Search Results (23)

This study investigates the effect of Hull Vane^® on the total resistance and propulsion performance of a patrol vessel using computational fluid dynamics (CFD). Utilizing SHIPFLOW software, multiple simulations were conducted to evaluate how Hull Vane^® position and angle of attack influence hydrodynamic performance. A patrol vessel hull form the MAXSURF’s library was selected to investigate resistance and propulsive performance. Nine (9) configurations (named Cases A to I) of the Hull Vane^® were examined based on variations in longitudinal position and angle of attack. A grid independence study was conducted to determine the optimal mesh configuration. Validation was performed using the Holtrop–Mennen power prediction method and MAXSURF. According to this study, results indicate that Hull Vane^® configurations significantly reduce total resistance and delivered power at higher vessel speeds, with the best improvement in resistance occurring in Case C and in propulsion power in Case B. Propulsive efficiency was maximized in Case E. Furthermore, the study also demonstrates the potential of Hull Vane^® as a practical retrofit for enhancing naval vessel performance and reducing energy consumption. Full article

Few studies have examined Hybrid Aquatic–Aerial Vehicles (HAAVs), autonomous vehicles designed to operate in both air and water, especially those that are aircraft-launched and recovered, with a variable-sweep design to free dive into a body of water and breach under buoyant and propulsive force to re-achieve flight. The novel design research examines the viability of a recoverable sonar-search child aircraft for maritime patrol, one which can overcome the prohibitive sea state limitations of all current HAAV designs in the research literature. This paper reports on the analysis from computational fluid dynamic (CFD) simulations of such an HAAV diving into static seawater at low speeds due to the reverse thrust of two retractable electric-ducted fans (EDFs) and its subsequent breach back into flight initially using a fast buoyancy engine developed for deep-sea research vessels. The HAAV model entered the water column at speeds around 10 ms⁻¹ and exited at 5 ms⁻¹ under various buoyancy cases, normal to the surface. Results revealed that impact force magnitudes varied with entry speed and were more acute according to vehicle mass, while a sufficient portion of the fuselage was able to clear typical wave heights during its breach for its EDF propulsors and wings to protract unhindered. Examining the medium transition dynamics of such a novel HAAV has provided insight into the structural, propulsive, buoyancy, and control requirements for future conceptual design iterations. Research is now focused on validating these unperturbed CFD dive and breach cases with pool experiments before then parametrically and numerically examining the effects of realistic ocean sea states. Full article

Fast patrol boats account for a large number among the numerous vessels used in naval fleets. Owing to their operational characteristics, which involve relatively high speeds, they contribute to emissions significantly. This study presents an optimized design concept for a diesel–battery hybrid electric propulsion system integrated into the general ship design process for fast patrol boats. The optimization design uses mixed-integer linear programming to determine the most eco-friendly shares ratio of battery and diesel usage while satisfying high-endurance operational scenarios. A shares ratio of 1.259 tons of diesel to 2.88 tons of batteries was identified as the most eco-friendly configuration capable of meeting a 200-nautical-mile operational scenario at a maximum speed of 35 knots for the selected case study. A quantitative comparison through a global warming potential (GWP) analysis was conducted between conventional diesel propulsion systems and the designed diesel–battery hybrid electric propulsion system, using a life-cycle assessment (LCA) standardized under the ISO framework. The analysis confirmed that the optimized hybrid propulsion system can achieve a GWP reduction of approximately 7–9% compared with conventional propulsion systems. Few studies have applied LCA in this field, and the application of batteries as hybrid secondary energy sources is viable and sustainable for high-endurance scenarios. Full article

The cooperative patrol control of multiple unmanned surface vehicles (Multi-USVs) in dynamic aquatic environments presents significant challenges in global coverage efficiency and system robustness. The study proposes a cooperative patrol control algorithm for multiple unmanned surface vehicles (Multi-USVs) based on a hybrid embedded task state information model and reward reshaping techniques, addressing global coverage challenges in dynamic aquatic environments. By integrating patrol, collaboration, and obstacle information graphs, the algorithm generates kinematically feasible control actions in real time and optimizes the exploration-cooperation trade-off through a dense reward structure. Simulation results demonstrate that the algorithm achieves 99.75% coverage in a 1 km × 1 km task area, reducing completion time by 23% and 74% compared to anti-flocking and partition scanning algorithms, respectively, while maintaining collision rates between agents (CRBAA) and obstacles (CRBAO) below 0.15% and 0.5%. Compared to DDPG, SAC, and PPO frameworks, the proposed training framework (TFMUSV) achieves 28% higher rewards with 40% smaller fluctuations in later training stages. This study provides an efficient and reliable solution for autonomous monitoring and search-rescue missions in complex aquatic environments. Full article

