Topological photonic crystals provide an important platform for robust light transport and light-field manipulation. To meet the demands for developing multifunctional and densely integrated photonic circuits, it is necessary to flexibly control light flow with multi-degrees of freedom while maintaining strong topological protection. In this work, we investigate multifunctional topological photonic crystals based on hybrid topological domain walls, which support valley-polarized chiral edge states (VCES). Based on hybrid domain walls, we design two types of compact topological photonic devices. By exploiting direction-selective coupling between valley edge states (VES) and VCES, we construct nonreciprocal coupled waveguides with a nonreciprocal transmission ratio of 10 dB and output-port isolation ratio of more than 30 dB. Moreover, through different configurations of the direction of external magnetic field, we construct a multi-channel selective routing device that enables the configurable transport of valley-polarized electromagnetic waves among multiple channels. Hybrid topological waveguides provide a foundation for designing novel photonic devices, offering the potential for realizing multifunctional integrated topological photonic networks in both classical and quantum regimes. Full article

Traditional tunable Bragg waveguide grating filters, which rely on thermo-optic or carrier effects, often face limitations such as high energy consumption, low tuning efficiency, and difficulty in achieving independent multi-parameter control. To overcome these bottlenecks, this work proposes a novel optical waveguide filter based on the heterogeneous integration of silicon nitride and the phase-change material Sb₂Se₃. The device leverages the substantial refractive index contrast between crystalline and amorphous states of Sb₂Se₃ to construct a programmable Bragg grating within the thin film layer. This is realized through laser-induced phase transition method, enabling nonvolatile manipulation of the light field. Simulation results indicate that the independent tuning of central wavelength over 19.2 nm range was achieved by adjusting the grating width and ripple width simultaneously. Likewise, the extinction ratio could be independently controlled over 22.3 dB through coordinated adjustments of the grating length and position shift. Beyond its tuning capabilities, the proposed device theoretically exhibits exceptional performance characteristics, including an ultra-low insertion loss of 0.1 dB and strong side lobe suppression. These advantages highlight the potential of this approach to provide a low energy consumption, multifunctional solution for integrated photonic devices, offering a promising pathway for the next generation of programmable photonic integrated circuits. Full article

The rapid growth of artificial intelligence (AI) workloads is reshaping semiconductor design across architecture, interconnect, memory hierarchy, packaging, timing, and design automation. Rather than converging on a single hardware solution, the field is expanding into a heterogeneous ecosystem that includes data-center graphics processing units (GPUs), edge neural processing units (NPUs), and application-specific integrated circuits (ASICs), field-programmable gate array (FPGA)-based and hybrid AI system-on-chip (SoC) platforms, chiplet-enabled systems, and emerging beyond-conventional-silicon approaches such as photonic, neuromorphic, and analog in-memory processors. This paper presents a comprehensive review of AI-on-chip systems from a cross-layer perspective. It examines AI chip architectures and hardware platforms, network-on-chip (NoC) designs for AI communication patterns, and algorithm–hardware co-design methods for model acceleration, including compression, quantization, and sparsity-aware optimization. It also reviews clocking, synchronization, and clock-domain-crossing (CDC) challenges in large heterogeneous systems and chiplets, as well as manufacturing, advanced packaging, and reliability issues, including two-and-a-half-dimensional (2.5D) and three-dimensional (3D) integration, thermal and mechanical constraints, assembly quality, and long-term yield considerations. In parallel, the paper surveys the growing role of AI in chip design itself, covering machine-learning-assisted analysis, Bayesian and reinforcement-learning-based optimization, and the emerging use of large language models (LLMs) and AI agents for register-transfer level (RTL) generation, design-space exploration, and autonomous electronic design automation (EDA) workflows. Finally, it discusses beyond-silicon AI chip directions and the broader economic and industry context shaping cloud, on-premises, and edge deployment. By integrating these topics into a unified framework, this review highlights the key technological drivers, system-level tradeoffs, and future research directions that will define next-generation scalable, reliable, and energy-efficient AI-on-chip systems. Full article

