Search Results (62)

Search Parameters:
Keywords = polycrystalline perovskite

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
14 pages, 9951 KiB
Article
Magnetocaloric Effect of Gd1-xDyxScO3 (x = 0, 0.1, 0.2 and 1) Polycrystalline Compounds
by Yuwei Li, Xiukun Hu, Qiong Wu, Yi Zhao, Hangfu Yang, Minxiang Pan and Hongliang Ge
Materials 2025, 18(12), 2884; https://doi.org/10.3390/ma18122884 - 18 Jun 2025
Viewed by 352
Abstract
This study systematically investigates the magnetic ordering and magnetocaloric properties of a series of polycrystalline compounds, Gd1-xDyxScO3 (x = 0, 0.1, 0.2 and 1). X-ray powder diffraction (XRD) analysis confirms that all samples exhibit an orthorhombic perovskite structure [...] Read more.
This study systematically investigates the magnetic ordering and magnetocaloric properties of a series of polycrystalline compounds, Gd1-xDyxScO3 (x = 0, 0.1, 0.2 and 1). X-ray powder diffraction (XRD) analysis confirms that all samples exhibit an orthorhombic perovskite structure with a space group of Pbnm. The zero-field cooling and field cooling magnetization curves demonstrate a transition from antiferromagnetic to paramagnetic phases, with Néel temperatures of about 3 K for GdScO3 and 4 K for DyScO3. The doping of Dy3+ weakened long-range antiferromagnetic order and enhanced short-range magnetic disorder in GdScO3, leading to vanished antiferromagnetic transition between 2 and 100 K for the sample of x = 0.2. Using the Arrott–Noakes equation, we constructed Arrott plots to analyze the system’s critical behavior. Both the compounds with x = 0.1 and x = 0.2 conform to the 3D-Heisenberg model. These results indicate the weakened long-range antiferromagnetic order induced by Dy3+ doping. Significant maximal magnetic entropy change (−ΔSMMax) of 36.03 J/kg K at 3 K for the sample Gd0.9Dy0.1ScO3 is achieved as the magnetic field changes from 0 to 50 kOe, which is higher than that of GdScO3 (−ΔSMMax = 34.32 J/kg K) and DyScO3 (−ΔSMMax = 15.63 J/kg K). The considerable magnetocaloric effects (MCEs) suggest that these compounds can be used in the development of low-temperature magnetic refrigeration materials. Full article
(This article belongs to the Section Advanced Nanomaterials and Nanotechnology)
Show Figures

Figure 1

18 pages, 16900 KiB
Article
Synthesis, Structure, and Optoelectronic Properties of a Hybrid Organic–Inorganic Perovskite with a Monoethanolammonium Cation MAxMEA1−xPbI3
by Andrey Ryabko, Maxat Ovezov, Alexandr Tuchkovsky, Oleg Korepanov, Alexandr Maximov, Alexey Komolov, Eleonora Lazneva, Ekaterina Muratova, Igor Vrublevsky, Andrey Aleshin and Vyacheslav Moshnikov
Nanomaterials 2025, 15(7), 494; https://doi.org/10.3390/nano15070494 - 26 Mar 2025
Viewed by 469
Abstract
Hybrid organic–inorganic perovskites have emerged as promising materials for next-generation optoelectronic devices owing to their tunable properties and low-cost fabrication. We report the synthesis of 3D hybrid perovskites with monoethanolammonium cations. Specifically, we investigated the optoelectronic properties and morphological characteristics of polycrystalline films [...] Read more.
Hybrid organic–inorganic perovskites have emerged as promising materials for next-generation optoelectronic devices owing to their tunable properties and low-cost fabrication. We report the synthesis of 3D hybrid perovskites with monoethanolammonium cations. Specifically, we investigated the optoelectronic properties and morphological characteristics of polycrystalline films of hybrid perovskites MAxMEA1−xPbI3, which contain methylammonium (MA) and monoethanolammonium (MEA) cations. MAxMEA1−xPbI3 crystallizes in a tetragonal perovskite structure. The substitution of methylammonium cations with monoethanolammonium ions led to an increase in the lattice parameters and the bandgap energy. Energy level diagrams of the synthesized samples were also constructed. The bandgap of MA0.5MEA0.5PbI3 makes it a promising material for use in tandem solar cells. These polycrystalline films, namely MA0.5MEA0.5PbI3 and MA0.25MEA0.75PbI3 were fabricated using a one-step spin-coating method without an antisolvent. These films exhibit a uniform surface morphology under the specified deposition parameters. Within the scope of this study, no evidence of dendritic structures or pinhole-type defects were observed. All synthesized samples demonstrated photocurrent generation under visible light illumination. Moreover, using monoethanolammonium cations reduced the hysteresis of the I–V characteristics, indicating improved device stability. Full article
(This article belongs to the Section Nanoelectronics, Nanosensors and Devices)
Show Figures

