Elastomer-based nanocomposites combining polymer flexibility with conductive nanofillers provide lightweight, stretchable systems with tunable electromechanical properties for wearable electronics, soft robotics, and self-powered sensors. However, predicting their nonlinear response remains challenging because the observed piezoelectric-like response arises from strain-dependent interfacial polarization and evolving piezoresistive conduction pathways within heterogeneous microstructures. We introduce a continuum electro-hyperelastic framework combining the Mooney–Rivlin model for large-strain elasticity with a Helmholtz free-energy approach for electrostatic coupling. Analytical expressions for stress, electric displacement, and apparent piezoelectric coefficients are derived and implemented in finite element simulations. The model accurately reproduces the experimental mechanical, dielectric, and electromechanical behaviour of polydimethylsiloxane (PDMS) nanocomposites with 0.1–1 wt% graphene. These show increased stiffness, relative permittivity (from 3.4 to 4.0, ≈18%), and quasi-static d₃₃ coefficients (from −5.6 to −10.0 pC N⁻¹, ≈80% enhancement). Analytical and finite element method (FEM) results show consistent trends across the full deformation range, with Maxwell stress agreement within 10% at lower deformation levels, while deviations of 33–40% for coupled electromechanical quantities at an axial displacement u_z = ~−1 mm (~16.7% compressive strain) are attributable to three-dimensional shear effects absent from the uniaxial analytical assumption. Simulations reveal that graphene boosts Maxwell stress, yielding a four-fold increase at lower stretch ratios. This reframes PDMS–graphene composites as electro-hyperelastic materials, offering a predictive, extensible framework. It highlights apparent piezoelectricity as an emergent, tunable effect from charge redistribution in a compliant hyperelastic matrix—guiding the design of next-generation flexible devices leveraging field-induced coupling over intrinsic polarization. Full article

Bio-inspired engineering draws on principles refined by natural evolution to tackle persistent challenges in fluid mechanics, structural dynamics, and thermal transport. This article presents a critical, mechanism-driven narrative review that integrates recent advances across three complementary domains that are often treated independently, namely: flow-control strategies such as leading-edge tubercles, alula-like devices, riblets, superhydrophobic skins, and hybrid low-Reynolds-number fliers; fluid-structure interactions inspired by aquatic and aerial organisms that leverage compliant foils, flexible filaments, ciliary arrays, and piezoelectric fluttering plates for propulsion, wake regulation, mixing, and energy harvesting; and phase-change heat-transfer surfaces modeled after stomata, porous biological networks, and textured cuticles that enhance nucleation control, liquid replenishment, and droplet or bubble removal. Rather than providing an exhaustive catalog of biological analogues, this review emphasizes the underlying physical mechanisms that link these domains and enable multifunctional performance. These developments reveal shared physical principles, including multiscale geometry, capillary- and vortex-mediated transport, and compliance-enabled flow tuning, which motivate the integrated treatment of aerodynamic, hydrodynamic, and thermal systems in applications spanning aerospace, energy conversion, and microscale thermal management. The review assesses persistent challenges associated with scaling biological architectures, ensuring long-term durability, and modeling tightly coupled fluid-thermal-structural interactions. By synthesizing insights across flow control, fluid-structure interaction, and phase-change heat transfer, this review provides a unifying conceptual framework that distinguishes it from prior domain-specific reviews. Emerging opportunities in hybrid multi-mechanism designs, data-driven optimization, multiscale modeling, and advanced fabrication are identified as promising pathways to accelerate the translation of biological strategies into robust, multifunctional thermal–fluid systems. Full article

A compliant parallel multi-directional piezoelectric vibration energy harvester (C-MVEH) is proposed based on a 3-RRR compliant parallel mechanism. The energy harvester structure consists of three identical L-shaped beams, whose bending deformation can be equivalent to the rotations of the three joints. In order to achieve greater bending deformation for composite beams, motion flexibility optimization of the mechanism theory is applied to structure the synthesis of the C-MVEH. Meanwhile, to reduce the natural frequencies corresponding to the working modes, the length of the elastic beam is optimized with the maximum natural frequency among the first three modes. In order to verify the excellent performance of the C-MVEH, an electromechanical model, finite element simulations, and experimental studies are carried out. Analysis of the studies reveals that the C-MVEH has three resonance peaks of output voltage within a bandwidth of 7–13 Hz and can output a total voltage of at least 20 V under a small excitation of 0.2 g. The energy harvester can achieve multiple peak output voltages under small excitations in different directions and a wide frequency range. With its outstanding stability, the proposed C-MVEH demonstrates considerable application value in the supplying of power to microenergy electronic devices, such as smart sensors and microactuators. Full article

