Search Results (31)

This study numerically examines laminar natural convection within a square cavity that has a horizontally attached adiabatic fin on its heated vertical wall. The analysis employed the finite element method to investigate how fin position, length, thickness, and thermal conductivity affect heat transfer behavior over a broad spectrum of Rayleigh numbers (Ra = 10 to 10⁶) and Prandtl numbers (Pr = 0.1 to 10). The findings indicate that the geometric configuration and the properties of the fluid largely influence the thermal disturbances caused by the fin. At lower Ra values, conduction is the primary mechanism, resulting in minimal impact from the fin. However, as Ra rises, convection becomes increasingly significant, with the fin positioned at mid-height (Y_fin = 0.5), significantly improving thermal mixing and flow symmetry, especially for high-Pr fluids. Extending the fin complicates vortex dynamics, whereas thickening the fin improves conductive heat transfer, thereby enhancing convection to the fluid. A new fluid-focused metric, the normalized Nusselt ratio (NNR), is introduced to evaluate the true thermal contribution of fin geometry beyond area-based scaling. It exhibits a non-monotonic response to geometric changes, with peak enhancement observed at high Ra and Pr. The findings provide practical guidance for designing passive thermal management systems in sealed enclosures, such as electronics housings, battery modules, and solar thermal collectors, where active cooling is infeasible. This study offers a scalable reference for optimizing natural convection performance in laminar regimes by characterizing the interplay between buoyancy, fluid properties, and fin geometry. Full article

The Reynolds number (Re), introduced in the late 19th century, has become a fundamental parameter in a lot of scientific fields—the main one being fluid mechanics—as it allows for the determination of flow characteristics by distinguishing between laminar and turbulent regimes, or some intermediate stage. Reynolds’ 1895 paper, which decomposed velocity into average and fluctuating components, laid the foundation for modern turbulence modeling. Since then, the concept has been applied to various fields, including external flows—the science that studies friction—as well as wear, lubrication, and heat transfer. Literature research in recent times has explored new interpretations of Re, and despite its apparent simplicity, the precise prediction of Reynolds numbers remains a computational challenge, especially under conditions such as the study of multiphase flows, non-Newtonian fluids, highly turbulent flow conditions, flows on very small scales or nanofluids, flows with complex geometries, transient or non-stationary flows, and flows of fluids with variable properties. Reynolds’ work, which encompasses both scientific and engineering contributions, continues to influence research and applications in fluid dynamics. Full article

Despite non-Newtonian fluids being involved in many industrial processes, e.g., in food and chemical industries, their thermal treatment still represents a significant challenge due to their generally high apparent viscosity and consequent low heat transfer capability. Heat transfer in heat exchangers can be enhanced by passive systems, such as inserts or fins, to promote boundary layer disruption and fluid recirculation. However, most of the existing configurations cannot significantly improve the heat transfer over pressure drops in deep laminar flows. The present paper presents a numerical investigation on non-Newtonian flows passing through the annulus side of a double-pipe heat exchanger with staggered helical fins. The adopted geometry was conceptualized by merging the beneficial effects of swirling flow devices and boundary layer disruption. The numerical results were first validated against analytical solutions for non-Newtonian flows in annuli under a laminar flow regime. The finned geometry was therefore numerically tested and compared with the bare annulus to quantify the resulting heat transfer augmentation. When compared with the bare annuli, the proposed novel geometry greatly enhanced the heat transfer while mitigating friction losses. Full article

Microchannels are widely used across various industries, including pharmaceuticals and biochemistry, automotive and aerospace, energy production, and many others, although they were originally developed for the computing and electronics sectors. The performance of microchannels is strongly affected by factors such as rarefaction and viscous dissipation. In the present paper, a numerical analysis of the performance of microchannels featuring rectangular, trapezoidal and double-trapezoidal cross-sections in the slip flow regime is presented. The fully developed laminar forced convection of a Newtonian fluid with constant properties is considered. The non-dimensional forms of governing equations are solved by setting slip velocity and uniform heat flux as boundary conditions. Model accuracy was established using the available scientific literature. The numerical results indicated that viscous dissipation effects led to a decrease in the average Nusselt number across all the microchannels examined in this study. The degree of reduction is influenced by the cross-section, aspect ratio and Knudsen number. The highest reductions in the average Nusselt number values were observed under continuum flow conditions for all the microchannels investigated. Full article