The integration density of photonic integrated circuits is fundamentally limited by evanescent field overlap and subsequent inter-channel crosstalk. Layered transition metal dichalcogenides (TMDCs) bypass these confinement constraints through intrinsic optical birefringence and high refractive indices. Here, we report the near-infrared optical constants and waveguide dispersion of molybdenum diselenide (MoSe₂). Ellipsometry performed on centimeter-scale crystals yields an in-plane refractive index of 4.1–4.7 over 1000–2000 nm, with an extinction coefficient close to the sensitivity limit of the fit away from strong excitonic resonances. To validate the anisotropic dielectric tensor at the device scale, scattering-type scanning near-field optical microscopy (s-SNOM) was utilized to map the propagation of transverse-magnetic modes in 235 nm thick exfoliated flakes. Spatial Fourier analysis of the edge-scattered near-field interference yields effective mode indices that precisely match the modeled dispersion. Using the verified dielectric tensor, finite-element simulations demonstrate that single-mode MoSe₂ waveguides optically outperform equivalent tungsten disulfide (WS₂) benchmarks. The enhanced evanescent field suppression in the claddings of MoSe₂ waveguide increases the coupling length by a factor of 3.5, reducing the required routing pitch and enabling a 12.5% direct increase in on-chip integration density. The results identify MoSe₂ as a high-index anisotropic platform for compact waveguiding in the near-infrared. Full article

Graphene–plasmonic electro–optic (EO) modulators have attracted significant interest for compact and energy-efficient integrated photonic systems due to their electrically tunable optical response and strong light–matter interaction. In this work, an ultra-thin silicon-on-insulator (SOI) graphene–plasmonic slot modulator (G-PSM) is investigated using a combined semi-analytical and numerical framework. The analysis integrates finite-temperature Kubo conductivity modeling, perturbation-based effective-index analysis, overlap-factor evaluation, eigenmode analysis, and full-wave simulations to study the influence of silicon thickness on the EO performance of the proposed structure. The obtained results demonstrate that geometry engineering strongly affects modal confinement, overlap enhancement, effective-index perturbation, transmission characteristics, extinction ratio (ER), insertion loss (IL), energy-per-bit consumption, and EO bandwidth. Under optimized operating conditions, the proposed G-PSM achieves an effective refractive-index variation of approximately $3.1\times {10}^{-3}$, an ER of approximately 3.5 dB, an IL of 1.5–2 dB, an energy-per-bit consumption of approximately 7.5 fJ/bit, and a 3 dB EO bandwidth approaching 200 GHz. Strong electromagnetic confinement is achieved inside the plasmonic slot region near the graphene-active layer, enabling efficient electro–absorptive and electro–refractive modulation. Excellent agreement between the semi-analytical calculations and numerical simulations validates the developed framework and confirms the suitability of the proposed ultra-thin SOI G-PSM for compact broadband EO modulation in future integrated photonic systems. Full article

Fiber optic gyroscopes (FOGs) are core sensors in inertial navigation systems, and their miniaturization and integration are currently hot research topics. This work presents an FOG system driven by a silicon photonics integrated circuit (PIC). The PIC, based on a 90 nm silicon-on-insulator (SOI) process, integrates core components such as polarizers, 3 dB couplers, and phase modulators within a compact footprint of 3 × 0.45 mm². These components exhibit excellent performance over a wide spectral range and play a crucial role in high-performance FOG systems. Experimental results show that the proposed FOG system can definitively measure the small angular velocity of the Earth’s rotation (±7.5 °/h). Further Allan variance analysis reveals that the FOG system has an angular random walk (ARW) of 0.00358 °/h^1/2 and a bias instability (BIS) of 0.1185 °/h. These results demonstrate the application potential of silicon photonics-based FOG systems. Full article