Mitigating hand tremors in surgical applications has a critical role in laser-based medical procedures. We report the development of a proof-of-concept 3 degrees of freedom (DOF) hand vibration compensation device that features a compliant mechanical structure with three stack-type piezoelectric actuators. Inspired by the Stewart-type mobile platform, the system has the capability to manipulate a laser beam in two directions. In the present work, the mechanical part of the device is designed, and its mathematical model is developed. Also, the manufacturing of the proposed platform is presented, and the precision of its parts is assessed. An in-house developed mechanical stand is designed and utilized in order to perform a static analysis of the linkage amplification mechanism. Both a finite element analysis (FEA) and experimental validations of this mechanism are performed. A good match is obtained between the results obtained with the two methods. An analysis of the errors is made in order to assess the mechanical aspects of the platform. The study lays the foundation for the further development of the mechatronic and optical parts of the system, as well as for its miniaturization. Full article

With advancements in small-scale research fields, precision manipulation has become crucial for interacting with small objects. As research progresses, the demand for higher precision in manipulation has led to the emergence of ultrahigh-precision engineering (UHPE), which exhibits significant potential for various applications. Traditional rigid-body manipulators suffer from issues like backlash and friction, limiting their effectiveness at smaller-scale applications. Smart materials, particularly piezoelectric materials, offer promising solutions with their rapid response and high resolution, making them ideal for creating efficient piezoelectric transducers. Meanwhile, compliant mechanisms, which use elastic deformation to transmit force and motion, eliminate inaccuracies induced by rigid-body mechanisms. Integrating piezoelectric transducers and compliant mechanisms into piezoelectric compliant devices enhances UHPE system performance. This paper reviews the recent advances in piezoelectric compliant devices. By focusing on the utilization of piezoelectric transducers and compliant mechanisms, their applications in perception, energy harvesting, and actuation have been surveyed, and future research suggestions are discussed. Full article

In this work, a novel method of viscosity measurement is proposed using a device comprising a compliant mechanism, a vibration source, and a piezoelectric sensor. The vibration source creates linear harmonic vibrations in the compliant mechanism suspended in the liquid, and the acceleration response of the mechanism is measured using the piezoelectric sensor. The vibration source is located in the central mass of the compliant mechanism, which is designed to have the necessary directional stiffness. As the mechanism vibrates, the links in the mechanism undergo damping due to the shearing action of the fluid because of its viscosity. A series of viscosity measurements are carried out with the use of water–glycerol solutions such that the acceleration of the mass is influenced by the fluid’s viscosity. During the working of the device, the mechanism is immersed in the liquid whose viscosity is to be measured. The acceleration response of the mass is recorded as time domain data using NI Lab View hardware and software, which are used to train a machine learning model. Later, a regression-based machine learning model is used for the estimation of dynamic viscosity for the given acceleration input. Experiments are performed with the prototype device using the water–glycerol solution within a viscosity ranging from 10 cP to 60 cP. The proposed sensor can be used for in-line measurements or used as a handheld instrument for quick measurements. The machine learning model achieved a high level of accuracy, evidenced by an R-squared value of 0.99, indicating that it explains 99% of the variance in the data. Full article

At present, a large number of two-degree-of-freedom piezoelectrically driven compliant mechanisms (2-DOF PDCMs) have been widely adopted to construct various elliptical vibration machining (EVM) devices employed in precisely fabricating functional micro-structured surfaces on difficult-to-cut materials, which have broad applications in many significant fields like optical engineering and precision manufacturing. For a higher precision of conventional 2-DOF PDCMs on tracking elliptical trajectories, a novel type of pseudo-decoupling method is proposed based on phase difference compensation (PDC). With finite element analysis (FEA), the dependences of elliptical trajectory tracking precision on PDC angles will then be investigated for optimizing PDC angles under different elliptical parameters. As the modification of the PDC-based method, another type of pseudo-decoupling method will be improved based on elliptical parameter compensation (EPC) for much higher tracking precision, an amplification coefficient and a coupling coefficient will be introduced to mathematically construct the EPC-based model. A series of FEA simulations will also be conducted on a conventional 2-DOF PDCM to calculate the amplification and coupling coefficients as well as optimize the EPC parameters under four series of elliptical parameters. The tracking precision and operational feasibility of these two new pseudo-decoupling methods on four series of elliptical trajectories will be further analyzed and discussed in detail. Meanwhile, a conventional 2-DOF PDCM will be practically adopted to build an experimental system for investigating the pseudo-decoupling performances of an EPC-based method, the input and output displacements will be measured and collected to actually calculate the amplification coefficients and coupling coefficients, further inversely solving the actual input elliptical parameters with EPC. The error distances between the expected and experimental elliptical trajectories will also be calculated and discussed. Finally, several critical conclusions on this study will be briefly summarized. Full article