Cell adhesion regulates specific migratory patterns, location, communication with other cells, physical interactions with the extracellular matrix, and the establishment of effector programs. Proper immune control of cancer strongly depends on all these events occurring in a highly accurate spatiotemporal sequence. In response to cancer-associated inflammatory signals, effector immune cells navigating the bloodstream shift from their patrolling exploratory migration mode to establish adhesive interactions with vascular endothelial cells. This interaction enables them to extravasate through the blood vessel walls and access the cancer site. Further adhesive interactions within the tumor microenvironment (TME) are crucial for coordinating their distribution in situ and for mounting an effective anti-tumor immune response. In this review, we examine how alterations of adhesion cues in the tumor context favor tumor escape by affecting effector immune cell infiltration and trafficking within the TME. We discuss the mechanisms by which tumors directly modulate immune cell adhesion and migration patterns to affect anti-tumor immunity and favor tumor evasion. We also explore indirect immune escape mechanisms that involve modifications of TME characteristics, such as vascularization, immunogenicity, and structural topography. Finally, we highlight the significance of these aspects in designing more effective drug treatments and cellular immunotherapies. Full article

The seriousness of vessel air pollution has forced the International Maritime Organization (IMO) to introduce a series of relevant laws and regulations. This paper proposes a monitoring scheme based on the synergistic operation of motherships and UAVs. This scheme innovatively adopts a harbor sea patrol vessel or the other official vessel (mothership) as the mobile power supply base for UAVs and realizes efficient and accurate monitoring of vessel air pollution in the pre-monitored area at sea by carrying multiple UAVs. The focus of this paper is on the path optimization problem for multi-UAV collaboration with mothership (MUCWM) monitoring, where the objective is to minimize the total monitoring time for MUCWM. The following three main aspects are studied in this paper: (1) multi-UAV monitoring path optimization; (2) the collaboration mechanism between the mothership and multiple UAVs; and (3) mothership traveling path optimization. In order to effectively solve the above problems, this thesis constructs a path optimization model for multi-UAV collaborative mothership monitoring of air pollution from vessels in port waters; solves the model using the improved adaptive differential evolution (IADE) algorithm; and verifies the effectiveness of the model and the algorithm by using the position data in the Automatic Identification System (AIS) of vessels in Ningbo Zhoushan Port. Through the performance comparison and sensitivity analysis of the algorithm, it is confirmed that the algorithm can effectively solve the path planning problem of the collaborative operation between the mothership and multiple UAVs. The research results in this paper not only help to reduce the air pollution level of harbor vessels and improve the efficiency of sea cruising but also play an important supporting role in the enforcement of relevant emission regulations. Full article

Thermal simulations have become increasingly popular in assessing energy efficiency and predicting thermal behaviors in various structures. Calibration of these simulations is essential for accurate predictions. A crucial aspect of this calibration involves investigating the influence of meteorological variables. This study aims to explore the impact of meteorological variables on thermal simulations, particularly focusing on ships. Using TRNSYS (TRaNsient System Simulation) software (v17), renowned for its capability to model complex energy systems within buildings, the significance of incorporating meteorological data into thermal simulations was analyzed. The investigation centered on a patrol vessel stationed in a port in Galicia, northwest Spain. To ensure accuracy, we not only utilized the vessel’s dimensions but also conducted in situ temperature measurements onboard. Furthermore, a dedicated weather station was installed to capture real-time meteorological data. Data from multiple sources, including Meteonorm and MeteoGalicia, were collected for comparative analysis. By juxtaposing simulations based on meteorological variables against those relying solely on in situ measurements, we sought to discern the relative merits of each approach in enhancing the fidelity of thermal simulations. Full article

This paper explores the impact of sampling rates during sea trials on the estimation of hydrodynamic parameters in a nonlinear manoeuvring model. Sea trials were carried out using an offshore patrol vessel and test data were collected. A nonlinear manoeuvring model is introduced to characterise the ship’s manoeuvring motion, and the truncated least squares support vector machine is employed to estimate nondimensional hydrodynamic coefficients and their corresponding uncertainties using the 25°–25° zigzag test. To assess the influence of the sampling rates, the training set is resampled offline with 14 sampling rates, ranging from 0.2 Hz to 5 Hz, encompassing a rate 10 times the highest frequency component of the signal of interest. The results show that the higher sampling rate can significantly diminish the parameter uncertainty. To obtain a robust estimation of linear and nonlinear hydrodynamic coefficients, the sampling rate should be higher than 10 times the highest frequency component of the signal of interest, and 3–5 Hz is recommended for the case in this paper. The validation is also carried out, which indicates that the proposed truncated least square support vector machine can provide a robust parameter estimation. Full article

