Search Results (16)

The viscoelastic branched-preformed particle gel (B-PPG) has been successfully applied to enhance oil recovery in mature reservoirs. However, due to a lack of a clear understanding of the transport characteristics of B-PPG in porous media, the injectivity and plugging efficiency are not ideal, and the incremental oil recovery is not as expected, which poses a great obstacle to the large-scale popularization and application of B-PPG in mature oilfields. Thus, the influences of elastic moduli, matching coefficients, and injection rates on transport characteristics of B-PPG in porous media were investigated by conducting core flow experiments. The results indicate that the elastic modulus of B-PPG can significantly affect the injectivity and plugging efficiency. The higher the elastic modulus is, the more difficult it is to transport in the porous medium. When the particle size is similar, as the elastic modulus increases, the resistance factor (F_r) and residual resistance factor (F_rr) increase. When the elastic modulus is similar, as the particle size increases, the F_r and F_rr increase. As the matching coefficient decreases, the F_r and F_rr decrease, reflecting the improvement of injectivity and the weakening of plugging efficiency. The higher the reservoir permeability, the lower the matching coefficient. When the reservoir permeability ranges from 0.30 to 5.30 μm², the B-PPG with an elastic modulus of 42.2 Pa and a D₅₀ of 525 μm can migrate smoothly into the depth of porous media and form effective plugging. As the injection rate increases, the F_r and F_rr decrease, reflecting the improvement of injectivity and the weakening of plugging efficiency. Therefore, to achieve good injectivity and plugging efficiency of the B-PPG suspension, the injection rate should be in the range of 0.5 mL·min⁻¹ to 1.5 mL·min⁻¹. Hence, these findings could give an important understanding of the factors affecting the transport characteristics of B-PPG and provide guidance for enhancing oil recovery by B-PPG flooding in mature oilfields. Full article

In view of the limited applicability of traditional chemical flooding and binary composite flooding for heavy-oil reservoirs, branched-preformed particle gel (B-PPG) with excellent plugging performance was added to construct the B-PPG/SP (B-PPG/surfactant/polymer) composite system. Through sand pack flooding experiments, it has been proven that the synergistic effect between B-PPG and polymer can expand the swept area and increase the contact between the viscosity reducer and heavy oil, enabling the viscosity reducer to better exert emulsification and viscosity reduction effects. The synergistic effect between B-PPG, polymer and viscosity reducer can further expand the swept area and oil displacement efficiency, ultimately enhancing the heavy-oil recovery by 37.8%. Microscopic visualization flooding experiments proved that cluster remaining oil accounts for the largest proportion in the microscopic remaining oil in heavy oil. By adding B-PPG and polymers, cluster remaining oil can be effectively displaced, thereby significantly enhancing the heavy-oil recovery. And adding viscosity reducer to the composite system can effectively enhance the dispersed residual oil recovery within the swept area. The sand pack flooding experiments with different heavy-oil viscosity proved that the optimal oil viscosity of the B-PPG/SP composite system can reach 657.2 mPa·s, with an incremental oil recovery rate increase of 30.2%. Full article

Excessive reservoir water poses significant challenges in the oil and gas industry by diminishing hydrocarbon recovery efficiency and generating environmental and economic complications. Conventional polymer flooding techniques, although beneficial, often prove inadequate under conditions of elevated temperature and salinity, highlighting the need for more resilient materials. In this research, two types of acrylamide-based preformed particle gels (PPGs) were synthesized, as follows: polyelectrolyte and polyampholyte. These PPGs were engineered to improve plugging efficiency and endure extreme reservoir environments. The polyelectrolyte gels were synthesized using acrylamide (AAm) and sodium acrylate (SA), while the polyampholyte gels incorporated AAm, AMPS, and APTAC, with crosslinking achieved through MBAA. The swelling properties, modulated by temperature, salinity, and pH, were evaluated using the Ritger–Peppas and Yavari–Azizian models. The mechanical characteristics and surface morphology of the gels were analyzed using SEM and BET techniques. In sand pack experiments designed to mimic high-permeability reservoirs, the inclusion of 0.5 wt.% of fine PPGs substantially reduced water permeability, outperforming traditional hydrogels. Notably, the polyampholyte PPGs demonstrated superior resilience and efficacy in plugging. However, the experiments were limited by the low test temperature (25 °C) and brine salinity (26.6 g/L). Future investigations will aim to apply these PPGs in high-temperature, fractured carbonate reservoirs. Full article

