A significant amount of mechanical and thermal energy is lost when typing on a laptop keyboard. To address this, hybrid energy harvesters must increase the generated power density and mitigate energy fluctuation issues. This paper explores the potential enhancement of energy harvesting by combining thermoelectric and piezoelectric effects within a multilayered structure integrated into a laptop keyboard button. Through numerical simulation, the study assesses how these two behaviors can synergistically increase the power density generated by the hybrid device. The focus is on optimizing energy efficiency by harnessing the heat losses from integrated circuits and the mechanical stresses due to the act of typing. The point is to refine the design of such a system to maximize the conversion of ambient energy into electricity. The findings indicate that the hybrid structure combining both piezoelectric and thermoelectric effects, effectively captures energy from a laptop keyboard, producing a substantial amount of electricity. This investigation shows that the generator can produce up to 2.07 mW of power using PU-40%PZT as piezoelectric material and an additional 71.93 μW through the PEDOT: PSS as thermoelectric material from a single keystroke when pressed and heated. This study underscores the potential for improving energy-harvesting efficiency in laptop keyboards, contributing to more sustainable and energy-efficient electronic devices. Full article

Lithium niobate on insulator (LNOI) has emerged as a promising platform for compact, low-loss phase modulators. The extant LNOI studies evaluate device performance almost exclusively through the Pockels effect, treating piezoelectric–photoelastic strain and thermo-optic drift as decoupled channels. Crucially, both mechanisms directly perturb the phase bias of a fiber-optic gyroscope (FOG), rendering them indispensable in sensing-oriented design. This work establishes a unified multiphysics model of an X-cut TFLN ridge phase modulator that self-consistently couples the electro-optic, piezoelectric–photoelastic, thermo-optic, and pyroelectric channels. The contributions of the four mechanisms are quantitatively decomposed under realistic FOG operating conditions, and the slab thickness, ridge-top width, and electrode gap are systematically optimized to balance modulation efficiency against environmental robustness. The co-optimization of the ridge geometry and electrode gap design maintains the EO overlap factor near 0.55, while reducing the half-wave voltage requirement. This results in a half-wave voltage length of V_πL = 1.65 V·cm at a 4.4 μm electrode gap. The optimized geometry and electrode gap (4.4 μm) are essentially temperature-independent: extracted from the Pockels modulation slope, V_πL remains stable at ≈1.65 V·cm (push–pull single-pass; within ~0.3%) across 25~85 °C. Furthermore, an externally imposed substrate temperature rise of 60 K (the upper end of the 25~85 °C FOG operating range) induces a mode-field-weighted thermal residual corresponding to approximately 27% of the Pockels modulation depth at an applied voltage of 5 V. The present study demonstrates that the DC-coupled operation of TFLN sensor-grade modulators is viable across the full FOG temperature range, without dedicated active temperature stabilization, and the residual thermal-bias offset is absorbed by the FOG’s standard closed-loop servo electronics. The results of the study provide quantitative design guidelines for high-performance, environmentally stable TFLN phase modulators in compact FOG systems. Full article

The electromechanical coupling factor (K²) is one of the key parameters characterizing the performance of surface acoustic wave (SAW) devices. Conventional SAW structures suffer from a spatial mismatch between mechanical energy and electric fields, which severely limits improvements in K². To address this limitation, this paper proposes a novel microstructure based on trapezoidal etching of the piezoelectric layer. First, an Al/ZnO/Si trapezoidal etching model was established for simulation studies. The results show that trapezoidal etching reduces mechanical energy leakage and enhances the spatial overlap with electric fields. Subsequently, by varying the bottom width (S_ZnO), the variation of K² under three etching shapes (standard trapezoidal, rectangular, and inverted trapezoidal) was investigated. The results indicate that trapezoidal etching significantly enhances K², which gradually increases as S_ZnO decreases. Under the theoretical limit (S_ZnO = 0.1 μm), K² reaches a maximum of 14.34%, representing a 19-fold improvement over the conventional structure. Simultaneously, the figure of merit (FOM) and insertion loss (S₂₁) are also remarkably improved. Finally, considering practical manufacturing constraints, this paper discusses the configurations of S_ZnO = 0.2 μm and 0.4 μm, revealing that the performance of the SAW devices remains significantly enhanced in both cases, thereby providing a practically feasible solution for the design and fabrication of high-performance SAW devices. Full article

