Search Results (94)

Photoacoustic (PA) imaging (PAI) holds great promise for non-invasive biomedical diagnostics. However, the efficacy of current contrast agents is often limited by photobleaching, toxicity, and complex synthesis processes. In this study, we introduce a novel, biocompatible PAI contrast agent: a recombinant water-soluble chlorophyll-binding protein (WSCP) from Lepidium virginicum (LvP) reconstituted with chlorophyll a (LvP-chla). LvP-chla exhibits a strong and narrow absorption peak at 665 nm, with a molar extinction coefficient substantially higher than oxyhemoglobin and deoxyhemoglobin, enabling robust signal generation orthogonal to endogenous chromophores. Phantom studies confirmed a linear relationship between PA signal amplitude and LvP-chla concentration, demonstrating its stability and reliability. In vitro cytotoxicity testing using 4T1 cells showed high cell viability at 5 mg/mL, justifying its use for in vivo studies. In vivo experiments with a 4T1 tumor-bearing mouse model demonstrated successful tumor localization following intratumoral injection of LvP-chla, with clear visualization via spectroscopic differentiation from endogenous absorbers at 665 nm and 685 nm. Toxicity assessments, both in vitro and in vivo, revealed no adverse effects, and clearance studies confirmed minimal retention after 96 h. These findings show that LvP-chla is a promising contrast agent that enhances PAI capabilities through its straightforward synthesis, stability, and biocompatibility. Full article

The photoacoustic (PA) method is commonly used in the measurement of trace gas concentration owing to its high accuracy and reliability. However, the conventional PA method is usually used in the gas-phase environment, which leads to a long measurement time and a large equipment volume for the degassing process. In this paper, we report a scheme to measure the acetylene (C₂H₂) concentration from the acetylene–dielectric oil (C₂H₂–Oil) mixed solution without the degassing process. The frequency and intensity distribution of the PA signal in the C₂H₂–Oil mixed liquid is investigated using the finite element method (FEM). Simulation results reveal that the incident light modulation frequency and the geometry size of the PA cell are two core factors to determine the PA signal. Furthermore, a PA sensor system is constructed to measure the concentration of C₂H₂ from the C₂H₂–Oil mixed solution. The measurement results demonstrate that the intensity of the PA signal in the C₂H₂–Oil mixed solution rises mostly linearly with the concentration of C₂H₂ from 0 to 100 mL/L. The Allan variance results from the continuous tests indicate that the measurement limit of the PA sensor system is about 0.2 mL/L. This work points to a novel method for the measurement of the C₂H₂ concentration from the C₂H₂–Oil mixed solution. Full article

Noninvasive blood glucose monitoring is crucial for diabetes management, and photoacoustic spectroscopy (PAS) offers a promising solution by detecting glucose levels through human skin. However, weak acoustic signals in PAS systems require optimized resonator designs for enhanced detection sensitivity. Designing such resonators physically is complex, requiring the precise identification of critical parameters before practical implementation. This study focused on optimizing a T-shaped photoacoustic resonator using finite element modeling in a COMSOL Multiphysics environment. By systematically varying the geometric design parameters of the T-cell resonator, a maximum increase in the pressure amplitude of 12.76 times with a quality factor (Q-factor) of 47.5 was achieved compared to the previously designed reference acoustic resonator. This study took a significant step forward by identifying key geometric parameters that influence resonator performance, paving the way for more sensitive and reliable noninvasive glucose monitoring systems. Full article

This study compares the performance of a quartz tuning fork (QTF) with a highly sensitive ultrasound microphone in the context of acoustic measurements, applying the substitution calibration method. QTF sensors are increasingly used for high-precision tasks due to their sensitivity and stability, while microphones are still the standard in general acoustic measurements. The aim of this study is to evaluate both technologies across several key performance metrics, including linearity of response, sensitivity, noise characteristics, and acoustic detection limit. Which sensor is better suited to which acoustic and physical condition? The results show that QTFs perform exceptionally well in applications requiring high precision, especially in high-frequency and narrow-band measurements. The signal-to-noise-ratio (SNR) of the QTF at its resonance frequency is 14 dB higher than that of the microphone, whereas the detection limit and linearity are comparable. The findings suggest that QTF sensors are particularly advantageous for specialized applications like photoacoustic spectroscopy (PAS). Full article