Figure 1

15 pages, 4184 KiB
Article
Photocatalysis of Methyl Orange (MO), Orange G (OG), Rhodamine B (RhB), Violet and Methylene Blue (MB) Under Natural Sunlight by Ba-Doped BiFeO3 Thin Films
by Abderrahmane Boughelout, Abdelmadjid Khiat and Roberto Macaluso
Materials 2025, 18(4), 887; https://doi.org/10.3390/ma18040887 - 18 Feb 2025
Viewed by 749
Abstract
We present structural, morphological, optical and photocatalytic properties of multiferroic Bi0.98Ba0.02FeO3 (BBFO2) perovskite thin films prepared by a combined sol–gel and spin-coating method. X-ray diffraction (XRD) analysis revealed that all the perovskite films consisted of the stable polycrystalline [...] Read more.
We present structural, morphological, optical and photocatalytic properties of multiferroic Bi0.98Ba0.02FeO3 (BBFO2) perovskite thin films prepared by a combined sol–gel and spin-coating method. X-ray diffraction (XRD) analysis revealed that all the perovskite films consisted of the stable polycrystalline rhombohedral phase structure (space group R3c) with a tolerance factor of 0.892. By using Rietveld refinement of diffractogram XRD data, crystallographic parameters, such as bond angle, bond length, atom position, unit cell parameters, and electron density measurements were computed. Scanning electron microscopy (SEM) allowed us to assess the homogeneous and smooth surface morphology of the films with a small degree of porosity, while chemical surface composition characterization by X-ray photoelectron spectroscopy (XPS) showed the presence of Bi, Fe, O and the doping element Ba. Absorption measurements allowed us to determine the energy band gap of the films, while photoluminescence measurements have shown the presence of oxygen vacancies, which are responsible for the enhanced photocatalytic activity of the material. Photocatalytic degradation experiments of Methylene Blue (MB), Methyl orange (MO), orange G (OG), Violet and Rhodamine B (RhB) performed on top of BBFO2 thin films under solar light showed the degradation of all pollutants in varying discoloration efficiencies, ranging from 81% (RhB) to 54% (OG), 53% (Violet), 47% (MO) and 43% (MB). Full article
(This article belongs to the Special Issue Halide Perovskite Crystal Materials and Optoelectronic Devices)
Show Figures

Figure 1

14 pages, 2963 KiB
Article
Synthesis, Structure, and Electrophysical and Electrochemical Properties of Novel Composite La0.9MnO3-LaFeO3
by Mukhametkali Mataev, Zamira Sarsenbaeva, Bahadir Keskin, Marzhan Nurbekova, Amangeldi Meldeshov, Zhanar Tursyn and Karima Seitbekova
Molecules 2025, 30(1), 132; https://doi.org/10.3390/molecules30010132 - 31 Dec 2024
Cited by 1 | Viewed by 1277
Abstract
This article presents the synthesis, electrophysical, and catalytic properties of a La0.9MnO3–LaFeO3 nanocomposite material. The nanocomposite was synthesized via the sol–gel (Pechini) method. X-ray diffraction (XRD) analysis revealed a polycrystalline, biphasic perovskite structure combining both hexagonal and cubic [...] Read more.
This article presents the synthesis, electrophysical, and catalytic properties of a La0.9MnO3–LaFeO3 nanocomposite material. The nanocomposite was synthesized via the sol–gel (Pechini) method. X-ray diffraction (XRD) analysis revealed a polycrystalline, biphasic perovskite structure combining both hexagonal and cubic symmetry. The microstructure and elemental composition, examined using field emission scanning electron microscopy (FESEM), indicated an average particle size of approximately 186.9 nm. The composite exhibits semiconducting behavior within the temperature ranges of 293–323 K and 343–393 K. Developing electrocatalysts free of precious metals for the hydrogen evolution reaction (HER) is increasingly important to facilitate the production of hydrogen from renewable sources. In this study, the conductive La0.9MnO3–LaFeO3 composite was deposited on graphite and, for the first time, evaluated as an electrocatalyst for HER in acidic media. The resulting composite films were tested using linear sweep voltammetry (LSV) and electrochemical impedance spectroscopy (EIS) in a glassy carbon electrode (GCE) setup, providing insights into their potential as effective, cost-efficient electrocatalysts. Full article
Show Figures