To study the effects of fluid compressibility on the dynamics of a cavitating vortex street flow in a regime where the vortex shedding frequency increases as a result of the cavitation increase, the cavitating wake behind a wedge was simulated employing both incompressible and compressible solvers. To do this, a compressible cavitation model was implemented, modifying the Zwart-Gerber-Belamri (ZGB) incompressible solver and including a pressure limit and absorbing boundary conditions to prevent a non-physical pressure field. To validate the performance of the compressible model, preliminary simulations were carried out on a 1D Sod cavitating tube and the cavitating vortex shedding behind a circular body at laminar flow conditions. The results of the cavitating wake behind the wedge with the incompressible and the compressible solvers showed similar predictions in terms of pressure, vortex shedding frequency, and instantaneous and average vapor volume fraction profiles. In spite of this, differences were obtained in the energy content of the fluid force fluctuations on the body at higher frequencies, which appear to be better resolved and amplified when the compressibility model is considered. Overall, both solvers provided comparable results in terms of cavitation phenomena that are well aligned with experimental observations. Full article

Pore-scale flow velocity is an essential parameter in determining transport through porous media, but it is often miscalculated. Researchers use a static porosity value to relate volumetric or superficial velocities to pore-scale flow velocities. We know this modeling assumption to be an oversimplification. The variable fraction of porosity conducive to flow, what we define as hydrodynamic porosity, ${\theta }_{mobile}$, exhibits a quantifiable dependence on the Reynolds number (i.e., pore-scale flow velocity) in the Laminar flow regime. This fact remains largely unacknowledged in the literature. In this work, we quantify the dependence of ${\theta }_{mobile}$ on the Reynolds number via numerical flow simulation at the pore scale for rectangular pores of various aspect ratios, i.e., for highly idealized dead-end pore spaces. We demonstrate that, for the chosen cavity geometries, ${\theta }_{mobile}$ decreases by as much as 42% over the Laminar flow regime. Moreover, ${\theta }_{mobile}$ exhibits an exponential dependence on the Reynolds number, Re = $R$. The fit quality is effectively perfect, with a coefficient of determination (R²) of approximately 1 for each set of simulation data. Finally, we show that this exponential dependence can be easily fitted for pore-scale flow velocity through use of only a few Picard iterations, even with an initial guess that is 10 orders of magnitude off. Not only is this relationship a more accurate definition of pore-scale flow velocity, but it is also a necessary modeling improvement that can be easily implemented. In the companion paper (Part 2), we build upon the findings reported here and demonstrate their applicability to media with other pore geometries: rectangular and non-rectangular cavities (circular and triangular). Full article

This paper presents the results of a study on the non-isothermal laminar flow and heat transfer of oil with Newtonian and viscoplastic rheologies. Heat exchange with the surrounding environment leads to the formation of a near-wall zone of viscoplastic fluid. As the flow proceeds, the transformation of a Newtonian fluid to a viscoplastic state occurs. The rheology of the Shvedoff–Bingham fluid as a function of temperature is represented by the effective molecular viscosity apparatus. A numerical solution to the system of equations of motion and heat transfer was obtained using the Semi-Implicit Method for Pressure-Linked Equations (SIMPLE) algorithm. The calculated data are obtained at Reynolds number Re from 523 to 1046, Bingham number Bn from 8.51 to 411.16, and Prandl number Pr = 45. The calculations’ novelty lies in the appearance of a “stagnation zone” in the near-wall zone and the pipe cross-section narrowing. The near-wall “stagnation zone” is along the pipe’s radius from r/R = 0.475 to r/R = 1 at Re = 523, Bn = 411.16, Pr = 45, u₁ = 0.10 m/s, t₁ = 25 °C, and t_w = 0 °C. The influence of the heat of phase transition of paraffinic oil on the development of flow and heat transfer characteristics along the pipe length is demonstrated. Full article