Heterogeneous phase combined flooding (HPCF) has been a promising technology used for enhancing oil recovery in heterogeneous mature reservoirs. However, the injectivity and propagation behavior of preformed particle gel (PPG) in low–medium-permeability reservoir porous media is crucial for HPCF treatment in a low–medium-permeability reservoir. Thus, the injectivity and propagation behavior of preformed particle gel in a low–medium-permeability reservoir were systematically studied by conducting a series of sand pack flooding experiments. The matching factor (δ) was defined as the ratio of the average size of PPG particles to the mean size of pore throats and the pressure difference ratio (β) was proposed to characterize the injectivity and propagation ability of PPG. The results show that with the increase in particle size and the decrease in permeability, the resistance factor and residual resistance factor increase. With the increase in the matching factor, the resistance factor and residual resistance factor increase. The higher the resistance factor and residual resistance factor are, the worse the injectivity of particles is. By fitting the relationship curve, PPG injection and propagation standards were established: when the matching coefficient is less than 55 and β is less than 3.4, PPG can be injected; when the matching coefficient is 55–72 and β is 3.4–6.5, PPG injection is difficult; when the matching coefficient is greater than 72 and β is greater than 6.5, PPG cannot be injected Thus, the matching relationship between PPG particle size and reservoir permeability was obtained. This research will provide theoretical support for further EOR research and field application of heterogeneous phase combined flooding. Full article

Gel treatment is an economical and efficient method of controlling excessive water production. The gelation of in situ gels is prone to being affected by the dilution of formation water, chromatographic during the transportation process, and thus controlling the gelation time and penetration depth is a challenging task. Therefore, a novel gel system termed preformed particle gels (PPGs) has been developed to overcome the drawbacks of in situ gels. PPGs are superabsorbent polymer gels which can swell but not dissolve in brines. Typically, PPGs are a granular gels formed based on the crosslinking of polyacrylamide, characterized by controllable particle size and strength. This work summarizes the application scenarios of PPGs and elucidates their plugging mechanisms. Additionally, several newly developed PPG systems such as high-temperature-resistant PPGs, re-crosslinkable PPGs, and delayed-swelling PPGs are also covered. This research indicates that PPGs can selectively block the formation of fractures or high-permeability channels. The performance of the novel modified PPGs was superior to in situ gels in harsh environments. Lastly, we outlined recommended improvements for the novel PPGs and suggested future research directions. Full article

To address challenges associated with excessive water production in mature oil reservoirs, this study introduces a carboxymethyl cellulose (CMC)-based material as a novel preformed particle gel (PPG) designed to plug excessive water pathways and redistribute the subsequent injected water toward unswept zones. Through microwave-assisted grafting copolymerization of CMC with acrylamide (AM), we successfully generated multi-sized dry particles within the range of 250–800 µm. Comprehensive analyses, including Fourier-transform infrared spectroscopy (FTIR) and scanning electron microscopy (SEM), have confirmed the chemical composition and morphology of the resulting carboxymethyl cellulose-grafted crosslinked polyacrylamide (CMC/PAMBA). Swelling kinetics and rheology tests were conducted to confirm the ability of this novel PPG system to perform at different reservoir conditions. The results of core flooding experiments showed that the CMC/PAMBA PPG is capable of plugging open fractures with a water breakthrough pressure gradient of up to 144 psi/ft. This preformed particle gel (PPG) system was designed specifically for application in Middle East reservoirs, which are distinguished by high salinity and elevated temperature levels. This PPG system is able to swell up to 10 times its original size in seawater and maintain a strength of about 1300 Pa at a temperature of 80 °C. Further optimization is conceivable to enhance injection efficiency and achieve superior plugging outcomes. Full article