Cobalt ferrite (CoFe₂O₄) magnetostrictive ultrasonic elliptical vibration cutting (UEVC) tools have recently emerged as a low-cost, low-eddy-loss alternative to piezoelectric and rare-earth-driven cutting heads. The structural design and resonance characterisation of such a dual-bending CoFe₂O₄ UEVC tool was reported in our previous work. The present paper builds directly on that platform and addresses a different objective: to determine how the four primary process variables—feed rate, cutting speed, cutting depth, and inter-channel phase difference—should be set to obtain the best surface quality on a representative ductile metal. Using H62 brass as the workpiece and a single-crystal diamond tool with a 0.2 mm nose radius and 60° included angle, single-factor experiments are run on a custom 5-axis precision lathe, and surface roughness is mapped in both the cutting and the feed direction with a Keyence VK-X1000 confocal microscope (Keyence, Osaka, Japan). The speed ratio K = Vc/(2πfA) is computed for every test point so that each result can be classified as belonging to the continuous-contact or to the intermittent-contact UEVC regime. The results show: (i) feed rate has a non-monotonic effect, with an optimum at 1 μm where ductile-mode separation is achieved without secondary tool-trajectory overlap, reducing the cutting direction roughness by up to 45% with respect to conventional cutting (CC); (ii) the UEVC advantage shrinks at high cutting speeds because the speed ratio approaches unity and the intermittent regime collapses, but is still 12.6%–38% over the 50–375 mm/s range tested; (iii) the relative improvement is largest at low depth and decreases as the depth grows, retaining 11.5%–49% gain over CC across 0.5–10 μm; (iv) the inter-channel phase difference, which controls the geometry of the tool-tip ellipse, is the strongest single lever—at 60°, the trajectory becomes an oblique ellipse whose major axis is tilted with respect to the cutting direction, bringing the cutting direction roughness down to 1.21 μm against 2.82 μm for CC, a 57% reduction. A simple kinematic argument links this optimum to a maximum effective separation duration per cycle and offers a design rule for analogous UEVC tools. Full article

Integration of lead zirconate titanate (PZT) films on metallic substrates is important for flexible piezoelectric devices, but achieving highly textured crystallinity without detrimental interfacial diffusion or oxidation remains challenging. In this work, PZT thick films (~1.3 μm) were deposited on titanium substrates using radio-frequency magnetron sputtering at 400 °C followed by rapid thermal processing at 640 °C for 2.5 min. A conductive LaNiO₃ buffer layer was introduced to promote the nucleation of the perovskite phase and suppress interfacial degradation. The resulting PZT films on the LNO/Pt/Ti substrates exhibit a strong (001) preferred orientation and a dense microstructure. The films show a large remnant polarization P_r of ~61 μC cm⁻² and a low coercive field E_c of ~56 kV cm⁻¹ at 60 V, together with a dielectric constant ε_r of ~1350–1612 and a dielectric loss tanδ ≤ 0.06 in the frequency range of 1 kHz to 1 MHz. Patterned Pt/PZT/LNO/Pt/Ti cantilevers yield a transverse piezoelectric coefficient e_31,f of ~−6.7 C/m², significantly outperforming reported piezoelectric films deposited on Ti. These results demonstrate that controlled nucleation and rapid thermal crystallization enable highly textured PZT films on reactive metallic substrates, providing a viable route for flexible piezoelectric MEMS devices. Full article