Multiple-input multiple-output (MIMO) radars offer significant advantages over conventional standalone radars in terms of target detection and localization capabilities. However, to fully exploit their potential, such systems require excellent time and phase synchronization among the central unit and the radar heads. Only recently, thanks to microwave photonics (MWP) techniques, it has been possible to develop the first coherent MIMO radar demonstrators. In this paper, a simulation tool in MATLAB programming language is proposed to model coherent MIMO radars based on MWP techniques in maritime surveillance applications. Moreover, a novel approach for estimating the radar cross section of extended maritime targets is presented. The system performance in co-located and distributed MIMO configuration, as well as in single- and multi-band operations, is evaluated by means of relevant key performance indicators (KPIs). Simulations are carried out in two close-to-reality scenarios. In the first, a co-located MIMO radar is mounted on top of a patrolling vessel. In the second, a distributed MIMO radar is deployed inside a port. The proposed KPIs are analyzed in terms of both geometric and frequency diversities of the system, laying the foundations for general system optimization criteria valid in any given surveillance application. Full article

Redundancy in ship systems is provided to ensure operational resilience through equipment backups, which ensure system availability and offline repairs of machinery. The electric power generation system of ships provides the most utility of all systems; hence, it is provided with a good level of standby units to ensure reliable operations. Nonetheless, the occurrence of undesired blackouts is common onboard ships and portends a serious danger to ship security and safety. Therefore, understanding the contributing factors affecting system reliability through component criticality analysis is essential to ensuring a more robust maintenance and support platform for efficient ship operations. In this regard, a hybrid reliability and fault detection analysis using DFTA and ANN was conducted to establish component criticality and related fault conditions. A case study was conducted on a ship power generation system consisting of four marine diesel power generation plants onboard an Offshore Patrol Vessel (OPV). Results from the reliability analysis indicate an overall low system reliability of less than 70 percent within the first 24 of the 78 operational months. Component criticality-using reliability importance measures obtained through DFTA was used to identify all components with more than a 40 percent contribution to subsystem failure. Additionally, machine learning was used to aid the reliability analysis through feature engineering and fault identification using Artificial Neural Network classification. The ANN has identified a failure pattern threshold at about 200 kva, which can be attributed to overheating, hence establishing a link between component failure and generator performance. Full article

The effective defense of sparsely populated border islands, surrounded by a multifaceted sea, against enemy infiltration poses a crucial problem in national defense. One possible solution is to deploy multiple unmanned surface vessels (USVs) to form an intelligent patrol and defense system. With the designated or daily patrols of USVs, we need to allocate target positions in real time to ensure their continuous operation. Currently, the state-of-art methods contain two major problems of target deadlock and local optimization, which limit the efficiency of reaching the target. To this end, we proposed a novel Region-Construction (RECO) method aimed at high-efficiency target allocation. Firstly, a dynamic calculation approach in K value for unsupervised clustering and time factor’s lead-in for Market-Based Mechanism (MBM) method was created to resolve potential target deadlock among USVs. Secondly, we proposed a novel construction strategy in a non-complete graph (NCG) consisting of neighborhood connection and pheromone extension to provide enough feasible nodes for solution searching. Finally, we introduced adjustment of search range and edge weights, and activated node interaction in traditional Ant Colony Optimization (ACO) algorithm in NCG to obtain the optimal combination of each USV’s target allocations. We established a simulation platform with an airborne managing base station and several USVs. The experimental results demonstrated that when the number of USVs was four, the average time for all USVs to reach the target in the RECO method reduced by 10.9% and 7.7% compared to the MBM and ACO methods, respectively. This reduction was 25% and 11.6% for 6 USVs, 25.7% and 21.8% for 8 USVs, 20% and 19% for 10 USVs. It reflects that the proposed RECO allocation method has shown improvements in terms of successfully-assigned USVs’ quantity and operational efficiency, compared to the state-of-art MBM and ACO algorithms. Full article