Figure 1

16 pages, 5518 KiB
Article
Comparing the Efficacies of Electrospun ZnO and TiO2 Nanofibrous Interlayers for Electron Transport in Perovskite Solar Cells
by Abdullah Zafar, Waqar Iqbal, Shahzaib Khan, Aiyeshah Alhodaib and Mahvish Fatima
Ceramics 2024, 7(4), 1742-1757; https://doi.org/10.3390/ceramics7040111 - 13 Nov 2024
Viewed by 1360
Abstract
ZnO and TiO2 are both well-known electron transport materials. Their comparison of performance is considered advantageous and novel. Therefore, a viable electrospinning route was considered for the development of highly polycrystalline TiO2 and ZnO nanofibers as an electron transport material (ETM) [...] Read more.
ZnO and TiO2 are both well-known electron transport materials. Their comparison of performance is considered advantageous and novel. Therefore, a viable electrospinning route was considered for the development of highly polycrystalline TiO2 and ZnO nanofibers as an electron transport material (ETM) for perovskite solar cells. The materials were well-characterized in terms of different analytical techniques. The X-ray diffraction detected polycrystalline structural properties corresponding to TiO2 and ZnO. Morphological analysis by scanning electron microscopy revealed that the nanofibers are long, uniform, and polycrystalline, having a diameter in the nanometer range. Optoelectronic properties showed that TiO2 and ZnO exhibit absorption values in the ultraviolet and visible ranges, and band gap values for TiO2 and ZnO were 3.3 and 3.2 eV, respectively. TiO2 bandgap and semiconductor nature were more compatible with Electron Transport Layer (ETL) compared to ZnO. Electrical studies revealed that TiO2 nanofibers have enhanced values of conductivity and sheet carrier mobility compared to ZnO nanofibers. Therefore, higher photovoltaic conversion efficiency was achieved for TiO2 nanofibers (10.4%) compared to ZnO (8.5%). Full article
(This article belongs to the Special Issue Advances in Electronic Ceramics)
Show Figures

Graphical abstract

25 pages, 6231 KiB
Article
Physical Properties of an Efficient MAPbBr3/GaAs Hybrid Heterostructure for Visible/Near-Infrared Detectors
by Tarek Hidouri, Maura Pavesi, Marco Vaccari, Antonella Parisini, Nabila Jarmouni, Luigi Cristofolini and Roberto Fornari
Nanomaterials 2024, 14(18), 1472; https://doi.org/10.3390/nano14181472 - 10 Sep 2024
Cited by 4 | Viewed by 1336
Abstract
Semiconductor photodetectors can work only in specific material-dependent light wavelength ranges, connected with the bandgaps and absorption capabilities of the utilized semiconductors. This limitation has driven the development of hybrid devices that exceed the capabilities of individual materials. In this study, for the [...] Read more.
Semiconductor photodetectors can work only in specific material-dependent light wavelength ranges, connected with the bandgaps and absorption capabilities of the utilized semiconductors. This limitation has driven the development of hybrid devices that exceed the capabilities of individual materials. In this study, for the first time, a hybrid heterojunction photodetector based on methylammonium lead bromide (MAPbBr3) polycrystalline film deposited on gallium arsenide (GaAs) was presented, along with comprehensive morphological, structural, optical, and photoelectrical investigations. The MAPbBr3/GaAs heterojunction photodetector exhibited wide spectral responsivity, from 540 to 900 nm. The fabrication steps of the prototype device, including a new preparation recipe for the MAPbBr3 solution and spinning, will be disclosed and discussed. It will be shown that extending the soaking time and refining the precursor solution’s stoichiometry may enhance surface coverage, adhesion to the GaAs, and film uniformity, as well as provide a new way to integrate MAPbBr3 on GaAs. Compared to the pristine MAPbBr3, the enhanced structural purity of the perovskite on GaAs was confirmed by X-ray Diffraction (XRD) upon optimization compared to the conventional glass substrate. Scanning Electron Microscopy (SEM) revealed the formation of microcube-like structures on the top of an otherwise continuous MAPbBr3 polycrystalline film, with increased grain size and reduced grain boundary effects pointed by Energy-Dispersive Spectroscopy (EDS) and cathodoluminescence (CL). Enhanced absorption was demonstrated in the visible range and broadened photoluminescence (PL) emission at room temperature, with traces of reduction in the orthorhombic tilting revealed by temperature-dependent PL. A reduced average carrier lifetime was reduced to 13.8 ns, revealed by time-resolved PL (TRPL). The dark current was typically around 8.8 × 10−8 A. Broad photoresponsivity between 540 and 875 nm reached a maximum of 3 mA/W and 16 mA/W, corresponding to a detectivity of 6 × 1010 and 1 × 1011 Jones at −1 V and 50 V, respectively. In case of on/off measurements, the rise and fall times were 0.40 s and 0.61 s or 0.62 s and 0.89 s for illumination, with 500 nm or 875 nm photons, respectively. A long-term stability test at room temperature in air confirmed the optical and structural stability of the proposed hybrid structure. This work provides insights into the physical mechanisms of new hybrid junctions for high-performance photodetectors. Full article
(This article belongs to the Special Issue Physical Properties of Semiconductor Nanostructures and Devices)
Show Figures