We present a family of compact, programmable wavelength demultiplexers enabled by an etchless silicon nitride platform integrated with the low-loss phase-change material Sb₂Se₃. Using topology optimization (LumOpt) with a p-norm (p = 2) figure-of-merit defined over a 10 nm bandwidth, we design several devices within a common 24 × 24 μm² design region: single-wavelength routers (1530, 1550, 1570, 1590 nm), two-channel (1550/1570 nm), three-channel (1530/1550/1570 nm), and four-channel (1530–1590 nm) coarse wavelength-division demultiplexers, all sharing the same input/output waveguide configuration. Simulation results show that all devices achieve low insertion loss at target wavelengths (peak transmission better than −1.21 dB across all channels), high average transmission over the respective 10 nm bands (typically within 0.1 dB of the peak), and suppressed crosstalk (worst case below −11.52 dB). Leveraging the reversible amorphous-to-crystalline phase transition of Sb₂Se₃ via laser pulses, all devices support post-fabrication reconfiguration, overcoming the static functionality of conventional etched photonic circuits. This work establishes a scalable, software-defined platform that combines inverse design and phase-change materials for high-density, reconfigurable wavelength-routing photonic integrated circuits. Full article

Miniaturization of photonic integrated circuits is a long-standing problem in optical engineering. Nowadays, the most promising material platform for integrated photonics are anisotropic van der Waals materials due to overcoming the light diffraction limit. Here, we numerically study V-groove channel waveguides formed in a 50 nm-thick slab of the in-plane hyperbolic in visible and near-infrared ranges of van der Waals material, MoOCl₂. At the telecom wavelength 1550 nm, a channel supports a guided mode with an effective index 1.0206 and a decay length of 13.7 µm. We also design a Mach–Zehnder-type interferometric layout with a maximum splitter angle of approximately 7° for demonstration of a possible practical application in a telecom range and in-plane angular channel modes’ propagation characteristics. We demonstrate that using MoOCl₂ instead of gold leads to a ten-fold reduction in the linear dimensions of the photonic integrated circuit. Therefore, we envision that by combining the extraordinary material properties of MoOCl₂ with the V-shaped geometry of waveguides, one can make the integration density of photonic devices close to that of electronics. Full article

This study evaluates the effect of decorative ceramic screen printing on the optical and photovoltaic performance of glass covers intended for building-integrated photovoltaics (BIPV). Nine ceramic-printed glass samples with different colors and optical densities were compared with a 4 mm Optiwhite reference glass and a bare silicon solar cell. The samples were characterized by UV-VIS-NIR spectrophotometry, energy-dispersive X-ray spectroscopy (EDS), and electrical measurements under simulated AM 1.5G irradiation at 1000 W/m². The optical results showed that the Optiwhite reference provided the highest transmittance, whereas the printed samples exhibited lower transmission, typically in the range of 60–80% in the visible region, depending on the coating type. Among the decorative variants, sample 1 showed the highest transparency, while sample 6 exhibited the lowest transmittance. The spectral behavior of the coated glasses indicates that the ceramic layers modify the photon flux reaching the solar cell through wavelength-dependent absorption and scattering effects. The photovoltaic measurements confirmed a clear relationship between decorative coating and electrical performance. Relative to the Optiwhite-covered reference cell, the printed samples showed power losses ranging from approximately 17% to 32%, with sample 1 achieving the highest maximum power among the decorative variants at 1.41 W, and sample 4 the lowest at 1.16 W. The main electrical effect of the ceramic coatings was a reduction in short-circuit current, whereas the open-circuit voltage remained nearly constant across the tested samples. EDS analysis identified the presence of ceramic-layer constituents associated with silica-, zinc-, titanium-, iron-, cobalt-, aluminum-, and fluorine-containing compounds, supporting the interpretation of vitrified decorative coatings formed during high-temperature processing. Overall, the results demonstrate that decorative ceramic printing can provide a practical compromise between architectural appearance and photovoltaic output when the optical density of the coating is appropriately controlled. Full article

