Aiming to address the problem of low recognition accuracy in the current cleaning loss detection system of rapeseed harvesters, a rapeseed cleaning loss detection system was developed using the energy distinction method based on the principle of impact piezoelectricity. A signal processing circuit, centered around a hardware integral circuit and a triple voltage comparison circuit, was designed. The energy of the impact signals generated by rapeseed kernels and impurities was calculated through hardware integration. The distinction threshold for the energy of the impact signals generated by kernels and impurities under the operating wind speed of the cleaning system was found through experiments, and a fitting model relating the fan speed to the distinction threshold was constructed. A loss detection and counting system for rapeseed kernels was designed to realize the statistics and real-time display of rapeseed kernels regarding cleaning loss. Performance verification tests were conducted on mixtures of rapeseed kernels and impurities with different mixing ratios, and a field test was carried out on the platform of a 4LZY-5.0Z rapeseed combine harvester. The test results showed that the accuracy of the designed loss detection system for kernel identification was more than 91.6%. Under operating conditions of 700, 900 and 1200 r/min fan speeds in the combine harvester cleaning system, the relative errors of the loss detection system compared to manual detection were 5%, 4.7% and 3.8%, respectively. The developed loss detection system for rapeseed kernels has high detection accuracy and good overall performance, which means it can provide feedback information for the control of the harvester. Full article

Real-time condition monitoring of various types of machinery using sensor technology has gained significant importance in recent years. However, relying on batteries to power these sensors proves to be sub-optimal, as it necessitates regular charging or replacement. To address this, harvesting waste energy from ambient sources emerges as a more efficient alternative. Everyday applications like vehicle wheels, fans, and turbines present ambient sources of waste rotational energy. In this study, we propose a novel rotational energy harvester design that converts rotational energy into linear energy. This linear energy impacts a piezoelectric disk, generating an electric potential. Through simulations, the expected electric potential at varying frequencies was evaluated. Subsequently, experimental tests were conducted by connecting the harvester to a rectifier for AC-to-DC signal conversion and an oscilloscope for voltage measurement. A DC motor replicated the rotational motion at the frequencies from the simulation, and the power output was measured. Using the power transfer theorem, simulation and experimental power outputs were calculated, resulting in values of 188, 513, and 1293 μW and 88.89, 336, and 923 μW, respectively. These results reveal that the designed harvester is competitive with those of existing rotational energy harvester designs, demonstrating the promising potential of this novel harvester. Full article

Human–machine interaction is now deeply integrated into our daily lives. However, the rigidity and high-power supply of traditional devices limit their further development. Herein, a high-performance flexible piezoelectric sensor (HFPS) based on a novel zinc oxide/polyacrylonitrile/Ecoflex (ZnO/PAN/Ecoflex) composite membrane is proposed. Due to the synergistic piezoelectricity of ZnO and PAN, the output voltage/current of the HFPS is increased by 140%/100% compared to the pure Zno/Ecoflex composite membrane. Furthermore, the fabricated HFPSs also have excellent sensitivity, linearity, stability and flexibility under periodic pressure. On this basis, due to its flexibility, stretchability and battery-free characteristics, a self-powered HFPS-based intelligent glove is proposed to wirelessly control diverse electronic systems through human hand gestures. In the meanwhile, the intelligent glove has been successfully applied to car two-dimensional motion, light bulb control and fan control. With the advantages of simple operation, portability and low power consumption, the glove is expected to provide new application prospects for human–machine interaction systems. Full article

There are five closed types of piezo actuators (closed type of PA, closed PA) as a cooling fan relative to those different PAJs of the previous work (open type of PAJ, open PAJ) for analysis in the present study. Closed PA was composed of circular piezoelectric ceramics (PCs) and acrylic (PMMA) plates and investigated on five different types at operating conditions. The results show that the noise of the closed PA is quieter than that of the open PAJ by about 10 dB. When the closed PA is deposed at a suitable distance of 10 to 20 mm from the heat source, averting sucking back the high-temperature fluids around that, the thermal convection coefficient is above 120% more than that of the conventional rotary fan. The cooling performances of these five closed PAs were evaluated by thermal analysis technique, and the convection thermal resistance of the best closed PA can be decreased by over 15%. In terms of energy consumption, a monolithic closed PA was less than 10% than that of a rotary fan. Among these five closed PAs, the best one has the essential qualities that the diameter of the piezoelectric sheet is 41 mm, the opening length is 4 mm, and the outer opening length is 10 mm. Moreover, the best operating conditions are a voltage frequency of 300 Hz and a release distance of 15 mm in the present study. Full article