Figure 1

13 pages, 3019 KiB
Article
Open-Air Processing of Mechanically Robust Metal Halide Perovskites with Controllable Thicknesses above 10 µm
by Kayshavi Bakshi, Muzhi Li, Muneeza Ahmad, Mason Mahaffey and Nicholas Rolston
Processes 2024, 12(9), 1901; https://doi.org/10.3390/pr12091901 - 5 Sep 2024
Viewed by 2738
Abstract
We report on the use of open-air blade-coating as a scalable method for producing metal halide perovskite films with >10× fracture energy for durability and mechanical stability through the addition of corn starch polymer additives. This results in a manufacturable and robust perovskite [...] Read more.
We report on the use of open-air blade-coating as a scalable method for producing metal halide perovskite films with >10× fracture energy for durability and mechanical stability through the addition of corn starch polymer additives. This results in a manufacturable and robust perovskite that has tunable thicknesses exceeding 10 µm, among the highest reported values for solution-processed polycrystalline films. We find that an increasing amount of starch causes more uniform carbon distribution within the perovskite thickness as quantified by cross-sectional elemental composition measurements. Further, the incorporation of starch introduces beneficial compressive film stresses. Importantly, the optoelectronic behavior is not compromised, as the photoluminescence spectrum becomes more homogenous with the addition of corn starch up to 20% by weight. Full article
Show Figures

Graphical abstract

24 pages, 3999 KiB
Review
Single Crystal Sn-Based Halide Perovskites
by Aditya Bhardwaj, Daniela Marongiu, Valeria Demontis, Angelica Simbula, Francesco Quochi, Michele Saba, Andrea Mura and Giovanni Bongiovanni
Nanomaterials 2024, 14(17), 1444; https://doi.org/10.3390/nano14171444 - 4 Sep 2024
Cited by 2 | Viewed by 4058
Abstract
Sn-based halide perovskites are expected to be the best replacement for toxic lead-based counterparts, owing to their similar ionic radii and the optimal band gap for use in solar cells, as well as their versatile use in light-emitting diodes and photodetection applications. Concerns, [...] Read more.
Sn-based halide perovskites are expected to be the best replacement for toxic lead-based counterparts, owing to their similar ionic radii and the optimal band gap for use in solar cells, as well as their versatile use in light-emitting diodes and photodetection applications. Concerns, however, exist about their stability under ambient conditions, an issue that is exacerbated in polycrystalline films because grain boundaries present large concentrations of defects and act as entrance points for oxygen and water, causing Sn oxidation. A current thriving research area in perovskite materials is the fabrication of perovskite single crystals, promising improved optoelectronic properties due to excellent uniformity, reduced defects, and the absence of grain boundaries. This review summarizes the most recent advances in the fabrication of single crystal Sn-based halide perovskites, with emphasis on synthesis methods, compositional engineering, and formation mechanisms, followed by a discussion of various challenges and appropriate strategies for improving their performance in optoelectronic applications. Full article
Show Figures