Photoacoustic (PA) imaging combines optical contrast with ultrasound (US) detection, enabling high-resolution imaging of biological tissues with greater penetration depth than conventional optical techniques. Among its various implementations, photoacoustic microscopy (PAM) achieves micrometer-scale resolution by focusing laser excitation and detecting ultrasonic signals, allowing for the detailed visualization of microvascular structures and fine tissue morphology. Over the last decade, PAM imaging speed has significantly increased by adopting PA scanners that steer optical and acoustic waves. However, these scanners must be placed after focusing optics to co-align the waves on a spot, which creates bent focal lines along the scanning direction and limits the scanning range. To achieve wide-field imaging, various image mosaic algorithms have been applied, but these methods require multiple manual operations, which take more time than the imaging itself. In this study, we developed a wide-field, high-speed scanning acoustic/photoacoustic microscopy (SA/PAM) system equipped with a transparent ultrasound transducer and a moving magnet linear stage, which eliminates the need for complex mosaic algorithms. This system enables wide-field imaging up to 50 × 50 mm² while maintaining high lateral resolution, achieving an imaging speed of 50 Hz in a B-scan image. Through in vivo mouse US/PA imaging, the system demonstrated its capability to visualize blood vessels and organs across the whole body of small animals. These findings suggest that the SA/PAM system is a practical tool for biomedical research, allowing for efficient visualization of vascular networks and anatomical structures in various preclinical studies. Full article

Senescence is an intricate physiological progression that can be instigated by a multiplicity of factors. Aberrant cellular senescence is capable of precipitating a substantial array of diseases. During chemotherapy, drugs typically tend to gradually accumulate in the liver, thereby inducing liver senescence and leading to a successive deterioration in its physiological function. β-galactosidase (β-gal), serving as a significant index in the exploration of senescence, has attracted considerable attention. In this study, a fluorescence/photoacoustic (FL/PA) biomodal probe (Gal-QCS) was developed based on a hemicyanine fluorophore for the imaging of β-gal in the process of drug-induced liver senescence. Gal-QCS demonstrates rapid responsiveness, high sensitivity, and remarkable selectivity in detecting β-gal in aqueous solutions. After incubation with β-gal, the fluorescence signal at 810 nm significantly increases, and concurrently, the photoacoustic signal at 775 nm also exhibits a substantial increment. Upon the induction of cell senescence with camptothecin, Gal-QCS can expeditiously and selectively image senescent cells. Moreover, after administering this probe to mice with liver senescence, the FL/PA signals in the livers of senescent mice were enhanced by 10.53-fold and 1.43-fold, respectively. This work robustly substantiates the potential and application prospects of Gal-QCS in detecting drug-induced liver senescence, with β-gal serving as a biomarker. Full article

Skulls with high optical scattering and acoustic attenuation are a great challenge for photoacoustic imaging for human beings. To explore and improve photoacoustic generation and propagation, we conducted the photoacoustic simulation and image reconstruction of the multi-layer brain model with an embedded blood vessel under different optical source types. Based on the optical simulation results under different types of optical sources, we explored the characteristics of reconstructed images obtained from acoustic simulations with and without skull conditions. Specifically, we focused on the detection of blood vessels and evaluated the image reconstruction features, morphological characteristics, and intensity of variations in the target vessels using optical and acoustic simulations. The results showed that under the initial PA signals, the types of optical source types corresponding to the strongest and weakest photoacoustic signals at different positions within the target region were consistent, while the optical source types were different in the reconstructed images. This study revealed the characteristics of acoustic signal transmission with and without skull conditions and its impact on image reconstruction. It further provides a theoretical basis for the selection of optical sources. Full article