The piezoelectric (PE) fan is widely adopted in the field of microelectronics cooling due to its advantages of high reliability and good heat dissipation characteristics. However, PE fans driven by conventional circuits suffer from plenty of energy loss. To save energy, we propose an inductor-based charge recovery method and apply it to the driving circuit for the PE fan. Two inductor-based driving circuits, a single inductor-based driving (SID) circuit and a double inductor-based driving (DID) circuit are compared. The SID circuit has a simple structure and a slightly higher energy-saving rate, while the DID circuit introduces no additional oscillations and is more stable. The experimental results show that when the supply voltage changes, both circuits have a relatively stable energy-saving rate, which is about 30% for the SID circuit and 28% for the DID circuit. Moreover, the proposed circuits enjoy the same driving capacity as the conventional circuit, and the driven fan has the same cooling performance. Full article

Piezoelectric fans have started to play an essential role in small-scale heat removal applications in recent years due to their high reliability and efficiency. In this study, an experimental study on the flow field characteristics produced by an oscillating piezoelectric fan at various Reynolds numbers (140 < Re < 550) in a quiescent air environment is investigated. Time resolved particle image velocimetry (PIV) measurements are performed for the flow field visualization. The flow pattern generated by the oscillating fan blade in the longitudinal plane changes as the Reynolds number increases. The ratio between the trailing edge velocity and side edge velocity increases as the Reynolds number increases. As a result, the trailing edge plays a more important role in driving fluid at a higher Reynolds number. Multiple vortexes are shed from the trailing edge during one oscillation cycle and is observed only at a high Reynolds number. This vortex shedding increases the unsteadiness of velocity field significantly, resulting in a turbulence intensity level beyond 100%. This result implies that turbulence models used in numerical studies need to be carefully validated as some might struggle at this highly turbulent flow regime. Full article

A flutter-type, nonlinear piezoelectric energy harvester was tested in various combinations of aerodynamic and harmonic base excitation to study its power output and efficiency. The commercial polyvinylidene fluoride film transducer LDT1-028K was used in 33 excitation mode. The aerodynamic excitation was created by a centrifugal fan and the base excitation by a cone speaker. The excitations were produced by varying independently the mean airflow velocity and the frequency of base vibration. A capacitive load was used to store the harvested energy. A line laser was employed along with long exposure photography and high-speed video, for the visualization of the piezo film’s mode shapes and the measurement of maximum tip deflection. The harvested power was mapped along with the maximum tip deflection of the piezo-film, and a process of optimally combining the two excitation sources for maximum power harvesting is demonstrated. The energy conversion efficiency is defined by means of electrical power output divided by the elastic strain energy rate of change during oscillations. The efficiency was mapped and correlated with resonance conditions and results from other studies. It was observed that the conversion efficiency is related to the phase difference between excitation and response and tends to decrease as the excitation frequency rises. Full article

The present study utilizes an acrylic (PMMA) plate with circular piezoelectric ceramics (PC) as an actuator to design and investigate five different types of piezo actuation jets (PAJs) with operating conditions. The results show that the heat transfer coefficient of a device of PAJ is 200% greater than that of a traditional rotary fan when PAJ is placed at the proper distance of 10 to 20 mm from the heat source, avoiding the suck back of surrounding fluids. The cooling effect of these five PAJs was calculated by employing the thermal analysis method and the convection thermal resistance of the optimal PAJ can be reduced by about 36%, while the voltage frequency, wind speed, and noise were all positively correlated. When the supplied piezoelectric frequency is 300 Hz, the decibel level of the noise is similar to that of a commercial rotary fan. The piezoelectric sheets had one of two diameters of 31 mm or 41 mm depending on the size of the tested PAJs. The power consumption of a single PAJ was less than 10% of that of a rotary fan. Among the five types of PAJ, the optimal one has the characteristics that the diameter of the piezoelectric sheet is 41 mm, the piezoelectric spacing is 2 mm, and the length of the opening is 4 mm. Furthermore, the optimal operating conditions are a voltage frequency of 300 Hz and a placement distance of 20 mm in the present study. Full article

Three-phase induction motors (TIMs) play a key role in industrial production lines. Due to their robustness and versatility, TIMs are commonly used to drive different devices like fans, conveyors, sieves, and compressors. However, these devices are often exposed to mechanical and electrical faults. Among them, failures in stator winding insulation lead to severe damage to the TIMs and can cause operational interruptions. Therefore, several approaches have been developed to monitor electrical faults in induction motors. The acoustic emission (AE) stands out as an efficient non-invasive technique (NIT) for TIM diagnosis. In this work, the AE analysis was applied to detect winding insulation faults and identify which electrical phase was affected. To achieve this proposal, a TIM was subjected to insulation faults in each of the three electrical phases, and the acoustic signals were acquired by four piezoelectric sensors attached to the motor. These signals were processed using a new technique, which calculates the energy of a specific range of the signal spectrum and assigns the energy values of each piezoelectric sensor to a coordinate axis (x, y). By ploting the values for each fault condition, this technique allows the detection of insulation faults and correctly identifies the affected phase by clustering the resulting values. Finally, the proposed methodology presented satisfactory results in winding insulation diagnosis. Full article