Smart manufacturing, Industry 4.0, and cyber-physical systems (CPSs) require sensing architectures capable of resolving both spatially distributed asset behavior and highly localized process states. This review examines optical fiber sensors (OFSs) and integrated photonic sensors for industrial monitoring through a deployment-oriented, multi-scale perspective. The discussion covers five major application regimes: continuous infrastructure surveillance, structural health monitoring (SHM) of load-bearing composites, dynamic condition monitoring of machinery, in situ observability in advanced manufacturing, and localized chemical or gas sensing. Extended fiber-optic networks, including distributed fiber-optic sensing (DFOS) based on Rayleigh, Raman, and Brillouin scattering, together with multiplexed fiber Bragg grating (FBG) sensors, provide passive, embeddable, and remotely interrogated monitoring for large-scale assets and harsh environments. Photonic integrated circuits (PICs) shift transduction to compact node-level devices for localized thermal, mechanical, refractive-index, absorption, vibration, and inertial measurements, while plasmonic and dielectric nanophotonic sensors extend optical monitoring toward surface-selective and chemically specific detection. Across these platforms, digital signal processing (DSP), machine learning (ML), sensor fusion, and digital-twin (DT) coupling are treated as artificial-intelligence-enabled (AI-enabled) layers for signal recovery, inverse mapping, uncertainty reduction, and predictive maintenance. The review argues that scalable industrial adoption is less limited by sensing physics than by the complete deployment chain: packaging, fiber–chip interfacing, calibration stability, interrogation robustness, and AI-enabled data interpretation. This manuscript is structured as a deployment-oriented narrative review of optical fiber and integrated photonic sensors for industrial monitoring and smart manufacturing. Full article

As silicon photonics technology advances toward high-density integration scenarios—such as large-scale matrices, optical phased arrays, and optical neural networks—single-layer waveguide routing encounters severe topological challenges, rendering waveguide crossings indispensable fundamental components for constructing complex on-chip interconnect networks. As photonic hubs bridging distinct functional regions, the insertion loss, crosstalk, and bandwidth of these crossings directly dictate the signal integrity and transmission capacity of optical links. This paper systematically reviews recent research progress and key technologies concerning silicon-based waveguide crossings. Initially, the mechanism of scattering loss in direct crossings is elucidated, followed by a detailed examination of three mainstream design paradigms for loss mitigation: multimode interference (MMI) structures based on the self-imaging principle, adiabatic transformation structures relying on mode evolution, and medium engineering structures utilizing sub-wavelength gratings and metamaterials. Furthermore, the application of algorithm-driven inverse design in overcoming the constraints of traditional physical configurations is discussed. Crucially, addressing the urgent demand for ultra-high transmission capacity in the post-Moore era, this review highlights functional crossings capable of polarization division multiplexing (PDM) and mode division multiplexing (MDM), analyzing the design challenges and breakthroughs associated with multi-dimensional light field manipulation. Finally, this paper presents prospects for the future development trends of the waveguide crossing junction. Full article

We present a monolithically integrated wavelength meter fabricated on an indium phosphide (InP) platform, suitable for seamless integration with active photonic components such as lasers and optical amplifiers. The device architecture incorporates multiple ring resonators and was realized through a commercial multi-project wafer (MPW) process. Experimental characterization over a 1 nm spectral window using a tunable laser demonstrates the feasibility of the approach and validates the operating principle. Full article

Fiber Bragg Grating (FBG) sensors are widely used for strain and temperature monitoring due to their high sensitivity, compact size, electromagnetic immunity, and multiplexing capability. While conventional FBG interrogators remain bulky and costly, Photonic Integrated Circuit (PIC) platforms provide a promising route toward compact, scalable, and low-power FBG interrogation. However, the choice of architecture strongly determines the achievable resolution, bandwidth, multiplexing capacity, and robustness. This review compares on-chip demodulation architectures, evaluating their performance in resolution, bandwidth, and interrogation speed. We show that the optimal architecture depends strongly on the application: AWG-based schemes excel in compact, multi-FBG readout; ring-resonator systems are highly effective for tunable filtering; and interferometric phase-domain schemes offer the highest sensitivity for dynamic strain sensing. Despite these architectural advances, practical deployment remains constrained by system-level bottlenecks. These challenges primarily include source/detector integration, fiber–chip coupling, packaging robustness, and thermal drift. Overcoming these barriers requires a shift in future development from isolated photonic-device optimization toward comprehensive, system-level co-design. Full article