In this study, we explored the structural and chemical modifications of cellulose fibres subjected to chemical and mechanical treatments through an innovative analytical approach. We employed photoacoustic spectroscopy (PAS) and reversed double-beam photoacoustic spectroscopy (RDB-PAS) to examine the morphological changes and the chemical integrity of the treated fibres. The methodology provided enhanced sensitivity and specificity in detecting subtle alterations in the treated cellulose structure. Additionally, we applied Coifman wavelet transformation to the PAS signals, which facilitated a refined analysis of the spectral features indicative of chemical and mechanical modifications at a molecular level. This advanced signal processing technique allowed for a detailed decomposition of the PAS signals, revealing hidden characteristics that are typically overshadowed in raw data analyses. Further, we utilised the concept of energy trap distribution to interpret the wavelet-transformed data, providing insights into the distribution and density of energy states within the fibres. Our results indicated significant differences in the energy trap spectra between untreated and treated fibres, reflecting the impact of chemical and mechanical treatments on the fibre’s physical properties. The combination of these sophisticated analytical techniques elucidated the complex interplay between mechanical and chemical treatments and their effects on the structural integrity and chemical composition of cellulose fibres. Full article

In this work, a miniaturized Y-sphere coupled photoacoustic (YSCPA) sensor is proposed for trace C₂H₂ gas detection. The cavity volume of the designed YSCPA sensor is about 0.7 mL. The finite element method (FEM) has been performed to analyze the comparative performance of the YSCPA sensor and T-type PA sensor, indicating that the first-order resonance frequency (FORF) of the newly proposed YSCPA sensor has been reduced by half while the PA signal has been improved by a factor of 3 compared to the T-type PA sensor. C₂H₂ is employed as a target gas to test the performance of the YSCPA sensor. The experimental test results show that the response time of the gas is 26 s. The minimum detection limit (MDL) reaches 189 ppb at a lock-in integration time of 1 s. By extending the lock-in integration time to 100 s, the MDL of the designed PA sensor is reduced to 18.1 ppb. The designed YSCPA sensor has the advantages of small size, low gas consumption, simple structure, and high sensitivity, which is expected to be an effective solution for rapid and real-time monitoring of dissolved C₂H₂ gas in transformer oil. Full article

Diabetes mellitus is a prevalent disease with a rapidly increasing incidence projected worldwide, affecting both industrialized and developing regions. Effective diabetes management requires precise therapeutic strategies, primarily through self-monitoring of blood glucose levels to achieve tight glycemic control, thereby mitigating the risk of severe complications. In recent years, there have been significant advancements in non-invasive techniques for measuring blood glucose using photoacoustic spectroscopy (PAS), as it shows great promise for the detection of glucose using the infrared region (e.g., MIR and NIR) of light. A critical aspect of this method is the detection of the photoacoustic signal generated from blood glucose, which needs to be amplified through a photoacoustic resonator (PAR). In this work, an overview of various types of PARs used for non-invasive glucose sensing is reviewed, highlighting their operating principle, design requirements, limitations, and potential improvements needed to enhance the analysis of photoacoustic signals. The motivation behind this review is to identify and discuss main parameters crucial to the efficient design of PARs used in non-invasive glucose detection, which will be helpful for furthering the basic understanding of this technology and achieving the highly sensitive PAR required for non-invasive glucose monitoring. Full article

Photoacoustic imaging (PAI) is an emerging hybrid imaging modality that combines high-contrast optical imaging with high-spatial-resolution ultrasound imaging. PAI can provide a high spatial resolution and significant imaging depth by utilizing the distinctive spectroscopic characteristics of tissue, which gives it a wide variety of applications in biomedicine and preclinical research. In addition, it is non-ionizing and non-invasive, and photoacoustic (PA) signals are generated by a short-pulse laser under thermal expansion. In this study, we describe the basic principles of PAI, recent advances in research in human and animal tissues, and future perspectives. Full article