Graphical abstract

12 pages, 5268 KiB
Article
Enhancing Perovskite Solar Cell Performance through Propylamine Hydroiodide Passivation
by Fulin Sun, Ting Zhu, Chenhui Zhang, Yi Dong, Yuzhu Guo, Dan Li, Fangtian You and Chunjun Liang
Nanomaterials 2024, 14(17), 1416; https://doi.org/10.3390/nano14171416 - 29 Aug 2024
Cited by 1 | Viewed by 1784
Abstract
In recent years, the power conversion efficiency of perovskite solar cells has increased rapidly. Perovskites can be prepared using simple and cost-effective solution methods. However, the perovskite films obtained are usually polycrystalline and contain numerous defects. Passivation of these defects is crucial for [...] Read more.
In recent years, the power conversion efficiency of perovskite solar cells has increased rapidly. Perovskites can be prepared using simple and cost-effective solution methods. However, the perovskite films obtained are usually polycrystalline and contain numerous defects. Passivation of these defects is crucial for enhancing the performance of solar cells. Here, we report the use of propylamine hydroiodide (PAI) for defect passivation. We found that PAI can result in higher-efficiency cells by reducing the defects and suppressing non-radiative recombination. Consequently, n-i-p perovskite solar cells with a certificated efficiency of 21% were obtained. In addition, PAI exhibited excellent performance in p-i-n devices by serving as a buried interface layer, leading to an improved efficiency of 23%. Full article
(This article belongs to the Section Solar Energy and Solar Cells)
Show Figures

Figure 1

14 pages, 10436 KiB
Article
Impact of Residual Strains on the Carrier Mobility and Stability of Perovskite Films
by Moulay Ahmed Slimani, Luis Felipe Gerlein, Ricardo Izquierdo and Sylvain G. Cloutier
Nanomaterials 2024, 14(15), 1310; https://doi.org/10.3390/nano14151310 - 3 Aug 2024
Cited by 1 | Viewed by 2156
Abstract
Solution-based inorganic–organic halide perovskites are of great interest to researchers because of their unique optoelectronic properties and easy processing. However, polycrystalline perovskite films often show inhomogeneity due to residual strain induced during the film’s post-processing phase. In turn, these strains can impact both [...] Read more.
Solution-based inorganic–organic halide perovskites are of great interest to researchers because of their unique optoelectronic properties and easy processing. However, polycrystalline perovskite films often show inhomogeneity due to residual strain induced during the film’s post-processing phase. In turn, these strains can impact both their stability and performance. An exhaustive study of residual strains can provide a better understanding and control of how they affect the performance and stability of perovskite films. In this work, we explore this complex interrelationship between residual strains and electrical properties for methylammonium CH3NH3PbI3xClx films using grazing incidence X-ray diffraction (GIXRD). We correlate their resistivity and carrier mobility using the Hall effect. The sin2(ψ) technique is used to optimize the annealing parameters for the perovskite films. We also establish that temperature-induced relaxation can yield a significant enhancement of the charge carrier transports in perovskite films. Finally, we also use Raman micro-spectroscopy to assess the degradation of perovskite films as a function of their residual strains. Full article
Show Figures

Figure 1

17 pages, 3580 KiB
Article
Impact of Temperature Optimization of ITO Thin Film on Tandem Solar Cell Efficiency
by Elif Damgaci, Emre Kartal, Furkan Gucluer, Ayse Seyhan and Yuksel Kaplan
Materials 2024, 17(11), 2784; https://doi.org/10.3390/ma17112784 - 6 Jun 2024
Cited by 1 | Viewed by 2646
Abstract
This study examined the impact of temperature optimization on indium tin oxide (ITO) films in monolithic HJT/perovskite tandem solar cells. ITO films were deposited using magnetron sputtering at temperatures ranging from room temperature (25 °C) to 250 °C. The sputtering target was ITO, [...] Read more.
This study examined the impact of temperature optimization on indium tin oxide (ITO) films in monolithic HJT/perovskite tandem solar cells. ITO films were deposited using magnetron sputtering at temperatures ranging from room temperature (25 °C) to 250 °C. The sputtering target was ITO, with a mass ratio of In2O3 to SnO2 of 90% to 10%. The effects of temperature on the ITO film were analyzed using X-ray diffraction (XRD), spectroscopic ellipsometry, and sheet resistance measurements. Results showed that all ITO films exhibited a polycrystalline morphology, with diffraction peaks corresponding to planes (211), (222), (400), (440), and (622), indicating a cubic bixbyite crystal structure. The light transmittance exceeded 80%, and the sheet resistance was 75.1 Ω/sq for ITO deposited at 200 °C. The optical bandgap of deposited ITO films ranged between 3.90 eV and 3.93 eV. Structural and morphological characterization of the perovskite solar cell was performed using XRD and FE-SEM. Tandem solar cell performance was evaluated by analyzing current density-voltage characteristics under simulated sunlight. By optimizing the ITO deposition temperature, the tandem cell achieved a power conversion efficiency (PCE) of 16.74%, resulting in enhanced tandem cell efficiency. Full article
Show Figures