Low-frequency traffic noise below 500 Hz is difficult to mitigate because its long wavelengths require impractically large conventional resonators. Here, we report an active-learning-guided inverse-design approach for scalable phononic-crystal-based acoustic metamaterial resonators that simultaneously suppress low-frequency noise transmission and harvest acoustic energy. The approach combines Gaussian process regression surrogate modeling with genetic algorithm optimization to efficiently explore high-dimensional cavity geometries. By iteratively retraining the surrogate with FEM-validated designs, the active-learning process guides the search toward high-performance structures while reducing costly FEM evaluations compared with conventional GA optimization. After geometric scaling, the 2.5D prototype derived from the nine-point optimized cavity achieved a pressure amplification factor of approximately 20 near 490 Hz, while the revolved 3D cavity exhibited amplification exceeding 30 and a transmission loss of approximately 14 dB near the target frequency. Integrated with a mass-loaded five-PZT stack, the device generated 5.5 V_pp and 0.25 mW under 100 dB SPL, corresponding to a normalized power density of 0.58 μW Pa⁻² cm⁻³. These results demonstrate a route toward multifunctional piezoelectric acoustic devices for noise mitigation, localized energy harvesting, and self-powered sensing. Full article

To address the low monitoring accuracy of traditional methods caused by the complex composition and severe signal overlapping of threshed materials during soybean threshing, this study proposes a high-precision impact signal classification system based on edge perception and a hybrid deep learning architecture, serving as a foundational step for threshing loss monitoring. At the hardware level, a high-speed parallel sensing system was developed to achieve continuous acquisition and high-fidelity mapping of transient impact signals. At the algorithmic level, a CNN–Transformer hybrid network was constructed to effectively extract local signal features and capture long-term temporal dependencies, successfully decoupling complex collision dynamics. Bench tests demonstrate that the hybrid model achieves a comprehensive classification accuracy of 97.36% and F1-scores above 0.96 for soybean grains, stems, and pods, significantly outperforming single networks. Furthermore, feature visualization confirms that the model effectively extracted features strongly correlated with the intrinsic impact dynamics of different materials rather than simply fitting environmental noise. This study provides a highly robust algorithm foundation and bench-level engineering reference for the intelligent classification of soybean harvesting mixtures, laying the groundwork for actual loss estimation under real field conditions. Full article

This study aims to demonstrate the feasibility of controlling particle size through a mathematical model in the design of industrially applicable ultrasonic spray nozzles by utilizing the vibrational characteristics of piezoelectric ceramics. A piezoelectric ceramic composition with a low sintering temperature and excellent thermal stability (Curie temperature above 300 °C) was developed and used as a ceramic vibrator. Furthermore, the resonance frequency and nozzle displacement were calculated using the COMSOL program and applied to a mathematical model to design an ultrasonic nozzle capable of producing a spray particle diameter of approximately 30 μm. The designed ultrasonic nozzle was fabricated, and its spray characteristics were analyzed. The consistency of the spray characteristics was examined by comparing them with the mathematical model based on changes in ultrasonic nozzle length, resonance frequency, and fluid viscosity. When the ultrasonic nozzle horn length was 22 mm, the resonance frequency was found to be 42.1 kHz, and at a flow rate of 65 mL/min. the average spray particle size was approximately 30–40 μm, indicating fine and uniform particles. In addition, it can be seen that as the length of the nozzle horn increases, the resonance frequency decreases, reducing the supply energy delivered to the liquid, and the particle size increases as shown in the mathematical analysis. The theoretical separation energy required to atomize pure water at a flow rate of 65 mL/min. is 2100 J, which was found to be greater than all energy loss occurring during the atomization process. However, it can be seen that as the length of the ultrasonic nozzle increases, the maximum atomization volume increases, and as viscosity increases, the energy required to separate a single atomized particle becomes greater. Full article