Sedimentation is an important property of colloidal systems that should be considered when designing pharmaceutical formulations. In pharmaceutical applications, sedimentation is normally described using Stokes’ law, which assumes laminar flow of fluid. In this work we studied swelling and hydration of spherical cross-linked amorphous starch microspheres in pure water, solutions of sodium chloride, and in pH-adjusted aqueous solutions. We demonstrated that Reynolds numbers obtained in these experiments correspond to the transition regime between the laminar flow and the turbulent flow and, hence, expressions based on the non-Stokes drag coefficient should be used for calculations of sedimentation velocity from known density or for assessment of density from observed sedimentation velocity. The density of starch microparticles hydrated in water was about 1050 kg/m³, while densities obtained from experiment with other liquids were dependent on the liquids’ densities. The data indicate that the swelling of the cross-linked starch microparticles as characterized by their densities is not sensitive to pH and salt concentration in the studied range of these parameters. Full article

We present the concept and a proof-of-principle experiment for an acoustofluidic single- particle sorter. In a microfluidic channel, a flow profile with the following three parallel fluid domains is generated: buffer fluid in the center and buffer plus particles in the lateral domains. Due to the laminar flow regime present in microfluidics, the particles essentially follow the stream line(s) along the channel. In the spatially confined sorting and detection region, by switching on the standing acoustic wave, particles of interest (POIs) are pushed into the center fluid domain, thus leaving the chip at the center outlet. For particles of non-interest (PONIs), the acoustic region remains silent, so PONIs are not centered and follow their path to the side outlet. Full article

The pipeline flow behavior of suspensions of cellulose nanocrystals (CNCs) was investigated over the CNC concentration range of 0.24 to 3.65 wt% in different diameter pipelines. The CNC suspensions were Newtonian below the CNC concentration of 1 wt%. At higher concentrations, the CNC suspensions were non-Newtonian power-law fluids. For Newtonian CNC suspensions, the experimental friction factor–Reynolds number data were obtained only in the turbulent regime, and the data followed the Blasius equation closely. For power-law CNC suspensions, the experimental data of friction factor–Reynolds number covered both laminar and turbulent regimes. The experimental data followed the friction factor–Reynolds number relationships for power-law fluids reasonably well. Full article

Natural circulation loops are thermohydraulic circuits used to transport heat from a source to a sink in the absence of a pump, using the forces induced by the thermal expansion of a working fluid to circulate it. Natural circulation loops have a wide range of engineering applications such as in nuclear power plants, solar systems, and geothermic and electronic cooling. The Lattice Boltzmann Method was applied to the simulation of this thermohydraulic system. This numerical method has several interesting features for engineering applications, such as parallelization capabilities or direct temporal convergence. A 2D model of a single-phase natural circulation mini-loop with a small inner diameter was implemented and tested under different operation conditions following a double distribution function approach (coupling a lattice for the fluid and a secondary lattice for the thermal field). An analytical relationship between the Reynolds number and the modified Grashof number was used to validate the numerical model. Two regimes were found for the circulation, a laminar regime for low Reynolds numbers and a non-laminar regime characterized by a traveling vortex near the heater and cooler’s walls. Both regimes did not present flux inversion and are considered stable. The recirculation of the fluid can explain some of the heat transfer characteristics in each regime. Changing the Prandtl number to a higher value affects the transient response, increasing the temperature and velocity oscillations before reaching the steady state. Full article

This numerical study investigated the flow-induced vibration (FIV) on non-heated and heated cylinders with different normalized corner radii (r*) at different Reynolds numbers (Re). Four different values of r* were considered (i.e., 0 (square cylinder), 0.5, 0.75, and 1.0 (circular cylinder)) at three different Re: 100, 150, and 200 within the laminar regime. The cylinder constrained in the axial direction and oscillated transversally was considered for a fixed nondimensional cylinder mass $\left(m^{*}\right)$ of 10 and a reduced velocity (Ur) of 4.92. The effect of r* and Re could be seen in the vibration modes of cylinders. The two-dimensional incompressible Navier–Stokes and energy equations were solved together with Newton’s Second Law governing the motion of the cylinder with the help of a computational solver. Four different modes were observed in this study: Mode-I characterized by exceptionally low amplitude; Mode-II characterized by fluctuating amplitude known as hysteresis (beating); Mode-III characterized by high amplitude due to synchronization or lock-in; and Mode-IV characterized by the monotonic oscillation of fixed amplitude. For r* = 1, synchronization phenomenon/lock-in was observed. For the heated cylinder cases, due to the change in the normalized corner radius, a notable change in nondimensional vibrational amplitude $A/D$ and the average Nusselt number $N{u}_{avg}$ was seen. It was observed that A/D was higher when lock-in occurred (at Re = 100 and r* = 1), leading to a rise in $N{u}_{avg}$ by 47.9% compared to Re = 100 and r* = 0. Due to the change in r*, a shifting phenomenon was observed at Re = 150, r* = 0.75 and Re = 200, r* = 1. A major change in $N{u}_{avg}$ was observed from the circular cylinder to square cylinder at different Re. The beating phenomenon was observed at Re = 100 for r* = 0.75, which was similar to that occurring at Re = 150 and r* = 0.5, and those at Re = 200 and r* = 0. Heat transfer and wake structure parameters were found to be dependent on r* and Re. Full article