Figure 1

14 pages, 3052 KiB
Article
Improving Device-to-Device Reproducibility of Light-Emitting Diodes Based on Layered Halide Perovskites
by Quang-Huy Do, Rémi Antony, Bernard Ratier and Johann Bouclé
Electronics 2024, 13(6), 1039; https://doi.org/10.3390/electronics13061039 - 11 Mar 2024
Cited by 2 | Viewed by 1360
Abstract
Layered halide perovskites have emerged as a promising contender in solid-state lighting; however, the fabrication of perovskite light-emitting devices in laboratories usually experiences low device-to-device reproducibility since perovskite crystallization is highly sensitive to ambient conditions. Although device processing inside gloveboxes is primarily used [...] Read more.
Layered halide perovskites have emerged as a promising contender in solid-state lighting; however, the fabrication of perovskite light-emitting devices in laboratories usually experiences low device-to-device reproducibility since perovskite crystallization is highly sensitive to ambient conditions. Although device processing inside gloveboxes is primarily used to reduce the influence of oxygen and moisture, several extraneous variables, including thermal fluctuations in the inert atmosphere or contaminations from residual solvents, can destabilize the crystallization process and alter the properties of the emissive layers. Here, we examine typical experimental configurations used in research laboratories to deposit layered perovskite films in inert atmospheres and discuss their crucial influences on the formation of polycrystalline thin films. Our results demonstrate that fluctuations in the glovebox properties (concentrations of residual O2 and H2O or solvent traces), even in very short timescales, can negatively impact the consistency of the perovskite film formation, while thermal variation plays a relatively minor role in this phenomenon. Furthermore, the careful storage of chemical species inside the workstation is critical for reproducing high-quality perovskite layers. Consequently, when applying our most controlled environment for perovskite deposition, the photoluminescence lifetime of perovskite thin films shows a standard deviation of only 3%, whereas the reference set-up yields a 15% standard deviation. Regarding complete perovskite light-emitting diodes, the uncertainties in statistical luminance and EQE data are significantly reduced from 230% and 140% to 38% and 42%, respectively. Full article
(This article belongs to the Special Issue Optoelectronic Materials, Heterostructures and Devices)
Show Figures

Figure 1

18 pages, 4786 KiB
Article
Synthesis of LaXO3 (X = Fe, Mn, Cr, Ni) Thin Films Using a Simple Spin Coating Set-Up for Resistive Switching Memory Devices
by Raghad K. Aljurays, Aicha Loucif and Abdulrahman M. Albadri
Electronics 2023, 12(19), 4141; https://doi.org/10.3390/electronics12194141 - 4 Oct 2023
Cited by 7 | Viewed by 2091
Abstract
This study focuses on the preparation of LaXO3(X=Fe,Mn,Cr,Ni) perovskite thin films using a simple set-up spin coating technique and the evaluation of their properties [...] Read more.
This study focuses on the preparation of LaXO3(X=Fe,Mn,Cr,Ni) perovskite thin films using a simple set-up spin coating technique and the evaluation of their properties for application in switching memory devices. The properties of as-deposited films were thoroughly characterized using X-ray diffraction (XRD), field emission scanning electron microscopy (FESEM), UV-Vis spectroscopy, and a vibrating sample magnetometer (VSM). The results obtained revealed that the as-deposited films have a polycrystalline cubic structure. The film surfaces were uniform and densely packed without any voids, cracks, or pinholes. In addition, irregularly shaped grains were observed having an average size of 140, 120, 89, and 70 nm for LaFeO3, LaMnO3, LaCrO3, and LaNiO3 films, respectively. VSM analysis demonstrated that LaFeO3 film exhibited superior magnetic properties compared to the other films. Furthermore, memory devices with Au/LaXO3(X=Fe,Mn,Cr,Ni)/FTO structures were fabricated, and their I-V characteristics were measured. In order to assess their performance, an endurance test was conducted. The findings indicated that Au/LaFeO3/FTO device exhibited higher RHRSRLRS ratio (~7×105), low Set/Reset voltages, lower power consumption (2.7×104 W), and stable endurance with no significant degradation was observed in the LRS and HRS after 20 sweep cycles. These favorable parameters can be attributed to the reduced thickness, larger grain size, and excellent magnetic properties of the active-layer LaFeO3. Moreover, the conduction mechanism of the fabricated devices was investigated, revealing that the conduction in the LRS is primarily dominated by Ohmic behavior, while the HRS exhibited different conduction mechanisms. Full article
Show Figures