Preformed particle gels (PPGs) based on acrylamide (AAm), (3-acrylamidopropyl) trimethylammonium chloride (APTAC), and 2-acrylamido-2-methyl-1-propanesulfonic acid sodium salt (AMPS) were synthesized via conventional free radical copolymerization. The resultant PPGs of various compositions were characterized using FTIR spectroscopy, TG and DT analysis, and mechanical testing. The swelling behavior of PPGs depending on ionic strength, temperature, degree of crosslinking, and pH was also studied. The obtained results show that the swelling mechanism of PPGs is mainly due to the diffusion of the solvent. The mechanical properties of PPGs were improved by creating a composite polymer network by adding the clay mineral (bentonite) to the reaction mixture of monomers, which also makes it possible to control the Young’s modulus and the swelling degree of the samples. Full article

Daqing Oilfield faces increasing reservoir heterogeneity after years of polymer flooding, limiting further enhanced oil recovery. A novel preformed particle gel (PPG) was developed by Daqing Oilfield due to the limited profile control ability of polymer flooding. The preformed particle gel possesses strong deformation ability and the ability to pass through pore throats. The PPG was developed considering the in situ reservoir conditions and combined effects of plugging and flooding. Thus, a heterogeneous system was prepared by mixing polymers and the PPG. In this study, we measured the related properties of the system and assessed its profile control ability and oil displacement performance after polymer flooding. The experimental results demonstrate that typical polymer flooding cannot improve oil recovery under current reservoir conditions. Thus, deep profile control technology should be applied to remediate the highly heterogeneous reservoir issue. PPG can considerably increase the viscosity and stability of the system. The heterogeneous system has a strong plugging ability during the subsequent water flooding stage and is suitable to inject into the medium and high permeability layers. The water absorption profile of the core samples is significantly improved due to the impact of the PPG on the plugging of the layer with high permeability and the liquid flow direction. The system displays an excellent profile control effect in the core with a permeability ratio (high permeability/low permeability) of two under the conditions of a PPG concentration of 500 mg/L and an injection volume of 0.5 PV. In the oil displacement experiment, the recovery efficiency was raised by 16.56% using the polymer system, leading to significant swept volume increment and oil recovery improvement. Full article

After polymer flooding in Daqing Oilfield, the heterogeneity of the reservoir is enhanced, leading to the development of the dominant percolation channels, a significant issue with inefficient circulation, a substantial amount of displacement agents, and elevated cost. In order to further improve oil recovery, an adaptive oil displacement system (ASP-PPG) was proposed by combining preformed particle gel (PPG) with an alkali-surfactant-polymer system (ASP). This comprehensive study aims to assess the effectiveness of the adaptive oil displacement system (ASP-PPG) in improving the recovery efficiency of heterogeneous reservoirs after polymer flooding. The evaluation encompasses various critical aspects, including static performance tests, flow experiments, microscopic experiments, profile control experiments, and flooding experiments conducted on a four-layer heterogeneous physical model. The experimental results show that the adaptive system has robust stability, enhanced mobility, effective plugging capability, and profile improvement capability. Notably, the system demonstrates the remarkable ability to successfully pass through the core and effectively block the large pores, resulting in an 18.4% recovery incremental after polymer flooding. This improvement is reflected in the reduced oil saturation values in the ultra-high permeability, high permeability, medium, and low permeability layers, which are 5.09%, 7.01%, 13.81%, and 15.45%, respectively. The adaptive system effectively recovered the remaining oil in the low and medium permeability layers, providing a promising approach for improving the recovery factors under challenging reservoir conditions. Full article