Portable ultrasound systems typically suffer from unwanted heat and limited battery life, resulting in reduced system performance or the applicable number of piezoelectric transducer elements. This can be a bottleneck in widely used portable ultrasound systems. Class-A power amplifiers are typically used in portable ultrasound systems. However, unwanted heat dissipation needs to be reduced by using large cooling fans and heat pipe structures. To reduce unwanted heat, class-B power amplifiers may be a possible solution. However, the non-linearity of class-B power amplifiers could limit their integration with piezoelectric transducers because non-linearity in the high-voltage output of the power amplifiers deteriorates the sensitivity of portable ultrasound systems. To improve the linearity of the power amplifier, we developed prelinearized class-B power amplifiers for piezoelectric transducers and portable ultrasound systems. To verify our proposed method, we compared the performances of class-B and prelinearized class-B power amplifiers in their pulse-echo responses. Therefore, prelinearized class-B power amplifiers are a possible solution to produce better echo signal performance in piezoelectric transducers and portable ultrasound systems. Full article

Functionally graded piezoelectric–piezomagnetic (FGPP) material simultaneously consists of piezomagnetic and piezoelectric phases, which are able to convert energy among mechanical, electric, and magnetic fields. The magneto-electric effect on waves in FGPP fan-shaped cylindrical structures is studied by exploiting the double Legendre orthogonal polynomial method. By means of the Heaviside function, the initial conditions are brought into wave motion equations. Dispersion properties, electric and magnetic potential, and the Poynting vector are calculated. Subsequently, the effect of the graded variation and geometric size on wave characteristics is analyzed. The FGPP fan-shaped cylindrical structures are of complex geometrical shape and material inhomogeneity, so their influences on the magneto-electric effect are the focus of discussion. Results reveal that the cut-off frequencies have a negative relationship with the cross-section area of the structure. The magneto-electric effect could be adjusted via altering the geometric size of the cross-section. These results can be utilized to design and optimize piezoelectric–piezomagnetic fan-shaped transducers. Full article

In the last two decades, various flexural plate-wave (FPW)-based biosensors with low phase velocity, low operation frequency, high sensitivity, and short response time, have been developed. However, conventional FPW transducers have low fabrication yield because controlling the thickness of silicon/isolation/metal/piezoelectric multilayer floating thin-plate is difficult. Additionally, conventional FPW devices usually have high insertion loss because of wave energy dissipation to the silicon substrate or outside area of the output interdigital transducers (IDTs). These two disadvantages hinder the application of FPW devices. To reduce the high insertion loss of FPW devices, we designed two focus-type IDTs (fan-shaped and circular, respectively) that can effectively confine the launched wave energy, and adopted a focus-type silicon-grooved reflective grating structure (RGS) that can reduce the wave propagation loss. To accurately control the thickness of the silicon thin-plate and substantially improve the fabrication yield of FPW transducers, a 60 °C/27 °C two-step anisotropic wet etching process was developed. Compared with conventional FPW devices (with parallel-type IDTs and without RGS), the proposed FPW devices have lower insertion loss (36.04 dB) and higher fabrication yield (63.88%). Furthermore, by using cystamine-based self-assembled monolayer (SAM) nanotechnology, we used the improved FPW device to develop a novel FPW-based carcinoembryonic antigen (CEA) biosensor for detection of colorectal cancer, and this FPW-CEA biosensor has a low detection limit (5 ng/mL), short response time (<10 min), high sensitivity (60.16–70.06 cm²/g), and high sensing linearity (R-square = 0.859–0.980). Full article

Heat dissipation per unit volume has grown rapidly, as the size of modern electronic devices has continued to decrease. The air flow induced by an oscillating cantilever blade enhances the heat transfer performance of high heat density devices. The heat transfer improvement mainly depends on the velocity magnitude and distribution of air streams induced by the vibrating blade. Accordingly, this study numerically and experimentally examines the time-varying flow characteristics of a vibrating cantilever for five blade types. The blades are rectangular or trapezoidal with various widths and actuated at various frequencies. The fluid domain is numerically discretized using a dynamic meshing scheme to model the three-dimensional time-varying vibrating blade. The experiment utilizes nine hot-wire velocity meters to measure the average velocities. The flow structure with streamlines and velocity contours of the induced air flow are determined at various section planes. The results show that a major maximum-velocity region appears around the blade tip and that four minor local-maximum-velocity regions appear at the four corners. In addition, the width and width ratio of the blade significantly affects the velocity distribution of the flow induced by the vibrating cantilever blade. Full article