Figure 1

32 pages, 1061 KiB
Review
Overview of the Current State of Flexible Solar Panels and Photovoltaic Materials
by Rashid Dallaev, Tatiana Pisarenko, Nikola Papež and Vladimír Holcman
Materials 2023, 16(17), 5839; https://doi.org/10.3390/ma16175839 - 25 Aug 2023
Cited by 47 | Viewed by 14856
Abstract
The rapid growth and evolution of solar panel technology have been driven by continuous advancements in materials science. This review paper provides a comprehensive overview of the diverse range of materials employed in modern solar panels, elucidating their roles, properties, and contributions to [...] Read more.
The rapid growth and evolution of solar panel technology have been driven by continuous advancements in materials science. This review paper provides a comprehensive overview of the diverse range of materials employed in modern solar panels, elucidating their roles, properties, and contributions to overall performance. The discussion encompasses both traditional crystalline silicon-based panels and emerging thin-film technologies. A detailed examination of photovoltaic materials, including monocrystalline and polycrystalline silicon as well as alternative materials such as cadmium telluride (CdTe), copper indium gallium selenide (CIGS), and emerging perovskite solar cells, is presented. Furthermore, the impact of transparent conductive materials, encapsulation polymers, and antireflective coatings on solar panel efficiency and durability is explored. The review delves into the synergistic interplay between material properties, manufacturing processes, and environmental considerations. Through a comprehensive survey of materials utilized in modern solar panels, this paper provides insights into the current state of the field, highlighting avenues for future advancements and sustainable solar energy solutions. Full article
Show Figures

Figure 1

12 pages, 3917 KiB
Communication
A High-Performance UVA Photodetector Based on Polycrystalline Perovskite MAPbCl3/TiO2 Nanorods Heterojunctions
by Yupeng Zhang, Yannan Zhai, Hui Zhang, Zhaoxin Wang, Yongfeng Zhang, Ruiliang Xu, Shengping Ruan and Jingran Zhou
Sensors 2023, 23(15), 6726; https://doi.org/10.3390/s23156726 - 27 Jul 2023
Cited by 3 | Viewed by 2176
Abstract
The application of TiO2 nanorods in the field of ultraviolet (UV) photodetectors is hindered by a high dark current, which is attributed to crystal surface defects and intrinsic excitation by carrier thermal diffusion. Here, a photodetector based on polycrystalline perovskite MAPbCl3 [...] Read more.
The application of TiO2 nanorods in the field of ultraviolet (UV) photodetectors is hindered by a high dark current, which is attributed to crystal surface defects and intrinsic excitation by carrier thermal diffusion. Here, a photodetector based on polycrystalline perovskite MAPbCl3/TiO2 nanorods heterojunctions has been fabricated to overcome the shortcoming. The structure was composed of horizontal MAPbCl3 polycrystalline and vertically aligned TiO2 nanorods array. Many localized depletion regions at the MAPbCl3/TiO2 interface can reduce the dark current. The TiO2/MAPbCl3 detector shows high performance including a high ratio of light-dark current of about six orders of magnitude, which is much larger than that of the TiO2 detector. This study indicates the potential in the TiO2/MAPbCl3 heterojunction to fabricate high-performance UV detectors. Full article
(This article belongs to the Topic Electronic and Optical Properties of Nanostructures)
Show Figures

Figure 1