Quartz-Enhanced Photoacoustic Spectroscopy (QEPAS) is a technique in which the sound wave is detected by a quartz tuning fork (QTF). It enables particularly high specificity with respect to the excitation frequency and is well known for an extraordinarily sensitive analysis of gaseous samples. We have developed the first photoacoustic (PA) cell for QEPAS on solid samples. Periodic heating of the sample is excited by modulated light from an interband cascade laser (ICL) in the infrared region. The cell represents a half-open cylinder that exhibits an acoustical resonance frequency equal to that of the QTF and, therefore, additionally amplifies the PA signal. The antinode of the sound pressure of the first longitudinal overtone can be accessed by the sound detector. A 3D finite element (FE) simulation confirms the optimal dimensions of the new cylindrical cell with the given QTF resonance frequency. An experimental verification is performed with an ultrasound micro-electromechanical system (MEMS) microphone. The presented frequency-dependent QEPAS measurement exhibits a low noise signal with a high-quality factor. The QEPAS-based investigation of three different solid synthetics resulted in a linearly dependent signal with respect to the absorption. Full article

Differential photoacoustic spectroscopy (DPAS) cells are usually excited on the first longitudinal ring mode, with a microphone situated in the middle of each of the two resonator tubes. However, it is known from other photoacoustic spectroscopy cell designs that connecting the microphones via a capillary can lead to signal enhancement. By means of finite element method (FEM) simulations, we compared such a photoacoustic spectroscopy (PAS) cell with a capillary to a DPAS cell with a capillary attached to each of the two resonators and showed that the behavior of both systems is qualitatively the same: In both the PAS and the DPAS cell, in-phase and anti-phase oscillations of the coupled system (resonator–capillary) can be excited. In the DPAS cell, capillaries of suitable length also increase the pressure signal at the microphones according to the FEM simulations. For different capillary diameters (1.2 mm/1.7 mm/2.2 mm), the respective optimal capillary length (36–37.5 mm) and signal amplification was determined (94%, 70%, 53%). According to the results of these FEM simulations, a significant increase in sensitivity can, therefore, also be achieved in DPAS cells by expanding them with thin tubes leading to the microphones. Full article

Photoacoustic imaging (PAI) is a rapidly developing biomedical imaging technology. Linear array-based photoacoustic tomography (LA-PAT) is one of the most popular configurations of cross-sectional PAI due to its simplicity and clinical translatability. However, when using an optical fiber for LA-PAT, the optical beam shape is deformed due to rapid divergence and, therefore, a larger area on the tissue is illuminated (and the illumination across the linear array is non-uniform), leading to the acquisition of PA signals outside the desired cross-section, which generates artifacts and degrades image resolution. A Powell lens is an optical element that converts a circular beam profile to a nearly linear flat-top profile. In this paper, a Powell lens is used to generate a uniform line illumination scheme that is evaluated with Zemax OpticStudio 2023 R1.02. The system is then characterized experimentally, and the performance is compared with a conventional illumination scheme in LA-PAT. Full article

Indirect photoacoustic sensing (PAS) offers accurate low-ppm gas measurements, with an inverse relation of the obtained signal to the measured gas concentration. The gas is sealed in transistor outline (TO) housing using a new method. This provides a relatively a very small volume for the reference gas signal. The gas sensing system features a black body source, highly reflective measurement volumes and TO housing sealed with gas and multiple sensors. CO₂ is used for testing and characterizing the sensor sealing and working concepts in the measurement range 0–2000 ppm, with other gases, such as CO, methane, etc., planned to be tested. A PAS signal corresponding to a 4 ppm minimum gas concentration is measured. Allan Deviation measurements provide a theoretical limit of detection of 3.14 ppm, with the integration time of 5.2 × 10³ s. Full article