Heterogeneous phase composite (HPC) flooding technology that is based on branched-preformed particle gel (B-PPG) is an important technology for enhancing oil recovery in high water-cut reservoirs. In this paper, we conducted a series of visualization experiments under the condition of developed high-permeability channels after polymer flooding, with respect to well pattern densification and adjustment, and HPC flooding and its synergistic regulation. The experiments show that for polymer-flooded reservoirs, HPC flooding can significantly reduce the water cut and increase oil recovery, but that the injected HPC system mainly advances along the high-permeability channel with limited sweep expansion. Furthermore, well pattern densification and adjustment can divert the original mainstream direction, which has a positive effect on HPC flooding, and can effectively expand the sweeping range under the synergistic effect of residual polymers. Due to the synergistic effect of multiple chemical agents in the HPC system, after well pattern densification and adjustment, the production time for HPC flooding with the water cut lower than 95% was significantly prolonged. In addition, conversion schemes, in which the original production well is converted into the injection well, are better than non-conversion schemes in terms of expanding sweep efficiency and enhancing oil recovery. Therefore, for well groups with obvious high-water-consuming channels after polymer flooding, the implementation of HPC flooding can be combined with well pattern conversion and intensification in order to further improve oil displacement. Full article

Oil and gas extraction frequently produces substantial volumes of produced water, leading to several mechanical and environmental issues. Several methods have been applied over decades, including chemical processes such as in-situ crosslinked polymer gel and preformed particle gel, which are the most effective nowadays. This study developed a green and biodegradable PPG made of PAM and chitosan as a blocking agent for water shutoff, which will contribute to combating the toxicity of several commercially used PPGs. The applicability of chitosan to act as a crosslinker has been confirmed by FTIR spectroscopy and observed by scanning electron microscopy. Extensive swelling capacity measurements and rheological experiments were performed to examine the optimal formulation of PAM/Cs based on several PAM and chitosan concentrations and the effects of typical reservoir conditions, such as salinity, temperature, and pH. The optimum concentrations of PAM with 0.5 wt% chitosan were between 5–9 wt%, while the optimum chitosan amount with 6.5 wt% PAM was in the 0.25–0.5 wt% range, as these concentrations can produce PPGs with high swellability and sufficient strength. The swelling capacity of PAM/Cs is lower in high saline water (HSW) with a TDS of 67.2976 g/L compared with fresh water, which is related to the osmotic pressure gradient between the swelling medium and the PPG. The swelling capacity in freshwater was up to 80.37 g/g, while it is 18.73 g/g in HSW. The storage moduli were higher in HSW than freshwater, with ranges of 1695–5000 Pa and 2053–5989 Pa, respectively. The storage modulus of PAM/Cs samples was higher in a neutral medium (pH = 6), where the fluctuation behavior in different pH conditions is related to electrostatic repulsions and hydrogen bond formation. The increase in swelling capacity caused by the progressive increment in temperature is associated with the amide group’s hydrolysis to carboxylate groups. The sizes of the swollen particles are controllable since they are designed to be 0.63–1.62 mm in DIW and 0.86–1.00 mm in HSW. PAM/Cs showed promising swelling and rheological characteristics while demonstrating long-term thermal and hydrolytic stability in high-temperature and high-salinity conditions. Full article

After tertiary recovery from the oilfields, improving the production of the remaining hydrocarbon is always challenging. To significantly improve oil recovery, a heterogeneous composite flooding system has been developed with preformed particle gels (PPG) and polymers according to the technical approach of plugging and flooding combination. In addition, an oil saturation monitoring device and a large-scale 3D physical model were designed to better evaluate the performance of the technique. The evaluation results show that the viscosity, stability, and elasticity of the heterogeneous composite flooding system are better than the single polymer system. In addition, both systems exhibit pseudoplastic fluid characteristics and follow the principle of shear thinning. The results of seepage experiments showed that PPG migrates alternately in porous media in the manner of “piling plugging-pressure increasing-deformation migration”. The heterogeneous composite system can migrate to the depths of the oil layer, which improves the injection profile. In the visualization experiment, the heterogeneous composite system preferentially flowed into the high-permeability layer, which increased the seepage resistance and forced the subsequent fluid to flow into the medium and low permeability layers. The average saturation of the high, medium, and low permeability layers decreased by 4.74%, 9.51%, and 17.12%, respectively, and the recovery factor was further improved by 13.56% after the polymer flooding. Full article