The patrol boat is one of the critical aspects for archipelago countries, such as Indonesia, to supervise and maintain the sea border. Due to rough sea conditions, the patrol boat could lose its stability due to the loss of a self-righting roll moment in severe waves. One of the most challenging aspects is to ensure the sufficient stability of the patrol boat during rough conditions. Another challenge is to design a boat that has a self-righting moment during rolling in extreme conditions. This paper examines the design of an anti-capsize ship by improving the self-righting moment with different deck houses height. The rough condition is described when the boat experiences a roll angle of 170°. The principal dimensions of the patrol boat, i.e., Lpp, B, H, T, are 13.0 m, 4.2 m, 2.19 m, and 1.15 m, respectively. Four different deck house heights are compared to obtain the best self-righting roll moment with a height increment of 0.1 m. The physical model is implemented with ship model 1:27.4. In addition, computational fluid dynamics (CFD) is also used to support the proof of the existence of the self-righting roll moment. It is revealed that the center of gravity and buoyancy are essential parameters to acquire the self-righting moment. The height of the deckhouse improves the center of the metacenter, which influences the righting arm of ship stability. The results show that our ship design has a self-righting moment during heel at 180°. Full article

This paper presents the proposal for the concept design of hybrid Offshore Patrol Vessels (OPV) that are suitable for countries with budget constraints. Many countries cannot afford two different classes of ships to answer the current civil and military challenges. Therefore, the proposed approach might be the most acceptable solution for these countries. The concept design covers hybrid OPVs that could include traditional navy capabilities such as anti-ship and anti-air warfare in addition to offshore patrol tasks. This enables a hybrid concept design model that incorporates major tasks of both patrol and corvette classes of ships. The solutions are achieved by applying a multi-attribute concept design procedure that was developed earlier for a generic naval vessel design. The procedure is customized to suit this purpose by applying appropriate design variables, parameter space constraints, updated ship propulsion systems, weapons, other equipment, and design requirements i.e., required areas, volumes, and electricity. The results are the Pareto optimal set of solutions that are used as initial designs in the subsequent phases of the design of the hybrid OPV. The earlier developed software named “MonakoPRB” is updated to suit the above-mentioned changes in the design procedure to generate hybrid OPV concept design solutions. Full article

Indonesia is the largest archipelagic country and has the potential to become the world’s maritime axis. Two-thirds of Indonesia’s territory is ocean, with a total coastline of 54,716 km. Therefore, Indonesia must have solid systems and tools to overcome the various threats in the maritime sector. One of the technologies that can be developed to protect Indonesia’s naval territory is fast patrol boats. Indonesia requires efficient patrol boats that can optimally monitor the large Indonesian sea area and various potential threats in the maritime sector. Thus, research on the hydrodynamic criteria for the hull design of patrol boats is fundamental. In this study, we aimed to evaluate the design method based on hydrodynamic characteristics to obtain the primary dimensions and shape of the ship’s hull. We designed and analysed 11 ship models in terms of the following criteria: the resistance, stability, and seakeeping performance. The 11 models included five reference models of patrol boats with varying dimensions and block coefficients between 0.42 and 0.53, three ship models with the regression method with the exact dimensions and block coefficients between 0.45 and 0.46, and three ship models with the scale method with the exact measurements and block coefficients between 0.43 and 0.45. According to the analysis results, the regression method had better total hydrodynamic criteria and greater similarity to the reference vessel. With a shorter processing time, the regression method was more efficient than the scaling method and reference ship. Full article

Identification of parameters involved in the linear response model with high precision is a highly cost-effective, as well as a challenging task, in developing a suitable model for the verification and validation (V+V) of some key techniques for autonomous vessels in the virtual testbed, e.g., guidance, navigation, and control (GNC). In order to deal with this identification problem, a novel identification framework is proposed in this paper by introducing the extended state observer (ESO), and the well-evaluated robust weighted least square support vector regression algorithm (RW-LSSVR). A second-order linear response model is investigated in this study due to its wide use in controller designs. Considering the highly possible situation that only limited states could be measured directly, the required but immeasurable states in identifying parameters contained in the response model are approximately estimated by the ESO. Theoretical analysis of the stability is given to show and improve the applicability of the ESO. Simulation studies based on linear response models with predefined parameter values of a cargo vessel and a patrol vessel maneuvering in an open water area are carried out, respectively. Results show that the proposed approach not only estimates immeasurable states with high accuracy but also ensures good performance on the parameter identification of the response model with very close values to the nominal ones. The proven identified approach is economic because it only requires limited kinds of low-cost sensors. Full article