Energy harvesting technologies and material science has made it possible to tap into the abundant amount of surrounding vibrational energy to efficiently convert it into useable energy providing power to portable electronics and IoT devices. Recent investigations show that the piezoelectric effect is created in cellular polymers called ferroelectrets. These cellular-compliant polymers with polarized pores have a piezoelectric response to generate electrical energy when subjected to mechanical strain or surrounding vibration. It is found that there is a significant difference between ferroelectret polarized cellular polypropylene foam and traditional piezoelectric polymers such as polyvinylidene fluoride (PVDF). The former has approximately ten times higher piezoelectric coefficient than the latter. This means that with an acceleration of 9.81 $\mathrm{m}/{\mathrm{s}}^2$ force on this material, ferroelectrets generate up to 39 (µW/g/${\mathrm{m}\mathrm{m}}^3$) power output. Designing a polypropylene-based piezoelectric energy harvester based on the d33 mode of vibration can be challenging due to several factors, as it requires balancing multiple factors such as mechanical stability, piezoelectric response, circuit topology, electrode size, spacing, placement relative to the piezoelectric material, and so on. This paper proposes the preliminary experimental investigation of ferroelectret cellular polypropylene foam in harvesting performance. Suggestions of different approaches for the structural design of energy harvesters are provided. The vibration-dependent response and generated output are examined concerning pulse or sinusoidal input excitation. The voltage generated for both excitations is compared and suggestions are provided regarding the suitable kind of excitation for the chosen ferroelectret material. Finally, conclusions and prospects for ferroelectret materials used in energy-harvesting applications are given. Full article

The limited degrees of freedom (DOF) and movement form of the compliant vibration-assisted processing device are inherent constraints of the polishing technique. In this paper, a concept of a 3-DOF rotary vibration-assisted micropolishing system (3D RVMS) is proposed and demonstrated. The 3-DOF means the proposed vibration-assisted polishing device (VPD) is driven by three piezo-electric (PZT) actuators. Compared with the current vibration-assisted polishing technology which generates a trajectory with orthogonal actuators or parallel actuators, a novel 3-DOF piezoelectrically actuated VPD was designed to enable the workpiece to move along the rotational direction. Meanwhile, the proposed VPD can deliver large processing stoke in mrad scale and can be operated at a flexible non-resonant mode. A matrix-based compliance modeling method was adopted for calculating the compliance and amplification ratio of the VPD. Additionally, the dynamic and static properties of the developed VPD were verified using finite element analysis. Then, the VPD was manufactured and experimentally tested to investigate its practical performance. Finally, various polished surfaces which used silicon carbide (SiC) ceramic as workpiece material were uniformly generated by the high-performance 3D RVMS. Compared with a nonvibration polishing system, surface roughness was clearly improved by introducing rotary vibration-assisted processing. Both the analysis and experiments verified the effectiveness of the present 3D RVMS for micro-machining surfaces. Full article

Electrical stimulation devices can be used as adjunct therapy to lumbar spinal fusion to promote bone healing, but their adoption has been hindered by the large battery packs necessary to provide power. Piezoelectric composite materials within a spinal interbody cage to produce power in response to physiological lumbar loads have recently been investigated. A piezoelectric macro-fiber composite spinal interbody generated sufficient power to stimulate bone growth in a pilot ovine study, despite fabrication challenges. The objective of the present study was to electromechanically evaluate three new piezoelectric disc composites, 15-disc insert, seven-disc insert, and seven-disc Compliant Layer Adaptive Composite Stack (CLACS) insert, within a spinal interbody, and validate their use for electrical stimulation and promoting bone growth. All implants were electromechanically assessed under cyclic loads of 1000 N at 2 Hz, representing physiological lumbar loading. All three configurations produced at least as much power as the piezoelectric macro-fiber composites, validating the use of piezoelectric discs for this application. Future work is needed to characterize the electromechanical performance of commercially manufactured piezoelectric stacks under physiological lumbar loads, and mechanically assess the composite implants according to FDA guidelines for lumbar interbody fusion devices. Full article

The evolution of microelectronic technologies is giving constant impulse to advanced micro-scaled systems which perform complex operations. In fact, the actual micro and nano Electro-Mechanical Systems (MEMS/NEMS) easily integrate information-gathering and decision-making electronics together with all sorts of sensors and actuators. Mechanical manipulation can be obtained through microactuators, taking advantage of magnetostrictive, thermal, piezoelectric or electrostatic forces. Electrostatic actuation, more precisely the comb-drive approach, is often employed due to its high versatility and low power consumption. Moreover, the device design and fabrication process flow can be simplified by compliant mechanisms, avoiding complex elements and unorthodox materials. A nano-scaled rotary comb drive is herein introduced and obtained using NEMS technology, with an innovative design which takes advantages of the compliant mechanism characteristics. A theoretical and numerical study is also introduced to inspect the electro-mechanical behavior of the device and to describe a new technological procedure for its fabrication. Full article

The response to different force load ranges and actuation at low energies is of considerable interest for applications of compliant and flexible devices undergoing large deformations. We present a review of technological platforms based on nitride materials (aluminum nitride and silicon nitride) for the microfabrication of a class of flexible micro-electro-mechanical systems. The approach exploits the material stress differences among the constituent layers of nitride-based (AlN/Mo, Si ${}_x$ N ${}_y$ /Si and AlN/polyimide) mechanical elements in order to create microstructures, such as upwardly-bent cantilever beams and bowed circular membranes. Piezoresistive properties of nichrome strain gauges and direct piezoelectric properties of aluminum nitride can be exploited for mechanical strain/stress detection. Applications in flow and tactile sensing for robotics are described. Full article