In this work, we explore a piezoelectric neuron model in deterministic perturbations and stochastic forcing due to its use in mechanically driven sensing systems and neuromorphic sensor design. The model comprises of fast activation and slow recovery behaviors and constitutes a multiscale excitable system, converting external mechanical perturbations into nonlinear electrical responses. We initially examine the deterministic dynamics with phase-space reconstruction, basin of attraction mapping, return map analysis and sensitivity to initial conditions. These findings demonstrate stable limit-cycle oscillations and high nonlinear sensitivity that are crucial to high-resolution sensing and signal amplification. Stochastic forcing is added in order to include realistic environmental effects, and solved numerically with the Euler-Maruyama scheme. Time-series statistics, phase portraits, and recurrence quantification analysis are used to analyze the resulting ensemble dynamics, making it possible to characterize the variability and loss of predictability caused by noise. Comparison of deterministic and stochastic regimes indicates that the intensity of noise can considerably alter the firing patterns and recurrence structures. Full article

Resonant electromechanical de-icing uses piezoelectric actuators to generate stresses high enough to fracture and shed ice, offering an energy-efficient alternative to conventional systems. This work focuses on prestressed piezoelectric actuators composed of a ceramic stack clamped between two brackets, addressing limitations of previous designs such as mechanical losses and screw fatigue. A new architecture is proposed, featuring a variable-cross-section screw that concentrates deformation in a thinned central region and brackets bonded to the structure to reduce losses. An analytical sizing method is developed using multi-beam longitudinal vibration modelling and two de-icing criteria, including a newly introduced one. The analysis shows how actuator geometry and modal shapes influence de-icing performance, required voltage, and mechanical stresses, highlighting key trade-offs. A dedicated prototype is designed and experimentally tested, with results in good agreement with the analytical predictions. Full article

Piezoelectric semiconductor combines the unique properties of semiconducting characteristics and piezoelectric effect together, providing a universal methodology to modulate piezoelectric semiconductor device’s performance by simply introducing mechanical strain. To reveal the device physics beneath the piezoelectric modulation, in this work, a multiphysics COMSOL 6.0 simulation was employed to investigate the modulation of Si/GaN heterojunction PN diode characteristics via piezoelectric-induced interface polarization charges. The effects of charge polarity and density on forward recovery, reverse recovery, and irradiation responses were systematically analyzed. The results demonstrate that negative interface charges enhance carrier injection and accelerate device activation, whereas positive charges suppress overshoot and stabilize transient voltage behavior. During reverse recovery, negative charges shorten the storage delay and reduce the reverse peak current, improving the switching speed, whereas positive charges cause slower recovery. Under irradiation, the interface polarization charges modulate the photocurrent density by altering the depletion width and carrier collection efficiency; negative charges notably enhance the photocurrent in partially depleted devices. Furthermore, the influence of the polarization charges diminishes with increasing device length or doping concentration, as the built-in charge and electric field effects dominate. This study elucidates the physical mechanisms of piezoelectric charge control in Si/GaN heterojunctions and provides theoretical guidance for the design of high-speed, low-loss, and radiation-tunable power and optoelectronic devices. Full article

In this study, the sintering behavior and electrical properties of 0.7Pb(Zr_0.46Ti_0.54)O₃ (PZT)–0.1Pb(Zn₁/₃Nb₂/₃)O₃ (PZN)–0.2Pb(Ni₁/₃Nb₂/₃)O₃ (PNN) piezoelectric ceramics with different Pb(Fe₂/₃W₁/₃)O₃ (PFW) doping contents were investigated to obtain a formulation that can be co-fired with silver (Ag) electrodes below 900 °C for multilayer ceramics. PFW was introduced as a sintering aid, which effectively reduced the sintering temperature of the ceramics from 1200 °C to 850 °C. The sample with x = 0.12 exhibited the largest average grain size of 1.72 μm, achieving excellent comprehensive properties with piezoelectric constant (d₃₃) = 477 pC/N, planar electromechanical coupling factor (k_p) = 0.68, dielectric loss tangent (tanδ) = 0.0154, and relative density of 98.2%. Furthermore, the feasibility of fabricating piezoelectric actuators based on this optimized composition was verified. Multilayer piezoelectric devices were prepared via screen printing combined with a carbon-based sacrificial layer method. No obvious interdiffusion was observed at the interface between the Ag internal electrodes and the ceramic matrix. The 9-layer device attained a high d₃₃ = 1470 pC/N and produced a large displacement of 5.5 μm (corresponding to a strain = 1.83%) with a voltage of 500 V. The thickness of the multilayer piezoelectric film was approximately 0.3 mm. Through this, the feasibility of manufacturing a multilayered actuator with an Ag electrode was confirmed through the composition of 0.58PZT–0.1PZN–0.2PNN–0.12PFW. Full article