According to recent investigations on bottom boundary layer development under tsunami, a wave boundary can be observed even at the water depth of 10 m, rather than a steady flow type boundary layer. Moreover, it has been surprisingly reported that the tsunami boundary layer remains laminar in the deep-sea area. For this reason, the bottom boundary layer under tsunami experiences two transitional processes during the wave shoaling: (1) flow regime transition in a wave-motion boundary layer from laminar to the turbulent regime, and (2) transition from non-depth-limited (wave boundary layer) to depth-limited boundary layer (steady flow boundary layer). In the present study, the influence of these two transition processes on tsunami wave height damping has been investigated using a wave energy flux model. Moreover, a difference of calculation results by using the conventional steady flow friction coefficient was clarified. Full article

An analysis of the R134a (tetrafluoroetane) coolant’s non-stationary behavior in rectangular microchannels was conducted with the help of a newly proposed miniature refrigerating machine of our own design and construction. The experimental device incorporated, on the same plate, a condenser, a lamination tube and a vaporizer, all of which integrated rectangular microchannels. The size of the rectangular microchannels was determined by laser profilometry. R-134a coolant vapors were pressurized using a small ASPEN rotary compressor. Using the variable soft spheres (VSS) model, the mean free path, Knudsen and Reynolds numbers, as well as the dimensionless velocity profile can be assessed analytically. In order to determine the average dimensionless temperature drop in the vaporizer’s rectangular microchannels, in non-stationary regime, an analytical solution for incompressible flow with slip at the walls, fully developed flow and laminar regime was used, by aid of an integral transform approach. In the experimental study, the transitional distribution of temperature was tracked while modifying the R134a flow through the rectangular microchannels. Coolant flow was then maintained at a constant, while the amount of heat absorbed by the vaporizer was varied using multiple electric resistors. A comparative analysis of the analytical and experimental values was conducted. Full article

Sheet cavitation inception can be influenced by laminar boundary layer flow separation under Reynolds numbers regimes with transitional flow. The lack of accurate prediction of laminar separation may lead to massive over-prediction of sheet cavitation under certain circumstances, including model scale hydrofoils and marine propellers operating at relatively low Reynolds number. For non-cavitating flows, the local correlation based transition model, $\gamma -R{e}_{\theta }$ transition model, has been found to provide predictions of laminar separation and resulting boundary layer transition. In the present study, the predicted laminar separation using $\gamma -R{e}_{\theta }$ transition model is bridged with a cavitation mass transfer model to improve sheet cavitation predictions on hydrofoils and model scale marine propellers. The bridged model is developed and applied to study laminar separation and sheet cavitation predictions on the NACA16012 hydrofoil under different Reynolds numbers and angles of attack. As a reference case, the open case of the PPTC VP1304 model scale marine propeller tested on an inclined shaft is studied. Lastly as an application case, the predictions of cavitation on a commercial marine propeller from Kongsberg is presented for model scale conditions. Simulations using the bridged model and the standard unbridged approach with $k-\omega SST$ turbulence model are performed using the open-source package OpenFOAM, both using the Schnerr–Sauer cavitation mass transfer model, and the respective results are compared with available experimental results. The predictions using the bridged model agree well compared to experimental measurements and show significant improvements compared to the unbridged approach. Full article
