystal display 3D printer using ultra-violet-curable resin. Then, following ASTM D3574-17, these samples were subjected to compression tests. An experimental analysis was conducted to examine the deformation characteristics of these structures, focusing on parameters such as yield strain, initial stiffness, and the maximum force at 50% compression. Full article

Additive manufacturing (AM) has emerged as one of the core components of Industry 4.0, which allows extreme customization of products and offers the full potential of design freedom. Recently, AM has been utilized to manufacture patient-specific, customized assistive devices in the field of rehabilitation. This work presents the design and development process of customized wrist-hand orthosis (WHO) elaborately using AM technology. The main focus of this research was to perform an experimental evaluation of the WHO devices for fitting and customer satisfaction. In this case, the primary anatomic measurement of the wrist was obtained using an infrared-based 3D scanner. Then a 3D model of the orthotic device was prepared in nTop using different lattice parameters. Finally, these devices were additively manufactured in liquid crystal display (LCD) 3D resin printers for superior surface quality. To maximize user comfort and mechanical robustness at the same time, mechanical tests were simulated to assess the WHO’s mechanical characteristics and confirm its operation during typical hand activities. Full article

In contemporary dentistry, several 3D printing techniques, including a stereolithography apparatus (SLA), digital light processing (DLP), liquid crystal display (LCD), and PolyJet 3D inkjet printing technology (PolyJet), are employed for model production. Despite their widespread use, there remains a paucity of the literature regarding the trueness and precision of these devices in dental applications. Existing studies comparing the accuracy of dental models manufactured by different printing technologies yield disparate conclusions regarding dental prosthesis manufacturing. This study aimed to test two null hypotheses: first, that the trueness of various new-generation 3D printers is equivalent, and second, that the trueness of printing by these printers is sufficient for achieving high-precision mastercasts in dental prosthodontics manufacturing. The research focuses on evaluating the trueness of five contemporary dental 3D printers: Anycubic Mono X 6Ks (Hongkong Anycubic Technology Co., Hongkong, China), Asiga Max (Asiga, Sydney, Australia), Creo C5 (Planmeca Oy, Helsinki, Finland), Form 3B (Formlabs, Boston, MA, USA), and J5 Dentajet (Stratasys Ltd., Eden Prairie, MN, USA). The methodology employed involved the creation of a digital test object using Blender software, adhering meticulously to the dimensions outlined in ISO standard 20896-1. These dimensions were chosen to be both relevant for this study and representative of clinical scenarios. Subsequently, the test object was printed and precise measurements were conducted utilizing a metrology-type Nikon XTH225 ST Reflection target in conjunction with VGStudio MAX analysis software. The results of our investigation revealed clinically negligible deviations in ball dimensions across all printers, with the maximum observed deviations ranging between 1.17% and 2.03% (notably observed in the Creo C5 printer). Transversal distortion exhibited variance based on the linear accuracy of each printer, with Stratasys21 and Formlabs 3B demonstrating superior accuracy among the evaluated printers. Distortions in the analyzed dimensions (specifically, anterior b–c, posterior a–d, and oblique a–c) were found to be uniform. In conclusion, while the first null hypothesis was rejected, indicating variations in trueness among the 3D printers assessed, our findings affirm the suitability of all five analyzed 3D printers for clinical applications. Consequently, these printers can be utilized for the fabrication of high-precision mastercasts in dental prosthodontics manufacturing. Full article