A bottom-up fabrication approach for flexible piezoelectric micromachined ultrasound transducer (PMUT) arrays on stainless-steel substrates was developed. Devices were fabricated using chemical solution deposition of a 700 nm-thick layer of Pb_0.99□_0.01(Zr_0.52Ti_0.48)Nb_0.02O₃, where □ denotes a vacancy on the Pb site, on 50 μm-thick LaNiO₃/HfO₂/stainless-steel foils. Lithography for definition of the electrode and piezoelectric layers was completed on the front of the wafer. Ni electroplating on the back side of the foil was used to create locally stiff areas to define the deflection area. PMUT devices were successfully fabricated using this method. The permittivity and loss tangent of the fabricated device at 1 kHz were 283 ± 9 and <1.5%, respectively. The remanent polarization was measured to be 38 ± 0.3 μC/cm². Full article

This study experimentally investigates a compact side-exhaust piezoelectric synthetic jet actuator equipped with outlet flaps and compares its performance with a flap-free baseline design. The flap concept is intended to mitigate hot-air recirculation during the suction phase and thereby improve near-field cooling in confined layouts. Experiments were conducted under a 350 Hz, 60 Vpp driving signal with an exit dimension of 20 mm × 1 mm. An initial screening campaign evaluated 24 flap configurations by varying flap length, thickness, and installation distance; the results showed that overly long flaps impose substantial blockage and momentum loss, and therefore the flow analysis was narrowed to a practical flap length of 29.5 mm. The final velocity characterization focuses on two representative flap thicknesses (0.1 mm and 0.5 mm) and three installation distances (5, 10, and 15 mm from the exit). For heat transfer evaluation, the nozzle-to-target spacing was varied from 5 to 50 mm in 5 mm increments. The modified actuator demonstrates improved near-field cooling performance, with the best case achieved using 0.1 mm flaps installed at 5 mm, yielding a maximum Nusselt number enhancement of 6.24% relative to the baseline at very small spacings. Furthermore, the thermal benefit becomes more pronounced at elevated heat source temperatures, with the strongest improvement observed around 60–80 °C (up to ~13% at 60 °C). These results provide practical design guidance for enhancing localized convective heat transfer in compact electronics cooling applications. Full article

High-strength bolted connections are fundamental load-bearing components in critical engineering infrastructures such as wind turbines, bridges, and heavy machinery. Under complex service environments involving dynamic loading, vibration, corrosion, and temperature variations, bolts are prone to interacting failure mechanisms, including fatigue fracture, corrosion-assisted cracking, hydrogen embrittlement, and progressive preload loss, which pose significant challenges for reliable condition monitoring and early fault diagnosis. This review provides a structured synthesis of recent advances in bolt health monitoring and intelligent fault diagnosis. A unified framework is established to link multi-physics failure mechanisms with multi-modal sensing technologies and data-driven diagnostic methods. Key sensing approaches—such as piezoelectric impedance techniques, ultrasonic phased array inspection, and computer vision-based monitoring—are critically reviewed in terms of their physical principles, diagnostic capabilities, and limitations. Furthermore, the transition from traditional model-based and signal-processing-driven methods to machine learning- and deep learning-based approaches is examined, with emphasis on multi-modal data fusion, real-time monitoring, and lifecycle-oriented health management enabled by IoT and digital twin technologies. Finally, key challenges and future research directions toward robust and scalable intelligent bolt health management systems are outlined. This review’s primary contribution lies in establishing a novel, integrated framework that links failure physics to sensing and diagnosis, thereby providing a structured roadmap for transitioning from isolated component monitoring to lifecycle-oriented, intelligent health management systems for critical bolted connections. Full article