Ultrafast physical random bit generators (PRBGs) are essential components for modern applications in secure communication, quantum cryptography, encrypted optical fiber sensing and artificial intelligence. While optical chaos-based PRBGs offer high-speed capabilities, conventional systems often rely on discrete components that suffer from system complexity and environmental instability. This paper proposes and experimentally demonstrates a robust, integrated solution using a two-section mutual injection DFB laser. The device was fabricated using the reconstruction equivalent chirp (REC) technique, which provides precise control over grating phase variation while utilizing low-cost, high-volume fabrication methods. The laser sections, each measuring 450 μm in length, were designed with a free-running wavelength difference of 0.3 nm to ensure a flat optical spectrum and enhanced chaotic dynamics. By optimizing the bias currents, we achieved a chaos RF bandwidth of 20.1 GHz. Notably, the resulting chaotic signal lacks time-delayed signatures, which simplifies the randomness extraction process. To generate random bits, the chaotic waveform was sampled by an 8-bit analog-to-digital converter at 100 GSa/s. Following post-processing through delay-subtracting and the extraction of the four least significant bits (4-LSBs), we realized a total physical random bit rate of 400 Gb/s. The randomness of the generated sequence was successfully verified using the NIST SP 800-22 statistical test suite. This approach offers a compact, energy-efficient, and high-performance integrated chaotic source suitable for secure communication and high-performance computation. Full article

Wafer-level testing of Photonic Integrated Circuits (PICs) represents a critical throughput bottleneck in silicon photonics manufacturing, particularly as co-packaged optics demand testing of thousands of optical I/O per wafer. This work introduces optimized alignment algorithms for the Technoprobe Eclipse Dynamic probe card system, which integrates electrical probes and a piezoelectrically actuated fiber array unit within a single probe head, eliminating external positioning equipment. We systematically evaluate seven alignment algorithms: Reference Coarse Scan, Reference Coarse+Fine Scan, Cross Scan, Local and Global Bayesian Optimization, Variable and Fixed Gradient Ascent. The evaluation is made across 72 simulated test cases derived from eight experimental datasets through systematic spatial windowing, combined with experimental validation. Performance is assessed under four operating regimes—high-speed (HS) and low-speed (LS) operation, each with or without hysteresis compensation (H/NH). Experimental validation across eight die positions confirms 100% success rate for both Local Bayesian (98.24% accuracy in 99.87 arbitrary units (a.u.)) and Fixed Gradient (99.18% accuracy in 154.01 a.u.) baseline algorithms. Comprehensive simulation results with improved algorithms across all four scenarios reveal distinct performance characteristics. Fixed Gradient achieves the highest reliability (95.8%) with 99.4% average accuracy across all operating conditions. Variable Gradient provides the fastest alignment (1.18 a.u. in HS-NH) with 90.3% reliability. Local Bayesian demonstrates 94.4% reliability with intermediate performance. Global Bayesian Optimization achieves the best sample efficiency (average 24 steps) but exhibits scenario-dependent reliability ranging from 88.9% (HS-H, LS-H) to 93.1% (LS-NH). For the ideal production scenario, high speed with effective hysteresis compensation (HS-NH), Fixed Gradient emerges as the optimal choice, delivering 95.8% reliability with 1.44 a.u. alignment time, resulting in the best success rate while being nearly as fast as the fastest method. Variable Gradient achieves the absolute fastest alignment (1.18 a.u.) but with 5.5% lower reliability (90.3%), making it suitable only for applications tolerating higher failure rates. Under realistic production conditions with uncompensated hysteresis (HS-H), Fixed Gradient maintains its advantage (95.8% reliability, 3.32 a.u.), while Global Bayesian degrades significantly (88.9% reliability, 4.29 a.u.). Statistical analysis using data profiles validates these methods for high-volume PIC manufacturing, with the Eclipse Dynamic system demonstrating per-die optical alignments in sub-second timescales using open-loop control hardware. Full article
