To improve maneuverability, the focus of photoelectric theodolites is on reducing the weight of the primary mirror and enhancing its optical performance. This study uses MOAT and Sobol methods to identify key parameters that affect design. Using the high-sensitivity part as the optimization domain, six optimization results were obtained based on the multi-objective SIMP topology optimization method and synthesized into a compromise optimization structure. The performance of the mirror before and after optimization was compared on the opto-mechanical–thermal level. Modal analysis shows the optimized structure has a first natural frequency of 716.84 Hz, indicating excellent stiffness and avoiding low-frequency resonance, with a 30.37% weight reduction. Optical performance is also improved, with a 6 μm reduction in the spot diagram radius and an 8.95 nm decrease in RMS. Simulations under real-world conditions show that the lightweight mirror performs better in resisting gravity deformation and maintaining imaging quality. At maximum thermal deformation, the spot diagram radius of the optimized mirror is 1521.819 μm, with only a 0.145% difference in imaging quality compared to the original. In conclusion, the optimized structure shows comprehensive advantages. Constructing the optical system components and the real physical environment of the site provides a valuable reference for the optimization and analysis of the mirror. Full article

This study presents a novel approach to address the autonomous stable tracking issue in electro-optical theodolite operating in closed-loop mode. The proposed methodology includes a multi-sensor adaptive weighted fusion algorithm and a fusion tracking algorithm based on a three-state transition model. A refined recursive formula for error covariance estimation is developed by integrating attenuation factors and least squares extrapolation. This formula is employed to formulate a multi-sensor weighted fusion algorithm that utilizes error covariance estimation. By assigning weighted coefficients to calculate the residual of the newly introduced error term and defining the sensor’s unique states based on these coefficients, a fusion tracking algorithm grounded on the three-state transition model is introduced. In cases of interference or sensor failure, the algorithm either computes the weighted fusion value of the multi-sensor measurement or triggers autonomous sensor switching to ensure the autonomous and stable measurement of the theodolite. Experimental results indicate that when a specific sensor is affected by interference or the off-target amount cannot be extracted, the algorithm can swiftly switch to an alternative sensor. This capability facilitates the precise and consistent generation of data, thereby ensuring the stable operation of the tracking system. Furthermore, the algorithm demonstrates robustness across various measurement scenarios. Full article

Station arrangement optimization of photoelectric theodolites in shooting ranges presents a non-convex and non-linear problem, and the method required to seek the global optimal solution remains an open question. This paper proposes an efficient traversal algorithm that could solve this problem by utilizing discretization of regions with a finite length of mesh, in which both the terrain of the station arrangement region and the observation airspace region are discretized through triangulation. To enhance the computational efficiency of the traversal algorithm, two strategies are employed to speed up the calculation: reducing the dimension of the observation airspace and using the Euclidean distance matrix to compute the intersection angle. After the global optimal solution with discrete finite precision was obtained through the traversal algorithm, it was then used as the initial points for local mesh refinement and to implement gradient-based optimization in order to further improve the precision of the solution. The proposed approach is demonstrated to be practical through application to numerical examples used for the optimization of station arrangements that involve two to four stations. Full article

For photoelectric theodolite, the mirror is the core optical component, so it is of great significance to design and optimize a mirror with excellent overall performance. In order to comprehensively consider the contradictory objectives of mass, natural frequency, and RMS under gravity, a multiobjective optimization method based on the performance analysis of two-parameter coupling was proposed. On the basis of the performance law, a suitable solution for balancing multiple objective functions is obtained by introducing manual intervention. The results show that compared with the traditional empirical design of mirrors, the first-order natural frequency, mass, and RMS performance of the optimized mirror are improved by 18.64%, 0.1%, and 15.58%, respectively. The frequency/Mass ratio and 1/(RMS*Mass) ratio are increased by 18.72% and 18.59%, respectively. Its comprehensive performance has been improved. This method is effective and provides a reference for the design of photoelectric theodolite and other mirrors. Full article

In this paper, the experimental modes of a large-scale photoelectric theodolite tracking frame are presented. On the basis of the experimental data and the gradient-less optimization approach, the modeling strategy and the parameterized equivalent dynamic finite element model are presented. Shafting, three-point leveling units, and other components are reasonably simplified during the modeling process. Influence factors such as contact stiffness are introduced as dynamic parameters in the model. The optimized parametric model obtained demonstrates that the linearization modeling strategy represents the dynamic response characteristics of this type of structure accurately. The maximum relative error of the first four-order natural frequencies between numerical simulation and experimental data is 4.45% when the consistency of mode shapes is taken into account. The research results in this paper can provide engineering guidance for the dynamic stiffness optimization design of the large-scale photoelectric theodolite tracking frame. Full article

To address the limitation of the existing UAV (unmanned aerial vehicles) photoelectric localization method used for moving objects, this paper proposes an improved two-UAV intersection localization system based on airborne optoelectronic platforms by using the crossed-angle localization method of photoelectric theodolites for reference. This paper introduces the makeup and operating principle of intersection localization system, creates auxiliary coordinate systems, transforms the LOS (line of sight, from the UAV to the target) vectors into homogeneous coordinates, and establishes a two-UAV intersection localization model. In this paper, the influence of the positional relationship between UAVs and the target on localization accuracy has been studied in detail to obtain an ideal measuring position and the optimal localization position where the optimal intersection angle is 72.6318°. The result shows that, given the optimal position, the localization root mean square error (RMS) will be 25.0235 m when the target is 5 km away from UAV baselines. Finally, the influence of modified adaptive Kalman filtering on localization results is analyzed, and an appropriate filtering model is established to reduce the localization RMS error to 15.7983 m. Finally, An outfield experiment was carried out and obtained the optimal results: ${\sigma }_B=1.63\times {10}^{-4}(°)$ , ${\sigma }_L=1.35\times {10}^{-4}(°)$ , ${\sigma }_H=15.8(m)$ , ${\sigma }_{sum}=27.6(m)$ , where ${\sigma }_B$ represents the longitude error, ${\sigma }_L$ represents the latitude error, ${\sigma }_H$ represents the altitude error, and ${\sigma }_{sum}$ represents the error radius. Full article