Performed gels are widely used in fields to support profile modification and Enhance Oil Recovery. Previous studies of profile modification of performed gels mainly used the index of pressure, resistance factor, or residual resistance factor to represent their ability. However, there is a lack of methods available to directly study their modification ability. In this article, the preformed gels with fluorescence properties, CQDs@PPG, would provide a new way to explore the profile modification of preformed gels. This paper uses poly (acrylamide, sodium p-styrene sulfonate), carbon quantum dots, and N,N-methylenebisacrylamide to prepare the CQDs@PPG via inverse emulsion polymerization. The morphology, size distribution, structure, fluorescence characteristics, surface potential thermal stability, viscosity changes, and viscoelastic properties of CQDs@PPG were analyzed. Moreover, the fluorescence properties of CQDs@PPG under different temperature, salinity, and pH were examined. Results indicate that the CQDs@PPG have excellent stability and that pH and salinity have little influence on their fluorescence properties. Further, only the temperature would affect the fluorescence properties of CQDs@PPG, but that effect is reversible after the temperature drops. By examining the fluorescence intensity, it would be more direct for researchers to study the profile modification in further experiments. Full article

The preformed particle gel (PPG) has been proved to be an effective chemical agent to reduce fluid channeling and increase the sweeping efficiency. However, we still lack a clear understanding of the field-scale matching relationship between PPG size, elastic modulus and a heterogeneous reservoir. In this respect, the paper carried out various sand pack displacement experiments. The results indicated that an excessively large PPG or elastic modulus would plug a low-permeability sand pack and even increase the severity of fluid channeling. On the contrary, an excessively small PPG or elastic modulus allowed a certain degree of profile control, but the PPG could easily migrate out of high-permeability sand packs with water. If the elastic modulus remained unchanged, the suitable PPG size increased as the reservoir permeability ratio increased. On the other hand, the suitable elastic modulus increased with the increase of the reservoir permeability ratio when the PPG size was kept the same. By using regression analysis, quantitative expressions were established in order to determine the best suitable PPG size for a certain heterogeneous reservoir. When the elastic modulus was fixed, the best suitable PPG mesh exhibited a linear relation with the permeability ratio. This paper provides a useful reference to select the most convenient PPG size and elastic modulus for a potential heterogeneous reservoir, suitable to enhance oil recovery. Full article

Simultaneous utilization of surfactant and preformed particle gel (henceforth; PPG) flooding on the oil recovery enhancement has been widely investigated as a preferable enhanced oil recovery technique after the polymer flooding. In this paper, a numerical model is developed to simulate the profound impact of hybrid chemical enhanced oil recovery methods (PPG/polymer/surfactant) in sandstone reservoirs. Moreover, the gel particle conformance control is considered in the developed model after polymer flooding performances on the oil recovery enhancement. To validate the developed model, two sets of experimental field data from Daqing oil field (PPG conformance control after polymer flooding) and Shengli oil field (PPG-surfactant flooding after polymer flooding) are used to check the reliability of the model. Combination of preformed gel particles, polymers and surfactants due to the deformation, swelling, and physicochemical properties of gel particles can mobilize the trapped oil through the porous media to enhance oil recovery factor by blocking the high permeable channels. As a result, PPG conformance control plays an essential role in oil recovery enhancement. Furthermore, experimental data of PPG/polymer/surfactant flooding in the Shengli field and its comparison with the proposed model indicated that the model and experimental field data are in a good agreement. Consequently, the coupled model of surfactant and PPG flooding after polymer flooding performances has led to more recovery factor rather than the basic chemical recovery techniques. Full article
